Ariterm Biomatic 50 Installation and operating instructions

INSTALLATION, OPERATION AND MAINTENANCE
• Biomatic 50

ARITERM SWEDEN AB Installation, Operation and Maintenance - 2007.10.26- 2/12
CONTENTS IMPORTANT INFORMATION
Important Information.....................................................................2
Dimensions / Items included...........................................................3
Operating Principle...........................................................................4
Wiring Diagram................................................................................5
Control Panel ....................................................................................6
Installation..........................................................................................6
Water Piping .....................................................................................7
Filling of Water.................................................................................8
Maintenance, Care, Sweeping..........................................................8
Advice about Fuel Pellets.................................................................9
Pellets Store........................................................................................9
Guarantee.........................................................................................10
Declaration of Conformity.............................................................10
Installation Protocol........................................................................11
• Keep this instruction manual readily available for future use.
• Read the instructions carefully before taking your boiler into service.
• Follow these instructions carefully and carry out care and maintenance work as
recommended.
Notification to building authority
Attention! When you change heating installation this must always be
communicated to the local building authorities.
Sweeping
According to the fire protection laws a chimney shall be swept regularly. is is done
by the local chimneysweep. Sweeping of the boiler shall be carried out in such a man-
ner that good operating economy is achieved. (see under ”Maintenance”) Prepare to
chimney-sweeping by turning off the boiler at least one hour before cleaning to mini-
mize the amount of glowing ash.
Maintenance contract
Ariterm recommends the boiler installation to be made by a company with professio-
nal competence. For more information please contact your Ariterm retailer.
Replacing of spare parts
Ariterm recommends that replacing of spare parts is made by authorized serviceman
of Ariterm retailer. e retailer supplies required spare parts and authorized service-
man makes the necessary adjustments and combustion gas analysis when replacing
spare parts.

ARITERM SWEDEN AB Installation, Operation and Maintenance - 2007.10.26- 3/12
DIMENSIONS / ITEMS INCLUDED IN THE DELIVERY
Art.nr
Biomatic 50 (art.nr PELL-517010050)
Standard delivery
• Sweeping gear
Accessories
• Combination flue for horizontal and vertical installation (art.nr 5208)
• Hot water heat exchanger
• Assembly kit for oil burner
Biomatic 50
1. Drain DN 15
2. Flue pipe Ø 139 mm
3. Sweeping hatch
4. Expansion DN 25 male
5. Feed line DN 50 male
6. Cable bushing
7. Ash box
8: Sight glass
9. Return line DN 50 male
10. Return line DN 25 male
1
8
2
4
5
6
3
7
10
9
Höjdmått gäller exkl ställbara fötter
725410 600
245
606
1690
264
410
500
4251229
270
240
Ø 139 utv.
389
758 728
304162
A=1560
150
154
Kombinationsrökrör
620
130
Ø159
Ø159
50
TECHNICAL SPECIFICATION
Performance Capacity range, pellets 25 - 50 kW
Dimensions
Width
Depth (without flue pipe)
Height (without connections)
Weight
Water contents
606 mm
720 mm
1690 mm
452 kg
115 l
Design values and settings
Design pressure
Design temperature
Recommended flue gas temperature
Recommended draught
Rec. free height above boiler
0,5 - 1,5 bar
max 100 °C
100 - 140 °C
5-20 Pa
500 mm
Connections
Heating system
Expansion
Drain
Flue
DN 25 / 50
DN 25 male thread
DN 15
Ø 139 mm
Dimensions are without adjustable feet
A-dimensions including comb.flue pipe is app. 1853 mm
Comb. flue pipe

ARITERM SWEDEN AB Installation, Operation and Maintenance - 2007.10.26- 4/12
Biomatic 50 the new generation pellet boiler is specically designed for pellet
heating. It is equipped with vertical convection tubes to prevent soot to stick
to the convection surfaces.
Biomatic 50 is equipped with an oversized ash box to facilitate maintenance
work. Sweeping is mainly done from the soot-hatch on top of the boiler but
also through the rebox door where the burner is located.
e boiler is designed to operate with a pellet burner.
Biomatic 50 consists of a combustion chamber with flue pipes, which is
enclosed by a jacket holding 115 litres of water. Heat generated by the
burner is transferred directly to the boiler water.
Oil heating
e Ariterm pellet boiler can also be used for heating with oil (oil heating
accessories on demand).
OPERATING PRINCIPLE

ARITERM SWEDEN AB Installation, Operation and Maintenance - 2007.10.26- 5/12
WIRING DIAGRAM
S21
S20
F1 Control fuse 3 A, external circ. pump hot water circuit
F2 Control fuse 3 A, external circ. pump heating circuit
S20 Switch, external circ. pump, heating circuit On/Off
S21 Switch, internal circ. pump, hot water circuit, continous operation
TS Regulating thermostat, burner
TZ High limit thermostat, burner
THERMOSTAT CONNECTION
MAINS SUPPLY MMJ
3x1,5 mm2
MAINS SUPPLY
PELLER BURNER
CONN. EXTERNAL CIRC. PUMP,
HEATING CIRCUIT
CONN. FLOW SWITCH
EXTERNAL CIRC. PUMP,
HOT WATER CIRCUIT
CONN. EXTERNAL CIRC. PUMP,
HOT WATER CIRCUIT

ARITERM SWEDEN AB Installation, Operation and Maintenance - 2007.10.26- 6/12
e boiler shall be positioned and installed according to the building rules in force.
Before installing the boiler, the chimney must be controlled for underpressure and
possible risk of condensation. It is possible that an air draught compensator has to be
installed. Inner pipe is recommended for minimizing the risk of condensation.
Space needed for installation: Minimum clearance in front of the boiler (burner
included) is 1000 mm. Clearence on the top shall be at least 0,5 m. By the other side
of the boiler clearence shall be at least 0,8 m. e boiler must be level. If the floor is
uneven, adjustments can be made with the help of four adjusting bolts (enclosed with
the boiler) that shall be fitted to the bottom plate of the boiler.
e air intake duct to the boiler room must have at least the same area as the flues.
Chimney installation
To embed the angular tube in the chimney, proceed according to the drawing below.
If the tube is embedded as described, you will be able to avoid soot leakage when the
chimney is being swept.
Flue connection and combustion air intake
e combination flue of the boiler allows for connection towards the top as well as
to the rear. Boiler cement is suitable for sealing. Recommended flue gas requirements
for Biomatic+ 50: brick chimney lined with a Ø 150 mm acid proof thin-walled tube
or an acid proof Ø 150 mm element chimney. Recommended underpressure in the
chimney is 25 Pa. e height of the gas flue shall be dimensioned according to the
building’s requirements, but should be at least 6 m. If condensation water comes out of
the flue, a condensate drain pan shall be installed in the lower portion of the chimney.
e combustion air intake must not be covered.
1. Regulating thermostat
Adjustment of operating temperature for pellet burner
2. Overheating protection, burner
- Press the button to reset the overheating cut-out. Before reset,
check that there is water in the boiler and that the operating thermostat
works correctly. If you cannot reset the overheat protection, please
contact a qualied installation contractor.
3. ermometer / Pressure gauge
- Shows water pressure and water temperature at the top of the
boiler. Due to the stratication of water, boiler temperature varies
considerably within the boiler; the lowest water temperature is measured
at the bottom and the highest at the top.
4. Flue gas thermometer
- Displays temperature of leaving flue gases at the flue connection
point.
5. Automatic fuse
- Automatic fuse, circulation pump, external heating circuit.
6. Switch
- Switch, circulation pump, external heating circuit.
7. Automatic fuse
- Automatic fuse, circulation pump, external hot water circuit.
8. Switch
- Switch, circulation pump, external hot water circuit.
9. Connection for external auger
CONTROL PANEL INSTALLATION
30
Mortar
Flue pipe
30 mm incom-
bustible
insulation
ATTENTION! The chimneysweep must be
notied for inspection of the flue.
CAUTION! The boiler has low flue gas
temperatures, which, under certain
conditions,might lead to condensation of
flue gases.
1
2
34
57
9
8 6

ARITERM SWEDEN AB Installation, Operation and Maintenance - 2007.10.26- 7/12
Water piping shall be carried out in accordance with current local and national hot
water and building regulations. Safety equipment shall be installed in accordance
with regulations in force. If a closed expansion vessel is used, an approved safety valve,
a pressure gauge, and a vent valve shall be fitted. e safety valve shall be fitted just
above, but not directly on, the boiler in such a manner that the connection with the
boiler cannot be closed off. e connecting line from the boiler to the safety valve must
rise continuously. Before the boiler is filled with water, the enclosed drain tap shall be fitted.
Radiator system and expansion vessel
When you fill the system, all valves must be open and the external circulation pump
turned off. Bleed the system carefully while filling. When the installation has been in
service for a few days, it shall be bled and refilled once again.
ATTENTION! See also separate instructions for filling of water.
e volume of the expansion vessel is determined as follows:
Open system:
5% of the water volume in the heating system.
Closed system:
Select the volume of the vessel in accordance with the manufacturer’s instructions.
In the following table, you will find examples of suitable closed system expansion
vessels.
System volume Opening pressure Initial pressure Vessel volume
(litre)* (bar) (bar) (litre)
70˚C 90˚C
500 1,5 0,5 35 80
1000 1,5 0,5 80 140
1500 1,5 0,5 80 140
2000 1,5 0,5 140 200
An open system with 500 litre water volume demands at least a 35 litre expansion vessel and a 1500 litre
system volume a 80 litre expansion vessel
* System volume = boiler volume + storage tanks + piping volume + radiator volume.
Planning and installation
Planning and installation shall be carried out in a professional manner, attention being
paid to general and local rules and regulations. Operating pressure is max.
1,5 bar. Before taking the installation into service, and always at the beginning of the
heating season, the following checks shall be carried out:
• that the heating system is filled and bled
• that the circulation pump is working
• that the system valves are open
• that the automatic control and safety devices are in working order
• that the chimney has the necessary draught and that the fresh air ventilation
is open.
Safety valve
If a closed expansion vessel has been installed in the radiator system, the safety valve
must be checked 4 times a year. Activate the valve by pressing or turning the control
button and check that water escapes from the overflow pipe connecting the valve to
the drain.
WATER PIPING

ARITERM SWEDEN AB Installation, Operation and Maintenance - 2007.10.26- 8/12
Before you begin heating, the heating system must be filled with water.
To fill the system, do as follows:
1. Open all shut-off valves, including the shunt valve.
e pump must be switched off.
2. Fill the boiler and the radiator system with water.
Bleed the system at the radiators.
3. Once the system is filled completely, the circulation pump can be started and
heating can begin.
4. When the boiler water has reached its pre-set operating temperature, the pump
should be stopped and the system bled at the radiators once again. is should be
repeated several times.
Remember that much air is enclosed in tap water. e enclosed air volume may reach
as much as 10%, which explains why bleeding takes time – especially where there are
large water volumes. A closed system shall be filled until the pressure gauge indicates
the correct system pressure, i.e. the distance from the pressure gauge to the highest ra-
diator in meter times 0,1 which gives the system pressure in bar. Adjust the red needle
of the pressure gauge to the same value as the big needle.
FILLING OF WATER MAINTENANCE, CARE, SWEEPING
Boiler cleaning
Burning solid fuels, even if operation is automated, normally calls for a little more care
and maintenance than oil heating. For Biomatic 20 maintenance has been minimized
as the result of well planned design and a big ash box holding 50 litres. Ash is removed
when necessary. e convection parts of the boiler are to be cleaned when the flue gas
temperature has risen by 20-30˚C above the temperature of a newly swept boiler.
ATTENTION! Pay special attention to the pellets quality when you receive a new delivery or when
you change supplier.
ATTENTION! Show a great care when emptying the ash as it might be glowing hot. Ash must be
kept in a fireproof container.
e following measures and checks shold be carried out when the boiler is cleaned:
•Switch off the burner an hour before service.
•Lift the soot hatch at the top of the boiler and brush clean the flues.
•Remove the fixing bolts from the burner and loosen the hose and electric connec
tions.
•Pull out the burner and brush clean the walls of the combustion chamber.
• Empty the ash.
ATTENTION! Disconnect the power to the boiler before removing the protective housing
ATTENTION! Show great care when emptying the ash as it can be glowing hot.

ARITERM SWEDEN AB Installation, Operation and Maintenance - 2007.10.26- 9/12
ADVICE ABOUT FUEL PELLETS
• Pellet fuel can be manufactured from several different biologically derived raw
materials. Most common is wood, but today there are several alternative materials
available on the market that are suitable for pellets manufacture.
ese raw materials have various characteristics that can be advantageous or disad-
vantageous for pelletised fuel.
Important factors that can be assessed are energy content, size, amount of fines,
moisture content and, last but not least, the price. We recommend that you choose
the fuel that has the lowest cost per energy unit after checking how the fuel per-
forms in the burner. Study carefully the fuel performance after new delivery.
In case of doubt, please contact us at Ariterm.
• Most of the problems that arise on account of inferior fuel quality are the result of
inadequate handling and storage before the fuel reaches the end customer.
If the fuel has high fines content the problem is usually due to separation
during storage or loading.
e formation of sintered ash is due to silicate contaminants (sand). eses
cannot be discovered before they are used. If you get pellets that produce
sintered ash, a claim must immediately be sent to the pellet supplier.
ATTENTION! If sintered ash is formed, the burn pot must be continuously
cleaned of sintered material (with a table spoon for example).
• Damp pellets can be the result of inadequate handling and transport.
If possible, inspect the pellets before they are unloaded to make sure that
you get clean and dry pellets and no fines.
ATTENTION! Damp pellets must be rejected immediately.
FUEL RECOMMENDATION
Raw material Chemically untreated barkless wood
Diameter 8 mm
Length 15 to 32 mm
Volume weight over 600 kg/m3
Moisture content less than 10 %
Ash content less than 0.7 weight %
Fine material content max 4 weight %
Melting temperature of ash >1100 °C
Energy content >4,75 kWh/kg
PELLET STORE
anks to the pellet feed system the pellet store can be built for bulk deliveries.
e store can either be located inside the house or in a separate building.
Pellets must, however, never be exposed to moisture.
Data for flexible feed system:
Maximum climb: 2,5 m
Maximum gradient: 45˚
Outside pipe diameter: 75 mm
Attention! The pellet store can have a maximum of 3 intake openings, and only one intake
can be used at a time.
e store shall be well sealed to avoid the spreading of dust. As a guide when determi-
ning the size of the store, it may be useful to know that the minimum bulk delivery is
normally 3 tons if you wish to avoid freight surcharge. 1 ton of pellets corresponds to
about 1,6 m3. To accommodate 3 tons of pellets you would need a store of at least 6
m3to have some space to spare.
Inspection hatch
600 x 600 mm
Store pipe (delivered by Ariterm),
see previous page. The whole length
of the store pipe shall be supported.
2 x horizontal
studs 45x95 mm
50˚
80 mm
Bulk lling pipe
Ø 100 mm
Vent pipe Ø 200 mm
Attention!
If lter sack is used
for lling we
recommend
2 x Ø 200 mm
Vertical studs
95x45 mm
c/c 600 mm
Slippery plywood
board 16 mm Horizontal stud
45x95 mm
Stud 45x95 mm
c/c 600 mm
e drawing represents a stand alone pellet storage bin. If the store is built
against a supporting wall, the sloping studs will have to be arranged differently.

ARITERM SWEDEN AB Installation, Operation and Maintenance - 2007.10.26- 10/12
DECLARATION OF CONFORMITY
is boiler manufactured by Ariterm AB is guaranteed to be free of defects in work-
manship and materials for a period of 24 months (2 years) from the date of installati-
on. e manufacturer shall not be held liable for faults caused by incorrect installati-
on, incorrect use, freezing, over-temperature or over-pressure. Any attempts made to
repair the product without the manufacturer’s permission or if the guarantee card has
not been returned to the manufacturer, will invalidate the guarantee. e manufactu-
rer shall not be held liable for any possible indirect damage and/or financial loss caus-
ed by the burner.
Ariterm AB reserves the right to decide the method how a possible guarantee repair is
carried out. Ariterm AB is not liable for damages occurred after the expiration of the
guarantee period, but compensation for such incidents may be agreed upon separately
case by case.
GUARANTEE

ARITERM SWEDEN AB Installation, Operation and Maintenance - 2007.10.26- 11/12
After installation the burner has to be adjusted. To test every power range, press plus key for 8 seconds in On/Off menu, then can high, low and min modes be test
manually. Returning to normal position: Press minus key once.
ATTENTION! In this function, the burner won’t stop when the boiler water reaches desired temperature: boiling risk!
If these instructions are not followed during installation, operation and maintenance,
the obligations of Ariterm AB under the warranty regulations are no longer binding.
Ariterm reserves the right to alter any details and specifications without prior notice.
Flue gas temp. High CO
Retailer / Installer
Installed by Inst. date
O2CO2
Efficiency Draught (mm) Fan Effect %
Flue gas temp. Low CO O2CO2
Efficiency Draught (mm) Fan Effect %
Flue gas temp. Min CO O2CO2
Efficiency Draught (mm) Fan Effect %
Air-fuel ratio 
Air-fuel ratio 
Air-fuel ratio 
INSTALLER
INSTALLATION PROTOCOL

ARITERM SWEDEN AB |Flottiljvägen 15
39241 Kalmar |www.ariterm.se | 0771-442850
