Asko D5459XLSOF User manual

Dear Customer,
Thank you for choosing this quality product from ASKO.
We hope it will meet your expectations and fulfill your needs for many years to
come. Scandinavian design combines clean lines, everyday functionality, and
high quality. These are key characteristics of all our products and the reason
they are greatly appreciated throughout the world.
To get the most out of your new dishwasher, we recommend that you read the
operating instructions before using it. The operating instructions also include
information on how you can help protect the environment.
Do you need this Use&Care Guide in spanish? Log onto
www.askona.com/customer-care to download.
¿Necesita esta Instrucciones de uso y cuidado en español? Entre en
www.askona.com/customer-care y descárguesela.
Operating Instructions
Dishwasher
ASKO D5459XLSOF

Contents
2Front panel
3Important safety instructions
4Before washing for the first time
5Loading the dishwasher
8Using the dishwasher
11Settings
14Care and maintenance instructions
16Troubleshooting
19Technical information
20Service
21Program chart
22Notes
Front panel
The panel is fitted with touch buttons with audible feedback (see the chapter Settings).
PROG
START
STOP
2
1
8
9 10
3
45
6
12
14
13
11
16
15
17
18
7
1 Program selector
2 Heavy wash
3 Sanitation wash
4 Normal wash
5 Eco wash
6 Time program
7 Rinse & Hold
8 Time set (for the Time program)
9 High temperature
10 Long dry
11 Time saver
12 Start/Stop
13 Display
14 Delayed start
15 Child lock (button lock)
16 Salt indicator
17 Rinse aid indicator
18 TAB (3-in-1/all-in-one detergent)
NOTE!
•Two minutes after the last button press, the display enters left-on mode to save energy. The display brightness is reduced. Press
the Program selector once, or one of the option buttons, to reactivate the display.
Customer Care Center 1-800-898-1879
www.askona.com
2

Important safety
instructions
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
WARNING!
This manual does not cover all possible conditions and
situations that may occur. Common sense and caution should
always be used when installing, operating, and maintaining
any appliance.
•Read all instructions before using the dishwasher.
•Dishwashers must be electrically grounded. Read the
Installation Instructions for details.
•Use the dishwasher only for its intended purpose.
•Do not run the dishwasher while you are out of the home.
•Use only automatic dishwasher detergents and rinse agents.
•To reduce the risk of injury, keep detergents and rinse aids
out of the reach of children.
•Do not load sharp items near the door; you could damage
the door seal.
•Place sharp knives in the cutlery basket with the sharp ends
down to avoid the risk of cut-type injuries.
•Do not wash plastic items unless they are marked
“dishwasher safe”or the equivalent. For items not marked,
check the manufacturer’s recommendations. Items not
dishwasher safe could become deformed or melt and create
a potential fire hazard.
•Do not operate the dishwasher unless all enclosure panels
are properly in place (i.e., guard plate, access panel, toe
kick, etc.).
•Do not tamper with controls by removing or changing.
•Do not abuse, sit on, or stand on the dishwasher door or
baskets.
•To reduce the risk of injury, do not allow children to play in
or on a dishwasher.
•Under certain conditions, hydrogen gas may be produced
in a hot water system that has not been used for two weeks
or more. HYDROGEN GAS IS EXPLOSIVE. If the hot water
system has not been used for two weeks, before using the
dishwasher turn on all hot water faucets and let the water
flow from each for several minutes. This will release any
accumulated hydrogen gas. As the gas is flammable, do
not smoke or use an open flame during this time.
•When removing an old dishwasher from service or
discarding it, remove the door to the washing compartment.
•Do not store or use combustible materials, gasoline, or other
flammable vapors and liquids in the vicinity of this or any
other appliance.
•Disconnect electrical power to dishwasher before servicing.
•Repairs should be done by a qualified technician.
•Read the grounding instructions in the installation
instructions.
Child safety
TIP!
Dishwasher detergents and rinse aids are corrosive, so always
keep them out of reach of children.
•Should a child swallow dishwasher detergent or rinse aid,
give plenty to drink immediately, i.e., one or two glasses of
milk or water. Do not try to induce vomiting. Seek medical
advice immediately: Call the National Capital Poison Center
at 1-800-222-1222.
•Always close the door and start the dishwasher as soon as
you put in the detergent.
•Always keep small children away from the machine when it is
open. There may be some detergent residue left inside the
machine.
•If dishwasher detergent gets in someone’s eyes, rinse them
with plenty of water for at least 15 minutes.
•Do not allow children to use or play in or on the dishwasher.
•Load sharp objects with the pointed end facing the back of
the dishwasher. Sharp items loaded in the cutlery basket
should be loaded with pointed ends down.
Activate child lock (Kid Safe™)
You can activate the child lock (button lock) to prevent children
from starting the dishwasher (see the section Settings).
Winter storage/Transport
•Store the dishwasher where the temperature remains above
freezing.
•Avoid long transport distances in very cold weather.
•Transport the dishwasher upright or laying on its back.
Overflow guard function
The overflow protection starts pumping out the machine and turns
off the water supply if the water level in the dishwasher exceeds
the normal level. If the overflow protection is triggered, turn off
the water supply and call the Customer Care Center.
Care and maintenance instructions
When cleaning the edge around the door, use only a slightly
damp cloth. Do not spray water around the edge! Moisture can
make its way into the lock, which contains electrical components.
Packing material
Please sort waste materials in accordance with local guidelines.
Disposal
•When the machine has reached the end of its service life and
is to be disposed of, it should immediately be made unusable.
Pull out the power cable and cut it as short as possible.
•The dishwasher is manufactured and labeled for recycling.
•Contact your municipality for information about where and
how your dishwasher can be recycled correctly.
Customer Care Center 1-800-898-1879
www.askona.com 3

Before washing for the
first time
Water supply
The machine can be connected to either a hot (max. 160 °F, 70
°C) or cold water supply. We recommend a cold water supply.
The water pressure should be 4.2-140 psi. See also the section
Economic dishwashing in the chapter Loading the dishwasher.
Program key
Some dishwashers include program keys in different languages.
Attach the program key in the appropriate language to the top
of the door.
The water softener
In order to achieve good dishwashing results, the dishwasher
needs soft water (water with low mineral content). Hard water
leaves a white coating on dishes and the dishwasher.
Water hardness is specified using the following scales: The
German water hardness scale (°dH) and the French water
hardness scale (°fH). A water supply with a water hardness in
excess of 6°dH (9°fH) must be softened. This is done
automatically with the aid of the built-in water softener. In order
for the softener to function optimally, it must be adjusted to the
hardness of the water supply.
Contact the local water utility to check the water hardness in your
area. Once you have adjusted the water softener, use detergent
and rinse aid doses suitable for soft water.
Adjusting the water softener
Chapter Settings, page 13 describes how to adjust the water
softener. Don't forget to fill the salt compartment with salt after
adjusting the water softener.
Fill up the salt
Before you begin using a dishwasher with a water softener, you
must fill the salt compartment with salt. Use large grain salt or
special dishwasher salt.
WARNING!
Top up the salt just before running a program. To avoid the risk
of rust stains, the dishwasher must be rinsed immediately after
topping up the salt.
Never pour dishwasher detergent into the salt compartment.
This destroys the water softener!
Do as follows the first time:
1 Unscrew the lid as illustrated.
2 Insert the funnel supplied with the dishwasher in the salt
compartment top-up hole. First, pour in about 0,3 gal (1 l) of
water.
3 Then add salt, a maximum of 3 lb (1.5 kg), until the
compartment is full.
4 Wipe up any excess salt so that the lid can be screwed on
firmly.
5 Run a program to ensure that any salt in the dishwasher is
rinsed away.
Salt compartment lid
Refill salt indicator
When the salt needs topping up, the above symbol lights on the
display.
When the salt runs out, unscrew the cap and fill the container
with salt. Water is only needed the first time! Wipe clean and
tighten. Run a program to ensure that any salt in the dishwasher
is rinsed away.
NOTE!
After topping up, it may take a while before the symbol goes
out.
Top up with rinse aid
Drying is faster if you use rinse aid.
1 Open the rinse aid compartment lid.
2 Carefully top up with rinse aid. Only add rinse aid to the level
marked max.
3 Wipe up any spilled rinse aid around the compartment.
4 Close the lid firmly.
Selecting the rinse aid dosage
Rinse aid dispensing can be set from (Off) to (High
dose). (Factory settings: )
Increase the rinse aid dosage:
•If the dishes have water marks.
Reduce the rinse aid dosage:
•If the dishes have a sticky white/blue film.
•If the dishes are streaked.
•Heavy foaming. If you have very soft water, the rinse aid can
be diluted 50:50 with water.
Customer Care Center 1-800-898-1879
www.askona.com
4

Setting the rinse aid dosage
The section Settings describes how to set the rinse aid dosage.
Refill rinse aid indicator
When the rinse aid needs topping up, the above symbol lights
on the display.
NOTE!
After topping up, it may take a while before the symbol goes
out.
Loading the dishwasher
Economic dishwashing
Run programs only with a full load
Wait until the dishwasher is fully loaded before running a program,
this way you save energy. Use the Rinse & Hold program to rinse
the dishes if there are any unpleasant odors while you wait for
the dishwasher to become fully loaded.
Run programs at a lower temperature
If the dishes are only lightly soiled, you can select a lower
temperature with certain programs. See also the section Selecting
Options in the chapter Using the dishwasher.
Select a program with Short dry
To save energy, use Short dry. The drying result will be better if,
once the program is finished, you leave the door slightly open.
Do not rinse under running water
Simply scrape off large food particles before loading the
dishwasher.
Choose a green detergent
Read the environmental declaration on the packaging!
Connect to cold water...
If you use oil or electricity to heat your home.
Connect to hot water (max. 160 °F (70 °C))...
If you use district heating, solar power, or geothermal power to
heat your home. Choosing a hot water connection cuts program
times and reduces the dishwasher's electricity consumption.
Fragile dishes
Some cookware is not dishwasher safe. This can be for several
reasons. Some materials cannot withstand high temperatures,
others can be damaged by dishwasher detergent.
Fragile decoration
Porcelain with decoration on top of the glazing (the items feel
rough) should not be washed in a dishwasher.
Crystal/Glass
Position items so that they do not touch each other during the
wash. Use the lowest possible wash temperature and the shortest
possible program. Select Short dry. Antique and very fragile items
should not be washed in a dishwasher.
Glass washed in a dishwasher at high temperatures can gradually
develop a gray film that cannot be removed. Wash fragile glasses
at a low temperature and with a small amount of detergent.
Silver
Silver and stainless steel items should not come into contact, as
the silver can become discolored.
Cutlery with glued handles
Some types of glue are not dishwasher safe. In such cases, the
handles may loosen.
Wood
Wooden items should only be washed in a dishwasher if marked
dishwasher safe.
Aluminum
Aluminum can lose its shine if washed in a dishwasher. However,
good quality aluminum pans can be washed in a dishwasher,
even if some of the shine will be lost.
Plastic items
Avoid washing plastic items that cannot withstand high
temperatures.
Customer Care Center 1-800-898-1879
www.askona.com 5

Typical load for 10 place settings
Upper basket with 10 place settings AHAM DW-1
NOTE!
Ensure the upper basket is set to its lowest position.
Lower basket with 10 place settings AHAM DW-1
Upper basket
Place glasses, cups, bowls, side plates, and saucers in the upper
basket. Wine glasses are placed on the wine glass shelf and
knives are placed in the knife stand on the right (if equipped).
NOTE!
All dirty surfaces should face in and down!
Raising the upper basket
1 Pull out the upper basket.
2 Grab the sides of the upper basket with both hands and lift it
up.
Lowering the upper basket
1 Pull out the upper basket.
2 While holding the basket, pull out the two locking handles on
either side to lower the upper basket.
Lower basket
Place plates, side plates, serving dishes, pots, and cutlery (in
the cutlery basket) in the lower basket.
Place pots and pans in the rear left of the lower basket to best
utilize dishwashing performance from the rear spray nozzle
(Power Zone™Pot & Pans), which is intended for these types of
dishes.
Customer Care Center 1-800-898-1879
www.askona.com
6

Fold-down plate supports
Lower the fold-down plate supports when washing pots.
1
2
Forward mount for plate support
Used for plates with a diameter greater than 9 3/4" (25 cm).
1
2
3
4
Cutlery basket
Place cutlery with the handles facing down, except for knives,
and spread them out as much as possible. Ensure that spoons
do not stack inside each other.
The cutlery basket is best placed in the middle at the front of the
lower basket to best utilize dishwashing performance from the
unique spray nozzle (Power Zone™Cutlery), which is intended
for the cutlery basket.
NOTE!
Do not place cutlery made of different materials, such as silver
and stainless steel, in the same place (risk of discoloration).
WARNING!
Knives and other pointed items must be placed with the points
down in the cutlery basket or horizontally in other baskets.
Fold-down section for small items
The cutlery basket has a fold-down section in the middle for small
items, or small shafts, such as electric whisk attachments.
ac
b
Customer Care Center 1-800-898-1879
www.askona.com 7

Using the dishwasher
Add detergent
1 Prewash detergent compartment
2 Main wash detergent compartment
We recommend that you use only unscented, granular automatic
dishwashing detergent. Using the wrong detergent could cause
flooding and/or damage your dishwasher. Do not use detergent
that has been wet and is clumped. Also, check the expiration
date on the container.
The amount of detergent needed can vary due to differences in
water hardness. To determine the water hardness in your area,
contact your local water utility or area water softening company.
The harder the water, the more detergent you may need. Refer
to the chart below for the recommended detergent amounts
based on water hardness. Remember, you should adjust the
amount of detergent you use by small amounts until you find the
correct amount. Twelve grains and higher is extremely hard water
and detergent alone may not be enough. You may need to use
a water softener to maximize the performance of your dishwasher.
Also, in areas with hard water (9+) you may need to wash at lower
temperatures to prevent hard water deposits from forming in tank
and wash system. In hard water areas, both the dishes and the
machine can develop a white or gray film after a while. If this
happens, run the Normal wash program with high temperature
and two tablespoons of citric acid or commercially available
dishwasher cleaner in the detergent compartment (with no dishes
in the machine).
NOTE!
If you use a dishwashing detergent with a rinse aid additive,
you should not fill the rinse aid dispenser. This could cause a
film on your dishes.
Recommended detergent amounts based on water hardness
Detergent amountsWater hardness
Prewash 1 teaspoon
Main wash 1 to 1-1/2 tablespoons
Soft
(0-3 grains per gallon)
Prewash 1 teaspoon
Main wash 1 to 2 tablespoons
Medium
(4-8 grains per gallon)
Prewash 1 teaspoon
Main wash 2 to 3 tablespoons
Hard
(9+ grains*)
*12 grains and higher is extremely hard water.
WARNING!
Children must be supervised –dishwasher detergent is
corrosive!
NOTE!
Use only dishwasher detergent! Liquid hand-washing detergent
must not be used as the foam that forms prevents the
dishwasher from operating effectively.
Dishwasher tablets
Halve the tablet if it is difficult to close the dispenser lid. There is
a risk that the detergent will not be released properly if the lid is
tight and cannot open correctly.
NOTE!
Dishwasher tablets are not recommended for short programs
(less than 75 minutes). Use powder or liquid dishwasher
detergent instead.
3-in-1/All-in-one detergent
Read through the directions for these products carefully. If
anything is unclear, contact the detergent manufacturer.
Program selection
Press the Program selector one or more times until the desired
program symbol lights.
Heavy wash
Program for very dirty dishes, such as pans, casserole dishes,
and oven dishes. If these dishes do not completely fill the
dishwasher, you can add plates and other dishes that can
withstand a Heavy wash to fill out the load.
Sanitation wash
A program with the ability to help with most household germs
and extra dirty dishware. This program will have a high final rinse
temperature for a good drying result and germ treatment.
NOTE! Do not put in dishware that cannot stand high wash or
rinse temperatures.
Normal wash
Use to wash normally soiled dishes, such as plates, serving
dishes, cups, glasses, and so on.
Eco wash
Use when you want to save energy. For normally soiled dishes.
Time program
The program adapts to the specified running time or finish time.
With this program, it is important to choose a time suited to how
dirty the dishes are.
Lightly soiled dishes0:30-1:15
Normally soiled dishes1:30-2:00
Heavily soiled dishes2:15-3:00
To set the program time, see the section Selecting Options.
Customer Care Center 1-800-898-1879
www.askona.com
8

Rinse & Hold
Use to rinse dishes while you wait for the dishwasher to become
fully loaded.
Selecting Options
To select an option, press one of the option buttons. The field
next to the button lights when the option is activated. The available
options depend on the selected program. Once you have started
the program, the options you selected are saved for the next time
you use the same program. An exception is the Delayed start
option.
Time set
Press the option button several times –or hold it in –to set the
desired program time for Time program. You can choose a
program time between 30 minutes and 3 hours.
High temperature
Activate this option for improved dishwashing results. The
machine then uses a higher temperature for the main wash. This
option cannot be activated if the Time saver option is selected.
If you want to use the lower temperature, press until the field next
to the button turns off.
You can vary the temperature as shown below:
130 °F (55 °C) / 160 °F (70 °C)Sanitation wash:
130 °F (55 °C) / 150 °F (65 °C)Normal wash:
140 °F (60 °C) / 150 °F (65 °C)Heavy wash:
120 °F (50 °C) / 140 °F (60 °C)Eco wash:
Long dry
A higher temperature in the final rinse and a longer drying phase
improves the drying result if you activate the Long dry option.
This causes a slight increase in energy consumption. This option
can be used with all programs except Time program. This option
cannot be activated if the Time saver option is selected.
If you want a program with Short dry, press so that the field next
to the button turns off.
Time saver
This option shortens the program time, but uses more energy
and water. This option can be selected with Heavy wash,
Sanitation wash, or Normal wash.
Delayed start
When you select Delayed start, the dishwasher will start 1-24
hours after you press the Start/Stop button.
1 Press the button once to activate Delayed start. Press the
button several times –or hold it in –to set the desired number
of hours.
2 Press Start/Stop and the dishwasher counts down 1 hour at
a time and starts after the selected delay.
Press and hold Start/Stop for five seconds if you want to cancel
the Delayed start option.
NOTE!
Remember to press the Start/Stop button to start the program.
Start the dishwasher
Press and hold Start/Stop until the display flashes three times
with the remaining time. This indicates that the program has
started. Close the door properly, otherwise the dishwasher will
not start. The display indicates if the door is open.
NOTE!
If the machine does not start within 2 minutes of the last button
press, the display returns to showing the last program run.
Time remaining
Once you have selected a program and options, the display
indicates how long the program took the last time it was used.
Once you have started the dishwasher, the display indicates how
much program time remains. The remaining time is updated after
the water for the final rinse has been heated.
This may differ somewhat from time to time depending on the
temperature of the water supply, the amount of dishes, the
ambient temperature, and other factors.
The time counts down while the program is running and the
remainder of the program is displayed. The remaining time is
displayed, e.g., 1:15, meaning that 1 minute 15 seconds of the
program remains.
NOTE!
During the first run of each program, the remaining time
displayed can be slightly misleading, as the dishwasher is
estimating the time. When you run the program a second time,
the dishwasher will calculate the remaining time based on the
previous duration of the program.
Stopping or changing a program
If you want to change programs after starting the dishwasher,
open the door then press and hold Start/Stop for five seconds.
Add more detergent if the lid of the detergent dispenser has
opened. Then choose a new program, press Start/Stop, and close
the door.
Do you want to add more dishes?
Open the door. The dishwasher stops automatically. Add the
dishes, close the door, and the dishwasher resumes the program.
If the dishwasher is turned off using
the main power switch or due to a
power failure
If the program was not finished, the interrupted program resumes
when power is restored.
NOTE!
During drying, the program is interrupted if the power is cut or
the door is open for more than 2 minutes.
Customer Care Center 1-800-898-1879
www.askona.com 9

Once the program has finished
Once the program has finished, "End" appears on the display.
A buzzer also sounds at the end of the program. See the section
Settings, which describes how to change this function.
Once the dishwasher has finished, it uses only standby power.
Turn off the dishwasher using the main power switch if you want
to completely cut the power. Turn off the water supply valve after
each use.
Customer Care Center 1-800-898-1879
www.askona.com
10

Settings
Do as follows to open the settings menu:
Turn off the dishwasher using the main power switch. Wait about five seconds.1.
Then press the main power switch again. Wait until the numbers appear in the right-hand display before continuing to
the next step.
2.
Within five seconds, press and hold the Program selector (wait for the audible signal confirming the button press) and
then immediately press the Long dry button without releasing the Program selector.
3.
+
Keep the buttons pressed until the symbols for the Heavy wash and Rinse & Hold programs start to flash.4.
TIP!
Be sure to press right on the symbols, so as not to inadvertently activate any other button. Try again if you fail to open
the settings menu the first time.
P R O G
START
ST OP
Press to save the set value and continue to
the next setting.
Current setting.
Current setting value.
Press to browse between setting values.
Display
You can now adjust the following settings:
DescriptionSettingsOptionsButton press
You can activate the child lock (button lock) option to
prevent children from starting the dishwasher.
Child lock
(Kid Safe™)
(Off)
(On) Press the High temperature and Long dry buttons simulta-
neously to temporarily deactivate the button lock when
you want to start the dishwasher. The button lock is auto-
matically reactivated after 2 minutes.
Press Start/Stop to save the setting value and continue to the next setting.
If you do not want to change any other settings, keep pressing Start/Stop to step through the entire settings menu.
The dishwasher uses a buzzer to indicate when a program
is finished or when a fault has occurred.
Buzzer volume
(Off)
(Low)
(High)
Press Start/Stop to save the setting value and continue to the next setting.
Customer Care Center 1-800-898-1879
www.askona.com 11

DescriptionSettingsOptionsButton press
This sound is used to confirm each button press.Operation volume
(Off)
(Low)
(High)
Press Start/Stop to save the setting value and continue to the next setting.
For adjusting the contrast of the display.LCD contrast
(Low)
(High)
Press Start/Stop to save the setting value and continue to the next setting.
Rinse aid dosage setting.Rinse aid
(Off)
(Low dosage)
(High dosage)
Press Start/Stop to save the setting value and continue to the next setting.
This option can be activated when using 3-in-1/all-in-one
detergents. The dishwashing program automatically
adapts to provide the best possible dishwashing and
drying results every time. If you deactivate this option, the
dishwasher will return to ordinary function for all programs.
If this setting is activated, there is no need to add rinse
aid since this option disables rinse aid dispensing. It also
reduces the amount of salt added to the water softener.
NOTE!
In order to achieve good dishwashing results, it is essen-
tial to check which type of detergent or all-in-one product
best suits your needs! Read the detergent packaging
carefully for information on proper use. Always follow
the directions for use or information on the detergent
packaging!
TAB
(3-in-1/all-in-one detergent)
(Off)
(On)
Customer Care Center 1-800-898-1879
www.askona.com
12

DescriptionSettingsOptionsButton press
Press Start/Stop to save the setting value and continue to the next setting.
Adjusting the water softener. Read off the appropriate
setting from the water hardness table below.
°dH
0-5
6-8
9-11
12-14
15-19
20-24
25-29
30-39
40-49
50+
0-9
10-14
15-20
21-25
26-34
35-43
44-52
53-70
71-88
89+
°fH
Water hardness
(Soft water)
(Hard water)
Press Start/Stop to exit the settings menu.
Customer Care Center 1-800-898-1879
www.askona.com 13

Care and maintenance
instructions
Coarse filter
The coarse filter traps larger food particles, which cannot get
past the drain pump. Empty the coarse filter as necessary.
1 Lift the coarse filter by the handle.
2 Empty the coarse filter. Remember to replace it!
Coarse filter
Fine filter
Debris that collects on the fine filter is automatically rinsed away
during each wash. However, the fine filter and its pipe section
should be cleaned a couple of times a year.
1 Turn the handle counterclockwise once.
1x
Fine filter
2Lift the pipe section straight up by the handle. Free the coarse
filter to clean the pipe section.
3 Remove and clean the fine filter.
4 Replace in reverse order. Check that the edges seal properly
when replacing the fine filter.
Pipe section
5 Lock the filter in place by turning the handle clockwise to the
stop position. The handle should point straight out from the
dishwasher.
1x
NOTE!
The dishwasher must not be used without the filters in place!
Dishwashing results may be affected if the coarse filter is
incorrectly fitted.
Drain pump
The pump can be accessed from inside the dishwasher.
1 Cut the power to the dishwasher by unplugging the unit from
the power outlet.
2 Remove the coarse filter and pipe section.
3 Remove the small yellow drain pump access cover at the left
of the bottom drain (see illustration below).
4 By inserting your finger into the hole, you can turn the pump
blades to release anything blocking the pump.
5 Reinstall the access cover and filters.
6 Plug the machine in again.
If the dishwasher still does not start and a whirring sound is
heard, the overflow protection has been triggered.
•Shut off the water.
•Unplug the unit from the power outlet.
•Call the Customer Care Center.
NOTE!
Do not forget to reinstall the drain pump access cover.
Lower spray arm
Holes and bearings can sometimes become blocked.
1 Pull the lower spray arm straight up to release it.
2 Remove any debris using a needle, toothpick, or some other
similar pointed device. The spray arms also have holes
underneath.
Customer Care Center 1-800-898-1879
www.askona.com
14

Upper spray arm
1 Pull out the basket.
2 Unscrew the spray arm bearings as illustrated to remove the
spray arm from the upper basket.
Spray arm bearings
3 Clean the upper spray arm in the same manner as the lower
spray arm.
4 Replace the spray arm and screw the spray arm bearings
firmly back into place.
Door
When cleaning the edge around the door, use only a slightly
damp cloth (with a little cleaner if necessary).
WARNING!
Do not use a spray bottle or the like around the door lock. This
is to ensure that water does not penetrate the door catch and
come into contact with the electrical components.
Limescale deposits
The dishwasher tub is made of stainless steel and is kept clean
through normal use. However, if you have hard water, limescale
deposits may form in the dishwasher. If this happens, run the
Normal wash program with high temperature and two tablespoons
of citric acid or commercially available dishwasher cleaner in the
detergent compartment (with no dishes in the machine).
Front panel
Keep the touch buttons clean and free from grease. Wipe them
clean with a dry or slightly damp cloth. Never use cleaners –they
can scratch the surface. Use the main power switch to turn off
the dishwasher before cleaning the touch buttons to avoid
activating any buttons unintentionally.
Customer Care Center 1-800-898-1879
www.askona.com 15

Troubleshooting
ActionType of faultDisplay
Call the Customer Care Center.Overfilling
See "Water remains in the dishwasher above the filters"
in the table below.
Water outlet fault
Check that the water supply valve is on.Water inlet fault
Turn off the water supply valve and call the Customer
Care Center.
Inlet valve leakage
Turn off the machine with the main power switch and then turn it on again to clear the error message from the display.
ActionPossible causesProblem
Remove the arms and clean them.The spray arms do not rotate.The dishes are not clean.
Check that the dishes are not blocking the
spray arms.
Avoid large packages.Detergent is too old. Detergent is a perish-
able product.
Dose according to water hardness. Far too
much or far too little detergent can result in
poor dishwashing results.
Incorrect detergent dosage.
Select a higher temperature or a more pow-
erful program.
Dishwashing program too weak.
Do not cover dishes with large bowls or lids.
Avoid placing very tall glasses in the corners
of the baskets.
Dishes loaded incorrectly.
Load the dishes securely.Glasses and cups have toppled over during
the program.
Screw the filter firmly into place. See the
section Care and maintenance instructions.
The filter is not correctly fitted.
Check that the salt compartment lid is prop-
erly tightened. Otherwise call the Customer
Care Center.
The water softener is leaking salt.Spots or films on the dishes.
See the section Settings.Incorrect water softener setting.
See the sections Before washing for the first
time and Settings.
Incorrect rinse aid dosage setting.
Top up with salt. See the section Before
washing for the first time.
Salt compartment empty.
Wash crystal at a low temperature and with
a conservative amount of detergent. Contact
the detergent manufacturer.
Too high temperature and/or too much deter-
gent can cause etching on crystal. Unfortu-
nately, this cannot be repaired, only prevent-
ed.
Reduce the amount. See the sections Before
washing for the first time and Settings. If you
have very soft water, you may want to dilute
the rinse aid 50:50 with water.
Rinse aid dosage setting too high.The dishes have a sticky white/blue film.
Customer Care Center 1-800-898-1879
www.askona.com
16

ActionPossible causesProblem
Rinse off these types of food if not starting
the dishwasher immediately. Or why not run
the Rinse & Hold program?
Some types of food, such as mustard, may-
onnaise, lemon, vinegar, salt, and dressings,
can mark stainless steel if left for too long.
Spots on stainless steel or silver.
Silver and stainless steel items should not
come into contact during dishwashing.
All stainless steel can cause spots on silver
if they come into contact during dishwashing.
Aluminum can also cause spots on dishes.
Use a detergent with a bleaching agent.Lipstick and tea can be difficult to wash off.Spots left after washing.
Check that the dishes are placed securely.
Spin the spray arms to make sure they can
rotate.
The dishes are not correctly placed or the
spray arms are not rotating.
Rattling sound when dishwashing.
Press and hold Start/Stop until the display
flashes three times with the remaining time.
The Start/Stop start button has been pressed
for too short a time.
The dishwasher does not start.
Check.The door is not properly closed.
Check.A fuse/circuit breaker has been tripped.
Check.The plug is not plugged into the power outlet.
Check.The water supply valve is turned off.
Check.Overflow/leaks.
Turn off the water supply valve. Pull out the
plug and call the Customer Care Center.
A whirring sound (the drain pump) is heard
from the dishwasher and does not stop when
the main power switch is turned off.
Press and hold Start/Stop for five seconds if
you want to cancel the Delayed start option.
Check that the Delayed start option has not
been selected.
None. Next time the program is run, the cor-
rected time will be displayed.
The program is taking longer than estimated.1 minute appears on the display.
Loosen the drain hose from where it termi-
nates. Check that no debris has clogged the
hose. Is the cone-shaped part of the drain
boot cut to the maximum size of the fitting
where it attaches?
Blocked drain hose.Water remains in the dishwasher above the
filters.
Check that the hose is free from kinks and
sharp bends.
Kink in drain hose.
Clean the coarse and fine filters.The filters are blocked.
Clean the drain pump. See the section Care
and maintenance instructions.
Debris in the drain pump.
Clean with dish brush and low foaming
cleaner.
Dirt around the seals and in corners.Bad odor in dishwasher.
Run a program with a higher temperature
about once a month.
Low temperature programs have been select-
ed for a prolonged period.
Customer Care Center 1-800-898-1879
www.askona.com 17

ActionPossible causesProblem
Activate the Long dry option.Drying power too low.The dishes are not dry enough.
Fully load the dishwasher.The dishwasher is not fully loaded.
Top up with rinse add or increase the rinse
aid dosage. See the sections Before washing
for the first time and Settings.
Rinse aid needs topping up or dosage is set
too low.
Open the door a little once the program has
finished.
Check that the baskets are correctly posi-
tioned horizontally.
The baskets are not correctly positioned.Cannot close door.
Check that the dishes are not blocking the
baskets from sliding properly into place.
Wait a moment then try again.You have pressed the touch buttons too soon
after opening the door.
The touch buttons do not react when
pressed.
Clean with a dry or slightly damp cloth.Dirt on the touch buttons.
See the section Settings.Child lock (button lock) activated.
Customer Care Center 1-800-898-1879
www.askona.com
18

Technical information
Technical data
32-1/4'' - 34'' (819-864 mm)Height:
24" (610 mm)Width:
22-7/8" (581 mm)Depth:
115 lb (52 kg) 1) Weight:
4.2–140 psiWater pressure:
See serial number tag and rating plate.Electrical connection:
See serial number tag and rating plate.Rated power:
1) Weight can vary due to different specifications.
Customer Care Center 1-800-898-1879
www.askona.com 19

Service
LIMITED WARRANTY –RESIDENTIAL
APPLIANCES
ASKO Distribution North America, LLC. (hereinafter “ASKO”) warrants
the original purchaser (the “ASKO Customer”) of the ASKO product
(the “ASKO Product”), who purchased the appliance from a
distributor, dealer, manufactures representative or other seller who
has been authorized by ASKO (“Authorized ASKO Dealer”), that this
ASKO Product is free of defects in material and workmanship, subject
to the terms and conditions set forth herein. The limited warranty
covers parts and labor, except as set forth in this Limited Warranty.
Service must be provided by an ASKO designated service company.
YOUR SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED
WARRANTY SHALL BE PRODUCT REPAIR AS PROVIDED HEREIN.
The limited warranty is valid only in the United States or Canada and
applies only when the appliance is used in the country in which it
was purchased. Proof of original purchase date is required to obtain
service under this limited warranty.
Residential ASKO Products Used Exclusively for
Household/Personal Purposes:
Two (2) Years limited Warranty –Any warranty service claims for
residential ASKO Products must be filed with ASKO within two (2)
years from date of purchase.
Residential ASKO Products Not Used Exclusively for House Hold
Purposes, used Commercially or Use in marine, Mobile or
Aeronautical Applications:
One (1) Year limited Warranty –Any warranty service claims for
ASKO Products not used exclusively for household and personal
use, used commercially or used in marine, mobile, or aeronautical
application must be filed with ASKO within One (1) year from date
of purchase.
ITEMS EXCLUDED FROM
WARRANTY
This limited warranty does not cover:
1 Replacement parts or repair labor if this appliance is used in a
manner that is inconsistent to published user or operator
instructions and or/or installation instructions.
2 Service calls to correct the installation of your appliance, to
instruct you on how to use your appliance, to replace or repair
house fuses, or to correct house wiring or plumbing.
3 Consumable parts are excluded from warranty coverage.
4 Damage resulting from accident, alteration, misuse, abuse, fire,
flood, acts of God, improper installation, installation not in
accordance with electrical or plumbing codes, or use of products
not approved by ASKO.
5 Cosmetic damage, including scratches, dents, chips or other
damage to the finish of your appliance, unless such damage
results from defects in material or workmanship and is reported
to ASKO within 5 days from date of purchase.
6 Pickup and delivery. This appliance is intended to be repaired
in your home.
7 Repairs to parts or systems resulting from unauthorized
modifications made to the appliance.
8 Expenses for travel and transportation for product service if your
appliance is located in a remote area where service by an
authorized ASKO servicer is not available.
9 The removal and reinstallation of your appliance if it is installed
in an inaccessible location or is not installed in accordance with
ASKO’s published installation instructions.
10 Replacement parts or repair labor on appliances with original
model/serial numbers that have been removed, altered or cannot
be easily determined.
DISLCAIMER OF IMPLIED
WARRANTIES
YOUR SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED
WARRANTY SHALL BE PRODUCT REPAIR AS PROVIDED HEREIN.
ASKO SHALL NOT BE LIABLE FOR INCIDENTIAL OR
CONSEQUENTIAL DAMAGES. Some states and provinces do not
allow the exclusion or limitation of incidental or consequential
damages, so these limitations and exclusion may not apply to you.
This warranty gives you specific legal rights, and you also may have
other rights that vary from state to state or province to province.
If you think you need repair service, first see the “Trouble Shooting”
section of the Use & Care Guide. If you are unable to resolve after
checking “Trouble Shooting”additional help can be found by calling
ASKO Customer Care at 1-800-898-1879
Read chapter Troubleshooting before contacting the Customer
Care Center. Make a note of the details on the rating plate
positioned on the right inside the dishwasher. Make a note of the
service number (1), item number (2) and serial number (3).
SERIAL NO.
1
3
ART. NO.
Service no.
2
Should you need further assistance, contact us at the address
below:
ASKO Distribution North America, LLC.
Customer Care Center
PO Box 44848
MADISON WI 53744
Customer Care Center 1-800-898-1879
www.askona.com
20
