ITEMNO:IHP-378-FSL/KHACombo File
Thankyouforpurchasingthisqualityproduct.Besuretocheckallpacking material carefullyfor
small partsthatmaycomelooseinsidethe cartonduringshipment.
BEFORE USING THISPRODUCT PLEASEREAD, UNDERSTAND, AND FOLLOWTHESEINSTRUCTIONS.
Save these instructionsforfuture reference. FORINDOORUSEONLY
aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
COMPONENTSLIST:
No. Description Sketch Quantity
1Case 1PC
2MetalBase 2PCS
TOOLSREQUIRED (NOTPROVIDED)
PHILLIPSSCREWDRIVER
STEP1: Putthecasebacksidedownon asoftsurface.Matchthehole
patternonmetalbasestothethreadedinsertsonthebottomandattach to
thebottomofthecasebyusing8bolts(A),lockwashers(B) and flat
washers(C).Turnthecasetotheuprightposition.
Remove the woodscrews
on the back panels of
drawerbox toremove the
rod loopsand file rods if
necessary.
FUNCTIONALITYINSTRUCTION
Leveleron metalbases
Adjustthe leveler
when necessary
Heavy DutyBall Bearing Slide
Locking file drawers hold
letterorlegalsize files
Case
Bottom
MetalBase
A
B
C
D
HARDWARELIST:
No. Description Sketch Quantity
ABolt 5/16"*1" 8PCS
BLock Washer5/16" 8PCS
CFlatWasher5/16" *3/4" 8PCS
DAllen Wrench 1PC
02-15-2022

Hook
Drawerrail
Push this tab in
To remove the drawer, please remove the set screwson two sides
ofthe drawers. Push the tab in toward the drawerand lift up the
drawerto move out.
To install the drawer, please extend the slidesall the way out. Set
the drawerbox into cabinet rail and slide back so the drawerrail
goesunderthe hook in cabinet rail. Then snap the tab into drawer
rail and replace set screws.
Set screw
Cabinet rail
InstructionfortheFileDrawerwithHeavyDutyBall Bearing Slides
