Armstrong 64424 Assembly instructions
64424
Visit our website at: http://www.harborfreight.com
Email our technical support at: [email protected]
Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions,
assembly, operating, inspection, maintenance and cleaning procedures.
Write the product’s serial number in the back of the manual
(or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference. 18e
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright© 2018 by Harbor Freight Tools®. All rights reserved.
No portion of this manual or any artwork contained herein may
be reproduced in any shape or form without the express written
consent of Harbor Freight Tools. Diagrams within this manual may
not be drawn proportionally. Due to continuing improvements,
actual product may differ slightly from the product described herein.
Too ls requ ire d f or a sse mbl y a n d s erv ice may no t b e in clu ded .
Read this material before
using this product. Failure
to do so can result in
serious injury. SAVE THIS
MANUAL.
Page 2 For technical questions, please call 1-888-866-5797. Item 64424
Specifications
Receptacle Rating 125 VAC, 20 A
USB Output Rating 5 VDC
Wire Terminals #14 to #12 AWG
Operating Temperature -4° to 104° F
Important Safety Information
TO PREVENT SERIOUS INJURY AND
DEATH FROM ELECTROCUTION:
1. Install and use in accordance
with federal, state and local
code and regulations.
2. If you are not sure about any part
of these instructions, have an
electrician install this receptacle.
3. Device is supplied by a
single branch circuit.
4. Use with Class 2 connectors
with interconnecting cables.
5. All connected Class 2 output
cables must be routed away from
the receptacle slots or any plug/
cord inserted into the receptacle.
6. Class 2 output connections
are not intended to support
products or appliances.
7. Use this device with copper
or copper clad wire only.
8. Wall plate is needed to complete
installation but is not provided.
9. Do not use if parts are deformed,
loose, or damaged.
10. To reduce the risk of overheating,
fire, or explosion, check device
compatibility with manufacturer’s
charging instructions.
SAVE THESE INSTRUCTIONS.
Page 3For technical questions, please call 1-888-866-5797.Item 64424
Installation
Note: A wall plate is needed
to complete the installation
but is not provided.
1. WARNING! TO PREVENT FIRE,
ELECTRIC SHOCK, OR DEATH
FROM ELECTROCUTION:
Turn off power at the circuit
breaker or fuse and test that
power is off before wiring.
2. WARNING! Attach a warning
tag to the circuit breaker
or fuse location warning
not to reconnect power.
3. Install the USB Outlet in a
standard single gang electrical
wall box wired in accordance
with NEC Article 314 box
fill requirements.
4. Connect wires per diagram.
Wire terminals accept #14 to
#12 AWG copper or copper clad
wires. Strip wire back 4/5″.
5. Loop wire around terminal
screws and firmly tighten
terminal screw to secure.
6. Mount the USB Outlet in the wall
box with the four screws provided.
7. Install wall plate (not provided).
8. Restore power.
Note: The USB ports are for charging
only and cannot transfer data.
