ASBER AESP-18-2 User manual

STOCK POT
Manual Instructions
AESP-18-2, AESP-48-4
DOCUMENT CODE:
Manual instructions
Installation and Operation
Manuel talimatları
Kurulum ve Çalıştırma
Manual de instrucciones
Uso y mantenimiento
Manuel d’instructions
Installation et fonctionnement
Bedienungshinweise
Installation und Betrieb
Manual do instruções
Instalação e Operação
Ręczny
Obsługa i konserwacja
ES
EN
DE
TK
FR
PT
PL

ii
asberprofessional.com
INDEX
ENGLISH
MACHINE INTRODUCTION.......................................................................................................................................1
1.1 INTRODUCTION TO MACHINE & MODELS...............................................................................................1
1.2 IMPORTANT SAFETY INFORMATION .......................................................................................................1
1.3 SPECIFICATION CHART.............................................................................................................................1
INSTALLATION..........................................................................................................................................................2
2.1 Transport, handling, unpacking, location ................................................................................................2
2.2 Manufacturer’s identification label description......................................................................................2
2.3 Installation and assembly ........................................................................................................................3
2.3.1 UNCRATING .....................................................................................................................................3
2.3.2 INSTALLATION OF LEGS ...................................................................................................................3
2.4 Gas Connections ......................................................................................................................................4
2.4.1 MANUAL SHUT OFF VALVE ..............................................................................................................4
2.4.2 PRESSURE REGULATOR....................................................................................................................4
2.4.3 THIS APPLIANCE IS EQUIPPED FOR NATURAL GAS. .........................................................................4
2.4.4 PRESSURE REGULATOR CONVERSION .............................................................................................5
2.5 Location ...................................................................................................................................................5
2.6 CLEARANCES ............................................................................................................................................6
2.7 AIR SUPPLY & VENTILATION ....................................................................................................................6
OPERATION..............................................................................................................................................................7
3.1 General information. ...............................................................................................................................7
3.2 LIGHTING INSTRUCTIONS ........................................................................................................................7
3.3 TOP BURNERS ..........................................................................................................................................7
3.4 BROILER/GRIDDLE....................................................................................................................................7
MAINTENANCE ........................................................................................................................................................8
4.1 CLEANING ................................................................................................................................................8
4.1.1 DAILY................................................................................................................................................8
4.1.2 STAINLESS STEEL PARTS...................................................................................................................8
TROUBLE SHOOTING ...............................................................................................................................................9
WARRANTY ........................................................................................................................................................... 10
5.1 Limited Warranty.................................................................................................................................. 10

1asberprofessional.com
asberprofessional.com
MACHINE INTRODUCTION
1.1 INTRODUCTION TO MACHINE & MODELS
All equipment manufactured by ASBER. is for use with the type of gas specified on the rating plate
and for installation will be in accordance with National Fuel Gas Code ANSI Z223.1 (latest edition)
Instruction to be followed in the event the user smells gas shall be posted in a prominent location.
This information shall be obtained by consulting the local gas supplier.
PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCES.
This equipment is design engineered for commercial use only
1.2 IMPORTANT SAFETY INFORMATION
WARNING: Improper installation, adjustment, alteration, service or maintenance
can cause property damage, injury or death. Read the installation, operating and
maintenance instructions thoroughly before installing or servicing this
equipment.
FOR YOUR SAFETY: Do not store or use gasoline or other flammable vapors or
liquids in the vicinity of this or any other appliance.
1.3 SPECIFICATION CHART
MODEL
BTU’S LP
AT 10’’
W.C.
ORIFICE
SIZE LP
BTU’S NG
AT 5’’
W.C.
ORIFICE
SIZE NG
BURNERS
ALTITUDE
BURNER RANGE
AESP 18-2
90,000
47
100,000
28
2
AESP 48-4
180,000
47
200,000
28
4

2asberprofessional.com
asberprofessional.com
INSTALLATION
2.1 Transport, handling, unpacking, location.
2.2 Manufacturer’s identification label description.
2.3 Installation and assembly.
2.4 Gas Connections
2.1 Transport, handling, unpacking, location
Upon receiving your new ASBER Equipment, check the package and the machine for any damages that
may have occurred during transportation. Visually inspect the exterior of the package. If damaged, open
and inspect the contents with the carrier. Any damage should be noted and reported on the delivering
carrier’s receipt.
In the event that the exterior is not damaged, yet upon opening, there is concealed damage to the
equipment notify the carrier immediately. Notification should be made verbally as well as in written form.
Request an inspection by the shipping company of the damaged equipment. Retain all crating material
until inspection has been made. Finally, contact the dealer through which you purchased the unit.
2.2 Manufacturer’s identification label description
Information on this plate includes the model, serial number, BTU / hour input of the burners operating
gas pressure in inches WC, and whether the appliance is orifices for natural or propane gas.
When communicating with factory about a unit or requesting for special parts or information,
Rating plate data is essential for proper identification.
ASBER COOKING APPLIANCES MUST BE CONNECTED ONLY TO THE TYPE OF GAS
IDENTIFIED ON THE RATING PLATE
Model
Gas Type
Serial Number

3asberprofessional.com
asberprofessional.com
2.3 Installation and assembly
SHIPPING DAMAGE CLAIM PROCEDURE
The equipment is inspected and crated by skilled personnel before leaving our factory. The
transportation company assumes full responsibility for safe delivery upon acceptance of this equipment.
If shipment arrives damaged:
Visible loss or damage: Note on freight bill or express delivery and signed by person making
delivery.
File claim for damages immediately: Regardless of extent of damages.
Concealed loss or damage: If damage is noticed after unpacking, notify Transportation
Company immediately and file “Concealed Damage “claim with them. This should be done
within (15) days from date of delivery made to you. Retain container for inspection.
2.3.1 UNCRATING
Cut and remove the outer packaging. Cut the (4) clamps that hold the equipment to the skid lift the unit
off the skid.
2.3.2 INSTALLATION OF LEGS
LEGS ASSEMBLY:
Mount Legs on bottom of product, the appliance may be further leveled with adjustment in
the foot of the leg.

4asberprofessional.com
asberprofessional.com
2.4 Gas Connections
The gas supply (service) line must be the same size or greater than the inlet line of the appliance.
ASBER appliances use a ¾” NPT inlet.
Pipe joint compound must be resistive to Natural or LP gas.
For equipment using propane gas do not install supply lines with a diameter less than ½ under any
circumstances.
All connections must be tested with a soapy water solution before lighting any pilots.
The appliance shall be connected to the fuel gas for which it was designed. No attempt shall be made to
convert the appliance from the gas specified on the rating plate for use with a different gas without
consulting the installation instructions, the serving gas supplier, or the appliance manufacturer for
complete instructions.
2.4.1 MANUAL SHUT OFF VALVE
This installer supplied valve must be in the gas service line ahead of the appliance regulator in
the gas stream and in a position accessible in the event of an emergency.
2.4.2 PRESSURE REGULATOR
Commercial cooking equipment must have a pressure regulator on the incoming service line for
safe and efficient operation; the gas pressure regulator supplied by ASBER must be installed at
the gas inlet of each piece of equipment.
The regulators supplied along with ASBER appliances, will have 3/4”inlet/outlet openings and
are adjusted at the factory for 5” WC (natural gas) or 10” WC (propane gas) depending on
customer’s ordering instructions.
Prior to connecting the regulator, check the incoming line pressure, as these regulators can only
withstand a maximum pressure of ½” PSI (14”WC). If the line pressure is beyond this limit, a
step down regulator will be required.
The arrow shown on the bottom of the regulator body shows the gas flow direction, it should
point downstream to the appliance. The BLUE air vent cap on the top is part of the regulator
and should not be removed.
Any adjustments to the regulator should be made by qualified service personnel only with the
proper equipment.
2.4.3 THIS APPLIANCE IS EQUIPPED FOR NATURAL GAS.
This appliance is equipped with orifices sized (# 36) for operation with natural gas.
For conversion to LP (PROPANE) gas see instruction plate in the appliance. Gas conversion
must be performed by qualified or authorized personnel. Orifices (#52) necessary for LP
(PROPANE) and regulator for conversion are provided on accessory box.

5asberprofessional.com
asberprofessional.com
2.4.4 PRESSURE REGULATOR CONVERSION
Failure to install the pressure regulator will void the appliance warranty
The fryer needs to be restrained to prevent tipping when installed in order to avoid the
splashing of hot liquid. Install the fryer connection to a battery of appliances or installing the
fryer in an alcove, or by separate means, such as adequate ties
2.5 Location
• Installation of the equipment should be performed by qualified, certified, and authorized personnel
who are familiar and experienced with local installation codes.
• Before Installation please read instructions completely and carefully.
• Do not remove permanently affixed labels, warnings or plates from the product.
• Please observe all local and national codes and ordinances
• Installation must conform with local codes, or in the absence of local codes, the National
Fuel Gas Code, ANSI Z223.1 (latest edition)
• The appliance must be isolated from gas supply piping system, by closing its individual manual shut
off valve during any pressure testing of the gas supply piping system at test pressure equal to or less
than ½ psi (3.45kpa)
A. Remove cap and snap out plastic plunger from bottom of cap.
B. Turn plunger over and snap back in original location.
C. Re-insert the cap assembly into the regulator and tighten.

6asberprofessional.com
asberprofessional.com
2.6 CLEARANCES
The appliance area must be kept free and clear of all combustibles
SRR, SRMR Series products are for installation in Non-Combustible locations only.
COMBUSTIBLE
NON COMBUSTIBLE
SIDES
15 Inches
0 Inches
REAR
17 Inches
4 Inches
2.7 AIR SUPPLY & VENTILATION
The area in front of, around and above the appliance must be kept clear to avoid any obstruction of the
flow of combustion and ventilation air.
Adequate clearance must be maintained around the appliance for easy servicing. Provision should be
made for any commercial, heavy-duty cooking appliance exhaust combustion waste products to the
outside of the building. Usual practice is to place the appliance under an exhaust hood, which should be
constructed in accordance to the local codes. Strong exhaust fans in this hood or in the overall air
conditioning system can produce a slight vacuum in the room and / or cause air drafts, either of which
can interfere with the pilot or burner performance and could be difficult to diagnose. Air movement
should be checked during installation. Air openings or baffles may have to be provided in the room, if
pilot or burner outage problem persists.

7asberprofessional.com
asberprofessional.com
OPERATION
3.1 General information.
3.2 Lighting Instructions..
3.1 General information.
Operation of this equipment must be performed by qualified or authorized personnel who have read and
are familiar with the functions of the equipment.
3.2 LIGHTING INSTRUCTIONS
1. Set the thermostat and the gas tap dial on the combination gas valve to the “OFF” position.
2. Wait for five minutes.
3. Turn gas tap dial on the combination gas valve to “Pilot” position.
4. Depress the gas tap dial and apply a lighted match or taper to the pilot.
5. Hold the gas tap dial depressed for about 30 seconds or until pilot stays lit before releasing.
6. If the pilot does not stay lit, repeat step 4 and 5.
7. Turn gas tap dial on the combination gas valve to “on” position.
8. Turn the thermostat to the desired temperature.
3.3 TOP BURNERS
All top section burners are equipped with constant burning pilots. These are to be manually lighted
immediately after the gas is turned on and can be rechecked for proper adjustment. All adjustments can
be made with a screw driver to the brass pilot valve accessible through the valve cover.
3.4 BROILER/GRIDDLE
The pilot should be lighted immediately after the gas is turned on and the system is checked for leaks.
The pilot can be reached with a long match through the valve cover, or by lifting the plate upward and
accessing through the top. Adjustment of the pilot flame can be made with a screwdriver to the pilot
valve, accessible through the valve cover.
WARINING
Hot oil and hot surfaces can cause severe burns. Use caution when operating the fryer.
Do not attempt to move the fryer filled whit hot oil or shortening.
Do not go near the area directly above the flue when fryer is operation.
Severe burns may be caused.
Drain hot oil in metal containers, do not use plastic buckets or glass containers.

8asberprofessional.com
asberprofessional.com
MAINTENANCE
4.1 Cleaning
4.1 CLEANING
For continued performance efficiency and longevity of your Fryer it is essential to carry out a good
maintenance program.
4.1.1 DAILY
OPEN BURNERS / HOT PLATES
1. Remove all top grates.
2. Lift off the burners heads and venturies by raising the head slightly, sliding to the rear
and lifting upwards.
3. Wash off the above in hot soapy water.
4. Re-install parts in the reverse order.
GRIDDLES
1. Scrape with a nylon griddle scraper to remove the cooked spills. When absolutely
necessary use a fine grained stone to scrape.
2. Wipe away any griddle stone dust and food particles with burlap.
3. Wash with hot, soapy water, and then rinse with vinegar and water.
4. Rinse again with clear water.
5. Re-oil with shortening or liquid frying compound.
6. DO NOT FLOOD A HOT GRIDDLE WITH COLD WATER. This could cause warping
and griddle plate to crack.
4.1.2 STAINLESS STEEL PARTS
Do not use steel wool, abrasive cloths, cleansers or powders to clean stainless steel surfaces.
All stainless steel parts should be wiped regularly with hot soapy water during the day and a
stainless steel liquid cleaner at the end of the day. To remove encrusted materials, soak in hot
water to loosen the material, and then use a wood or nylon scraper. NOT USE a metal knife,
spatula, or any other metal tool to scrape stainless steel. Scratches are almost impossible to
remove.
Contact the factory, factory representative or a local service company to perform all Maintenance and
Service Repairs.

9asberprofessional.com
asberprofessional.com
TROUBLE SHOOTING
PROBLEM
PROBLEM CAUSE
SOLUTION
BURNER AND/OR PILOTS
NOT TURN ON
GAS SUPPLY TO COOKING
EQUIPMENT IS OFF
TURN ON GAS SUPPLY
UNIT PRODUCING CARBON
DEPOSITS
GAS TYPE
VERIFY CORRECT GAS
GAS SUPPLY PRESURE
CONTACT LOCAL GAS
SUPPLIER
PRIMARY AIR NOT
ADJUSTED PROPERLY
ADJUST AIR SHUTTER
ORIFICE TOO BIG
VERIFY ORIFICE SIZE
PILOT WILL NOT REMAIN LIT
PILOT FLAME NOT
ADJUSTED
ADJUST PILOT FLAME
DRAFT CURRENTS NEAR
EQUIPMENT
FIX DRAFT
NOT ENOUGH VENTILATION
CONTACT HVAC
CONTRACTOR
DEBRIS OR GREASE
CLOGGING PILOT BURNER
CLEAN DEBRIS AND GREASE
FROM PILOT BURNER
EXCESSIVE FLARE-UP
OVERLOAD OF OIL AND
LEFTOVERS
CLEAN AND PREPARE PAN
NOT HEATING PROPERLY
ORIFICES DIRTY/CLOGGED
CLEAN ORIFICE, MAKE SURE
THERE IS NO RESTRICTION
IN THE ORIFICE BURNER
LOW GAS PRESSURE
INCREASE GAS PRESSURE
TO 5” WC (NAT) OR 10” WC
(L.P.)
GRATES DIRTY/CLOGGED
CHECK AND CLEAN TOP
GRATES
IF THE VENTILATION IS TO
STRONG IT WILL DRAFT
HEAT FROM THE
COOKING/BROILING
SURFACE
CALL HVAC CONTRACTOR

10 asberprofessional.com
asberprofessional.com
WARRANTY
5.1 Limited Warranty
ASBER warrants its new product(s) to be free from defects in material and workmanship for a period of one (1) year from the
original date of installation not to exceed 15 months from date of shipment from our factory. Equipment sold and installed for
residential use, or outside the continental US is excluded from this warranty.
This warranty is limited to product(s) sold to the original commercial user. The liability of ASBER is limited to, at ASBER’s
option, the repair or replacement of any part (ground shipping only) found by ASBER to be warranted herein. ASBER shall
bear the normal labor charges for repair of replacement to the extent that such repair or replacement is performed within (2)
two hours or up to 100 miles total of the office of an authorized service agency, within the continental US and during regular
(straight time) hours. Travel outside of the (2) two hours or 100 miles, and any work performed at overtime or weekend rates
would be the responsibility of the owner/user. Defective parts must be returned to ASBER, freight pre-paid, for Warranty
inspection.
ASBER assumes no responsibility for any product not installed properly in accordance with the instructions supplied with the
equipment by an authorized representative. Any equipment which has been modified by unauthorized personnel or changed
from its original design is not covered under this warranty. Furthermore, ASBER assumes no obligation for any product
which has been subject to misuse, abuse or hard chemicals. Normal maintenance as outlined in the instructions is the
responsibility of the owner-user and is not a part of this warranty. Normal parts wear and maintenance is also not covered by
this warranty. This warranty is in lieu of any other agreement, expressed or implied, and constitutes the only warranty of
ASBER with respect to the product.
This states the exclusive remedy against ASBER relating to the product(s) whether in contract or in tort or under any other
legal, theory, and whether arising out of warranties, representations, instruction, installation or defects’ from any cause.
ASBER shall not be liable whether in contract or in tort or under any other legal theory for loss of revenue or profit, or for any
substitute use or performance or for incidental, indirect, special or consequential damages, or for any other loss or cost of
similar type.
Proper installation, initial check out, air shutter adjustments, or normal maintenance such as lubrication, adjustment or
calibration of controls is the responsibility of the dealer, owner-user or installing contractor and is not covered by this
warranty.
Parts warranty cover –ASBER warrants all new machine parts produced authorized by ASBER to be free from defects in
material and workmanship for a period of 90 days from the Warranty Commencement Date. If any defect in material and
workmanship is found to exist within the warranty period ASBER will replace the defective part without charge. Defective
parts become the property of ASBER.
Warranty Exclusions
Negligence or Acts of God.
Thermostat calibrations after (30) thirty days from equipment installation due.
Air and Gas adjustments.
Adjustments to burner flames and cleaning of pilot burners.
Failures caused by erratic voltages or gas supplies.
Unauthorized repair by anyone other than an ASBER Authorized Service Center.
Damage in shipment.
Alteration, misuse or improper installation.
If serial number has been removed or altered.
Thermostats and safety valves with broken capillary tubes.
Ordinary wear and tear.

ASBER
Circuito Exportación N° 201
Parque Industrial Tres Naciones
San Luís Potosí, S.L.P. México
13105 NW 47th Ave
Miami, Fl. 33054
www.asberprofessional.com
MULTI-SOLUTION MANUFACTURER OF FOODSERVICE EQUIPMENT
