ASROCK 775VM800Pro-DDR2 User manual

11
11
1
775VM800Pro-DDR2
User Manual
Version 1.0
Published September 2005
Copyright©2005 ASRock INC. All rights reserved.

22
22
2
Copyright Notice:Copyright Notice:
Copyright Notice:Copyright Notice:
Copyright Notice:
No part of this manual may be reproduced, transcribed, transmitted, or translated in
any language, in any form or by any means, except duplication of documentation by
the purchaser for backup purpose, without written consent of ASRock Inc.
Products and corporate names appearing in this manual may or may not be regis-
tered trademarks or copyrights of their respective companies, and are used only for
identification or explanation and to the owners’ benefit, without intent to infringe.
Disclaimer:Disclaimer:
Disclaimer:Disclaimer:
Disclaimer:
Specifications and information contained in this manual are furnished for informa-
tional use only and subject to change without notice, and should not be constructed
as a commitment by ASRock. ASRock assumes no responsibility for any errors or
omissions that may appear in this manual.
With respect to the contents of this manual, ASRock does not provide warranty of
any kind, either expressed or implied, including but not limited to the implied warran-
ties or conditions of merchantability or fitness for a particular purpose.
In no event shall ASRock, its directors, officers, employees, or agents be liable for
any indirect, special, incidental, or consequential damages (including damages for
loss of profits, loss of business, loss of data, interruption of business and the like),
even if ASRock has been advised of the possibility of such damages arising from any
defect or error in the manual or product.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
ASRock Website: http://www.asrock.com

33
33
3
ContentsContents
ContentsContents
Contents
1. Introduction1. Introduction
1. Introduction1. Introduction
1. Introduction ....................................................................................................
....................................................................................................
.................................................. 55
55
5
1.1 Package Contents.......................................................... 5
1.2 Specifications ................................................................ 6
1.3 Motherboard Layout ...................................................... 9
1.4 ASRock I/O PlusTM ................................................................................................. 10
2. Installation2. Installation
2. Installation2. Installation
2. Installation ........................................................................................................
........................................................................................................
.................................................... 1111
1111
11
2.1 Screw Holes ................................................................. 11
2.2 Pre-installation Precautions........................................... 11
2.3 CPU Installation .............................................................. 12
2.4 Installation of CPU Fan and Heatsink ............................ 14
2.5 Installation of Memory Modules (DIMM)......................... 15
2.6 Expansion Slots (PCI,AMR, and AGP Slots)................. 16
2.7 Jumpers Setup .............................................................. 17
2.8 Onboard Headers and Connectors .............................. 18
2.9 Serial ATA (SATA) Hard Disks Installation ..................... 21
2.10 Hot Plug and Hot Swap Functions for SATAHDDs .... 21
2.11 Installing Windows 2000 / Windows XP / Windows XP
64-bit With RAID Functions.......................................... 22
2.12 Installing Windows 98 / ME / 2000 / XP / XP 64-bit
Without RAID Functions ................................................23
3. BIOS S3. BIOS S
3. BIOS S3. BIOS S
3. BIOS SETUP UTILITYETUP UTILITY
ETUP UTILITYETUP UTILITY
ETUP UTILITY ..................................................................................
..................................................................................
......................................... 2424
2424
24
3.1 Introduction .................................................................... 24
3.1.1 BIOS Menu Bar .................................................... 24
3.1.2 Navigation Keys ................................................... 25
3.2 Main Screen................................................................... 25
3.3 Advanced Screen ......................................................... 25
3.3.1 CPU Configuration................................................ 26
3.3.2 Chipset Configuration .......................................... 28
3.3.3 ACPI Configuration ............................................... 32
3.3.4 IDE Configuration ................................................. 33
3.3.5 PCIPnP Configuration ........................................... 35
3.3.6 Floppy Configuration ........................................... 35
3.3.7 Super IO Configuration ........................................ 36
3.3.8 USB Configuration ............................................... 37
3.4 Hardware Health Event Monitoring Screen .................. 38
3.5 Boot Screen................................................................... 38
3.5.1 Boot Settings Configuration.................................. 39
3.6 Security Screen ............................................................ 40
3.7 Exit Screen .................................................................... 41

44
44
4
4. Software Support4. Software Support
4. Software Support4. Software Support
4. Software Support....................................................................................
....................................................................................
.......................................... 4242
4242
42
4.1 Install Operating System ............................................... 42
4.2 Support CD Information ................................................. 42
4.2.1 Running Support CD ............................................ 42
4.2.2 Drivers Menu........................................................ 42
4.2.3 Utilities Menu ........................................................ 42
4.2.4 “LGA 775 CPU Installation Live Demo” Program.... 42
4.2.5 Contact Information .............................................. 42

55
55
5
1.1.
1.1.
1. IntroductionIntroduction
IntroductionIntroduction
Introduction
Thank you for purchasing ASRock 775VM800Pro-DDR2 motherboard, a reliable
motherboard produced under ASRock’s consistently stringent quality control. It de-
livers excellent performance with robust design conforming to ASRock’s commit-
ment to quality and endurance. In this manual, chapter 1 and 2 contain introduction of
the motherboard and step-by-step guide to the hardware installation. Chapter 3 and
4 contain the configuration guide to BIOS setup and information of the Support CD.
Because the motherboard specifications and the BIOS software might be
updated, the content of this manual will be subject to change without
notice. In case any modifications of this manual occur, the updated
version will be available on ASRock website without further notice. You
may find the latest memory and CPU support lists onASRock website as
well. ASRock website http://www.asrock.com
1.1 Package Contents1.1 Package Contents
1.1 Package Contents1.1 Package Contents
1.1 Package Contents
ASRock 775VM800Pro-DDR2 Motherboard
(Micro ATX Form Factor: 9.6-in x 8.5-in, 24.4 cm x 21.6 cm)
ASRock 775VM800Pro-DDR2 Quick InstallationGuide
ASRock 775VM800Pro-DDR2 Support CD
(including LGA 775 CPU Installation Live Demo)
One 80-conductor Ultra ATA 66/100/133 IDE Ribbon Cable
One Ribbon Cable for a 3.5-in Floppy Drive
One Serial ATA (SATA) Cable
One SerialATA (SATA) HDD Power Cable(Optional)
OneASRock I/O PlusTM Shield
One COM Port Bracket

66
66
6
1.21.2
1.21.2
1.2 SpecificationsSpecifications
SpecificationsSpecifications
Specifications
Platform - Micro ATX Form Factor: 9.6-in x 8.5-in, 24.4 cm x 21.6 cm
CPU - 775-Pin Socket supporting Intel®Dual Core Pentium®XE and
Pentium®D/ Pentium® 4 / Celeron®Dprocessor
(in 775-land LGApackage)
- FSB 1066/800/533 MHz
- Supports EM64T CPU
- Supports Hyper-Threading Technology (see CAUTION 1)
Chipset - Northbridge: VIA® P4M800Pro chipset
- Southbridge: VIA®VT8237R Plus
Memory - 2 xDDRIIDIMM slots
- SupportDDRII533
- Max. capacity: 2GB
Hybrid Booster - CPU Frequency Stepless Control (see CAUTION 2)
-ASRock U-COP (see CAUTION 3)
- Boot Failure Guard (B.F.G.)
Expansion Slot - 3 x PCI slots
- 1 x AGP slot for 1.5V 8X/4X AGP card (see CAUTION 4)
- 1 x AMR slot
Graphics - VIA®UniChrome Pro 3D/2D
- DirectX 7.0 VGA
- Max. VGA shared memory 64MB
Audio - Cmedia 5.1 channel audio codec
LAN - VIA®PHY VT6103
- Speed: 10/100Mb Ethernet
- Supports Wake-On-LAN
Rear Panel I/O ASRock I/O PlusTM
- 1 x PS/2 Mouse Port
- 1 x PS/2 Keyboard Port
- 1 x VGA Port
- 1 x Parallel Port (ECP/EPP Support)
- 6 x Ready-to-Use USB 2.0 Ports
- 1 x RJ-45 Port
-Audio Jack: Line In / Line Out / Microphone

77
77
7
Connector - 2 x Serial ATA 1.5Gb/s connectors
(Supports RAID 0, 1, JBOD and “Hot Plug” functions)
- 2 x ATA133 IDE connector (supports 4 x IDE devices)
- 1 x Floppy connector
- 1 x COM port header
- 1 x IR header
- CPU/Chassis FAN connector
- 20 pin ATX power connector
- 4 pin 12V power connector
- CD in header
- AUX in header
- Front panel audio header
- 2 x USB 2.0 headers (support 4 USB 2.0 ports; 2 of them are
shared with USB4_5) (see CAUTION 5)
BIOS Feature - 4MbAMI BIOS
-AMI Legal BIOS
- Supports “Plug and Play”
-ACPI 1.1 Compliance Wake Up Events
- Supports jumperfree
- SMBIOS 2.3.1 Support
Support CD - Drivers, Utilities, AntiVirus Software
Hardware - CPU Temperature Sensing
Monitor - Chassis Temperature Sensing
- CPU Overheat Shutdown to Protect CPU Life
- CPU FanTachometer
- Chassis Fan Tachometer
- Voltage Monitoring: +12V, +5V, +3.3V, Vcore
OS - Microsoft® Windows® 98SE/ME/2000/XP/XP 64-bit compliant
Certifications - FCC, CE, WHQL

88
88
8
CAUTION!
1. About the setting of “Hyper ThreadingTechnology”, please check page 27.
2. Although this motherboard offers stepless control, it is not recommended
to perform over-clocking. Frequencies other than the recommended CPU
bus frequencies may cause the instability of the system or damage the
CPU.
3. While CPU overheat is detected, the system will automatically shutdown.
Before you resume the system, please check if the CPU fan on the
motherboard functions properly and unplug the power cord, then plug it
back again. To improve heat dissipation, remember to spray thermal
grease between the CPU and the heatsink when you install the PC system.
4. Do NOT use a 3.3V AGP card on the AGP slot of this motherboard!
It may cause permanent damage!
5. Power Management for USB 2.0 works fine under Microsoft®Windows® XP
SP1 / 2000 SP4. It may not work properly under Microsoft®Windows® 98 /
ME.

99
99
9
1.3 Motherboard Layout1.3 Motherboard Layout
1.3 Motherboard Layout1.3 Motherboard Layout
1.3 Motherboard Layout
VIA
P4M800 Pro
Chipset
VIA
VT8237R
Plus
DDRII_2 (64/72 bit, 240-pin module) DDRII_1 (64/72 bit, 240-pin module)
ATXPWR1
ATX12V1
PS2_USB_PWR1
1
PCI 1
PCI 2
PCI 3
1.5V_AGP1
4Mb
BIOS
CMOS
Battery
775VM800Pro-DDR2
Super
I/O
LAN
PHY
AMR1
SATA
ATA133
USB2.0
AGP 8X
FSB1066
CLRCMOS1
CD1
AUX1
Audio
CODEC
JR1 JL1
1
AUDIO1
CHA_FAN1
CPU_FAN1
IR1
1
COM1
1
USB4_5
1
PARALLEL PORT
VGA1
PS2
Mouse
PS2
Keyboard
USB 2.0
T: US B2
B: USB3
USB 2.0
T: US B0
B: USB1
Top :
RJ-45
USB 2.0
T: USB 4
B: USB5
Top :
Line In
Center:
Line Out
Bottom:
Mic In
5.1CH
SATA2 SATA1
1
PANEL1
HDLED RESET
PLED PWRBTN
1
SPEAKER1
1
USB67
FLOPPY1
IDE2
IDE1
24.4cm (9.6 in)
21.6cm (8.5 in)
Dual Core CPU
DDRII533
6
45
3
127
8
9
10
11
12
18
14
15
16
1719
13
20
21
22
23
24
25
26
27
28
29
1 PS2_USB_PWR1 Jumper 15 Secondary Serial ATA Connector (SATA2)
2 ATX 12V Connector (ATX12V1) 16 System Panel Header (PANEL1)
3 CPU Fan Connector (CPU_FAN1) 17 Chassis Speaker Header (SPEAKER 1)
4 ATX Power Connector (ATXPWR1) 18 USB 2.0 Header (USB67, Blue)
5 775-Pin CPU Socket 19 Floppy Connector (FLOPPY1)
6 North Bridge Controller 20 AMR Slot (AMR1)
7 2 x 240-pin DDRII DIMM Slots 21 JR1 / JL1 Jumpers
(DDRII_1, DDRII_2; Yellow) 22 Front Panel Audio Header (AUDIO1)
8 Primary IDE Connector (IDE1, Blue) 23 Internal Audio Connector: CD1 (Black)
9 Secondary IDE Connector (IDE2, Black) 24 Internal Audio Connector: AUX1 (White)
10 AGP Slot (1.5V_AGP1) 25 3 x PCI Slots (PCI1- 3)
11 Clear CMOS Jumper (CLRCMOS1) 26 Flash Memory
12 South Bridge Controller 27 Serial Port Connector (COM1)
13 Chassis Fan Connector (CHA_FAN1) 28 Infrared Module Header (IR1)
14 Primary Serial ATA Connector (SATA1) 29 Shared USB 2.0 Header (USB4_5, Blue)

1010
1010
10
1.4 ASRock I/O Plus1.4 ASRock I/O Plus
1.4 ASRock I/O Plus1.4 ASRock I/O Plus
1.4 ASRock I/O PlusTMTM
TMTM
TM
1 Parallel Port 7 USB 2.0 Ports (USB01)
2 RJ-45 Port 8 USB 2.0 Ports (USB23)
3 Line In (Light Blue) 9 VGA Port
4 Line Out (Lime) 10 PS/2 Keyboard Port (Purple)
5 Microphone (Pink) 11 PS/2 Mouse Port (Green)
6 Shared USB 2.0 Ports (USB45)
12
3
4
5
6
7
8910
11

1111
1111
11
Chapter 2 InstallationChapter 2 Installation
Chapter 2 InstallationChapter 2 Installation
Chapter 2 Installation
775VM800Pro-DDR2 is a Micro ATX form factor (9.6" x 8.5", 24.4 x 21.6 cm)
motherboard. Before you install the motherboard, study the configuration of your
chassis to ensure that the motherboard fits into it.
Make sure to unplug the power cord before installing or removing the
motherboard. Failure to do so may cause physical injuries to you and
damages to motherboard components.
2.1 Screw Holes2.1 Screw Holes
2.1 Screw Holes2.1 Screw Holes
2.1 Screw Holes
Place screws into the holes indicated by circles to secure the motherboard to the
chassis.
Do not over-tighten the screws! Doing so may damage the motherboard.
2.2 Pre-installation Precautions2.2 Pre-installation Precautions
2.2 Pre-installation Precautions2.2 Pre-installation Precautions
2.2 Pre-installation Precautions
Take note of the following precautions before you install motherboard components
or change any motherboard settings.
1. Unplug the power cord from the wall socket before touching any component.
2. To avoid damaging the motherboard components due to static electricity, NEVER
place your motherboard directly on the carpet or the like. Also remember to use
a grounded wrist strap or touch a safety grounded object before you handle
components.
3. Hold components by the edges and do not touch the ICs.
4. Whenever you uninstall any component, place it on a grounded antistatic pad or
in the bag that comes with the component.
Before you install or remove any component, ensure that the power is
switched off or the power cord is detached from the power supply.
Failure to do so may cause severe damage to the motherboard, peripherals,
and/or components.

1212
1212
12
2.3 CPU Installation2.3 CPU Installation
2.3 CPU Installation2.3 CPU Installation
2.3 CPU Installation
For the installation of Intel 775-LAND CPU,
please follow the steps below.
Before you insert the 775-LAND CPU into the socket, please check if
the CPU surface is unclean or if there is any bent pin on the socket.
Do not force to insert the CPU into the socket if above situation is
found. Otherwise, the CPU will be seriously damaged.
Step 1. Open the socket:
Step 1-1. Disengaging the lever by depressing
down and out on the hook to clear
retention tab.
Step 1-2. Rotate the load lever to fully open po-
sition at approximately 135 degrees.
Step 1-3. Rotate the load plate to fully open po-
sition at approximately 100 degrees.
Step 2. Insert the 775-LAND CPU:
Step 2-1. Hold the CPU by the edges where are
marked with black lines.
Step 2-2. Orient the CPU with IHS (Integrated
Heat Sink) up. Locate Pin1 and the two
orientation key notches.
775-Pin Socket Overview
black line
black line
775-PinSocket
Pin1
alignment key alignment key
Pin1
orientation
key notch orientation
key notch
775-LAND CPU

1313
1313
13
For proper inserting, please ensure to match the two orientation key
notches of the CPU with the two alignment keys of the socket.
Step 2-3. Carefully place the CPU into the socket
by using a purely vertical motion.
Step 2-4. Verify that the CPU is within the socket
and properly mated to the orient keys.
Step 3. Remove PnP Cap (Pick and Place Cap):
Use your left hand index finger and thumb to
support the load plate edge, engage PnP cap
with right hand thumb and peel the cap from the
socket while pressing on center of PnP cap to
assist in removal.
1. It is recommended to use the cap tab to handle and avoid kicking
off the PnP cap.
2. This cap must be placed if returning the motherboard for after
service.
Step 4. Close the socket:
Step 4-1. Rotate the load plate onto the IHS.
Step 4-2. While pressing down lightly on load
plate, engage the load lever.
Step 4-3. Secure load lever with load plate tab
under retention tab of load lever.

1414
1414
14
2.42.4
2.42.4
2.4 Installation of CPU Fan and HeatsinkInstallation of CPU Fan and Heatsink
Installation of CPU Fan and HeatsinkInstallation of CPU Fan and Heatsink
Installation of CPU Fan and Heatsink
This motherboard is equipped with 775-Pin socket that supports Intel 775-LAND CPU.
Please adopt the type of heatsink and cooling fan compliant with Intel 775-LANDCPU
to dissipate heat. Before you installed the heatsink, you need to spray thermal
interface material between the CPU and the heatsink to improve heat dissipation.
Ensure that the CPU and the heatsink are securely fastened and in good contact with
each other. Then connect the CPU fan to the CPU_FAN connector (CPU_FAN1, see
page 9, No. 3).
For proper installation, please kindly refer to the instruction manuals of
your CPU fan and heatsink.
Below is an example to illustrate the installation of the heatsink for 775-LAND CPU.
Step 1. Apply thermal interface material onto center
of IHS on the socket surface.
Step 2. Place the heatsink onto the socket. Ensure
fan cables are oriented on side closest to the
CPU fan connector on the motherboard
(CPU_FAN1, see page 9, No. 3).
Step 3. Align fasteners with the motherboard
throughholes.
Step 4. Rotate the fastener clockwise, then press
down on fastener caps with thumb to install
and lock. Repeat with remaining fasteners.
If you press down the fasteners without rotating them clockwise,
the heatsink cannot be secured on the motherboard.
Step 5. Connect fan header with the CPU fan
connector on the motherboard.
Step 6. Secure excess cable with tie-wrap to ensure
cable does not interfere with fan operation or
contact other components.

1515
1515
15
2.5 Installation of Memory Modules (DIMM)2.5 Installation of Memory Modules (DIMM)
2.5 Installation of Memory Modules (DIMM)2.5 Installation of Memory Modules (DIMM)
2.5 Installation of Memory Modules (DIMM)
775VM800Pro-DDR2 motherboard provides two 240-pin DDRII (Double Data Rate)
DIMMslots.
Please make sure to disconnect power supply before adding or removing
DIMMs or the system components.
Step 1. Unlock a DIMM slot by pressing the retaining clips outward.
Step 2. Align aDIMM on the slot such that the notch on the DIMM matches the break
on the slot.
The DIMM only fits in one correct orientation. It will cause
permanent damage to the motherboard and the DIMM if you
force the DIMM into the slot at incorrect orientation.
Step 3. Firmly insert theDIMM into the slot until the retaining clips at both ends fully
snap back in place and the DIMM is properly seated.
It is not allowed to install DDR into DDRII slot; otherwise, this motherboard
and DIMM may be damaged.
notch
break
notch
break

1616
1616
16
2.6 Expansion Slots (PCI, AMR and AGP Slots)2.6 Expansion Slots (PCI, AMR and AGP Slots)
2.6 Expansion Slots (PCI, AMR and AGP Slots)2.6 Expansion Slots (PCI, AMR and AGP Slots)
2.6 Expansion Slots (PCI, AMR and AGP Slots)
There are 3 PCI slots, 1 AMR slot, and 1 AGP slot on 775VM800Pro-DDR2
motherboard.
PCI slots: PCI slots are used to install expansion cards that have the 32-bit PCI
interface.
AMR slot: The AMR slot is used to insert an ASRock MR card with v.92 Modem
functionality.
AGP slot: The AGP slot is used to install a graphics card. The ASRock AGP slot has
a special design of clasp that can securely fasten the inserted graphics
card.
Please do NOTuse a 3.3VAGP card on theAGP slot of this motherboard!
It may cause permanent damage! For the voltage information of your
AGP card, please check with the AGP card vendors.
Installing an expansion cardInstalling an expansion card
Installing an expansion cardInstalling an expansion card
Installing an expansion card
Step 1. Before installing the expansion card, please make sure that the power
supply is switched off or the power cord is unplugged. Please read the
documentation of the expansion card and make necessary hardware
settings for the card before you start the installation.
Step 2. Remove the system unit cover (if your motherboard is already installed in a
chassis).
Step 3. Remove the bracket facing the slot that you intend to use. Keep the screws
for later use.
Step 4. Align the card connector with the slot and press firmly until the card is
completely seated on the slot.
Step 5. Fasten the card to the chassis with screws.
Step 6. Replace the system cover.

1717
1717
17
2.7 Jumpers Setup2.7 Jumpers Setup
2.7 Jumpers Setup2.7 Jumpers Setup
2.7 Jumpers Setup
The illustration shows how jumpers are
setup. When the jumper cap is placed on
pins, the jumper is “Short”. If no jumper cap
is placed on pins, the jumper is “Open”. The
illustration shows a 3-pin jumper whose pin1
and pin2 are “Short” when jumper cap is
placed on these 2 pins.
Jumper Setting
PS2_USB_PWR1 Short pin2, pin3 to enable
(see p.9, No. 1) +5VSB (standby) for PS/2
or USB wake up events.
Note: To select +5VSB, it requires 2 Amp and higher standby current provided
by power supply.
JR1(see p.9, No.21)
JL1(see p.9, No. 21)
Note: If the jumpers JL1 and JR1 are short, both the front panel and the rear panel
audio connectors can work.
ClearCMOS
(CLRCMOS1, 2-pin jumper)
(see p.9, No. 11)
Note: CLRCMOS1 allows you to clear the data in CMOS. The data in CMOS includes
system setup information such as system password, date, time, and system
setup parameters. To clear and reset the system parameters to default setup,
please turn off the computer and unplug the power cord from the power
supply. After waiting for 15 seconds, use a jumper cap to short 2 pins on
CLRCMOS1 for 5 seconds.
+5V
1_2
+5VSB
2_3
Short Open
JR1 JL1
2-pin jumper

1818
1818
18
2.8 Onboard Headers and Connectors2.8 Onboard Headers and Connectors
2.8 Onboard Headers and Connectors2.8 Onboard Headers and Connectors
2.8 Onboard Headers and Connectors
Onboard headers and connectors are NOT jumpers. Do NOT place jumper
caps over these headers and connectors. Placing jumper caps over the
headers and connectors will cause permanent damage of the motherboard!
FDDConnector
(33-pinFLOPPY1)
(see p.9, No. 19)
Note: Make sure the red-striped side of the cable is plugged into Pin1 side of the
connector.
Primary IDE Connector (Blue) Secondary IDE Connector (Black)
(39-pin IDE1, see p.9, No. 8) (39-pin IDE2, see p.9, No. 9)
Note: If you use only one IDE device on this motherboard, please set the IDE
device as “Master”. Please refer to the instruction of your IDE device vendor
for the details. Besides, to optimize compatibility and performance, please
connect your hard disk drive to the primary IDE connector (IDE1, blue) and
CD-ROM to the secondary IDE connector (IDE2, black).
Serial ATA Connectors These two Serial ATA (SATA)
(SATA1: see p.9,No.14) connectors support SATA data
(SATA2: see p.9,No.15) cables for internal storage
devices. The current SATA
interface allows up to 1.5 Gb/s
data transfer rate.
Serial ATA (SATA) Either end of the SATA data
Data Cable cable can be connected to the
SATA hard disk or the SATA
connector on the motherboard.
FLOPPY1
Pin1
IDE1
PIN1
IDE2
PIN1
connect the black end
to the IDE devices
connect the blue end
to the motherboard80-conductor ATA 66/100/133 cable
thered-striped side to Pin1
SATA1SATA2

1919
1919
19
Serial ATA (SATA) Please connect the black end of
Power Cable SATA power cable to the power
(Optional) connector on the drive. Then
connect the white end of SATA
power cable to the power
connector of the power supply.
USB 2.0 Header ASRock I/O PlusTM provides you
(9-pinUSB67) 6 ready-to-use USB 2.0 ports on
(see p.9, No. 18) the rear panel. If the rear USB
ports are not sufficient, this
USB 2.0 header is available to
support 2 extra USB 2.0 ports.
Infrared Module Header This header supports an optional
(5-pin IR1) wireless transmitting and
(see p.9, No. 28) receiving infrared module.
Internal Audio Connectors These connectors allow you
(4-pin CD1, 4-pin AUX1) to receive stereo audio input
(CD1: see p.9, No. 23) from sound sources such as
(AUX1:see p.9, No. 24) a CD-ROM,DVD-ROM,TV
tuner card, or MPEG card.
Front PanelAudio Header This is an interface for the front
(9-pin AUDIO1) panel audio cable that allows
(see p.9, No. 22) convenient connection and
control of audio devices.
CD-R
GND
GND
CD-L
AUX-R
GND
GND
AUX-L
CD1
AUX1
USB_PWR
USB_PWR
P+7
P-7
P+6
P-6
GND
GND
DUMMY
1
GND
GND
+5VA
BACKOUT-R
BACKOUT-L
AUD-OUT-L
AUD-OUT-R
MIC-POWER
MIC
1
connect to the SATA HDD
powerconnector
connect tothe
powersupply
Shared USB 2.0 Header ThisUSB4_5connectorisshared
(9-pinUSB4_5) with the USB 2.0 ports 4,5 on
(see p.9, No. 29) ASRock I/O PlusTM. When using
the front panel USB ports by
attaching the front panel USB
cable to this connector
(USB4_5), the USB ports 4,5 on
ASRockI/O PlusTM will notbe able
to function.
USB_PWR
1
P-5
GND
DUMMY
USB_PWR
P+5
GND
P-4
P+4
1
IRTX
IRRX
GND
+5VSB
DUMMY

2020
2020
20
System Panel Header This header accommodates
(9-pinPANEL1) several system front panel
(see p.9, No. 16) functions.
Chassis Speaker Header Please connect the chassis
(4-pinSPEAKER 1) speaker to this header.
(see p.9, No. 17)
Chassis Fan Connector Please connect the chassis fan
(3-pin CHA_FAN1) cable to this connector and
(see p.9, No. 13) match the black wire to the
ground pin.
CPU Fan Connector Please connect the CPU fan
(4-pin CPU_FAN1) cable to this connector and
(see p.9, No. 3) match the black wire to the
ground pin.
ATX Power Connector Please connect an ATX power
(20-pinATXPWR1) supply to this connector.
(see p.9, No. 4)
ATX 12V Connector Please note that it is necessary
(4-pin ATX12V1) to connect a power supply with
(see p.9, No. 2) ATX 12V plug to this connector
so that it can provides sufficient
power. Failing to do so will cause
the failure to power up.
Serial port connector This COM1 connector
(9-pin COM1) supports a serial port module.
(see p.9 item 27)
GND
PWRBTN#
PLED-
PLED+
DUMMY
RESET#
GND
HDLED+
HDLED-
1
+5V
DUMMY
DUMMY
SPEAKER
1
CCTS#1
DDSR#1
DDTR#1
RRXD1
DDCD#1
TTXD1
GND
RRTS#1
RRI#1
1
Please install the heatsink and the CPU fan before installing ATX 12V
connector; otherwise, it may cause permanent damage!
GND
+12V
CHA_FAN_SPEED
