Aspar RS485 MODBUS User manual

RS485 MODBUS Module 16O
Expansion Module – 16 digital outputs
Version 1. User Manual
Manufactured for

RS485 MODBUS Module 16O
User Manual
Thank you for choosing our product.
This manual will help you with proper support and proper operation of the device.
The information contained in this manual have been prepared with utmost care by our
professionals and serve as a description of the product without incurring any liability for
the purposes of commercial law.
This information does not release you from the obligation of own judgment and
verification.
We reserve the right to change product specifications without notice.
Please read the instructions carefully and follow the recommendations contained
therein.
WAR I G!
Failure to follow instructions can result in equipment damage or impede
the use of the hardware or software.
Expansion Module– 16 digital outputs
User Manual Version 1. / 16

RS485 MODBUS Module 16O
User Manual
1. Safety rules
•Before first use, refer to this manual
•Before first use, make sure that all cables are connected properly
•Please ensure proper working conditions, according to the device specifications
(eg: supply voltage, temperature, maximum power consumption)
•Before making any modifications to wiring connections, turn off the power supply
2. Module Features
2.1. Purpose and description of the module
16O Module is an innovative device that provides a simple and cost-effective
extension of the number of outputs in popular PLCs.
The module has 16 digital outputs. All inputs and outputs are isolated from the
logic of using optocouplers.
The module is produced in two versions with P P and P outputs:
Mark Output type
16O-P P P P
16O- P P
This module is connected to the RS485 bus with twisted-pair wire.
Communication is via MODBUS RTU or MODBUS ASCII. The use of 32-bit ARM
core processor provides fast processing and quick communication. The baud rate is
configurable from 2400 to 115200.
The module is designed for mounting on a DI rail in accordance with
DI E 5002.
The module is equipped with a set of LEDs used to indicate the status of outputs
useful for diagnostic purposes and helping to find errors.
Module configuration is done via USB by using a dedicated computer program.
You can also change the parameters using the MODBUS protocol.
Expansion Module– 16 digital outputs
User Manual Version 1. 3 / 16

RS485 MODBUS Module 16O
User Manual
2.2. Technical Specifications
Power Supply Voltage 10-38VDC; 10-28VAC
Maximum Current 180 mA @ 12V / 100 mA @ 24V
Digital Outputs
No of outputs 16
Max Voltage 30V
Max current 500mA
Output Type PNP or NPN (depends on version)
Temperature Work -10 °C - +50°C
Storage -40 °C - +85°C
Connectors
Power Supply 2 pin
Communication 3 pin
Outputs 10 pin
Quick connector IDC10
Configuration Mini USB
Size
Height 120 mm
Length 101 mm
Width 22,5 mm
Interface RS485 Up to 128 devices
* Maximum current with active Modbus transmission, all outputs on and high state on all inputs
Expansion Module– 16 digital outputs
User Manual Version 1. 4 / 16

RS485 MODBUS Module 16O
User Manual
2.3. Dimensions of the product
Look and dimensions of the module are shown below. The module is mounted
directly to the rail in the DI industry standard. Power connectors, communication and
IOs are at the bottom and top of the module. USB connector configuration and
indicators located on the front of the module.
Expansion Module– 16 digital outputs
User Manual Version 1. 5 / 16

RS485 MODBUS Module 16O
User Manual
3. Communication configuration
3.1. Grounding and shielding
In most cases, IO modules will be installed in an enclosure along with other
devices which generate electromagnetic radiation. Examples of these devices are relays
and contactors, transformers, motor controllers etc. This electromagnetic radiation can
induce electrical noise into both power and signal lines, as well as direct radiation into
the module causing negative effects on the system. Appropriate grounding, shielding
and other protective steps should be taken at the installation stage to prevent these
effects. These protective steps include control cabinet grounding, module grounding,
cable shield grounding, protective elements for electromagnetic switching devices,
correct wiring as well as consideration of cable types and their cross sections.
3.2. Network Termination
Transmission line effects often present a problem on data communication
networks. These problems include reflections and signal attenuation.
To eliminate the presence of reflections from the end of the cable, the cable must
be terminated at both ends with a resistor across the line equal to its characteristic
impedance. Both ends must be terminated since the direction of propagation is bi-
directional. In the case of an RS485 twisted pair cable this termination is typically
120 Ω.
3.3. Setting Module ddress in RS485 Modbus Network
The following table shows how to set switch to determine the address of the
module. The module address is set with the switches in the range of 0 to 31. Addresses
From 32 to 255 can by set via RS485 or USB.
Adr SW5 SW4 SW3 SW2 SW1
0 OFF OFF OFF OFF OFF
1 OFF OFF OFF OFF ON
2 OFF OFF OFF ON OFF
3 OFF OFF OFF ON ON
4 OFF OFF ON OFF OFF
5 OFF OFF ON OFF ON
6 OFF OFF ON ON OFF
7 OFF OFF ON ON ON
8 OFF ON OFF OFF OFF
9 OFF ON OFF OFF ON
10 OFF ON OFF ON OFF
Adr SW5 SW4 SW3 SW2 SW1
11 OFF ON OFF ON ON
12 OFF ON ON OFF OFF
13 OFF ON ON OFF ON
14 OFF ON ON ON OFF
15 OFF ON ON ON ON
16 ON OFF OFF OFF OFF
17 ON OFF OFF OFF ON
18 ON OFF OFF ON OFF
19 ON OFF OFF ON ON
20 ON OFF ON OFF OFF
21 ON OFF ON OFF ON
Adr SW5 SW4 SW3 SW2 SW1
22 ON OFF ON ON OFF
23 ON OFF ON ON ON
24 ON ON OFF OFF OFF
25 ON ON OFF OFF ON
26 ON ON OFF ON OFF
27 ON ON OFF ON ON
28 ON ON ON OFF OFF
29 ON ON ON OFF ON
30 ON ON ON ON OFF
31 ON ON ON ON ON
Expansion Module– 16 digital outputs
User Manual Version 1. 6 / 16

RS485 MODBUS Module 16O
User Manual
3.4. Types of Modbus Registers
There are 4 types of variables available in the module
Type Beginning
address Variable Access Modbus Command
1 00001 Digital Outputs Bit
Read & Write 1, 5, 15
2 10001 Digital Inputs Bit
Read 2
3 30001 Input Registers Registered
Read 3
4 40001 Output Registers Registered
Read & Write 4, 6, 16
3.5. Communication settings
The data stored in the modules memory are in 16-bit registers. Access to
registers is via MODBUS RTU or MODBUS ASCII.
3.5.1. Default settings
You can restore the default configuration by the switch SW6 (see 3.5.2 - Restore
the default configuration)
Baud rate 19200
Parity No
Data bits 8
Stop bits 1
Reply Delay [ms] 0
Modbus Type RTU
3.5.2. Restore t e default configuration
To restore the default configuration:
•turn off the power
•turn on the switch SW6
•turn on the power
•when power and communication LED flash turn off the switch SW6
Caution! After restoring the default configuration all values stored in the registers will
be cleared as well.
Expansion Module– 16 digital outputs
User Manual Version 1. 7 / 16

RS485 MODBUS Module 16O
User Manual
3.5.3. Configuration registers
Modbus Dec Hex Name Values
Address
40003 2 0x02 Baud rate
0 – 2400
1 – 4800
2 – 9600
3 – 19200
4 – 38400
5 – 57600
6 – 115200
other – value 10
40005 4 0x04 Parity
0 – none
1 – odd
2 – even
3 – always 1
4 – always 0
40004 3 0x03 Stop Bits LSB 1 – one stop bit
2 – two stop bits
40004 3 0x03 Data Bits MSB 7 – 7 data bits
8 – 8 data bits
40006 5 0x05 Response delay Time in ms
40007 6 0x06 Modbus Mode 0 – RTU
1 – ASCII
Expansion Module– 16 digital outputs
User Manual Version 1. 8 / 16

RS485 MODBUS Module 16O
User Manual
4. Indicators
Indicator Description
Power supply LED indicates that the module is correctly powered.
Communication The LED lights up when the unit received the correct packet and sends the answer.
Outputs state LED indicates that the output is on.
Expansion Module– 16 digital outputs
User Manual Version 1. 9 / 16
Outputs State 1 – 8
Outputs state 9 – 16
Power Supply
1 3 4 5 6
ON
Communication

RS485 MODBUS Module 16O
User Manual
5. Module Connection – PNP outputs
Expansion Module– 16 digital outputs
User Manual Version 1. 10 / 16

RS485 MODBUS Module 16O
User Manual
6. Module Connection – NPN outputs
Expansion Module– 16 digital outputs
User Manual Version 1. 11 / 16

RS485 MODBUS Module 16O
User Manual
7. Switc es
Switch Function Description
1 Module address +1
Setting module address from 0 to 31
2 Module address +2
3 Module address +4
4 Module address +8
5 Module address +16
6 Restoring default settings
Restoring default settings
(see 3.5.1 - Default settings and 3.5.2 - Restore the
default configuration).
Expansion Module– 16 digital outputs
User Manual Version 1. 1 / 16

RS485 MODBUS Module 16O
User Manual
8. Modules Registers
8.1. Registered access
Modbus Dec Hex Register Name Access Description
30001 0 0x00 Version/Type Read Version and Type of the device
30002 1 0x01 Switches Read Switches state
40003 2 0x02 Baud rate Read & Write RS485 baud rate
40004 3 0x03 Stop Bits & Data Bits Read & Write No of Stop bits & Data Bits (see 3.5.3)
40005 4 0x04 Parity Read & Write Parity bit
40006 5 0x05 Response Delay Read & Write Response delay in ms
40007 6 0x06 Modbus Mode Read & Write Modbus Mode (ASCII or RTU)
40009 8 0x08 Watchdog Read & Write Watchdog
40013 12 0x0C Default Output State Read & Write Default output state (after power on or
watchdog reset)
40033 32 0x20 Received packets LSB Read & Write No of received packets
40034 33 0x21 Received packets MSB Read & Write
40035 34 0x22 Incorrect packets LSB Read & Write No of received packets with error
40036 35 0x23 Incorrect packets MSB Read & Write
40037 36 0x24 Sent packets LSB Read & Write No of sent packets
40038 37 0x25 Sent packets MSB Read & Write
40052 51 0x33 Outputs Read & Write Output state
Expansion Module– 16 digital outputs
User Manual Version 1. 13 / 16

RS485 MODBUS Module 16O
User Manual
8.2. Bit access
Modbus
Address
Dec
Address
Hex
Address Register name Access Description
193 192 0x0C0 Default state of output 1 Read & Write Default state of output 1
194 193 0x0C1 Default state of output 2 Read & Write Default state of output 2
195 194 0x0C2 Default state of output 3 Read & Write Default state of output 3
196 195 0x0C3 Default state of output 4 Read & Write Default state of output 4
197 196 0x0C4 Default state of output 5 Read & Write Default state of output 5
198 197 0x0C5 Default state of output 6 Read & Write Default state of output 6
199 198 0x0C6 Default state of output 7 Read & Write Default state of output 7
200 199 0x0C7 Default state of output 8 Read & Write Default state of output 8
201 200 0x0C8 Default state of output 9 Read & Write Default state of output 9
202 201 0x0C9 Default state of output 10 Read & Write Default state of output 10
203 202 0x0CA Default state of output 11 Read & Write Default state of output 11
204 203 0x0CB Default state of output 12 Read & Write Default state of output 12
205 204 0x0CC Default state of output 13 Read & Write Default state of output 13
206 205 0x0CD Default state of output 14 Read & Write Default state of output 14
207 206 0x0CE Default state of output 15 Read & Write Default state of output 15
208 207 0x0CF Default state of output 16 Read & Write Default state of output 16
817 816 0x330 Output 1 Read & Write Output 1 state
818 817 0x331 Output 2 Read & Write Output 2 state
819 818 0x332 Output 3 Read & Write Output 3 state
820 819 0x333 Output 4 Read & Write Output 4 state
821 820 0x334 Output 5 Read & Write Output 5 state
822 821 0x335 Output 6 Read & Write Output 6 state
823 822 0x336 Output 7 Read & Write Output 7 state
824 823 0x337 Output 8 Read & Write Output 8 state
825 824 0x338 Output 9 Read & Write Output 9 state
826 825 0x339 Output 10 Read & Write Output 10 state
827 826 0x33A Output 11 Read & Write Output 11 state
828 827 0x33B Output 12 Read & Write Output 12 state
829 828 0x33C Output 13 Read & Write Output 13 state
830 829 0x33D Output 14 Read & Write Output 14 state
831 830 0x33E Output 15 Read & Write Output 15 state
832 831 0x33F Output 16 Read & Write Output 16 state
Expansion Module– 16 digital outputs
User Manual Version 1. 14 / 16

RS485 MODBUS Module 16O
User Manual
9. Configuration software
Modbus Configurator is software that is designed to set the module registers
responsible for communication over Modbus network as well as to read and write the
current value of other registers of the module. This program can be a convenient way to
test the system as well as to observe real-time changes in the registers.
Communication with the module is done via the USB cable. The module does
not require any drivers.
Configurator is a universal program, whereby it is possible to configure all available
modules.
Expansion Module– 16 digital outputs
User Manual Version 1. 15 / 16

RS485 MODBUS Module 16O
User Manual
Table of content
1. Safety rules.......................................................................................................................................3
2. Module Features...............................................................................................................................3
2.1. Purpose and description of the module.....................................................................................3
2.2. Technical Specifications...........................................................................................................4
2.3. Dimensions of the product........................................................................................................5
3. Communication configuration..........................................................................................................6
3.1. Grounding and shielding...........................................................................................................6
3.2. etwork Termination................................................................................................................6
3.3. Setting Module Address in RS485 Modbus etwork...............................................................6
3.4. Types of Modbus Registers.......................................................................................................7
3.5. Communication settings...........................................................................................................7
3.5.1. Default settings.................................................................................................................7
3.5.2. Restore the default configuration......................................................................................7
3.5.3. Configuration registers......................................................................................................8
4. Indicators..........................................................................................................................................9
5. Module Connection – P P outputs................................................................................................10
6. Module Connection – P outputs................................................................................................11
7. Switches..........................................................................................................................................12
8. Modules Registers..........................................................................................................................13
8.1. Registered access....................................................................................................................13
8.2. Bit access................................................................................................................................14
9. Configuration software...................................................................................................................15
Manufactured for:
Aspar s.c.
ul. Oliwska 11
80- 09 Chwaszczyno
Poland
[email protected]
www.ampero.eu
Tel. [phone]
Expansion Module– 16 digital outputs
User Manual Version 1. 16 / 16
