Asko D3532 User manual

Quick Start Guide
We know you’re excited about owning an ASKO dishwasher and you’re anxious to get started, so here’s a brief summary of the operation
procedures. The page references in this Guide refer to the Use and Care Guide. To get the most out of your dishwasher’s features, we
recommend that you read this guide and the Use and Care Guide before using the dishwasher.
PROGRAMSPROGRAMS
PROGRAMSPROGRAMS
PROGRAMS
To select a program, simply press the program button until the program you desire displays then press Start/Stop. The programs are
described below. You can also change certain program features. See “Options” below.
Heavy Wash (Cold, 85° – 170°/Sani F)
For the heaviest soiled loads, such as casseroles
or sauce pans.
Normal Wash (Cold, 85° – 170° F)
For normally soiled loads, such as plates, glasses,
bowls, and lightly soiled pans.
Mixed Wash
Designed to wash heavily soiled dishes in the lower
basket and lightly soiled dishes in the upper basket.
Upper Basket
Washes only the upper basket
Delayed Start
This option allows you to delay starting the dishwasher from 1/2 hour
to 24 hours. Press the Menu button until Delayed Start displays, then
press Set until the number of hours you wish to delay starting the
dishwasher displays along with a flashing clock symbol. Press Menu
then press Start/Stop.
To cancel Delay after you press Start/Stop, hold down the Start/Stop
button for three seconds. If you change your mind before you press
Start/Stop, continue to press this button until “0” displays.
AllBaskets
This option lets you set which spray arms will function. You have
three choices:
THE CONTRTHE CONTR
THE CONTRTHE CONTR
THE CONTROL POL P
OL POL P
OL PANELANEL
ANELANEL
ANEL
Your ASKO dishwasher has our state-of-the-art electronic control panel, as illustrated below.
OPTIONSOPTIONS
OPTIONSOPTIONS
OPTIONS
Once you have selected a program, you can change some of the program features by using the options (described below). To select an
option, simply press the Menu button until the option you desire displays, then press the Set button until the desired setting displays. Press
Menu to confirm your selection. You can continue to make programming changes or press Start/Stop to start the program.
Lower Basket
Washes only the lower basket
Delicate Wash (Cold, 140° F)
For delicate items, such as fine china and crystal, that are washed
immediately after use. When using this program, you should set the
temperature to low and dry the dishes without heat.
Quick Wash (Cold, 85° – 140° F)
For lightly soiled loads that are washed immediately after use. This
program can also be used for delicate items, but you should set the
temperature to low and dry the dishes without heat.
Rinse and Dry (120° F)
Rinses the dishes with hot water then activates the fan and heating
element to dry them.
Rinse and Hold
To rinse dishes that you plan to wash later that day.
All Baskets – Washes the upper basket, Safe and Handy upper
cutlery basket and the bottom baskets.
Upper Basket – Washes only the upper basket and the Safe and
Handy upper cutlery basket.
Lower Basket – Washes only the lower basket
Temperature
The temperature can be changed in all programs, exceptAuto wash,
Rinse and Hold, and Rinse and Dry. Your choices are: cold, 85°,
105°, 120°, 130°, 140°, 160°, and 170° F. (Note: The Delicate and
Quick wash programs cannot be set over 140° F.) To select a
temperature, press the Menu button until Temperature displays, then
press the Set button until the desired setting displays. Press Menu to
confirmyourselection.
When you select 170° F, the word “Sani” displays.
Optionscontinuedonnextpage...
Model D3532
SELF CLEANING SYSTEM
DISPLADISPLA
DISPLADISPLA
DISPLAYY
YY
Y WINDOWINDO
WINDOWINDO
WINDOWW
WW
W
The display window shows the programs, options, remaining program time and fault codes. It also allows you to access the program menus
and customize the wash programs. If you select Delayed Start, the window will display the number of hours selected. When you press Start/
Stop, the countdown time displays.
Remaining program time – The remaining program time is calculated by the time it took the program to run last time. (Note: The first time
you run a program, the display will display 1:00.) As the program progresses, the time remaining displays the hour and minutes (e.g., 1:02,
which means one hour and two minutes.)
Auto Wash
The dishwasher has sensors that detect the level of soil on the
dishes and adjust the water consumption and temperature
accordingly. You cannot adjust the temperature or drying time with
this program. “The Normal Wash
program is used
for energy testing
and should be
used for normal or
lightly soiled
loads. When
washing dishes
that are more
heavily soiled, use
a longer program
with higher
temperatures such
as Heavy Wash or
Auto wash.”
Start/Stop
button
Programming
buttons
Display
window
Program
button
Power
button

QQ
QQ
QUICK STUICK ST
UICK STUICK ST
UICK STARAR
ARAR
ART PRT PR
T PRT PR
T PROCEDURESOCEDURES
OCEDURESOCEDURES
OCEDURES
1. Load the dishwasher. (There’s no need to pre-rinse. Simply scrape off large food particles before you 3, 4
load the dishware.)
2. After you’ve pushed the baskets back inside the unit, manually rotate the upper and lower spray arms 3
to be sure they turn freely. Rearrange any item that blocks the wash arms.
3. Add 1 to 3 tablespoons of automatic dishwashing detergent and close the dispenser cover. 5
4. Make sure there is rinse aid in the dispenser. Add rinse aid, if needed. 6
5. Press the main power button on the far left side of the inner door panel to turn on power to the machine.
6. Press the Program button until the desired program displays.
7. If desired, set program options by pressing Menu until the option you wish to select displays. Press Set until
the desired setting displays, then press Menu to confirm your selection.
8. Press the Start/Stop button.
9. Close the door securely. (You should hear it click shut.) The dishwasher will start.
Refer to this page in
the Use & Care Guide.
INTERRINTERR
INTERRINTERR
INTERRUPTINGUPTING
UPTINGUPTING
UPTING A PRA PR
A PRA PR
A PROGRAMOGRAM
OGRAMOGRAM
OGRAM TT
TT
TOO
OO
O ADDADD
ADDADD
ADD AN ITEMAN ITEM
AN ITEMAN ITEM
AN ITEM
If you want to interrupt a program to add an item, open the door slightly until the spray arms stop turning. You can then open the door fully and
place the item into the dishwasher. Close the door securely. The program will continue from where it was interrupted.
WARNING! Be extremely careful when opening the door during a program. The water is hot and you could get scalded.
CHANGING OR STOPPING A PROGRAMCHANGING OR STOPPING A PROGRAM
CHANGING OR STOPPING A PROGRAMCHANGING OR STOPPING A PROGRAM
CHANGING OR STOPPING A PROGRAM
If you decide to change the program after you have started the machine, press the Start/Stop button for three seconds. You will have to select
the program and options again when you are ready to restart the program. (Note: If the program has already gone through the wash cycle,
you will have to add detergent.)
CHILD-SAFE BCHILD-SAFE B
CHILD-SAFE BCHILD-SAFE B
CHILD-SAFE BUTTUTT
UTTUTT
UTTON LON L
ON LON L
ON LOCKOCK
OCKOCK
OCK
To prevent a child from accidentally starting the dishwasher or changing the program settings, the dishwasher can be programmed not to
start unless two buttons are held down simultaneously. Refer to your Use and Care Guide for instructions on how to activate this feature.
END-OF-PROGRAM SIGNALEND-OF-PROGRAM SIGNAL
END-OF-PROGRAM SIGNALEND-OF-PROGRAM SIGNAL
END-OF-PROGRAM SIGNAL
The dishwasher emits a short signal at the end of the program. Refer to your Use and Care Guide for instructions on how to adjust the volume
or to deactivate the signal.
DISHWASHING DETERGENT AND RINSE AIDDISHWASHING DETERGENT AND RINSE AID
DISHWASHING DETERGENT AND RINSE AIDDISHWASHING DETERGENT AND RINSE AID
DISHWASHING DETERGENT AND RINSE AID
We recommend that you use only unscented, granular automatic dishwashing detergent. Generally, one tablespoon of detergent is needed
for a normal wash load. More heavily soiled items, however, may need more detergent. (See page 5.) In any case, you should never use
more than three tablespoons of detergent.
Using liquid rinse aid prevents water spots from forming on dishes and improves drying by allowing water to “sheet” off the dishes. The rinse
aid is released during the final rinse. For information on how to fill the rinse aid dispenser and control the amount released, refer to page
6 in your Use and Care Guide. NOTE: If you use a dishwashing detergent with a rinse aid additive, you should not fill the rinse aid
dispenser.
STST
STST
STARAR
ARAR
ART/STT/ST
T/STT/ST
T/STOP BUTTOP BUTT
OP BUTTOP BUTT
OP BUTTONON
ONON
ON
Once you have selected the wash program and options, press this button to start the dishwasher. (Make sure the door is securely closed.)
Temperature
Thetemperature canbe changed in all programs,exceptAutowash,
Rinse and Hold, and Rinse and Dry. Your choices are: cold, 85°,
105°, 120°, 130°, 140°, 160°, and 170° F. (Note: The Delicate and
Quick wash programs cannot be set over 140° F.) To select a
temperature, press the Menu button until Temperature displays,
then press the Set button until the desired setting displays. Press
Menu to confirm your selection.
Drying
This lets you select how long the turbo fan runs after the final rinse.
You have three options: Short, Normal, or Extra drying. (Note: This
option is not available with the Auto wash, Rinse and Hold and
Rinse and Dry programs.) To set the drying time, press Menu until
“Drying” displays, then press Set until your preference displays.
Press Menu to confirm your selection.
Express
This option reduces the wash time and lowers the wash temperature
by 20° F. (Note: This option is not available with the Quick Wash
and Rinse and Hold/Dry Programs.) Press Menu until Express
displays, then press Set once to select On or twice to select Off.
Press Menu to confirm your selection.
CoolTouch
This option lets you set a cool-down cycle after the drying program.
Press Menu until Cool Touch displays, then press Set once to select
On or twice to select Off. Press Menu to confirm your selection.
NOTE: There are more programming options available. Refer to
your Use and Care Guide for details.
Art. 8077187. Rev 01
Refer to your Use and Care Guide for additional information.
POPO
POPO
POWER BUTTWER BUTT
WER BUTTWER BUTT
WER BUTTONON
ONON
ON
Press this button to turn the main power to the unit on and off. See the illustration on the opposite side of this page to see the location
of the power button.
