Ariterm BioCompPX Guide

For a sustainable future.
INSTALLATION AND
USER INSTRUCTIONS
• BioCompPX

2
2014-03-03 / 06
TABLE OF CONTENTS
General ........................................................................................................3
Delivery contents .........................................................................................3
Transport, storage and unpacking..............................................................4
Technical data...............................................................................................5
Dimensions ...................................................................................................6
Installation of the boiler ..............................................................................7
Pipe installation ..................................................................................... 8–9
Electrical installation ..........................................................................10–11
Connection box ..........................................................................................12
Installation of the burner ..........................................................................14
Commissioning ..........................................................................................15
Service, decommissioning .................................................................16–18
Declaration of conformity .........................................................................19
Standard equipment ..................................................................................20
Installation report ......................................................................................21
Warranty .....................................................................................................23

3
General
e Ariterm BioComp with PX52 burner is an economical, reliable and environmentally
friendly boiler for fuel pellets intended for heating buildings and larger detached homes.
As standard, the BioComp is equipped with integrated automatic controls for the production of
hot water (does not apply to the Ultra Light version).
e burner is mounted on runners on the left or right side of the boiler (specify when ordering)
and can be easily removed from the boiler for cleaning. e burner can also be reached from the
service hatch on the front of the boiler. e control electronics, which are mounted on the front
of the boiler, regulate the boiler's temperature and the burner's output in upto three steps. e
current operating information, set values, alarms etc. are shown on the display.
e vertical convection tubes are kept clean automatically with the help of motorised turbula-
tors. e ash that is scraped off the tubes collects in the ash space at the bottom of the boiler,
together with the ash blown out of the burner pipe. e ash can be removed through a hatch at
the bottom of the front, and through 2 hatches, one at the bottom of each side.
An immersion heater can be installed as an accessory on either side. e immersion heater is
connected to its own separate electricity supply and has a thermostat and overheat protection.
e output is 3 + 6 kW. e boiler has 2 connections on each side with DN50 internal thread,
which can be used for the boiler return water or immersion heater.
Delivery contents (page 23)
e delivery includes:
• e boiler with associated burner and hatches
• Hatch with seals and runners for the burner
• Automatic control for the burner
• Cleaning tools
• Integral flue gas fan
• Flue gas pipe
• Automatic cleaning of the convection tubes
• Flat heat exchanger and pump for hot tap water (does not apply to the Ultra Light version)
• Overheat protection
Extra accessories:
• Combination flue gas connection 5208
• Automatic ash removal
• Mixing valve for hot tap water 4322
• Shunt valve 4321
• Wireless automatic shunt Esbe Crb 122 4319
• GSM alarm with automatic control 1159
• Immersion heater and thermostat with overheat protection 5749

4
2014-03-03 / 06
180
202
302
274
310
335
128
182
287
PELLETSPANNA BioCompPX
Vid leverans ingår:
t 4PUOJOHTSFETLBQ
t 4MBNmMUFS
t .VSOJOHTTUÚE
t 3ÚLSÚS
t 3ÚLHBTnÊLU
t "VUPNBUJLGÚSLPOWFLUJPOTSFOHÚSJOH
BTLVUNBUOJOH
Tillbehör:
t ,PNCJOBUJPOTSÚLSÚSBSUOS
t "TLVUNBUOJOH
t #MBOEOJOHTWFOUJMGÚSWBSNWBUUFO75"BSUOS
t 4IVOUWFOUJM73($VBSUOS
t 5SÌEMÚT4IVOUSFHMFSJOH$3#BSUOS
t (4.NPEVMGÚSMBSNPDIGKÊSSTUZSOJOHBSUOS
t &MQBUSPOJOLMTUZSOJOHBSUOS
BioCompPX
.BYFGGFLUQFMMFUT L8 
7BUUFOWPMZNQBOOB MJUFS 
.BYBSCFUTUSZDL CBS 
.BYBSCFUTUFNQFSBUVS $ 
7FSLOJOHTHSBE  
7JLUCSVUUP LH 
3FLTLPSTUFOTEJBNFUFS NN 
3FLTLPSTUFOTIÚKE N 

7JGÚSCFIÌMMFSPTTSÊUUFOUJMMLPOTUSVLUJPOTÊOESJOHBSVUBOGÚSFHÌFOEFNFEEFMBOEF
 3FTFSW%/
 %ZLSÚSCSÊOOBSHJWBSFPDIÚWFSIFUUOJOHTTLZEE
 3FTFSW%/
 #SÊOOLBNNBSF%/
 #SÊOOLBNNBSF%/
 *OLPNNBOEFLBMMWBUUFONN$V
 5BQQWBSNWBUUFONN$V
 7ÊSNFWÊYMBSFUBQQWBUUFO
 1VNQUJMMUBQQWBUUFOWÊYMBSF
 "WMVGUOJOHTWFOUJMUBQQWBUUFOWÊYMBSF
 &YQBOTJPOTÊLFSIFUTWFOUJMWFOUJM%/
 'SBNMFEOJOH%/
 &MQBUSPOVUUBH%/
 3FUVS%/
 "WUBQQOJOH%/
 #SÊOOBSÚQQOJOHIÚHFSFMMFSWÊOTUFSTJEB
 4FSWJDFMVDLB
 4ZOHMBT
 4PUTLÌQNFELPOWFLUJPOTSFOHÚSOJOH
 "TLMVDLB
 3FOHÚSJOHTMVDLPS
 ,POWFLUJPOTSFOHÚSJOHNPUPS
 .PUPSUJMMBTLTLSVWUJMMCFIÚS
 "TLTLSVWUJMMCFIÚS
 3ÚLLBOBMNN
,POUSPMMQBOFMFOIBSFOEJTQMBZPDIFOKVTUFSJOHTSBUU
 %JTQMBZFOWJTBSESJGUMÊHFPDIBLUVFMMQBOOUFNQFSBUVS
'ÚSLMBSBOEFUFYUSVMMBSJEJTQMBZFOWBSFTFLVOE
 +VTUFSJOHTSBUUFOBOWÊOETHFOPNBUUWSJEBFMMFSUSZDLB
 .BOWSJEFSGÚSBUUWÊYMBJNFOZOFMMFSÊOESBWÊSEFWJE
FOKVTUFSJOH&UUUSZDLWÊMKFSFMMFSTQBSBSJNFOZO
TRANSPORTATION, STORAGE AND OPENING THE PACKAGE
Transport
e boiler is delivered in a wooden crate secured by screws to a pallet, which means the boiler
can be lifted safely using a standard pallet truck. e boiler should be unpacked as close to the
installation site as possible. Ariterm's transport insurance covers any transport damage that oc-
curs during transport from the factory to the first intermediate storage location. It is important
that the recipient of the boiler checks the boiler's condition before accepting the delivery. In case
of damage, the transport company must be contacted immediately.
Storage
e boiler can be stored outside, protected against the rain. It is however best to store the boiler
indoors.
Unpacking
Check that all parts on the equipment list are present, after removing the packaging. Loose parts
are placed inside the soot hatch, on the front of the boiler. e wooden packaging is sorted as
combustible material and the plastic bag as plastic, at the recycling station.
Service hatch, convection
section
Burner hatch
Ash hatches, convection
section
Hearth ash auger (optional equipment)
Flue gas fan (can also be
installed instead of an ash
hatch in the convection
section)
Window for inspecting the flame
Service hatch
Ash hatch
The control panel has a display and adjustment dial:
- The display shows the operating mode and the cur-
rent boiler temperature.
Explanatory text scrolls through the display every 5
seconds.
- The adjustment dial is used by pressing or turning.
Turn it to toggle through the menu or other values
when making an adjustment One press makes a
selection or saves in the menu.

52014-03-03 / 06
TECHNICAL DATA
BioCompPX
Max. output pellets kW 18-60
Water volume boiler litres 175
Max. operating pressure bar 3.0
Max. operating temperature C 130
Efficiency % >90
Weight (gross) kg 495
Rec. chimney diameter mm 150
Rec. chimney height m 5
Height mm 895
Diameter mm 430
Volume m30.13
Electrical connection
Permanent connection via an isolator switch 220-240 Vac 50Hz,350W
Load on heating surface kW/m211.1
Size of burner opening mm x mm 250x250
Size of flue Ø mm 139
Required underpressure Pa > 5
Smoke Gas Temperature nominal effect 60 kW °C ca 140
Smoke Gas Temperature min effect 18 kW °C ca 85
Pressure drop acrossthe boilerwater connections 26 mbar @ 2,5m3/h
107 mbar vid 5,2 m3/h
Supply/return connection DN 50
Connection for expansion DN 25
Thermostat connection DN 15
Flat heat exchanger, output kW 57
Heat exchanger pump UPS 25-40
Noise level dbA 62
Class according to 303-5 2012 class 5

6
2014-03-03 / 06
180
202
302
274
310
335
128
182
287
PELLETSPANNA BioCompPX
Vid leverans ingår:
t 4PUOJOHTSFETLBQ
t 4MBNmMUFS
t .VSOJOHTTUÚE
t 3ÚLSÚS
t 3ÚLHBTnÊLU
t "VUPNBUJLGÚSLPOWFLUJPOTSFOHÚSJOH
BTLVUNBUOJOH
Tillbehör:
t ,PNCJOBUJPOTSÚLSÚSBSUOS
t "TLVUNBUOJOH
t #MBOEOJOHTWFOUJMGÚSWBSNWBUUFO75"BSUOS
t 4IVOUWFOUJM73($VBSUOS
t 5SÌEMÚT4IVOUSFHMFSJOH$3#BSUOS
t (4.NPEVMGÚSMBSNPDIGKÊSSTUZSOJOHBSUOS
t &MQBUSPOJOLMTUZSOJOHBSUOS
BioCompPX
.BYFGGFLUQFMMFUT L8 
7BUUFOWPMZNQBOOB MJUFS 
.BYBSCFUTUSZDL CBS 
.BYBSCFUTUFNQFSBUVS $ 
7FSLOJOHTHSBE  
7JLUCSVUUP LH 
3FLTLPSTUFOTEJBNFUFS NN 
3FLTLPSTUFOTIÚKE N 

7JGÚSCFIÌMMFSPTTSÊUUFOUJMMLPOTUSVLUJPOTÊOESJOHBSVUBOGÚSFHÌFOEFNFEEFMBOEF
 3FTFSW%/
 %ZLSÚSCSÊOOBSHJWBSFPDIÚWFSIFUUOJOHTTLZEE
 3FTFSW%/
 #SÊOOLBNNBSF%/
 #SÊOOLBNNBSF%/
 *OLPNNBOEFLBMMWBUUFONN$V
 5BQQWBSNWBUUFONN$V
 7ÊSNFWÊYMBSFUBQQWBUUFO
 1VNQUJMMUBQQWBUUFOWÊYMBSF
 "WMVGUOJOHTWFOUJMUBQQWBUUFOWÊYMBSF
 &YQBOTJPOTÊLFSIFUTWFOUJMWFOUJM%/
 'SBNMFEOJOH%/
 &MQBUSPOVUUBH%/
 3FUVS%/
 "WUBQQOJOH%/
 #SÊOOBSÚQQOJOHIÚHFSFMMFSWÊOTUFSTJEB
 4FSWJDFMVDLB
 4ZOHMBT
 4PUTLÌQNFELPOWFLUJPOTSFOHÚSOJOH
 "TLMVDLB
 3FOHÚSJOHTMVDLPS
 ,POWFLUJPOTSFOHÚSJOHNPUPS
 .PUPSUJMMBTLTLSVWUJMMCFIÚS
 "TLTLSVWUJMMCFIÚS
 3ÚLLBOBMNN
,POUSPMMQBOFMFOIBSFOEJTQMBZPDIFOKVTUFSJOHTSBUU
 %JTQMBZFOWJTBSESJGUMÊHFPDIBLUVFMMQBOOUFNQFSBUVS
'ÚSLMBSBOEFUFYUSVMMBSJEJTQMBZFOWBSFTFLVOE
 +VTUFSJOHTSBUUFOBOWÊOETHFOPNBUUWSJEBFMMFSUSZDLB
 .BOWSJEFSGÚSBUUWÊYMBJNFOZOFMMFSÊOESBWÊSEFWJE
FOKVTUFSJOH&UUUSZDLWÊMKFSFMMFSTQBSBSJNFOZO
DIMENSIONS
1. Reserve DN 15
2. Submersible tube burner sensor and overheat
protection
3. Reserve DN 15
4. Combustion chamber DN 20
5. Combustion chamber DN 15
6. Incoming cold water Ø 22 Cu
7. Hot tap water Ø 22 mm Cu
8. Heat exchanger tap water
9. Pump to tap water exchanger
10. Bleed valve tap water exchanger
11. Expansion/safety valve DN 25
12. Supply DN 50
13. Immersion heater socket DN 50
14. Return DN 50
15. Draining DN 20
16. Burner opening, right or left side
17. Service hatch
18. Sight glass
19. Soot cabinet with convection cleaning
20. Ash hatch
21. Cleaning hatches
22. Convection cleaning motor
23. Motor for ash auger (accessory)
24. Ash auger (accessory)
25. Flue gas connection Ø 139 mm

72014-03-03 / 06
BOILER INSTALLATION
Installation must be carried out by a qualified installer. The electrical connection must be car-
ried out by a qualified electrician.
Space requirements
e boiler room must fulfil the requirements in Boverkets Nybyggnadsregler BBR (Swedish
National Board of Housing's Regulations for New Buildings). ere must be at least one me-
tre's free space for service in front of the boiler and at the side where the burner is located. e
rear must also be accessible for servicing the flue gas fan and connection box. Above the boiler,
there must be space for manual cleaning of the convection tubes. In addition, reserve space for
ash auger, where applicable, on one side.
Chimney connection and opening for combustion air
e low temperature of the flue gas from the BioCompPX gives rise to a risk of condensation in
the chimney. Make sure the chimney is well ventilated with the help of draught diverter/inhibi-
tor e chimney flue should be stainless steel or acid-proof. Ensure that the chimney connec-
tion (boiler flue to chimney connection) is air tight since, during certain operating cases, there
could be an over-pressure after the boiler flue (legend 25 on page 6).
e chimney's minimum diameter should not be less than 150 mm.
Note: for the boiler to function, it is important that there is sufficient combustion air. ere
must be an opening to the open air in the boiler room of at least 2.5 dm2 for each BioCompPX.
It must not be possible to close the air intake.
CAUTION!
For complete combustion and for the boiler to work well, it is important that there is a sufficient
quantity of combustion air. The opening for the combustion air must not be blocked. The area
for the opening for replacement air should be approximately 5dm2 /100kW.

8
2014-03-03 / 06
VV
KV
VV
KV
TV
1. ARITERM BIOCOMP PX
2. 3-VÄGSVENTIL, RADIATORVÄRME
3. VÄRMELEDNINGSPUMP, RADIATORVÄRME
4. RADIATORVÄRMESYSTEM
5. EXPANSIONSKÄRL
6. AVSTÄNGNINGSVENTIL FÖR SERVICEÄNDAMÅL
7. SÄKERHETSVENTIL
8. PÅFYLLNINGSVENTIL
9. BLANDNINGSVENTIL
10. CIRKULATIONSPUMP FÖR TAPPVATTEN
PIPE INSTALLATION
Pipe installations
e boiler is delivered with integrated overheat protection. However, a safety valve must be in-
stalled close to the boiler.
If the return water temperature is too low it can result in a risk of corrosion. Make sure the low-
est return water temperature is approx. 60°C during operation.
Example of installation
1. ARITERM BIOCOMP PX
2. 3-WAY VALVE, RADIATOR HEAT
3. HEATING SYSTEM PUMP, RADIATOR HEAT
4. RADIATOR HEATING SYSTEM
5. EXPANSION TANK
6. SHUT OFF VALVE FOR SERVICING
7. SAFETY VALVE
8. REFILL VALVE
9. MIXING VALVE
10. CIRCULATION PUMP FOR TAP WATER

92014-03-03 / 06
PIPE INSTALLATION
Installation of safety valve (not included in the delivery)
e valve must be CE marked with maximum opening pressure 3.0 bar, minimum size DN 25.
e safety valve must be selected based on the combined equipment's highest pressure class.
Do not install any device between the valve and the boiler that can be used to close the connec-
tion.
e blow-off pipe must be installed so it does not limit the valve's blow-off capacity nor cause
any risk of accidents when the valve is activated.
WARNING! When the valve is activated, hot steam sprays out of the pipe under pressure!
Expansion tank
e size of the expansion tank is determined as follows:
Closed system: according to the instructions from the expansion tank's manufacturer
System volume = boiler volume (+ hot water heater volume) + pipe volume + radiator volume
Production of hot tap water
ere is an efficient flat heat exchanger for tap water in the boilers in the BioComp series, so
generally speaking there is no need for a separate hot water heater. e flat heat exchanger with-
stands pressures up to 10 bar. e system can also be connected to an external heat exchanger of
the size required.
System volume (lit-
res)
Opening pressure
(bar)
Pre-pressure
(bar)
Tank volume (litres)
70 °C 90 °C
500 3.0 0,5 35 80
1 000 3.0 0.5 80 140
1 500 3.0 0.5 80 140
2 000 3.0 0.5 140 200

10
2014-03-03 / 06
ELECTRICAL INSTALLATION
e BioCompPX is equipped as standard with a heat exchanger pump and automatic soot re-
moval; these are already connected in the connection box. In addition, a flue gas fan is included
in the standard equipment. e fan is installed at the back of the boiler and is controlled by the
burner's control panel, setting Fan 2/Air 2.
The control panel has a display and adjustment dial
e BioComp master controller has the following functions:
• e display shows the operating mode and current boiler temperature. Explanatory texts
roll on the display every 5 seconds.
• To use the adjustment dial, press or turn.
• Turn it to toggle through the menu or other values when making an adjustment.
• One press makes a selection or saves in the menu.
• To exit the menu, hold the button pressed in for 4 seconds.
Example:
Switching on the boiler. One press makes the panel ask "Start?" Another press means
you confirm, and the burner starts.
If you turn one step clockwise instead, you jump to the main menu and come to "Start
T". Turn further to arrive at "Stop T", "User menu" and "Back" respectively.
Start T: is is where you set the desired start temperature.
Stop T: is is where you set the desired stop temperature.
User menu: is is where you adjust the time and temperature settings.
To be able to perform more advanced settings it is necessary to enter the settings menu,
as described under “Settings” on page 13. Note that it is necessary to enter access code
21 to get access to these settings.
e burner is lit using a hot air element when the boiler temperature is less than the
temperature selected in the main menu. e start procedure takes place completely au-
tomatically in several steps to provide fast and almost smoke free ignition.
When the boiler temperature has increased by 2-5°C, the burner's output is lowered to
half, and stops completely when the set stop temperature is reached (80-85°C). After a
short cooling phase, the burner stops and restarts automatically when the temperature
has fallen to the set temperature again.

11 2014-03-03 / 06
230 Vac In
230 Vac Out
230 Vac In
230 Vac In
230 Vac In
Pwm
Com
Tacho
+ 5 Vdc
Remote
Com
Alarm Relay
Alarm Relay
Burner
Dhw pump
Exhaust fan
Conv cleaning
1
2
3
4
5
IN
Temp
1
Temp
2
Com
1
Com
2
12
5 4 3
P 1
(N)
(PE)
(L)
U
B
N
Y
B = svart
N = brun
UVVP
VVP
PB
PB
4
1
2
3
PB
B
GR
PTG
PTG Temperaturgivare, pannvatten
B
4
M
M
N
U
Y
N
F
F
U
Y
N
B1
2
3
N
Colors
B = black
U = blue
N = braun
Y = yellow-green
GR = grey
VVP Circulation pump hot domestic water
PB Pellet burner
PTG Temperature sensor, boiler water
M Motor for convection cleaning
F Fan motor

12
2014-03-03 / 06
1. Loosen the two securing screws on the bottom
edge of the boiler's front panel.
2. Loosen the front panel's securing screws on the
top of the boiler.
3. Connection box for soot removal motor (10)
and heat exchanger pump (11).
CONNECTION BOX

13 2014-03-03 / 06
MENU
Menu PX52
1.renrub eht pots ro trats ot mrifnoC?tratS 5
View
Start T 70 (0-90) Boiler start temperature in ° C. Firedet 000-999 Actual flame sensor reading.
lower than Stop T Current 000-999 Actual current consumtion reading.
Stop T 80 (0-90) Boiler start temperature in ° C. Syspoint 000-999 Actual syspoint i program
higher than Start T Temp 1 00-99 Actual temperature reading 1 in ° C.
2 UserMenu Jump to User Menu Temp 2 00-99 Actual temperature reading 2 in ° C.
Back Pgm V 5.1
Actual program version.
# Ignit 000-999 Number of ignitions since latest reset.
2UserMenu Therm K Not Active
3 Settings Jump to Settings Menu OpTiHour(Min) 000-999
External auger running time since
4
Service
Jump to Service Menu latest reset in hours or minutes.
5 View Jump to View Menu TachoAct 000-999 Tachometer readings from fan.
6 ClockSet Back
Back
6
ClockSet
3Settings 00:00 Set Time (HH:MM)
SetCode(21) 01-01-01 Set Date (YY-MM-DD)
4 Service Back
Ign dose 70 (010-240) Ignition dose in seconds.
TstDose Testing of ignition dose.
Feed HI 10,9 (0-20) Feeder HI-Power mode in seconds.
Feed LO 7,2 (0-20) Feeder LO-Power mode in seconds.
Feed MIN 4,0 (0-20) Feeder MIN-Power mode in seconds.
Air HI 50 (0-100) Fan HI-Power mode in percent.
Air2 HI 55 (0-100) Fan2 HI-Power mode in percent.
Air LO 35 (0-100) Fan LO-Power mode in percent.
Air2 LO 45 (0-100) Fan2 LO-Power mode in percent.
Air MIN 20 (0-100) Fan MIN-Power mode in percent.
Air2 MIN 35 (0-100) Fan2 MIN-Power mode in percent.
HI I/0 1 (0-1) Activate HI-Power mode.
LO I/0 1 (0-1) Activate LO-Power mode.
MIN I/0 0 (0-1) Activate Min-Power mode.
Default? Set default values.
Language 2 (1-5) Set language
1 = Swedish
2 = English
3 = Finnish
4 = German
5 = French
6 = Italian
Back

14
2014-03-03 / 06
Mount the runners on the burner hatch flange. Secure the guide lugs onto the mounting bracket
with screws, and the mounting bracket at the bottom edge of the burner, angled back out from
the boiler. First apply the sealing braid as shown in the picture, then push the burner back into
place. It may be necessary to lift the burner a little from runner sled. Screw the burner securely
to the burner hatch flange using the 4 nuts enclosed. If necessary, adjust the height of the run-
ners afterwards. Connect the cables on the side of the burner.
INSTALLATION OF THE BURNER
1. Installation of the immersion heater 2. Installation of the thermostat
Electrical operation:
An immersion heater (6 or 9 kW) can be installed in the boiler, in the DN 50 connection, on
the side closest to the front of the boiler (14). e immersion heater is delivered together with
an adjustment/overheat thermostat TY3. Detailed instructions for connection are enclosed
with the thermostat.
Fuse sizes: 6kW immersion heater 3x10A and 9kW immersion heater 3x16A.
Supply voltage: 400V, 3~, 50Hz
NOTE! A safety switch must be installed in the immersion heater's power supply.

15 2014-03-03 / 06
COMMISSIONING
Prior to commissioning the heating equipment, the following must be checked:
• that the heating system and boiler are filled with water, with a pressure of at least 0.5 bar
• that any flue gas damper is open
• that the circulation pump is on
• that the heating system's valves are open
• that the supply air vent is open
• that the safety valve's connection to the boiler cannot be obstructed and that safety valve is
working as it should
Start the burner and test the burner is working according to the burner's instructions. Make
sure the circulation functions and bleed air from the system. Combustion characteristics should
bechecked with a flue gas analyser, allowing for optimum combustionto be achieved.
Adjust the balance between the burner fan and the boiler flue gas fan, so the underpressure in
the hearth is 15 - 25 Pa. The underpressure gauge is connect to the Ø6 mm copper tube, on the
top of the boiler to the left of the tap water pipes. The flue gas fan is adjusted separately for each
output mode: AirHi 2, AirLo 2 and AirMin 2.
Daily operation and daily maintenance
The daily operation of the boiler depends on the wood pellet quality used and the need for
heating. We recommend the following fuel type is used: ENplusA1.
Ensure that all hatches are closed and air tight during operations. Hatches that are not air tight
can cause incorrect combustion.
WARNING Changing to another wood pellet quality always assumes the equipment is adjusted! If
necessary, check the fuel suitability with the equipment supplier!
NOTE! The servicing intervals are extremely dependent on the wood pellet quality used and
the correct burner setting. On average, the boiler must be cleaned every 2 – 4 weeks.

16
2014-03-03 / 06
SERVICE
The BioComp series Service interval
Sweeping the convection section
At intervals of 4 – 6 months. The spirals must
be removed from the convection section before
sweeping.
Sweeping the hearth Once a year.
Removing ash from the hearth After 2 – 3 tonnes of pellets.
Removing ash under the convection section After approx. 3 tonnes of pellets.
Visual inspection of the boiler Inspection: Once a month (pipe connections).
Test the safety valves Twice a year.
The seals and hatch sealing
(change if necessary) Inspection: Once a month.
Removal of ash from burner At the same time as the ash is removed from the
hearth.
*) Use of a fuel rich in ash naturally increases the quantity of ash and thereby shortens the serv-
ice interval.
Service intervals
e service intervals given are guide values and can vary considerably depending on the wood
pellet quality used and the load.
Check the boiler more frequently at the start, so you can determine the length of the service
interval. If the quality of the fuel varies, the service interval must be determined again. During
the winter, there is a great need for heating and so the service interval may be shorter than in the
summer.

17 2014-03-03 / 06
Removing ash from the hearth
SERVICE
Removing ash from the convection
section
Check the hearth's ash space once a year and
remove the ash with an ash scraper as re-
quired. The intervals between emptying the ash
space depend on the fuel used and the output
need.
Check the convection section's ash space
once a month and remove the ash with an
ash scraper as required. The intervals between
emptying the convection section's ash space
depend on the fuel used and the output need.
Clean the surfaces of the hearth at least once a
year. Use a round brush with a bent shaft.
Sweeping the hearth

18
2014-03-03 / 06
SERVICE, DECOMMISSIONING
Decommissioning
A worn out boiler should be scrapped.
Inspection of the convection section
The boiler is equipped with automatic soot re-
moval, but the convection section should still
be checked 2 – 3 times a year. Open the con-
vection section service hatch and lift the hatch
to one side. NOTE! The hatch is heavy.
If the tubes' surfaces appear sooty, they must
be swept manually. Lift the spirals out of the
convection tubes.
Sweeping the convection section
Use a tube brush with a straight shaft. Go
through each convection tube. Push the brush
all the way down to the ash space, as it will
then be easier to pull it back. Reinstall the spi-
rals and close the convection section service
hatch.
Check the pipes in the convection section and
remove y ash from the surfaces. Feel to see
whether the spirals can move in the convec-
tion tubes. If the convection tubes appear to be
clean, manual sweeping is not needed.

19 2014-03-03 / 06
FELSÖKNING OCH ÅTGÄRDER
FAULT CAUSE WHAT TO DO
The burner stops The burner and/or boiler
need(s) sweeping Clean the burner and boiler
The burner stops,
Fault code ErrSafe The burner has overheated
Clean the burner and boiler.
Reset the fall pipe’s overheat
protection
The burner stops,
Fault code ErrStart The burner has not lit Check the pellet supply and the starter dose “Ign dose”
The burner stops,
Fault code ErrLow
The burner has gone out in
low output mode
Check the pellet supply and the
“Feed LO” and “Air LO” settings
The burner stops,
Fault code ErrHigh
The burner has gone out in
high output mode
Check the pellet supply and the
“Feed HI” and “Air Hi” settings
The burner stops,
Fault code GOutStrt
The burner lit but then went
out during pre-operation
Check the pellet supply and the
“Feed SU” and “Air Su” settings.
(ServCode)
The burner stops,
Fault code ErrorIgn
The firing element is not
drawing any power
Check the connections to the
firing element or replace the firing
element
The burner stops,
Fault code Tempsens
The control circuit board has no
contact with the temp. sensor
The temperature sensor circuit
may be broken by the external
thermostat or switch. If not, check
the connections to the temp.
sensor or replace
The burner stops from
time to time and without any
visible cause
May be due to too large or
strong variations in vacuum in
the chimney, or fuel feed fault
Contact your authorised installer for
overhauling and any installation of
draft inhibitors

20
