ARTDEV AL-D460 User manual

Quick Installation Guide
Printer overview
Printer Installation
Button functions
Loading the label
Feed button
Top cover open lever
Note: The interface picture in the quick start guide is for reference only. Please
refer to the product specification for the interfaces availability.
1.Insert a 1" label spindle into a paper roll (* If your paper core is 1''inch, remove
the 1.5'' core adapter from the fixed tab,use the label spindle derectly).
2.Open the printer top cover by pushing
forward the top cover open levers.
(1)Feed labels
When the printer is ready, press the button to feed one label to the beginning of next label.
(2)Pause the printing job
When the printer is printing, press the button to pause a print job. When the printer is
paused the LED will blink blue. Press the button again to continue the printing job.
3.Orient a roll of paper on the paper roll mount.
4.Feed the paper, printing side face up, through
the label guide and pass over the platen.
5.Adjust the black center-biasde label guides in
or out turning adjustment knob so they are
slightly touch the edges of the label backing.
6.Close the printer top cover slowly and make sure
the cover locks latch securely.
7.Use the “Diagnostic tool” to set the media sensor type
and calibrate the selected sensor. (See “Diagnostic
tool” and “Sensor Calibrate” in the next page).
Note:
1. Please calibrate the gap/black mark sensor when changing media.
2. Failure to securely close and lock the cover will result in
poor print quality.
Note: Please switch OFF printer power switch prior to
plug in the power cord to printer power jack.
1.5'' Core Adaptor
1"label spindle
0 1 0 2
Top cover open lever
Fix tab
Paper roll
LED indicator
USB interface
MicroSD slot
Power jack
Power jack
Power supply
Power plug
power switch Printer top cover
Paper roll mount
Label guide
Printing side face up
1.Arrange this printer on a reliable flat surface and make sure the power switch is off。
2.Connect the printer to a computer mainframe with a USB cable。
3.Plug the power cord into the power jack connector
at the rear of the printer, then plug the power cord into
a properly grounded outlet。
Ethernet Interface

AL-D460
Thermal-Labelprinter
Quick Start Guide
Drivers and Manuals available at:
https://www.artdev.de/etikettendrucker/al-d460/
