Asgard Secure Store User manual

Drill through the four holes in the base of the unit using 6mm dia masonry
drill to a depth of 70mm. Screw in the anchor fixings. (These have a self
cutting thread). If not anchoring the unit, fit the self seal plugs BEFORE
BUILDING to seal the fixing holes from underneath.
TOOLS REQUIRED
Power driver POSI-DRIV screwdriver, 6mm dia. masonry drill, a 13mm
socket spanner and all weather sealent suitable for steel and concete.
SECURE STORE
BASE INSTRUCTIONS
Flat and firm base. Recommended: concrete, tarmac or paving flags.
Min. distance from walls/ shrubbery: 1000mm.
Min. base size (WxDxH) 1600mm x 1000mm x 50mm.
LEVELING THE UNIT
Correctly level the constructed unit using the shims (ZCOMPPLAS)
provided prior to fixing the unit to the ground. Slide the packing pieces
under the corners of the unit base as required until an equal gap has
been achieved around the door allowing for its smooth operation and
alignment.
For maintenance instructions of this product visit www.asgardsss.co.uk
Warning: panels weigh over 20Kg
Beware of manual handling
6mm
Dia.
13mm
Spanner
18V
x2
SEALANT
ZSCREW32 x4
ZSCREW100 x67
ZSCREW340 x18
ZCOMPPLZS02 x4
ZCOMPPLAS22-23-24 x6
2x 2mm, 2x 3mm, 2x 5mm
TOP PANEL 41916 x1
LH SIDE 38003 x1
RH SIDE 38004 x1
RH DOOR 41917 x1
LH DOOR 38020 x1
BASE PANEL 37903 x1
LH BACK PANEL
36971 x1
RH BACK PANEL
37015 x1
COVER PLATE
38031x2
Warning: Please keep
this key card safe! Refer
to if replacement key is
required.
00001
YOUR UNIQUE
KEY CODE
Posi-Driv
Screwdriver

3
1
5 6
4
2
x4
x2 x13
x14
PLEASE NOTE ALL SCREWS ARE FIXED FROM THE INSIDE
x14 x2
BASE PANEL 37903
RH BACK PANEL 37015
x4
x5
x9
X2
x4
x5
x9
x9
RH SIDE 38004
COVER PLATE 38031
COVER PLATE 38031
LH BACK PANEL 36971
x2
LH SIDE 38003

7 8
910
x18
x18
x4
www.asgardsss.co.uk
41915/07.01.16/KW/REV1
x4
x2
x2
x3
x3
x4
TOP PANEL 041916
RH DOOR 38028
LH DOOR 38020
