1SCOPE OF MANUAL
This manual describes ASK LDB 2 reader main features and setup information. This manual
is intended for use by end users. No specific tools are required for operation described in this
document.
1.1UNPACKING AND INSPECTION
Each LDB 2 kit is shipped with :
-serial cable (length : 3 meters)
-This user manual
-One power supply 110V AC / 12V DC 500mA
-LDB 2 reader packaged in plastic case
2LDB 2READER
LDB 2 readers are contactless readers designed for integrators and operators as
development tools as well as desktop readers for card issuing center and point of sales.
LDB 2 provides the communication between a terminal and customer smart cards.

USER MANUEL LDB 2
DESKTOP READER
ASK R&D Réf. : RD-MU-03036-10 Rév.: 1.0 5/ 10
Copyright ASK SA - 2003
2.1READER COMPONENTS
LDB 2 consists of a control board called ”coupler board”, and antenna board, a DC supply
converter board (with two extra SAM sockets) and a contact card interface board.
2.1.1 COUPLER BOARD
The coupler board contains a microprocessor, non-volatile memory and a radio frequency
transmitting circuitry. This board communicates with smart cards via RF link (provided by an
antenna board), and to the terminal via RS-232 interface. The serial rate is set to 115,2 bps.
The coupler platforms are GEN320 or GEN325 elements which can be purchased separately
at ASK. These two OEM coupler boards are compliant with ISO/IEC14443-2 directives (Radio
frequency power and signal interface). Communications can be executed according to the
type A or type B of the directive.
Figure 1: GEN 320-GEN 325 board
GEN 320 and GEN 325 board are strictly identical, except that on GEN 325, PHILIPS ‘s
RC500 chip is added. In this case, the chip just manages MIFARE cryptography mode.
The RC500 chip is located (or not) at the bottom of the printed circuit board (PCB).
SAM location
RS232 connector
Antenna connector
RC500 chip
TOP VIEW
BOTTOM VIEW
Figure 3: GEN 320 board
Figure 2: GEN 325 board

USER MANUEL LDB 2
DESKTOP READER
ASK R&D Réf. : RD-MU-03036-10 Rév.: 1.0 6/ 10
Copyright ASK SA - 2003
2.1.2 ANTENNA BOARD
The antenna board consists of a printed circuit board with copper traces forming the transmit
and the receive antenna. Antenna may be one of several types, varying in dimensions and
connection. LDB 2 receives GEN 530 antenna because its area (110x120mm) matches well
with a desktop application. This antenna has a tuning capacitor, but no setting is required
because it has been optimized in factory.
Figure 4: LDB 2 antenna board : GEN 530
2.1.3 POWER SUPPLY BOARD
This board contains a DC-DC converter and two extra SAM locations. Input line should be
from 9V to 36V DC. Typically an AC power bloc with output 12V 500mA (without regulation)
should be used.
Figure 5: LDB 2 DC conversion / SAM extension board : GEN 351
SAM location

USER MANUEL LDB 2
DESKTOP READER
ASK R&D Réf. : RD-MU-03036-10 Rév.: 1.0 7/ 10
Copyright ASK SA - 2003
2.1.4 CONTACT CARD INTERFACE BOARD
This card has been added for allowing standard contact card transactions.
Figure 6: LDB 2 contact card interface board : GEN 362
2.2ASSEMBLY
Inside the plastic case these boards are stacked together (Figure 7). This way, no cables are
needed :
Figure 7: stacked boards in reader
Contact card connector
Contact card interface board
Power supply board
coupler board
Antenna board

USER MANUEL LDB 2
DESKTOP READER
ASK R&D Réf. : RD-MU-03036-10 Rév.: 1.0 8/ 10
Copyright ASK SA - 2003
3READER SETUP
3.1INSTALLING A NEW SAM IN READER
In most applications, one SAM (Security Application Module) or more is required.
These components are provided separately, so to set a SAM, the plastic case
should be opened.
For opening, flip over the plastic case. You have to put a blade in the rear slot and
lift the bottom of the case in order to set free a central ergot. Then the bottom of the
box should be removed by sliding in the front side direction.
The stacked board will appear as in Figure 7, the first SAM should be installed on
coupler board GEN 32X (Figure 1) and next SAMs should be installed on DC
conversion board GEN 351 (Figure 5).
Caution : In a first time, µSIM SAMs must be gently inserted in the open door
socket (Figure 8), then in a second time the door should be locked.
Figure 8: SAM in open door
SAM

USER MANUEL LDB 2
DESKTOP READER
ASK R&D Réf. : RD-MU-03036-10 Rév.: 1.0 9/ 10
Copyright ASK SA - 2003
3.2READER CONNEXION
The reader’s DB9 should be connected to a RS232 serial port, usually to a
computer via the serial cable provided.
Plug the main adapter included in the « Power-Jack » connector. The main adapter
should provide 12V DC – 500mA.
Turn on the switch located at the front side, the red LED will light at power-on. The
LDB 2 is then in power and ready to work.
Figure 9: LDB 2 connexions
Serial connector
To computer
Power jack

USER MANUEL LDB 2
DESKTOP READER
ASK R&D Réf. : RD-MU-03036-10 Rév.: 1.0 10 / 10
Copyright ASK SA - 2003
4HOW TO USE THE READER
4.1CONTACTLESS OPERATIONS
All the top surface of LDB 2 reader is active. Contactless smart card must be laid flat on the
reader, yellow LED is turned on when operation is correct.
4.2 CONTACT OPERATIONS
The smart card should be inserted, chip on top, in the front slot of the LDB 2 reader (card
contact faces triangle on reader front side).
The card should be pushed until a resistance appears (reader’s contacts fall down on card’s
contact).
4.3 SOFTWARE
The LDB is delivered by default with an application software called CSC which supports the
ASK cards and C.ticketfamilies.
The external LEDs of the reader can be controlled by customer applicative software using
CSC software commands.
In the same way, the GEN360 contact card reader and the extra SAM modules supported by
the GEN351 board have to be managed by the host application via CSC protocol.
4.4 CLEANING
No adjustments on the reader are required. To clean, simply wipe with a wet cloth and plastic
cleaner, abrasive products are prohibited.
