Artos MC600H User manual

www.artos-westover.com
Installation Guide
Installation GuideInstallation Guide
Installation Guide
Corinium Towel Warmer MC600H ( hydronic version )
Corinium Towel Warmer MC600H ( hydronic version )Corinium Towel Warmer MC600H ( hydronic version )
Corinium Towel Warmer MC600H ( hydronic version )

Congratulations! You are the proud owner of a quality ARTOS towel warmer.
The Corinium Towel Rack is intended for towel warming/drying, auxiliary heating or as a
decorati e product.
The a erage heat up time is about thirty minutes, but would depend on:
a ) the size of the unit and
b ) the initial temperature of the unit.
Do not connect heater to the network before having read and understood the following
Do not connect heater to the network before having read and understood the following Do not connect heater to the network before having read and understood the following
Do not connect heater to the network before having read and understood the following
instructions.
instructions.instructions.
instructions.
Electrical and plumbing connections must be carried out by qualified personnel and the
unit should be securely mounted to the wall in a ertical position. The following pages
are to assist in installation.
In case of damages or failures of the rail/connection, the towel rail should be returned to
the manufacturer or their distributor. The warranty from the manufacturer is NOT VALID
in case of improper use or installation. Product designed for use in Canada and USA on-
ly.
See page 4 for detailed installation steps.
USE
USE USE
USE
INST LL TION
INST LL TIONINST LL TION
INST LL TION

TECHNICAL SPECIFCATIONS
Rev 05/11
MODEL# MC600
ELECTRIC VERSION Element
specifications 300W, 110V, 48 cord,
UL approved. See separate technical
sheet for details of CSA-US approved
hardwire kit.
HYDRONIC VERSION Heat ouput
2217 BTU. ½ BSPT tappings.
Steel towel warmers should only
be used in a closed water system,
incorporating a rust inhibitor.
CARE & MAINTENANCE A periodic
wash using warm water and a soft
cloth will retain the high quality finish
of your towel warmer for many years
to come. ON NO ACCOUNT should
any household bleaches, detergents,
abrasive polish, steel wool or similar
cleaning agents be used on this
product.
WALL FIXING Towel warmer
brackets must be securely fastened
to either masonry, wall studs or
plywood board in accordance with
the fitting instructions.
PACKAGING Packaged for regular
UPS type shipping.
WARRANTY Frame 5 years –
Heating element 5 years.
17 1/4 ”
Approximate valve centers

INSTALLATION STEPS
1. Check that all the installation pack contents ha e been recei ed. There should be 3
items as shown below:
2. Determine location of towel warmer and install heating system pipework to proposed towel
warmer location. Tee off the main circuit to pro ide a branch circuit for the towel warmer.
Refer to page 3 for piping locations. The al e shown abo e is an angled al e which re-
quires piping through the wall. Straight al es are also a ailable for piping coming through
the floor. Piping to towel warmer al es should be 1/2 ” copper. Note: Position towel
Note: Position towel Note: Position towel
Note: Position towel
warmer so that at least two of the brackets are attached to a firm wall stud.
warmer so that at least two of the brackets are attached to a firm wall stud.warmer so that at least two of the brackets are attached to a firm wall stud.
warmer so that at least two of the brackets are attached to a firm wall stud.
Brackets Valve X 2
Hot water to oth-
er appliances
Valve
Water Heater irculator Pump
Typical Heating System Diagram

Bracket Installation ( u se diagram below as a guide )
2. Insert buffers ( D ) into bracket ( B ) . Attach bracket ( B ) to top and bottom towel
rack bars with short bolt ( E ) . Note: position brackets as near to the edge as possible
in order to gi e as much hanging space for the towel as possible.
3. Next, using either the diagram on page 3 as a guide or by measuring the centers of
bracket ( B ) , fix bracket ( A ) to the wall with screw ( C ) to stud work with slots fac-
ing up on upper brackets and slots facing down on lower brackets.
4. Slide towel rack onto mounting brackets and install long bolts ( F ) , tightening all four
bolts.
INSTALLATION STEPS

Valve body
#2 compression fitting
# 1 male stub
INSTALLATION STEPS
Val e Installation: ( use Diagram below as a guide )
7. Thread # 1 male stub into female inlets on bottom of towel warmer using a threadlocking
substance.
8. Push # 2 compression fitting onto supply pipe and tighten onto al e body.
9. Tighten #1 male stub ( now attached to towel warmer ) onto al e.
10.Insert blanking plugs ( pro ided with brackets ) into female inlets located at the top of
towel warmer.
11.Check for leaks.
NOTE: this diagram shows a PX40 angled al e. PX41 straight al es are also
a ailable. The same installation steps can be followed, but supply pipes must
enter through the floor rather than through the wall.

CARE & MAINTENANCE
For best results, keep the following in mind to retain the high quality finish of your ARTOS towel
warmer:
• se a soft, dampened sponge or cloth.
• On no account shout you use an abrasive material such as a brush, scouring pad or steel wool to
clean surfaces.
• Polishwith a soft dry cloth
WARRANTY
This warranty covers against defective products for a period of five years. nder the warranty we will
provide replacement components or products at our discretion. Damage caused by accident, misuse,
abuse, improper installation, improper cleaning or alteration will void the warranty. . Westover, Inc is
not responsible for labor charges, installation or other incidental or consequential costs.
PLEASE REGISTER THIS PRODUCT ONLINE AT WWW.ARTOS-WESTOVER.COM
Item №: MC600H-
Serial №
