Armstrong TechZone ML-TZ-DF User manual

Modulinear™ Diffuser for 4"
and 6" Technical Zones
Catalog No.s:
ML-TZ-LT-9/16" and 15/16" Lay-In
ML-TZ-DF-15/16" Tegular
ML-TZ-NT-9/16" Tegular
The Titus Modulinear TZ series is a high-performance,
high-quality slot diffuser. The TZ series is designed to
easily integrate into the Armstrong’s TechZone ceiling
grid system providing a customized and aesthetically
pleasing look with standard components.
Modulinear TZ series diffusers are available in
1, 2, 3 and 4-slot configurations in several lengths.
The unique, aerodynamically curved “ice tong”
deflector blades allow both changes in air volume
and direction from the face of the diffuser. This
versatile diffuser is an excellent choice for variable
air volume applications.
The Modulinear TZ series is designed to fit Lay-In,
Narrow Tee, and Tegular ceilings. Optional distribution
plenums are available in standard heights (shown below),
or 8" low profile heights.
990 Security Row
Richardson, TX 75081
972.699.1030
www.titus-hvac.com/techzone
CS-3813-1010
Modulinear Diffuser
3-3/8"
11-1/8"
8-1/8"
3-3/8"
Low
Profile
ML-TZ-NT
9/16" TEE BAR
1 AND 2-SLOT
LENGTHS FROM 24" TO 72"
Standard
Profile
3"
11-1/8"
Standard
Profile
Low
Profile
ML-TZ-DF
TEGULAR
15/16" T-BAR
1 AND 2-SLOT
LENGTHS FROM 24" TO 72"
8-1/8"
3"
3-3/4"
8-1/8"
3-3/4"
11-1/8"
Low
Profile
ML-TZ-LT
LAY-IN
9/16" AND 15/16" TEE BAR
1 AND 2-SLOT
LENGTHS FROM 24" TO 72"
Standard
Profile
ML-TZ-LT 6
Lay-In, 6" width
9/16" and 15/16" T-Bars
1, 2, 3 and 4-slot
Lengths: 24" to 72"
ML-TZ-DF 6
Tegular, 6" width
15/16" T-Bars
1, 2 and 3-slot
Lengths: 24" to 72"
ML-TZ-NT 6
Narrow Tee, 6" width
9/16" T-Bar
1, 2, 3 and 4-slot
Lengths: 24" to 72"
ML-TZ-LT 4
Lay-In, 4" width
9/16" and 15/16" T-Bars
1 and 2-slot
Lengths: 24" to 72"
ML-TZ-DF 4
Tegular, 4" width
15/16" T-Bars
1 and 2-slot
Lengths: 24" to 72"
ML-TZ-NT 4
Narrow Tee, 4" width
9/16" T-Bar
1 and 2-slot
Lengths: 24" to 72"
TECHZONE™ Ceiling System
Air Diffusers
Armstrong® TechZone™ Compatible
ML-TZ-LT
15/16˝ Lay-In
Standard
Profile
Low
Profile
11-1/8˝
8-1/8˝
5-3/4˝
5-3/4˝
ML-TZ-NT
9/16˝ Tegular
Standard
Profile
Low
Profile
11-1/8˝
8-1/8˝
5-3/8˝
5-3/8˝
ML-TZ-DF
15/16˝ Tegular
Standard
Profile
Low
Profile
11-1/8˝
8-1/8˝
5-3/4˝
5-3/4˝
5˝
5˝
5/16˝
