aspenhome I287-412 User manual

Page1/4
ITEMNO:I287-412Queen Panel HB
I287-402 QueenRails
I287-403 Queen LowProfileFB
Thankyouforpurchasingthisqualityproduct.Besuretocheckallpacking material carefullyfor
small partsthatmaycomelooseinsidethe cartonduringshipment.
UNIT SHOULDBE INSTALLEDBY2ORMORE PERSONS.
All Bedsneedtobeset upinthe exact final
locationsothatafterfull assemblyit will not
needtobemoved. Moving thebedwill cause
thesupportlegstomoveoutofperpendicular
(90degree),weakenthesupportsystem, and
may allowthebedtocollapse.
aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
BEFORE USING THISPRODUCT PLEASEREAD, UNDERSTAND, AND FOLLOWTHESEINSTRUCTIONS.
Save these instructionsforfuture reference.
FORINDOORUSEONLY
TOOLSREQUIRED (NOTPROVIDED)
PHILLIPSSCREWDRIVER
I287-403
I287-402
I287-412
HARDWARELIST:I287-412
1PC
No.
A
B
C
D
E
Description Sketch Quantity
Bolt 5/16" x1-3/4"
Lock Washer5/16"
FlatWasher5/16" x3/4"
HARDWARELIST:I287-402
8PCS
No.
F
G
H
I
J
Description Sketch Quantity
HangerBolt 5/16" x3-1/2"
HexNut5/16"
HexWrench 12mm
8PCS
1PC
8PCS
Wood Screw #8x1-1/4" 8PCS
Lock Washer5/16" 8PCS
COMPONENTSLIST: I287-412
1PC
No.
1
2
3
4
5
Description Sketch Quantity
Headboard
LeftLeg
RightLeg
WoodStretcher
CenterSupportLeg 1PC
1PC
1PC
1PC
COMPONENTSLIST: I287-402
No.
1
2
Description Sketch Quantity
Bedrail
Slat 4PCS
2PCS
COMPONENTSLIST: I287-403
No.
1
2
Description Sketch Quantity
Footboard
SupportLeg(forslat) 4PCS
1PC
HalfMoon Washer 5/16"
Allen Wrench 5mm
12 PCS
08-05-2020
12 PCS
12 PCS

aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
Page2/4
STEP3:Attachthecentersupport leg toheadboardandwoodstretcherbyusing2bolts(A), lock
washers(B) and flat washers(C).
CenterSupportLeg
LeftLeg
RightLeg
A
B
C
D
STEP1: Laytheheadboardfacedownon asoft
surface. Attach theleftlegandright leg to
headboardbyusing8bolts(A),lockwashers(B)
andflatwashers(C).
STEP2: Attachthewoodstretchertoleftlegandrightlegbyusing2bolts(A), lock washers(B)
andflatwashers(C).
A
C
D
B
ITEMNO:I287-412Queen Panel HB
I287-402 QueenRails
I287-403 Queen LowProfileFB
A
B
C
D
08-05-2020

aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
Page3/4
STEP6: Attachthesupportlegswithlevelerstothe slats.
Adjustthelevelersonbottomofsupportlegswhen
necessary. SupportLeg
Leveler
ThisEndUp
Slat
STEP5:Screwthebolts(E)intoHB&FB.Makesuretheslatbearerisinthe position (a).
Alignthe boltswiththe holesintheendofsiderailsandattach theside railstoHB&FBusing
halfmoonwasher(F),lockwashers(G)andnuts(H).Thenuseahexwrenchtotighten all the nuts.
b
a
Makesuretheslatbeareris
inthe position (a).
STEP4:Theslatbearershavebeenattachedinposition (b) approximately 2"fromthetop of the side
railsforusewithastoragefootboard.Theslatbearersmustbemovedintoposition (a)based on
thisbedconfiguration.Removetheboltsandscrewsfromtheslatbearers and side railsasshown
below.Thenre-attachtheslatbearerstothesiderailsinposition(a)withbolts, lock washers, flat
washers,andscrews. Caution:Donotovertightenboltsasthismayloosenthethreaded
insertsinthesiderails.
Headboard
Slatbearer
Side Rail
E
FGH
I
Position a
Position b
ITEMNO:I287-412Queen Panel HB
I287-402 QueenRails
I287-403 Queen LowProfileFB
Side Rail
08-05-2020

STEP7: Arrangetheslatsontheslatbearers equallyand
attachtotheslatbearerswithwoodscrews (J).
aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
FUNCTIONALITYINSTRUCTION
Page4/4
I287-403
I287-412
SinglePowered USB
PortforCharging on
bothsides
ITEMNO:I287-412Queen Panel HB
I287-402 QueenRails
I287-403 Queen LowProfileFB
J
08-05-2020

Page1/5
Thankyouforpurchasingthisqualityproduct.Besuretocheckallpacking material carefullyfor
small partsthatmaycomelooseinsidethe cartonduringshipment.
UNIT SHOULDBE INSTALLEDBY2ORMORE PERSONS.
All Bedsneedtobeset upinthe exact final
locationsothatafterfull assemblyit will not
needtobemoved. Moving thebedwill cause
thesupportlegstomoveoutofperpendicular
(90degree),weakenthesupportsystem, and
may allowthebedtocollapse.
aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
BEFORE USING THISPRODUCT PLEASEREAD, UNDERSTAND, AND FOLLOWTHESEINSTRUCTIONS.
Save these instructionsforfuture reference.
FORINDOORUSEONLY
TOOLSREQUIRED (NOTPROVIDED)
PHILLIPSSCREWDRIVER
HARDWARELIST:I287-412
1PC
No.
A
B
C
D
E
Description Sketch Quantity
Lock Washer5/16"
COMPONENTSLIST:I287-412
1PC
No.
1
2
3
4
5
Description Sketch Quantity
Headboard
LeftLeg
RightLeg
WoodStretcher
CenterSupportLeg 1PC
1PC
1PC
1PC
COMPONENTSLIST:I287-402
No.
1
2
Description Sketch Quantity
Bedrail
Slat 4PCS
2PCS
HARDWARELIST:I287-402
8PCS
No.
F
G
H
I
J
Description Sketch Quantity
8PCS
1PC
8PCS
K
8PCS
8PCS
HARDWARE LIST:I287-403D
No.
L
M
N
O
Description Sketch Quantity
Lock Washer1/4"
Allen Wrench 4mm 1PC
FlatWasher1/4" x3/4"
COMPONENTSLIST:I287-403D
1PC
No.
1
2
3
4
Description Sketch Quantity
Footboard
SupportLeg(forcenterrail)
Decking
Centerrail
1PC
2PCS
4PCS
HangerBolt 5/16" x3-1/2"
HalfMoon Washer5/16"
HexNut5/16"x1/2"
HexWrench 12mm
Wood Screw #8x1-1/4"
Lock Washer5/16"
Bolt 5/16" x1-3/4"
Wood Screw #8x1-1/4"
Bolt 1/4"x1-1/4"
Allen Wrench 5mm
8PCS
12 PCS
8PCS
ITEMNO:I287-412Queen Panel HB
I287-402 QueenRails
I287-403DQueen Storage FB
I287-403D
I287-402
I287-412
12 PCS
12 PCS
12 PCS
5
6
SupportLeg(forfootboard)
MetalBase 1PC
Bolt 1/4" x1" 4PCS
P
12 PCS
FlatWasher5/16" x3/4"
2PCS
08-05-2020

aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
Page2/5
ITEMNO:I287-412Queen Panel HB
I287-402 QueenRails
I287-403DQueen Storage FB
STEP3:Attachthecentersupportlegtoheadboardandwoodstretcherby using 2bolts(A),
lockwashers(B)andflatwashers(C).
CenterSupportLeg
LeftLeg
RightLeg
A
B
C
D
STEP1: Laytheheadboardfacedownon asoft
surface. Attach theleftlegandright leg to
headboardbyusing8bolts(A),lockwashers(B)
andflatwashers(C).
STEP2: Attachthewoodstretchertoleftlegandrightlegbyusing2bolts(A), lock washers(B)
andflatwashers(C).
A
C
D
B
A
B
C
D
08-05-2020

aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
Page3/5
STEP5:Screwthebolts(E)intoHB&FB.Makesuretheslatbearerisinthe position (b).
Alignthe boltswiththe holesintheendofsiderailsandattach theside railstoHB&FBusing
halfmoonwashers(F),lockwashers(G)andnuts(H).Thenuseahexwrenchtotighten all the nuts.
Side Rail
Headboard
ESlatbearer
Side Rail
Makesuretheslatbeareris
inthe position (b).
FGHI
Position b
Position a
ITEMNO:I287-412Queen Panel HB
I287-402 QueenRails
I287-403DQueen Storage FB
STEP4:Putthefootboardupsidedownon apadded,cleansurface.Attach thesupportlegs(for
footboard)andthemetal basetofootboardbyusing4bolts(L),lockwashers(M)and flat
washers(N).
Metal Base
Footboard
M
N
OL
Metal Base
SupportLeg(forfootboard)
08-05-2020

aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
Page4/5
STEP6:Attachcenterrailtothefootboardandcentersupportlegofheadboardusing 4bolts(K),
lockwashers(M)andflatwashers(N).
STEP7:Attach2supportlegs(forcenterrail)tothe
centerrailusing4bolts(K),lockwashers(M)and
flatwashers(N).UsetheAllenWrench(O)totighten
all ofthebolts.
KN
Centerrail
Centerrail
Leveler
CenterRail
SupportLeg
(forcenterrail)
O
N
KM
O
M
ITEMNO:I287-412Queen Panel HB
I287-402 QueenRails
I287-403DQueen Storage FB
STEP8:Arrangeslatsontheslatbearers and then
lay deckingontop oftheslats. Makesuretheslats
arepositionedalongtheseamsofthe decking as
showninthe detailinSTEP9underthe
pre-drilledhole. Remove thedecking andattach
slatstotheslatbearerswithwoodscrews (J).
WoodScrews(J)
08-05-2020

aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
Page5/5
STEP9: Putthedeckingsovertheslats,securedeckingstotheslatswithwood screws (P)
throughthepre-drilledholesinthe deckingsasshownbelow.
Slat
Decking
Decking
Theslatshouldsupport
bothpiecesofdecking.
P
Decking
Pre-drilledhole
Makesurethatthereisaslat
underthepre-drilled hole.
Cedar-linedStorageDrawers
I287-412
I287-402
I287-403D
FUNCTIONALITYINSTRUCTION
SinglePowered USB
PortforCharging on
bothsides
ITEMNO:I287-412Queen Panel HB
I287-402 QueenRails
I287-403DQueen Storage FB
08-05-2020

Page1/4
ITEMNO: I287-415KingPanelHB
I287-406 King Rails
I287-410 Cal King Rails
I287-407 KingLowProfileFB
Thankyouforpurchasingthisqualityproduct.Besuretocheckallpacking material carefullyfor
small partsthatmaycomelooseinsidethe cartonduringshipment.
UNIT SHOULDBE INSTALLEDBY2ORMORE PERSONS.
All Bedsneedtobeset upinthe exact final
locationsothatafterfull assemblyit will not
needtobemoved. Moving thebedwill cause
thesupportlegstomoveoutofperpendicular
(90degree),weakenthesupportsystem, and
may allowthebedtocollapse.
aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
BEFORE USING THISPRODUCT PLEASEREAD, UNDERSTAND, AND FOLLOWTHESEINSTRUCTIONS.
Save these instructionsforfuture reference.
FORINDOORUSEONLY
TOOLSREQUIRED (NOTPROVIDED)
PHILLIPSSCREWDRIVER
I287-407
I287-406
I287-415
I287-410
HARDWARELIST:I287-406/410
8PCS
No.
F
G
H
I
J
Description Sketch Quantity
HexWrench 12mm
8PCS
1PC
8PCS
K10 PCS
Lock Washer5/16" 8PCS
COMPONENTSLIST: I287-415
1PC
No.
1
2
3
4
5
Description Sketch Quantity
Headboard
LeftLeg
RightLeg
WoodStretcher
CenterSupportLeg 1PC
1PC
1PC
1PC
COMPONENTSLIST: I287-406
No.
1
2
Description Sketch Quantity
Bedrail
Slat 5PCS
2PCS
COMPONENTSLIST: I287-407
No.
1
2
Description Sketch Quantity
SupportLeg(forslat) 5PCS
COMPONENTSLIST: I287-410
No.
1
2
Description Sketch Quantity
Bedrail
Slat 5PCS
2PCS
3Centerrail(Long) 1PC
HARDWARELIST:I287-415
1PC
No.
A
B
C
D
E
Description Sketch Quantity
Lock Washer5/16"
8PCS
Wood Cap(onlyfor410)
HangerBolt 5/16" x3-1/2"
HexNut5/16"
Wood Screw #8x1-1/4"
Bolt 5/16" x1-3/4"
HalfMoon Washer 5/16"
Allen Wrench 5mm
Footboard 1PC
12 PCS
12 PCS
12 PCSFlatWasher5/16" x3/4"
08-05-2020

LeftLeg
RightLeg
A
B
C
D
A
B
C
D
aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
Page2/4
STEP3: Attachthecentersupportlegtoheadboardandwoodstretcherby using 2bolts(A),
lockwashers(B)andflatwashers(C).
CenterSupportLeg
STEP1: Laytheheadboardfacedownon asoft
surface. Attach theleftlegandright leg to
headboardbyusing8bolts(A),lockwashers(B)
andflatwashers(C).
STEP2: Attachthewoodstretchertoleftlegandrightlegbyusing2bolts(A), lock washers(B)
andflatwashers(C).
A
C
D
B
ITEMNO: I287-415KingPanelHB
I287-406 King Rails
I287-410 Cal King Rails
I287-407 KingLowProfileFB
08-05-2020

aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
Page3/4
STEP5:Screwthebolts(E)intoHB&FB.Makesuretheslatbearerisinthe position (a).
Alignthe boltswiththe holesintheendofsiderailsandattach theside railstoHB&FBusing
halfmoonwasher(F),lockwashers(G)andnuts(H).Thenuseahexwrenchtotighten all the nuts.
Makesuretheslatbeareris
inthe position (a).
Side Rail
The outsideholesmatchto6/6standardkingrails,
the insideholesmatchto6/0Calkingbed rails.
STEP6: Attachthesupportlegswithlevelerstothe slats.
Adjustthelevelersonbottomofsupportlegswhen
necessary. SupportLeg
ThisEndUp
Slat
Leveler
b
a
STEP4:Theslatbearershavebeenattachedinposition (b) approximately 2"fromthetop of the side
railsforusewithastoragefootboard.Theslatbearersmustbemovedintoposition (a)based on
thisbedconfiguration.Removetheboltsandscrewsfromtheslatbearers and side railsasshown
below.Thenre-attachtheslatbearerstothesiderailsinposition(a)withbolts, lock washers, flat
washers,andscrews. Caution:Donotovertightenboltsasthismayloosenthethreaded
insertsinthesiderails.
Headboard
Slatbearer
Side Rail
E
FGH
I
Position a
Position b
ITEMNO: I287-415KingPanelHB
I287-406 King Rails
I287-410 Cal King Rails
I287-407 KingLowProfileFB
08-05-2020

FUNCTIONALITYINSTRUCTION
aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
Page4/4
STEP7:Arrangetheslatsontheslatbearers equallyand
attachtotheslatbearerswithwoodscrews (J).
STEP8: ForCal Kingbed,insertwood capsintotheholeson
headboardandfootboard.ForregularKingbed, skipthisstep. WoodCap(K)
I248-407
I248-406
I248-415
I248-410
Single Powered USB
PortforChargingon
bothsides
I248-407
I248-415
ITEMNO: I287-415KingPanelHB
I287-406 King Rails
I287-410 Cal King Rails
I287-407 KingLowProfileFB
J
08-05-2020

Page1/6
Thankyouforpurchasingthisqualityproduct.Besuretocheckallpacking material carefullyfor
small partsthatmaycomelooseinsidethe cartonduringshipment.
UNIT SHOULDBE INSTALLEDBY2ORMORE PERSONS.
All Bedsneedtobeset upinthe exact final
locationsothatafterfull assemblyit will not
needtobemoved. Moving thebedwill cause
thesupportlegstomoveoutofperpendicular
(90degree),weakenthesupportsystem, and
may allowthebedtocollapse.
aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
BEFORE USING THISPRODUCT PLEASEREAD, UNDERSTAND, AND FOLLOWTHESEINSTRUCTIONS.
Save these instructionsforfuture reference.
FORINDOORUSEONLY
TOOLSREQUIRED (NOTPROVIDED)
PHILLIPSSCREWDRIVER
I287-407D
I287-406
I287-415
I287-410 COMPONENTSLIST: I287-415
1PC
No.
1
2
3
4
5
Description Sketch Quantity
Headboard
LeftLeg
RightLeg
WoodStretcher
CenterSupportLeg 1PC
1PC
1PC
1PC
COMPONENTSLIST: I287-406
No.
1
2
Description Sketch Quantity
Bedrail
Slat 5PCS
2PCS
COMPONENTSLIST: I287-410
No.
1
2
Description Sketch Quantity
Bedrail
Slat 5PCS
2PCS
3Centerrail(Long) 1PC
COMPONENTSLIST: I287-407D
1PC
No.
1
2
3
4
5
Description Sketch Quantity
Footboard
SupportLeg(forcenterrail)
Decking
Centerrail(Short)
1PC
2PCS
3PCS
Filler 2PCS
HARDWARELIST:I287-406/410
8PCS
No.
F
G
H
I
J
Description Sketch Quantity
HexWrench 12mm
8PCS
1PC
8PCS
K10 PCS
Lock Washer5/16" 8PCS
HARDWARELIST:I287-415
1PC
No.
A
B
C
D
E
Description Sketch Quantity
Lock Washer5/16"
8PCS
Wood Cap(onlyfor410)
HangerBolt 5/16" x3-1/2"
HexNut5/16"
Wood Screw #8x1-1/4"
Bolt 5/16" x1-3/4"
HalfMoon Washer 5/16"
Allen Wrench 5mm
12 PCS
HARDWARE LIST:I287-407D
No.
L
M
N
O
Description Sketch Quantity
Lock Washer1/4"
Allen Wrench 4mm 1PC
FlatWasher1/4" X 3/4"
Wood Screw #8x1-1/4"
Bolt 1/4"x1-1/4" 8PCS
6PCS
P
ITEMNO: I287-415KingPanelHB
I287-406 King Rails
I287-410 Cal King Rails
I287-407DKing Storage FB
12 PCS
12 PCS
Bolt 1/4" x1" 6PCS
14 PCS
14 PCS
Q6
7
SupportLeg(forfootboard)
MetalBase 1PC
FlatWasher5/16" x3/4"
2PCS
08-05-2020

aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
Page2/6
LeftLeg
RightLeg
A
B
C
D
A
B
C
D
STEP3: Attachthecentersupportlegtoheadboardandwoodstretcherby using 2bolts(A),
lockwashers(B)andflatwashers(C).
CenterSupportLeg
STEP1: Laytheheadboardfacedownon asoft
surface. Attach theleftlegandright leg to
headboardbyusing8bolts(A),lockwashers(B)
andflatwashers(C).
STEP2: Attachthewoodstretchertoleftlegandrightlegbyusing2bolts(A), lock washers(B)
andflatwashers(C).
A
C
D
B
ITEMNO: I287-415KingPanelHB
I287-406 King Rails
I287-410 Cal King Rails
I287-407DKing Storage FB
08-05-2020

aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
Page3/6
STEP5:Screwthebolts(E)intoHB&FB.Makesuretheslatbearerisinthe position (b).
Alignthe boltswiththe holesintheendofsiderailsandattach theside railstoHB&FBusing
halfmoonwashers(F),lockwashersG)andnuts(H).Thenuseahexwrenchtotighten all the nuts.
Side Rail
The outsideholesmatchto6/6standardkingrails,
the insideholesmatchto6/0Calkingbed rails.
Headboard
Slatbearer
Side Rail
E
Makesuretheslatbeareris
inthe position (b).
FGHI
Position b
Position a
ITEMNO: I287-415KingPanelHB
I287-406 King Rails
I287-410 Cal King Rails
I287-407DKing Storage FB
STEP4:Putthefootboardupsidedownon apadded,cleansurface.Attach thesupportlegs(for
footboard)andthemetal basetofootboardbyusing6bolts(M),lockwashers(N) and flat
washers(O).
Metal Base
Metal Base
Footboard SupportLeg(forfootboard)
M
N
O
P
08-05-2020

WoodScrews(J)
aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
Page4/6
STEP7:Attach2supportlegs(forcenterrail)tothe
centerrailusing4bolts(L),lockwashers(N) and flat
washers(O).UsetheAllenWrench(P)totighten all
ofthebolts.
Leveler
CenterRail
SupportLeg
(forcenterrail)
O
PN
Centerrail
L
L
STEP6:Thestandardkingcenterrail(short)isintheStorageFootboardcarton, and the Cal king
centerrail (long)isintheCal Kingside rail carton.Attachthe appropriatecenterrail tothe
footboardandcentersupportlegofheadboardusing4bolts(L),lockwashers(N) and flat
washers(O).
ITEMNO: I287-415KingPanelHB
I287-406 King Rails
I287-410 Cal King Rails
I287-407DKing Storage FB
Centerrail
STEP8: Arrangeslatsontheslatbearers and then
lay thedecking on topoftheslats.Makesurethe
top andbottomslatsaresituated underneaththe
pre-drilledholesasshownbelowinSTEP 10.
Remove thedecking andattachslatstothe slat
bearerswithwoodscrews(J).
O
N
P
08-05-2020

aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
Page5/6
Filler Notch
STEP9:FortheCalKingbed,bothfilerboardsarenotched. Usingautilityknifeonlycut off
the small piece atthenotchononeofthe fillerboards.Thiscutofffillerboardwillbeplaced at
the foot ofthe bedgoingfromleft toright asshownonthe rightsidebelowinSTEP10. Forthe
standardKingbed,skipthisstepandarrangethedecking boardsasshownbelow.
STEP10:Putthedeckingsandfillersovertheslats,securedeckingstothe slatswithwood screws
(Q)throughthepre-drilledholesinthedeckingsasshownbelow.
STEP11:ForCal Kingbed,insertwood capsintotheholeson
headboardandfootboard.ForregularKingbed, skipthisstep.
WoodCap(K)
Makesurethatthereisaslat
underthepre-drilled hole.
Q
Decking
Pre-drilledhole
CalKingBed
StandardKing Bed
Decking
Decking
Decking
Decking
Decking
Decking
ITEMNO: I287-415KingPanelHB
I287-406 King Rails
I287-410 Cal King Rails
I287-407DKing Storage FB
08-05-2020

aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
Page6/6
FUNCTIONALITYINSTRUCTION
Cedar-linedStorageDrawers
I287-407D
I287-415
I287-406
SinglePowered USB
PortforCharging on
bothsides
ITEMNO: I287-415KingPanelHB
I287-406 King Rails
I287-410 Cal King Rails
I287-407DKing Storage FB
Cedar-linedStorageDrawers
I287-407D
I287-415
I287-410
SinglePowered USB
PortforCharging on
bothsides
08-05-2020
