Ascaso Steel User manual

Manual del usuario (p.4)
Users manual (p.26)
Benutzerhandbuch (p.48)
Gebruikershandleiding (p.70)
Manuel de l’utilisateur (p.92)
Steel -Steel PID
MAN-38 V7 / 2022
MAN.38 V7 - MANUAL STEEL-STEEL PID 2022.indd 1MAN.38 V7 - MANUAL STEEL-STEEL PID 2022.indd 1 01/06/2022 9:30:0701/06/2022 9:30:07

2
ascaso
EC DIRECTIVE 2002/96/EC
Reciclaje de su cafetera
Las cafeteras pueden contener materiales reciclables.
Contacte con su distribuidor o con el centro de reciclaje de su localidad.
Recycling
Coffee makers may contain recyclable materials.
Please contact your distributor or your local waste collection centre.
Recycling Ihrer Kaffeemaschine
Die Kaffeemaschinen können recycelbare Teile enthalten.
Kontaktieren Sie Ihren Händler oder das Recycling-Center Ihrer Stadt.
Recyclen van uw koffiezetapparaat
Koffiezetapparaten kunnen recycleerbare materialen bevatten.
Neem contact op met uw dealer of met het inzamelpunt in uw woonplaats.
Recyclage de votre cafetière.
Les cafetières peuvent contenir des matériaux recyclables.
Contactez votre distributeur ou le centre de recyclage de votre ville.
MAN.38 V7 - MANUAL STEEL-STEEL PID 2022.indd 2MAN.38 V7 - MANUAL STEEL-STEEL PID 2022.indd 2 01/06/2022 9:30:0701/06/2022 9:30:07

3
ascaso
Introducción
Gracias por haber adquirido un producto ascaso . Con él podrá obtener el
mejor café espresso y deliciosos cappuccinos.
Su máquina de café ha sido diseñada y construida aplicando las últimas
innovaciones tecnológicas, tanto en el ámbito informático como de ingeniería,
por lo que el resultado es un producto de alta calidad, seguro y fiable.
Introduction
Thank you very much for purchasing an ascaso product. This machine makes
the best espresso coffee and delicious cappuccinos.
Your coffee machine has been designed and built using the latest technological
computing and engineering innovations. It is therefore a high-quality, safe and
reliable product.
Einleitung
Danke, dass Sie ein Produkt von ascaso erworben haben. Damit können Sie
den besten Espresso und köstliche Cappuccinos zubereiten.
Ihre Kaffeemaschine wurde in Bezug auf Informatik und Technik mit den
neuesten technologischen Innovationen entworfen und gebaut. Das Ergebnis ist
ein hochwertiges, sicheres und zuverlässiges Produkt.
Inleiding
Hartelijk dank voor het aankopen van een ascaso . Daarmee kunt u de beste
espresso´s en heerlijke cappuccino´s bereiden.
Uw koffiezetapparaat is ontworpen en ontwikkeld volgens de laatste
technologische innovaties, zowel wat betreft informatica als techniek. Het
resultaat is een hoogwaardig, veilig en betrouwbaar product.
Introduction
Merci d’avoir acheté un produit ascaso . Il vous permettra d’obtenir le meilleur
café expresso et de délicieux cappuccinos.
Votre machine à café a été conçue et construite en appliquant les dernières
innovations technologiques, tant en informatique qu’en ingénierie, ce qui donne
un produit de haute qualité, sûr et fiable.
MAN.38 V7 - MANUAL STEEL-STEEL PID 2022.indd 3MAN.38 V7 - MANUAL STEEL-STEEL PID 2022.indd 3 01/06/2022 9:30:0701/06/2022 9:30:07

26
ascaso
IMPORTANT SAFEGUARDS
READ ALL INSTRUCTIONS
1-The machine is only suitable for
installation in places where its use
and maintenance are restricted to
qualified personnel only.
2-Do not allow the machine to
be operated by children or the
inexperienced.
3-Do not carry out cleaning or
maintenance while the machine is
plugged in.
4-Do not disconnect the Coffee
machine by pulling on the power
cord.
5-To ensure safety, if the power cord
is damaged, it should be replaced by
the manufacturer, after-sales Service
or similar qualified personnel only.
6-Never turn on a defective machine
or one with a damaged power cord.
7-Do not touch hot surfaces. Use
handles or knobs.
8-Unplug from outlet when not in use
and before cleaning. Allow to cool
before putting on or taking off parts,
and before cleaning the machine.
9-The use of accesory attachements
not recommended by the machine
manufacturer may result in fire,
electric shock or injury to persons.
10-Do not let cord hang over Edge
of table or counter, or touch hot
surfaces.
11-Do not place on or near a hot gas
or electric burner, or in a heated oven.
12-Always attach plug to the machine
first, then plug cord into the wall
outlet. To disconnect, turn any control
to “off”, then remove plug from wall
outlet.
13-Do not use the machine for other
than intended use.
14-Do not handle the machine with
wet feet or hands.
15-Place the machine on a flat, stable
surface, out of the reach of children
and animals and away from hot
surfaces.
16-Do not inmerse in water.
17-In the event of incorrect
performance or malfunction, switch
off the machine and unplug it.
18-This machine is not designed
to be used by people with reduced
physical, sensory or mental abilities
(including children), or who lack
experience or knowledge, except
where such persons have had due
instruction or supervisión regarding
the use of the machine by a person
responsable for their safety.
19-Children should be supervised
to ensure they do not play with the
machine.
20-This machine is not designed for
outdoor use.
21-Do not use this machine if room
temperature is above 40°C or below
0°C.
ENGLISH
MAN.38 V7 - MANUAL STEEL-STEEL PID 2022.indd 26MAN.38 V7 - MANUAL STEEL-STEEL PID 2022.indd 26 01/06/2022 9:30:2101/06/2022 9:30:21

27
ascaso
22-Cleaning and user maintenance
shall not be made by children without
supervision.
23-This appliance is intended
to be used in household and
similarapplications such as:
•Staff kitchen áreas in shops, offices
and other working environments
•Farm houses
•By clients in hotels, motels and other
residential type environments
•Bed and breakfast type
environments.
24-Avoid spillage on the connector.
25-Misuse of the machine can cause
injury.
26-Caution: the heating element is
subject to residual heat after use.
27-Ignoring these warnings can
jeopardise the safety of both the
machine and the user.
SAVE THESE
INSTRUCTIONS IN A SAFE
PLACE.
ENGLISH
MAN.38 V7 - MANUAL STEEL-STEEL PID 2022.indd 27MAN.38 V7 - MANUAL STEEL-STEEL PID 2022.indd 27 01/06/2022 9:30:2101/06/2022 9:30:21

28
ENGLISH
C
l
i
c
k
25
C
l
i
c
k
26
C
l
i
c
k
25
C
l
i
c
k
25
25 DISPLAY 26
See/Select coffee temperature
Setup
Program the dose Make a coffee
wait 3s to fix
(up)
(down)
DISPLAYTEMPERATURE
Ud
C
l
i
c
k
25
C
l
i
c
k
26 ºC/ºF
Pr
C
l
i
c
k
26
26 25
Press3s
(CELSIUS/FAHRENHEIT)
(PREINFUSION)
(CHRONOMETER)
(STAND-BY)
(TEMPERATURE DIFFERENTIAL SETTING)
Click & drop
to make a coffee
Press and hold ‘x’ or ‘y’ seconds
and drop to set the dose
X’’
Y’’
C
l
i
c
k
25 Cr
C
l
i
c
k
26 ON/OFF
(STEAM(ONLY STEEL DUO))
C
l
i
c
k
25 St
C
l
i
c
k
26 ON/OFF
C
l
i
c
k
25 OFF
C
l
i
c
k
26 OFF/0,5h/1h/2h
C
l
i
c
k
25 U
C
l
i
c
k
26
C
l
i
c
k
25
Quick
Guide
PID
0-0/5-5
MAN.38 V7 - MANUAL STEEL-STEEL PID 2022.indd 28MAN.38 V7 - MANUAL STEEL-STEEL PID 2022.indd 28 01/06/2022 9:30:2101/06/2022 9:30:21

29
ascaso
230VAC - 50Hz 120VAC - 60Hz Weight
(kg) Dimensions (L x W x D)*
Tank
capacity
(L)
Power
(W) Intensity (A) Power (W) Intensity (A)
UNO 1050 5 1050 9 11 270 x 360 x
315 2
DUO 2100 10 2100 20 15
1. Technical features
2. Diagram. Start-up.
3. Making coffee
4. Making cappuccino
5. Making hot water
6. Specific functions of the PID
model
7. Stand-by mode
8. Maintenance and cleaning
9. Warranty
10. EC Declaration of Conformity
11. Lights and alarms
12. Troubleshooting
Contents
1. Technical features
Features
20 bar pump pressure
Body in epoxy-painted steel and
stainless steel.
Professional system, exchanger with
stainless steel ducts.
Food-safe materials.
Electronic temperature control.
Working pressure gauge in PID models.
* Length x width x depth (mm)
Frother and hot water.
Separate steam and water outlets
(DUO models).
Active cup warmer in PID models.
Lit work zone.
EC certification.
ENGLISH
MAN.38 V7 - MANUAL STEEL-STEEL PID 2022.indd 29MAN.38 V7 - MANUAL STEEL-STEEL PID 2022.indd 29 01/06/2022 9:30:2101/06/2022 9:30:21

30
ascaso
2. Start-up diagram
UNO / DUO
1
2
3
4
5
6
7
8
9
10
11
13
14
15
16
20
21
22
23
24
25 26
ON/OFF switch
Coffee switch
Steam switch
Steam/hot water control (UNO), steam (DUO)
Steam/hot water wand (UNO) - Steam wand (DUO)
Coffee temperature pilot light / Coffee group II temperature
Mobile filter holder (ground)
Coffee group
Cup warmer (Caution: hot surface)
OPV (overpressure valve)
Tray
ON/OFF pilot light
Hot water switch
Steam pilot light
Hot water wand (DUO)
Pressure gauge
Coffee tamper
Spoon (7 g)
Hot water pilot light
Screen (PID models)
PIC system control buttons.
Versatile
1 coffee 2 coffees
1 coffee
Super
cream
2 coffees
Super
cream
Pod
Fixed filter holder
(Only pod option)
OFF
ON
1
Capsule adapter filter
holder (FAP)
7
1 Blind
ENGLISH
MAN.38 V7 - MANUAL STEEL-STEEL PID 2022.indd 30MAN.38 V7 - MANUAL STEEL-STEEL PID 2022.indd 30 01/06/2022 9:30:2101/06/2022 9:30:21

31
ascaso
ENGLISH
21
21
22
8
9
11
4
20 1214 3
5
15
23
24
26
6
13
16
10 25
MAN.38 V7 - MANUAL STEEL-STEEL PID 2022.indd 31MAN.38 V7 - MANUAL STEEL-STEEL PID 2022.indd 31 01/06/2022 9:30:2201/06/2022 9:30:22

32
ascaso
The installer must read this manual
closely before start-up.
The operator should be an adult and
fully competent person.
Should any anomaly occur, please
contact your distributor.
Start-up
1. Check that the voltage is the same
as that indicated on nameplate of
the machine.
2. Fill the water tank with fresh water
(see figure 1). Check that the
water inlet tube is immersed in
the tank.
Figure 1
NB! We recommend using water
with a low mineral content. The
quality of the water will affect the taste
and quality of your coffee as well as
help avoid future malfunctions. Check
out our especial anti-lime scale filters
(optional).
3. Make sure that there is enough
water in the tank. Running the
machine without water may
damage the pump. Water levels
should be checked visually.
To reduce the risk of injury, do
not drape cord over the counter
top or table top where it can pulle
don by children or tripped over
unintentionally.
IMPORTANT:
UNO/DUO models. When turned
on for the first time, the machine
enters start-up mode. The pilot light
13
comes on and
6
flashes while
the machine heats up, until the right
temperature is reached. During this
process no service can be provided.
A.) Using the machine for the
first time or after a long interval.
Replacing the water in the circuit.
1. Turn the coffee maker on with the
general switch
1
in position (I).
2. Attach the empty filter holder
7
with a receptacle underneath.
3. Press the coffee switch
2
and let
approximately half a tank of clean
water flow through.
B.) PRIMING.
• If no coffee comes out.
• After a period without use.
• After generating steam.
• If the tank has been emptied.
In the DUO model, repeat point A).
In the UNO model, the priming
procedure should be carried out:
1. With the coffee maker on, turn on
the steam tap
4
.
2. Turn on the water function
14
and release some water (a cup)
through the steam wand
5
.
3. Turn off the water function
14
and
turn off the steam tap
4
. The
coffee maker is now ready to use.
UNO model only
C.) After producing steam, wait
5 minutes before making coffee.
Or carry out the priming operation,
but let the water flow (point B2) until
the temperature pilot light
6
stops
flashing.
ENGLISH
MAN.38 V7 - MANUAL STEEL-STEEL PID 2022.indd 32MAN.38 V7 - MANUAL STEEL-STEEL PID 2022.indd 32 01/06/2022 9:30:2201/06/2022 9:30:22

33
ascaso
3. Making coffee
Check your system: Ground, pod or
capsule.
Any type of coffee may be used,
ground or pod, thanks to the 5 filters
supplied: 2 ground filters (1- and
2-cup), 2 pressurised filters (1- and
2-cup Cream+) and 1 pod filter.
For optimal results, we advise using
ready mixes for espressos, as they
have the appropriate ground size for
use with ground filters. If the results
are not as expected, use pressurised
filters, which will give good results
regardless of ground size.
Regardless of the type of filter used
for ground coffee, and depending
on the whether the coffee comes out
quickly or slowly, we recommend
changing the type of coffee, the
ground size or experimenting with
compactness to suit your preference.
Figure 2BFigure 2A
Figure 3
If using ground coffee:
1. Turn on the machine, turning the
ON/OFF switch
1
to position
(I). Place the filter holder
7
(with
filter) in the group
8
.
2. UNO/DUO models. Wait for the
pilot light to come on
6
without
flashing. This takes approx 1.5
minutes. This shows that the water
has reached the right temperature.
Turn on the coffee switch
2
and
let water flow through the group.
Performing this procedure before
making coffee will eliminate
residues and establish the
temperature for optimal service.
3. The filter must be filled to 3/4 its
capacity, once the coffee has
been tamped down (see figure
2A).
4. Clean the coffee residues that
have been deposited on the
edges of the filter to ensure a
perfect fit.
5. Attach the filter holder
7
to the
group and
8
turn from left to
right, exerting sufficient pressure
at the end. (See figure 3).
6. Place the cup or cups on the tray
and turn on the coffee switch
2
.
7. When the coffee
NB! It is normal for the ground
coffee in the filter holder
7
to have
a liquid consistency if the filter holder
is immediately removed
7
after
delivery.
Dibujo 4
Dibujo 4
Figure 4
If pods or FAP-capsules are used:
Use the specific filter holder for
capsules or pods. Place the pod in
the filter holder (see figure 4). Follow
points 1, 2, 5, 6 and 7 as in the
previous section.
Ground (mobile filter holder)
ENGLISH
MAN.38 V7 - MANUAL STEEL-STEEL PID 2022.indd 33MAN.38 V7 - MANUAL STEEL-STEEL PID 2022.indd 33 01/06/2022 9:30:2201/06/2022 9:30:22

34
ascaso
Pod (fixed filter holder)
Proceed as follows:
1. Follow Points 1 and 2, as in the
section for ground coffee.
2. Place a tablet on the filter holder
and turn it gently to the right as
far as it will go. Do not force it,
closure is smooth. (See figure 5).
3. Point 5, 6, 7 and notes as in the
previous section.
NB! Do not remove or turn the
filter holder while the water is running
through, as the machine is under
pressure at this time.
Figure 5
General tips:
1. The filter holder
7
should always
be fitted in the machine
8
to keep
it warm. In the closed position.
2. Only in UNO models. If the
coffee does not come out hot
enough, turn on the steam switch
3 for 10 seconds. This raises
the temperature of the machine.
increases the working pressure
and turning to the left reduces it.
3. Place the cups on the cup warmer
9
. Espresso is best at optimal
temperature (40°C/105°F). (See
figure 6)
4. The coffee will continue to drip out
for a few seconds after the coffee
is switched off.
NB! Tamping: To obtain
perfect espresso, the coffee should
be firmly tamped down.
NB! Pressure gauge: The
right working pressure depends on
the type of coffee and the ground
size. In all cases, a working pressure
of between 9 and 12 bar is adequate.
In the PID versions, the temperature is
shown on the screen
24
included for
this purpose.
NB! The machine›s maximum
working pressure can be adjusted
using the OPV
10
next to the coffee
group
8
.
To do this, use the blind filter fitted
in the filter holder
7
, attach it to
the group
8
and turn on the coffee
switch
2
. The pressure can be
adjusted by turning the OPV
10
using
a flat-head screwdriver. Turning it
to the right increases the maximum
working pressure and turning it to the
left reduces it.
ENGLISH
Figure 6
MAN.38 V7 - MANUAL STEEL-STEEL PID 2022.indd 34MAN.38 V7 - MANUAL STEEL-STEEL PID 2022.indd 34 01/06/2022 9:30:2201/06/2022 9:30:22

35
ascaso
PID models - Programming
the coffee dose
PID models have a coffee dose
control function, so that the amount
of coffee required can be adjusted
for both the available options (small
coffee, large coffee).
There is a 3-position
2
coffee switch
for this process. The two available
coffee selections are obtained by
turning the switch to the top or bottom
positions, while the midpoint turns off
the coffee function.
NB! The coffee switch
2
on the
two PID models is not a permanent
setting. Once the function has been
activated, it returns to its original
position. The switch does not have to
stay in the working position; once the
programmed amount of coffee has
been obtained, the function will stop
automatically.
To programme the dose at either
of the two selections, just turn the
switch to the desired position until
the required dose is obtained. On
releasing it, the dose will have been
programmed.
WARNING: To avoid the risk of injury,
do not open the brew chamber during
the brew process.
4. Making cappuccino
True ‘cappuccino’ contains 25
millilitres of espresso coffee and
125 millilitres of cold steam-
whipped milk, which goes from 3
or 4 degrees centigrade to nearly
55 degrees centigrade. .Use fresh
cow’s milk with a protein content of
over 3.2 percent and a fat content
of 3.5 percent. Whip only the amount
required for one cup in a steel jug
to prevent it from mixing with other
odours or tastes.
The density of the cream must
be uniform and there must be no
separation from the liquid, or holes
or bubbles.
UNO model
1. Turn on the general switch
1
The pilot lights come on
13
, and
6
flash.
2. When the pilot light
6
stops
flashing, turn on the steam switch
3
. The pilot light comes on
15
and
6
flashes.
3. Turn on the hot water/steam knob
4
and let water flow until it runs
discontinuously. Turn it off.
4. Wait for the pilot light to
6
come
on without flashing This shows
that the water has reached the
right temperature. The pump will
start to work in bursts. When this
happens, turn on the knob again
to obtain steam
4
.
NB! The pilot light
6
will flash
faster for about 10 seconds before
steam is generated. Use this signal to
turn the knob on
4
.
5. Immerse about half of the steam
wand in the milk
5
to heat it.
6. When finished, turn both the water/
steam knob
4
and the steam
switch
3
off.
7. If you want to obtain more than
three consecutive cappuccino
services, or make more coffee
afterwards, see sections 2B and
2C.
NB! When the steam service is
finished, the machine temperature will
be too high to make coffee. The pilot
light
6
will flash until the machine
returns to the correct temperature.
Follow point 2.B to force cooling.
NB! The steam generation
system includes a safety limit that
cuts off the service after 3 minutes of
continual operation.
ENGLISH
MAN.38 V7 - MANUAL STEEL-STEEL PID 2022.indd 35MAN.38 V7 - MANUAL STEEL-STEEL PID 2022.indd 35 01/06/2022 9:30:2201/06/2022 9:30:22

36
ascaso
UNO PID model
1. Turn on the general switch
1
The
pilot lights come on
13
, and
6
flash. The PID system screen
24
shows the temperature rise.
2. When the pilot light
6
stops
flashing and the screen
24
shows
the pre-set coffee temperature,
turn on the steam switch
3
.
The pilot light
15
will flash,
indicating the heating process to
steam temperature. The screen
24
will flash the pre-set steam
temperature.
3. Turn on the hot water/steam knob
4
and let water flow until it is
running continuously. Turn it off.
4. Wait for the pilot light to
15
come
on without flashing This shows that
the water has reached the right
temperature. The temperature
value will also be shown steadily
on the screen
24
. The pump will
start to work in bursts. When this
happens, turn on the knob again
to obtain steam
4
.
NB! The pilot light
15
will flash
faster for about 10 seconds before
steam is generated. Use this signal to
turn the knob on
4
.
5. Immerse about half of the steam
wand in the milk
5
to heat it.
6. When finished, turn both the water/
steam knob
4
and the steam
switch
3
off.
7. If you want to obtain more than
three consecutive cappuccino
services, or make more coffee
afterwards, see sections 2B and
2C.
NB! The steam generation
system includes a safety limit that
cuts off the service after 3 minutes of
continual operation.
NB! When the steam service is
finished, the machine temperature will
be too high to make coffee. The pilot
light
6
will flash until the machine
returns to the correct temperature at
which point the screen
24
flashes the
pre-set coffee temperature. Follow
point 2.B to force cooling.
DUO models
1. Make sure that the main switch
1
is in position (II).
2. Press button
3
. The pilot light
15
comes on.
3. Open the steam knob
4
to get
steam. Whenever the switch is
turned on
3
the pilot light comes
on
15
.
4. Without turning the switch on,
3
the pilot light
15
will come on
at intervals. This does not affect
its use as the temperature is
automatically regulated.
5. Immerse about half the steam
wand
5
in the milk to heat it.
6. When finished, close the switch
3
and the steam knob
4
.
NB! After each use it is
advisable to release steam for 5
seconds to clean the tube and
prevent blockage. You can use
a toothpick or clip to clean the
absorption hole. Make sure the nozzle
is free of obstructions.
DUO PID models
1. Turn on the general switch
1
The
pilot lights come on
13
, and
6
flash. The PID system screen
24
shows the temperature rise.
NB! Check that the steam
generation system is on (see section
6 of this manual). Once activated,
the steam generation system starts
heating to the required temperature.
2. When the pilot light
6
stops
flashing and the screen
24
shows
the pre-set coffee temperature,
turn on the steam switch
3
.
If the temperature of the steam
generation system has not yet
ENGLISH
MAN.38 V7 - MANUAL STEEL-STEEL PID 2022.indd 36MAN.38 V7 - MANUAL STEEL-STEEL PID 2022.indd 36 01/06/2022 9:30:2301/06/2022 9:30:23

37
ascaso
reached the pre-set temperature,
the pilot light
15
will flash
indicating that the heating process
is continuing until the right
temperature is reached. Once the
correct temperature is reached,
the pilot light
15
remains lit without
flashing and steam generation
starts. Open the steam knob
4
to get steam through the steam
pipe
5
.
NB! Once the steam generation
process has started, the pilot light
15
will flash, indicating that the system
is heating to maintain the steam
temperature.
3. Immerse about half the steam
wand
5
in the milk to heat it.
4. When finished, close the switch
3
and the steam knob
4
.
NB! After each use it is
advisable to release steam for 5
seconds to clean the tube and
prevent blockage. You can use
a toothpick or clip to clean the
absorption hole. Make sure the nozzle
is free of obstructions.
NB! The steam generation
system includes a safety limit that
cuts off the service after 3 minutes of
continual operation.
Tips for making cappuccino.
1. TEXTURE: Obtaining cream
To obtain what is known as a
‘velvety’ consistency, place the
frother nozzle just beneath the
surface of the milk. To do this,
move the nozzle at different angles
(constantly under the surface of
the milk) to obtain an emulsion
with the circulating air. Once
textured, the milk may double its
volume. Remember to move the
jug and the steam nozzle very
close to the surface of the milk.
Upon completion of this operation,
the milk will be textured but still
cold.
2. TEMPERATURE: Heating the
milk
Once you have obtained the
texture, submerge the steam
nozzle as far as you can into the
jug. Move the jug in circles to
heat the milk until it reaches the
temperature you want.
NB! Texturing should be done
immediately beneath the milk’s
surface, while the nozzle should be
placed deeper for heating.
Texturing Heating
Once the milk is hot and textured, it
is ready to be served in the cup by
adding it to the espresso base.
Possible problems.
The cream may be too thin and lack
consistency.
1. One possible reason is that the
milk has already been heated.
The milk has been overheated (the
steam nozzle has been placed too
far into the jug and the milk has been
heated without allowing the air to
circulate on the surface) before the
required texture has been attained.
Step 1 (texturing) has not been
performed properly and the air
has not been allowed to work the
milk.
5. Making hot water
UNO model
1. Put a cup below the steam nozzle
5
.
2. Turn the hot water/steam knob
4
and press the switch
14
(the pilot
ENGLISH
MAN.38 V7 - MANUAL STEEL-STEEL PID 2022.indd 37MAN.38 V7 - MANUAL STEEL-STEEL PID 2022.indd 37 01/06/2022 9:30:2301/06/2022 9:30:23

38
ascaso
the screen
24
shows the time
taken to make a coffee, not the
temperature.
5. In stand-by mode, selecting an
activation period from 0 (off),
0.5/1/2 hours.
6. Correction parameter between
water temperature and
measurement in the machine. This
enables the water temperature to
be adjusted according to room
temperature.
7. On models DUO PID, this allows
you to switch the steam system
on and off, as well as to select its
temperature.
Enter the programming menu to
change the values of parameters 2 to
7. The process is as follows:
1. With the machine on, press and
hold button
26
while pressing
25
for 3 seconds. The screen
24
will show the words SET UP
alternately, indicating that the
programming menu has been
accessed.
2. Press button
25
to scroll through
the different parameters that can
be modified. Once the required
parameter is reached, press
button
26
to change its values.
3. To change the value of the
selected parameter, press buttons
25
and
26
to reduce or increase
the values, respectively.
4. After three seconds without
pressing a button, the system
saves the data and returns to its
initial setting.
NB! The PID system can be
reset in the following way: With the
machine on, press the button
26
for
three seconds. The screen
24
will
show the text PrS, indicating that the
factory settings have been reset.
light will come on
23
. Carry out
the reverse operation to obtain the
required water.
Remember: do not heat the milk to
over 75°C. Beyond this temperature
you will scald the milk and it will not
be suitable for cappuccino.
The espresso is released at 75-80°C.
The milk is textured and heated to
between 55-70°C. It is important
to maintain these temperatures for
serving. The cups should therefore
be warmed on the cup warmer. If this
is not possible, heat the cup with hot
water prior to use.
DUO models
3. Put a cup below the hot water
nozzle
16
.
4. Press the switch
14
, the pilot
light will turn on
23
. Carry out the
reverse operation to obtain the
required water.
6. Specific functions of the
PID model
The UNO PID and DUO PID models
have a control system consisting of
a screen(24) and two control buttons
25 26
1. Coffee temperature, shown on
screen. To change it, press the
button
25
, the screen will display
the message PrG, indicating that
it is in temperature programming
mode. Press button
25
to reduce
the temperature, press
26
to
increase it. After three seconds
without pressing a button, the
system will return to its initial
setting.
2. Temperature units, in °C or F.
3. Pre-infusion, selecting the pump
activation and stop time between
0 and 5 seconds.
4. Timer, showing the time taken
to make a coffee. This function
can be turned on or off in the
programming menu. If on,
ENGLISH
MAN.38 V7 - MANUAL STEEL-STEEL PID 2022.indd 38MAN.38 V7 - MANUAL STEEL-STEEL PID 2022.indd 38 01/06/2022 9:30:2301/06/2022 9:30:23

39
ascaso
The table of parameters and available values is given below:
Param. Value - Description Default value
Ud C Degrees Celsius C
F Degrees Fahrenheit
Pr 0 Pre-infusion off 0
1 Pre-infusion 1 s
2 Pre-infusion 2 s
3 Pre-infusion 3 s
4 Pre-infusion 4 s
5 Pre-infusion 5 s
Cr ON Timer on OFF
OFF Timer off
OFF OFF Stand-by mode OFF OFF
0.5 Stand-by mode ON, starting in 0.5 h
001 Stand-by mode ON, starting in 1 h
002 Stand-by mode ON, starting in 2 h
UX X indicates the offset between the
regulated temperature and the one
shown on the display
0
ST ON Steam generation ON (in DUO models) ON
OFF Steam generation OFF (in DUO models)
tSt Lets you modify the group temperature when
generating steam, from 110ºC to 165ºC. 165
CLn C.on Cleaning mode activated (only in DUO
models) OFF
OFF Cleaning mode deactovated (only in
DUO models)
Ct1 Total coffee counter (1 coffee) 0
Ct2 Total double coffee counter (2 coffees) 0
CP1 Partial coffee counter (1 coffee) 0
CP2 Partial double coffee counter (2 coffees) 0
rS1 Partial coffee counter reset (1 coffee) OFF
rS2 Partial double coffee counter reset (2 coffees) OFF
rSt Applies a total reset to the machine configuration,
returning to factory settings. OFF
ENGLISH
MAN.38 V7 - MANUAL STEEL-STEEL PID 2022.indd 39MAN.38 V7 - MANUAL STEEL-STEEL PID 2022.indd 39 01/06/2022 9:30:2301/06/2022 9:30:23

40
ascaso
7. Stand-by mode
An energy-saving mode is included in
the UNO/DUO/PID models, which
turns the machine off after 2 hours
without activating a function.
When stand-by mode is on, only pilot
light
13
remains lit while all others are
turned off.
To turn the machine on again, just
press any of the switches for the
machine to go back to its initial status,
as though turned on for the first time.
NB! UNO/DUO models.
The stand-by mode can be turned off
as follows:
1. With the machine off, turn on the
coffee
2
and steam
3
switches.
2. Turn on the general switch
1
3. After five seconds the steam pilot
light
15
shows the stand-by function
status. If it is flashing, it means the
function is off, if it remains steady, it
means the function is on.
4. To return to service mode, turn off the
coffee
2
and steam
3
switches.
NB! In PID models the function
can be turned on and off using the
PID system controls
24
and
25
. See
section 6 of this manual.
8. Maintenance and cleaning
Cleaning and preventive care of the
machine’s internal system is vital if an
espresso of optimum quality is to be
obtained.
General Notice! Cleaning and
maintenance should be done when
the machine is cool and disconnected
from the power source. Do not
immerse the machine in water. Not
dishwasher safe.
General Notice! Cleaning and
maintenance should be done when
the machine is cool and disconnected
from the power source. Do not
immerse the machine in water. Not
dishwasher safe.
Figure 8
1. External cleaning: To clean the
outside of the machine, use 96°
alcohol or specific products for
stainless steel.
• Remove and clean the tray from
time to time (figure 8).
• If you are not going to use the
machine for a long period of time,
empty the water tank.
• Immediately after use, clean the
steam nozzle with a damp cloth.
To clean the inside of the nozzle,
let the water circulate.
• Use a toothpick or paper clip to
clean the frother hole. This keeps
the tube free of obstructions.
2. Internal cleaning: Cleaning and
preventive care of the machine’s
internal system is vital if an
espresso of optimum quality
is to be obtained. To clean the
inside of the distribution unit, use
Ascaso Coffee Washer V.666.
This product is also useful for
descaling the machine. Regularly
descaling your coffee machine
helps ensure the excellent quality
of the coffee and prolong the
useful life of the machine.
Consult your distributor.
ENGLISH
MAN.38 V7 - MANUAL STEEL-STEEL PID 2022.indd 40MAN.38 V7 - MANUAL STEEL-STEEL PID 2022.indd 40 01/06/2022 9:30:2301/06/2022 9:30:23

41
ascaso
Recommendations for using Coffee
Washer:
To prevent lime-scale problems, you
can also use water treatment filters.
However, we recommend cleaning in
line with consumption. Use of filters
and Coffee Washer helps prolong the
life of the coffee machine in optimum
condition.
Internal cleaning (back flushing)
- blind filter. Weekly. Except pod
models (fixed filter holder).
Put the blind filter in the filter holder
and attach it to the machine. Press
the coffee switch. After 10 seconds,
press the switch to turn off the group.
Repeat the operation twice.
3. Cleaning of the steam unit on
DUO / DUO PID models.
For the internal cleaning of the
steam unit, use the product
Ascaso coffee washer V.666.
Consult your distributor.
• DUO PID models. Enter the
system parameters menu and
activate the CLn option. After 5
seconds the first phase of the
cleaning function will be activated,
showing on the screen
24
the
message CL.b, which will flash
until the temperature of the groups
reaches 75ºC. Until this is not
the case, the second phase of
the cleaning mode must not be
activated. Once the text CL.b is
fixed, we can activate the water
Coffees/day Descaling
>10 monthly
5-10 every 2 months
1-5 every 3 months
flow through the steam group by
activating the steam switch
3
. The pump will run continuously
instead of by pulses, with a time
limit for the operation of 3 minutes.
• DUO models. With the machine
off, activate the hot water
14
and steam
3
switches. Activate
the main switch
1
and leave
the previous ones activated 5
seconds, after this time the coffee
6
, hot water
23
and steam
15
pilot lights will flash indicating that
the cleaning mode is activated.
Then we can deactivate the
switches
14
and
3
and proceed
to the cleaning of the steam
group.
Attention! Once the cleaning
process is finished, we must turn
the machine off and on again to
return to the normal operating
mode.
Attention! In DUO PID models as
well as in DUO models, the CLn
mode can also be used to clean
the coffee group.
NB! Grinding system (mobile
filter holder).
We recommend that you do not leave
ground coffee or coffee pods in the
filter holder. The coffee will leave
behind residue that will affect the
cleanliness of the coffee machine and
the flavour of the coffee. Should this
happen, run a tank of water through
the machine.
4. Cleaning the filter holder and
shower heads.
• Mobile filter holder: Wash the
filter holder with hot water and pH
neutral soap. Rinse thoroughly.
Dry the holder with a soft cloth. Do
not put in the dishwasher.
• The filters, tray and tank can
be washed in the top of the
ENGLISH
MAN.38 V7 - MANUAL STEEL-STEEL PID 2022.indd 41MAN.38 V7 - MANUAL STEEL-STEEL PID 2022.indd 41 01/06/2022 9:30:2301/06/2022 9:30:23

42
ascaso
dishwasher. If you wash them
by hand, don’t forget to rinse
thoroughly. Dry with a soft cloth.
• Use a brush or similar to clean
off coffee grounds from the top
shower head.
NB! Grinding system (mobile
filter holder).
The top shower head should be
cleaned after 80 to 100 espresso
coffees. To do this, clean with hot
water and neutral soap. Reinsert it
after cleaning.
5. Cleaning the water tank.
Remove the tank from the side of the
machine. Clean the inside with water.
You can find all the information
you need on coffee machine
cleaning and maintenance at www.
ascaso.com.
9. Warranty
The warranty will be the receipt of
purchase. Please keep it. It must be
presented to the After-sales Service in
case of malfunction.
This machine is guaranteed by the
distributor from the date of purchase
for any manufacturing defects or
faulty parts.
The costs of postage or packaging
will be met by the user.
This warranty will be rendered invalid if:
1. There is no receipt of payment.
2. Improper use of the machine has
taken place.
3. There are lime-scale deposits
or the machine has not been
cleaned.
4. The machine has been
disassembled by staff other than
the Ascaso Official Technical
Assistance Network.
ENGLISH
MAN.38 V7 - MANUAL STEEL-STEEL PID 2022.indd 42MAN.38 V7 - MANUAL STEEL-STEEL PID 2022.indd 42 01/06/2022 9:30:2301/06/2022 9:30:23
