LINDR Green Line AS-110-US User manual

VCH 02236 AS-110-us Green Line
LINDR FLOW-THROUGH
WATER COOLING
ENGLISH
Number 007-2020 Valid 2020-01-01

2

ˇ
3
LINDR.CZ s.r.o.
Sadová 132
503 15 Nechanice, Czech Republic
mob.: + 420 778 070 276
tel.: [phone]
e-mail: [email protected]
web: www.lindr.cz, www.lindr.eu
This manual contains instructions for installation, use and
operation of the appliance. This manual is an integral part of
the device.
It must be stored in the vicinity of the device for the entirety of
its service life and must be made available to the user any time
the device is installed, moved, used or maintained.
Read this manual carefully before installing and using the
device. It contains important information necessary to ensure
that all operations are done properly and safely.
This manual is a translation of the original Czech manual.

4
Contents:
1.
Introduction
…...............................................................
6
2.
Description of the cooler
…...............................................................
6
3.
Machine plate
…...............................................................
6
4.
General instructions, measures and safety
instructions
…...............................................................
7
5.
Installation and placement
…...............................................................
8
6.
Electrical connection
…...............................................................
10
7.
Testing
…...............................................................
10
8.
Warranty
…...............................................................
10
9.
Description of the cooler
…...............................................................
11
10.
Beverage inlets and outlets
…...............................................................
12
11.
Thermostat placement
…...............................................................
13
12.
Temperature and adjustment
…...............................................................
13
13.
Putting into operation
…...............................................................
14
14.
Interconnecting beverage tubing
…...............................................................
15
15.
Pouring water into the tank
…...............................................................
16
16.
Keg tapping and untapping
…...............................................................
18
17.
How to work with rapid couplings
…...............................................................
25
18.
Environmental protection
…...............................................................
26
19.
Maintenance
…...............................................................
26
20.
Inspection before every use
…...............................................................
26
21.
Periodic checks
…...............................................................
27
22.
Cleaning the condenser
…...............................................................
27
23.
Sanitation by water
…...............................................................
30
24.
Table of malfunctions
…...............................................................
31
25.
Spare parts
…...............................................................
32
26.
Technical data
…...............................................................
33
27.
Wiring diagram
…...............................................................
34
28.
Cooling diagram
…...............................................................
35

ˇ
5
Symbols and Markings Used in the Manual:
WARNING:
Not following instructions may cause injury or damage the
device.
WARNING:
Risk of injury by electrical current.
NOTE:
This symbol indicates information and recommendations for
the user.
WARNING: The cooling system contains
flammable coolant R290 (propane)!

6
1. Introduction:
Thank you for purchasing this LINDR
product.
2. Description of the cooler:
The cooler is designed for professional
cooling of beverages and dispensing
and serving well cooled beer and
beverages from a keg.
This dispensing system is the elite
among professional undercounter
coolers.
The Lindr modern compressor cooling
unit uses input energy and transforms it
directly into cooling, ensuring proper
beer cooling at minimum energy drain.
Cooling is transferred to the beverage
via a water bath and a stainless heat
exchanger (beer cooling coil). If the
thermostat is set to max., the device can
accumulate a large amount of energy in
the form of an ice bank which can then
be used to dispense well cooled beers
in quick sequence one after another.
The time required to accumulate this
energy is approx. 90-120 min.,
depending on the initial water
temperature and the ambient
temperature. Lindr cooling technology is
45 % more powerful than its electric
input power.
The cooler is equipped with an
aftercooling pump which also stirs the
water bath to increase the effectiveness
of the heat exchange. The cooler body
is built from galvanised sheet metal with
a plastic surface finish, while the coil is
made of stainless steel. The materials
used meet the strictest hygienic
standards and guarantee long service
life of the cooler.
3. Product label:

ˇ
7
4. General Instructions,
Measures and Safety
Instructions:
When using the device, follow basic
safety instructions stated by the
manufacturer. The cooling device is
designed for flow cooling of beverages
dispensed from kegs. Any other use is
considered impermissible and therefore
dangerous. The supplier is not liable for
damage caused by incorrect use.
DO NOT USE THE DEVICE FOR
PURPOSES OTHER THAN THOSE
STATED BY THE MANUFACTURER!
General safety principles. Observe
the following safety instructions.
The supplier is not liable for damage
caused by activities carried out on this
device without observing the following
instructions!
WARNING: Children aged 15 or
more and persons with reduced
physical, sensory or mental capabilities
or insufficient experience and
knowledge may only use the device
when supervised or instructed in safe
use of the appliance and familiarised
with potential dangers.
WARNING: Children must not be
allowed to play with the appliance. Store
all packaging material out of reach of
children (comes with a plastic bag –
suffocation hazard).
WARNING: Cleaning and
maintenance of the appliance on the part of
the user must not be done by unsupervised
children.
WARNING: Before connecting to main
electrical supply, check that the voltage and
frequency in the mains corresponds to the
data stated on the device.
WARNING: Always make sure that the
socket you intend to plug the cooler into
meets the specifications on the machine
plate (voltage, frequency, input power).
WARNING: Before any interference
with the device, such as cleaning or
maintenance, ALWAYS disconnect the
device from power supply: set the
thermostat to "O" position and unplug the
appliance from the socket.
WARNING: Never place tools or other
object into the fan.
WARNING: Never touch electrical
components with wet or damp hands.
WARNING: To ensure the cooling unit
works properly and at full capacity, make
sure air supply to the unit is not obstructed.
WARNING: Water temperature
during sanitation must not be higher than
25 °C!
WARNING: Always make sure the
power socket you intend to plug the cooler
into is accessible, so that the appliance can
be immediately unplugged in case of
emergency.
WARNING: When unplugging the
device from the socket, grab the plug and
pull it out. Do not under any circumstances
pull at the cable; risk of damage.

8
WARNING: To turn the device off
completely, unplug the appliance from the
power socket.
WARNING: In the event the electrical
wiring of the product becomes damaged,
summon a trained service technician. Do not
under any circumstances repair the device
yourself.
WARNING: The cooling systém
contains flammable coolant R290
(propane)!
WARNING: Emergency maintenance
and repair of the cooling system must be
done by trained, authorised technicians
familiar with cooling and electrical systems.
The technicians should have special training
and qualification for handling flammable
substances in order to perform service on
coolers containing R290 coolant. Follow
basic regulations and safety measures
regarding service and repair!
WARNING: Do not use an open flame
or potential sources of sparks in the vicinity
of a cooler using R290 coolant!
WARNING: After unpacking, place the
cooler so that heat created by the cooling
unit can be vented sufficiently.
WARNING: Do not place objects that
could prevent air circulation on top of the
cooler.
5. Instalation and Placement:
Place the cooler onto a stable, level surface
(maximum permitted inclination: 2 degrees).
The appliance requires unobstructed air
circulation.
Ensure sufficient free space for air
circulation and heat dissipation.
Ensure sufficient supply of fresh air.
The device must not be placed in an
enclosed space.
The device must not be placed in
the vicinity of heat sources or
exposed to
direct sunlight.
Minimum required distances of vents from
an obstacle that prevents air circulation are
listed on page 8. Ideally, use the device in a
cool and well ventilated room. The device is
designed for use at ambient temperature of
at least 16 °C and at most 32°C.

ˇ
9
V Clearances, mm (inch)
Model
Top
Rear
Right Side
Left Side
Front
AS-110-us
200 (7.87)
200 (7.87)
508 (20)
70 (2.76)
200
(7.87)

10
The device MUST NOT be used or stored
at ambient temperature lower than 0 °C.
The device is designed for use in a normal
environment, always indoors, protected from
rain or sunlight. Climate class N.
WARNING: Protect the cooler and
electrical connection from rain and spraying
water!
WARNING: Do not under any
circumstances lay the cooler on its side, not
even during transport.
NOTE: In order for the device to
work correctly and at maximum output, it is
important to not cover up any of the device's
vents and ensure sufficient air circulation.
6. Electrical Connection:
Connect the device to a power socket in
accordance with specifications on the
product label of the device. Electrical wiring
is subject to local regulations. If the power
lead (cable) is damaged, it must be replaced
by the manufacturer, the manufacturer's
service technician or a similarly
qualified person to prevent risk of hazardous
situations.
WARNING: Do not use or turn on
the device if the power lead (cable) is
damaged!
7. Testing:
The product is delivered ready for immediate
use.
8. Warranty:
The device comes with a warranty in
accordance with general legal regulations of
the Czech Republic or in accordance with
the trade agreement. During the validity
period of the warranty, we will remove any
defects on the product free of charge,
provided these defects were not caused by
excess wear, improper handling, incorrect
storage or by using the product in a way that
is counter to the instruction manual or the
product's design as defined by the
manufacturer. Materials replaced during the
validity period of the warranty are our
property. The legitimacy of the warranty
claim is always decided by an authorised
service centre. Warranty provided by a
retailer outside of the territory of the Czech
Republic is governed by the agreement
between the retailer and the buyer in their
mutual relationship; this agreement is not
directly linked to the manufacturer. The
agreement does not give the buyer the right
to submit warranty claims to the
manufacturer. Transport expenses or other
costs are not covered by the warranty.
Attention:
Electrical devices and appliances must be
checked/inspected at a time stipulated by
valid legislation of the country the device is
operated in. Inspection of wiring may only be
done by a person with valid authorisation for
this activity. Service work, provision of spare
parts and inspection is done by the
manufacturer or an authorised service
centre.

ˇ
11
9. Description of the cooler:
1
Thermostat
6
Inlet beverage - speed fiting 3/8“
(9,5mm)
2
Main switch
7
Outlet beverage - speed fiting
3/8“ (9,5mm)
3
Pump socket
8
Outlet cold water-speed fiting
1/2“ (12,7mm)
4
Product label
9
Pump
5
Power cable
10
Condenser

12
10. Beverage inlets and outlets:
The beverage inlet and outlet is fitted with a 3/8“ speed fiting (9.5 mm), while the
pump outlet is fitted with a 1/2" (12.7 mm) speed fiting.
Beverage outlet
Beverage inlet
Outlet cold water

13
č.1 = max. beverage
temperature of 12 °C
11. Thermostat placement:
The mechanical thermostat with 1 -7
numerical scale located on the front of
the cooler.
12. Temperatureand adjustment:
The temperature of the cooled beverage is controlled by a mechanical thermostat. The
thermostat has a numerical scale of 1-7. Setting the thermostat to 6-7 creates an ice bank
(ice accumulation). Setting the thermostat to 1-5 regulates the temperature of cooled water in
1 °C – 12 °C
0 = off
č.7 = ice bank

14
13. Putting into operation:
The device requires professional installation by a qualified firm including training of
the operator (owner) and operating staff.
1. Interconnect the beverage tubing according to point 14.
WARNING: Check the connection of the pump outlet - until it is
connected, water will pour out of the pump after when the device is
turned on.
2. Fill the tank with clean water or glycol in accordance with point 15.
3. Connect the cooler to the power mains.
4. Tap the keg in accordance with point 16.
5. Check that all the joints and connections are sufficiently tightened.
WARNING: If leakage is found, untap the keg according to point 16
and turn off the device. Fix any leaks found on the tubing. If a leak is
found inside the device or you are unsure how to proceed, contact a
service centre.
6. Set the desired temperature on the thermostat –see point 12.
7. Turn on the device using the main switch.
8. The beverage is now cooling; once cooled (in ca. 90 minutes) you can start
pouring the first drink.
WARNING: BEFORE STARTING THE DEVICE, FILL THE TANK WITH CLEAN
WATER. DO NOT USE ANY CHEMICAL AGENTS. COULD CAUSE DAMAGE TO THE
COOLING SYSTEM. FOR SPECIAL APPLICATIONS REQUIRING COOLING TO SUB-ZERO
TEMPERATURES, IT IS POSSIBLE TO USE AN ECO-FRIENDLY ANTIFREEZE MIXTURE
BASED ON PROPYLENE GLYCOL.

ˇ
15
14. Interconnecting beverege tubing:
The figure shows a model example of connection.

16
15. Pouring water into the tank:
1. Remove the two screws holding the lid.
WARNING: Always disconnect the device from power before pouring in
water.
2. Remote the lid.

ˇ
17
3. Pour water all the way up to the overflow, the cooling coils must be
submerged.
4. Replace the lid and secure it with screws.

18
16. KEG TAPPING AND UNTAPPING
WARNING:
Make sure the adapter is clean before tapping the keg!
S system keg coupler:
Procedure for tapping and untapping a keg with an S system keg coupler:
1. Keg tapping:

ˇ
19

20
2. Keg untapping:
