Asoni CAM616M User manual

2 Mega-Pixel
H.264 CMOS Network Camera
CAM616M / CAM616M-PoE
User’s Manual
Date: 7/20/2012
Firmware Version: V1.0.32

1
Content
Content .......................................................................................................................................1
1. Preface.................................................................................................................................3
2. Product Specifications.......................................................................................................3
3. Product Installation ............................................................................................................5
A. Hardware Installation......................................................................................................5
Cable Connections................................................................................................................5
I/O Connections....................................................................................................................6
B. Monitor Setting................................................................................................................8
C. IP Assignment..................................................................................................................9
4. Live Video..........................................................................................................................11
5. Configuration ....................................................................................................................16
A. System ...........................................................................................................................16
System Information.............................................................................................................16
User Management..............................................................................................................20
System Upgrade.................................................................................................................22
System Logs.......................................................................................................................23
B. Video/Audio Setting ......................................................................................................24
Video Format ......................................................................................................................24
Image Setting......................................................................................................................29
Audio Setting ......................................................................................................................31
C. Network Setting.............................................................................................................32
Network Setting ..................................................................................................................32
Mail / FTP / Samba Setting.................................................................................................36
PPPoE Setting....................................................................................................................39
DDNS Setting .....................................................................................................................40
D. Event Handling..............................................................................................................42
Event Setting ......................................................................................................................42
I/O Setting...........................................................................................................................47
Schedule.............................................................................................................................49
6. Network Configuration.....................................................................................................51
A. Intranet Only..................................................................................................................51

2
Connects to PC Directly......................................................................................................51
Connects to an Exist LAN...................................................................................................52
B. Internet Only..................................................................................................................53
Connects toADSL with Fixed Public IPAddress.................................................................53
Connects toADSL with Floating Public IPAddress (PPPoE)..............................................54
C. Intranet + Internet..........................................................................................................56
Connects to Internet with Fixed Public IPAddress..............................................................56
Connects to Internet with Floating Public IPAddress..........................................................58
7. Factory Default..................................................................................................................59

3
1. Preface
This camera is a professional 2 Mega-Pixel CMOS network camera which builds in web
server. User views real-time video via IE browser. It supports H.264, JPEG and MPEG4
(3GPP Only) video compression which provides smooth and high quality video.
The PoE model built-in support for Power over Ethernet allows the camera to receive both
data and power over a single Ethernet cable.
This camera is an easy-to-use IP camera which is designed for security application.
2. Product Specifications
2 Mega-Pixel CMOS Sensor
H.264 / MJPEG / MPEG4 (3GPP Only) compression formats.
Supports resolution up to 1600x1200
H.264 / MJPEG / MPEG4 (3GPP Only) triple streaming.
Self-Contained HTTP Web Server providing Internet capability for remote access
Built-in PoE splitter, support for Power over Ethernet (PoE model)
2-way audio
Online firmware upgrade
Recorded files compatible with Microsoft Windows Media Player
Hardware
CPU / RAM / ROM ARM 9, 32 bit RISC / 256MB / 16MB
Image Sensor 1/3” CMOS, 2 Mega-Pixel
Lens 1/3”, Fixed 3.7 mm, Mega-Pixel Lens, F1.8
Illumination 0. 5 lux
Lens Changeable Yes, CS Mount
Support DC IRIS Yes
Video Out 1 Analog video out (BNC connector)
Audio In Built-in microphone
Audio Out 1 Line out (RCA connector for connecting external amplified speaker)
Digital I/O 1 Digital in / 1 Relay out
Power Supply Normal: DC 12V, 1A
PoE model (built-in PoE Splitter):

4
Use PoE: PoE Injector (IEEE 802.3af)
Or, use Power Adaptor: DC 12V, 1A
Power Consumption Max. 6 Watt
Dimensions W69 x H60 x D151 mm
Network
Ethernet 10/ 100 Base-T
Network Protocol HTTP, TCP/IP, RTP/RTSP, 3GPP, SMTP, FTP, PPPoE, DHCP, DDNS, NTP, UPnP
System
Video Resolution 1600x1200, 1280x1024, 1280x960, 1280x720
800x592, 640x480, 320x240, 176x144
Compression Format H.264 / MJPEG / MPEG-4 (3GPP only)
Frame Rate Up to 15FPS@1600x1200, 22FPS@1280x1024, 25FPS@1280x960,
30FPS@1280x720
Triple Streaming Yes (2 for live view, 1 for 3GPP)
3GPP Yes, Live view with 3G mobile phone
Video Bitrate Adjustment CBR, VBR
Video Adjustment Brightness, Contrast, Sharpness, BLC, Frame Rate at Night, Video
orientation
Image Snapshot Yes
Privacy Mask Yes, 3 different areas
Motion Detection Yes, 3 different areas
Event Trigger Motion Detection, Digital In
Triggered Action Send Email, Send to FTP, Relay Out
Pre/ Post Alarm Yes, configurable
Security Password protection
Firmware Upgrade HTTP mode, can be upgraded remotely
Connection Up to 10 clients simultaneously
Audio Yes, 2-way
Web browsing requirement
OS Windows 2000, XP, Vista, Windows 7
Web Browser Microsoft IE V7.0 (32-bit) or above, Mozilla Firefox V6.0 or above, Opera
V11.5 or above, Safari V5.1 or above, Google Chrome V13.0 or above
Suggested Hardware Intel Core 2 Duo 1.66GHz, RAM: 1GB
Graphic card: 128MB onboard RAM
* Specifications are subject to change without notice

5
3. Product Installation
A. Hardware Installation
Cable Connections
Network Connector:
The RJ-45 connector allows connect the Ethernet cable.
Power Jack:
To connect the DC 12V power adapter.
Audio Out: The RCA connector allows connect to an amplified speaker,
you can hear the voice of the remote site from the speaker.

Video Out: The BNC connector allows connect to the analog display to
output analog video for locally monitoring.
Digital I/O:
Digital In and Relay Out.
1. Connect the cable of Digital I/O, Video output, andAudio output if you want to use
these functionalities.
2. Connect Ethernet cable for network connection.
3. Connect power adapter to turn on the camera.
4. If the camera is PoE model, the power adapter is not necessary. The camera will get






6
the power from the PoE injector or PoE switch.
PoE (Power over Ethernet) is a technology that integrates power into a standard LAN
infrastructure. It enables power to be provided to the network device, such as an IP
phone or a network camera, using the same cable as that used for network connection.
It eliminates the need for power outlets at the camera locations. Please follow the
below figure for the connection.
5. Set up the network configurations according to the network environment. For further
explanation, please refer to Network Configuration chapter.
I/O Connections
I/O terminal connector – used in application, for e.g., motion detection, event triggering,
alarm notifications. It provides the interface to:
1 set of Digital Input (Alarm In + GND) – The digital inputs for connecting devices
that can toggle between an open and closed circuit, such as PIRs, door/window
contacts, glass break detectors, etc. When a signal is received the status changes
and the input becomes active.
1 sets of Relay Output (N.O. + COM or N.C. + COM) –The output to Relay switch
of the alarm device such as LEDs, Sirens, etc.
Alarm In Relay Out
PoE Switch or PoE Injector
Ethernet Cable
Data only
Ethernet Cable
Mixed data and power
PoE Network Camera
To Network

7
Digital Input (Alarm Input)
GND (Ground): Initial status is LOW.
Alarm: Max. 50mA, 12VDC.
Relay output
COM: Common pin.
N.O. (Normally Open): Max. 1A / 24VDC or 0.5A / 125VAC.
N.C. (Normally Close): Max. 1A/ 24VDC or 0.5A / 125VAC.
Door/Window
Contacts

8
B. Monitor Setting
1. Right-Click on the desktop. Select “Properties”
2. Change color quality to “Highest (32bit)”.

9
C. IP Assignment
Always consult your network administrator before assigning an IP address to your
camera in order to avoid using a previously assigned IP address.
MAC Address: Each network camera has a unique Ethernet address (MAC address)
shown on the sticker of the device.
One final note, although the IP Search is able to find and configure any network
device on the LAN except those that are behind a router, it is a good idea to set the
host PC to the same subnet. In order to connect to the Web-based user interface of
the network camera, the host PC must be in the same subnet. For more information
about subnets, please consult your network administrator.
“Asoni IP Search” is a utility that provides an easier, more efficient way to configure the IP
address and network settings of the network camera in Local Network (LAN).
The software can be installed from the attached software CD.
1. Once “Asoni IP Search” has been successfully installed on the computer, double
click the “Search CAM4_CAM6_NVR6LX” icon on the desktop.





