Armour Home Electronics Systemline S7 NetAmp 19” Rack Adapter User manual

S7 NetAmp 19” Rack Adapter
19” rack adapter used to mount up to two S7 NetAmps SN8200

Specialist tools
Pack contents
Rack panel x 1
Cage nut (M6) x 8
Cable cover x 1
NetAmp x 2
(each unit includes
2 brackets & 4 screws)
Instruction manual x 1
Screw (M4x10mm Pozi) x 10
Long reach screwdriver advised for easy assembly
Screw (M6x10mm Pozi) x 8
A
G
E
B
F
C D
Supplied separately
Installation instructions
1. Unscrew 2 screws either side of cable cover. Detach cable cover from rack panel.
A
B
Cx2
Systemline® is a registered trademark of Armour Home Electronics Ltd.
All other product names are trademarks or registered trademarks of their respective owners.

A
2. Fit 2 brackets to each NetAmp as shown (all items supplied with NetAmp).
3. Mount each NetAmp onto rack panel using screws provided (4 screws per NetAmp).
4. Plug in mains cables (supplied with NetAmps). Feed all additional cables through provided cutouts and plug in.
Cx4 Cx4
x2
x2
G
GG

5. Fix cable cover onto rack panel using 2 screws provided.
6. Fit 8 cage nuts into appropriate positions in the rack. Fix rack panel into rack using 8 screws provided.
x4
E
x4
E
A
B
Cx2
Dx4
Dx4
