Ariston FB 83C AUS User manual

FB 83C AUS
FB 83C IX AUS
Contents
Installation, 2-3
Positioning
Electrical connections
Data plate
Description of the appliance, 4
Overall view
Control panel
Start-up and use,
Starting the oven
Cooking modes, 6-7
Cooking modes
Practical cooking advice
Cooking advice table
The electronic cooking programmer, 8
Precautions and tips, 9
General safety
Disposal
Respecting and conserving the environment
Assistance
Maintenance and care, 10
Switching the appliance off
Cleaning the appliance
Cleaning the oven door
Replacing the light b lb
Operating Instructions
OVEN
GB
English,1
GB

2
GB
 Before placing yo r new appliance into operation
please read these operating instr ctions caref lly.
They contain important information for safe se, for
installation and for care of the appliance.
 Please keep these operating instr ctions for f t re
reference. Pass them on to possible new owners of
the appliance.
Positioning
 Keep packaging material o t of the reach of
children.It can become a choking or s ffocation
hazard. (see Precautions and tips).
 The appliance m st be installed by a q alified
person in compliance with the instr ctions provided.
Incorrect installation may ca se harm to persons,
animals or may damage property.
Fitting the appliance
Use the appropriate cabinet to ens re that the
appliance f nctions properly.
 The panels adjacent to the oven m st be made of
heat-resistant material.
 Cabinets with a veneer exterior m st be
assembled with gl es which can withstand
temperat res of p to 100°C.
 to install the oven nder the co nter (see diagram)
and in a kitchen nit, the cabinet m st have the
following dimensions:
 The appliance m st not come into contact with
electrical parts once it has been installed.
The cons mption indications on the data plate have
been calc lated for this type of installation.
Ventilation
To ens re good ventilation, the back panel of the
cabinet m st be removed. It is advisable to install
the oven so that it rests on two strips of wood, or on
a completely flat s rface with an opening of at least
45 x 560 mm (see diagrams).
Centring and fastening
Position the 4 tabs on the side of the oven according
to the 4 holes of the o ter frame. Adj st the tabs
according to the thickness of the cabinet side panel,
as shown below:
thickness of 20 mm: take off
the removable part of the tab
(see diagram)
thickness of 18 mm: se the
first groove, which has already
been set in the factory (see
diagram)
thickness of 16 mm: se the
second groove (see diagram)
Sec re the appliance to the cabinet by opening the
oven door and p tting 4 screws into the 4 holes of
the o ter frame.
! All parts which ens re the safe operation of the
appliance m st not be removable witho t the aid of
a tool.
Installation
595 mm.
595 mm.
24 mm.
545 mm.
5 mm.
567 mm.
23 mm.
593 mm.
45 mm.
558 mm.
547 mm. min.
560 mm.
45 mm.

3
GB
Electrical connections
! Ovens eq ipped with a three-pole power s pply
cable are designed to operate with alternating
c rrent at the voltage and freq ency indicated on
the data plate located on the appliance (see below).
Fitting the power supply cable
1. Open the terminal
board by inserting a
screwdriver into the
side tabs of the cover.
Use the screwdriver as
a lever by p shing it
down to open the cover
(see diagram).
2. Loosen the cable
clamp screw and
remove it, sing a
screwdriver as a lever
(see fig re).
3. Remove the wire
contact screws L-N-
, then fasten the wires
nder the screw heads,
respecting the colo r
code: Bl e (N), Brown
(L) and Yellow-Green
Verde ( ).
Connecting the supply cable to the mains
Install a standardised pl g corresponding to the
load indicated on the data plate (see side).
The appliance m st be directly connected to the
mains sing an omnipolar circ it-breaker with a
minim m contact opening of 3 mm installed between
the appliance and the mains, s itable for the load
indicated and complying with c rrent electrical
reg lations (the earthing wire m st not be interr pted
by the circ it-breaker). The s pply cable m st not
come into contact with s rfaces with temperat res
higher than 50°C.
! The installer m st ens re that the correct electrical
connection has been made and that it is compliant
with safety reg lations.
Before connecting to the power s pply, make s re
that:
 The appliance is earthed and the pl g is
compliant with the law.
 The socket can withstand the maxim m power of
the appliance, which is indicated on the data
plate (see below).
 The voltage m st be in the range between the
val es indicated on the data plate (see below).
 The socket is compatible with the pl g of the
appliance. If the socket is incompatible with the
pl g, ask an a thorised technician to replace it.
Do not se extension cords or m ltiple sockets.
! Once the appliance has been installed, the power
s pply cable and the electrical socket m st be
easily accessible.
! The cable m st not be bent or compressed.
! The cable m st be checked reg larly and replaced
by a thorised technicians only (see Assistance).
! The manufacturer declines any liability should
these safety measures not be observed.
DATA PLATE
Dimensions
width cm 43.5
height cm 32
depth cm 40
Volume lt. 56
Electrical
connections
voltage 240V ~ 50Hz
maximum power absorbed
3000W
ENERGY LABEL
Directive 2002/40/EC o the label
of electric ove s. Norm EN 50304
E ergy co sumptio for Natural
co vectio - heati g mode:
Traditio al mode: =
Declared e ergy co sumptio for
Forced co vectio Class -
heati g mode: K Baki g.
This applia ce co forms to the
followi g Europea Eco omic
Commu ity directives: -
2006/95/EEC of 12/12/06 (Low
Voltage) a d subseque t
ame dme ts;- 89/336/EEC of
03/05/89 (Electromag etic
Compatibility) a d subseque t
ame dme ts;- 93/68/EEC of
22/07/93 a d subseque t
ame dme ts.- 2002/96/EC

4
GB
Description of the
appliance
Overall view
Control panel
Control panel
GRILL
DRIPPING PAN
GUIDES for the
sliding racks
position 5
position 4
position 3
position 2
position 1
MAX
60
0
10 0
220
18 0
14 0
SELECTOR
knob
THERMOSTAT
knob
ELECTRONIC
programmer
THERMOSTAT
indicator light
•• ••

5
GB
! The first time yo se yo r appliance, heat the
empty oven with its door closed at its maxim m
temperat re for at least half an ho r. Ens re that the
room is well ventilated before switching the oven off
and opening the oven door. The appliance may
prod ce a slightly npleasant odo r ca sed by the
b rning away of protective s bstances sed d ring
the man fact ring process.
Starting the oven
1. Select the desired cooking mode by t rning the
SELECTOR knob.
2. Select the desired temperat re with the
THERMOSTAT knob. See the Cooking advice table
for cooking modes and the s ggested cooking
temperat res (see Cooking Modes).
3. When preheating is finished, the THERMOSTAT
indicator light will stay on: place the food in the
oven.
4. Yo may do the following d ring cooking:
- change the cooking mode by t rning the
SELECTOR knob.
- change the temperat re by t rning the
THERMOSTAT knob.
- stop cooking by t rning the SELECTOR knob to the
0 position.
! Never p t objects directly on the oven bottom to
avoid damaging the enamel coating.
! Always place cookware on the rack(s) provided.
Cooling ventilation
In order to cool down the external temperat re of the
oven, some models are fitted with a cooling fan that
blows o t air between the control panel and the oven
door.
! Once the cooking has been completed, the cooling
fan remains on ntil the oven has cooled down
s fficiently.
Oven light
It goes on when selecting with the SELECTOR
knob. It stays on when a cooking mode is selected.
Start-up and use

6
GB
Cooking modes
Cooking modes
! A temperat re val e can be set for all cooking
modes between 60°C and Max, except for
 BARBECUE (recommended: set only to MAX
power level);
 GRATIN (recommended: do not exceed 200°C).
= TRA ITIONAL OVEN mode
Both the top and bottom heating elements will come
on. With this traditional cooking mode, it is best to
se one cooking rack only: if more than one rack is
sed, the heat will be distrib ted nevenly.
K BAKING mode
The rear heating element and the fan come on,
g aranteeing the distrib tion of heat delicately and
niformly thro gho t the oven. This mode is ideal for
baking and cooking temperat re sensitive foods
s ch as cakes that need to rise and to prepare
certain tartlets on 3 shelves sim ltaneo sly.
L FAST COOKING mode
The heating elements and the fan come on,
g aranteeing the distrib tion of heat consistently
and niformly thro gho t the oven.
Pre-heating is not necessary for this cooking mode.
This mode is especially recommended for cooking
pre-packed food q ickly (frozen or pre-cooked). The
best res lts are obtained if yo se one cooking
rack only.
> MULTI-COOKING mode
All the heating elements (top, bottom and circ lar),
as well as the fan, will come on. Since the heat
remains constant thro gho t the oven, the air cooks
and browns food niformly. A maxim m of two racks
may be sed at the same time.
M PIZZA mode
The bottom and circ lar heating elements, as well as
the fan, will come on. This combination heats the
oven rapidly by prod cing a considerable amo nt of
heat, partic larly from the bottom element. If yo
se more than one rack sim ltaneo sly, switch the
position of the dishes halfway thro gh the cooking
process.
@ BARBECUE mode
The top heating element comes on.
The high and direct temperat re of the grill is
recommended for food that req ires high s rface
temperat re. Always cook in this mode with the oven
door closed.
A GRATIN mode
The top heating element, as well as the fan, will
come on. This combination of feat res increases the
effectiveness of the nidirectional thermal radiation
of the heating elements thro gh forced circ lation of
the air thro gho t the oven. This helps prevent food
from b rning on the s rface, allowing the heat to
penetrate right into the food. Always cook in this
mode with the oven door closed.
Practical cooking advice
! Do not place racks in position 1 and 5 d ring fan-
assisted cooking. Excessive direct heat can b rn
temperat re sensitive foods.
! In the BARBECUE and GRATIN cooking modes,
place the dripping pan in position 1 to collect
cooking resid es (fat and/or grease).
MULTI-COOKING
 Use position 2 and 4, placing the food that
req ires more heat on 2.
 Place the dripping pan on the bottom and the rack
on top.
BARBECUE
 Insert the rack in position 3 or 4. Place the food in
the centre of the rack.
We recommend that yo set the maxim m power
level. The top heating element is reg lated by a
thermostat and may not always be on.
PIZZA MODE
 Use a light al mini m pizza pan. Place it on the
rack provided.
For a crispy cr st, do not se the dripping pan
(prevents cr st from forming by extending
cooking time).
 If the pizza has a lot of toppings, we recommend
adding the mozzarella cheese on top of the pizza
halfway thro gh the cooking process.

7
GB
Cooking advice table
Setting made Type of food Weig-
ht (in
kg)
Position of
the rack from
the oven
bottom
Preheating
tim e (m in.)
Thermostat
setting
Cooking
tim e
(m in.)
1 Traditional
=
Duck
Roast veal or beef
Pork roast
Biscuits (short pastry)
Tarts
1
1
1
-
1
3
3
3
3
3
15
15
15
15
15
200
200
200
180
180
65-75
70-75
70-80
15-20
30-35
2 Baking
K
Tarts
Fruit cakes
Plum cake
Sponge cake
Stuffed pancakes (on 2 racks)
Small cakes (on 2 racks)
Cheese puffs (on 2 racks)
Cream puffs (on 3 racks)
Biscuits (on 3 racks)
Meringues (on 3 racks)
0.5
1
0.7
0.5
1.2
0.6
0.4
0.7
0.7
0.5
3
2/3
3
3
2-4
2-4
2-4
1-3-5
1-3-5
1-3-5
15
15
15
15
15
15
15
15
15
15
180
180
180
160
200
190
210
180
180
90
20-30
40-45
40-50
25-30
30-35
20-25
15-20
20-25
20-25
180
3 Fast
cooking
L
Frozen food
Pizza
Courgette and prawn pie
Country style spinach pie
Turnovers
Lasagne
Golden Rolls
Chicken morsels
0.3
0.4
0.5
0.3
0.5
0.4
0.4
2
2
2
2
2
2
2
-
-
-
-
-
-
-
Max
200
220
200
200
180
220
12
20
30-35
25
35
25-30
15-20
Pre-cooked food
Golden chicken wings 0.4 2 - 200 20-25
Fresh Food
Biscuits (short pastry)
Plum cake
Cheese puffs
0.3
0.6
0.2
2
2
2
-
-
-
200
180
210
15-18
45
10-12
4 Mu lti-
cooking
>
Pizza (on 2 racks)
Lasagne
Lamb
Roast chicken + potatoes
Mackerel
Plum cake
Cream puffs (on 2 racks)
Biscuits (on 2 racks)
Sponge cake (on 1 rack)
Sponge cake (on 2 racks)
Savoury pies
1
1
1
1+1
1
1
0.5
0.5
0.5
1.0
1.5
2-4
3
2
2-4
2
2
2-4
2-4
2
2-4
3
15
10
10
15
10
10
10
10
10
10
15
230
180
180
200
180
170
190
180
170
170
200
15-20
30-35
40-45
60-70
30-35
40-50
20-25
10-15
15-20
20-25
25-30
5 Pizza
M
Pizza
Roast veal or beef
Chicken
0.5
1
1
3
2
2/3
15
10
10
220
220
180
15-20
25-30
60-70
6 Barbecue
@
Soles and cuttlefish
Squid and prawn kebabs
Cod filet
Grilled vegetables
Veal steak
Cutlets
Hamburgers
Mackerels
Toasted sandwiches
1
1
1
1
1
1
1
1
n.° 4
4
4
4
3/4
4
4
4
4
4
5
5
5
5
5
5
5
5
5
Max
Max
Max
Max
Max
Max
Max
Max
Max
8-10
6-8
10
10-15
15-20
15-20
7-10
15-20
2-3
7 Gratin
A
Grilled chicken
Cuttlefish
1.5
1.5
3
3
5
5
200
200
55-60
30-35
N.B.: cooking times are approximate and may vary according to personal taste. When cooking using the grill or
gratin, the dripping pan must always be placed on the 1st oven rack from the bottom.

8
GB
The electronic cooking
rogrammer
DISPLAY
SET TIME
button
END OF
COOKING icon
CLOCK icon
DURATION
icon
TIMER icon
DECREASE TIME
button
INCREASE TIME
button
•• ••
Setting the clock
 The clock may be set when the oven is switched
off or when it is switched on, provided that a the end
time of a cooking cycle has not been programmed
previo sly.
After the appliance has been connected to the
mains, or after a blacko t, the icon and the fo r
n merical digits on the DISPLAY will begin to flash.
1. Press the b tton several times ntil the
icon and the fo r digits on the display begin to
flash.
2. Use the + and - b ttons to adj st the time; if
yo press and hold either b tton, the display will
scroll thro gh the val es more q ickly, making it
q icker and easier to set the desired val e.
3. Wait for 10 seconds or press the b tton again
to finalise the setting.
Setting the timer
 This f nction does not interr pt cooking and does
not affect the oven; it is simply sed to activate the
b zzer when the set amo nt of time has elapsed.
1. Press the b tton several times ntil the
icon and the three digits on the display begin to
flash.
2. Use the + and - b ttons to set the desired
time; if yo press and hold either b tton, the display
will scroll thro gh the val es more q ickly, making it
q icker and easier to set the val e.
3. Wait for 10 seconds or press the b tton again
to finalise the setting.
The display will then show the time as it co nts
down. When this period of time has elapsed the
b zzer will be activated.
Programming cooking
 A cooking mode m st be selected before
programming can take place.
Programming the cooking duration
1. Press the b tton several times ntil the
icon and the three digits on the DISPLAY begin to
flash.
2. Use the + and - b ttons to set the desired
d ration; if yo press and hold either b tton, the
display will scroll thro gh the val es more q ickly,
making it q icker and easier to set the val e.
3. Wait for 10 seconds or press the b tton again
to finalise the setting.
4. When the set time has elapsed, the text END
appears on the DISPLAY, the oven will stop cooking
and a b zzer so nds.
For example: it is 9:00 a.m. and a time of 1 ho r
and 15 min tes is programmed. The programme
will stop a tomatically at 10:15 a.m.
Setting the end time for a cooking mode
 A cooking d ration m st be set before the cooking
end time can be sched led.
1. Follow steps 1 to 3 to set the d ration as detailed
above.
2. Next, press the b tton ntil the icon and
the fo r digits on the DISPLAY begin to flash.
3. se the + and - b ttons to adj st the cooking
end time; if yo press and hold either b tton, the
display will scroll thro gh the val es more q ickly,
making it q icker and easier to set the desired
val e.
4. Wait for 10 seconds or press the b tton again
to finalise the setting.
5. When the set time has elapsed, the text END
appears on the DISPLAY, the oven will stop cooking
and a b zzer so nds.
Programming has been set when the and
b ttons are ill minated. The DISPLAY shows the
cooking end time and the cooking d ration
alternately.
Cancelling a programme
To cancel a programme:
 press the b tton ntil the icon corresponding to
the setting yo wish to cancel and the digits on the
display are no longer flashing. Press the - b tton
ntil the digits 00:00 appear on the display.
 Press and hold the + and - b ttons; this will
cancel all the settings selected previo sly,
incl ding timer settings.

9
GB
Precautions and ti s
! The appliance was designed and man fact red in compliance with
international safety standards. The following warnings are provided for
safety reasons and m st be read caref lly.
General safety
 The appliance was designed for domestic se inside the home and is
not intended for commercial or ind strial se.
 The appliance m st not be installed o tdoors, even in covered areas.
It is extremely dangero s to leave the appliance exposed to rain and
storms.
When handling the appliance, always se the handles provided on
the sides of the oven.
 Do not to ch the appliance with bare feet or with wet or moist hands
and feet.
 The appliance m st be sed to cook food by ad lts only and
according to the instr ctions in this man al.
When the appliance is in use, the heating elements
and some parts of the oven door become
extremely hot. Make sure you don't touch them and
keep children well away.
 Ens re that the power s pply cable of other electrical appliances does
not come into contact with the hot parts of the oven.
 The openings sed for ventilation and dispersion of heat m st never
be covered.
 Always grip the oven door handle in the centre: the ends may be hot.
 Always se oven gloves to place cookware in the oven or when
removing it.
 Do not se al mini m foil to line the bottom of the oven.
 Do not place flammable materials in the oven: if the appliance is
switched on by mistake, it co ld catch fire.
 Always make s re the knobs are in the l/¡ position when the
appliance is not in se.
When npl gging the appliance always p ll the pl g from the mains
socket, do not p ll on the cable.
 Never carry o t any cleaning or maintenance work witho t having
npl gged the pl g from the mains.
 In the case of a malf nction, nder no circ mstances sho ld yo
attempt to repair the appliance yo rself. Repairs carried o t by
inexperienced persons may ca se inj ry or f rther malf nctioning of
the appliance. Contact a Service Centre (see Assistance).
 Do not rest heavy objects on the open oven door.
 The appliance sho ld not be operated by people (incl ding
children) with red ced physical, sensory or mental capacities, by
inexperienced individ als or by anyone who is not familiar with the
prod ct. These individ als sho ld, at the very least, be s pervised
by someone who ass mes responsibility for their safety or receive
preliminary instr ctions relating to the operation of the appliance.
 Do not let children play with the appliance.
Disposal
 Observe local environmental standards when disposing packaging
material for recycling p rposes. Observe existing legislation when
disposing of the old appliance.
 The E ropean Directive 2002/96/EC on Waste Electrical and
Electronic Eq ipment (WEEE), req ires that old ho sehold electrical
appliances m st not be disposed of in the normal nsorted m nicipal
waste stream. Old appliances m st be collected separately in order to
optimise the recovery and recycling of the materials they contain and
red ce the impact on h man health and the environment. The
crossed o t wheeled bin symbol on the prod ct reminds yo of yo r
obligation, that when yo dispose of the appliance it m st be
separately collected.
Cons mers sho ld contact their local a thority or retailer for
information concerning the correct disposal of their old appliance.
Respecting and conserving the
environment
 By sing the appliance in the ho rs between late afternoon and early
morning, yo can help red ce the work load placed on electrical
companies.
 Always keep the oven door closed when sing the BARBECUE and
GRATIN mode to attain best res lts and to save energy
(approximately 10%).
 Reg larly check the door seals and wipe clean to ens re they are free
of debris so that they stick properly to the door and do not allow heat
to disperse.
Assistance
Communicating:
 appliance model (Mod.)
 serial n mber (S/N)
This information is fo nd on the data plate located on the appliance and/
or on the packaging.

10
GB
Maintenance and care
Switching the a liance off
Disconnect yo r appliance from the electricity s pply
before carrying o t any work on it.
Cleaning the appliance
 The stainless-steel or enamel-coated external parts as
well as the r bber seals may be cleaned sing a
sponge that has been soaked in l kewarm water and
ne tral soap. If these stains are diffic lt to remove, se
only specialised prod cts. After cleaning, rinse and
dry thoro ghly. Do not se abrasive powders or
corrosive s bstances.
 Ideally, the inside of the oven sho ld be cleaned after
each se, when it is still l kewarm. Use hot water and
detergent, rinse and dry with a soft cloth. Do not se
abrasive prod cts.
 The accessories can be washed like everyday
crockery (even in yo r dishwasher).
 Never se steam cleaners or press re cleaners on the
appliance.
Cleaning the oven door
Clean the glass part of the oven door sing a sponge
and a non-abrasive cleaning prod ct, then dry thoro ghly
with a soft cloth. Do not se ro gh abrasive material or
sharp metal scrapers as these co ld scratch the s rface
and ca se the glass to crack.
To clean more thoro ghly, yo can remove the oven door.
1. Open the oven door f lly (see
diagram)
2. Lift p and t rn the small
levers located on the two hinges
(see diagram)
3. Grip the door on the two
external sides and close it
approximately half way.
P ll the door towards yo lifting it
o t of its seat (see diagram).
To replace the door, reverse this
seq ence.
Inspecting the seals
Check the door seals aro nd the oven periodically. If the
seals are damaged, please contact yo r nearest After-
sales Service Centre (see Assistance). We recommend
not sing the oven ntil the seals have been replaced.
Replacing the light bulb
To replace the oven light b lb:
1. Remove the glass cover of the lamp-holder.
2. Remove the light b lb and replace it with a similar one:
Wattage 25 W, cap E 14.
3. Replace the glass cover (see diagram).

11
GB

12
GB
04/2008 - 195068440.00
XEROX BUS NESS SERVCES
