aspenhome IHP-360T-FSL User manual

05-17-2018
Page1/2
ITEMNO:IHP-360T-FSL60"Adj.LiftDeskTop(for IUAB-301)
Thankyou for purchasing thisqualityproduct.Besuretocheckallpacking material carefullyfor
small partsthatmaycomelooseinsidethecartonduringshipment.
BEFOREUSINGTHISPRODUCTPLEASEREAD,UNDERSTAND,ANDFOLLOWTHESEINSTRUCTIONS.
Savetheseinstructionsforfuturereference. FORINDOORUSEONLY
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
TOOLSREQUIRED(NOTPROVIDED)
PHILLIPS SCREWDRIVER
FUNCTIONALITY INSTRUCTION
LiftMechanism
AssemblyinstructionsfortheLift
MechanismareintheLift
Mechanismpackage.Followthese
instructionswhenattachingdesktop
totheLiftMechanism.
HARDWARELIST:
No. Description Sketch Quantity
ABolt 5/16"*2" 4PCS
BBolt 5/16"*3/4" 6PCS
CLockWasher5/16" 10PCS
DFlatWasher5/16"*7/8" 10PCS
EAllenWrench4mm 1PC
FPlasticWireClip 6PCS
GWoodScrewM4*5/8" 6PCS
COMPONENTS LIST:
No. Description Sketch Quantity
1DeskTop 1Set
LeveleronBase
Adjusttheleveler
whennecessary
Pressheretorelease
Hook latch
Metal plate
Flipdownkeyboard
tray
2ACoutlet/2USB
powerpack
PowerUnitintheflippanel

05-17-2018
Page2/2
ITEMNO:IHP-360T-FSL60"Adj.LiftDeskTop(for IUAB-301)
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
D
C
A
E
D
C
B
E
DeskBack
DeskBack
Note:RefertoLiftMechanismassemblyinstructionsforControlUnitoperation.
LiftMechanism
Control Unit
Screw
Threaded insert
ACoutlet
PowerUnit
LiftMechanism
ControlUnit
STEP1:Putthedesktopfacedownonasoftsurface.
STEP2:PlaceLiftMechanismondesktopandadjusttoalignwiththreadedinserts.
STEP3:SecureLiftMechanismtodesktopbyusing4bolts(A),6bolts(B),lockwashers(C)andflatwashers(D). Then
useanallenwrenchtotightenallthebolts.
STEP4:Tightenboltsforcrossbeampiecesandtightenhexangularrod.
STEP5:AttachtheLiftMechanismControlUnit("J"oncomponetsforLiftDeskMechanism)tothedesiredposition
withscrews("O"onhardwarebagforLiftDeskMechanism).
STEP6:Clipthewireintotheplasticwireclip,Attachtheplasticwireclips(F)totherightpositionwithscrews(G).
STEP7:Turntheassembleddesktotheuprightposition.
STEP8:ConnecttheappropriatewireclipsleadingfromthemotortotheLiftMechanismControlUnit.
STEP9:SituatePowerUnitinsideflippanelondesktopandconnecttheappropriatewireclipsleadingfromtheLift
MechanismControlUnittothePowerUnit.
STEP10:PluginthePowerUnittoanACoutlet.
STEP11:Ifdisassemblyisrequired,lowertheLiftMechanismtothelowestpoint.
G
F
Wire
