Ascentic HLS-71 Series User manual

HLS-71 Series
Intelligent Surround Sound Switcher
User Manual

Introduction
The HLS-71 Intelligent Audio Switcher controls multi-channel audio systems between two sets of outputs. This
device also monitors system health, with optional network control and monitoring capabilities.
Features
• Switches up to seven channels of High-Level audio
and one LFE audio channel between two outputs.
• Measures input voltage, current draw, and peak
current draw for device health monitoring.
• Optional IP version (HLS-71-IP) enables remote
access to device functions, conguration, and event
logs.
• Firmware updated via microSD.
GREEN POWER LED
YELLOW STATUS LED
SPEAKER
INPUT
SUBWOOFER
INPUT
SUBWOOFER
OUTPUT A
12V DC
POWER BUS
SUBWOOFER
OUTPUT B
LEFT | CENTER | RIGHT
(SPEAKER OUTPUTS A/B)
STR - NULL
SWITCH
RS-232
PORT
RS-485
BUS
MICRO SD
PORT
FEATURE
SWITCHES 1-4
ETHERNET PORT
(IP VERSION ONLY)

Communication
The HLS-71 Intelligent Audio Switcher has the default device ID 7. It can send and receive serial commands via
RS-485 at 57600 Baud, 8-N-1, and half-duplex; and via RS-232 at 115200 Baud, 8-N-1, and full-duplex. Both
conguration ports utilize a modular RJ-45 jack with the following pinouts:
RS-485 Pinout: RS-232 Pinout:
Pin # Function Pin # Function Pin # Function Pin # Function
P1 Orange White = ground P5 Blue White = switched
power bus (12V dev only)
P1 Orange White = ground P5
P2 Orange = ground P6 Green = Data B negative P2 Orange = ground P6 Green = RX or TX
P3 Green White = data A
positive
P7 Brown White = ground P3 Green White = TX or RX P7 Brown White = ground
P4 Blue = switched power
bus (12V devices only)
P8 Brown = ground P4 P8 Brown = ground
RS-232 Commands
Commands Command Format Response
REBOOT [DEV=7;REBOOT]
ANALOG ON [DEV=7;ANALOG=#;ON]
ANALOG OFF [DEV=7;ANALOG=#;OFF]
RESET DEFAULTS [DEV=7;RESET;DEFAULT]
GET CURRENT [DEV=7;CURRENT=1;NOW?] (DEV=7;CURRENT=1;NOW=$)
GET MAX CURRENT [DEV=7;CURRENT=1;MAX?] (DEV=7;CURRENT=1;MAX=$)
GET MIN CURRENT [DEV=7;CURRENT=1;MIN?] (DEV=7;CURRENT=1;MIN=$)
RESET CURRENT [DEV=7;CURRENT=1;RESET]
GET VOLTAGE [DEV=7;VOLTAGE=1;NOW?] (DEV=7;VOLTAGE=1;NOW=$)
GET MAX VOLTAGE [DEV=7;VOLTAGE=1;MAX?] (DEV=7;VOLTAGE=1;MAX=$)
GET MIN VOLTAGE [DEV=7;VOLTAGE=1;MIN?] (DEV=7;VOLTAGE=1;MIN=$)
RESET VOLTAGE [DEV=7;VOLTAGE=1;RESET]
APP VERSION [DEV=7;APP;VERSION?] (DEV=7;APP;VERSION=$)
BOOTLOADER VER [DEV=7;BOOT;VERSION?] (DEV=7;BOOT;VERSION=$)
Front A Enable [ANALOG=1]
Front B Enable [ANALOG=2]
Rear A Enable [ANALOG=3]
Rear B Enable [ANALOG=4]
Sub A Enable [ANALOG=5]
Sub B Enable [ANALOG=6]
Surround/Height A Enable [ANALOG=7]
Surround/Height B Enable [ANALOG=8]
Center A Enable [ANALOG=9]
Center B Enable [ANALOG=10]
Tips and Guidelines
• Enable or disable multiple outputs with one command. Example: [DEV+7;ANALOG=1,3,5,7,9;ON]
• Only one speaker pair per channel can be active at one time, and switching between pairs will disable the
previous pair. For example, if Front A speakers are enabled, and then the Front B speakers are selected, the
HLS-71 automatically disables the Front A speakers before switching.
• Left and Right channels are enabled simultaneously for Front, Rear, and Surround speaker channels.
• To provide stereo audio from any channel, enable multi-channel stereo output on the amplier or bridge your
inputs. The HLS-71 does not distribute stereo audio to multiple outputs on-board.
• Follow all commands with a carriage return.

Quick Start Instructions
• Connect the receiver harness from “Speaker Level Input” on HLS device to AVR outputs.
• Connect the speaker harness from the “Left/Right/Center Speaker Output A/B” connections
• on the HLS device to the appropriate speakers.
• Open a serial terminal - 115200 8-N-1. Toggle Null/Straight switch if needed to correct signal polarity.
• Send analog switch commands to device 7 (default) to enable or disable a position.
Troubleshooting
No RS-232 Communication:
• Connections are fully seated.
• Devices are using the correct protocol settings.
• Null/Straight selector is set correctly.
No Ethernet Connectivity (IP version only)
• Connections fully seated.
• The end device is powered on, with Ethernet enabled.
• Power cycle all devices to clear out previous TCP connections.

Example System: HLS-71-IP With Speakers and Subwoofers
This display uses audio to attract and communicate. It leverages the HLS-71-IP module’s high level audio output
options to demonstrate two different products. All audio outputs can play either digital or analog audio, depending
on the requirements of the device. The Ethernet port interfaces with the network to receive commands and output
analytics; with the added capability to control and monitor the system remotely. The HLS-71-IP receives power via
an MH2-4K media hub.
NETWORK
HLS-71-IP
OUTPUT HARNESS
PN: 806-785
LOW LEVEL AUDIO (RCA CABLE)
SPEAKER LEVEL AUDIO (SPEAKER WIRE HARNESS - SEE PAGE 6, 7)
NETWORK (CAT 5/6)
SERIAL (CAT 5/6)
INPUT
HARNESS
806-784
SPEAKERS A & B
MH2-4K
MEDIAHUB
SUBWOOFERS A & B A-V RECEIVER
P1
LT
CTR
RT
P3 P2

Firmware Updates
• The HLS-71 series is updatable through the microSD port utilizing a card with FAT-32 formatting (preferred).
Below are the steps outlining the rmware update process:
• Copy new rmware “.FWU” le onto a blank microSD card (FAT-32 format preferred). Insert Firmware Update
SD into the device with device power disconnected.
• Apply power to device, monitoring the power LED Indicator.
• When power LED indicator returns to a slow blink, update is complete.
• To verify the rmware update, send the rmware version query listed in the Commands List (see above) and
ensure response matches the rmware version expected.
Specications
Power Entry Port: 2x barrel jack connectors (5.5 x 2.1mm,
bussed, center positive)
Voltage: +12V DC
No-Load Current: HLS-71: 16mA HLS-71-IP: 145mA
Maximum Load Current: HLS-71: 175mA HLS-71-IP: 350 mA
Maximum Current Output: RS-485 Bus: 1.25 A @ 12.0VDC
Case Type: Ascentic universal case, molded ABS
Case Dimensions:
W x L x H
7.5” x 4.1” x 1.5” 190mm x 104mm x 38mm
Mounting Locations:
molded anges
Centerline Holes: 2x 0.165” (4.5mm)
diameter
Slots: 4x 0.165” x 0.28” (4.5mm x 7mm)
1.0” (25.4mm) above/below center line
holes.
Input Harness (AVR to HLS-71) PN 806-784
Fabricate harness from 16GA speaker wire. Finish the speaker connections with banana plugs or similar.
MOLEX PN: 39-01-2140
RECEPTICLE 14P 2-ROW CABLE MINI-FIT JR
FINISH WITH BANANA
PLUGS OR SIMILAR

Output Harness 806-785 (HLS-71 to Speakers)
Fabricate harness from 16GA speaker wire. Finish the speaker connections with banana plugs or similar.
P1 AND P3 = MOLEX PN: 39-01-2120
RECEPTACLE 12P 2-ROW CABLE MINI-FIT JR
P2 = MOLEX PN: 39-01-2040
RECEPTACLE 4P 2-ROW CABLE MINI-FIT JR FINISH WITH BANANA
PLUGS OR SIMILAR

Ascentic is a trademark of Audio Authority Corp.
2048 Mercer Road, Lexington, Kentucky 40511-1071
800-322-8346 • 859-233-4599 • Fax: [phone]
www.audioauthority.com • [e-mail]
E-217
20240117
