Artos Denby M06875P User manual

www.artos-westover.com
Installation Guide
Installation GuideInstallation Guide
Installation Guide
Denby Towel Warmer M06875P ( plug
Denby Towel Warmer M06875P ( plugDenby Towel Warmer M06875P ( plug
Denby Towel Warmer M06875P ( plug-
--
-in version )
in version )in version )
in version )

The Denby Towel Rack is intended for towel warming/drying, auxiliary heating or as a
decorative product.
The average heat up time is about thirty minutes, but would depend on
a ) the si e of the unit and
b ) the initial temperature of the unit.
Typically the unit is programmed to be on an hour before expected use and remain on for
an hour afterwards.
The running cost of the towel rack, is usually similar to the running cost of lights in the
same room.
Clean with a soft cloth and use non abrasive cleaners.
Do not connect heater to the network before having read and understood the following
Do not connect heater to the network before having read and understood the following Do not connect heater to the network before having read and understood the following
Do not connect heater to the network before having read and understood the following
instructions.
instructions.instructions.
instructions.
Electrical and plumbing connections must be carried out by qualified personnel and the
unit should be securely mounted to the wall in a vertical position and such that it will not
fall into water if the brackets should loosen. Check with local regulations to verify whether
a GFI is required or not. The following pages are to assist in installation.
In case of damages or failures of the rail/connection, the towel rail should be returned to
the manufacturer or their distributor. The warranty from the manufacturer is NOT VALID
in case of improper use or installation. Product designed for use in Canada and USA on-
ly.
See page 4 for detailed installation steps.
U E
U E U E
U E
IN TALLATION
IN TALLATIONIN TALLATION
IN TALLATION

TECHNICAL SPECIFCATIONS
CARE & MAINTENANCE A periodic
wash using warm water and a soft
cloth will retain the high quality finish
of your towel warmer for many years
to come. ON NO ACCOUNT should
any household bleaches, detergents,
abrasive polish, steel wool or similar
cleaning agents be used on this
product.
WALL FIXING Towel warmer
brac ets must be securely fastened
to either masonry, wall studs or
plywood board in accordance with
the fitting instructions.
PACKAGING Pac aged for regular
UPS type shipping.
WARRANTY Frame 5 years –
Heating element 5 years.
MODEL# M06875
ELECTRIC VERSION Element
specifications 200W, 110V, 48” cord,
UL approved. Hardwire Kit CSA-US
approved. File ref: 229718
HYDRONIC VERSION Heat ouput
2305 BTU. ½” BSPT tappings.
Steel towel warmers should only
be used in a closed water system,
incorporating a rust inhibitor.
NOTE: Towel warmer must be installed so that electrical cord comes out
of the BOTTOM RIGHT of the unit.

INSTALLATION STEPS
1. Check that all the installation pack contents have been received. There should be 1 item
as shown below plus the towel warmer:
2.
2.2.
2. Determine location of towel warmer near a electrical outlet. The towel warmer cord is 4 ’
long. Note: where possible, attach at least two of the brackets to a firm wall stud.
Note: where possible, attach at least two of the brackets to a firm wall stud.Note: where possible, attach at least two of the brackets to a firm wall stud.
Note: where possible, attach at least two of the brackets to a firm wall stud.
3. Attach bracket pieces 1,2,3, and 4 to towel warmer using diagram 1 below as a guide.
Typically the brackets are positioned between the 2nd and 3rd bars from the top and
bottom. To allow maximum hanging space for the towel, position brackets as near to the
edges as possible.
Brackets
Diagram 1
#8 Cap
#1 Securing
Bolt
#2 Front Cylinder
Head
Horizontal Bars
#3 Rear Cylinder Head
#4 Inner Rear
Cylinder
#5 Wall Fixing
Screw
#7 Loc ing Screw
#6 Outer Rear Cylinder

INSTALLATION STEPS
5. Determine location of #6 outer rear cylinder by measuring the brackets attached to towel
warmer. Attach #6 cylinder to wall with hole for #7 locking screw facing down on the bot-
tom brackets and facing up on the top brackets.
6. Insert #4 bracket pieces ( attached to towel warmer ) into #6 bracket pieces ( attached
to wall ) and fasten with locking screw #7.
7. Plug towel warmer in, allow 30 minutes for towel to heat up.
8. ENJOY!

ARTOS
Towel Warmer Warranty
®
Item №: M06875P
Item №: M06875PItem №: M06875P
Item №: M06875P-
--
-
Serial №:
Serial №:Serial №:
Serial №:
This warranty covers against defective product for a period of five years. If a heating element is
installed, this is covered for a period of five years.
Under the warranty we will provide replacement components or product at our discretion.
Westover, Inc is not responsible for labor charges connected with removal or installation.
PLEASE REGISTER THIS PRODUCT ONLINE AT WWW.ARTOS
PLEASE REGISTER THIS PRODUCT ONLINE AT WWW.ARTOSPLEASE REGISTER THIS PRODUCT ONLINE AT WWW.ARTOS
PLEASE REGISTER THIS PRODUCT ONLINE AT WWW.ARTOS-
--
-WESTOVER.COM
WESTOVER.COMWESTOVER.COM
WESTOVER.COM
