ASROCK Rack X570D4U-2L2T User manual

X570D4U-2L2T
X570D4U
User Manual
Version 1.0
Published July 2020
Copyright©2020 ASRock Rack INC. All rights reserved.

Version 1.0
Published October 2020
Copyright©2020 ASRock Rack Inc. All rights reserved.
Copyright Notice:
No part of this documentation may be reproduced, transcribed, transmitted, or translated
in any language, in any form or by any means, except duplication of documentation by the
purchaser for backup purpose, without written consent of ASRock Rack Inc.
Products and corporate names appearing in this documentation may or may not be
registered trademarks or copyrights of their respective companies, and are used only for
identication or explanation and to the owners’ benet, without intent to infringe.
Disclaimer:
Specications and information contained in this documentation are furnished for
informational use only and subject to change without notice, and should not be
constructed as a commitment by ASRock Rack. ASRock Rack assumes no responsibility
for any errors or omissions that may appear in this documentation.
With respect to the contents of this documentation, ASRock Rack does not provide
warranty of any kind, either expressed or implied, including but not limited to the implied
warranties or conditions of merchantability or tness for a particular purpose.
In no event shall ASRock Rack, its directors, ocers, employees, or agents be liable for
any indirect, special, incidental, or consequential damages (including damages for loss of
prots, loss of business, loss of data, interruption of business and the like), even if ASRock
Rack has been advised of the possibility of such damages arising from any defect or error
in the documentation or product.
is device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
CALIFORNIA, USA ONLY
e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance
controlled in Perchlorate Best Management Practices (BMP) regulations passed by the
California Legislature. When you discard the Lithium battery in California, USA, please
follow the related regulations in advance.
“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/
perchlorate”
ASRock Rack’s Website: www.ASRockRack.com

Contact Information
If you need to contact ASRock Rack or want to know more about ASRock Rack, you’re
welcome to visit ASRock Rack’s website at www.ASRockRack.com; or you may contact
your dealer for further information.
ASRock Rack Incorporation
6F., No.37, Sec. 2, Jhongyang S. Rd., Beitou District,
Taipei City 112, Taiwan (R.O.C.)
e terms HDMI®and HDMI High-Denition Multimedia Interface, and the HDMI
logo are trademarks or registered trademarks of HDMI Licensing LLC in the United
States and other countries.

Contents
Chapter 1 Introduction 1
1.1 Package Contents 1
1.2 Specications 2
1.3 Unique Features 6
1.4 Motherboard Layout 7
1.5 Onboard LED Indicators 10
1.6 I/O Panel 12
1.7 Block Diagram 14
Chapter 2 Installation 16
2.1 Screw Holes 16
2.2 Pre-installation Precautions 16
2.3 Installing the CPU 17
2.4 Installing the CPU Fan and Heatsink 19
2.5 Installing Memory Modules (DIMM) 22
2.6 Expansion Slots (PCI Express Slots) 24
2.7 Jumpers Setup 26
2.8 Onboard Headers and Connectors 28
2.9 Dr. Debug 34
2.10 Unit Identication purpose LED/Switch 40
2.11 Driver Installation Guide 40
2.12 M.2_SSD (NGFF) Module Installation Guide (M2_1) 41
2.13 M.2_SSD (NGFF) Module Installation Guide (M2_2) 43

Chapter 3 UEFI Setup Utility 45
3.1 Introduction 45
3.1.1 UEFI Menu Bar 45
3.1.2 Navigation Keys 46
3.2 Main Screen 47
3.3 Advanced Screen 48
3.3.1 CPU Conguration 49
3.3.2 Chipset Conguration 50
3.3.3 Storage Conguration 52
3.3.4 ACPI Conguration 53
3.3.5 USB Conguration 54
3.3.6 Super IO Conguration 55
3.3.7 H/W Monitor 56
3.3.8 RAM Disk Conguration 57
3.3.9 Tls Auth Conguration 58
3.3.10 AMD PBS 59
3.3.11 AMD Overclocking 62
3.3.12 AMD CBS 63
3.3.13 Instant Flash 64
3.4 Server Mgmt 65
3.4.1 System Event Log 66
3.4.2 BMC Network Conguration 67
3.4.3 BMC Tools 69

3.5 Security 70
3.5.1 Key Management 71
3.6 Boot Screen 74
3.6.1 CSM Parameters 76
3.7 Exit Screen 78
Chapter 4 Software Support 79
4.1 Install Operating System 79
4.2 Support CD Information 79
4.2.1 Running The Support CD 79
4.2.2 Drivers Menu 79
4.2.3 Utilities Menu 79
4.2.4 Contact Information 79
Chapter 5 Troubleshooting 80
5.1 Troubleshooting Procedures 80
5.2 Technical Support Procedures 82
5.3 Returning Merchandise for Service 82

X570D4U-2L2T / X570D4U
PB 1
English
Chapter 1 Introduction
ank you for purchasing ASRock Rack X570D4U-2L2T/ X570D4U motherboard,
a reliable motherboard produced under ASRock Rack’s consistently stringent quality
control. It delivers excellent performance with robust design conforming to ASRock
Rack’s commitment to quality and endurance.
1.1 Package Contents
• ASRock Rack X570D4U-2L2T / X570D4U Motherboard
(micro-ATX Form Factor: 9.6-in x 9.6-in, 24.4 cm x 24.4 cm)
• Quick Installation Guide
• 1 x I/O Shield
• 1 x SATA3 Cable (60cm)
• 2 x Screws for M.2 Sockets
If any items are missing or appear damaged, contact your authorized dealer.
Because the motherboard specications and the BIOS soware might be updated, the con-
tent of this manual will be subject to change without notice. In case any modications of
this manual occur, the updated version will be available on ASRock Rack website without
further notice. You may nd the latest memory and CPU support lists on ASRock Rack
website as well. ASRock Rack’s Website: www.ASRockRack.com
If you require technical support related to this motherboard, please visit our website for
specic information about the model you are using.
http://www.asrockrack.com/support/

2 3
English
1.2 Specications
X570D4U-2L2T / X570D4U
MB Physical Status
Form Factor micro-ATX
Dimension 9.6'' x 9.6'' (24.4 cm x 24.4 cm)
Processor System
CPU AMD Ryzen™ PRO 3000 and 2000 Series Desktop Processors
3rd and 2nd Gen AMD Ryzen™ Desktop Processors
2nd and 1st Gen AMD Ryzen™ Desktop Processors with Radeon™
Vega Graphics
Socket AM4 PGA 1331
Chipset AMD X570
ermal Design
Power
105W
System Memory
Capacity - 4 x 288-pin DDR4 DIMM slots
- Support up to 128GB DDR4 ECC/UDIMM
Type - Dual Channel DDR4 memory technology
- Support DDR4 ECC/UDIMM
*Conditionally supports ECC error reporting function.
DIMM Size Per
DIMM
- ECC/UDIMM: 32GB, 16GB, 8GB
DIMM Frequency - ECC/UDIMM: up to 3200MHz
Voltage 1.2V
Expansion Slot
PCIe 3.0/4.0 x 16 Matisse:
PCIE6: Gen4 x16 link, auto switch to x8 link if Slot 4 is
occupied (Physical x16, EE x16/x8, shared with Slot 4)
Picasso:
PCIE6: Gen3 x8 link (Physical x16, EE x8)
Renoir:
PCIE6: Gen3 x16 link, auto switch to x8 link if Slot 4 is
occupied (Physical x16, EE x16/x8, shared with Slot 4)
PCIe 3.0/4.0 x 8 Matisse:
PCIE4: Gen4 x8 link (Physical x8, EE x0/x8, shared with Slot 6)
Picasso:
PCIE4: N/A (not supported)
Renoir:
PCIE4: Gen3 x8 link (Physical x8, EE x0/x8, shared with Slot 6)

X570D4U-2L2T / X570D4U
2 3
English
PCIe 3.0/4.0 x 1 Matisse:
PCIE5: Gen4 x1 link
Picasso:
PCIE5: Gen3 x1 link
Renoir:
PCIE5: Gen3 x1 link
Storage
SATA Controller 8 x SATA3 6.0 Gb/s (SATA0-7, SATA_0 supports SATA DOM),
support RAID 0, 1, 10
M.2 Slot 2 (M2_1: 2242/2260/2280/22110, supports SATA3 (6.0 Gb/s) or
PCIE4.0(x4)(Matisse) / PCIE3.0(Renoir/Picasso)(x4) ;
M2_2: 2242/2260/2280, supports SATA3 (6.0 Gb/s) or
PCIE4.0(x4)(Matisse) / PCIE3.0(Renoir/Picasso)(x4)
Ethernet
Interface X570D4U-2L2T:
10000/1000 /100 /10 Mbps
X570D4U:
1000 /100 /10 Mbps
LAN Controller X570D4U-2L2T:
- 2 x RJ45 10G base-T by Intel® X550-AT2
- 2x RJ45 1G base-T by Intel® I210-AT
- 1 x RJ45 Dedicated IPMI LAN port by RTL8211E
- Supports Wake-On-LAN
- Supports Energy Ecient Ethernet 802.3az
- Supports Dual LAN with Teaming function
- Supports PXE
- LAN3 supports NCSI
X570D4U:
- 2x RJ45 1G base-T by Intel® I210-AT
- 1 x RJ45 Dedicated IPMI LAN port by RTL8211E
- Supports Wake-On-LAN
- Supports Energy Ecient Ethernet 802.3az
- Supports Dual LAN with Teaming function
- Supports PXE
- LAN1 supports NCSI
Management
BMC Controller ASPEED AST2500
IPMI Dedicated
GLAN
1 x Realtek RTL8211E for dedicated management GLAN
Features Watch Dog
Graphics
Controller ASPEED AST2500

4 5
English
VRAM DDR4 16MB
Rear Panel I/O
VGA Port 1 x D-Sub
Serial Port 1 x COM port
USB 3.2 (Gen2)
Port
2
HDMI 1 (only supported for Picasso(APU))
LAN Port X570D4U-2L2T:
- 2 x RJ45 1 Gigabit Ethernet LAN ports
- 2 x RJ45 10 Gigabit Ethernet LAN ports
- 1 x RJ45 Dedicated IPMI LAN port
- LAN Ports with LED (ACT/LINK LED and SPEED LED)
X570D4U:
- 2 x RJ45 1 Gigabit Ethernet LAN ports
- 1 x RJ45 Dedicated IPMI LAN port
- LAN Ports with LED (ACT/LINK LED and SPEED LED)
UID 1
Internal Connector
Auxiliary Panel
Header
1 (includes chassis intrusion, location button & LED, front
LAN LED, system fault, and BMC alert)
Front Panel 1 (RST, PWRBTN, HDDLED, PWRLED)
TPM Header 1 (17-pin LPC TPM header, supports TPM 1.2/2.0)
SPI TPM Header 1 (13-pin SPI TPM header, supports TPM 2.0)
IPMB Header 1
Fan Header 3 (6-pin), 3 (4-pin)
ATX Power 1 x (24-pin) + 1 x (4-pin)
USB 3.2 Gen1
Header
1 (supports 2 USB 3.2 Gen1 ports)
M.2 2
SATA DOM 1
BMC_SMB1 1
PSU_SMB1 1
SPEAKER 1
TR1 1
Front VGA 1
Front LAN LED X570D4U-2L2T: 1
X570D4U: N/A
80 debug port LED 1
Buzzer 1
Clear CMOS 1 (short pad)

X570D4U-2L2T / X570D4U
4 5
English
is motherboard supports Wake from on Board LAN. To use this function, please make
sure that the “Wake on Magic Packet from power o state” is enabled in Device Manager
> Intel® Ethernet Connection > Power Management. And the “PCI Devices Power On” is
enabled in UEFI SETUP UTILITY > Advanced > ACPI Conguration. Aer that, onboard
LAN3&4 can wake up S5 under OS.
If you install Intel® LAN utility or Marvell SATA utility, this motherboard may fail Win-
dows® Hardware Quality Lab (WHQL) certication tests. If you install the drivers only, it
will pass the WHQL tests.
OH/FanFail LED 6
System BIOS
BIOS Ty pe 32MB AMI UEFI Legal BIOS
BIOS Features - Plug and Play (PnP)
- ACPI 2.0 Compliance Wake Up Events
- SMBIOS 2.8 Support
- ASRock Rack Instant Flash
Hardware Monitor
Temperature - CPU/FCH/DDR/LAN* Temperature Sensing
- MB/Card Side Temperature Sensing
*LAN Temperature Sensing is supported for X570D4U-2L2T only.
Fan - Fan Tachometer
- Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by CPU
Temperature)
- Fan Multi-Speed Control
Voltage Voltage Monitoring: 3VSB, 5VSB, VCPU, VSOC, VCCM, APU
VDDP, PM VDD CLDO, PM VDDCR S5, PM VDDCR, BAT,
3V, 5V, 12V
Support OS
OS Microso® Windows®:
Windows 10 (64 bit)
Linux®:
- UBuntu 18.04 (64 bit)
- RedHat Enterprise Linux Server 8.1 (64bit)
* Please refer to our website for the latest OS support list.
* e Linux system doesn’t support Raid mode.
* Supports UEFI BOOT only.
Environment
Temperature Operation temperature: 10°C ~ 35°C / Non operation
temperature: -40°C ~ 70°C
NOTE: Please refer to our website for the latest specications.

6 7
English
1.3 Unique Features
ASRock Rack Instant Flash is a BIOS ash utility embedded in Flash ROM. is con-
venient BIOS update tool allows you to update system BIOS without entering operat-
ing systems rst like MS-DOS or Windows®. With this utility, you can press the <F6>
key during the POST or the <F2> key to enter into the BIOS setup menu to access
ASRock Rack Instant Flash. Just launch this tool and save the new BIOS le to your
USB ash drive, oppy disk or hard drive, then you can update your BIOS only in a
few clicks without preparing an additional oppy diskette or other complicated ash
utility. Please be noted that the USB ash drive or hard drive must use FAT32/16/12
le system.

X570D4U-2L2T / X570D4U
6 7
English
1.4 Motherboard Layout
24.4cm (9.6 in)
24.4cm (9.6 in)
ATXPWR1
VGA1
COM1
DDR4_A2 (64 bit, 288-pin module)
DDR4_A1 (64 bit, 288-pin module)
DDR4_B2 (64 bit, 288-pin module)
DDR4_B1 (64 bit, 288-pin module)
ATX12V3
USB 3.2
Gen1
T: USB3_2
B: USB3_1
IPMI_LAN
UID1
USB3_3_4
PCIE5
PCIE6
PCIE4
M2_2
M2_1
NUT42_2
NUT80_2
X570D4U-2L2T /
X570D4U
BMC
ROM
Socket
AM4 PGA 1331
1
PSU_SMB1
FAN3
NUT42_1
NUT60_1
NUT80_1
NUT110_1
CLRCMOS1
1
AUX_PANEL1
HDLED RESET
PLED PWRBTN
PANEL1
1
Dr.
Debug
TPM1
1
SPEAKER1
1
CHASSIS_ID1
1
1
IPMB_1
BMC_SMB_1
BUZZER1
RoHS
23 1 4
8
7
9
10
11
12
13
14
16
17
18
19
20
15
21222325
2930
313233
LAN3 LAN4
LAN2
LAN1
HDMI1
1
LED_LAN_3_4
1
FRNT_VGA1
BAT1
FAN4
FAN5
FAN6
SATA_0
SATA_1
X550
SATA_ 2
SATA_ 3
SATA_ 4
SATA_ 5
SATA_7
SATA_6
FAN1
1
FAN2
Super
I/O
1
TPM_BIOS_PH1
1
SATAPWR1
BIOS
ROM
T 1
R
1
1
CHASSIS_ID2
1
CHASSIS_ID3
5
6
AMD
X570
24262728
34
35
36
ASPEED
2500
NUT60_2
(X570D4U-2L2T only)
(X570D4U-2L2T only)
(X570D4U-2L2T only)(X570D4U-2L2T only)

8 9
English
No. Description
1 ATX 12V Power Connector (ATX12V3)
2 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1, Blue)*
3 PSU SMBus Header (PSU_SMB1)
4 ATX Power Connector (ATXPWR1)
5 System Fan Connector (4-pin) (FAN3)
6 System Fan Connector (6-pin) (FAN4)
7 System Fan Connector (6-pin) (FAN5)
8 2 x 288-pin DDR4 DIMM Slots (DDR4_A2, DDR4_B2, White)*
9 System Fan Connector (6-pin) (FAN6)
10 SATA DOM Power Connector (SATAPWR1)
11 AM4 PGA 1331 Socket
12 M.2 Socket (M2_2) (Type 2242 / 2260 / 2280)
13 SATA3 DOM Connector (SATA_0), Red
14 USB 3.2 Gen1 Header (USB3_3_4)
15 SATA3 Connector (SATA_1)
16 M.2 Socket (M2_1) (Type 2242 / 2260 / 2280 / 22110)
17 SATA3 Connector (SATA_3)(Upper), SATA3 Connector (SATA_2)(Lower)
18 TPM-SPI Header (TPM_BIOS_PH1)
19 SATA3 Connector (SATA_5)(Upper), SATA3 Connector (SATA_4)(Lower)
20 SATA3 Connector (SATA_7)
21 SATA3 Connector (SATA_6)
22 ermal Sensor Header (TR1)
23 System Panel Header (PANEL1)
24 Auxiliary Panel Header (AUX_PANEL1)
25 Clear CMOS Pad (CLRMOS1)
26 System Fan Connector (4-pin) (FAN1)
27 System Fan Connector (4-pin) (FAN2)
28 TPM Header (TPM1)
29 Chassis ID1 Jumper (CHASSIS_ID1) (Reserved for BOM option)
30 Speaker Header (SPEAKER1)
31 BMC SMBus Header (BMC_SMB_1)
32 Intelligent Platform Management Bus Header (IPMB_1)
33 Chassis ID2 Jumper (CHASSIS_ID2) (Reserved for BOM option)

X570D4U-2L2T / X570D4U
8 9
English
No. Description
34 Chassis ID3 Jumper (CHASSIS_ID3) (Reserved for BOM option)
35 Front LAN LED Connector (LED_LAN_3_4) (X570D4U-2L2T only)
36 Front VGA Header (FRNT_VGA1)
*For DIMM installation and conguration instructions, please see p.21 (Installation of Memory Modules
(DIMM)) for more details.

10 11
English
1.5 Onboard LED Indicators
ATXPWR1
DDR4_A2 (64 bit, 288-pin module)
DDR4_A1 (64 bit, 288-pin module)
DDR4_B2 (64 bit, 288-pin module)
DDR4_B1 (64 bit, 288-pin module)
ATX12V3
PCIE4
ASPEED
2500
X570D4U-2L2T
BMC
ROM
Socket
AM4 PGA 1331
FAN3
11
1
1
IPMB_1
BMC_SMB_1
RoHS
1
FAN4
FAN5
FAN6
FAN1
1
FAN2
BIOS
ROM
1
CHASSIS_ID2
1
CHASSIS_ID3
AMD
X570
2
3
4
1
5
6
7
8

X570D4U-2L2T / X570D4U
10 11
English
No. Item Status Description
1 SB_PWR1 Green STB PWR ready
2FAN_LED3 Amber FAN3 failed
3FAN_LED4 Amber FAN4 failed
4FAN_LED5 Amber FAN5 failed
5FAN_LED6 Amber FAN6 failed
6FAN_LED1 Amber FAN1 failed
7FAN_LED2 Amber FAN2 failed
8BMC_LED1 Green BMC heartbeat LED

12 13
English
1.6 I/O Panel
57
3
2
18
6 9
4
10
No. Description No. Description
1VGA Port (VGA1) 6 LAN RJ-45 Port (IPMI_LAN1)*
2 Serial Port (COM1) 7 HDMI Port
3 1G LAN RJ-45 Port (LAN1) 8 10G LAN RJ-45 Port (LAN3)**
(X570D4U-2L2T only)
4 1G LAN RJ-45 Port (LAN2) 9 10G LAN RJ-45 Port (LAN4)**
(X570D4U-2L2T only)
5 USB 3.2 Gen2 Ports (USB3_1_2) 10 UID Switch (UID1)
*ere are two LED next to the LAN port. Please refer to the table below for the LAN port
LED indications.
Dedicated IPMI LAN Port LED Indications
Activity / Link LED Speed LED
Status Description Status Description
O No Link O 10M bps connection or no
link
Blinking Yellow Data Activity Yellow 100M bps connection
On Link Green 1Gbps connection
ACT/LINK LED
SPEED LED
LAN Port

X570D4U-2L2T / X570D4U
12 13
English
**ere are two LEDs on each LAN port. Please refer to the table below for the LAN port
LED indications.
10G LAN Port (LAN3, LAN4) LED Indications (X570D4U-2L2T only)
Activity / Link LED Speed LED
Status Description Status Description
O No Link O 10M/100Mbps
connection or no link
Blinking Yellow Data Activity Orange 1Gbps connection
On Link Green 10Gbps connection
1G LAN Port (LAN1, LAN2) LED Indications
Activity / Link LED Speed LED
Status Description Status Description
O No Link O 10Mbps connection or
no link
Blinking Orange Data Activity Yellow 100Mbps connection
On Link Green 1Gbps connection
ACT/LIN K LE D SPEED LED
LAN Port
ACT/LIN K LE D SPEED LED
ACT/LIN K LE D SPEED LED
LAN Port
ACT/LIN K LE D SPEED LED

14 15
English
1.7 Block Diagram
X570D4U-2L2T:
IPMI
ASPEED
AST25 00
PCIeUSB
MAC
U AR T
RTL
8211E
MAC
VGA
RGMII
USB2.0
PCIe2.0 x1
LPC/eSPI
SPI
D-Sub
AMD
X570
BXB-C
BIOS
32MB
Switch
2xUSB3.2 Gen2
2xUSB2.0
2xUSB3.2Gen1 2xUSB2.0
NCT6796D-R
PCIe3.0x4
DDR4 DDR4
A
B
AMD Ryzen™
Processor
AMD AM4 Socket
PGA 1331
TDP: max. 105W
PCIe4.0x8
NCSI
PCIe4.0 x4/SATAIII
LPC
Upstream Link PCIe4.0x4
X550
-AT2
HDMI
i210 i210
PCIe2.0x1 PCIe2.0x1
PCIe4.0 x4/SATAIII
MUX
SLOT4 x8
SLOT6 x16
PCIe4.0x8
SLOT5 x1
Share NIC
8x SATAIII
PCIe4.0 x1
COM port
