Chapter 1 Introduction
ank you for purchasing ASRock Rack Z490D4U-2L2T / W480D4U-2L2T /
W480D4U-V1L / motherboard, a reliable motherboard produced under ASRock
Rack’s consistently stringent quality control. It delivers excellent performance with
robust design conforming to ASRock Rack’s commitment to quality and endurance.
1.1 Package Contents
• ASRock Rack Z490D4U-2L2T / W480D4U-2L2T / W480D4U-V1L / W480D4U
Motherboard (mATX Form Factor: 9.6-in x 9.6-in, 24.4 cm x24.4 cm)
• Quick Installation Guide
• 1 x SATA3 Cable (60cm)
• 1 x I/O Shield
• 2 x Screws for M.2 Sockets
If any items are missing or appear damaged, contact your authorized dealer.
Because the motherboard specications and the BIOS soware might be updated, the con-
tent of this manual will be subject to change without notice. In case any modications of
this manual occur, the updated version will be available on ASRock Rack website without
further notice. You may nd the latest memory and CPU support lists on ASRock Rack
website as well. ASRock Rack’s Website: www.ASRockRack.com
If you require technical support related to this motherboard, please visit our website for
specic information about the model you are using.
http://www.asrockrack.com/support/

2 3
English
1.2 Specications
Z490D4U-2L2T / W480D4U-2L2T / W480D4U-V1L / W480D4U
MB Physical Status
Form Factor mATX
Dimension 9.6'' x 9.6'' (24.4 cm x24.4 cm)
Processor System
CPU Z490D4U-2L2T:
Supports Intel® 10th Gen. Core™ i9/i7/i5/i3, Pentium, Celeron
Series Processors
W480D4U-2L2T / W480D4U-V1L / W480D4U:
Supports Intel® 10th Gen. Core™ i9/i7/i5/i3 and Xeon W series
CPU
Chipset Intel® Z490 / W480
System Memory
Capacity - 4 x 288-pin DDR4 DIMM slots
- Support up to 128GB DDR4 non-ECC UDIMM
Type Z490D4U-2L2T:
- Dual Channel DDR4 memory technology
- Supports DDR4 non-ECC UDIMM
W480D4U-2L2T / W480D4U-V1L / W480D4U:
- Dual Channel DDR4 memory technology
- Supports DDR4 ECC-DIMM and non-ECC U DIMM
DIMM Size Per
DIMM
Non-ECC UDIMM : 32GB, 16GB, 8GB, 4GB
ECC UDIMM : 32GB, 16GB, 8GB, 4GB
DIMM
Frequency
Non-ECC UDIMM: 2933*/2666/2400 MHz
* CoreTM (i9/i7) support DDR4 up to 2933; CoreTM (i5/i3), Pentium® and
Celeron® support DDR4 up to 2666.
Voltage 1.2V
Expansion Slot
PCIe 3.0 x16 Slot 6: Gen3 x16 link, auto switch to x8 link if Slot 4 is
occupied (Physical x16, EE x16/x8 (from CPU), shared with
Slot 4)
PCIe 3.0 x8 Slot 4: Gen3 x8 link (Physical x8, EE x0/x8 (from CPU),
shared with Slot 6)
PCIe 3.0 x1 Slot 7: Gen3 x1 link (Physical x1, EEx1 (from PCH))
Storage
SATA
Controller
Z490D4U-2L2T:
6 x SATA3 6Gb/s (SATA0-5, SATA_0 supports SATA DOM)
W480D4U-2L2T / W480D4U-V1L / W480D4U:
8 x SATA3 6Gb/s (SATA0-7, SATA_0 supports SATA DOM)

Z490D4U-2L2T / W480D4U Series
2 3
English
Ethernet
Interface Z490D4U-2L2T / W480D4U-2L2T:
10000/1000 /100 Mbps
W480D4U-V1L /W480D4U:
1000/100 /10 Mbps
LAN Z490D4U-2L2T / W480D4U-2L2T / W480D4U:
- 2 x RJ45 GLAN by Intel® i210
W480D4U-V1L:
- 1 x RJ45 GLAN by Intel® i210
Z490D4U-2L2T / W480D4U-2L2T:
- 2 x RJ45 10G base-T by Intel® X710-AT2
Z490D4U-2L2T / W480D4U-2L2T / W480D4U-V1L /
W480D4U:
- 1 x RJ45 Dedicated IPMI LAN port by RTL8211E
- Supports Wake-On-LAN
- Supports Energy Ecient Ethernet 802.3az
- Supports Dual LAN with Teaming function
- Supports PXE
- LAN1 supports NCSI
Management
BMC Controller Z490D4U-2L2T / W480D4U-2L2T / W480D4U:
ASPEED AST2500
W480D4U-V1L:
ASPEED AST2510
IPMI Dedicated
GLAN
1 x Realtek RTL8211E for dedicated management GLAN
Features - Watch Dog
- NMI
Graphics
Controller ASPEED AST2500
VRAM DDR4 256MB
Rear Panel I/O
VGA Port 1 x D-Sub
USB 3.1 Port 2 (Gen2), 2(Gen1)
HDMI Port 1
LAN Port - 4 or 2 +1 RJ45 Gigabit Ethernet LAN ports
- LAN Ports with LED (ACT/LINK LED and SPEED LED)
UID Button/
LED
1
Serial port 1

4 5
English
Internal Connector
Auxiliary Panel
Header
1 (includes chassis intrusion, location button & LED, and
front LAN LED)
Front Panel 1 (RST, PWRBTN, HDDLED, PWRLED)
SATA DOM 1
TPM Header 1
SPI TPM Header 1
IPMB Header 1
Fan Header 7 (1CPU/4Front/2Rear)
ATX Power 1x (24-pin) + 1x (8-pin)+ 1x (4-pin)
TR1 1
Buzzer 1
USB 3.1 Gen1
Header
1 (supports 2 USB 3.1 Gen1 ports)
USB 2.0 Header 1 (supports 2 USB 2.0 ports)
M.2 2 (M2_1: 2260/2280/22110, Supports PCIE3.0(x4);
M2_2:2260/2280, Supports PCIE3.0(x4))*
*e M.2 slot (M2_2) is shared with the PCIE5 slot (BOM option). When
M2_2 is populated with a M.2 PCIe module, PCIE5 is disabled.
ME/SPS
Recovery
1
BMC_SMB_1 1
PSU_SMB1 1
SGPIO 1
Front VGA 1
Front LAN LED 1
NMI Button 1
80 Debug Port
LED
1
ClearCMOS 1 (short pin)
OH/FanFail
LED
7 (header)
System BIOS
BIOS Ty pe 256 Mb AMI UEFI Legal BIOS
BIOS Features - Plug and Play (PnP)
- ACPI 2.0 Compliance Wake Up Events
- SMBIOS 2.8.0 Support
- ASRock Rack Instant Flash
Hardware Monitor
Temperature - CPU Temperature Sensing
- MB/Card side/TR1 Temperature Sensing

Z490D4U-2L2T / W480D4U Series
4 5
English
is motherboard supports Wake from on Board LAN. To use this function, please make
sure that the “Wake on Magic Packet from power o state” is enabled in Device Manager
> Intel® Ethernet Connection > Power Management. And the “PCI Devices Power On” is
enabled in UEFI SETUP UTILITY > Advanced > ACPI Conguration. Aer that, onboard
LAN1&2 can wake up S5 under OS.
If you install Intel® LAN utility or Marvell SATA utility, this motherboard may fail Win-
dows® Hardware Quality Lab (WHQL) certication tests. If you install the drivers only, it
will pass the WHQL tests.
Fan - Chassis Fan Tachometer
- CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by
CPU Temperature)
- CPU/Rear/Front Fan Multi-Speed Control
Voltage Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM,
V1.0M,+BAT, 3VSB, 5VSB
Support OS
OS Microso® Windows®
- Server 2016 (64 bit)
- Server 2019 (64 bit)
Linux®
- RedHat Enterprise Linux Server 6.9 (64 bit) / 7.4 (64 bit)
- SUSE Enterprise Linux Server 12 SP1 (64 bit) /
12 SP3 (64 bit)
- Ubuntu 15.10 (64 bit) / 16.04 (64 bit)
Virtual
- VMWare® ESXi 6.5 u1
- Win hyper-V Server 2016
* HDMI port (E3C246D4U2-2L2T ) OS installation on Linux is only
supported for RedHat Enterprise Linux Server 6.9 (64 bit).
*Please refer to our website for the latest OS support list.
Environment
Temperature Operation temperature: 10°C ~ 35°C / Non operation
temperature: -40°C ~ 70°C

6 7
English
1.3 Unique Features
ASRock Rack Instant Flash is a BIOS ash utility embedded in Flash ROM. is con-
venient BIOS update tool allows you to update system BIOS without entering operat-
ing systems rst like MS-DOS or Windows®. With this utility, you can press the <F6>
key during the POST or the <F2> key to enter into the BIOS setup menu to access
ASRock Rack Instant Flash. Just launch this tool and save the new BIOS le to your
USB ash drive, oppy disk or hard drive, then you can update your BIOS only in a
few clicks without preparing an additional oppy diskette or other complicated ash
utility. Please be noted that the USB ash drive or hard drive must use FAT32/16/12
le system.

Z490D4U-2L2T / W480D4U Series
6 7
English
1.4 Motherboard Layout
DDR3_B1 (64 bit, 240-pin module)
DDR3_A1 (64 bit, 240-pin module)
24.4cm (9.6 in)
ATXPWR1
COM1
VGA1
BMC
LAN1
IPMI
LAN
DDR4_B2 (64 bit, 288-pin module)
DDR4_B1 (64 bit, 288-pin module)
DDR3_B1 (64 bit, 240-pin module)
DDR3_A1 (64 bit, 240-pin module)
DDR4_A2 (64 bit, 288-pin module)
DDR4_A1 (64 bit, 288-pin module)
PCIE6
PCIE7
PCIE4
BAT1
1
PSU_SMB1
ATX12V1
SATA_SGPIO1
1
SATA_1
1
USB3_1_2
SATA_0
PANEL1
AUX_PANEL1
HDLED RESET
PLED PWRBTN
1
11
FRONT_LED_LAN34
1
IPMB_1
BMC_SMB_1
1
USB_1_2
1
CHASSIS_ID2
1
UID1
24.4cm (9.6 in)
Intel
Z490/
W480
BIOS
ROM
145
3
6
CHASSIS_ID0
1
T 1
1
Super
I/O
R
M2_2
NUT60_2 NUT80_2
7
8
19
20
42
RoHS
Z490D4U-2L2T/
W480D4U-2L2T/
W480D4U-V1L/
W480D4U
43
46
1
SEC_OR1
1
1
CHASSIS_ID1
1
PECI1
1
1
PWM_CFG1
LAN2
10
11
12
13
14
21
29
30
34
36
37
39
41
44
35
USB 3.1 Gen2
T: USB31_1
B: USB31_2
USB 3.1 Gen1
T: USB31_3
B: USB31_4
HDMI1
SATA_ 3
Dr. Debug
LAN3
LAN4
1
FRNT_VGA1
2
9
1
SPEAKER1
15
16
17
18
SATA_ 2
SATA_ 5
SATA_ 4
1
SPI_TPM_J1
NMI_BTN1
ME_RECOVERY1
TPM1
1
BUZZER1
M2_1
NUT110_1 NUT80_1 NUT60_1
ATX12V2
22
23
24
27
BMC
ROM
31
33 32
45
38
CLRMOS1
40
1
SATA_PWR1
28
X710-AT2
i210
i210
SATA_ 7
SATA_ 6
25
26
(Not supported for
W480D4U-V1L)
(Not supported for
W480D4U-V1L)
(Z490D4U2L2T /
W480D4U2L2T only)
(SATA_6 ~ SATA_7:
Not supported for
Z490D4U-2L2T)
(Z490D4U2L2T /
W480D4U2L2T only)
(Z490D4U2L2T /
W480D4U2L2T only)
FAN1
FAN2
FAN3
FAN4
FAN5
FAN6
FAN7

8 9
English
No. Description
1 Front VGA Header (FRNT_VGA1)
2 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1, Blue)
3PSU SMBus (PSU_SMB1)
4 ATX Power Connector (ATXPWR1)
5 2 x 288-pin DDR4 DIMM Slots (DDR4_A2, DDR4_B2, White)
6 Chassis Fan Connector (FAN1)
7 Chassis Fan Connector (FAN2)
8 Chassis Fan Connector (FAN3)
9 Chassis Fan Connector (FAN4)
10 Chassis ID0 Jumper (CHASSIS_ID0)
11 Security Override Jumper (SEC_OR1)
12 Chassis ID1 Jumper (CHASSIS_ID1)
13 Chassis ID2 Jumper (CHASSIS_ID2)
14 CPU PECI Mode Jumper (PECI1)
15 Chassis Speaker Header (SPEAKER1)
16 Chassis Fan Connector (FAN5)
17 Chassis Fan Connector (FAN6)
18 Chassis Fan Connector (FAN7)
19 SATA3 Connector (SATA_1)
20 USB 3.1 Gen1 Header (USB3_1_2)
21 SATA3 Connector (SATA_2)
22 SATA3 Connector (SATA_3)
23 SATA3 Connector (SATA_4)
24 SATA3 Connector (SATA_5)
25 SATA3 Connector (SATA_6) (Not supported for Z490D4U-2L2T)
26 SATA3 Connector (SATA_7) (Not supported for Z490D4U-2L2T)
27 SATA3 DOM Connector (SATA_0), Red
28 SATA DOM Power Connector (SATA_PWR1)
29 System Panel Header (PANEL1)
30 Auxiliary Panel Header (AUX_PANEL1)
31 Non Maskable Interrupt Button (NMI_BTN1)
32 SPI TPM Header (SPI_TPM_J1)
33 Front LAN LED Connector (FRONT_LED_LAN34)

Z490D4U-2L2T / W480D4U Series
8 9
English
No. Description
34 USB 2.0 Header (USB_1_2)
35 SATA SGPIO Connector (SATA_SGPIO1)
36 ME Recovery Jumper (ME_RECOVERY1)
37 BMC SMBus Header (BMC_SMB_1)
38 Intelligent Platform Management Bus Header (IPMB_1)
39 TPM Header (TPM1)
40 Clear CMOS Pad (CLRMOS1)
41 ermal Sensor Header (TR1)
42 M.2 Socket (M2_2) (Type 2260/2280)
43 M.2 Socket (M2_1) (Type 2260/2280/22110)
44 PWM Conguration Header (PWM_CFG1)
45 ATX 12V Power Connector (ATX12V2)
46 ATX 12V Power Connector (ATX12V1)

10 11
English
1.5 Onboard LED Indicators
DDR3_B1 (64 bit, 240-pin module)
DDR3_A1 (64 bit, 240-pin module)
DDR4_B2 (64 bit, 288-pin module)
DDR4_B1 (64 bit, 288-pin module)
DDR3_B1 (64 bit, 240-pin module)
DDR3_A1 (64 bit, 240-pin module)
DDR4_A2 (64 bit, 288-pin module)
DDR4_A1 (64 bit, 288-pin module)
1
1
Intel
Z490
RoHS
Z490D4U-2L2T
1
1
2
3
4
5
6
7
8
9

Z490D4U-2L2T / W480D4U Series
10 11
English
No. Item Status Description
1 SB_PWR1 Green STB PWR ready
2FAN1_LED1 Amber FAN1 failed
3FAN2_LED1 Amber FAN2 failed
4FAN3_LED2 Amber FAN3 failed
5FAN4_LED4 Amber FAN4 failed
6FAN5_LED2 Amber FAN5 failed
7FAN6_LED1 Amber FAN6 failed
8FAN7_LED3 Amber FAN7 failed
9BMC_LED1 Green BMC heartbeat LED

12 13
English
1.6 I/O Panel
8
7
4
3
210
6
15
911
No. Description No. Description
1 UID Switch (UID1) 7 10G LAN RJ-45 Port (LAN2)**
(Z490D4U-2L2T /W480D4U-2L2T only)
2VGA Port (VGA1) 8 USB 3.1 Gen2 Ports (USB31_1_2)
3 Serial Port (COM1) 9 1G LAN RJ-45 Port (LAN3)***
4 LAN RJ-45 Port (IPMI_LAN)* 10 USB 3.1 Gen1 Ports (USB31_3_4)
5HDMI Port (HDMI) 11 1G LAN RJ-45 Port (LAN4)***
(Not supported for W480D4U-V1L)
610G LAN RJ-45 Port (LAN1)**
(Z490D4U-2L2T /W480D4U-2L2T only)
LAN Port LED Indications
*ere are two LED next to the LAN port. Please refer to the table below for the LAN port
LED indications.
Dedicated IPMI LAN Port LED Indications
Activity / Link LED Speed LED
Status Description Status Description
O No Link O 10M bps connection or no
link
Blinking Yellow Data Activity Yellow 100M bps connection
On Link Green 1Gbps connection
ACT/LINK LED
SPEED LED
LAN Port

Z490D4U-2L2T / W480D4U Series
12 13
English
**ere are two LEDs on each LAN port. Please refer to the table below for the LAN port
LED indications.
10G LAN Port LED Indications (Z490D4U-2L2T /W480D4U-2L2T only)
Activity / Link LED Speed LED
Status Description Status Description
O No Link O 100Mbps connection or
no link
Blinking Green Data Activity Yellow 1Gbps connection
On Link Green 10Gbps connection
***ere are two LEDs on each LAN port. Please refer to the table below for the LAN port
LED indications.
1G LAN Port LED Indications
Activity / Link LED Speed LED
Status Description Status Description
O No Link O 10Mbps connection or
no link
Blinking Orange Data Activity Yellow 100Mbps connection
On Link Green 1Gbps connection
SPEED LED
ACT/LINK LED
LAN Port
ACT/LINK LED
SPEED LED
LAN Port

14 15
English
1.7 Block Diagram
