Asset ATLANTIS 60 Operating instructions

Rev. February 2011 - Code Man-02-ENG
ASSET S.r.l. Loc. Isola del Pero, 16 - 17041 - ALTARE (SV) - ITALY
Tel: [phone] Fax: [phone] - e-mail: [e-mail] - www.assetitalia.it
ENGLISH
Installation, User and
Maintenance Manual
prodotto conforme
D.M.174/2004
ATLANTIS

ABSENCE
METAL
HEAVY
94/62/CE
prodotto conforme
D.M.174/2004
Certificate Number TIFQ-1206TA03F3P7

I-1
ATLANTIS - Installation, Use and Maintenance - Man cod.-02 - Rev. 02/2011
Table of Contents
CHAPTER 1
INTRODUCTION .................................... 1-3
1.1 General information .................................... 1-3
1.2 Aim ofo the manual .................................... 1-4
1.3 Where and how to keep the manual ................... 1-4
1-4 Manual updating .................................... 1-5
1.5 Cooperation with the user ................................ 1-5
1.6 Manufacturer .................................... 1-6
1.7 Manufacturer’s responsibility and warranty ........ 1-7
1.7.1 warranty terms .....................................1-7
1.8 Thecnical assistance service .............................. 1-8
1.9 Copyright .................................... 1-8
CHAPTER 2
TECHNOLOGICAL DESCRIPTION .................................... 2-1
2.1 Available models .................................... 2-1
2.1.1 atlantis 60/120 .....................................2-1
2.2 Technical data .................................... 2-2
2.3 Emission of machine noise ............................... 2-5
CHAPTER 3
SAFETY REQUIREMENTS .................................... 3-1
3.1 General notes .................................... 3-1
3.2 Symbols .................................... 3-1
3.3 Safety warnings .................................... 3-2
3.3.1 operator’s qualification .....................................3-3
CHAPTER 4
UNPACKING .................................... 4-1
4.1 Visial check .................................... 4-1
4.1.1 check of machine and equipment supplied ..............4-1
4.2 Unpacking .................................... 4-2
4.3 Packing list .................................... 4-2
CHAPTER 5
INSTALLATION .................................... 5-1
5.1 Environmental characteristics ........................... 5-1
5.2 Cleaning .................................... 5-1
5.3 Positioning .................................... 5-1
5.4 Connections .................................... 5-2
5.4.1 outer accessories .....................................5-2
5.4.2 taps assembly .....................................5-3
5.4.3 water filter insertion (optional) ...........................5-4
5.4.4 insertion of the litrecounter (optional) .................5-4
5.4.5 connection to the water mains ............................ 5-5
5.4.6 power supply connection ....................................5-6
5.4.7 connection of the Co2 .....................................5-7

I-2 ATLANTIS - Installation, Use and Maintenance - Man cod.-02 - Rev. 02/2011
CHAPTER 6
DISPENSER USE ....................................6-1
6.1 Control panel ....................................6-1
6.2 First start up ....................................6-2
6.3 Temperature setting ....................................6-4
6.4 Ice bank defrosting ....................................6-4
6.5 Ice bank emptying and ice bank water
replacement .................................... 6-5
6.6 Touch screen user interface .............................. 6-6
6.7 Anomalies signalling leds ................................ 6-7
6.8 Touch Models Dispay .................................... 6-7
6.9 Water Temperature Adjustment ........................ 6-8
6.10 Energy Saving Function .................................... 6-8
6.11 Automatic Water Dispesing Dosage ................... 6-9
6.12 Enable Tone .................................. 6-10
6.13 Keyboard Lock .................................. 6-11
6.18 Dedicated Litre Counter .................................. 6-12
6.19 Firmware Version .................................. 6-12
CHAPTER 7
TROUBLE SHOOTING .................................... 7-1
7.1 Solutions to problems .................................... 7-1
CHAPTER 8
MAINTENANCE .................................... 8-1
8.1 Ordinary scheduled maintenance cycles
(HACCP) .................................... 8-1
8.2 Replacement of the monouse or rechargeable
CO2 bottle .................................... 8-2
8.2.1 replacement of the monouse bottle ...................... 8-2
8.2.2 replacement of the rechargeable bottle ..................8-2
8.3 Filter replacement .................................... 8-3
8.4 Replacement of the UV lamp (outer accessory) .. 8-5
8.5 Cleaning .................................... 8-5
8.6 Water dispenser sanitization ............................. 8-6
8.6.1 dispenser sanitization procedure
(with Everpure filter) ..................................... 8-6
8.6.2 Tap sanitization .....................................8-7
8.7 Technical assistance .................................... 8-8
CHAPTER 9
DISMANTLING .................................... 9-1
9.1 Dispenser dismantling .................................... 9-1
9.2 Electronic components disposal ........................ 9-1
CHAPTER 10
SPARE PARTS .....................................10-1
10.1 Identification and ordering modes .....................10-1

I-3
ATLANTIS - Installation, Use and Maintenance - Man cod.-02 - Rev. 02/2011

I-4 ATLANTIS - Installation, Use and Maintenance - Man cod.-02 - Rev. 02/2011

I-5
ATLANTIS - Installation, Use and Maintenance - Man cod.-02 - Rev. 02/2011
Pictures summary
CHAPTER 1
INTRODUCTION .................................... 1-3
Fig
1.1 Atlantis ..................................... 1-3
1.2 Atlantis 180 Touch .....................................1-3
1.3 Atlantis 180 US .....................................1-3
1.4 Identification label on the dispenser back side .......1-6
CHAPTER 2
TECHNOLOGICAL DESCRIPTION .................................... 2-1
Fig
2.1 Atlantis ..................................... 2-1
2.2 Atlantis parts description .................................... 2-2
CHAPTER 4
UNPACKING .................................... 4-1
Fig
4.1 Packaging ..................................... 4-1
CHAPTER 5
INSTALLATION .................................... 5-1
Fig
5.1a Outer connections on upper part of Atlantis 120 .....5-2
5.1b Outer connections on back side of Atlantis 120 ....... 5-2
5.2 Outer connections on back side of Atlantis 60 .........5-2
5.3 Taps assembly ..................................... 5-3
5.4 Taps tightening .....................................5-3
5.5 Stainless steel tap for sparkling water ...................5-3
5.6 Spanner for taps tightening .................................5-3
5.7 Litrecounter .....................................5-4
5.8 Drinking water pipe connection to mains ...............5-5
5.9 Power supply cable connection .............................5-6
5.10 CO2 gas pipe connection .....................................5-7
5.11 Rechargeable bottle .....................................5-7
5.12 Rechargeable bottle pressure reducer ..................... 5-7
5.13 Monouse bottle .....................................5-7
5.14 Rechargeable bottle opening ................................5-8
5.15 Pressure reducer opening .....................................5-8
CHAPTER 6
START UP AND OPERATION .................................... 6-1
Fig
6.1 Atlantis ..................................... 6-1
6.2 Control panel .....................................6-1
6.3 Dispenser upper cover opening .............................6-2
6.4 Dispenser upper part .....................................6-2
6.5 Rechargeable bottle opening ................................6-2
6.6 Pressure reducer adjustment .................................6-2

I-6 ATLANTIS - Installation, Use and Maintenance - Man cod.-02 - Rev. 02/2011
6.7 Dispenser upper part .....................................6-3
6.8 Safety valve ring ..................................... 6-3
6.9 Cold water dispensing tap .................................... 6-4
6.10 Thermostat for water temperature adjustment ......... 6-4
6.11 Control Panel (Touch Models) ...............................6-7
CHAPTER 8
MAINTENANCE .................................... 8-1
Fig
8.1 Monouse bottle replacement ...............................8-2
8.2 Rechargeable bottle replacement .........................8-2
8.3 Chip card slot (Touch Model only) ........................8-4

1-1
ATLANTIS - Installation, Use and Maintenance - Man cod.-02 - Rev. 02/2011
Dear Customer,
Asset Srl would like to thank you and congratulate for your
choice.
Water is a vital and essential element. Water represents 70%
of the human body and, every day, we ought to drink at least
2 litres of it to be in health and to refresh ourselves.
For this reason, the most important thing to do is to be sure of
the goodness and quality of the water we daily drink.
This useful and functional dispenser with MICROFILTRATION
system is manufactured with the most modern and innovative
technologies. Its quality materials are subjected to a rigorous
control according to our company standard. All the materials
and components are tested during the entire production proc-
ess to satisfy your expectations.
MICROFILTRATION is a filtration process which removes sol-
id particles from a fluid by passage through a microporous
membrane. Microperforated copper or silver scales, which are
natural antibacterial metals, are sometimes added to water
MICROFILTRATION so that an articulated pre-filtration process
is set, based on use of natural active principles (vegetal acti-
vated carbon) able to extensively collect and hold sediments,
chlorine and other polluting substances.
ASSET uses exclusively Filters certificated by the Italian Min-
istry of Heath.
ATTENTION: On the table shown on the next page it is possible
to check which elements are filtered by the dispenser through
MICROFILTRATION.
We ask you to read and respect these simple instructions to
guarantee the best results, since at the first use of the dis-
penser.
This manual includes important information, not only for the
use but, also, for your safety and for maintenance; it is part
of the machine.
ATTENTION: It is necessary to carry out periodi-
cal maintenance on this device in order to preserve
the drinkable characteristics of dispensed water.

1-2 ATLANTIS - Installation, Use and Maintenance - Man cod.-02 - Rev. 02/2011

1-3
ATLANTIS - Installation, Use and Maintenance - Man cod.-02 - Rev. 02/2011
1.1 General information
The machine is realized in compliance with the directives
in force in the European Community and with the required
technical rules, as certified by the Declaration of Conformity
issued by the Manufacturer and enclosed to the manual.
This publication, hereinafter simply called the ”manual”,
includes all the information for use and for a safe main-
tenance of the device mentioned in the Declaration of
Conformity.
This device, that in the course of the manual will be ge-
nerically called “machine” or “dispenser”, is manufactured
by the company ASSET srl, whose details are indicated
hereinafter in this publication.
This publication is intended for subjects, generically
defined as ‘users’, who are intended to use the machine.
In particular, they can be identified as follows:
- operators directly involved in transport, storage, in-
stallation, use and ordinary/extraordinary maintenance
of the machine, from its launch onto the market up to
the day of disposal;
- direct users.
The original text of this publication, drawn up in Italian
language, represents the only reference for the settlement
of possible disputes related to the interpretation of the
translation in the community languages.
This publication must be considered as an integral part
of the machine, and therefore it must be preserved for
future reference up to the final disposal and scrapping
of the machine.
1. Introduction
fig.1.1 ATLANTIS 60/120
fig.1.2 ATLANTIS 180 Touch TT
fig.1.3 ATLANTIS 180 US

1-4 ATLANTIS - Installation, Use and Maintenance - Man cod.-02 - Rev. 02/2011
1.2 Aim of the manual
The aim of this manual is to give the indications to use
the machine safely and to carry out the ordinary main-
tenance procedures.
Any calibrations, adjustments and extraordinary mainte-
nance operations are not included in this booklet, since
they are carried out exclusively by the service techni-
cian, that must operate on the machine in respect of
the technical and project characteristics for which is
was manufactured.
The machine intended use and configuration are the only
ones admitted by the Manufacturer; do not try to use
the machine disagreeing with the indications supplied.
Any other use or configuration must be previously agreed
upon with the Manufacturer in writing, and be enclosed
to this manual.
Concerning installation and use, the user must follow the
specific laws in force in the Nation where the machine
is installed.
The user is expected to know and consult the laws,
directives, etc. recalled in the text in order to achieve
the aims that the manual sets.
1.3 Where and how to keep the
manual
This manual (and any possible enclosures related to it)
must be kept in a protected and dry place, and always
be available for reference.
It is recommended to make a copy of the manual and
keep it in the archive.
Refer to the data of the machine identification label
when exchanging information with the Manufacturer or
with authorized assistance staff.
This manual must be kept for the whole life of the machine,
and in case of need (for ex. damage that compromises
consulting it also partially) the user must obtain a new
copy by requesting it exclusively to the Manufacturer,
indicating the publication code positioned on the cover.

1-5
ATLANTIS - Installation, Use and Maintenance - Man cod.-02 - Rev. 02/2011
1.4 Manual updating
The Manual reflects the machine state of art at the time
of its launch onto the market, being an integral part of it.
The publication is compliant with the directives in force
at that time; the Manual cannot be considered unsuitable
further to possible updates of standards or modifications
on the machine.
Any supplements of the Manual that the Manufacturer
considers suitable to send to the users, must be kept with
the Manual and become an integral part of it. To check if
this Manual version is the last one available, please visit
the Manufacturer website at www.assetitalia.it , where –
on every single product page - it is possible to download
the electronic version (as a pdf file) of the last updated
Manual release.
1.5 Cooperation with the user
The Manufacturer is available to supply additional infor-
mation to customers and to consider any suggestions for
improvement in order to bring this manual more into line
with the requirements for which it was published.
If the machine is sold, the original user must give this
manual to the new user and communicate the address
of the new owner to the manufacturer so that it may be
provided with any essential information or updates.
All property rights of the contents included in this publi-
cation are reserved to Asset s.r.l., therefore it cannot be
reproduced totally or partly unless written authorization
by the manufacturer.

1-6 ATLANTIS - Installation, Use and Maintenance - Man cod.-02 - Rev. 02/2011
1.6 Manufacturer
The machine identification data are included
in the label positioned on the rear of the
machine.
The label includes the following data in this order:
- model;
- serial number;
- power supply voltage (V), frequency (Hz), absorbency
only of the refrigerant part (A) and the pertaining
Climatic Class;
- type of refrigerant and quantity in grams;
- maximum pressure of the water supply to which the
dispenser can be connected (kPa);
- maximum pressure of the CO2 supply to which the
dispenser can be connected (kPa);
- country of manufacture;
- European CE conformity marking
ATTENTION: The removal or, however, every type of
tampering of the identification label, makes the
warranty expire.
fig.1.3

1-7
ATLANTIS - Installation, Use and Maintenance - Man cod.-02 - Rev. 02/2011
1.7 Manufacturer’s responsibility
and warranty
In order to take advantage of the warranty supplied by the
Manufacturer, the user must carefully follow the measures
indicated in the manual, and in particular:
- always operate within the machine limit of use;
- always carry out constant and accurate cleaning and
maintenance operations;
The manufacturer declines any responsibility, direct and
indirect, caused by:
- machine use different than what indicated in this
manual;
- use by staff who did not read and fully understand the
contents of this manual;
- use not in conformity with specific standards in force
in the Country of installation;
- modifications carried out on the machine, on the
software, on the operation logic, if not authorized in
writing by the Manufacturer;
- unauthorized repairs;
- exceptional events.
If the machine is sold to third parties also this manual
must be delivered to the new owner; any right of the Pur-
chaser will be automatically invalided if the manual is not
delivered, including the warranty terms where applicable.
If the machine is sold to third parties, in a Country where
is spoken a different language than the language indicated
in this manual, the old user is responsible to supply a
faithful translation of this manual in the language of the
Country where the machine will operate.
1.7.1 Warranty terms
The machine is guaranteed by ASSET srl for a 24 (twenty
four) month period from the invoice date.
This guarantee covers manufacturing and assembling defects.
ASSET srl undertakes to replace or repair at is own charge
at its factory, carriage free, any part that the manufacturer
considers defective.
If service by a repair technician of the Manufacturer (or
by a authorized technician) is required at the user’s site,

1-8 ATLANTIS - Installation, Use and Maintenance - Man cod.-02 - Rev. 02/2011
it is understood that the travel, board and lodgings costs
are at user’s charge.
The acknowledgment of a free supply of the parts under
warrantee is always subject to inspection by the Manu-
facturer (or authorized person).
The extension of guarantee following a technical inter-
vention or repair of the machine is excluded;
Damages to the machine are not included in the war-
rantee if caused by:
- transport;
- negligence;
- improper use and/or not in conformity with the
instructions given in the use manual;
- wrong electrical connection.
The warranty becomes null and void in case of:
- repairs carried out by staff not authorised of the
Manufacturer;
- modifications not authorized by the Manufacturer;
- use of parts and/or equipment not supplied or ap-
proved by the Manufacturer;
- identification label removal or tampering.
1.8 Technical assistance service
For any intervention of technical service directly contract
the Manufacturer or the authorised Dealer, and always
indicate the model and the serial number, imprinted on
the identification label.
1.9 Copyright
The information contained in this manual must not be
disclosed to third parties. Any reproduction, partial or
total, not authorized in writing by the Manufacturer,
obtained by photocopying, reproduction or with other
systems, also electronic acquisition, infringes the copyright
conditions and will be prosecuted according to the law.

1-9
ATLANTIS - Installation, Use and Maintenance - Man cod.-02 - Rev. 02/2011
DICHIARAZIONE DI CONFORMITA’ CE
2004/118/EC, EC 2006/95/EC.
ASSET S.r.l.
Loc. Isola del Pero, 16 - 17041 Altare (SV) - Italy
dichiariamo sotto la nostra responsabilità che il
prodotto
EROGATORE D'ACQUA Modello
ATLANTIS
al quale si riferisce questa dichiarazione è conforme
alle seguenti norme:
• Sicurezza di elettrodomestici e apparecchi elettri-
ci - Parte 1 - Requisiti generali - EN 60335-1 (2002)
+ A1(2004) + A2(2006) + A11(2004) + A12 (2006) +
A13(2008).
• Sicurezza di elettrodomestici e apparecchi elettrici -
Parte 2-24 - Requisiti specici per apparecchiature re-
frigeranti, gelatiere e produttori di ghiaccio - EN 60335-
2-24:2003 + A11:2004 + A1:2005 + A2:2007.
• Metodi di misurazione per campi elettromagnetici in
apparecchi elettrici di uso domestico e similari con ri-
ferimento all’esposizione umana - EN 62233:2008.
• Sicurezza di elettrodomestici e apparecchi elettrici
- Parte 2-15 - Requisiti specici per apparecchi per
riscaldare liquidi - EN 60335-2-15:2002 + A1:2005 +
A2:2008.
• Compatibilità elettromagnetica (EMC) - Requisiti di
emisissioni per apparecchi elettrici di uso domestico e
similari - Parte 1 - Emissioni - EN 55014-1:2006.
• Compatibilità elettromagnetica (EMC) - Requisiti di
immunità per apparecchi elettrici di uso domestico e
similari - Parte 2 - Immunità - Norma per famiglia di
prodotti - EN 55014-2:1997 + A1:2001.
• Compatibilità elettromagnetica (EMC) - Parte 3-2 - Li-
miti - Limiti per le emissioni di corrente armonica (cor-
rente in ingresso dell’apparecchiatura ≤ 16A per fase)
- EN 61000-3-2:2006.
• Compatibilità elettromagnetica (EMC) - Parte 3-3 - Li-
miti - Limitazione delle uttuazioni del voltaggio e dei
picchi di tensione nei sistemi di alimentazione a bassa
tensione per apparecchiature con corrente nominale ≤
16A. - EN 61000-3-3:1995 + A1:2001 + A2:2005.
Secondo le disposizioni delle direttive:
2004/108/EEC, 2006/95/EC.
Altare (SV), lì 15/01/2011
Project Manager
Paolo Tesi
EC DECLARATION OF CONFORMITY
2004/118/EC, 2006/95/EC.
ASSET S.r.l.
Loc. Isola del Pero, 16 - 17041 Altare (SV) - Italy
declare under our responsability that the
product
WATER DISPENSER Model
ATLANTIS
to which this declaration relates is in conformity with the
following standards or other normative documents:
• Household and similar electrical appliances - Safety
- Part 1: General requirements - EN 60335-1:2002
+ A1:2004 + A2:2006 + A11:2004 + A12:2006 +
A13:2008.
• Safety of household and electrical appliances - Part
2-24 : Particular requirements for refrigerating ap-
pliances, ice-cream appliances and ice-makers - EN
60335-2-24:2003 + A11:2004 + A1:2005 + A2:2007.
• Measurement methods for electromagnetic elds of
household appliances and similar apparatus with re-
gard to human exposure - EN 62233:2008.
• Household and similar electrical appliances - Safety
- Part 2-15: Particular requirements for appliances for
heating liquids - EN 60335-2-15:2002 + A1:2005 +
A2:2008.
• Electromagnetic compatibility (EMC) - Requirements
for household appliances, electric tools and similar ap-
paratus - Part 1: Emission - EN 55014-1:2006.
• Electromagnetic compatibility (EMC) - Requirements
for household appliances, electric tools and similar ap-
paratus - Part 2: Immunity - Product family standard
- EN 55014-2:1997 + A1:2001.
• Electromagnetic compatibility (EMC) - Part 3-2: Limits
- Limits for harmonic current emissions (equipment in-
put current ≤ 16 A per phase) - EN 61000-3-2:2006.
• Electromagnetic compatibility (EMC) - Part 3-3: Limits
- Limitation of voltage changes, voltage uctuations
and icker in public low-voltage supply systems, for
equipment with rated current ≤ 16 A per phase and not
subject to conditional connection - EN 61000-3-3:1995
+ A1:2001 + A2:2005.
Following the provision of the directives:
2004/108/EEC, 2006/95/EC.
Altare (SV) - February 15th, 2011
Project Manager
Paolo Tesi

1-10 ATLANTIS - Installation, Use and Maintenance - Man cod.-02 - Rev. 02/2011
Intentionally blank page

2-1
ATLANTIS - Installation, Use and Maintenance - Man cod.-02 - Rev. 02/2011
2.1 Available models
1 ATLANTIS 60
2 ATLANTIS 120
3 ATLANTIS 180 Touch TT
ATLANTIS 60 and ATLANTIS 120 featured by three lever
dispensing taps.
ATLANTIS 180 Touch featured by a front Touch panel with
a multi-function display.
2.1.1 ATLANTIS 60/120/180
Stainless steel and first quality Italian components ensure
reliability and strength to this Made in Italy gem.
ATLANTIS is the new range of water dispensers, table
top and under counter, that Asset has conceived for the
HoReCa (Hotel, Restaurant, Cafè) sector.
Asset is present where best performance and immediate
support is required, making available to the Customer a
direct pre-sale consulting line and an after-sales support,
very important values in this professional segment.
By using the “Ice Bank” technology, the ATLANTIS range
dispenses 60, 120 or 180 litres per hour, completely sat-
isfying the demand of small, medium and big restaurants
with high performances and compact dimensions.
The ATLANTIS 60/120/180 range is a quiet, easy to install
and use dispenser with low power consumption that stands
out for its stylish line and compactness.
2. Technological description
fig.2.1
ATLANTIS 60/120
ATLANTIS 180 Touch TT

2-2 ATLANTIS - Installation, Use and Maintenance - Man cod.-02 - Rev. 02/2011
1 cold sparkling water dispensing tap;
2 room temperature water dispensing tap;
3 cold water dispensing tap;
4 drip tray equipped with supporting grid.
2.2 Technical data
The following data are related to the dispenser with
serial configuration.
ATLANTIS 60
TABLE TOP
POWER SUPPLY VOLTAGE 220/230V 50/60Hz
monophase
MAX POWER CONSUMPTION 670W - 2,9A
Climatic Class SN
ROOM WORK TEMPERATURE 10-32 °C / 50-89,6°F
COMPRESSOR POWER Hermetic 65W
QUANTITY OF REFRIGERANT GAS R134a 98g
CONDENSATION OF VENTILATED AIR YES
WATER PUMP TYPE Rotary
fig.2.2
