aspenhome I256-360T User manual

Page1/2
Thankyouforpurchasingthisqualityproduct.Besuretocheckallpacking material carefullyfor
small partsthatmaycomelooseinsidethe cartonduringshipment.
BEFORE USING THISPRODUCT PLEASEREAD, UNDERSTAND, AND FOLLOWTHESEINSTRUCTIONS.
Save these instructionsforfuture reference. FORINDOORUSEONLY
aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
TOOLSREQUIRED (NOTPROVIDED)
PHILLIPSSCREWDRIVER
LiftMechanism
Assemblyinstructions forthe Lift
Mechanism areinthe Lift
Mechanism package. Follow the
below instructionswhen attaching
desktop tothe LiftMechanism.
HARDWARELIST:
1PC
No.
B
C
D
E
Description Sketch Quantity
Bolt 5/16" x3/4"
Lock Washer5/16"
Flat Washer 5/16"x 7/8"
Allen Wrench 4mm
8PCS
PlasticWireClip
Wood Screw #7 x5/8"
F6PCS
10 PCS
COMPONENTSLIST:
1Set
No.
1Description Sketch Quantity
DeskTop
8PCS
8PCS
ITEMNO:I256-360TLift DeskTop
FUNCTIONALITYINSTRUCTION
LeveleronBase
Adjusttheleveler
whennecessary
Flipdownkeyboardtray
2ACoutlet/2USB
powerpack
Liftmechanism
(IUAB-301-1)
A
LiftMechanism Handset
LiftMechanism PowerBox
04-18-2022
Press here torelease
Hook latch
Metalplate

DeskBack
Screw
F
E
Wire
C
B
A
D
F
DeskBack
ACoutlet
STEP1:Putthe desktop face downon a softsurface.
STEP2:Place LiftMechanism IUAB-301-1on desktop and adjusttoalign withthreaded inserts. Follow Step 3 from
the IUAB-301-1assemblyinstructionsforadjusting widthofLiftMechanism.
STEP3:Secure LiftMechanism IUAB-301-1todesktop by using 8bolts(A), 4wood screws (F), 8lock washers(B)
and 8 flatwashers(C). Then use an allen wrench totighten all the bolts.
Page2/2
aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
Threadedinsert
Note:RefertoLiftMechanism assemblyinstructions forHandsetoperation.
STEP4:Tighten boltsthatwere loosened inStep 3 fromthe IUAB-301-1assemblyinstructions.
STEP5:Attach LiftMechanism PowerBox and Handset (“5”and “6”on the componentlistforliftdesk
mechanism)tothe desired positionswithscrews(“A”on the hardware bag forliftdeskmechanism).
STEP6:Follow Step 5 from the IUAB-301-1assemblyinstructins.
STEP7:Clipthe wire intothe plastic wire clip, Attach the plastic wire clips(E) tothe rightposition withscrews(F).
STEP8:Turnthe assembled desktothe uprightposition.
STEP9:Connectthe appropriate wiresleading from the motorand Handsettothe LiftMechanism PowerBox.
STEP10:Plug inthe PowerBox toanACoutlet.
STEP11:If disassemblyisrequired, lowerthe LiftMechanism tothe lowestpoint.
LiftMechanism
Handset
LiftMechanism
PowerBox
LiftMechanism
Handset
LiftMechanism
PowerBox
03-25-2022
ITEMNO:I256-360TLift DeskTop
STEP12:Reverse each knob by removing the screwswhile each draweris open and attach
all knobstothe frontofthe drawerswithscrews as shownbelow.
Knob
Screw
Knob
