Dear Customer,
Thank you for choosing this quality product from ASKO.
We hope it will meet your expectations and fulfil your needs for many years to come.
Scandinavian design combines clean lines, everyday functionality and high quality. These
are key characteristics of all our products and the reason they are greatly appreciated
throughout the world.
To get the most from your new dishwasher, we recommend that you read the operating
instructions before using the dishwasher. The operating instructions also include information
on how you can help protect the environment.
ASKO D5894 XXL FI
Operating Instructions
Operating Instructions
Dishwasher

3Before washing for the first time
3Read the operating instructions
3Be careful with certain materials
3Checking water hardness
4Safety instructions
4General
4Installation
4Winter storage/Transport
4Overflow guard function
4Cleaning
4Packing material
4Disposal
5Child safety
5Child safety and dishwashing
5Activate child lock (button lock)
6Dishwasher components
7Dishwasher baskets
12Front panel
12Dispenser
13Economic dishwashing
14Fragile dishes
15Dishwashing
15Load the baskets correctly
16
Check that the spray arms can
rotate freely
16Add detergent
16
Press the main power switch until
the display lights up
16Select the program
19Select options
21
Press Start/Stop and close the
door
21After dishwashing
22Special settings
24Time remaining
25Status light
26Care and cleaning
29Rinse aid
30Error messages
31Troubleshooting
34Performance information
36Installation
36Safety instructions
36Setup
37Drainage connection
37Connection to water supply
37Electrical connection
38Service
40Quick guide
2
Contents

Read the operating instructions
Read through the operating instructions before using
the dishwasher, especially the sections Safety
instructions, Child safety and Dishwashing.
Be careful with certain materials
Read the section Fragile dishes before dishwashing
porcelain with unglazed decoration or other utensils
made from plastic, wood or crystal that you value.
Checking water hardness
Contact the local water utility to check the water
hardness in your area. This is important with regard
to how much detergent and rinse aid to use.
3
Before washing for the first time

General
•Read the operating instructions and keep them in
a safe place!
•Never use the dishwasher for any purpose other
than that specified in these operating instructions.
•Do not load the dishwasher door or dishwasher
baskets with anything other than dishes.
•Never leave the dishwasher door open as
someone may trip on it.
•Use only dishwasher detergent!
•Place knives and other sharp items so that they
cannot harm anyone or damage the dishwasher.
•The machine is not designed to be used by
persons (even children) that are physically or
mentally handicapped or lack experience and
knowledge. Such persons must receive instruction
in how to use the machine from the person
responsible for their safety.
•Damaged mains cables must only be replaced by
a qualified electrician.
•This dishwasher is for household or similar use,
such as:
-staff kitchens in shops, offices and other
workplaces.
-farms.
-for guests at hotels, motels and other types of
accommodation.
-bed & breakfast hotels.
•Never place dishes with solvent residues in the
dishwasher due to the risk of explosion. Nor may
dishes that contain ash, wax or lubricants be
washed in the dishwasher.
• Young children should be supervised to ensure
that they do not play with the appliance.
• The appliance is not intended for use by young
children or infirm persons without supervision.
Installation
See the section Installation.
Winter storage/Transport
•Store the dishwasher where the temperature
remains above freezing.
•Avoid long transport distances in very cold
weather.
•Transport the dishwasher upright or laying on its
back.
Overflow guard function
The overflow protection starts pumping out the
machine and turns off the water supply if the water
level in the dishwasher exceeds the normal level. If
the overflow protection is triggered, turn off the water
supply and call the service division.
Cleaning
When cleaning the edge around the door, use only a
slightly damp cloth. Do not spray water around the
edge! Moisture can make its way into the lock, which
contains electrical components.
Packing material
Sort waste materials in accordance with local
guidelines.
Disposal
•When the dishwasher has reached the end of its
service life and is to be disposed of, it should
immediately be made unusable. Pull out the power
cable and cut it as short as possible.
•The dishwasher is manufactured and labelled for
recycling.
•Contact your local authority for information about
where and how your dishwasher should be
correctly recycled.
4
Safety instructions

Child safety and dishwashing
•Use the knife basket, or knife stand, for all
long/sharp items.
•Always close the door and start the program
immediately after you have added the detergent.
•Keep children away from the dishwasher when
the door is open. Some detergent may remain
inside!
•Do not allow children to use or play with the
dishwasher. Be especially vigilant when the door
is open.
WARNING!
Children must be supervised – dishwasher
detergent is corrosive!
Store detergent and rinse aid out of the reach of
children! If anyone swallows dishwasher detergent,
they should immediately drink one or two glasses of
milk or water. Do not attempt to induce vomiting.
Contact a doctor! If anyone gets dishwasher
detergent in their eyes, rinse (for at least 15 minutes)
with plenty of water.
WARNING!
Dishwasher detergents are strongly alkaline. They
can be extremely dangerous if swallowed. Avoid
contact with skin and eyes and keep children away
from the dishwasher when the door is open.
Check that the detergent compartment is empty after
completion of the wash cycle.
Activate child lock (button lock)
You can activate the child lock (button lock) to prevent
children from starting the dishwasher (see the section
Special settings).
5
Child safety

START
PROG
STOP
17
8
9
8
10
11
12
2
3
4
5
6
Status light
Upper basket
7.
Knife basket
1.
Spray arms
8.
Interior light
2.
Serial number plate
9.
Middle basket
3.
Lower basket
10.
Filters
4.
Rinse aid compartment
11.
Cutlery basket
5.
Panel
12.
Detergent compartment
6.
*Specifications may differ depending on the model and market.
6
Dishwasher components*

Upper basket
1. Wine glass shelf
2. Handle
3. Knife guard
4. Spray arm
5. Locking handle for upper basket
Raising the upper basket
1. Pull out the upper basket.
2. Grab the sides of the upper basket with both hands
and lift it up.
Lowering the upper basket
1. Pull out the upper basket.
2. Pull out the two locking handles (5) on either side to
lower the upper basket.
1
4
2
5
1
3
Middle basket
12
3
4
Protective cap
1. Wire basket for cups, small glasses or bowls
2. Utensils basket for ladles, whisks, food turners,
serving cutlery and similar items
3. Spray pipes
4. Handle
The wire basket can be replaced with another utensils
basket.
The two baskets in the middle basket can be removed,
or the entire middle basket can be removed to create
more space between the upper and lower baskets if
larger items are being washed.
NOTE!
Fit the supplied protective cap if the wire basket with
spray pipes or the entire middle basket is removed.
Don't forget to remove the protective cap when the
wire basket with spray pipes or the entire middle basket
is refitted.
*Specifications may differ depending on the model and market.
7
Dishwasher baskets*

Lower basket
2
3
45
1
1. Wine glass shelf
2. Fold-down plate support left
3. Fold-down plate support right
4. Forward mount for plate support (used for plates
with a diameter greater than 25 cm)
5. Handle
NOTE!
Plastic items should not be placed in the circled area
of the lower basket as they can be damaged by the
heat. Plates, on the other hand, can be placed here
for warming (applies to Crockery warming program).
Knife basket
2
1
1. Basket
2. Knife support
Cutlery basket
ac
b
*Specifications may differ depending on the model and market.
8
Dishwasher baskets*

Cutlery basket with lid
ac
b
Positioning of cutlery basket lid (in upper basket)
The cutlery basket lid can be removed and used, for example, as an extra cutlery basket in the upper basket (see
below).
a
b
c
*Specifications may differ depending on the model and market.
9
Dishwasher baskets*

Extra cutlery basket (disassembly)
a
d
2
1
b
2
1
c
Extra cutlery basket (assembly)
a
c
b
d
x 4
x 2
x 4
x 2
TIP!
The disassembled parts can also be mounted on the large cutlery basket to make an even larger cutlery basket.
*Specifications may differ depending on the model and market.
10
Dishwasher baskets*

Positioning of extra cutlery basket
Upper basket
a b
Lower basket
a
c
b
*Specifications may differ depending on the model and market.
11
Dishwasher baskets*

The panel is fitted with touch buttons with audible feedback (see the chapter Special settings).
S TA R T
P R O G S T O P
1 2 3 4 5
Navigation buttons
4.
Main power switch
1.
Start/Stop
5.
Program selector
2.
Display
3.
NOTE!
•The touch buttons only react to use when the door is open. Wait a moment before pressing the touch buttons
after opening the door.
•Two minutes after the last button press, the panel backlight enters energy saving mode. Press the main
power switch once to reactivate the panel.
•Keep the touch buttons clean and free from grease. Wipe them clean with a dry or slightly damp cloth. Never
use cleaners – they can scratch the surface. Use the main power switch to turn off the dishwasher before
cleaning the touch buttons to avoid activating any buttons unintentionally.
Dispenser
12
45
3
1. Prewash detergent compartment
2. Main wash detergent compartment
3. Rinse aid compartment
4. Detergent compartment lid
5. Rinse aid compartment lid
12
Front panel

Run programs only with a full load
Wait to run a program until the dishwasher is full. This
way you save energy. Use the Rinse & Hold program
to rinse the dishes if there are any unpleasant odours
while you wait for the dishwasher to become fully
loaded.
Run programs at a lower
temperature
If the dishes are only slightly dirty, you can select a
lower temperature with certain programs. See also
the section Select options in the chapter Dishwashing.
Select a program with Short dry
To save energy, use Short dry. The drying result will
be better if, once the program is finished, you leave
the door slightly open.
Do not rinse under running water
Simply scrape off large food particles before loading
the dishwasher.
Choose a green detergent
Read the environmental declaration on the packaging!
Connect to cold water...
If you use oil or electricity to heat your home.
Connect to hot water (max. 70 °C)...
If you use district heating, solar power or geothermal
power to heat your home. Choosing a hot water
connection cuts program times and reduces the
dishwasher's electricity consumption.
13
Economic dishwashing

Some cookware is not dishwasher safe. This can be
for several reasons. Some materials cannot withstand
strong heat, others can be damaged by dishwashing
detergent.
Fragile decoration
Porcelain with decoration on top of the glazing (the
items feel rough) should not be washed in a
dishwasher.
Crystal/Glass
Position items so that they do not touch each other
during the wash. Use the lowest possible wash
temperature and the shortest possible program.
Select No dry. Antique and very fragile items should
not be washed in a dishwasher.
Glass washed in a dishwasher at high temperatures
can gradually develop a grey film that cannot be
removed. Wash fragile glasses at a low temperature
and with a small amount of detergent.
Silver
Silver and stainless steel items should not come into
contact, as the silver can become discoloured.
Cutlery with glued handles
Some types of glue are not dishwasher safe. In such
cases, the handles may loosen.
Wood
Wooden items should only be washed in a dishwasher
if marked dishwasher safe.
Aluminium
Aluminium can lose its shine if washed in a
dishwasher. However, good quality aluminium pans
can be washed in a dishwasher, even if some of the
shine will be lost.
Plastic items
Avoid washing plastic items that cannot withstand
high temperatures.
Your machine is equipped with a turbo dryer, which
improves the drying of plastic and other items.
NOTE!
Plastic items should not be placed in the circled area
of the lower basket as they can be damaged by the
heat.
14
Fragile dishes

Below are step-by-step instructions to help you
achieve the best possible dishwashing results.
1Load the baskets correctly
Do not rinse dishes under running water before
loading them in the dishwasher. Simply scrape
off large food particles before loading the dishwasher.
Place glasses, cups, bowls, side plates and saucers
in the upper basket. Wine glasses are placed on the
wine glass shelf (if fitted). Place sharp knives in the
special knife basket at the top of the dishwasher, or
in the knife stand on the right (if fitted).
NOTE!
All dirty surfaces should face inwards and
downwards!
The middle basket's wire basket with spray pipes is
suitable for low objects such as cups, small glasses
and bowls. The middle basket's utensils basket has
space for ladles, whisks, serving cutlery and similar
items.
Do not place bowls or cups in the
utensils basket!
The two baskets in the middle basket can be
removed, or the entire middle basket can be removed
to create more space between the upper and lower
baskets if larger items are being washed.
NOTE!
Fit the supplied protective cap if the wire basket with
spray pipes or the entire middle basket is removed.
Don't forget to remove the protective cap when the
wire basket with spray pipes or the entire middle
basket is refitted. See the section Dishwasher
baskets.
Place plates, side plates, serving dishes, pots and
cutlery (in the cutlery basket) in the lower basket.
Lower the fold-down plate supports when washing
pots.
Place cutlery with the handles facing down, except
for knives, and spread them out as much as possible.
Ensure that spoons do not stack inside each other.
The cutlery basket is placed in the lower basket.
WARNING!
Knives and other pointed items must be placed with
the points down in the cutlery basket or horizontally
in other baskets.
Do not place cutlery made of different materials, such
as silver and stainless steel, in the same place (risk
of discolouration).
The cutlery basket has a fold-down section in the
middle for small items, or small shafts, such as electric
whisk attachments.
15
Dishwashing

See the section Fragile dishes if you want to wash
items that may be considered fragile.
2Check that the spray arms can
rotate freely
3Add detergent
Detergent is added according to water
hardness.
Follow the instructions on the detergent packaging.
Too much detergent can result in less effective
dishwashing and also entails greater environmental
impact.
Add the detergent to the detergent compartment.
There is one compartment for the prewash and one
for the main wash (see the section Dispenser). If
tablets are not used, add a small amount of the
detergent to the prewash compartment. Contact the
detergent manufacturer if you have any questions
about the detergent.
WARNING!
Children must be supervised – dishwasher detergent
is corrosive!
NOTE!
Use only dishwasher detergent! Washing up liquid
must not be used as the foam that forms prevents
the dishwasher from operating effectively.
Dishwasher tablets
Halve the tablet if it is difficult to close the dispenser
lid. There is a risk that the detergent will not be
released properly if the lid is tight and will not open
correctly.
NOTE!
Dishwasher tablets are not recommended for short
programs (less than 75 minutes). Use powder or
liquid dishwasher detergent instead.
3–in–1/All-in-one detergent
Read through the directions for these products
carefully. If anything is unclear, contact the detergent
manufacturer.
4Press the main power switch
until the display lights up
5Select the program
Press the Program selector one or more times
until the desired program appears on the
display.
Auto wash
The dishwasher can measure how dirty the dishes
are and adjust water consumption and temperature
accordingly. When newly installed, the program needs
to be run five times before it is fully adapted and can
provide the best results.
Daily wash
A program suitable for day-to-day dishwashing. This
program can also clean dried leftovers, but is not
intended for burnt food, such as on oven dishes.
Time program
The program adapts to the specified running time or
finish time. With this program it is important to choose
a time suited to how dirty the dishes are.
Slightly dirty dishes0:30-1:15
Normally dirty dishes1:30-2:00
Very dirty dishes2:15-3:00
Heavy wash
Program for very dirty dishes, such as pans, casserole
dishes and oven dishes. If these dishes do not
completely fill the dishwasher, you can add plates
and the like.
Normal wash
Use to wash normally dirty dishes, and even dishes
with dried leftovers, such as plates, serving dishes,
cups, glasses and so on.
16
Dishwashing

Mixed wash
This dishwashing program is used when you have
lightly soiled dishes in the upper basket and heavily
soiled dishes in the lower basket. This program has
a longer program time than Lower half wash.
Upper half wash
You can use this program if you only have cups and
glasses that need washing in the upper basket.
Slightly dirty dishes can also be placed in the lower
basket.
Lower half wash
You can use this program when you only want to wash
plates and cutlery in the lower basket. Slightly dirty
dishes can also be placed in the upper basket.
Eco wash
Use when you want to save water. For normally dirty
dishes.
Plastic wash
A program intended for washing plastic items that are
not dishwasher safe. This program has an extra long
drying cycle. Porcelain and glasses can also be
washed.
Delicate wash
If the dishes are not very dirty, you can select Delicate
wash. This program is intended for glasses and
porcelain that have just been used and as such do
not require such a powerful program.
This program can be used for fragile dishes. Select
No dry if you want to be especially cautious. See also
the section Fragile dishes.
Quick wash
This program is used for glasses and porcelain that
is slightly dirty, such as coffee cups.
Super Quick wash
Short program lasting about 15 minutes with
acceptable results for very slightly dirty dishes.
Rinse & Dry
This program comprises a rinse with heating and
drying. This is a suitable program if, for example, you
plan to make jam and want to rinse and heat clean
glass jars.
Rinse & Hold
Used to rinse dishes while you wait for the dishwasher
to become fully loaded.
Crockery warming
Used to warm plates. See the section Dishwasher
baskets for how to place the plates.
17
Dishwashing

Program chart
Consumption values1)
Final rinse tem- perature (°C)
Number of rins- es
Main wash (°C)
Pre- washes
OptionsProgram
Hot water3)
Cold water2)
Water con- sumption (liter)
Energy (approx. kWh)
Wash time (approx. hours:minutes)
Energy (approx. kWh)
Wash time (approx. hours:minutes)
11-200,7-1,01:40-2:401,3-1,61:50-2:50652-355-651-3-Auto wash 130,81:301,31:4065260160 °C, Short dryDaily wash 120,81:301,21:30max. 652-3max. 650-2-Time program 180,73:001,43:2060355255 °C, Short dryHeavy wash 130,31:450,82:0545245145 °C, Short dry
Normal wash4)
150,72:101,42:2565265265 °C, Short dryNormal wash 100,72:151,12:3060255055 °C, Short dryUpper half wash 100,72:151,12:3060255055 °C, Short dryLower half wash 110,52:150,82:3050255055 °C, Short dryEco wash 140,62:051,22:2060255155 °C, Short dryPlastic wash 100,51:400,91:5050240040 °C, Short dryDelicate wash 100,10:200,20:20-230030 °C, No dryQuick wash 100,10:150,20:15-230030 °C, No drySuper Quick wash 40,40:400,50:45501-0-Rinse & Dry 40,010:060,010:06-1-0-Rinse & Hold 00,10:400,10:40-0-0-Crockery warming
1) Consumption values vary depending on the water supply temperature, the ambient temperature, the size of the load, the selected options and more. For dishwashers
equipped with a turbo dryer as illustrated below the drying time is reduced by some 40–60% for certain programs.
2) Connection to cold water, approx. 20 °C. 3) Connection to hot water, approx. 60 °C. 4) The energy label performance figures are based on this program.
18
Dishwashing

6Select options
If you do not want to select any more options, press the Program selector to exit the options menu.
P R O G
Description
This option activates both spray arms and enables you to
wash both the upper and lower baskets. This option can
be used with all programs except Lower half wash, Upper
half wash, Mixed wash and Crockery warming.
Full load
Loading the
baskets
You can use this option if you only have cups and glasses
that need washing in the upper basket. This option can be
used with all programs except Lower half wash, Upper half
wash, Mixed wash and Crockery warming.
Upper half load
You can use this option when you only want to wash plates
and cutlery in the lower basket. This option can be used
with all programs except Lower half wash, Upper half wash,
Mixed wash and Crockery warming.
Lower half load
When you select Delayed start, the dishwasher will start
30 minutes to 24 hours after you press the Start/Stop but-
ton.
Press and hold Start/Stop for three seconds if you want to
cancel the Delayed start option.
•is shown on the display. Press
the button to set the desired start
time.
•Press the Start/Stop button or se-
lect further options. The dishwash-
er now counts down the time every
minute until the program starts.
Then the remaining program time
appears on the display.
Delayed start
With this option, you can choose the temperature used in
the main wash. Select a high temperature if you want to
improve dishwashing efficiency. You can choose a temper-
ature from cold to 70 °C with all programs except Delicate
wash (from cold to 60 °C) and Plastic wash (from cold to
65 °C).
This option can be used with all programs except Auto
wash, Time program, Rinse & Dry, Rinse & Hold and
Crockery warming.
Press to choose the temperature used
in the main wash.
Temperature
19
Dishwashing

Description
Select Long dry for improved drying results. The tempera-
ture increases during the final rinse, which improves drying
results but increases program time and energy consump-
tion. If you want a program without drying, press the option
button again and the symbol turns off. To save energy,
select Short dry or No dry.
You can select the drying performance for all programs
except Auto wash, Time program, Rinse & Dry, Rinse &
Hold and Crockery warming.
Long dry
Drying
No dry
Short dry
This option shortens the program time, but uses more en-
ergy and water. This option can be selected with the pro-
grams Heavy wash, Normal wash, Mixed wash, Upper half
wash and Lower half wash.
OffTime saver
On
This option can be activated when using 3-in-1/all-in-one
detergents. The dishwashing program automatically adapts
to provide the best possible dishwashing and drying results
every time. If you deactivate this option, the dishwasher
will return to ordinary function for all programs. This option
can be used with all programs except Rinse & Dry, Rinse
& Hold and Crockery warming.
If this setting is activated there is no need to add rinse aid
since this option disables rinse aid dispensing.
NOTE!
In order to achieve good dishwashing results, it is essen-
tial to check which type of detergent or all-in-one product
best suits your needs! Read the detergent packaging
carefully for information on proper use. Always follow the
directions for use or information on the detergent packag-
ing!
OffTab
On 3in1
Super Rinse adds two extra rinses. This option can be
used with all programs except Auto wash, Time program,
Rinse & Dry, Rinse & Hold and Crockery warming.
OffSuper rinse
On
The fan runs for another 30 minutes to cool the dishes
before you unload them. This option can be used with all
programs except Auto wash, Time program, Rinse & Dry,
Rinse & Hold and Crockery warming.
OffCool touch
On
See the section Special settings.YesSpecial settings
Exit
20
Dishwashing
