Continental Fireplaces CHD35NT User manual

1
W415-0859 / B / 08.08.12
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
NEVER LEAVE CHILDREN OR OTHER AT RISK INDIVIDUALS ALONE WITH THE APPLIANCE.
INSTALLATION AND
OPERATING INSTRUCTIONS
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON, L4M 0G8 Canada /
103 Miller Drive, Crittenden, Kentucky, USA, 41030
Phone [phone] • Fax [phone] • www.continentalfireplaces.com • ask@continentalfire.on.ca
1.8B
$10.00
CERTIFIED FOR CANADA AND UNITED STATES USING ANSI/CSA METHODS.
SAFETY INFORMATION
!WARNING
- Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
- WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
any phone in your building.
• Immediately call your gas supplier from a
neighbour’s phone. Follow the gas supplier’s
instructions.
• If you cannot reach your gas supplier, call the
fire department.
- Installation and service must be performed by a
qualified installer, service agency or the supplier.
This appliance may be installed in an
aftermarket, permanently located, manufactured
home (USA only) or mobile home, where not
prohibited by local codes.
This appliance is only for use with the type of
gas indicated on the rating plate. This appliance
is not convertible for use with other gases,
unless a certified kit is used.
If the information in these instructions
are not followed exactly, a fire or
explosion may result causing property
damage, personal injury or loss of life.
HOT GLASS WILL CAUSE
BURNS.
DO NOT TOUCH GLASS UNTIL
COOLED.
NEVER ALLOW CHILDREN TO
TOUCH GLASS.
!
WARNING
CERTIFIED
CHD35NT, CHD40NT
& CHD46NT
NATURAL GAS
CHD35PT, CHD40PT
& CHD46PT
PROPANE
CERTIFIED UNDER CANADIAN AND AMERICAN NATIONAL STANDARDS: CSA 2.33, ANSI Z21.88 FOR VENTED GAS FIREPLACE HEATERS.
CHD35 ILLUSTRATED
fire-parts.com

2
W415-0859 / B / 08.08.12
TABLE OF CONTENTS
NOTE: Changes, other than editorial, are denoted by a vertical line in the margin.
1.0 INSTALLATION OVERVIEW 3
1.1 USING NON-COMBUSTIBLE MATERIAL 3
1.2 USING NON-COMBUSTIBLE MATERIAL 4
2.0 INTRODUCTION 5
2.1 DIMENSIONS 6
2.2 GENERAL INSTRUCTIONS 7
2.3 GENERAL INFORMATION 8
2.4 RATING PLATE INFORMATION 9
3.0 VENTING 10
3.1 VENTING LENGTHS AND COMPONENTS 10
3.2 TYPICAL VENT INSTALLATIONS 11
3.3 SPECIAL VENT INSTALLATIONS 12
3.3.1 PERISCOPE TERMINATION 12
3.3.2 CORNER TERMINATION 12
3.4 VENT TERMINAL CLEARANCES 13
3.5 VENT APPLICATION FLOW CHART 14
3.6 DEFINITIONS 14
3.7 ELBOW VENT LENGTHS 14
3.8 HORIZONTAL TERMINATION 15
3.9 VERTICAL TERMINATION 17
3.10 CO-AXIAL TO CO-LINEAR VENTING 19
4.0 INSTALLATION 20
4.1 WALL AND CEILING PROTECTION 20
4.1.1 HORIZONTAL INSTALLATION 21
4.1.2 VERTICAL INSTALLATION 21
4.2 USING FLEXIBLE VENT COMPONENTS 22
4.2.1 HORIZONTAL AIR TERMINAL INSTALLATION 22
4.2.2 VERTICAL AIR TERMINAL INSTALLATION 23
4.3 USING RIGID VENT COMPONENTS 24
4.3.1 HORIZONTAL AIR TERMINAL INSTALLATION 24
4.3.2 EXTENDED HORIZONTAL AIR TERMINAL INSTALLATION 24
4.3.3 VERTICAL VENTING INSTALLATION 25
4.4 MOBILE HOME 26
4.5 ACCESS PANEL FOR GAS LINE CONNECTION 26
4.6 GAS INSTALLATION 27
5.0 FRAMING 28
5.1 MINIMUM CLEARANCE TO COMBUSTIBLES 30
5.2 MINIMUM CLEARANCE TO COMBUSTIBLE ENCLOSURES 31
5.3 ALCOVE INSTALLATION 33
5.4 MINIMUM MANTEL CLEARANCES 34
6.0 FINISHING 35
6.1 DOOR REMOVAL / INSTALLATION 35
6.2 LOG PLACEMENT 36
6.3 GLOWING EMBER PLACEMENT 38
6.4 CHARCOAL EMBERS 38
6.5 OPTIONAL VERMICULITE 38
6.6 OPTIONAL CHARCOAL LUMPS (STANDARD ON CHD46) 38
6.7 LOGO PLACEMENT 38
7.0 OPTIONAL BLOWER INSTALLATION 39
7.1 ACCESSING THE BLOWER 39
7.2 INSTALLING THE BLOWER 40
8.0 WIRING DIAGRAM / ELECTRICAL INFORMATION 41
8.1 WIRING REQUIREMENTS 41
8.2 OPTIONAL ACCESSORIES REQUIREMENTS 41
8.3 JUNCTION BOX INSTALLATION 42
8.4 WIRING DIAGRAM 43
9.0 OPERATION 44
10.0 ADJUSTMENT 45
10.1 PRESSURE ADJUSTMENT 45
10.2 VENTURI ADJUSTMENT 45
10.3 FLAME CHARACTERISTICS 46
11.0 MAINTENANCE 46
11.1 DOOR GLASS REPLACEMENT 47
11.2 CARE OF GLASS 47
11.3 CARE OF PLATED PARTS 47
12.0 REPLACEMENT PARTS 48
13.0 TROUBLESHOOTING 51
14.0 WARRANTY 53
15.0 SERVICE HISTORY 54
fire-parts.com

3
W415-0859 / B / 08.08.12
1.0 INSTALLATION OVERVIEW
Mantel, see “MINIMUM
MANTEL CLEAR-
ANCES” section.
Enclosures, see the
section “MINIMUM
CLEARANCES TO
COMBUSTIBLE
ENCLOSURES”
section for drywall (or
other combustible
material).
Framing, see
“FRAMING”
section.
Side
Wall
Venting, see “VENTING”
section.
Framing, see “FRAMING”
section.
Enclosures, see the
section “MINIMUM
CLEARANCE TO COM-
BUSTIBLE ENCLO-
SURES” section for
non-combustible materials
such as tile, marble,
granite, etc.
Rating plate, see “RATING
PLATE INFORMATION”
section.
1.1 USING NON-COMBUSTIBLE MATERIAL
fire-parts.com

4
W415-0859 / B / 08.08.12
Mantel, see “MINI-
MUM MANTEL
CLEARANCES”
section.
Enclosures, see “MINIMUM
CLEARANCE TO COM-
BUSTIBLE ENCLO-
SURES” for drywall (or
other combustible mate-
rial)” section.
Framing, see
“FRAMING”
section
Side
Wall
Venting, see “VENTING”
section.
Framing, see “FRAMING”
section.
Rating plate, see “RATING
PLATE INFORMATION”
section.
1.2 USING COMBUSTIBLE MATERIAL
fire-parts.com

5
W415-0859 / B / 08.08.12
2.0 INTRODUCTION
3.2B
!
WARNING
• THIS APPLIANCE IS HOT WHEN OPERATED AND CAN CAUSE SEVERE BURNS IF CONTACTED.
• ANY CHANGES OR ALTERATIONS TO THIS APPLIANCE OR ITS CONTROLS CAN BE DANGEROUS
AND IS PROHIBITED.
• Do not operate appliance before reading and understanding operating instructions. Failure to operate
appliance according to operating instructions could cause fire or injury.
• Risk of fire or asphyxiation do not operate appliance with fixed glass removed.
• Do not connect 110 volts to the control valve.
• Risk of burns. The appliance should be turned off and cooled before servicing.
• Do not install damaged, incomplete or substitute components.
• Risk of cuts and abrasions. Wear protective gloves and safety glasses during installation. Sheet metal edges
may be sharp.
• Do not burn wood or other materials in this appliance.
• Children and adults should be alerted to the hazards of high surface temperature and should stay away to
avoid burns or clothing ignition.
• Young children should be carefully supervised when they are in the same room as the appliance. Toddlers,
young children and others may be susceptible to accidental contact burns. A physical barrier is recommended
if there are at risk individuals in the house. To restrict access to an appliance, install an adjustable safety gate
to keep toddlers, young children and other at risk individuals out of the room and away from hot surfaces.
• Clothing or other flammable material should not be placed on or near the appliance.
• Due to high temperatures, the appliance should be located out of traffic and away from furniture and draperies.
• Ensure you have incorporated adequate safety measure to protect infants/toddlers from touching hot surfaces.
• Even after the appliance is out, the glass and/or screen will remain hot for an extended period of time.
• Check with your local hearth specialty dealer for safety screens and hearth guards to protect children from hot
surfaces. These screens and guards must be fastened to the floor.
• Any safety screen or guard removed for servicing must be replaced prior to operating the appliance.
• The appliance is a vented gas-fired appliance. Do not burn wood or other materials in the appliance
• It is imperative that the control compartments, burners and circulating blower and its passageway in the
appliance and venting system are kept clean. The appliance and its venting system should be inspected
before use and at least annually by a qualified service person. More frequent cleaning may be required due
to excessive lint from carpeting, bedding material, etc. The appliance area must be kept clear and free from
combustible materials, gasoline and other flammable vapors and liquids.
• Under no circumstances should this appliance be modified.
• This appliance must not be connected to a chimney flue pipe serving a separate solid fuel burning appliance.
• Do not use this appliance if any part has been under water. Immediately call a qualified service technician to
inspect the appliance and to replace any part of the control system and any gas control which has been under
water.
• Do not operate the appliance with the glass door removed, cracked or broken. Replacement of the glass
should be done by a licensed or qualified service person.
• Do not strike or slam shut the appliance glass door.
• When equipped with pressure relief doors, they must be kept closed while the appliance is operating to
prevent exhaust fumes containing carbon monoxide, from entering into the home. Temperatures of the exhaust
escaping through these openings can also cause the surrounding combustible materials to overheat and catch
fire.
• Only doors / optional fronts certified with the appliance are to be installed on the appliance.
• Keep the packaging material out of reach of children and dispose of the material in a safe manner. As with all
plastic bags, these are not toys and should be kept away from children and infants.
• As with any combustion appliance, we recommend having your appliance regularly inspected and serviced as
well as having a Carbon Monoxide Detector installed in the same area to defend you and your family against
Carbon Monoxide.
• Ensure clearances to combustibles are maintained when building a mantel or shelves above the appliance.
Elevated temperatures on the wall or in the air above the appliance can cause melting, discolouration or
damage of decorations, a T.V. or other electronic components.
