ASROCK Rack TRX40D8-2N2T User manual

TRX40D8-2N2T
User Manual
Version 1.0
Published July 2020
Copyright©2020 ASRock Rack INC. All rights reserved.

Version 1.0
Published August 2020
Copyright©2020 ASRock Rack Inc. All rights reserved.
Copyright Notice:
No part of this documentation may be reproduced, transcribed, transmitted, or
translated in any language, in any form or by any means, except duplication of
documentation by the purchaser for backup purpose, without written consent of
ASRock Rack Inc.
Products and corporate names appearing in this documentation may or may not
be registered trademarks or copyrights of their respective companies, and are used
only for identication or explanation and to the owners’ benet, without intent to
infringe.
Disclaimer:
Specications and information contained in this documentation are furnished
for informational use only and subject to change without notice, and should not
be constructed as a commitment by ASRock Rack. ASRock Rack assumes no
responsibility for any errors or omissions that may appear in this documentation.
With respect to the contents of this documentation, ASRock Rack does not provide
warranty of any kind, either expressed or implied, including but not limited to
the implied warranties or conditions of merchantability or tness for a particular
purpose.
In no event shall ASRock Rack, its directors, ocers, employees, or agents be liable
for any indirect, special, incidental, or consequential damages (including damages
for loss of prots, loss of business, loss of data, interruption of business and the
like), even if ASRock Rack has been advised of the possibility of such damages
arising from any defect or error in the documentation or product.
is device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
CALIFORNIA, USA ONLY
e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance
controlled in Perchlorate Best Management Practices (BMP) regulations passed by the
California Legislature. When you discard the Lithium battery in California, USA, please
follow the related regulations in advance.
“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/
perchlorate”
ASRock Rack’s Website: www.ASRockRack.com

Contact Information
If you need to contact ASRock Rack or want to know more about ASRock Rack,
you’re welcome to visit ASRock Rack’s website at www.ASRockRack.com; or you
may contact your dealer for further information.
ASRock Rack Incorporation
6F., No.37, Sec. 2, Jhongyang S. Rd., Beitou District,
Taipei City 112, Taiwan (R.O.C.)

Contents
Chapter 1 Introduction 1
1.1 Package Contents 1
1.2 Specications 2
1.3 Unique Features 6
1.4 Motherboard Layout 7
1.5 Onboard LED Indicators 10
1.6 I/O Panel 11
1.7 Block Diagram 13
Chapter 2 Installation 14
2.1 Screw Holes 14
2.2 Pre-installation Precautions 15
2.3 Installing the CPU and Heatsink 16
2.4 Installing the CPU Cooler 20
2.5 Installation of Memory Modules (DIMM) 23
2.6 Expansion Slots (PCI Express Slots) 25
2.7 Onboard Headers and Connectors 26
2.8 Unit Identication purpose LED/Switch 33
2.9 Driver Installation Guide 33
2.10 M.2_SSD (NGFF) Module Installation Guide 34
Chapter 3 UEFI Setup Utility 37
3.1 Introduction 37
3.1.1 UEFI Menu Bar 37
3.1.2 Navigation Keys 38

3.2 Main Screen 39
3.3 Advanced Screen 40
3.4 OC Tweaker 41
3.4.1 CPU Conguration 45
3.4.2 Chipset Conguration 46
3.4.3 Storage Conguration 48
3.4.4 ACPI Conguration 49
3.4.5 Super IO Conguration 50
3.4.6 Serial Port Console Redirection 51
3.4.7 H/W Monitor 54
3.4.8 USB Conguration 55
3.4.9 PCI Subsystem Settings 56
3.4.10 AMD Mem Conguration Status 57
3.4.11 AMD CBS 58
3.4.12 AMD PBS 59
3.4.13 AMD Overclocking 60
3.4.14 Instant Flash 61
3.5 Server Mgmt 62
3.5.1 System Event Log 63
3.5.2 BMC Tools 64
3.5.3 BMC Network Conguration 65
3.6 Security 67
3.6.1 Key Management 68
3.7 Boot Screen 72

3.7.1 CSM Parameters 74
3.8 Exit Screen 76
Chapter 4 Software Support 77
4.1 Install Operating System 77
4.2 Support CD Information 77
4.2.1 Running The Support CD 77
4.2.2 Drivers Menu 77
4.2.3 Utilities Menu 77
4.2.4 Contact Information 77
Chapter 5 Troubleshooting 78
5.1 Troubleshooting Procedures 78
5.2 Technical Support Procedures 80
5.3 Returning Merchandise for Service 80

TRX40D8-2N2T
PB 1
English
Chapter 1 Introduction
ank you for purchasing ASRock Rack TRX40D8-2N2T motherboard, a reliable
motherboard produced under ASRock Rack’s consistently stringent quality control.
It delivers excellent performance with robust design conforming to ASRock Rack’s
commitment to quality and endurance.
In this manual, chapter 1 and 2 contains introduction of the motherboard and step-
by-step guide to the hardware installation. Chapter 3 and 4 contains the conguration
guide to BIOS setup and information of the Support CD.
1.1 Package Contents
• ASRock Rack TRX40D8-2N2T Motherboard
(ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm)
• Support CD
• Quick Installation Guide
• 1 x SATA3 Cable (60cm)
• 1 x Mini SAS HD to 4 SAS/SATA Cable (12G)
• 2 x Screws for M.2 Sockets
• 1 x I/O Shield
If any items are missing or appear damaged, contact your authorized dealer.
Because the motherboard specications and the BIOS soware might be updated, the con-
tent of this manual will be subject to change without notice. In case any modications of
this manual occur, the updated version will be available on ASRock Rack website without
further notice. You may nd the latest memory and CPU support lists on ASRock Rack
website as well. ASRock Rack’s Website: www.ASRockRack.com
If you require technical support related to this motherboard, please visit our website for
specic information about the model you are using.
http://www.asrockrack.com/support/

2 3
English
1.2 Specications
TRX40D8-2N2T
MB Physical Status
Form Factor ATX
Dimension 12'' x 9.6'' (30.5 cm x 24.4 cm)
Processor System
CPU Supports AMD Ryzen™ readripper™ TR4+ Series Processors
Socket AMD Socket TR4 4094P
Chipset AMD TRX40
System Memory
Capacity - 8 x 288-pin DDR4 DIMM slots
- Supports up to 256GB DDR4 ECC & non-ECC U-DIMM
Type - Dual Channel Memory Technology
- Supports DDR4 ECC U-DIMM
Voltage 1.2V
DIMM Size per
DIMM
ECC U-DIMM: 32GB, 16GB, 8GB, 4GB
DIMM Frequency ECC / non-ECC U-DIMM: 4666(OC)+ / 4600(OC) /
4533(OC) / 4466(OC) / 4400(OC) / 4333(OC) / 4266(OC) /
4200(OC) / 4133(OC) / 4000(OC) / 3866(OC) / 3800(OC) /
3733(OC) / 3600(OC) / 3466(OC) / 3200 / 2933 / 2667 / 2400 /
2133 MHz
Expansion Slot
PCIe 4.0 x 16 SLOT3: Gen4 x16 link
SLOT5: Gen4 x16 link
SLOT7: Gen4 x16 link
PCIe 4.0 x 8
(open-ended)
SLOT1: Gen4 x 8 link
M.2 2 x M-key (PCIe4.0 x4) support 2230/2242/2260/2280/22110
Storage
SATA Controller TRX40: 2 x SATA 6Gb/s; 2x SATA DOM, support RAID 0, 1, 5,
10
Additional SATA
Controller
Asmedia 1061: 2 x SATA3 6.0 Gb/s (A_SATA0/A_SATA1)
Ethernet
Interface 10Gbps/2.5Gbps
LAN Controller - 2 x RJ45 10GbEby Intel® X710-AT2
- 2 x RJ45 2.5GbEby Intel® i225
- Supports Wake-On-LAN
- Supports Energy Ecient Ethernet 802.3az
- Supports PXE
- LAN3 Supports NCSI

TRX40D8-2N2T
2 3
English
Management
BMC Controller ASPEED AST2500 : IPMI (Intelligent Platform Management
Interface) 2.0 with Ikvm and vMedia support
IPMI Dedicated
GLAN
1 x Realtek RTL8211E for dedicated management
Features NMI
Gracphics
Controller ASPEED AST2500
VRAM DDR4 16MB
Rear Panel I/O
PS/2 KB/mouse 1
VGA Port 1 x D-Sub
USB 3.2 Gen1 Port 2
USB 3.2 Gen2 Port 2 (1 type A, 1 type C)
LAN Port -2 x RJ45: 2 x 10GbE by Intel® X710-AT2
-2 x RJ45: 2 x 2.5GbE by Intel® i225
-1 x IPMI dedicated LAN
-LAN Ports with LED (ACT/LINK LED and SPEED LED)
UID 1
Internal Connector
Auxiliary Panel
Header
1 (includes chassis intrusion, location button & LED, system
fault LED, and front LAN LED)
Front Panel 1 (RST, PWRBTN, HDDLED, PWRLED)
VGA Header 1
COM Header 1
SATA DOM 2
Speaker 1 (4-pin)
TR1 1
TPM Header 1
SPI TPM Header 1
IPMB Header 1
PSU SMB Header 1
BMC SMBus
Header
1
Fan Header 6 x 6-pin Fans
ATX Power 1 x (24-pin) + 1 x (8-pin) + 1 x (8-pin)
Type A USB 3.2
Gen1 Port
1
USB 3.2 Gen1
Header
1 (support 2 USB 3.2 Gen1 ports)
USB 2.0 Header 1 (support 2 USB2.0 ports)
ClearCMOS 1 (short pad)
NMI button 1
Buzzer 1

4 5
English
80 Debug Port
LED
1
Front LAN LED 1
OH/FanFail LED 6 (Fan Fail LED only )
System BIOS
BIOS Ty pe 32Mb AMI UEFI Legal BIOS
BIOS Features - Plug and Play (PnP)
- ACPI 2.0 Compliance Wake Up Events
- SMBIOS 2.8 Support
- ASRock Rack Instant Flash
Hardware Monitor
Temperature - CPU Temperature Sensing
- System Temperature Sensing
- Card side Temperature Sensing
- System TR Temperature Sensing
Fan - CPU/Rear/Front Fan Tachometer
- CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by
CPU Temperature)
- CPU/Rear/Front Fan Multi-Speed Control
Voltage Voltage Monitoring: +3VSB, +5VSB, VCORE, VCORE_NB,
VCCM_AB, VCCM_CD, BAT, 3V, 5V, 12V
GPU Support
Technology Supports AMD Quad-GPU CrossFireX™ Technology
Support OS
OS Microso® Windows®
- Windows 10 (64 bit)
Linux®
- RedHat Enterprise Linux Server 8.1 (64 bit) / 7.6 (64 bit)
- CentOS 8.1 (64 bit) / 7.6 (64 bit)
- UBuntu 18.04.4 (64 bit)
* Please refer to our website for the latest OS support list.
Environment
Temperature Operation temperature: 10°C ~ 35°C / Non operation
temperature: -40°C ~ 70°C
NOTE: Please refer to our website for the latest specications.
is motherboard supports Wake from on Board LAN. To use this function, please make
sure that the “Wake on Magic Packet from power o state” is enabled in Device Manager
> Intel® Ethernet Connection > Power Management. And the “PCI Devices Power On” is
enabled in UEFI SETUP UTILITY > Advanced > ACPI Conguration. Aer that, onboard
LAN1&2 can wake up S5 under OS.

TRX40D8-2N2T
4 5
English
If you install Intel® LAN utility or Marvell SATA utility, this motherboard may fail Win-
dows® Hardware Quality Lab (WHQL) certication tests. If you install the drivers only, it
will pass the WHQL tests.

6 7
English
1.3 Unique Features
ASRock Instant Flash is a BIOS ash utility embedded in Flash ROM. is conve-
nient BIOS update tool allows you to update system BIOS without entering operating
systems rst like Windows®. With this utility, you can press the <F6> key during the
POST or the <F2> key to enter into the BIOS setup menu to access ASRock Rack
Instant Flash. Just launch this tool and save the new BIOS le to your USB ash drive,
oppy disk or hard drive, then you can update your BIOS only in a few clicks without
preparing an additional oppy diskette or other complicated ash utility. Please be
noted that the USB ash drive or hard drive must use FAT32/16/12 le system.

TRX40D8-2N2T
6 7
English
1.4 Motherboard Layout
ATXPWR1
30.5cm (12.0 in)
10G_LAN3
DDR4_B1 (64 bit, 288-pin module), Blue
DDR4_B2 (64 bit, 288-pin module), White
DDR4_A1 (64 bit, 288-pin module), Blue
DDR4_A2 (64 bit, 288-pin module), White
DDR4_C2 (64 bit, 288-pin module), White
DDR4_C1 (64 bit, 288-pin module), Blue
DDR4_D2 (64 bit, 288-pin module). White
DDR4_D1 (64 bit, 288-pin module), Blue
PCIE7
PCIE5
PCIE3
PCIE1
USB 3. 2 Ge n1
T: USB1
B: USB2
PS2
Keyboard
/Mouse
USB 3.2 Ge n2
T: USB31_TA_1
B: USB31_TC_1
VGA1
10G_LAN4
TRX40D8-2N2T
1
PSU_SMB1
ATX12V2AT X12V1
USB3_6_7
NUT30
NUT42NUT60NUT80
M2_1
NUT110
CMOS
Battery
24.4cm (9.6 in)
X710-AT2
AST2500
Super
I/O
1234
5
6
7
8
9
10
12
37
FRNT_VGA1
39
(NCSI)
AMD
TRX40
UID1
IPMI
LAN
2.5G_LAN2
2.5G_LAN1
FAN1
FAN2
FAN3
FAN4
FAN5
USB3_5
FAN6
A_SATA0
A_SATA1
SATA0
SATA1
SATA3
(Red)
SATA2
(Red)
NUT110_2
M2_2
NUT30_2NUT42_2NUT60_2
NUT80_2
RoHS
BUZZER1
HDLED RESET
PLED PWRBTN
PANEL1
1
1
AUX_PANEL1
COM1
1
USB_1_2
1
1
SPEAKER1
BIOS
ROM
1
TPM_BIOS_PH1
Dr.
Debug
1
TPM1
1
T 1
R
1
IPMB1
1
BMC_SMB1
1
LED_LAN3_4
BMC
ROM
NMI_BTN1
1
SATAPWR1 SATAPWR2
232425262731333536 34
18
19
20
2122
CLRMOS1
11
13
14
15
16
17
28293032
38

8 9
English
No. Description
1 2 x 288-pin DDR4 DIMM Slots (DDR4_C2, DDR4_D2, White)*
2 2 x 288-pin DDR4 DIMM Slots (DDR4_C1, DDR4_D1, Blue)*
3 ATX 12V Power Connector (ATX12V2)
4 ATX 12V Power Connector (ATX12V1)
5 ATX Power Connector (ATXPWR1)
6PSU SMBus (PSU_SMB1)
7 AMD Socket TR4 4094P
8 2 x 288-pin DDR4 DIMM Slots (DDR4_A2, DDR4_B2, White)*
9 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1, Blue)*
10 USB 3.2 Gen1 Header (USB3_6_7)
11 System Fan Connector (FAN1)
12 System Fan Connector (FAN2)
13 SATA3 Connector (A_SATA1) (Upper), SATA3 Connector (A_SATA0)
(Lower)
14 System Fan Connector (FAN3)
15 SATA3 Connector (SATA1) (Upper), SATA3 Connector (SATA0) (Lower)
16 System Fan Connector (FAN5)
17 System Fan Connector (FAN6)
18 Vertical Type A USB 3.2 Gen1 (USB3_5)
19 SATA DOM Power Connector (SATAPWR2)
20 SATA3 DOM Connector (SATA3), Red
21 System Panel Header (PANEL1)
22 Auxiliary Panel Header (AUX_PANEL1)
23 System Fan Connector (FAN4)
24 COM Port Header (COM1)
25 SATA3 DOM Connector (SATA2), Red
26 USB 2.0 Header (USB_1_2)
27 M.2 Socket (M2_1) (Type 2230/2242/2260/2280/22110)
28 SATA DOM Power Connector (SATAPWR1)
29 Clear CMOS Pad (CLRMOS1)
30 TPM Header (TPM1)
31 Speaker Header (SPEAKER1)
32 ermal Sensor Header (TR1)

TRX40D8-2N2T
8 9
English
No. Description
33 Intelligent Platform Management Bus Header (IPMB1)
34 BMC SMBus Header (BMC_SMB1)
35 Front LAN LED Connector (LED_LAN3_4)
36 Non Maskable Interrupt Button (NMI_BTN1)
37 M.2 Socket (M2_2) (Type 2230/2242/2260/2280/22110)
38 SPI TPM Header (TPM_BIOS_PH1)
39 Front VGA Header (FRNT_VGA1)
*For DIMM installation and conguration instructions, please see p.23 (Installation of Memory Modules
(DIMM)) for more details.

10 11
English
1.5 Onboard LED Indicators
ATXPWR1
DDR4_B1 (64 bit, 288-pin module), Blue
DDR4_B2 (64 bit, 288-pin module), White
DDR4_A1 (64 bit, 288-pin module), Blue
DDR4_A2 (64 bit, 288-pin module), White
DDR4_C2 (64 bit, 288-pin module), White
DDR4_C1 (64 bit, 288-pin module), Blue
DDR4_D2 (64 bit, 288-pin module). White
DDR4_D1 (64 bit, 288-pin module), Blue
TRX40D8-2N2T
NUT30
NUT42NUT60NUT80
M2_1
NUT110
CMOS
Battery
AST2500
Super
I/O
AMD
TRX40
FAN1
FAN2
FAN3
FAN4
FAN5
FAN6
(Red)
(Red)
NUT110_2
M2_2
NUT30_2NUT42_2NUT60_2
NUT80_2
RoHS
BIOS
ROM
SATAPWR1
2
3
4
6
7
8
1
5
No. Status Description
1Amber FAN1 failed
2Amber FAN2 failed
3Amber FAN3 failed
4Amber FAN4 failed
5Amber FAN5 failed
6Amber FAN6 failed
7Green STB PWR ready
8Green BMC heartbeat LED

TRX40D8-2N2T
10 11
English
1.6 I/O Panel
No. Description No. Description
1 UID Switch (UID1) 7 LAN RJ-45 Port (IPMI_LAN)*
2VGA Port (VGA1) 8 2.5G LAN RJ-45 Port (2.5G_LAN1)**
3 USB 3.2 Gen1 Ports (USB3_1_2) 9 2.5G LAN RJ-45 Port (2.5G_LAN2)**
4 PS/2 Mouse/Keyboard Port 10 10G LAN RJ-45 Port (LAN3)***
5 USB 3.2 Gen2 Port (USB31_TC_1) 11 10G LAN RJ-45 Port (LAN4)***
6 USB 3.2 Gen2 Port (USB31_TA_1)
LAN Port LED Indications
*ere are two LED next to the LAN port. Please refer to the table below for the LAN port
LED indications.
Dedicated IPMI LAN Port LED Indications
Activity / Link LED Speed LED
Status Description Status Description
O No Link O No link
Blinking Yellow Data Activity Yellow 10M/100M bps connection
On Link Green 1G bps connection
3
125
6
7
10 11
8
94
ACT/LINK LED
SPEED LED
LAN Port

12 13
English
**ere are two LEDs on each LAN port. Please refer to the table below for the LAN port
LED indications.
2.5G LAN Port (LAN1, LAN2) LED Indications
Activity / Link LED Speed LED
Status Description Status Description
O No Link O 10Mbps/100Mbps
connection or no link
Blinking Data Activity Yellow 1Gbps connection
On Link Green 2.5Gbps connection
***ere are two LEDs on each LAN port. Please refer to the table below for the LAN port
LED indications.
10G LAN Port (LAN3, LAN4) LED Indications
Activity / Link LED Speed LED
Status Description Status Description
O No Link O 100Mbps connection or no
link
Blinking Yellow Data Activity Yellow 5Gbps/2.5Gbps/1Gbps
connection
On Link Green 10Gbps connection
ACT/LIN K LE D SPEED LED
LAN Port
ACT/LIN K LE D SPEED LED
ACT/LINK LED
SPEED LE
D
LAN Port

TRX40D8-2N2T
12 13
English
1.7 Block Diagram
IPMI
COM header
ASPEED
AST2500
4x SATAIII
PCIeUSB
LPC
MAC
UART
RTL
8211E
MAC
VGA
RGMII
PCIe4.0 x8
1x USB2.0
PCIe2.0 x1
LPC/eSPI
SPI
D-Sub with Header
AMD
TRX40
BIOS
Switch
2xUSB3.1 Gen2, 2xUSB2.0
2xUSB3.1 Gen1,
2xUSB2.0
PCIe3.0x4
NCT6796D-
R
P_GPP [6]
PCIe2.0x1
PCIe2.0x1
C
DDDR4
DDR4DDR4
DDR4
A
B
3rd gen
AMD Ryzen™
Threadripper™
Series Processor
Socket sTRX4
TDP: max. 280W
G0
PCIe4.0x16
SLOT4 x8
PCIe4.0x16
PCIe4.0x16
2xUSB3.1 Gen1, 2xUSB2.0
NCSI
SLOT4 x8
SLOT7 x16
I225 I225
PCIe4.0x4
SLOT3 x16
PCIe4.0x8
2xUSB2.0
ASM
1061
PCIe2.0 x1
SLOT1 x8 SLOT5 x16
PS2 KB/MS
1xUSB3.1 Gen1, 1xUSB2.0
X710
-AT210GbE
10GbE
Oculink (BOM option)
TPM
TRX40D8-2N2T
AUX
PANEL
IPMB
Buzzer
PCIe4.0x4
2.5GbE
2.5GbE
P0 P2
G2
SATA [0:3]
P_GPP [12:15]
SATA [4:7]
P_GPP [8:11] SATA [8:11]
P_GPP [0:3]
P_GPP [4] P_GPP [5] P_GPP [7]

14 15
English
Chapter 2 Installation
is is an ATX form factor (12” x 9.6”, 30.5 cm x 24.4 cm) motherboard. Before you install
the motherboard, study the conguration of your chassis to ensure that the motherboard
ts into it.
2.1 Screw Holes
Place screws into the holes indicated by circles to secure the motherboard to the chassis.
Make sure to unplug the power cord before installing or removing the motherboard. Failure
to do so may cause physical injuries to you and damages to motherboard components.
Remove the standoff
from the chassis
Rear I/O
Attention! Before installing this motherboard, be sure to unscrew and remove the stando
at the marked location, under the motherboard, from the chassis, in order to avoid electri-
cal short circuit and damage to your motherboard.
