aspenhome I3048-444P User manual

Page1/5
ITEMNO: I3048-444P Q/K Bed Tall Posts
I3048-445P Q/K Bed ShortPosts
I3048-402 Queen Rails
I3048-442 Queen HB& FBPanels
Thankyouforpurchasingthisqualityproduct.Besuretocheckallpacking material carefullyfor
small partsthatmaycomelooseinsidethe cartonduringshipment.
UNIT SHOULDBE INSTALLEDBY2ORMORE PERSONS.
All Bedsneedtobeset upinthe exact final
locationsothatafterfull assemblyit will not
needtobemoved. Moving thebedwill cause
thesupportlegstomoveoutofperpendicular
(90degree),weakenthesupportsystem, and
may allowthebedtocollapse.
aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
FORINDOORUSEONLY
TOOLSREQUIRED (NOTPROVIDED)
PHILLIPSSCREWDRIVER
I3048-402
I3048-444P
I3048-442
I3048-442
I3048-402
I3048-442
I3048-442
I3048-445P
WARNING! Before using thisproduct, please read, understand, and follow these instructions. Failure tofollow
eachofthese assemblyinstructionspreciselymayresult indamage tothe productand /orinjurytothe consumer.
01-02-2024

aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
Page2/5
COMPONENTSLIST: I3048-442
No.
1Description Sketch Quantity
Headboard(HB)
COMPONENTSLIST: I3048-402
No.
1
2
Description Sketch Quantity
Bedrail
Slat 6PCS
2PCS
I
HARDWARELIST:I430-402
No. Description Sketch Quantity
8PCS
HexWrench 13mm
8PCS
1PC
12 PCS
8PCS
HangerBolt 5/16" x3"
HexNut 5/16"
Wood Screw #4x1-1/4"
HalfMoon Washer 5/16"
J
K
L
M
No. Description Sketch Quantity
ABolt 5/16"x1-1/2" 14 PCS
BLock Washer 5/16"
CFlatWasher 5/16" x5/8"
DAllen Wrench M4 1PC
HARDWARE LIST:I3048-442
2
3Footboard(FB) 1PC
6PCS
SupportLeg
4
1PC
1PC
WoodStretcher
COMPONENTSLIST: I3048-444P
No.
1Description Sketch Quantity
2
3
1PC
4
1PC
1PC
1PC
COMPONENTSLIST: I3048-445P
No.
1Description Sketch Quantity
2
3
1PC
4
1PC
1PC
1PC
HexWrench 13mm
HangerBolt 5/16" x3"
HexNut 5/16"
HalfMoon Washer 5/16"
6PCS
1PC
6PCS
6PCS
E
F
G
H
ITEMNO: I3048-444P Q/K Bed Tall Posts
I3048-445P Q/K Bed ShortPosts
I3048-402 Queen Rails
I3048-442 Queen HB& FBPanels
14 PCS
14 PCS
HBPost-Left
HBPost-Right
FBPost-Left
FBPost-Right
HBPost-Left
HBPost-Right
FBPost-Left
FBPost-Right
01-02-2024

aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
Page3/5
ABC
D
A
B
C
D
E
F
G
H
ITEMNO: I3048-444P Q/K Bed Tall Posts
I3048-445P Q/K Bed ShortPosts
I3048-402 Queen Rails
I3048-442 Queen HB& FBPanels
STEP1: LaytheHBposts-Left/Rightfacedownonasoftsurface. Attach the headboard
(HB)andwoodstretchertoHBposts-Left/Rightbyusing14bolts(A), lock washers (B)
andflatwashers(C).UsetheAllenwrenchprovidedtotighten all the bolts.
HBPosts -Right
HBPosts -Left
STEP2: LaytheFBposts-Left/Rightfacedownonasoftsurface.Screwthe bolts(E)intoFB
posts-left/ right. Align theboltswiththeholesintheend offootboardandattach thefootboard
toFBposts-left/ right using halfmoonWasher (F)andhexnuts(G).Thenuseahexwrench (H)
totightenall thenuts.
FBPosts -Right
FBPosts -Left
FBBackside
12-25-2023

STEP4: Attachthesupportlegstotheslatsasshownright.
Side Rail
STEP3: Screwthebolts(I)intoHB&FB.Makesuretheslatbearerisinthe LOWER position.
Alignthe boltswiththe holesintheendofsiderailsandattach theside railstoHB&FBusing
halfmoonWashers (J)andhexnuts(K).Thenuseahexwrenchtotighten all the nuts.
Headboard
Slatbearer
Side Rail
I
JKL
ThisEndUp
Slat
SupportLeg
aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
Page4/5
Makesuretheslatbeareris
inthe LOWER position.
ITEMNO: I3048-444P Q/K Bed Tall Posts
I3048-445P Q/K Bed ShortPosts
I3048-402 Queen Rails
I3048-442 Queen HB& FBPanels
01-02-2024

aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
Page5/5
STEP5: Arrangeslatsontheslat bearers.
Makesuretheslatsareplaced withinthe
notchesofeachbearerandsecured
completelywithwoodscrews (M).
FUNCTIONALITYINSTRUCTION
ITEMNO: I3048-444P Q/K Bed Tall Posts
I3048-445P Q/K Bed ShortPosts
I3048-402 Queen Rails
I3048-442 Queen HB& FBPanels
StandardQueen bed
StandardQueen bed
I3048-442
I3048-442
I3048-442
I3048-442
I3048-402
I3048-402
PoweredUSBPorts(1
Type A+1Type C) for
Charging on bothsides
I3048-444P
I3048-445P
M
Slat
Slatbearer
M
01-02-2024
