FRAME IT ALL Stack & Extend User manual

300001003
ANIMAL BARRIER
*Stack & **Extend
Customer Service: 1800-914-9835 | su[email protected]
© 2020 Frame It All. All Rights Reserved.
RAISED BED SOLD SEPARATELY
Each kit will protect a 4ft. x 4ft. garden to a height of 2
feet. Stackable & Extendable requires 2 or more kits.
KIT CONTAINS:
x 2 x 4 x 1 x 1 x 2 x 1 x 1 x 1
x 4 x 1 x 1
x 2 x 50
x 4
x 3
x 4
8
x 1
x 4
17
11 14 15
16
35mm
43
35mm
15
35mm 6
27mm
7
27mm
27mm
12 13
x 4
x 2
x 1
x 2
20
19 22
x 1
21
18
910
2
23

Customer Service: 1800-914-9835 | su[email protected]
ASSEMBLY INSTRUCTIONS
Your animal barrier kit goes together by plugging the various tubes into the pivoting
connectors and connecting the netting with zip ties.
STEP 1: Install the left gate
Use connectors (parts
13, 5, 4 & 2) to form
the upper right hinge
on round tube (20) –
follow left diagram
STEP 2: Install the right gate
Connect L-connector (9)
with square tube (17)
Connect the other end of L-connector
with square tube (18)
Attach 2nd L-connector (9)
to the square tube (18)
Use connectors
(parts 7 & 21) to
form the lower
left hinge – follow
right diagram
Use connectors (parts
6, 8 & 21) to form the
lower right hinge –
follow left diagram
Use connectors
(parts 13, 3, 5 & 2)
to form the upper
left hinge on round
tube (20) – follow
right diagram
Connect L-connector
(9) with square tube
Attach 2nd L-connector
(9) to the square tube
(18)
Connect the other end of L-
connector with square tube (18)
Connect square tube (17, with has
the gate-latch) to both L-connectors

Customer Service: 1800-914-9835 | su[email protected]
ASSEMBLY INSTRUCTIONS - continued
STEP 3: Attach the gates to the raised bed boards
STEP 4: Attach rest of framework to gate frame
Connect round tube (19)
to the two connectors
Use connectors
(parts 13, 1 & 2) to
form the upper left
hinge on round
tube (20) – follow
top diagram
Use connectors
(parts 13, 1 & 2) to
form the upper
right hinge on
round tube (20) –
follow top diagram
Slide the round pole
into the bracket
Slide the round
pole into the
bracket
Install gate stopper (12) with screws (11) on
the inner side of the board to prevent the gate
from swinging inward
View from the inner side of
the board.

Customer Service: 1800-914-9835 | su[email protected]
ASSEMBLY INSTRUCTIONS - continued
STEP 5: Apply black netting to frame- work
Apply the netting onto the remaining framework using zip ties. Attach top of netting
flush with horizontal poles so the netting will hang over your raised bed.
Attach zip ties all along the top horizontal steel tubes and vertical tubes as well.

Customer Service: 1800-914-9835 | su[email protected]
ASSEMBLY INSTRUCTIONS – stack and extend
Add additional kits to create a higher or larger barrier area.
To stack another animal barrier – same way of assembling the barrier and use the
additional round sleeves (part 22 – 1 sleeve is included in each pack).
Slide the round sleeve
(22) below the short
sleeve.
Slide the round
sleeve (22)
below the hinge
connector
To extend another animal barrier - where the door is at a different side
Remove bottom hinge connector (2) and
replaced it with extension connector (23)
Remove bottom hinge connector (2)
and replaced it with extension
connector (23)

Customer Service: 1800-914-9835 | [email protected]
ASSEMBLY INSTRUCTIONS – stack and extend (continued)
To extend another animal barrier - where the door is parallel as the 1st barrier
Remove bottom hinge connector (2)
and replaced it with extension
connector (23)
Remove middle
sleeve (8) and
replaced it with
hinge connector (7)
Remove middle sleeve (8) and
replaced it with hinge connector (7)
