Artcoustic SL TARGET MINI User manual

artcoustic.com
SL TARGET MINI
Owners manual

Congratulations on your purchase of the Artcoustic SL
Target Mini passive monitor.
This multi-purpose monitor shares many
characteristics with the other models in the SL range.
Maintaining Artcoustic's clean contemporary design,
the Target mini SL has been designed to match all
modern flat screen monitors.
Target mini SL - This is a very flexible loudspeaker,
designed for use in smaller rooms for home cinema or
HiFi, and multi-room applications in kitchens,
bedrooms, studies, etc.
Partner it with an Artcoustic Subwoofer for a truly full-
range, dynamic performance.
Thank you for purchasing the Artcoustic SL Target
Mini.
All the best,
The Artcoustic Team
OWNERS MANUAL – SL TARGET MINI ARTCOUSTIC LOUDSPEAKERS
WELCOME TO THE WORLD
OF ARTCOUSTIC

SL Target Mini
6 dB/octave low pass and 12 dB/octave high pass filter.
from HiFi Systems and Multi-Room Systems to smaller Home Cinemas.
Ultra-slim aesthetically pleasing cabinet design, designed to complement the latest LED screen
designs.
Extra long excursion and aluminium Short Circuiting Ring, 4-layer voice coil, anodised aluminium
for improved heat dissipation, combined with Distortion Reduced Motor.
Dual Ring Radiator diaphragm with highly linear suspension and low loss surrounds for high clarity
and clean transient response. Copper caps for better HF extension and lower distortion and
wave-guide center plug, copper-clad aluwire.
WOOFER
CROSSOVER
HIGH FREQUENCY DRIVER
EXTREMELY SMALL AND COMPACT CABINET
DESIGN WITH LOW DISTORTION
LOW POWER CONSUMPTION
WIDE FREQUENCY RESPONSE 70 HZ TO 40 KHZ
FAST, EASY, AND SIMPLE INSTALLATION
SUITABLE FOR A WIDE RANGE OF APPLICATIONS
Choose from a vast range of colour options from NSC and RAL to match your cabinet colour
and screen to your interior. Artcoustic has created a true all-rounder, covering most medium
SPL applications, where high performance and aesthetics is a focal point.
OWNERS MANUAL – SL TARGET MINI ARTCOUSTIC LOUDSPEAKERS
COMPONENTS OVERVIEW
FEATURES

LF-MF 1 x 3 inch cones
HF 1 x 1 inch Dual Ring Radiator
Low Pass Filter 6 dB/octave 1000 Hz
High Pass 12 dB/octave 4000Hz
Single amped Gold Plated Push Terminals
Operating Range 70 Hz (-3dB) to 40 kHz
Nominal Beamwidth Horizontal 90° Vertical 90°
Sensitivity l Watt @ 7 ohm 86 dB Full Space, 89 dB Half Space
Long Term SPL 30 Watt 98 dB Full Space, 101 dB Half Space
Short Term (Damage) SPL 55 watt 101 dB Full Space, 104 dB Half Space
Input Impedance Nominal Minimum 7 ohms
Recommended High pass filter 100 Hz 24 dB / Octave
1.4 kg
Horizontal 90°
Vertical 90°
H: 150 W: 150 D: 72mm
LF-MF 1 x 3 inch cone
HF 1 x 1 inch
Dual Ring Radiator
70 Hz 40 kHz
-3dB 70 Hz
Cabinet: Black, White,
RAL, NCS.
Screen: Black, White,
RAL, NCS,
Artcoustic Art Gallery
OWNERS MANUAL – SL TARGET MINI ARTCOUSTIC LOUDSPEAKERS
CROSSOVER
TRANSDUCER
CONNECTION
PERFORMANCE
FINISH
WEIGHT
DIMENSIONS
TRANSDUCER
OPERATING RANGE
NOMINAL BEAM
WIDTH
SPECIFICATIONS

150
83
72
37
100
50
SL Target Mini
front view
top view
bottom view
side view rear view
dimension are in mm
SCHEMATICS
150
65
21

Mount to wall with suitable
wall plugs
Attach bracket mount to
speaker rear side
Mount bracket to ceiling with
suitable screws
Mount Bracket to wall,
with suitable screws
Mount bracket to speaker
Mount stands to speaker
with supplied screws
Mount speaker to bracket, rotating clockwise
Mount bracket to
speaker
Speaker Stand
Universal Bracket Mount
Universal Alu Mount
Artcoustic Universal Bracket
SL Target Mini
SL Target Mini
SL Target Mini
Artcoustic Universal Bracket SL Target Mini
isometric rear view side view
isometric rear view
isometric rear view
MOUNTING INSTRUCTIONS
OWNERS MANUAL – SL TARGET MINI ARTCOUSTIC LOUDSPEAKERS
inserts
inserts
wall
inserts

Do not place product filled
with liquids such as vases
on the product.
Do not open product. There are
no user-serviceable parts inside.
To reduce the risk of fire and
electric shock do not expose this
product to rain or moisture.
Always use the power supply
shipped with this product. Using a
power supply with wrong voltage or
polarity,can damage the
electronics.
This product complies with Part 15 of the FCC Rules.
Its operation is subject to the following two conditions:
This product may not cause harmful interference.
This product must accept any interference received,
including interference that may cause undesired
operation.
Changes or modifications not expressly approved by the
party responsible for compliance could void the user’s
authority to operate the equipment.
OWNERS MANUAL – SL TARGET MINI ARTCOUSTIC LOUDSPEAKERS
Do not use this
product near water
Clean rear panel
with dry cloth only
Do not block any
ventilation opening
Do not install near
any heat sources
If wall mounted,
ensure the use of
matching screws
and rawl plugs
SAFETY INSTRUCTIONS
SAFETY
WARNING

Is valid only for products
purchased from an authorised
Artcoustic retailer or dealer.
Is limited to the repair of the
equipment (which could be a repair or
replacement at our discretion, neither of
which affects your original warranty).
If it is found necessary to return the product for repair, you will be given a form to fill out
and return. You should not return the product without previous acceptance. To validate your
warranty, you will need to produce the original sales invoice or other proof of ownership
and date of purchase.
Is valid from the date of purchase
for a period of 3-years for passive
loudspeakers, and 2-years for powered
loudspeakers and electronics.
Neither transportation nor any
other costs, nor any risk for removal,
transportation, and installation of
products is covered by this warranty.
OWNERS MANUAL – SL TARGET MINI ARTCOUSTIC LOUDSPEAKERS
Will not be applicable in cases other than defects in materials and/or workmanship
at the time of purchase and will not be applicable:
∙ For the deterioration of component parts, the nature of which is to become worn or
depleted with use, such as batteries.
∙ For damages caused by incorrect installation, connection or packing.
∙ For damages caused by accidents, lightning, water, fire heat, war, public
disturbances or any other cause beyond the reasonable control of Artcoustic.
and its appointed distributors.
∙ For damages caused by any use other than correct use described in the user
manual, negligence, modifications, or use of parts that are not made or authorized
by Artcoustic.
IS APPLICABLE
IS NOT APPLICABLE
WARRANTY
