Artcoustic Architect SL Series User manual

ARCHITECT SL OWNERS MANUAL
www.artcoustic.com

Welcome to the world of Artcoustic!
Congratulations with your purchase of the Artcoustic Architect SL
In-ceiling speaker.
The Architect SL Series is created to provide impressive sound from ultra thin
and aesthetically pleasing loudspeakers. The entire Architect line of in-wall/in-
ceiling loudspeakers will surprise you. Whether you are looking for true HiFi
music reproduction or louder applications such as home cinema installations,
commercial installations, bars, restaurants and public address setups, the
Artcoustic Architect Series offer the ultimate solution.
The Architect Series has been designed and Engineered with the same high
specifications as all the other Artcoustic models, leaving no space for
compromise on sound quality and built. The Architect series consist of four
models, Architect 2-1 SL single source speaker to the larger Architect 4-2 SL
single or dual source speaker, the Architect 3-2-1 single source full range
solution and finally the high SPL and more directional single source Architect
2-1 SL PAS.
Thank you for purchasing an Artcoustic product.
All the best,
The Artcoustic Team

High Frequency driver:
Dual Ring Radiator diaphragm with highly linear suspension and low loss surrounds for high
clarity and clean transient response. Copper caps for better HF extension and lower distortion
and wave-guide center plug, copper-clad aluwire.
Architect 2-1 SL, Architect 4-2 SL and Architect 3-2-1 SL.
5 degrees angled tweeters, for controlled directivity and improved off axis response.
Architect 2-1 SL PAS.
20 degrees angled, full-range all units.
Woofer:
Extra long excursion and aluminium Short Circuiting Ring, 4-layer voice coil, anodised aluminium
for improved heat dissipation, combined with Distortion Reduced Motor.
Crossover:
6 dB/octave low pass and 12 dB/octave high pass filter.
Design features:
Low resonance baffle, exceptional low mounting depth combined with very high SPL and
dynamic range.
Quick and easy installation with in-house developed Spider Grip metal mount.
ARCHITECT SL FEATURES

Architect 2-1 SL Architectural Speaker
Transducer:
LF-MF 2 x 3 inch cone
HF 1 x 1 inch Dual Ring Radiator
Crossover:
Low Pass Filter 6 dB/octave 1000 Hz High Pass
12 dB/octave 4000Hz
Connection:
Single amped Gold Plated Screw Terminals
Performance:
Operating Range 60 Hz (-3dB) to 40 kHz
Nominal Beamwidth Horizontal 90° Vertical 90°
Input Impedance Nominal Minimum 4 ohms
Sensitivity 1 Watt @ 4 ohm 89 dB Full Space, 92 dB Half Space
Long Term SPL 30 Watt 104 dB Full Space, 107 dB Half Space
Short Term (Damage) SPL 55 watt 107 dB Full Space, 110 dB Half Space
Recommended High Pass Filter =>100 Hz, 24 dB/octav
Weight 2 kg
Dimensions H: 240 W: 240 D: 74 mm
Finish:
Cabinet: Black, White, RAL, NCS, Tikkurila
Screen: Black, White, RAL, NCS, Tikkurila,
SPECIFICATIONS
Architect 2-1 SL
The smallest model in the in-ceiling, in-wall line up. Architect SL is the perfect solution for multi-room
applications, commercial installations, bars, restaurants, hotel lobby’s etc. And as well as the perfect
choice for Dolby Atmos effect speakers in Artcoustic cinema systems.
Couple the Architect 2-1 SL with one of the powerful Artcoustic subwoofers and experience the ultimate
sound performance, within the typical Artcoustic reward winning, discrete and aesthetic design.

Terminals
215
24
0
52
18
9
74
CUTDIMENSION220mm
4
R136
Round grille, for in-ceiling
and in-wall.
ARCHITECT 2-1 SL SCHEMATICS
4

Specification Architect 4-2 SL Architectural Speaker
Transducer:
LF-MF 4 x 3 inch cone
HF 2 x 1 inch Dual Ring Radiator
Crossover:
Low Pass Filter 6 dB/octave 1000 Hz High Pass
12 dB/octave 4000Hz
Connection:
Single or bi- amped Gold Plated Screw Terminals
Performance:
Operating Range 65 Hz (-3dB) to 40 kHz
Nominal Beamwidth Horizontal 90° Vertical 90°
Mono. Input Impedance Nominal Minimum 7 ohms
Sensitivity 1 Watt @ 7 ohm 91 dB Full Space, 94 dB Half Space
Long Term SPL 60 Watt 109 dB Full Space, 112 dB Half Space
Short Term (Damage) SPL 110 watt 112 dB Full Space, 115 dB Half Space
Stereo. Input Impedance Nominal Minimum 2 x 13 ohms
Sensitivity combined 1 Watt @ 13 ohm 91 dB Full Space, 94 dB Half Space
Long Term SPL 60 Watt 109 dB Full Space, 112 dB Half Space
Short Term (Damage) SPL 110 watt 112 dB Full Space, 115 dB Half Space
Weight 4 kg
Dimensions H: 300 W: 300 D: 74 mm
Finish:
Cabinet: Black, White, RAL, NCS, Tikkurila, Gloss
Screen: Black, White, RAL, NCS, Tikkurila,
SPECIFICATIONS
Architect 4-2 SL
The Architect In-Wall 4-2 SL is more powerful than the 2-1 and offer options of either single source high
output, high performance speaker, for more demanding applications, or can be used as a full range
dual source stereo speaker where appropriate.
The Architect 4-2 SL has an impressive operating dynamic range -3dB 45Hz and extend to and
impressive upper frequency response at 40kHz. All matched with an exceptional Sound pressure at
111dB. Making the Architect 4-2 SL a true all-rounder, fitting a large portfolio of applications.

CUTDIMENSION278mm
9
74
18
52
300
Stereo or
mono terminals
27
4
ARCHITECT 4-2 SL SCHEMATICS
4
R16
6
4
Round grille, for in-ceiling
and in-wall.

Specification Architect 3-2-1 Architectural Speaker
Transducer:
LF 3 x 3 inch cone
LF-MF 2 x 3 inch cone
HF 1 x 1 inch Dual Ring Radiator
Crossover:
Low Pass Filter LF 12 dB/octave 60 Hz
Low Pass Filter LF-MF 6 dB/octave 1000 Hz High Pass 12 dB/octave 3000Hz
Connection:
Single or bi-amped Gold Plated Push Terminals
Performance:
Operating Range 45 Hz (-3dB) to 40 kHz
Nominal Beamwidth Horizontal 90° Vertical 90°
Input Impedance Nominal Minimum 4 ohms
Sensitivity combined 1 Watt @ 4 ohm 90 dB Full Space, 93 dB Half Space
Long Term SPL 50 Watt 108 dB Full Space, 111 dB Half Space
Short Term (Damage) SPL 90 watt 110 dB Full Space, 113 dB Half Space
Weight 4.5 kg
Dimensions H: 300 W: 300 D: 74 mm
Finish:
Cabinet: Black, White, RAL, NCS, Tikkurila, Gloss
Screen: Black, White, RAL, NCS, Tikkurila,
SPECIFICATIONS
Architect 3-2-1 SL
The Architect 3-2-1 SL is a high SPL full range single source speaker, targeting multi room applications.
The Architect 3-2-1 SL perform with equal impressive dynamic range within a residential solution, or
in a professional setup, such as bars, restaurants, hotels, or simply anywhere, where the typical
Artcoustic superior quality sound reproduction is expected, all without the need of a subwoofer.
The Architect 3-2-1 SL has an impressive operating dynamic range -3dB 45Hz and extend to an
impressive upper frequency response at 40kHz. All matched with an exceptional Sound pressure level
at 110dB. Making the Architect 3-2-1 SL a true all-rounder, fitting a large portfolio of applications.

ARCHITECT 3-2-1 SL SCHEMATICS
CUTDIMENSION278
300
9
4
19
74
53
Terminals
R16
6
4
Round grille, for in-ceiling
and in-wall.
27
4

Specification Architect 2-1 SL PAS Architectural Speaker
Transducer:
LF-MF 2 x 3 inch cone
HF 1 x 1 inch Dual Ring Radiator
Crossover:
Low Pass Filter 6 dB/octave 1000 Hz High Pass
12 dB/octave 3000Hz
Connection:
Gold Plated Push Terminals
Performance:
Operating Range 70 Hz (-3dB) to 18 kHz
Nominal Beamwidth Horizontal 60° Vertical 60°
Input Impedance Nominal Minimum 13 ohms
Sensitivity 1 Watt @ 13 ohm 91 dB Full Space, 94 dB Half Space
Long Term SPL 30 Watt 106 dB Full Space, 109 dB Half Space
Short Term (Damage) SPL 55 watt 109 dB Full Space, 112 dB Half Space
Weight 3 kg
Dimensions H: 300 W: 300 D: 153 mm
Finish:
Cabinet: Black, White, RAL, NCS, Tikkurila, Gloss
Screen: Black, White, RAL, NCS, Tikkurila,
SPECIFICATIONS
Architect 2-1 PAS (Point And Shoot)
The Architect 2-1 (PAS) - is a high SPL, directional, single-source speaker, incorporating the same ultra-thin
and minimalistic design of the existing Architect products, the PAS is perfect for Dolby Atmos speaker
applications, and in-ceiling LCR configurations.
For ultimate sound reproduction, couple the Architect 2-1 PAS with one of our powerful subwoofers.
