Asset SORGENTE Operating instructions

Rev. February 2012 - Code A-Man03
ENGLISH
Installation, User and
Maintenance Manual
WARNING: Read this manual before operating
MADE IN ITALY
prodotto conforme
D.M.174/2004
ASSET S.r.l. Loc. Isola del Pero, 16 - 17041 - ALTARE (SV) - ITALY
Tel: [phone] Fax: [phone] - e-mail: inf[email protected] - www.assetitalia.it
SMILE
SORGENTE
UNDERCOUNTER
ISI-T

ABSENCE
METAL
HEAVY
94/62/CE
prodotto conforme
D.M.174/2004
Certification N. TIFQ-1206TA03F3P7
The Healthy Quality Mark TIFQ certifies the conformity of the product
with the Italian Regulation DM 174/2004 (EU directive 98/83/CE)
regarding the contact with water which is meant for humans.
(DM 174/2004: Regulation concerning materials and objects that can be used in stationary
collection systems, processing, adduction and distribution of waters meant for human use)

I-1
SORGENTE/SMILE/ISI-T/UNDERCOUNTER - Installation, User and Maintenance - cod. A-MAN03 - Rev. 02/2012
Table of Contents
CHAPTER 1
INTRODUCTION .................................... 1-3
1.1 General information .................................... 1-3
1.2 Aim of the manual .................................... 1-4
1.3 Where and how to keep the manual ................... 1-4
1.4 Manual updating .................................... 1-5
1.5 Cooperation with the user ................................ 1-5
1.6 Manufacturer .................................... 1-6
1.7 Manufacturer’s responsibility and warranty ........ 1-7
1.7.1 warranty terms .....................................1-7
1.8 Thecnical assistance service .............................. 1-8
1.9 Copyright .................................... 1-9
EC Declaration Of Conformity ..........................1-10
CHAPTER 2
TECHNOLOGICAL DESCRIPTION .................................... 2-1
2.1 Available models .................................... 2-1
2.1.1 SORGENTE .....................................2-1
2.1.2 SMILE .....................................2-3
2.1.3 ISI-T .....................................2-5
2.1.4 UNDERCOUNTER .....................................2-6
2.2 Technical data .................................... 2-6
2.3 Emission of machine noise ............................... 2-5
CHAPTER 3
SAFETY REQUIREMENTS .................................... 3-1
3.1 General notes .................................... 3-1
3.2 Symbols .................................... 3-1
3.3 Safety warnings .................................... 3-2
3.3.1 operator’s qualification .....................................3-3
CHAPTER 4
UNPACKING .................................... 4-1
4.1 Visual check .................................... 4-1
4.1.1 check of machine and equipment supplied ..............4-1
4.2 Unpacking .................................... 4-1
4.3 Packing list .................................... 4-2
4.4 Preassembly ISI-T .................................... 4-3
CHAPTER 5
INSTALLATION .................................... 5-1
5.1 Environmental characteristics ........................... 5-1
5.2 Cleaning .................................... 5-1
5.3 Positioning .................................... 5-1
5.4 Connections .................................... 5-2
5.4.1 outer accessories .....................................5-2
5.4.2 connection to the water mains ............................5-3
5.4.3 power supply connection .....................................5-4
5.4.4 internal monouse bottle replacement ....................5-5
5.4.5 connection of rechargeable external Co2 bottle ......5-6

I-2 SORGENTE/SMILE/ISI-T/UNDERCOUNTER - Installation, User and Maintenance - cod. A-MAN03 - Rev. 02/2012
CHAPTER 6
DISPENSER USE ....................................6-1
6.1 Control panel ....................................6-1
6.1.1 Anomalies signalling led .................................... 6-2
6.1.2 Display .................................... 6-3
6.2 Water temperature adjustmet ...........................6-3
6.3 Energy saving function ....................................6-4
6.4 Automatic water dispensing dosage ..................6-4
6.5 Enable tones ....................................6-5
6.6 Keyborad lock ....................................6-6
6-7 Fist start up ....................................6-6
6-8 Boiler - Hot water ....................................6-7
6.8.1 Procedure for starting-up the boiler ..................... 6-8
6.8.2 Setting the refrigerator temperature .................... 6-9
6.8.3 Reset Eco Save .................................... 6-9
6.8.4 Ozone setting .................................... 6-9
6.8.5 Firmware version .................................. 6-10
6.8.6 Technical Assistance .................................. 6-10
CHAPTER 7
TROUBLE SHOOTING .................................... 7-1
7.1 Signallings .................................... 7-1
7.1.1 List of singallings .....................................7-2
7.2 Solutions to prblems .................................... 7-3
7.3 Alarm signalling for UNDERCOUNTER ................. 7-5
7.3.1 Remote control setting .....................................7-5
7.3.2 Temperature adjustment .....................................7-5
7.3.3 Set Check ..................................... 7-7
7.3.4 Acoustic alarms .....................................7-7
7.3.5 Resyncing of the remote control ..........................7-8
7.3.6 Connection diagram .....................................7-9
CHAPTER 8
MAINTENANCE .................................... 8-1
8.1 Ordinary scheduled maintenance cycles
(HACCP) .................................... 8-1
8.2 Replacement of the monouse or rechargeable
CO2 bottle .................................... 8-2
8.2.1 replacement of the monouse bottle ......................8-2
8.2.2 replacement of the rechargeable bottle ..................8-3
8.3 Filter replacement .................................... 8-4
8.4 Replacement of the UV lamp (outer accessory) .. 8-5
8.5 Cleaning .................................... 8-5
8.6 Water dispenser sanitization ............................. 8-6
8.6.1 Sanitization procedure .................................... 8-6
CHAPTER 9
DISMANTLING .................................... 9-1
9.1 Dispenser dismantling .................................... 9-1
9.2 Electronic components disposal ........................ 9-1
CHAPTER 10
SPARE PARTS ...................................10-1
10.1 Identification and ordering modes ...................10-1

I-3
SORGENTE/SMILE/ISI-T/UNDERCOUNTER - Installation, User and Maintenance - cod. A-MAN03 - Rev. 02/2012
Pictures summary
CHAPTER 1
INTRODUCTION .................................... 1-3
Fig
1.1 SMILE .....................................1-3
1.2 ISI-T ..................................... 1-3
1.3 SORGENTE ..................................... 1-3
1.4 UNDERCOUNTER ..................................... 1-3
1.5 Rear Label ..................................... 1-6
1.7 Assistance ..................................... 1-8
CHAPTER 2
TECHNOLOGICAL DESCRIPTION .................................... 2-1
Fig
2.1 SORGENTE Elite .....................................2-1
2.2 SORGENTE Joy .....................................2-1
2.3 SORGENTE Stand .....................................2-2
2.4 SORGENTE Joy .....................................2-2
2.5 SORGENTE Elite .....................................2-2
2.6 SORGENTE Joy-HW .....................................2-2
2.7 SMILE ..................................... 2-3
2.8 SMILE Stand ..................................... 2-3
2.9 SMILE Joy ..................................... 2-4
2.10 SMILE Elite ..................................... 2-4
2.11 SMILE Joy-HW ..................................... 2-4
2.12 ISI-T ..................................... 2-5
2.13 ISI-T Elite .....................................2-5
2.14 ISI-T Elite-HW .....................................2-5
2.15 UNDERCOUNTER Wireless .....................................2-6
2.16 UNDERCOUNTER Electromechanical .......................2-6
2.17 UNDERCOUNTER Electronic .................................. 2-6
CHAPTER 4
UNPACKING .................................... 4-1
Fig
4.1 Packaging .....................................4-1
4.2 ISI-T Packaging .....................................4-1
CHAPTER 5
INSTALLATION .................................... 5-1
Fig
5.1 Outer connections on back side of Mithia ............... 5-2
5.2 Drinking water pipe connection to mains ............... 5-3
5.3 Power supply cable connection ............................5-5
5.4 Connection of internal monouse Co2 bottle............. 5-5
5.5 Internal monouse Co2 bottle compartment ............. 5-6
5.6 Connection of rechargeable external Co2 bottle .......5-6
5.7 Pressure reducer ..................................... 5-6
5.8 Pressure reducer detail ..................................... 5-7
5.9 Pressure reducer detail ..................................... 5-7

I-4 SORGENTE/SMILE/ISI-T/UNDERCOUNTER - Installation, User and Maintenance - cod. A-MAN03 - Rev. 02/2012
CHAPTER 6
DISPENSER USE .................................... 6-1
Fig
6.1 SORGENTE ..................................... 6-1
6.2 Rear control panel ..................................... 6-1
6.3 Signalling leds .....................................6-2
6.4 Rear menù access key .....................................6-3
6.5 Plastic front panel opening .................................. 6-6
6.6 Plastic front panel opening .................................. 6-6
6.7 Plastic front panel opening .................................. 6-6
6.8 Plastic front panel opening .................................. 6-6
6.9 Plastic front panel opening .................................. 6-6
6.10 Hot Water panel .....................................6-7
CHAPTER 7
TROUBLE SHOOTING .................................... 7-1
Fig
7.1 SORGENTE ..................................... 7-1
7.2 Control panel keys .....................................7-1
7.3 Control panel leds ..................................... 7-2
7.4 Remote Control ..................................... 7-4
7.5 Rear menù access key .....................................7-6
CHAPTER 8
MAINTENANCE .................................... 8-1
Fig
8.1 Monouse bottle replacement ...............................8-2
8.2 Rechargeable bottle replacement .........................8-3
8.3 Rechargeable bottle replacement .........................8-3
8.4 Rechargeable bottle replacement .........................8-3
8.5 Chip Card rear slot ..................................... 8-4
8.6 Filter replacement .....................................8-4

1-1
SORGENTE/SMILE/ISI-T/UNDERCOUNTER - Installation, User and Maintenance - cod. A-MAN03 - Rev. 02/2012
Dear Customer,
Asset Srl would like to thank you and congratulate for your
choice.
Water is a vital and essential element. Water represents 70%
of the human body and, every day, we ought to drink at least
2 litres of it to be in health and to refresh ourselves.
For this reason, the most important thing to do is to be sure of
the goodness and quality of the water we daily drink.
This useful and functional dispenser with MICROFILTRATION
system is manufactured with the most modern and innovative
technologies. Its quality materials are subjected to a rigorous
control according to our company standard. All the materials
and components are tested during the entire production proc-
ess to satisfy your expectations.
MICROFILTRATION is a filtration process which removes sol-
id particles from a fluid by passage through a microporous
membrane. Microperforated copper or silver scales, which are
natural antibacterial metals, are sometimes added to water
MICROFILTRATION so that an articulated pre-filtration process
is set, based on use of natural active principles (vegetal acti-
vated carbon) able to extensively collect and hold sediments,
chlorine and other polluting substances.
ASSET uses exclusively Filters certificated by the Italian Min-
istry of Heath.
ATTENTION: On the table shown on the next page it is possible
to check which elements are filtered by the dispenser through
MICROFILTRATION.
We ask you to read and respect these simple instructions to
guarantee the best results, since at the first use of the dis-
penser.
This manual includes important information, not only for the
use but, also, for your safety and for maintenance; it is part
of the machine.
ATTENTION: It is necessary to carry out periodi-
cal maintenance on this device in order to preserve
the drinkable characteristics of dispensed water.

1-2 SORGENTE/SMILE/ISI-T/UNDERCOUNTER - Installation, User and Maintenance - cod. A-MAN03 - Rev. 02/2012

1-3
SORGENTE/SMILE/ISI-T/UNDERCOUNTER - Installation, User and Maintenance - cod. A-MAN03 - Rev. 02/2012
1.1 General information
The machine is realized in compliance with the directives
in force in the European Community and with the required
technical rules, as certified by the Declaration of Conformity
issued by the Manufacturer and enclosed to the manual.
This publication, hereinafter simply called the ”manual”,
includes all the information for use and for a safe main-
tenance of the device mentioned in the Declaration of
Conformity.
This device, that in the course of the manual will be ge-
nerically called “machine” or “dispenser”, is manufactured
by the company ASSET srl, whose details are indicated
hereinafter in this publication.
This publication is intended for subjects, generically
defined as ‘users’, who are intended to use the machine.
In particular, they can be identified as follows:
• operators directly involved in transport, storage,
installation, use and ordinary maintenance of the
machine, from its launch onto the market up to the
day of disposal;
• direct users.
The original text of this publication, drawn up in Italian
language, represents the only reference for the settlement
of possible disputes related to the interpretation of the
translation in the community languages.
This publication must be considered as an integral part
of the machine, and therefore it must be preserved for
future reference up to the final disposal and scrapping
of the machine.
1. Introduction
fig.1.3 SORGENTE
fig.1.1 SMILE
fig.1.4 UNDERCOUNTER
fig.1.2 ISI-T

1-4 SORGENTE/SMILE/ISI-T/UNDERCOUNTER - Installation, User and Maintenance - cod. A-MAN03 - Rev. 02/2012
1.2 Aim of the manual
The aim of this manual is to give the indications to use
the machine safely and to carry out the ordinary main-
tenance procedures.
Any calibrations, adjustments and extraordinary mainte-
nance operations are not included in this booklet, since
they are carried out exclusively by the service techni-
cian, that must operate on the machine in respect of
the technical and project characteristics for which is
was manufactured.
The machine intended use and configuration are the only
ones admitted by the Manufacturer; do not try to use
the machine disagreeing with the indications supplied.
Any other use or configuration must be previously agreed
upon with the Manufacturer in writing, and be enclosed
to this manual.
Concerning installation and use, the user must follow the
specific laws in force in the Nation where the machine
is installed.
The user is expected to know and consult the laws,
directives, etc. recalled in the text in order to achieve
the aims that the manual sets.
1.3 Where and how to keep the manual
This manual (and any possible enclosures related to it)
must be kept in a protected and dry place, and always
be available for reference.
It is recommended to make a copy of the manual and
keep it in the archive.
Refer to the data of the machine identification label
when exchanging information with the Manufacturer or
with authorized assistance staff.
This manual must be kept for the whole life of the machine,
and in case of need (for ex. damage that compromises
consulting it also partially) the user must obtain a new
copy by requesting it exclusively to the Manufacturer,
indicating the publication code positioned on the cover.

1-5
SORGENTE/SMILE/ISI-T/UNDERCOUNTER - Installation, User and Maintenance - cod. A-MAN03 - Rev. 02/2012
1.4 Manual updating
The manual reflects the machine state of art at the time
of its launch onto the market, being an integral part of it.
The publication is compliant with the directives in force
at that time; the manual cannot be considered unsuitable
further to possible updates of standards or modifications
on the machine.
Any supplements of the manual that the Manufacturer
considers suitable to send to the users, must be kept with
the manual and become an integral part of it. To check
if this Manual version is the last issue available, consult
the website www.assetitalia.it where – on every product
page - it is possible to download the electronic version
of the last available version.
1.5 Cooperation with the user
The Manufacturer is available to supply additional infor-
mation to customers and to consider any suggestions for
improvement in order to bring this manual more into line
with the requirements for which it was published.
If the machine is sold, the original user must give this
manual to the new user and communicate the address
of the new owner to the manufacturer so that it may be
provided with any essential information or updates.
All property rights of the contents included in this publi-
cation are reserved to Asset s.r.l., therefore it cannot be
reproduced totally or partly unless written authorization
by the manufacturer.

1-6 SORGENTE/SMILE/ISI-T/UNDERCOUNTER - Installation, User and Maintenance - cod. A-MAN03 - Rev. 02/2012
1.6 Manufacturer
The machine identification data are included
in the label positioned on the rear
of the machine.
The label includes the following data in this order:
• model;
• serial number;
• power supply voltage (V), frequency (Hz) the input
of the only refrigerating part (A) and the pertaining
Climatic Class;
• type of refrigerant and quantity in grams;
• maximum pressure of the water supply to which the
dispenser can ne connected (kPa);
• maximum pressure of the CO2 to which the dispenser
can be connected (kPa);
• country of manufacture;
• European CE conformity marking.
ATTENTION: The removal or, however, every type of
tampering of the identification label, makes the
warranty expire.
fig.1.5

1-7
SORGENTE/SMILE/ISI-T/UNDERCOUNTER - Installation, User and Maintenance - cod. A-MAN03 - Rev. 02/2012
1.7 Manufacturer’s responsibility and
warranty
In order to take advantage of the warranty supplied by the
Manufacturer, the user must carefully follow the measures
indicated in the manual, and in particular:
• always operate within the machine limit of use;
• always carry out constant and accurate cleaning and
maintenance operations.
The manufacturer declines any responsibility, direct and
indirect, caused by:
• machine use different than what indicated in this manual;
• use by staff who did not read and fully understand the
contents of this manual;
• use not in conformity with specific standards in force
in the Country of installation;
• modifications carried out on the machine, on the
software, on the operation logic, if not authorized in
writing by the Manufacturer;
• unauthorized repairs;
• exceptional events.
If the machine is sold to third parties also this manual
must be delivered to the new owner; any right of the Pur-
chaser will be automatically invalided if the manual is not
delivered, including the warranty terms where applicable.
If the machine is sold to third parties, in a Country where
is spoken a different language than the language indicated
in this manual, the old user is responsible to supply a
faithful translation of this manual in the language of the
Country where the machine will operate.
1.7.1 Warranty terms
The machine is guaranteed by ASSET srl for a 24 (twenty
four) month period from the invoice date.
This guarantee covers manufacturing and assembling defects.
ASSET srl undertakes to replace or repair at is own charge
at its factory, carriage free, any part that the manufacturer
considers defective.
WARNING: Read this manual before operating
ATTENTION
READ
CAREFULLY !

1-8 SORGENTE/SMILE/ISI-T/UNDERCOUNTER - Installation, User and Maintenance - cod. A-MAN03 - Rev. 02/2012
If service by a repair technician of the Manufacturer
(or by a authorized technician) is required at the user’s
site, it is understood that the travel, board and lodgings
costs are at user’s charge.
The acknowledgment of a free supply of the parts under
warrantee is always subject to inspection by the Manu-
facturer (or authorized person).
The extension of guarantee following a technical inter-
vention or repair of the machine is excluded;
Damages to the machine are not included in the war-
rantee if caused by:
• transport;
• negligence;
• natural disasters or power problems;
• improper use and/or not in conformity with the
instructions given in the use manual;
• wrong electrical connection.
The warranty becomes null and void in case of:
• repairs carried out by staff not authorised of the
Manufacturer;
• modifications not authorized by the Manufacturer;
• use of parts and/or equipment not supplied or ap-
proved by the Manufacturer;
• identification label removal or tampering.
1.8 Technical assistance service
For any intervention of technical service directly contract
the Manufacturer or the authorised Dealer, and always
indicate the model u and the serial number v, im-
printed on the identification label.
u
v
fig.1.7

1-9
SORGENTE/SMILE/ISI-T/UNDERCOUNTER - Installation, User and Maintenance - cod. A-MAN03 - Rev. 02/2012
1.9 Copyright
The information contained in this manual must not be
disclosed to third parties. Any reproduction, partial or total,
not authorized in writing by the Manufacturer, obtained
by photocopying, reproduction or with other systems, also
electronic acquisition, infringes the copyright conditions
and will be prosecuted according to the law.

1-10 SORGENTE/SMILE/ISI-T/UNDERCOUNTER - Installation, User and Maintenance - cod. A-MAN03 - Rev. 02/2012 1-10
DICHIARAZIONE DI CONFORMITA’ CE
2004/118/EC, EC 2006/95/EC.
ASSET S.r.l.
Loc. Isola del Pero, 16 - 17041 Altare (SV) - Italy
dichiariamo sotto la nostra responsabilità che il
prodotto
EROGATORE D'ACQUA Modello
SMILE, SORGENTE, ISI-T e UNDERCOUNTER
al quale si riferisce questa dichiarazione è conforme
alle seguenti norme:
• Sicurezza di elettrodomestici e apparecchi elettri-
ci - Parte 1 - Requisiti generali - EN 60335-1 (2002)
+ A1(2004) + A2(2006) + A11(2004) + A12 (2006) +
A13(2008).
• Sicurezza di elettrodomestici e apparecchi elettrici -
-
frigeranti, gelatiere e produttori di ghiaccio - EN 60335-
2-24:2003 + A11:2004 + A1:2005 + A2:2007.
• Metodi di misurazione per campi elettromagnetici in
apparecchi elettrici di uso domestico e similari con ri-
ferimento all’esposizione umana - EN 62233:2008.
• Sicurezza di elettrodomestici e apparecchi elettrici
riscaldare liquidi - EN 60335-2-15:2002 + A1:2005 +
A2:2008.
• Compatibilità elettromagnetica (EMC) - Requisiti di
emisissioni per apparecchi elettrici di uso domestico e
similari - Parte 1 - Emissioni - EN 55014-1:2006.
• Compatibilità elettromagnetica (EMC) - Requisiti di
immunità per apparecchi elettrici di uso domestico e
similari - Parte 2 - Immunità - Norma per famiglia di
prodotti - EN 55014-2:1997 + A1:2001.
• Compatibilità elettromagnetica (EMC) - Parte 3-2 - Li-
miti - Limiti per le emissioni di corrente armonica (cor-
rente in ingresso dell’apparecchiatura ≤ 16A per fase)
- EN 61000-3-2:2006.
• Compatibilità elettromagnetica (EMC) - Parte 3-3 - Li-
picchi di tensione nei sistemi di alimentazione a bassa
tensione per apparecchiature con corrente nominale ≤
16A. - EN 61000-3-3:1995 + A1:2001 + A2:2005.
Secondo le disposizioni delle direttive:
2004/108/EEC, 2006/95/EC.
Altare (SV), lì 10/02/2012
Project Manager
Paolo Tesi
EC DECLARATION OF CONFORMITY
2004/118/EC, 2006/95/EC.
ASSET S.r.l.
Loc. Isola del Pero, 16 - 17041 Altare (SV) - Italy
declare under our responsability that the
product
WATER DISPENSER Model
SMILE, SORGENTE, ISI-T and UNDERCOUNTER
to which this declaration relates is in conformity with the
following standards or other normative documents:
• Household and similar electrical appliances - Safety
- Part 1: General requirements - EN 60335-1:2002
+ A1:2004 + A2:2006 + A11:2004 + A12:2006 +
A13:2008.
• Safety of household and electrical appliances - Part
2-24 : Particular requirements for refrigerating ap-
pliances, ice-cream appliances and ice-makers - EN
60335-2-24:2003 + A11:2004 + A1:2005 + A2:2007.
•
household appliances and similar apparatus with re-
gard to human exposure - EN 62233:2008.
• Household and similar electrical appliances - Safety
- Part 2-15: Particular requirements for appliances for
heating liquids - EN 60335-2-15:2002 + A1:2005 +
A2:2008.
• Electromagnetic compatibility (EMC) - Requirements
for household appliances, electric tools and similar ap-
paratus - Part 1: Emission - EN 55014-1:2006.
• Electromagnetic compatibility (EMC) - Requirements
for household appliances, electric tools and similar ap-
paratus - Part 2: Immunity - Product family standard
- EN 55014-2:1997 + A1:2001.
• Electromagnetic compatibility (EMC) - Part 3-2: Limits
- Limits for harmonic current emissions (equipment in-
put current ≤ 16 A per phase) - EN 61000-3-2:2006.
• Electromagnetic compatibility (EMC) - Part 3-3: Limits
equipment with rated current ≤ 16 A per phase and not
subject to conditional connection - EN 61000-3-3:1995
+ A1:2001 + A2:2005.
Following the provision of the directives:
2004/108/EEC, 2006/95/EC.
Altare (SV) - February 10 th, 2012
Project Manager
Paolo Tesi
Ref. Cetif. No. NO58822
Test Report issued under the responsibility of:

2-1
SORGENTE/SMILE/ISI-T/UNDERCOUNTER - Installation, User and Maintenance - cod. A-MAN03 - Rev. 02/2012
2.1 Available models
SORGENTE - Room temperature, cold, sparkling, micro-
filtrated water dispenser to be connected directly to the
water mains.
SMILE - Room temperature, cold, sparkling, microfiltrated
water dispenser to be connected directly to the water mains.
ISI-T - Room temperature, cold, sparkling, micro-filtrated
stand floor water dispenser to be connected directly to
the water mains.
UNDERCOUNTER - Room temperature, cold, sparkling,
micro-filtrated water dispenser to be connected directly
to the water mains and to position under the sink.
2.1.1 SORGENTE
SORGENTE dispensers are compact and elegant, ready to
always supply micro-filtrated cold still water or room
temperature and sparking. Very easy to install, it can
be adapted to meet any and all requirements. For their
noiseless characteristics these dispensers can be installed
in any environment.
They are controlled by a microprocessor which, through
special sensors, signals any malfunction and turns off the
dispenser when dangerous conditions arise, such as leaks.
Inside the dispenser there is a special monitoring system
that, supported by the chip card, controls the filter ser-
vice life and advises the user when it should be replaced.
Thanks to their low power consumption (less then 1.38W
in Stand-by mode) Sorgente dispensers fully comply with
the strictest regulations while Ozone or UV debacteria-
lization guarantees constant water hygiene. (OPTIONAL)
These dispensers are also available with the 95°C hot
water option: having to press two buttons at the same
time provides additional safety for your children.
2. Technological description
fig.2.2 SORGENTE Joy
fig.2.1 SORGENTE Elite

2-2 SORGENTE/SMILE/ISI-T/UNDERCOUNTER - Installation, User and Maintenance - cod. A-MAN03 - Rev. 02/2012
SORGENTE dispensers can be placed on an elegant stand
that perfectly matches the style of the machine; the stand
is not just a handy complement but can also be used
as a plastic cup container, with 100 cups capacity and/
or as a cabinet.
The SORGENTE dispenser is available in the following
versions:
JOY
Dispenser for micro-filtrated room temperature or
cold water coming from the water mains.
Featured by only 2 dispensing keys:
1 room temperature still water
2 cold still water
ELITE
Dispenser for micro-filtrated room temperature, cold and
sparkling water coming from the water mains.
Featured by three dispensing keys:
1 room temperature still water
2 cold sparkling water
3 cold still water
JOY-H or ELITE-H (HOT WATER)
Dispenser for micro-filtrated room temperature, cold,
sparkling water and hot water coming from the water mains.
Featured by four (Joy) or five (Elite) dispensing keys:
1 room temperature still water
2 cold sparkling water
3 cold still water
4-5 double security dispensing key hot water
fig.2.4 SORGENTE Joy
12
fig.2.5 SORGENTE Elite
123
123
45
fig.2.6 SORGENTE-H
HOT WATER (Elite Version)
fig.2.3 SORGENTE Stand

2-3
SORGENTE/SMILE/ISI-T/UNDERCOUNTER - Installation, User and Maintenance - cod. A-MAN03 - Rev. 02/2012
2.1.2 SMILE
SMILE, the first dispenser in the world which can be fully
customized.
The exclusive panels can be changed with images, logos,
colours and fantasy solutions according to the needs.
Panels can be coloured and customized with an infinite
variety of solutions that make this dispenser unique in any
environment thanks to its elegant and exclusive design.
SMILE water dispenser is the successful result of a new
design developed to give that extra touch of class to our
SORGENTE model.
Compact and elegant, this water dispenser supplies micro-
filtrated still, cold and sparkling water. Very easy to install,
it can be adapted to meet any and all requirements. For its
noiseless characteristic SMILE dispenser can be installed
in any environment.
It is controlled by a microprocessor which, through special
sensors, signals any malfunction and turns off the dispenser
when dangerous conditions arise, such as leaks.
Inside the dispenser there is a special monitoring system
that, supported by the chip card, controls the filter ser-
vice life and advises the user when it should be replaced.
Thanks to its low power consumption (less then 1.38W in
Stand-by mode) SMILE dispensers fully comply with the
strictest regulations while Ozone or UV debacterialization/
sanification guarantees constant water hygiene. (OPTIONAL)
Also SMILE dispensers are available with the 95°C hot
water option: having to press two buttons at the same
time provides additional safety for your children.
SMILE dispenser can be placed on an elegant stand that
perfectly matches the style of the machine; the stand is
not just a handy complement but can also be used as a
plastic cup container, with 100 cups capacity 100 and/
or as a cabinet.
fig.2.7 SMILE
fig.2.8 SMILE Stand

2-4 SORGENTE/SMILE/ISI-T/UNDERCOUNTER - Installation, User and Maintenance - cod. A-MAN03 - Rev. 02/2012
The SORGENTE dispenser is available in the following
versions:
JOY
Dispenser for micro-filtrated room temperature or
cold water coming from the water mains.
Featured by only 2 dispensing keys:
1 room temperature still water
2 cold still water
ELITE
Dispenser for micro-filtrated room temperature, cold and
sparkling water coming from the water mains.
Featured by three dispensing keys:
1 room temperature still water
2 cold sparkling water
3 cold still water
JOY-H or ELITE-H (HOT WATER)
Dispenser for micro-filtrated room temperature, cold,
sparkling water and hot water coming from the water mains.
Featured by four (Joy) or five (Elite) dispensing keys:
1 room temperature still water
2 cold sparkling water
3 cold still water
4-5 double security dispensing key hot water
fig.2.10 SMILE Elite
123
12
34
fig.2.11 SMILE-H
HOT WATER (Joy Version)
fig.2.9 SMILE Joy
12
