Astria Fireplaces Aries C Series User manual

- Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
any phone in your building.
• Leave the building immediately.
• Immediatelycallyourgassupplierfromaneigh-
bor’s phone. Follow the gas supplier’s instruc-
tions.
• If you cannot reach your gas supplier, call the
fire department.
- Installation and service must be performed by
a qualified installer, service agency or the gas
supplier.
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could
resultinseriousinjury,death,orpropertydamage.
AVERTISSEMENT:
RISQUED’INDENDIE OU D’EXPLOSION
Le non-respect Des avertissements de sécurité
pourrait d’entraîner des blessures graves, la mort
ou des dommages matériels.
- Ne pas entreposer ni utilizer d’essence ni d’autres
vapeursouliquidesinflammablesdanslevoisinage
de cet appareil ou de tout autre appareil.
- QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE GAZ:
• Ne pas tenter d’allumer d’appareil.
•Netouchezàaucaninterrupteur.Nepasvousservir
des téléphones se trouvant dans le bâtiment où
vous trouvez.
• Sortez immédiatement de bâtiment.
• Appelez immédiatement votre fournisseur de
gaz depuis un voisin. Suivez les instructions du
fournisseur.
• Si vous ne pouvez rejoindre le fournisseur de gaz,
appelez le service des incindies.
- L’installationetl’entretiendoiventêtreassuréspar
un installateur ou un service d’entretien qualifié
ou par le fournisseur de gaz.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future
reference.
Installateur : Laissez cette notice avec l’appareil.
Consommateur : Conservez cette notice pour
consultation ultérieure.
This appliance may be installed in an aftermarket permanently located, manufactured home (USA only)
or mobile home, where not prohibited by local codes. This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is not convertible for use with other gases, unless a certified kit
is used.
Cet appareil peut installé dans une maison préfabriquée (mobile) déjà installée à demeure, si les réglements
locaux le permettent. Ce appareil doit être utilisé uniquement avec le type de gaz indiqué sure la plaque
signalétique. Cet appareil ne peut être converti à d’autres gaz, sauf si une trousse de conversion est utilsée.
Installation and Operation Instructions
Models
CU
S
Report No. F13-094
Ce manuel est disponible en francais, simplement
en faire la demande. Numéro de la pièce 900921-02
P/N 900921-00 REV. E 06/2019
Aries™ -C Series Millivolt Direct-Vent Gas Fireplaces
P900921-00
ARIES35RMN-C
ARIES35RMP-C
ARIES35TMN-C
ARIES35TMP-C
ARIES40RMN-C
ARIES40RMP-C
ARIES40TMN-C
ARIES40TMP-C

General Information
900921-00E, 06/2019
Innovative Hearth Products
Aries™ -C Series Direct-Vent Gas Fireplaces
2
DANGER
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
A barrier* designed to reduce the risk of burns from the hot viewing glass is pro-
vided with this appliance and must be installed for the protection of children and
other at-risk individuals. *Included with required facade.
DANGER
VITRE CHAUDE
RISQUE DE BRÛLURES.
NE TOUCHEZ PAS UNE VITRE
NON REFROIDIE.
NE LAISSEZ JAMAIS UN ENFANT
DE TOUCHER LA VITRE.
L’écran pare-étincelles* fourni avec ce foyer réduit le risque de brûlure en cas de
contact accidentel avec la vitre chaude et doit être installé pour la protection Des
enfants et Des personnes à risques. *incluse avec le Facade - Requis.
Vea el volante adjunto para la representación de color adecuado
See attached color flyer for proper color representation
Voir ci-joint tract pour une bonne représentation de la couleur
SAFETY AND YOUR FIREPLACE
PELIGRO
EL VIDRIO CALIENTE
CAUSARÁ QUEMADURAS.
USTED NUNCA DEBE
TOCAR EL VIDRIO CALIENTE.
LOS NIÑOS NUNCA DEBE
TOCAR EL VIDRIO.
Se provee con este aparato una barrera* de proteccion (malla), diseñada para reducir
el riesgo de quemaduras por contacto accidental con el vidrio caliente que debe
estar instalada para proteccion de infantes y otros individuos en riesgo. *Incluida
con la fachada requerida.

General Information
900921-00E, 06/2019
Innovative Hearth Products
Aries™ -C Series Direct-Vent Gas Fireplaces
3
Afin d’éviter les brûlures
graves ou les blessures,
ne pas retirer l’écran de
protection de la foyer qui
empêche tout contact
direct avec la vitre.
Suivez les instructions de sécurité
ci-dessous et veillez à ce que tous
les membres de votre famille soient
conscients du danger de brûlure
encouru :
• Les surfaces de votre foyer deviennent
EXTRÊMEMENT CHAUDES !
• La vitre située à l'avant du foyer atteint
des températures EXTRÊMEMENT
ÉLEVÉES et peut causer de graves
blessures en cas de contact.
• Tenez les enfants à l'écart du foyer
lorsqu'il fonctionne. Surveillez
attentivement les enfants dans les
pièces où un foyer est utilisé afin
d'éviter qu'ils ne soient en contact avec
la vitre.
• Tenez tous les vêtements, les meubles,
l'essence et tout autre liquide
inflammable à l'écart du foyer.
• Même après fermeture du gaz, les
surfaces du foyer restent extrêmement
chaudes.
Veillez à coller les Étiquettes de mise
en garde relatives à la sécurité
d'utilisation à l'endroit où vous
utilisez le foyer, pour rappeler à tous
les utilisateurs les dangers liés aux
températures élevées (Page 48) .

Lisez L’information de sûreté
importante (Page 5) .
Para evitar quemaduras y lesiones
graves, no quite el protector de malla
o guardia de seguridad que evita el
contacto directo con el vidrio.
Siga las instrucciones de seguridad
a continuación y asegúrese de que
todos en su hogar sepan acerca de este
peligro de quemadura:
• ¡Las superficies de la chimenea
estarán EXTREMADAMANTE
CALIENTES!!
• El vidrio delante de la
chimenea alcanza temperaturas
EXTREMADAMENTE ALTAS y puede
causar quemaduras graves si se toca.
• Mantenga a los niños alejados de
la chimenea en funcionamiento.
Supervise en forma cercana a los niños
en cualquier cuarto donde haya una
chimenea funcionando para impedir el
contacto con el vidrio.
• Mantenga la ropa, mobiliario, gasolina
y otros líquidos inflamables alejados
de la chimenea.
• Aún después de haber apagado el
gas, las superficies de la chimenea
permanecen extremadamente
calientes.
Asegúrese de colocar las Etiquetas de
advertencia de seguridad de operación
en el lugar donde enciende la chimenea,
para que todos recuerden los peligros
asociados con las altas temperaturas
(Página 48) .
 Lea Información importante de
seguridad (Página 5).
Seguridad y su
chimenea
La sécurité et
votre foyer
[FRENCH][ENGLISH] [SPANISH]
Safety and Your
Fireplace
To prevent severe burns
and injuries, do Not
remove the barrier on the
appliance which prevents
direct contact with the
glass.
Follow the safety instructions below
and be sure everyone in your household
understands this burn hazard:
• The surfaces on your fireplace get
EXTREMELY HOT!
• The glass on the front of the
fireplace reaches EXTREMELY HIGH
temperatures and can cause severe
burns if touched.
• Keep children away from an operating
fireplace. Closely supervise children
in any room where a fireplace is
operating to prevent contact with glass.
• Keep clothing, furniture, gasoline, and
other flammable liquids away from the
fireplace.
• Even after the gas is turned off,
fireplace surfaces remain extremely
hot.
Be sure to attach the enclosed Safety-
in-Operation Warnings where you
turn on your fireplace, to help remind
everyone of the dangers associated with
high temperatures (Page 48) .
Read Important Safety Information
(Page 5) .
All parts of your
IHP fireplace get
EXTREMELY HOT!
Toutes les parties de votre
foyer IHP deviennent
EXTRÊMEMENT CHAUDES !
¡Todas las partes de la
chimenea IHP se ponen
MUY CALIENTES!

General Information
900921-00E, 06/2019
Innovative Hearth Products
Aries™ -C Series Direct-Vent Gas Fireplaces
4
THANK YOU FOR YOUR PURCHASE. WE APPRECIATE YOUR BUSINESS!
Please carefully read and follow all instructions in this manual. Pay special attention to all warnings and safety information. Following
these safety, care, and operation instructions will help ensure many years of dependable and enjoyable service from your fireplace.
Please read and understand these instructions before installing, operating, or servicing this product.
We recommend that our
gas hearth products be
installed and serviced by
professionals who are
certified in the U.S. by the
National Fireplace Institute®
(NFI) as NFI Gas Specialists.
General Information
Safety and Your Fireplace...................................................................2
Important Safety Information ............................................................5
Fireplace Installation, Operation, and Maintenance Notices...............6
Packaging List...................................................................................8
Introduction.......................................................................................8
Gas Pressure.....................................................................................9
Requirements for the Commonwealth of Massachusetts ................11
Cold Climate Insulation....................................................................11
Manufactured Home Requirements.................................................12
Location...........................................................................................12
Vent Termination Clearances ...........................................................13
Minimum Clearances to Combustibles ............................................15
Wall Finishes / Surrounds / Mantels................................................16
Installation Preparation....................................................................16
Installation
Installation Sequence ......................................................................17
Construct the Fireplace Framing......................................................17
Prepare the Fireplace Top Spacers...................................................19
Route the Gas Supply Line to the Fireplace .....................................19
Determine Vent Setup in the Combination Venting Unit...................20
Rough in the Electrical Supply, if Needed ........................................21
Place the Fireplace in the Framing and Secure ................................21
Optional Accessory, Install The Rock/Stone Stop Kit.......................21
Vent System Preparation.................................................................22
Install the Vent Restrictor (if necessary)..........................................23
Install the Vent System....................................................................26
Complete the Field Wiring................................................................38
Connect the Gas Line.......................................................................40
Verify Proper Fireplace Operation....................................................41
Optional Accessory: Install the Firebox Liners.................................43
Install the Logs, and Glowing Embers Media...................................43
Install the Glass Door ......................................................................43
Adjust the Air Shutter to Ensure Proper Flame Appearance.............43
Install the Hood ...............................................................................45
Required Accessory: Facade Installation And Barrier Replacement .46
Install the Finishing Materials..........................................................47
Attach the Safety-in-Operation Warnings.........................................47
Installation Accessories...................................................................49
Gas Conversion Kits ........................................................................51
Operation
Operation.........................................................................................52
Accessing control compartment and facade removal ......................54
Maintenance....................................................................................64
Accessory Components...................................................................67
Lighting Instructions .......................................................................71
Troubleshooting...............................................................................73
Replacement Parts ..........................................................................74
Warranty..........................................................................................77
35” Log Set 40” / 45” Log Set

General Information
900921-00E, 06/2019
Innovative Hearth Products
Aries™ -C Series Direct-Vent Gas Fireplaces
5
Important Safety Informa-
tion
1. WARNING: Do not operate appliance
with the glass front removed, cracked
or broken.
2. Do not use this appliance if any part
has been under water. Immediately
call a qualified service technician to
inspect the appliance and to replace
any part of the control system and
any gas control which has been under
water.
3. Due to high temperatures, the appli-
ance should be located out of traffic
and away from furniture and draperies.
4. Children and adults should be alerted
to the hazards of high surface tem-
perature and should stay away to avoid
burns or clothing ignition.
5. Clothing or other flammable material
should not be placed on or near the
appliance.
6. Young children should be carefully
supervised when they are in the same
room as the appliance. Toddlers,
young children, and others may be sus-
ceptible to accidental contact burns.
A physical barrier is recommended
if there are at-risk individuals in the
house. To restrict access to a fireplace
or stove, install an adjustable safety
gate to keep toddlers, young children,
and other at-risk individuals out of the
room and away from hot surfaces.
7. Any safety screen, guard or barrier
removed for servicing an appliance
must be replaced prior to operating
the appliance.
8. Installation and repair should be done
by a qualified service person. The ap-
pliance should be inspected before use
and at least annually by a professional
service person. More frequent clean-
ing may be required due to excessive
lint from carpeting, bedding material,
et cetera. It is imperative that control
compartments, burners, and circulat-
ing air passageways of the appliance
be kept clean. See maintenance in-
structions on Page 66.
L’information de sûreté
importante
1. AVERTISSEMENT. Ne pas utiliser l’appareil
si le panneau frontal en verre n’est pas en
place, est craqué ou brisé.
2. Ne pas se servir de cet appareil s’il a été
plongé dans l’eau, même partiellement.
Faire inspecter l'appareil par un technicien
qualifié et remplacer toute partie du systéme
de contrôle et toute commande qui ont été
plongées dans l'eau.
3. En raison des températures élevées,
l’appareil devrait être installé dans un en-
droit où il y a peu de circulation et loin du
mobilier et des tentures.
4. Les enfants et les adultes devraient être
informés des dangers que posent les tem-
pératures de surface élevées et se tenir à
distance afin d’éviter des brûlures ou que
leurs vêtements ne s’enflamment.
5. On ne devrait pas placer de vêtements
ni d’autres matières inflammables sur
l’appareil ni à proximité.
6. Les jeunes enfants devraient être surveillés
étroitement lorsqu’ils se trouvent dans la
même pièce que l’appareil. Les tout petits,
les jeunes enfants ou les adultes peuvent
subir des brûlures s’ils viennent en contact
avec la surface chaude. Il est recommandé
d’installer une barrière physique si des
personnes à risques habitent la maison.
Pour empêcher l’accès à un foyer ou à un
poêle, installez une barrière de sécurité ;
cette mesure empêchera les tout petits, les
jeunes enfants et toute autre personne à ris-
que d’avoir accès à la pièce et aux surfaces
chaudes.
7. Tout écran ou protecteur retiré pour per-
mettre l’entretien de l’appareil doit être
remis en place avant de mettre l’appareil
en marche.
8. L’installation et la réparation devrait être
confiées à un technicien qualifié. L’appareil
devrait faire l’objet d’une inspection par un
technicien professionnel avant d’être utilisé
et au moins une fois l’an par la suite. Des
nettoyages plus fréquents peuvent être
nécessaires si les tapis, la literie, et cetera
produisent une quantité importante de pous-
sière. Il est essentiel que les compartiments
abritant les commandes, les brûleurs et les
conduits de circulation d’air de l’appareil
soient tenus propres. Voyez les instructions
d’entretien à la Page 66.
Información importante de
seguridad
1. ADVERTENCIA: No opere el artefacto con el
frente de vidrio quitado, agrietado o roto.
2. No use este artefacto si alguna de sus partes
ha estado bajo agua. Llame de inmediato
a un técnico de servicio calificado para
que inspeccione el artefacto y reemplace
cualquier parte del sistema de control y
cualquier control de gas que haya estado
bajo agua.
3. Debido a las altas temperaturas, el artefacto
debe situarse fuera de las áreas de tráfico y
lejos del mobiliario y cortinas.
4. Se debe alertar a los niños y adultos sobre
los peligros de las altas temperaturas en la
superficie y que se mantengan alejados para
evitar quemaduras o ignición de la ropa.
5. No debe colocarse ropa u otros materiales
inflamables sobre y cerca del artefacto.
6. Se debe supervisar de cerca a los niños
cuando estén en el mismo cuarto que el
artefacto. Los niños pequeños, los jóvenes
y otras personas pueden ser susceptibles
a quemaduras por contacto accidental. Se
recomienda instalar una barrera física si hay
personas en riesgo en la casa. Para restringir
el acceso a una chimenea o estufa, instale
una puerta de seguridad ajustable para
mantener a los niños pequeños, jóvenes y
otras personas en riesgo fuera del cuarto y
lejos de las superficies calientes.
7. Cualquier malla o resguardo de seguridad
quitado para dar servicio a un artefacto, debe
reinstalarse antes de operar el artefacto.
8. Una persona de servicio competente debe
realizar la instalación y reparación. Una
persona de servicio profesional debe
inspeccionar el artefacto antes de usar al
menos una vez por año. Se puede requerir
limpieza más frecuente debido a la pelusa
excesiva del alfombrado, del material de
cobijas, etc. Es imprescindible mantener
limpios los compartimientos de control, los
quemadores y los pasajes de circulación del
aire del artefacto. Ver las instrucciones de
mantenimiento en la página 66.
IMPORTANT SAFETY INFORMATION
[English] [French] [Spanish]

General Information
900921-00E, 06/2019
Innovative Hearth Products
Aries™ -C Series Direct-Vent Gas Fireplaces
6
APPLIANCE INSTALLATION, SERVICE, AND MAINTENANCE NOTICES
WARNING
Improper installation, adjustment, alteration, service or maintenance can cause injury or
property damage. Refer to this manual. For assistance or additional information consult a
qualified installer, service agency or the gas supplier.
AVERTISSEMENT
Une installation, un réglage,une modification, une réparation ou un entretien mal effectué
peut causer des dommages matériels ou des blessures. Voir la notice de l’utilisateur qui
accompagne l’appareil. Pour de l’aide ou des renseignements supplémentaires, consultez
un installateur, un technicien agréé ou le fournisseur de gaz.
Only trim kit(s) supplied by the manufacturer shall be used in the installation of this fireplace.
Seules des portes certifiées pour cet appareil doivent être utilisées.
These appliances must not be connected to a chimney or flue serving a separate solid fuel
burning appliance.
Any change to this appliance and/or its operating controls is dangerous. Improper installation
or use of this appliance can cause serious injury or death from fire, burns, explosion or
carbon monoxide poisoning.
CARBON MONOXIDE POISONING: Early signs of carbon monoxide poisoning are similar to
the flu with headaches, dizziness and/or nausea. If you have these signs, obtain fresh air
immediately. Turn off the gas supply to the appliance and have it serviced by a qualified
professional, as it may not be operating correctly. Some people are more affected by carbon
monoxide than others, including pregnant women, people with heart or lung disease or
anemia, those under the influence of alcohol, and those at high altitudes.
Turn off gas and electrical power to the appliance and allow it to cool before cleaning or
servicing the appliance.
If the barrier becomes damaged, the barrier shall be replaced with the manufacturer’s barrier
for this appliance.
Si l’écran est endommagé, il doit être remplacé par celui fournit par le fabricant de cet
appareil.
For use with barrier(s) Part No(s). F3665 (35” Models), F3666 (40” Models), and F3667 (45”
Models). Follow installation instructions.
Reinstall any barrier removed before operating the appliance. The barrier is designed to
reduce the risk of burns from hot glass. Do not operate the appliance without the barrier
installed.

General Information
900921-00E, 06/2019
Innovative Hearth Products
Aries™ -C Series Direct-Vent Gas Fireplaces
7
APPLIANCE OPERATION NOTICES
WARRANTY INFORMATION
IMPORTANT SAFETY AND WARNING INFORMATION
CAUTION
Hot while in operation. Do not touch. Severe Burns may result. Keep children, clothing
furniture, gasoline and other liquids having flammable vapors away.
ATTENTION
L’appareil est chaud lorsqu’il fonctionne. Ne pas toucher l’appareil. Risque de brûlures
graves. Surveiller les enfants. Garder les vêtements, les meubles, l’essence ou autres
liquides produisant des vapeur inflammables loin de l’appareil.
These fireplaces are vented gas appliances. Do not burn wood or other material in these
appliances.
These appliances are designed to operate on natural gas or propane gas only. The use of
other fuels or combinations of fuels will degrade the performance of this system and may be
dangerous.
Provide adequate clearances around air openings and adequate accessibility clearance for
service and proper operation. Never obstruct the front openings of the appliance.
These appliances are designed as supplemental heaters. Therefore, it is advisable to have an
alternate primary heat source when installed in a dwelling.
Your gas appliance is covered by a limited lifetime warranty. You will find a copy of the
warranty accompanying this manual. Please read the warranty to be familiar with its
coverage.
Retain this manual. File it with your other documents for future reference.
Failure to comply with the installation and operating instructions provided will result in an
improperly installed and operating appliance, voiding its warranty.
Do not attempt to alter or modify the construction of the appliance or its components. Any
modification or alteration may void the warranty, certification, and listings of this unit.
WARNING
This product can expose you to chemicals including Carbon Black, which is known to the
State of California to cause cancer, and Carbon Monoxide, which is known to the State of
California to cause birth defects or other reproductive harm. For more information go to
www.P65Warnings.ca.gov

General Information
900921-00E, 06/2019
Innovative Hearth Products
Aries™ -C Series Direct-Vent Gas Fireplaces
8
INSTALLATION
PACKAGING
All models include
The assembled vented gas fireplace heater is packaged with:
• Literature Kit (bag in bottom compartment containing Installation and Operation Instructions (this manual), Hot
Glass Safety Flyer, and Safety-In-Operation Warning Labels)
• 1 Log Set
• 1 Bag of Glowing Embers (in bottom compartment)
• 15 feet of two conductor wire
NOTE: A Facade / Barrier shall be purchased separately and installed prior to operation (see Page 70).
INTRODUCTION
These vented gas fireplace heaters are sealed combustion, air-circulating gas fireplaces designed for residential and
commercial applications.
Millivolt fireplaces have a millivolt gas control valve with piezo ignition system. If a blower will be installed, electrical
power must be provided at the time of fireplace installation.
NOTE: Installation and repair should be done by a qualified service person. The fireplace should be inspected before
use and at least annually by a professional service person. More frequent cleaning may be required due to excessive
lint from carpeting, bedding material, etcetera. It is imperative that control compartment, burners and circulating air
passageways of the fireplace be kept clean.
Remarqué : L’installation et la réparation devrait être confiées à un technicien qualifié. L’appareil devrait faire
l’objet d’une inspection par un technicien professionnel avant d’être utilisé et au moins une fois l’an par la suite.
Des nettoyages plus fréquents peuvent être nécessaires si les tapis, la literie, et cetera produisent une quantité
importante de pous-sière. Il est essentiel que les compartiments abritant les commandes, les brûleurs et les
conduits de circulation d’air de l’appareil soient tenus propres.
NOTE: Diagrams and illustrations are not necessarily shown to scale.
Approved Vent Components
These fireplaces are designed, tested and listed for operation and installation with the following vent components
only:
• Secure Vent
®
Direct-Vent System Components,
• Secure Flex
®
Flexible Vent Components, and
• Z-FLEX
®
Model GA Venting Systems listed to UL1777 and ULCS635 manufactured by Flexmaster Canada
Limited.
Use only the correct size venting (4-1/2” inner and 7-1/2” outer).
These approved vent system components are labeled for identification. DO NOT use any other manufacturer’s vent
components with these fireplaces.
Codes and Standards
These fireplaces comply with National Safety Standards and are tested and listed by PFS Corporation (Report No.
F13-094) to ANSI Z21.88 (in Canada, CSA-2.33), and CAN/CGA-2.17-M91 in both USA and Canada, as vented gas
fireplace heaters.
These fireplaces are listed for installation in bedrooms and manufactured homes.
The installation must conform to local codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI
Z223.1/NFPA 54—latest edition (In Canada, the current CAN/CGA-B149.1 installation code).
The fireplace, when installed, must be electrically grounded and wired in accordance with local codes or, in the
absence of local codes, with the National Electrical Code, ANSI/NFPA 70—latest edition, or the Canadian Electrical
Code, CSA C22.1—latest edition.

General Information
900921-00E, 06/2019
Innovative Hearth Products
Aries™ -C Series Direct-Vent Gas Fireplaces
9
BTU Input
Gas Pressure
Table 3 - Inlet Line Gas Pressures
Fuel Minimum Maximum
Natural Gas 5” WC / (1.25 kPa) 10.5” WC / (2.61 kPa)
Propane 11.0” WC / (2.74 kPa) 13.0” WC / (3.23 kPa)
Table 4 - Manifold Outlet Gas Supply Pressure
Fuel Pressure
Natural Gas 3.5” WC / (0.87 kPa)
Propane 10.0” WC / (2.49 kPa)
* AFUE is a measurement of the US Department of Energy,
** Complies with CSA P.4.1-2015 “Testing Method for Measuring Annual Fireplace Efficiency. P4 (EnerGuide) is a measurement of the
Canadian Office of Energy Efficiency.
Efficiencies are based on Normal input operation.
Inlet Pressure Port
Test gauge connections are provided on the front of the millivolt gas control valve (identified IN for the inlet and OUT for
the manifold side). The control valves have a 3/8” (10 mm) NPT thread inlet and outlet side of the valve (Figure 1).
Figure 1 - Millivolt Gas Valve
Propane tanks are at pressures that will cause damage to valve components. Verify that the tanks have step down
regulators to reduce the pressure to safe levels.
The appliance and its appliance main gas valve must be disconnected from the gas supply piping system during
any pressure testing of that system at test pressures in excess of 1/2 psi (3.5 kPa).
The appliance must be isolated from the gas supply piping system by closing its equipment shutoff valve during
any pressure testing of the gas supply piping system at test pressures equal to or less than 1/2 psi (3.5 kPa).
SIT - Millivolt
Table 1 - Input Rate (BTU/HR), Gas Valves
Models Natural Gas Propane Gas
High Rate Low Rate High Rate Low Rate
35” Models 18,000 14,500 16,000 13,000
40” Models 21,000 16,000 21,000 16,000
45” Models 23,000 18,000 21,000 16,000
Table 2 - Thermal Efficiency (%)
Model
Millivolt
AFUE * P4 **
Natural Propane Natural Propane
35” Models 65.4 64.7 63.1 63.8
40” Models 63.2 64.3 64.2 64.5
45” Models 64.1 64.3 63.9 64.1
Based on CSA P. 4.1-2015

Installation
900921-00E, 06/2019
Innovative Hearth Products
Aries™ -C Series Direct-Vent Gas Fireplaces
10
The appliance and its appliance main gas valve must be disconnected from the gas supply piping system during
any pressure testing of that system at test pressures in excess of 1/2 psi (3.5 kPa).
The appliance must be isolated from the gas supply piping system by closing its equipment shutoff valve during
any pressure testing of the gas supply piping system at test pressures equal to or less than 1/2 psi (3.5 kPa).
Orifice Sizes—Sea Level to High Altitude
These fireplaces are tested and approved for installation at elevations of 0 - 4500 ft (0 - 1372 m) above sea level
using the standard burner orifice sizes (Table 5). For elevations above 4500 ft, contact your gas supplier or qualified
service technician.
Table 5 - Burner Orifice Sizes, Elevation 0 - 4500 ft ( 0 - 1372 m)
Model Natural Gas - drill size * Propane - drill size *
35” Models #48 (0.076”), Cat. No. J7910 #56 (0.046”), Cat. No. 62L37
40” Models #45 (0.082”), Cat. No. 39L66 #55 (0.052”), Cat. No. 19L52
45” Models #44 (0.086”), Cat. No. 60J80 #55 (0.052”), Cat. No. 19L52
* Standard size installed at factory
Deration
At elevations above 4500 ft, the amount of BTU fuel value delivered must be reduced by either:
• Using gas that has been derated by the gas company.
• Changing the burner orifice to a smaller size as regulated by the local authorities having jurisdiction and by the
(USA) National Fuel Gas Code NFPA 54/ANSI Z223.1—latest edition or, in Canada, the CAN/CGA-B149.1 codes—
latest edition.
NOTE: Flame breadth, height and width will diminish 4% for every 1,000 ft of altitude.
IN CANADA—CAN/CGA-2.17-M91 (HIGH ALTITUDE):
THE CONVERSION SHALL BE CARRIED OUT BY A MANUFACTURER’S AUTHORIZED REPRESENTATIVE,
IN ACCORDANCE WITH THE REQUIREMENTS OF THE MANUFACTURER, PROVINCIAL OR TERRITORIAL
AUTHORITIES HAVING JURISDICTION AND IN ACCORDANCE WITH THE REQUIREMENTS OF THE CAN/
CGA-B149.1 OR CAN/CGA-B149.2 INSTALLATION CODES.

Installation
900921-00E, 06/2019
Innovative Hearth Products
Aries™ -C Series Direct-Vent Gas Fireplaces
11
COMMONWEALTH OF MASSACHUSETTS REQUIREMENTS
These appliances are approved for installation in the US state of Massachusetts if the following additional
requirements are met:
• Install this appliance in accordance with Massachusetts Rules and Regulations 248 C.M.R. Sections 4.00
through 8.00.
• Installation and repair must be done by a plumber or gas fitter licensed in the Commonwealth of Massachusetts.
• The flexible gas line connector used shall not exceed 36 inches (92 centimeters) in length.
• The individual manual shut-off must be a T-handle type valve.
Massachusetts Horizontal Vent Requirements
In the Commonwealth of Massachusetts, horizontal terminations installed less than seven (7) feet above the finished
grade must comply with the following additional requirements:
• A hard wired carbon monoxide detector with an alarm and battery back-up must be installed on the floor level
where the gas fireplace is installed. The carbon monoxide detector must comply with NFPA 720, be ANSI/UL
2034 listed and be ISA certified.
• A metal or plastic identification plate must be permanently mounted to the exterior of the building at a minimum height of eight (8) feet
above grade and be directly in line with the horizontal termination. The sign must read, in print size no less than one-half (1/2) inch in size, GAS
VENT DIRECTLY BELOW. KEEP CLEAR OF ALL OBSTRUCTIONS.
COLD CLIMATE INSULATION
For cold climate installations, seal all cracks around your fireplace with noncombustible material and wherever cold
air could enter the room. It is especially important to insulate outside chase cavity between studs and under floor on
which fireplace rests, if floor is above ground level. Gas line holes and other openings should be caulked or stuffed
with unfaced fiberglass insulation.
NOTE: Do not use loose, or blown-in insulation in the cavity surrounding the fireplace.
If the fireplace is being installed on a cement slab in cold climates, a sheet of plywood or other raised platform can
be placed underneath to prevent conduction of cold transferring to the fireplace and into the room. It also helps to
seal inside surfaces and tape for maximum air tightness and caulk firestops.

Installation
900921-00E, 06/2019
Innovative Hearth Products
Aries™ -C Series Direct-Vent Gas Fireplaces
12
MANUFACTURED HOME REQUIREMENTS
This appliance may be installed in an aftermarket, permanently located, manufactured home (USA only) or mobile
home, where not prohibited by local codes.
Cet appareil peut être installé dans une maison préfabriquée (mobile) déjà installée à demeure si les règlements
locaux le permettent.
This appliance is only for use with the type of gas indicated on the rating plate. This appliance is not convertible for
use with other gases, unless a certified kit is used.
Cet appareil doit être utilisé uniquement avec le type de gaz indiqué sur la plaque signalétique. Cet appareil ne
peut être converti à d’autres gaz, sauf si une trousse de conversion est utilisée.
CAUTION
Ensure that the cross members are not cut or weakened during installation. The structural
integrity of the manufactured home floor, wall, and ceiling / roof must be maintained.
CAUTION
This appliance must be grounded to the chassis of the manufactured home in accordance
with local codes or in the absence of local codes, with the National Electrical Code ANSI /
NFPA 70—latest edition or the Canadian Electrical Code CSA C22.1—latest edition.
LOCATION
In selecting the location, the aesthetic and functional use of the fireplace are primary concerns. However, vent
system routing to the exterior and access to the fuel supply are also important.
Due to high temperatures, the fireplace should be located out of traffic and away from furniture and draperies.
En raison des températures élevées, l’appareil devrait être installé dans un endroit où il y a peu de
circulation et loin du mobilier et des tentures.
The location should also be free of electrical, plumbing or other heating/air conditioning ducting.
These direct-vent fireplaces are uniquely suited for installations requiring a utility shelf positioned directly above the
fireplace. Utility shelves like these are commonly used for locating television sets and decorative plants.
Be aware that this is a heat producing fireplace. Objects placed above the unit are exposed to elevated temperatures.
Do not insulate the space between the fireplace and the area above it.
The minimum height from the base of the fireplace to the underside of combustible materials used to construct a
utility shelf in this fashion is shown in Table 9.
Figure 2 - Typical Locations and Venting
Vertical Vent
(Rear Vent)
HORIZONTAL VENT
Horizontal Vent
(Top Vent) Vertical Vent (Top Vent)
VERTICAL VENT
Horizontal Vent
(Rear Vent with chase) Horizontal Vent (Rear Vent without chase)
Top Vent
Top Vent
Top Vent
Top Vent Top Vent
Top Vent Rear Vent
Rear Vent
Recessed
Installation
NOTE: Installations against side walls must meet requirements
shown in Figure 5, Page 16.

Installation
900921-00E, 06/2019
Innovative Hearth Products
Aries™ -C Series Direct-Vent Gas Fireplaces
13
VENT TERMINATION CLEARANCES
These instructions should be used as a guideline and do not supersede local codes in any way. Install venting with the
most restrictive requirements as outlined in these instructions, local codes, these instructions, the current National
Fuel Gas Code (ANSI Z223.1/NFPA 54) in the USA or the current standards of CAN/CGA-B149.1 in Canada.
Vertical Vent Termination Clearances
Terminate multiple vent terminations according to the installation codes listed above and Figure 3.
Figure 3 - Multiple Terminations
6”
(153 mm)
12”
(305 mm)
minimum
Terminate single vent caps relative to building components according to Table 6.
Table 6 - Termination Heights for Vents above Flat or Sloped Roofs (NFPA 54 / ANSI Z223.1)—Gas Vent Rule
Roof Pitch Termination Height *
Flat to 6/12 1.0 ft (0.3 m)
6/12 to 7/12 1.25 ft (0.38 m)
7/12 to 8/12 1.5 ft (0.46 m)
8/12 to 9/12 2.0 ft (0.61 m)
9/12 to 10/12 2.5 ft (0.76 m)
10/12 to 11/12 3.25 ft (0.99 m)
11/12 to 12/12 4.0 ft (1.22 m)
12/12 to 14/12 5.0 ft (1.52 m)
14/12 to 16/12 6.0 ft (1.83 m)
16/12 to 18/12 7.0 ft (2.13 m)
18/12 to 20/12 7.5 ft (2.29 m)
20/12 to 21/12 8.0 ft (2.44 m)
12
X
Roof pitch is X/12
2 ft
minimum
2 ft minimum
Lowest
discharge
opening
H*
*H = minimum height from roof to
lowest discharge opening of vent
Horizontal overhang
Vertical
wall
Vent
termination
Storm collar
Concentric
vent pipe
Flashing
1” (26mm) minimum
clearance to combustibles
TERMINATION HEIGHTS FOR VENTS ABOVE
FLAT OR SLOPED ROOFS
Horizontal Vent Termination Clearances
The horizontal vent termination must have a minimum of 6” (152 mm) clearance to any overhead combustible
projection of 2-1/2” (64 mm) or less (Figure 4). For projections exceeding 2-1/2” (64 mm) (Figure 4). For additional
vent location restrictions refer to Table 7.
All horizontal terminations may be located as close as 6” (152mm) to any (non-combustible and combustible)
exterior sidewall. This distance may be decreased to 2” (51mm) for noncombustible exterior sidewalls with all
approved terminations (Table 7).
Figure 4 - Horizontal Vent Termination Clearances
Combustible projection
2-1/2” or less in length
Combustible projection
greater than 2-1/2” in length
Ventilated
soffit - 18”
(457 mm)
Unventilated
soffit - 12”
(305 mm)
6” (152mm)
Termination kit
Termination kit
6”

Installation
900921-00E, 06/2019
Innovative Hearth Products
Aries™ -C Series Direct-Vent Gas Fireplaces
14
Table 7 - Horizontal vent termination clearances for buildings with combustible and noncumbustible exteriors
U.S. Installation ** Canadian Installation *
AClearance above grade, veranda, porch, desk, or balcony 12” (300 mm) ** 12” (300 mm) *
BClearance to window or door that may be opened 6” (150 mm)
for fireplaces < 10,000 Btu/h (3 kW),
9” (230 mm)
for fireplaces > 10,000 Btu/h (3 kW), and < 50,000 Btu/h (15
kW),
12” (300 mm)
for fireplaces > 50,000 Btu/h (15 kW) **
6” (150 mm)
for fireplaces < 10,000 Btu/h (3 kW),
12” (300 mm)
for fireplaces > 10,000 Btu/h (3 kW)
CClearance to permanently closed window 9” (229 mm)
recommended to prevent window condensation 12” (305 mm) recommended to prevent window
condensation
DVertical clearance to ventilated soffit located above the
termination within a horizontal distance of 18” (458 mm) 18” (458 mm) 18” (458 mm)
EClearance to unventilated soffit 12” (305 mm) 12” (305 mm)
FClearance to outside corner 5” (127 mm)
minimum 5” (127 mm) minimum
GClearance to inside corner 6” (152 mm) minimum 6” (152 mm) minimum
HClearance to each inside of center line extended above
meter / regulator assembly 36” (910 mm) within a height of 15 ft above the meter / regulator assembly ** 36” (910 mm) within a height of 15 ft above the meter /
regulator assembly *
IClearance to service regulator vent outlet 36” (910 mm)** 36” (910 mm)*
JClearance to nonmechanical air supply inlet to building or
the combustion air inlet to any other fireplace 6” (150 mm) for fireplaces < 10,000 Btu/h (3 kW),
9” (230 mm)
for fireplaces > 10,000 Btu/h (3 kW) and < 50,000 Btu/h (15 kW),
12” (300 mm)
for fireplaces > 50,000 Btu/h (15 kW)**
6” (150 mm)
for fireplaces < 10,000 Btu/h (3 kW),
12” (300 mm)
for fireplaces > 10,000 Btu/h (3 kW)
KClearance to a mechanical air supply inlet 36” (910 mm) above if within 10 ft (3 m) horizontally ** 72” (1830 mm) *
LClearance above paved sidewalk or paved driveway located
on public property 84” (2130 mm) ‡ 84” (2130 mm) ‡
MClearance under veranda, porch, deck or balcony 12” (300 mm) *‡ 12” (300 mm) *‡
NDepth of alcove (maximum) 72” (1830 mm) ** 72” (1830 mm) *
OClearance to termination (alcove) 6” (15.2 mm) ** 6” (15.2 mm)*
PWidth of alcove (minimum) 36” (910 mm) ** 36” (910 mm) *
QClearance to combustible above (alcove) 18” (457 mm) ** 18” (457 mm) *
*
**
‡
*‡
In accordance with the current CAN/CGA-B149.1 National Gas And Propane Installation Code
In accordance with the current ANSI Z223.1/NFPA 54 National Fuel Gas Codes
A vent shall not terminate directly above a sidewalk or paved driveway which is located between two single family dwellings and serves both dwellings
Only permitted if veranda, porch, deck, or balcony is fully-open on a minimum two sides beneath the floor
Fixed
Closed Openable Fixed
Closed
V
V
VV
V
V
X
X
VX
G
G
J
F
B
B
K
H
I
A
E
L
D
B
M
C
B
V
V
A
G
G
B
TERMINATION CAP AIR SUPPLY INLET GAS METER RESTRICTED AREA
(TERMINATION PROHIBITED)
Openable
See Table 6
V
V
Inside Corner
VV
Outside Corner Recessed Location
Balcony with No Side Wall
V
Balcony with Perpendicular Side Wall
G
F
M
M
NP
O
Q

Installation
900921-00E, 06/2019
Innovative Hearth Products
Aries™ -C Series Direct-Vent Gas Fireplaces
15
MINIMUM CLEARANCES TO COMBUSTIBLES
Fireplace And Vent Clearances
The fireplace is approved with zero clearance to combustible materials
on all sides (Table 8), with the following exception: The unit may not
be recessed (allowance made for mantel legs / side trim in Figure 5).
When the unit is installed with one side flush with a wall, the wall on the
other side of the unit must not extend beyond the front edge of the unit
(Figure 5).
The fireplace must be mounted on a fully supported base extending
the full width and depth of the unit. The fireplace may be located on
or near conventional construction materials. However, if installed on
combustible materials, such as carpeting, vinyl tile or other combustible
material other than wood flooring, the appliance shall be installed on a
metal or wood panel extending the full width and depth of the appliance.
Table 8 - Minimum Clearances *
Back *** 1-1/2” (38mm) to wrapper
0” (0 mm) to Spacers
Sides 1/2” (13 mm) to wrapper
0” (0 mm) to Spacers **
Top Standoffs 0” (0 mm) to top standoffs
Floor 0” (0 mm)
From Bottom of Unit to Ceiling 64” (1626 mm)
Vent 3” (77 mm)—Top *
1” (26 mm)—Sides and Bottom
Front Service Clearance—
clearance immediately in front of
viewing area(s)
36” (914 mm)
*3” (77 mm) above any horizontal/inclined vent component.
** See Page 22 for clearance requirements to the nailing flange
located at each side of the unit and any screw heads adjacent to it.
*** When in top vent mode; no combustible material shall be allowed to
contact the rear flue cap/cover.
Hearth Extension
A hearth extension is not required with this fireplace. If a hearth extension is used, do not block the facade from being installed or
removed. Any hearth extension used is for appearance only and does not have to conform to standard hearth extension installation
requirements.
Shelf Height
To provide for the lowest possible shelf surface, use the rear vent model. For top vent models, the venting attached to the top vent should
be routed in a way to minimize obstructions to the space above the fireplace. Do not insulate the space between the fireplace and the
area above it (Tables 9A anc 9B). The minimum height from the base of the fireplace to the underside of combustible materials used to
construct a utility shelf in this fashion is shown in Tables 9A and 9B.
Table 9A- Combustible Shelf Height—Top Vent
Table 9B - Combustible Shelf Height—Rear Vent
* Includes 3” clearance to combustibles (required above vent components)
** In alternative, Rear Vent applications, Top Vent will be sealed as detailed in Installation Sequence Step 4 (Page 20).
Model
Top Vent with one 90° Elbow *
Secure Vent®
(using rigid elbow) Secure Flex®
(using flex elbow)
35” Models 47” (1194 mm) 49” (1245 mm)
40” Models 52” (1321 mm) 54” (1372 mm)
45” Models 52” (1321 mm) 54” (1372 mm)
CLEARANCES TO COMBUSTIBLES MUST BE MAINTAINED:
No combustible materials or insulation is permitted in the shaded area
between the appliance and the shelf above it.
WARNING: CRITICAL INSTALLATION INFORMATION THAT IF NOT FOL-
LOWED CAN RESULT IN A SAFETY HAZARD!
Model
Rear Vent with two 90° Elbows **
Secure Vent®
(using rigid elbow) Secure Flex®
(using flex elbow)
35” Models 36-1/4” (921 mm) 36-1/4” (921 mm)
40” Models 40-1/2” (1029 mm) 40-1/2” (1029 mm)
45” Models 45-1/2” (1156 mm) 45-1/2” (1156 mm)
CLEARANCES TO COMBUSTIBLES MUST BE MAINTAINED:
No combustible materials or insulation is permitted in the shaded area
between the appliance and the shelf above it.
WARNING: CRITICAL INSTALLATION INFORMATION THAT IF NOT FOL-
LOWED CAN RESULT IN A SAFETY HAZARD!
Shelf Height
(see table)
Shelf Height
(see table)
≥3” clearance from shelf to
top of fireplace and/or vent
pipe, whichever is higher

Installation
900921-00E, 06/2019
Innovative Hearth Products
Aries™ -C Series Direct-Vent Gas Fireplaces
16
Wall Finishes / Surrounds / Mantels
NOTE: Combustible wall finish materials and/or surround materials must not be allowed to encroach the area
defined by the fireplace front face (black sheet metal). Non-combustible material up to 6 inches in depth, such as
surrounds may be positioned in front of or overlapping the fireplace face (Figure 36, Page 47).
Non-combustible materials, such as surrounds and other fireplace trim, may be installed on the fireplace face, but they
must not cover any portion of the removable glass panel or impede the removal or installation of facade.
Vertical installation clearances to combustible mantels vary according to the depth of the mantel (Figure 6). Mantels
constructed of non-combustible materials may be installed at any height above the fireplace opening. However, do
not allow anything to hang below the fireplace hood.
Minimum clearance requirements include any projections such as shelves, window sills, mantels, etc. above the
fireplace.
NOTE: To avoid heat-related finish damage, we recommend the use of high temperature paint (rated 175° F or higher) on
the underside of the mantel.
INSTALLATION PREPARATION
The fireplace is shipped with all gas controls and components installed and pre-wired. Before installing the fireplace,
follow these steps:
1. Remove the shipping carton, and retain the front of the carton (used to protect the fireplace during construction).
2. Remove the shipping pad, exposing the front glass door.
3. Remove the glass door (Pages 62 - 63).
NOTE: Place the glass door on the shipping carton to protect its surface.
Figure 5 - Combustible Side Clearances Figure 6 - Mantel Height
3-1/2”
(89 mm)
6”
(152 mm)
Top View of
Fireplace
45o
Combustible
mantel legs may
project beyond either side
of the fireplace opening
as long as they are kept
within the shaded area
illustrated here.
Combustible Materials
Allowed In Shaded Area
“Safe Zone”
Combustible Walls
shown in dark gray
At 6” minimu
m
side wall clearance,
a combustible wall
can project to an
y
length
.
12
(305) 10
(254)
8
(203) 6
(152)
4
(102)
2
(51)
in. (mm)
6 (153)
8 (203)
10 (254)
12 (305)
14 (356)
16 (407)
Hood
Fireplace
Mantel depth

Installation
900921-00E, 06/2019
Innovative Hearth Products
Aries™ -C Series Direct-Vent Gas Fireplaces
17
INSTALLATION SEQUENCE
The typical sequence of installation is outlined below; however, each installation is unique and may result in
variations to the steps described.
See the pages referenced in the following steps for detailed instructions.
Check local codes for more restrictive installation. The more restrictive installation for clearances must be used.
Framing
1. Construct the Fireplace Framing (Page 17).
2. Prepare the Fireplace Top Spacers (Page 19).
3. Route the Gas Supply Line to the Fireplace (Page 19).
4. Determine Venting in Combination Venting Fireplaces (Page 20).
5. Rough in the Electrical Supply, if Needed (Page 21).
6. Place the Fireplace in the Framing and Secure (Page 21).
6A. Optional Accessory, install the rock/ stone stop kit (Page 21)
Venting
7. Select a Horizontal or Vertical Vent System (Page 22).
8. Install the Vent Restrictor (if necessary) (Page 23).
9. Connecting the Vent Pipe (Page 24).
10. Install the Vent System (Page 26).
Electrical Connection
11. Complete the Field Wiring (Page 38).
Gas Connection
12. Connect the Gas Line (Page 40).
13. Verify Proper Fireplace Operation (Page 41).
Remote Control
14. Initialize the Remote Control System for the First Time (Page 42)
Finishing
15. Optional Accessory (see Page 67 for ordering information): Install the Firebox Liners (Page 44).
16. Install the Logs, and Glowing Embers (Page 44).
17. Install the Glass Door (Page 44).
18. Adjust the Air Shutter to Ensure Proper Flame Appearance (Page 44).
19. Install the Hood (Page 45).
20. Required Accessory (see Page 70 for ordering information): Reinstall the Facade and Barrier (Page 46).
21. Install the Finishing Materials (Page 47).
22. Attach the Safety-in-Operation Warning Labels (Page 47).
1. Construct the Fireplace Framing
1. Frame the fireplace as illustrated in Table 10. For corner framing installations, use Table 11. All framing details
must allow for a minimum clearance to combustible framing members as shown in Table 8.
2. If the fireplace is to be elevated above floor level, a solid continuous platform must be constructed below the fireplace.
NOTE: Headers may be in direct contact with the fireplace top standoff spacers when they are bent up vertically,
maintaining the 4” clearance to the fireplace top, but must not be supported by them or notched to fit around them.
All construction above the fireplace must be self-supporting. DO NOT use the fireplace for structural support.

Installation
900921-00E, 06/2019
Innovative Hearth Products
Aries™ -C Series Direct-Vent Gas Fireplaces
18
Model A B C* D* E F G H I J K
35” Models 32-1/8 (816) 30-1/2 (775) 19-1/2 (496) 29-1/4 (743) 35-1/4 (895) 25 (635) 12-1/2 (317) 32-7/8 (835) 6-7/8 (175) 17 (432) 10-1/8 (258)
40” Models 37-1/8 (943) 35-1/2 (902) 24-1/2 (623) 34-1/4 (870) 40-1/4 (1022) 30 (762) 15 (381) 37-7/8 (962) 6-7/8 (175) 17 (432) 10-1/8 (258)
45”Models 37-1/8 (943) 35-1/2 (902) 24-1/2 (623) 39-1/4 (997) 45-1/4 (1149) 35 (889) 17-1/2 (445) 42-7/8 (1089) 6-7/8 (175) 17 (432) 10-1/8 (258)
NOTE: When in top vent mode, No combustible material shall be allowed to contact the rear flue cap/cover.
Top View Front View Left Side View Right Side View
A
C*
B
D*
E
F
G
H
Blower
access panel
Hood
Junction
box access
Gas line
access
I
K
JK
Model A * B C D E
35” Models 35-7/8
(911) 36-1/4 (920) 38-3/4 (984) 18-1/2 (470) 23-3/8 (594)
40” Models 40-7/8
(1038) 41-1/4 (1148) 43-3/4 (1111) 18-1/2 (470) 28-1/4 (717)
45” Models 45-7/8
(1165) 41-1/4 (1148) 43-3/4 (1111) 18-1/2 (470) 28-1/4 (717)
C = Minimum height of top vent installations
E = Minimum height of rear vent installations
* Minimum opening size; additional 1/8” per side is recommended.
NOTE: Framing specifications do NOT apply for flexible venting.
When using flexible venting, refer to the kit requirements for framing
specifications.
NOTE: When in top vent mode - No combustible material shall be
allowed to contact the rear flue cap/cover.
Vent Framing—Top Vent
with One 90° Elbow
NOTE: Dimension “D” is the
required framing depth when
the finish material (drywall)
thickness is 1/2” (13mm).
Inches (millimeters)
Framing
construction to be
2 x 4, or larger.
BC
D
A
1/2 A
5-1/8
(130)
7 (178) 12-1/8
(308)
10-1/2
(267)
E
Model A B C D E F
35” 35-7/8
(911) 59-1/2 (1511) 42-1/8 (1070) 30-1/4 (768) 14-1/4 (362) 6-5/8 (168)
40” 40-7/8
(1038) 63-7/8 (1622) 45-3/8 (1153) 33-1/4 (845) 15-7/8 (403) 8-1/2 (216)
45” 45-7/8
(1165) 70-3/8 (1788) 49-3/4 (1264) 35-1/4 (895) 17-1/2 (445) 10-1/4 (260)
Table 10 - Fireplace Framing Specifications
Table 12 - Fireplace Specifications
Table 11 - Fireplace Framing Specifications - Corner Installation with Horizontal Termination
B
A
C
D
EF
Back wall of chase/enclosure (including finishing materials)
7 (178)
Front to rear with 1” distance to wall
Inches
(millimeters)
* C and D are glass viewing area dimensions Inches (millimeters)

Installation
900921-00E, 06/2019
Innovative Hearth Products
Aries™ -C Series Direct-Vent Gas Fireplaces
19
2. Prepare the Fireplace Top Spacers
1. The two (2) 4” standoff spacers on top of the fireplace cabinet are shipped flat. Remove the screw adjacent to the
detached end (Figure 7).
2. Bend the standoffs as shown (Figurex 7B):
3. Align the hole in the standoff with the hole in the fireplace top, and secure with the screw that was removed in
Step 1 (Figurex 7B).
Figurex 7A - Unassembled standoff Figurex 7B - Assembled standoffs
Positioned flat as shipped from the factory
Fireplace Front
Top Standoff
Screw
Fireplace
Front
Top Standoff
3. Route the Gas Supply Line to the Fireplace
1. Route a 1/2” (13 mm) gas line to the left side of the fireplace (Figurex 8).
NOTE: Gas lines must be routed, assembled, and made of materials that are in strict accordance with local codes and
regulations. All fireplaces are factory-equipped with a flexible gas line connector and a 1/2” shutoff valve (Page 40).
Figurex 8 - Routing the gas line - 35”, 40”, 45” Models
Left side front corner of
fireplace framing
Pipe coupling
(recommended)
7-5/8”
(195 mm)
3”
(77 mm)
Proper Sizing of Gas Line
Properly size and route the gas supply line from the supply regulator to the area where the appliance is to be installed
per requirements outlined in the National Fuel Gas Code, NFPA 54—latest edition (USA) or CAN/CGA-B149.1—latest
edition (Canada).
The gas supply line should not be connected to the appliance until step 12. Connect the Gas Line (Page 40).
NOTE:
• All fireplaces are factory-equipped with a flexible gas line connector and 1/2” shutoff valve (Figure 31, Page 41).
• See Massachusetts Horizontal Vent Requirements for additional requirements for installations in the state of
Massachusetts in the USA.
• A pipe joint compound rated for gas should be used on the threaded joints. Ensure propane-resistant compounds
are used in propane applications. Be very careful that the pipe compound does not get inside the pipe.
• A sediment trap in the supply line as close as possible to the fireplace is recommended.
• Check with the local building official for local code requirements (e.g., Are below grade penetrations of the gas
line allowed?, etc).
CAUTION
If propane is used, be aware that with a tank that is too small (i.e., under 100 lbs, if this
is the only gas appliance in the dwelling—see NPFA 58), there may be a loss of pressure.
This can result in insufficient fuel delivery that can cause sooting, delayed ignition, or other
malfunctions. Any damage resulting from an improper installation is not covered by the
limited warranty.

Installation
900921-00E, 06/2019
Innovative Hearth Products
Aries™ -C Series Direct-Vent Gas Fireplaces
20
4. Determining Vent Setup in the Combination Venting Unit (for 45” models only)
Combination venting units are shipped with round outer flue covers and inner flue cover plates installed that will require removal before connecting
the vent pipe. If you require a rear vented unit, remove the round outer rear flue cover (2 screws, Figure 9A) and the inner rear flue cover plate (4
screws, Figure 9B). If you require a top vented unit, remove the round outer top flue cover (2 screws, Figure 9A)and the inner top flue cover plate
(2 screws, Figure 9B). NOTE: it may be necessary to remove the upper lintel/ & baffle to access the inner flue cover plates (3 screws).
Outer Top Flue Cover
Outer Rear
Flue Cover
Inner Top Flue
Cover Plate
Inner Rear Flue Cover Plate
Figure 9A Figure 9B
