Armorgard forma-stor FR100-T User manual

User manual for your
Armorgard Forma-Stor
forma-stor™
Model Numbers FR100-T - FR400-T

2
Welcome...
to your Armorgard Forma-Stor, the most secure solution
for portable and fast-assembly storage. The Forma-Stor
can be erected in minutes from flat pack panels, making
it, simple, safe, and secure!
Please read this user manual carefully
prior to setting up the Forma-Stor
Please call 023 9238 0280 if you have any questions on setting up your
Forma-Stor.
Contents
Welcome... ...........................................................................................2
Safety information.................................................................................3
Contents ..............................................................................................4
Erecting the Forma-Stor .......................................................................5
Dismantling the Forma-Stor ..................................................................8
Using the lifting eyes.............................................................................9
Additional kits .....................................................................................10
General information ............................................................................10

3
Safety information
At least 2 people are required to safely erect or dismantle the
Forma-Stor and all relevant PPE must be worn while doing so.
The Forma-Stor must be positioned on a flat, solid surface, and
should be level and stable before being used.
Ensure the Forma-Stor is fully assembled and that it is empty
before lifting or moving it. Only qualified personnel should lift the
Forma-Stor.
Technical Specification
Product code Net weight
FR100-T 255kg
FR200-T 385kg
FR300-T 470kg
FR400-T 595kg

4
Contents
FR100-T pack contents:
2x 1m side panels
1x 2m rear panel
1x 2m door panel
1x 1x2m base
1x 1x2m roof
8x M12 x 20mm bolts
8x M12 x 50mm bolts
8x M12 large washer
8x M12 small washer
8x Pipe linchpin
4x M12 lifting eye with rubber
washer
FR300-T pack contents:
2x 3m side panels
1x 2m rear panel
1x 2m door panel
1x 2x3m base
1x 2x3m roof
8x M12 x 20mm bolts
8x M12 x 50mm bolts
8x M12 large washer
8x M12 small washer
8x Pipe linchpin
4x M12 lifting eye with rubber
washer
FR400-T pack contents:
2x 4m side panels
1x 2m rear panel
1x 2m door panel
1x 2x4m base
1x 2x4m roof
10x M12 x 20mm bolts
8x M12 x 50mm bolts
8x M12 large washer
10x M12 small washer
8x Pipe linchpin
4x M12 lifting eye with rubber
washer
FR200-T pack contents:
2x 2m side panels
1x 2m rear panel
1x 2m door panel
1x 2x2m base
1x 2x2m roof
8x M12 x 20mm bolts
8x M12 x 50mm bolts
8x M12 large washer
8x M12 small washer
8x Pipe linchpin
4x M12 lifting eye with rubber
washer

5
To begin assembling the
Forma-Stor, place the base on a
level, stable surface.
Place one of the side panels on
the base, using the bolts in step 2
to position the panel.
Ensure it is supported safely whilst
you use the 45mm bolts to secure
the side to the base.
1. 2.
3.
Erecting the Forma-Stor
4.
Next, position the rear panel to
form a corner. This will support
the side panel.

6
Fix a pipe linchpins in each corner.
5. 6.
8.
There are two linchpins for each
corner.
Place the other side panel on the
base, and secure it with bolts as
described in steps 3-4.
Bolt in the 20mm bolts into each
corner of the base, two to every
corner.
7.

7
9.
Secure the corner with two more
linchpins.
10.
11. 12.
The door panel is the last panel
to be fixed on. This slots onto
the base and is fixed to the side
panels with linchpins as described
in step 6.
Ensure the grooves in the roof fit
securely to the top of each of the
4 panels.
WARNING! The roof is heavy and care should be taken
when lifting into position. Please take all safety precautions
necessary when moving this part.
Now place the roof on top. An
extra person may be needed
inside the unit to balance the roof.

8
The Forma-Stor is now ready for
use
To dismantle the Forma-Stor,
remove the parts in reverse
order to that which they were
assembled.
Remove the roof first, followed by
the door panel, one of the side
panels, the rear panel and then
the remaining side panel. Fixings
can be bolted back into the panels
for safekeeping.
1. 2.
Dismantling the Forma-Stor
14.
13.
Lastly, fix the roof in place using
the bolts provided.

9
Before lifting, ensure that the bolts
holding the lifting eyes are securely
in place.
Attach the lifting equipment to all
four lifting eyes and ensure that
the load is lifted evenly across all
four eyes.
1. 2.
Using the lifting eyes
WARNING! The lifting eyes are provided only for positioning
the Forma-Stor, and the unit must be empty while lifting.
Before lifting, each lifting eye needs to be checked that it is
fitted correctly, and should be inspected by a lifting operator
before use.

10
Lost Keys?
Replacement keys can be purchased from Armorgard, using the
serial number on the product.
Spare Parts
The following parts are available to order as spares:
Additional kits
General information
The Forma-Stor can be fitted with an optional shelving kit. Please call
023 9238 0280 for more details.
- 1m side panel
- 2m side panel
- 2m door panel
- 2m rear panel
- 3m side panel
- 4m side panel
- Locks
- Roof (all 4 sizes)
- Base (all 4 sizes)
- Lifting eyes
- M12 bolts
- M12 washers
- Pipe linchpins

11
