Askey CDR6013-WG User manual

ASKEY Connected DashCAM
CDR6013-WG
User Manual
Nov. 2017
ASKEY Computer Corp.

Connected Car Cam CDR6012 User Manual
1
Content
1. Introduction.......................................................................................................................3
1.1 Features........................................................................................................................................... 3
1.1.1 Package Contents................................................................................................................... 3
1.2 Device Overview............................................................................................................................ 4
1.3 Getting Started............................................................................................................................... 5
1.3.1 Insert Memory Card and SIM Card........................................................................................ 5
1.3.2 Install in Vehicles..................................................................................................................... 5
1.4 Power the Device On / Off............................................................................................................ 5
1.4.1 Auto Power On/Off.................................................................................................................. 6
1.4.2 Manually Power Off................................................................................................................. 6
1.4.3 Reset the Device..................................................................................................................... 7
1.4.4 Set the Date / Time.................................................................................................................. 7
1.4.5 LED Indicator........................................................................................................................... 7
1.4.6 Menu Operation....................................................................................................................... 7
2. Using the Driving Recorder..............................................................................................8
2.1 Recording Videos.......................................................................................................................... 8
2.1.1 The Recoding Screen............................................................................................................. 8
2.1.2 Voice On/Off when recording ................................................................................................. 9
2.1.3 Take Picture............................................................................................................................. 9
2.1.4 Screenshot............................................................................................................................... 9
2.2 Playback the Videos and Photos................................................................................................ 9
2.2.1 Normal Videos ......................................................................................................................... 9
2.2.2 Event Videos...........................................................................................................................10
2.2.3 Risky Driving Videos..............................................................................................................10
2.3 Network Settings..........................................................................................................................11
2.3.1 LTE and 3G Frequency Bands..............................................................................................11
2.3.2 Wi-Fi........................................................................................................................................12
2.3.3 Bluetooth.................................................................................................................................12
2.3.4 APN Setting ............................................................................................................................12
2.4 Menu Options................................................................................................................................13
2.5 ADAS...............................................................................................................................................16
2.5.1 Auto Calibration......................................................................................................................16
2.5.2 FCWS (Front Collision Warning System).............................................................................16
2.5.3 LDWS (Lane Departure Waring System) .............................................................................17
2.6 Firmware Upgrade........................................................................................................................18

Connected Car Cam CDR6012 User Manual
2
2.6.1 Firmware Upgrade via OTA...................................................................................................18
2.7 Emergency Call.............................................................................................................................18
2.8 Technical Specifications.............................................................................................................19
3. Appendix.......................................................................................................................... 20
3.1. Package........................................................................................................................ 20
3.2. Memory Card Capacity................................................................................................ 21
4. Troubleshooting.............................................................................................................. 21
Copyright © 2017, All rights reserved.
All rights reserved. Printed in the Taiwan, 2017.
The information in this document is subject to change without notice. The statements,
configurations, technical data, and recommendations in this document are believed to be
accurate and reliable, but are presented without express or implied warranty. Users must take
full responsibility for their applications of any products specified in this document.
The information in this document is proprietary to ASKEY Computer Corp. The software
described in this document is furnished under a license agreement and may only be used in
accordance with the terms of that license. Asummaryof the Software License is included in this
document.
Statement of Conditions
In the interest of improving internal design, operational function, and/or reliability, ASKEY
Computer Corp. reserves the right to make changes to the products described in this document
without notice.
ASKEY Computer Corp. does not assume any liability that may occur due to the use or
application of the product(s) or circuit layout(s) described herein.
In addition, the program and information contained herein are licensed only pursuant to a
license agreement that contains restrictions on use and disclosure (that may incorporate by
reference certain limitations and notices imposed by third parties)

Connected Car Cam CDR6012 User Manual
3
1.Introduction
Thank you for purchasing this advanced Connected Car Cam. This device is specifically
designed for the functions descript as the following.
1.1 Features
• Full HD 1080p single camera driving recorder
• 1920x1080p video recording
• Wide view angel FOV 120˚(H)
• 2 Mega Pixel CMOS Sensor
• 2inch LED backlight TFT panel, QVGA 320 x 240 pixel color screen
• Built in LTE/3G,Wi-Fi, Bluetooth and GPS function
• 3.7V, 750 mAh rechargeable Li-ion battery non removable battery
• Seamless looping recording
• Support up to 128GB Class 10 Micro SDHC
(Suggest to use Micro SDHC 95 MB/s R, 90 MB/s W)
1.1.1 Package Contents
The package contains the following items. In case there is any missing or damaged item,
contact your dealer immediately.
The device Mount bracket Power Cable 1: Cigarette Car
Charger
5V 2A Cigarette Car Charger
with 5m cable with USB mini-B
connector.
Micro SD card Power Cable 2: Power Box
5V 2A power box with 5m cable
with USB mini-B connector.
Remark: Please notice there is one power cable in your package box. You could confirm with

Connected Car Cam CDR6012 User Manual
4
before your purchasing.
1.2 Device Overview
No. Description No. Description
1Mount Bracket 11 Up Button
2Knob/Hinge 12 Enter/OK Button
3Power Button 13 Down Button
4Main Device 14 Microphone-2
5Camera 15 Call Button
6Speaker 16 SIM Card Slot
7Back/Return Button 17 Reset Button
8Microphone-1 18 Micro SD Card Slot
9USB port
10 LED Indicator

Connected Car Cam CDR6012 User Manual
5
1.3 Getting Started
1.3.1 Insert Memory Card and SIM Card
Follow the direction indicated as the following to insert the memory card and SIM card.
(Please contact with your Operator to get the SIM card.)
1.3.2 Install in Vehicles
Please follow the steps to make sure the device is securely locked in place.
1. This device shall be installed near the rear view-mirror, at the center of windshield, if
possible, for optimal viewing.
2. Mount the device nearby the room mirror. Make sure the camera view area in LCD.
3. Position the mount bracket on the windshield, and then press to paste on the windshield.
Make sure the base is securely locked in place.
4. Loosen the knob swivel to adjust tilt angle. Locking knob, and confirm that the device is
securely locked in place.
1.4 Power the Device On / Off
Use only the attached car charger for activating the device and charging the built-in battery.
1. Connect one end of car charger connector to USB port on the device.
Micro SD card
Micro SIM card

Connected Car Cam CDR6012 User Manual
6
2. Plug the other end of the car charger to the cigarette lighter socket of your vehicle. Once
the vehicle engine is started, the device automatically turns on.
3. Switch key from ACC to OFF position, then device will enter sleep mode and start
consuming battery power.
1.4.1 Auto Power On/Off
Once the vehicle engine is started, the device automatically turns on and starts recording
(must have SD card).
When the vehicle engine stopped, the device will turn to sleep mode after 5 seconds, in sleep
mode, the device gets the power by battery. Turn device off, long pressing the Power button
around 3 seconds, a power off confirm dialog shows, pressing Enter button to power off the
device completely.
1.4.2 Manually Power Off
Press the power button around 2-3 seconds to power off, a dialog will be shown and press
Enter button to confirm it.

Connected Car Cam CDR6012 User Manual
7
1.4.3 Reset the Device
In case the device fails to function normally due to unknown causes, click the reset key on the
bottom of the device.
1.4.4 Set the Date / Time
Date and Time will be automatically updated after registered the LTE/3G network, connected
to Wi-Fi or receive the GPS signal
1.4.5 LED Indicator
LED Indicator Status Description
Red light keeps flashing Power on and recording
Red light on Sleep mode
Call Button LED Status Description
Red light keeps flashing Connecting to service center and
waiting answer the eCall.
Red light on Answered the eCall
1.4.6 Menu Operation
Press Enter button to enter menu setting, press Up / Down button to select sub menu, then
press Enter button OK to enter the setting, press Up / Down button to select the option, and
then press Enter button OK confirm. After completing the setting, press Back button to exit
menu setting.

Connected Car Cam CDR6012 User Manual
8
2.Using the Driving Recorder
2.1 Recording Videos
Before starting recording, please insert a SD card into the SD card slot.With car charger
connected the device will automatically turn on and start recording, the video recording icon
shown on the left top of the screen and a red color LED blinks . The recorded files are saved
on the SD card. To stop recording, press Enter button again.
The recorded files are saved on the SD card, you can get these video files under path
\\sdcard\DVR\driving\normal_video when you insert the SD card into your PC or playback these
files under the menu items of “Video and photos/Normal”.
2.1.1 The Recoding Screen
Icons on the recording screen.
Status icon What it means
00:00 Video is recorded
Show the battery level and charging status
Recording time counter
No sound when recording video
Tell you the current vehicle speed
ADAS is disabled
Display the current time
Satellite signal is acquired
No satellite signal is acquired
GPS location information is acquired

Connected Car Cam CDR6012 User Manual
9
Connected to Wi-Fi network
Wi-Fi hotspot allow other device sharing your 3G/LTE
connection.
Connected to 3G/LTE network and show the signal
strength.
2.1.2 Voice On/Off when recording
Enter the Video Setting to enable Voice when recording Off / On.
2.1.3 Take Picture
During recording, press Back button can capture the current scenery as a picture.
2.1.4 Screenshot
Press Power and Down button at the same time can capture the current screen as a
picture. The screen pictures are saved on the SD card, you can get these under path
\\sdcard\pictures\screenshots when you insert the SD card into your PC.
2.2 Playback the Videos and Photos
2.2.1 Normal Videos
As mentioned, video recording is started as soon as the device is powered on, but you have
to insert a SD card before recording. Without any setting in advance, the video recording will
keep continuous. The recorded video can be categorized into 4 types of Normal video, Collision
event video, Risking driving video and Security monitor video in Parking mode (Vehicle engine
is off), and video files are saved on the SD card under path \\sdcard\DVR\driving. The oldest
files will be overwritten if the SD card fills up. All kinds of video files can be played directly on
device. Enter into its corresponding sub menu item of “Video and photos” for normal, event,
risking driving and parking videos, scrolling through video clips or photos using “UP” and
“DOWN” button, to playback or view chosen video or photo files by pressing “ENTER” button.
The difference of 4 types of recorded files will be explained in later sections.

Connected Car Cam CDR6012 User Manual
10
2.2.2 Event Videos
The Event video record is triggered and activates in the case of a car collision accident
which is determined by the gravitational acceleration.
When collision is detected, this device will save the recorded video clips under \\sdcard
DVR\event\event_data_video and upload them to cloud forcibly.
2.2.3 Risky Driving Videos
Risking driving is indicated the behaviors of hard-brake or hard-turn. The video record of
risking driving is activated and determined according to the variation of Angular velocity via
gyroscope and g-sensor.
When risking driving is detected, this device will save the recorded video clips under
\\sdcard\DVR\event\rdb_video and upload them to cloud forcibly.

Connected Car Cam CDR6012 User Manual
11
2.3 Network Settings
The device built-in LTE/3G, Wi-Fi and GPS module, please insert a SIM card before power on,
when LTE/3G or GPS signal has been received, the recorded video can be tracked at this time.
2.3.1 LTE and 3G Frequency Bands
Please make sure the LTE and 3G frequency bands with your operator in local before you
insert the SIM card into the device.
•Support LTE Band
EU/JP/TW/APAC requirement:
2 (1900 MHz)
4(1700 MHz)
5(850 MHz)
17(700 MHz)
26(850 MHz)
•Support 3G Bands:
WCDMA 2(1900 MHz), 4(1700 MHz),5(850 MHz)
•Peak Downlink/Uplink
HSPA+ DL: 42Mbps, UL: 5.76Mbps, LTE Cat4 DL: 150Mbps, UL: 50Mbps

Connected Car Cam CDR6012 User Manual
12
2.3.2 Wi-Fi
The device support IEEE802.11 b/g/n, 2.4GHz Wi-Fi connections. Press Enter button to
select Network Setting menu to activate the Wi-Fi hotspot function. Insert a SIM card before
you activate the Wi-Fi hotspot function. (Please notice you will be charged by local operator if
you activate it).
2.3.3 Bluetooth
The device support Bluetooth 4.1, the profile can support SPP. Press Enter button to select
Network Setting menu to activate the Bluetooth function. Make sure the profile can be
connected to your mobile device before you activate it.
2.3.4 APN Setting
Press Enter button to select Network Setting menu, enter LTE to select "Access Point
Names", press "+"icon then use on-screen keypad to input the APN.

Connected Car Cam CDR6012 User Manual
13
2.4 Menu Options
Main Menu Description Available Option
Videos and
photo Normal Playback recorded movies and view
capture photos.
Review / Change to Event
folder / Delete
Event Event data / Risky driving
behaviors / FCWS: Review /
Delete
Parking Review / Delete
Photo Review / Change to Event /
Delete
ADAS Setting LDWS Off – No warning tone
when lane departure.
On – Turns on the
LDWS, there will be
warning when depart
from the lane.
-Off
-On
FCWS Off – No warning tone
when collision occur.
On – Turns of the
FCWS, there will be
warning before a
possible collision
when the vehicle in
front of you.
-Off
-On
Network
Settings Operator Name Display the Operator name after insert an
available SIM card.

Connected Car Cam CDR6012 User Manual
14
Wi-Fi Set the Wi-Fi
connection.
LTE Set the LTE
connection and APN. Roaming / Network /Access Point Name(APN)
Wi-Fi Hotspot Set the Wi-Fi as an
AP router. On / Off
Set up ID/Password
Bluetooth Set the Bluetooth
connection. On / Off
SD card Format Delete movies and
photos saved on the
SD card.
Yes / Cancel
USB port Mini USB Only for charger,
Can’t data
transmission
Parking mode
Set the parking mode
on / off and the
sensitivity.
On / Off / Auto detection
Video Setting Recording time Select to limit
recording time pre
file.
1minutes / 3minutes / 5minutes
Resolution Set the video
resolution. 1080p(FHD) / 720p(HD)
Display Set the display
brightness and on /
off when recording.
Brightness / On / Off
Information Setting the location -Off

Connected Car Cam CDR6012 User Manual
15
data on the video
recorded. -On
Voice when
recording Set the voice recording on / off
when video
recording.
On / Off
System
setting Manufacture Display the manufacture.
Model name Display the model
name for the device.
IMEI Display the IMEI for
the device.
System Update Select to update the
firmware if you
receive the
notification from the
service center.
Check current version / Version
update
Serial number Display the serial
number of the device.
Certificate ID Display the
Certificate ID of the
device.
For more Regulatory
compliance and marks
(E-labels) about
NCC/FCC/JRF/JPA, please
refer to your device via the
following steps: System
setting Certificate.
Volume Select the volume of
the device and the
voice(TTS) alert.

Connected Car Cam CDR6012 User Manual
16
Version Display the current
firmware version of
the device.
2.5 ADAS
2.5.1 Auto Calibration
When the ADAS (containing the sub functions of LDW, FCW) is enabled, the ADAS engine
will take around 1-2 minutes to calibrate its parameters of hood level, horizontal level and
horizontal Pan automatically. With these 3 parameters obtained accurately such that the ADAS
can further work correctly. Three short lines will appear on the screen once the calibration
procedure is finished. Please notice ADAS doesn’t work if the parameters are not acquired.
2.5.2 FCWS (Front Collision Warning System)
When FCWS is enabled after satellite positioning, the system calculates distances between
the front vehicle and our vehicle and the headway time, the device will has voice alert and
display an alarm screen before a possible collision when the vehicle in front of you.

Connected Car Cam CDR6012 User Manual
17
•Notice
FCWS turned on, a green square wireframe with distance is displayed on the screen from the
moment the front vehicle is detected, and as long as the headway is greater than the
predefined headway time threshold.
•Warning
FCWS turned on, a red square wireframe with distance is displayed on the screen with
voice alert, when the headway is less than 2.5 second.
2.5.3 LDWS (Lane Departure Waring System)
When LDWS is enabled after satellite positioning, the device will has voice alert and display
an alarm screen if vehicle begin to depart from the original lane. Press Enter button to select
the LDWS setting (the default setting is Off).
Turn on LDWS function, the recorded movie will give a voice alert and a red line is displayed
on the screen if the vehicle depart from the original lane.

Connected Car Cam CDR6012 User Manual
18
2.6 Firmware Upgrade
Check the device has already connected to the vehicle power before you activate the
firmware upgrade service. While the firmware upgrading, do not remove or stop the vehicle
engine. This information may be important for service and support communications.
2.6.1 Firmware Upgrade via OTA
Enter the System Upgrade and select Check Version to check and upgrade the firmware
version. Make sure the device already connected to Internet before proceed firmware
upgrading. Please notice you will be charged by local operator if you activate it.
2.7 Emergency Call
When detect car crash, the device will trigger voice call to service center automatically, and
you will receive the phone call from service center who will communication with you. (Please
notice you will be charged by local operator if activate it).

Connected Car Cam CDR6012 User Manual
19
2.8 Technical Specifications
Model Name CDR6013-WG
Support OS Android 6.0
Display 2inch LED backlight TFT panel, QVGA 320 x 240 pixel, brightness 200 nits ,
Dimensions 76mm (L) x 76mm (W) x 40.7mm (H)
Weight Around 150g
Battery Pack & Life 3.7V, 750mAh(non-removable lithium-ion battery), target 30minutes @
100nits, 720p, playback
Processor Qualcomm MSM8956 (Dual core AMR A72 1.8GHzand Quad core ARM
A53 1.6GHz)
Graphics Adreno 510 @ 600MHz
Main Memory On board 2GB LPDDR3 and 8GB eMMC
Sensors 1. G-Sensor(Accelerometer)
2. Gyroscope
3. GPS
WLAN 802.11 b/g/n
Wi-Fi Antenna*1
Bluetooth BT 4.1., Profile: SDP, HFP, HSP, PAN, HID, SPP, FMP, GATT
Modem WCDMA HSPA+/FDD LTE and TD-LTE
SIM card slot Support, single Micro SIM(3FF)
GPS GPS, AGPS & Glonass
Interface 1 x micro USB
1 x Card reader (Micro-SD),
Camera Single camera: 2MP with 1080p/720p video recording, FOV 120˚(H)
Audio Built-in high quality speaker x 1
Microphone Analog Microphone x2
LED Status Dual color LED x1(power button), red LED x2(call button)
Buttons 5 function keys(power, back, enter, up and down)
Reset and eCall button
AC adapter Output: 5V 2A ;9V .15ACigarette Car Charger
Input: 12V/24V DC
Cable length: 5m cable with USB mini-B connector
Environment Operation Temperature: -20 to 60 ℃.
Storage Temperature: -20 to 85 ℃
Humidity: 95%(60 ℃)
