ASROCK Rack GENOAD8UD-2T User manual

GENOAD8UD-2T
GENOAD8UD-2T/X550
User Manual
Version 1.0
Published January 2023
Copyright©2023 ASRock Rack INC. All rights reserved.

Version 1.0
Published February 2023
Copyright©2023 ASRock Rack INC. All rights reserved.
Copyright Notice:
No part of this documentation may be reproduced, transcribed, transmitted, or translated
in any language, in any form or by any means, except duplication of documentation by the
purchaser for backup purpose, without written consent of ASRock Rack Inc.
Products and corporate names appearing in this documentation may or may not be
registered trademarks or copyrights of their respective companies, and are used only for
identication or explanation and to the owners’ benet, without intent to infringe.
Disclaimer:
Specications and information contained in this documentation are furnished for
informational use only and subject to change without notice, and should not be
constructed as a commitment by ASRock Rack. ASRock Rack assumes no responsibility
for any errors or omissions that may appear in this documentation.
With respect to the contents of this documentation, ASRock Rack does not provide
warranty of any kind, either expressed or implied, including but not limited to the implied
warranties or conditions of merchantability or tness for a particular purpose.
In no event shall ASRock Rack, its directors, ocers, employees, or agents be liable for
any indirect, special, incidental, or consequential damages (including damages for loss of
prots, loss of business, loss of data, interruption of business and the like), even if ASRock
Rack has been advised of the possibility of such damages arising from any defect or error
in the documentation or product.
is device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
is equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. ese limits are designed to provide
reasonable protection against harmful interference in a residential installation. is
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment o and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.

e terms HDMI®and HDMI High-Denition Multimedia Interface, and the HDMI logo are
trademarks or registered trademarks of HDMI Licensing LLC in the United States and other
countries.
CALIFORNIA, USA ONLY
e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance
controlled in Perchlorate Best Management Practices (BMP) regulations passed by the
California Legislature. When you discard the Lithium battery in California, USA, please
follow the related regulations in advance.
“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/
perchlorate”
AUSTRALIA ONLY
Our goods come with guarantees that cannot be excluded under the Australian Consumer
Law. You are entitled to a replacement or refund for a major failure and compensation for
any other reasonably foreseeable loss or damage caused by our goods. You are also entitled
to have the goods repaired or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure. If you require assistance please call ASRock
Rack Tel : [phone] ext.123 (Standard International call charges apply)
ASRock Rack INC. hereby declares that this device is in compliance with the essential
requirements and other relevant provisions of related UKCA Directives. Full text of UKCA
declaration of conformity is available at: http://www.asrockrack.com
ASRock Rack INC. hereby declares that this device is in compliance with the essential re-
quirements and other relevant provisions of related Directives. Full text of EU declaration
of conformity is available at: http://www.asrockrack.com
ASRock Rack follows the green design concept to design and manufacture our products,
and makes sure that each stage of the product life cycle of ASRock Rack product is in line
with global environmental regulations. In addition, ASRock Rack disclose the relevant
information based on regulation requirements.
Please refer to https://www.asrockrack.com/general/about.asp?cat=Responsibility for
information disclosure based on regulation requirements ASRock Rack is complied with:
DO NOT throw the motherboard in municipal waste. is product has been
designed to enable proper reuse of parts and recycling. is symbol of the
crossed out wheeled bin indicates that the product (electrical and electronic
equipment) should not be placed in municipal waste. Check local regulations
for disposal of electronic products.

Contents
Chapter 1 Introduction 1
1.1 Package Contents 1
1.2 Specications 2
1.3 Unique Features 5
1.4 Motherboard Layout 6
1.5 Onboard LED Indicators 9
1.6 I/O Panel 10
1.7 Block Diagram 12
Chapter 2 Installation 13
2.1 Screw Holes 13
2.2 Pre-installation Precautions 13
2.3 Installing the CPU 14
2.4 Installation of Memory Modules (DIMM) 19
2.5 Expansion Slots (PCI Express Slots) 21
2.6 Onboard Headers and Connectors 22
2.7 ATX PSU / DC-IN Power Connections 33
2.8 Dr. Debug 34
2.9 Identication purpose LED/Switch 40
2.10 M.2 SSD Module Installation Guide 41
2.11 Dual LAN and Teaming Operation Guide 43
Chapter 3 UEFI Setup Utility 44
3.1 Introduction 44
3.1.1 UEFI Menu Bar 44

3.1.2 Navigation Keys 45
3.2 Main Screen 46
3.2.1 Mother Board Information 47
3.2.2 Processor Information 47
3.2.3 Memory Information 48
3.3 Advanced Screen 49
3.3.1 CPU Conguration 50
3.3.2 Chipset Conguration 51
3.3.3 Storage Conguration 53
3.3.4 NVMe Conguration 54
3.3.5 ACPI Conguration 55
3.3.6 USB Conguration 56
3.3.7 Super IO Conguration 57
3.3.8 Serial Port Console Redirection 58
3.3.9 H/W Monitor 61
3.3.10 PCI Subsystem Settings 62
3.3.11 AMD CBS 63
3.3.12 AMD PBS 64
3.3.13 PSP Firmware Versions 66
3.3.14 Network Stack Conguration 67
3.3.15 Driver Health 69
3.3.16 Tls Auth Conguration 70
3.3.17 Instant Flash 71
3.4 Security 72

3.4.1 Install Default Secure Boot Keys 73
3.4.2 Clear Secure Boot Keys 74
3.4.3 Key Management 75
3.5 Server Mgmt 79
3.6 Event Logs 81
3.7 Boot Screen 83
3.8 Exit Screen 84
Chapter 4 Software Support 85
4.1 Download and Install Operating System 85
4.2 Download and Install Software Drivers 85
4.3 Contact Information 85
Chapter 5 Troubleshooting 86
5.1 Troubleshooting Procedures 86
5.2 Technical Support Procedures 88
5.3 Returning Merchandise for Service 88

GENOAD8UD-2T
GENOAD8UD-2T/X550
PB 1
English
Chapter 1 Introduction
ank you for purchasing ASRock Rack GENOAD8UD-2T / GENOAD8UD-2T/X550
motherboard, a reliable motherboard produced under ASRock Rack’s consistently stringent
quality control. It delivers excellent performance with robust design conforming to ASRock
Rack’s commitment to quality and endurance.
In this manual, chapter 1 and 2 contains introduction of the motherboard and step-by-step
guide to the hardware installation. Chapter 3 and 4 contains the conguration guide to BIOS
setup and information of the Sofware Support.
1.1 Package Contents
• ASRock Rack GENOAD8UD-2T/GENOAD8UD-2T/X550 Motherboard
(Deep Micro-ATX Form Factor: 10.4-in x 10.5-in)
• Quick Installation Guide
• 1 x MCIO X8 to 8 SATA +8P Cable (63cm)
• 1 x ATX 4P to 24P Power Cable (8cm)
• 2 x Screws for M.2 Sockets
If any items are missing or appear damaged, contact your authorized dealer.
Because the motherboard specications and the BIOS soware might be updated, the con-
tent of this manual will be subject to change without notice. In case any modications of
this manual occur, the updated version will be available on ASRock Rack website without
further notice. You may nd the latest memory and CPU support lists on ASRock Rack
website as well. ASRock Rack’s Website: www.ASRockRack.com
If you require technical support related to this motherboard, please visit our website for
specic information about the model you are using.
http://www.asrockrack.com/support/

2 3
English
1.2 Specications
GENOAD8UD-2T / GENOAD8UD-2T/X550
MB Physical Status
Form Factor Deep Micro-ATX
Dimension 10.4" x 10.5" (264.16 x 266.7 mm)
Processor System
CPU Supports AMD EPYC GENOA processors
Socket 1 Socket SP5 (LGA 6096)
ermal Design
Power (TDP)
400W
Chipset System on Chip
System Memory
Supported DIMM
Quantity
8 DIMM slots (1DPC)
Supported Type Supports DDR5 288-pin RDIMM, RDIMM-3DS
Max. Capacity per
DIMM
RDIMM: 64GB (2R)
RDIMM-3DS: 512GB (2S8Rx4)
Max. Frequency 4800MHz
Voltage 1.1V
Note Memory capacity, frequency, and voltage support is to be validated
Expansion Slot
Slot 6 PCIe5.0 x16
Slot 5 PCIe5.0 x16
Slot 4 PCIe5.0 x16
Slot 3 PCIe5.0 x16
Other PCIe Expansion Connectors
M.2 2 M-key (PCIe5.0 x4); support 2280/2260/2242/2230 form
factor
MCIO 2 MCIO (PCIe5.0 x8)
2 MCIO (PCIe5.0 x8 or 8 SATA 6Gb/s)
1 MCIO (PCIe5.0 x4)
Storage
CPU Built-in Storage AMD EPYC GENOA (16 SATA 6Gb/s):
2 MCIO
Ethernet
Additional Ethernet
Controller
GENOAD8UD-2T:
Intel® X710-AT2: 2 RJ45 (10GbE)
GENOAD8UD-2T/X550:
Intel® X550-AT2: 2 RJ45 (10GbE)
USB
Controller/Hub AMD EPYC GENOA

GENOAD8UD-2T
GENOAD8UD-2T/X550
2 3
English
Connectors/Headers External:
2 Type-A (USB3.2 Gen1)
Internal:
1 header (19-pin, 2 USB3.2 Gen1)
Graphics
Controller ASPEED AST2600
VRAM DDR4 512MB
Security
TPM 1 (13-pin, SPI)
Rear Panel I/O
UID Button/LED 1 UID button w/ LED
VGA Port 1 DB15 (VGA)
USB 2 Type-A (USB3.2 Gen1)
RJ45 2 RJ45 (10GbE), 1 dedicated IPMI
Hardware Monitor
Temperature CPU, MB, TR1 Temperature sensing
Fan CPU/Rear/Front Fan Tachomete
CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by
CPU Temperature)
CPU/Rear/Front Fan Multi-Speed Control
Voltage VCORE, VCCSA, VCCM, 3V, 5V, 12V, +BAT, 3VSB, 5VSB,
VCCIO, +2.5V_VPP
Server Management
BMC Controller ASPEED AST2600
IPMI Dedicated
GLAN
1 Realtek RTL8211F for dedicated management GLAN
System BIOS
Type AMI UEFI BIOS; 256 Mb (32MB) SPI Flash ROM
Features ASRock Rack Instant Flash, ACPI 6.4 and abouve compliance
wake up events, SMBIOS 3.5.0 and above, Plug and Play(PnP)
Other Internal Connectors/Headers
PSU connector 1 (4-pin, ATX PSU signal) w/ ATX 24-pin adapter cable, 3 (8-
pin, ATX 12V) support 12V DC-in
Other Power
Connector
1 (6-pin) for HDD power
Auxiliary Panel
Header
1 (18-pin): chassis intrusion, system fault LED, LAN1/LAN2
activity LED, locate, SMBus
System Panel 1 (9-pin): power switch, reset switch, system power LED,
HDD activity LED
NMI Header 1
COM Header 1
Speaker Header 1 (4-pin)
Fan Header 6 (6-pin)
ermal Sensor
Header
1

4 5
English
TPM Header 1 (13-pin, SPI)
SGPIO Header 2
HSBP 1
SMbus Header 1
PMbus Header 1
IPMB Header 1
Clear CMOS 1 (contact pads)
LED Indicators
Standby Power LED 1 (5VSB)
Fan Fail LED 6
BMC Heartbeat LED 1
Support OS
OS Microso® Windows®:
- Server 2016 (64bit)
- Server 2019 (64bit)
- Server 2022 (64 bit)
Linux®:
- RedHat Enterprise Linux Server 8.3 (64 bit) / 8.4 (64 bit)
- CentOs 8.3 (64 bit) / 8.4 (64 bit)
- SUSE SLES 15.2 (64 bit) / 12.5 (64 bit)
- UBuntu 21.04 (64 bit) / 20.04.3 (64 bit) / 18.04.5 (64 bit)
Hypervisor:
- VMWare® ESXi 6.7.0 u3 / vSphere 6.7.0 u3
- VMWare® ESXi 7.0 U1 / vSphere 7.0 U1
- VMWare® ESXi 7.0 U2a / vSphere 7.0 U2b
- CITRIX Hypervisor 8.2.0
*Please refer to our website for the latest OS support list.
Environment
Temperature Operation temperature: 10°C ~ 35°C (50 - 95 degF) / Non
operation temperature: -40°C ~ 70°C (-40 - 158degF)
Humidity Non operation humidity: 20% ~ 90% ( Non condensing)
is motherboard supports Wake from on Board LAN. To use this function, please make
sure that the “Wake on Magic Packet from power o state” is enabled in Device Manager
> Intel® Ethernet Connection > Power Management. And the “PCI Devices Power On” is
enabled in UEFI SETUP UTILITY > Advanced > ACPI Conguration. Aer that, onboard
LAN1&2 can wake up S5 under OS.
If you install Intel® LAN utility or Marvell SATA utility, this motherboard may fail Win-
dows® Hardware Quality Lab (WHQL) certication tests. If you install the drivers only, it
will pass the WHQL tests.
NOTE: Please refer to our website for the latest specications.

GENOAD8UD-2T
GENOAD8UD-2T/X550
4 5
English
1.3 Unique Features
ASRock Rack Instant Flash is a BIOS ash utility embedded in Flash ROM. is convenient
BIOS update tool allows you to update system BIOS without entering operating systems rst
like MS-DOS or Windows®. With this utility, you can press the <F6> key during the POST or
the <F2> key to enter into the BIOS setup menu to access ASRock Rack Instant Flash. Just
launch this tool and save the new BIOS le to your USB ash drive, oppy disk or hard drive,
then you can update your BIOS only in a few clicks without preparing an additional oppy
diskette or other complicated ash utility. Please be noted that the USB ash drive or hard
drive must use FAT32/16/12 le system.

6 7
English
1.4 Motherboard Layout
26.7cm (10.5 in)
26.4cm (10.4 in)
23
10
11
13
1
SPEAKER1
14
15
17
18
19
20
22
23
2627
1
21
2425
FAN1
FAN2
FAN3
DDR5_G1
SA TA PWR1
MCIO1
M2_1
SA TA _SGPIO3
CPU_HSBP1
Dr. Debug
AUX_P ANEL1
PA NEL1
4
5
6
8
9
12
16
283233 293134
41
38
40
39
42
1
T
R1
Super
I/O
CLRMOS1
30
GENOAD8UD-2T
GENOAD8UD-2T/X550
ATX12V2
ATX12V1
ATX4PIN1
BAT1
FAN4
FAN5
FAN6
ATX12V3
MCIO2
MCIO3
MCIO4
MCIO5
PSU_SMB1
CPU1
US B 3. 2 Gen 1
T: USB_ 2
B: USB _ 1
(NCSI)
IPMI_LAN
LAN_1 LAN_2
UID1
APEED
AST2600
BIOS
ROM
TPM_BIOS_PH1
VGA1
PCIE6
PCIE5
PCIE4
DDR5_A1
DDR5_B1
DDR5_C1
DDR5_E1
USB3_3_4
COM1
IPMB1
BMC_SMB1
BMC
ROM
PCIE3
M2_2
SA TA _SGPIO4
1
NMI_BTN1
BUZZER1
DDR5_K1
DDR5_I1
DDR5_H1
353637
7
GENOAD8UD-2T :
Intel
X710- AT 2
GENOAD8UD-2T/X550:
Intel
X550- AT 2

GENOAD8UD-2T
GENOAD8UD-2T/X550
6 7
English
No. Description
1 2 x 288-pin DDR5 DIMM Slots (DDR5_G1, DDR5_I1)*
2 2 x 288-pin DDR5 DIMM Slots (DDR5_H1, DDR5_K1)*
3 ATX 4-PIN Power Connector (ATX4PIN1 (ATX 24pin-to-4pin))
4 ATX 12V Power Connector (ATX12V1)
5 ATX 12V Power Connector (ATX12V2)
6 ATX 12V Power Connector (ATX12V3)
7 AMD Socket SP5 (SM-LGA-6096) (CPU1)
8 System Fan Connector (FAN1)
9 System Fan Connector (FAN2)
10 System Fan Connector (FAN3)
11 System Fan Connector (FAN4)
12 System Fan Connector (FAN5)
13 System Fan Connector (FAN6)
14 2 x 288-pin DDR5 DIMM Slots (DDR5_A1, DDR5_C1)*
15 Mini Cool Edge IO x8 Connector (MCIO1)
16 2 x 288-pin DDR5 DIMM Slots (DDR5_B1, DDR5_E1)*
17 Mini Cool Edge IO x8 Connector (MCIO2)
18 Mini Cool Edge IO x8 Connector (MCIO3)
19 M.2 Socket (M2_1) (Type 2230/2242/2260/2280)
20 Mini Cool Edge IO x8 Connector (MCIO4)
21 Mini Cool Edge IO x4 Connector (MCIO5)
22 Backplane PCI Express Hot-Plug Connector (CPU1_HSBP1)
23 SATA Power Connector (SATAPWR1)
24 M.2 Socket (M2_2) (Type 2230/2242/2260/2280)
25 PSU SMBus Header (PSU_SMB1)
26 System Panel Header (PANEL1)
27 SATA SGPIO Connector (SATA_SGPIO4)
28 Auxiliary Panel Header (AUX_PANEL1)
29 SATA SGPIO Connector (SATA_SGPIO3)
30 USB 3.2 Gen1 Header (USB3_3_4)
31 Chassis Speaker Header (SPEAKER1)
32 Clear CMOS Pad (CLRMOS1)
33 Non Maskable Interrupt Button (NMI_BTN1)
34 ermal Sensor Header (TR1)

8 9
English
No. Description
35 Intelligent Platform Management Bus Header (IPMB1)
36 BMC SMBus Header (BMC_SMB1)
37 COM Port Header (COM1)
38 PCI Express 5.0 x16 Slot (PCIE3)
39 PCI Express 5.0 x16 Slot (PCIE4)
40 PCI Express 5.0 x16 Slot (PCIE5)
41 PCI Express 5.0 x16 Slot (PCIE6)
42 SPI TPM Header (TPM_BIOS_PH1)
* For DIMM installation and conguration instructions, please see p.19 (Installation of Memory Modules
(DIMM)) for more details.

GENOAD8UD-2T
GENOAD8UD-2T/X550
8 9
English
No. Item Status Description
1LED_FAN1 Red FAN1 failed
2LED_FAN2 Red FAN2 failed
3LED_FAN3 Red FAN3 failed
4LED_FAN4 Red FAN4 failed
5LED_FAN5 Red FAN5 failed
6LED_FAN6 Red FAN6 failed
7 SB_PWR1 Green STB PWR ready
8BMC_LED1 Green BMC heartbeat LED
1.5 Onboard LED Indicators
2
4
6
1
3
5
7
8

10 11
English
1.6 I/O Panel
6
5
3
4
2
1
No. Description No. Description
1 UID Switch (UID1) 4 10G LAN RJ-45 Port (LAN_1)**
2 IPMI LAN Header (IPMI_LAN1)* 5 10G LAN RJ-45 Port (LAN_2)**
3 USB 3.2 Gen1 Ports (USB3_1_2) 6 VGA Port (VGA1)
LAN Port LED Indications
*ere are two LED next to the LAN port. Please refer to the table below for the LAN port
LED indications.
Dedicated IPMI LAN Port LED Indications
Activity / Link LED Speed LED
Status Description Status Description
O No Link O 10Mbps connection or no
link
Blinking Yellow Data Activity Yellow 100Mbps connection
On Link Green 1Gbps connection
ACT/LINK LED
SPEED LED
LAN Port

GENOAD8UD-2T
GENOAD8UD-2T/X550
10 11
English
**ere are two LEDs on each LAN port. Please refer to the table below for the LAN port
LED indications.
10G LAN Port LED Indications
Activity / Link LED Speed LED
Status Description Status Description
O No Link O 100Mbps connection or
no link
Blinking Green Data Activity Yellow 1Gbps connection
On Link Green 10Gbps connection
ACT/LINK LED
SPEED LED
LAN Port

12 13
English
1.7 Block Diagram
5 5
4 4
3 3
2 2
1 1
D D C C B B A A
USB3.0 x 4
AMD Family 19h 10h-1Fh Processor
Socket SP5 (SMLGA-6096)
CPU
GENOA SP5
Support Max：
：
400 W
REALTEK RTL8211F/FD
10/100/1G PHY
DDR4 DRAM
(512MB)
BMC
AST2600
Ethernet
10/100/1000
Video
DAC
BMC & VRAM
PCI-Exp ress
USB
1.1 &
2.0
ESPI
MAC3
SPI
SPI FLASH
(64MB)
ESPI
PCIE Gen2 x1
ESPI
USB2.0 * 1
USB 3 .0
Ethernet
10/100/1000
MAC1
UART
0 1
NCSI
COM1
x1
PCI-E Gen3
P5
USB3_4
Switch
VGA1
USB10_DP
USB11_DP
USB HUB
USB3_1_2
USB2.0 x 1 USB2.0 x 1
USB2.0 x 1
PORT80_1
CHA
DDR5 RDIMM/RDIMM-3DS
CHB CHC CHE
CHG CHH CHI CHK
SuperIO
X710-AT2
or
X550-AT2
LAN1 LAN2
PCI-E Gen5
P0 x16PCIE Gen5 x16
x16
G0 G1 G2
PCI-E Gen5
G3
SPI
MCIO 1
PCIE Gen5 x16
MCIO 3
PCIE Gen5 x8 SATA 6Gb/s *8
PCI-E Gen3
x4
P4
PCIE Gen3 x4
10GbE 10GbE
PCI-E Gen3
x2
P5
LEVEL SHIFT
SPI
SW
SPI
BIOS FLASH
(32MB)
TPM
IPMI LAN
PCI-E Gen5
P1 x16PCIE Gen5 x16
PCIE6 Gen5 x16
PCI-E Gen5
P2 x16PCIE Gen5 x16
PCIE5 Gen5 x16
PCI-E Gen5
P3 x16PCIE Gen5 x16
PCIE4 Gen5 x16
PCIE Gen5 x8 SATA 6Gb/s *8
MCIO 4 MCIO 5
PCIE Gen5 x4
PCIE Gen5x4
M.2 Conn.
7 segment LED
PCIE Gen5x4
M.2 Conn. PCIE3 Gen5 x16
MCIO 2
x16
PCI-E Gen5
x16
PCI-E Gen5
x16
PCI-E Gen5
DDR5 RDIMM/RDIMM-3DS
DDR5 RDIMM/RDIMM-3DS
DDR5 RDIMM/RDIMM-3DS
DDR5 RDIMM/RDIMM-3DS
DDR5 RDIMM/RDIMM-3DS
DDR5 RDIMM/RDIMM-3DS
DDR5 RDIMM/RDIMM-3DS
Size
Project Name
Rev
Date: Sheet of
Title :
Engineer:
C
2156Wednesday, February 15, 2023
Asrockrack
Diagram Block
R5.00
GENOAD8U-2T
<Core Design>
Eric Hu
Size
Project Name
Rev
Date: Sheet of
Title :
Engineer:
C
2156Wednesday, February 15, 2023
Asrockrack
Diagram Block
R5.00
GENOAD8U-2T
<Core Design>
Eric Hu
Size
Project Name
Rev
Date: Sheet of
Title :
Engineer:
C
2156Wednesday, February 15, 2023
Asrockrack
Diagram Block
R5.00
GENOAD8U-2T
<Core Design>
Eric Hu

GENOAD8UD-2T
GENOAD8UD-2T/X550
12 13
English
Chapter 2 Installation
is is a Deep Micro-ATX form factor (10.4” x 10.5”, 265 x 26.7 cm) motherboard. Before
you install the motherboard, study the conguration of your chassis to ensure that the
motherboard ts into it.
Make sure to unplug the power cord before installing or removing the motherboard. Failure
to do so may cause physical injuries to you and damages to motherboard components.
2.1 Screw Holes
Place screws into the holes indicated by circles to secure the motherboard to the chassis.
Do not over-tighten the screws! Doing so may damage the motherboard.
2.2 Pre-installation Precautions
Take note of the following precautions before you install motherboard components or
change any motherboard settings.
1. Unplug the power cord from the wall socket before touching any components.
2. To avoid damaging the motherboard’s components due to static electricity, NEVER
place your motherboard directly on the carpet or the like. Also remember to use a
grounded wrist strap or touch a safety grounded object before you handle the compo-
nents.
3. Hold components by the edges and do not touch the ICs.
4. Whenever you uninstall any component, place it on a grounded anti-static pad or in
the bag that comes with the component.
5. When placing screws into the screw holes to secure the motherboard to the chassis,
please do not over-tighten the screws! Doing so may damage the motherboard.
Before you install or remove any component, ensure that the power is switched o or the
power cord is detached from the power supply. Failure to do so may cause severe damage to
the motherboard, peripherals, and/or components.

14 15
English
2.3 Installing the CPU
1. Before you insert the CPU into the socket, please check if the PnP cap is on the socket,
if the CPU surface is unclean, or if there are any bent pins in the socket. Do not force to
insert the CPU into the socket if above situation is found. Otherwise, the CPU will be
seriously damaged.
2. Unplug all power cables before installing the CPU.
1
2
