Asus PB238Q User manual

PB238Q Series
LCD Monitor
User Guide

ii
Copyright © 2012 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any
means, except documentation kept by the purchaser for backup purposes, without the express written
permission of ASUSTeK COMPUTER INC. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless
such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the
product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS
MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identication or explanation and to the
owners’ benet, without intent to infringe.
Table of contents
Notices......................................................................................................... iii
Safety information ...................................................................................... iv
Care & Cleaning........................................................................................... v
1.1 Welcome! ...................................................................................... 1-1
1.2 Package contents......................................................................... 1-1
1.3 Monitor introduction .................................................................... 1-2
1.3.1 Front of the LCD monitor ................................................ 1-2
1.3.2 Rear of the LCD monitor ................................................. 1-4
1.3.3 QuickFit Function ............................................................ 1-5
2.1 Detaching the arm/stand
(for VESA wall mount) ................................................................. 2-1
2.2 Adjusting the monitor.................................................................. 2-2
2.3 Connecting the cables................................................................. 2-3
3.1 OSD (On-Screen Display) menu ................................................. 3-1
3.1.1 Howtorecongure.......................................................... 3-1
3.1.2 OSD Function Introduction.............................................. 3-2
3.2 Specications............................................................................... 3-7
3.3 Troubleshooting (FAQ)................................................................ 3-8
3.4 Supported Timing List........................................................................3-9

iii
Notices
Federal Communications Commission Statement
This device complies with Part 15 of the FCC Rules. Operation is subject
tothefollowingtwoconditions:
• This device may not cause harmful interference, and
• Thisdevicemustacceptanyinterferencereceivedincluding
interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
ClassBdigitaldevice,pursuanttoPart15oftheFCCRules.Theselimits
aredesignedtoprovidereasonableprotectionagainstharmfulinterference
inaresidentialinstallation.Thisequipmentgenerates,usesandcan
radiateradiofrequencyenergyand,ifnotinstalledandusedinaccordance
with manufacturer’s instructions, may cause harmful interference to radio
communications.However,thereisnoguaranteethatinterferencewill
not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turningtheequipmentoffandon,theuserisencouragedtotrytocorrect
theinterferencebyoneormoreofthefollowingmeasures:
• Reorientorrelocatethereceivingantenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
AsanEnergyStar® Partner, our company has determined
thatthisproductmeetstheEnergyStar® guidelinesfor
energyefciency.
Canadian Department of Communications Statement
ThisdigitalapparatusdoesnotexceedtheClassBlimitsforradio
noiseemissionsfromdigitalapparatussetoutintheRadioInterference
RegulationsoftheCanadianDepartmentofCommunications.
ThisclassBdigitalapparatuscomplieswithCanadianICES-003.

iv
Safety information
• Beforesettingupthemonitor,carefullyreadallthedocumentationthat
camewiththepackage.
• To prevent fire or shock hazard, never expose the monitor to rain or
moisture.
• Nevertrytoopenthemonitorcabinet.Thedangeroushighvoltages
inside the monitor may result in serious physical injury.
• If the power supply is broken, do not try to fix it by yourself. Contact a
qualified service technician or your retailer.
• Beforeusingtheproduct,makesureallcablesarecorrectlyconnected
andthepowercablesarenotdamaged.Ifyoudetectanydamage,
contact your dealer immediately.
• Slotsandopeningsonthebackortopofthecabinetareprovidedfor
ventilation. Do not block these slots. Never place this product near or
over a radiator or heat source unless proper ventilation is provided.
• The monitor should be operated only from the type of power source
indicated on the label. If you are not sure of the type of power supply to
your home, consult your dealer or local power company.
• Usetheappropriatepowerplugwhichcomplieswithyourlocalpower
standard.
• Donotoverloadpowerstripsandextentioncords.Overloadingcan
result in fire or electric shock.
• Avoid dust, humidity, and temperature extremes. Do not place the
monitor in any area where it may become wet. Place the monitor on a
stable surface.
• Unplugtheunitduringalightningstormorifitwillnotbeusedfora
longperiodoftime.Thiswillprotectthemonitorfromdamagedueto
powersurges.
• Never push objects or spill liquid of any kind into the slots on the
monitor cabinet.
• To ensure satisfactory operation, in case use at a PC then it should
use the monitor only with computers which have appropriate
configuredreceptaclesmarkedbetween100-240VAC.
• If you encounter technical problems with the monitor, contact a
qualified service technician or your retailer.
• The wall socket shall be installed near the equipment and shall be
easily accessible.

v
Care & Cleaning
• Before you lift or reposition your monitor, it is better to disconnect the
cablesandpowercord.Followthecorrectliftingtechniqueswhen
positioningthemonitor.Whenliftingorcarryingthemonitor,graspthe
edgesofthemonitor.Donotliftthedisplaybythestandorthecord.
• Cleaning.Turnyourmonitoroffandunplugthepowercord.Cleanthe
monitor surface with a lint-free, non-abrasive cloth. Stubborn stains
may be removed with a cloth dampened with mild cleaner.
• Avoidusingacleanercontainingalcoholoracetone.Useacleaner
intended for use with the LED. Never spray cleaner directly on the
screen, as it may drip inside the monitor and cause an electric shock.
The following symptoms are normal with the monitor:
• Thescreenmayflickerduringtheinitialuseduetothenatureofthe
fluorescentlight.TurnoffthePowerSwitchandturnitonagainto
make sure that the flicker disappears.
• Youmayfindslightlyunevenbrightnessonthescreendependingon
the desktop pattern you use.
• Whenthesameimageisdisplayedforhours,anafterimageofthe
previousscreenmayremainafterswitchingtheimage.Thescreenwill
recover slowly or you can turn off the Power Switch for hours.
• Whenthescreenbecomesblackorflashes,orcannotworkanymore,
contact your dealer or service center to fix it. Do not repair the screen
by yourself!
Conventions used in this guide
WARNING:Informationtopreventinjurytoyourselfwhentryingto
complete a task.
CAUTION:Informationtopreventdamagetothecomponentswhen
tryingtocompleteatask.
IMPORTANT:InformationthatyouMUSTfollowtocompleteatask.
NOTE:Tipsandadditionalinformationtoaidincompletingatask.

vi
Wheretondmoreinformation
Refertothefollowingsourcesforadditionalinformationandforproductand
software updates.
1. ASUS websites
The ASUS websites worldwide provide updated information on ASUS
hardware and software products. Refer to http://www.asus.com
2. Optional documentation
Yourproductpackagemayincludeoptionaldocumentationthatmayhave
been added by your dealer. These documents are not part of the standard
package.

1-1ASUS LCD Monitor PB238Q Series
1.1 Welcome!
ThankyouforpurchasingtheASUS®PB238Q Series LCD monitor!
The latest widescreen LCD monitor from ASUS provides a crisper, broader, and
brighterdisplay,plusahostoffeaturesthatenhanceyourviewingexperience.
Withthesefeatures,youcanenjoytheconvenienceanddelightfulvisual
experiencethatthePB238QSeriesbringsyou!
1.2 Package contents
CheckyourPB238QSeriesLCDmonitorpackageforthefollowingitems:
LCD monitor
Power Cord
 VGACable
DVI Cable
DisplayPort Cable
USB Cable
Cable Tie
Audio Cable
 QuickStartGuide
 WarrantyCard
Ifanyoftheaboveitemsisdamagedormissing,contactyourretailer
immediately.

1-2 Chapter1:ProductIntroduction
1.3 Monitor introduction
1.3.1 Front of the LCD monitor
6
7
5
4
3
2
1

1. PowerButton/PowerIndicator:
• Press this button to turn the monitor on/off.
• The color definition of the power indicator is shown below.
Status Description
White ON
Amber Standby mode
OFF OFF
2. InputSelectButton:
• Press this button to select input source.
Press button(InputSelectbutton)todisplayHDMI/DisplayPortsignalsafter
you connect HDMI/DisplayPort cable with the monitor.
3. Button:
• Press this button to decrease values or to move your selection
left/down.
• This is also a hot key for Volume adjustment.

1-3ASUS LCD Monitor PB238Q Series
4. MENUButton:
• Press this button to turn on the OSD menu, or to enact the
selected OSD menu item.
• Press this button to exit the hotkey OSD menu.
5. Button:
• Press this button to increase values or to move your selection
right/up.
• Brightnesshotkey
6. Button:
• Press this button to select a desired preset mode.
• PressthisbuttontoexittheOSDmenuortogobacktothe
previous menu when the OSD menu is active.
• Press this button for 2 ~ 4 seconds to automatically adjust the
imagetoitsoptimizedposition,clock,andphase(forVGAmode
only).
7. QuickFitbutton:
• PressthisbuttontoactivatetheQuickFitfunctiondesignedfor
alignment.
• TheQuickFitfunctioncontains7pagesofcommongridpatterns,
paper sizes, and photo sizes. (Please refer to 1.3.3 QuickFit
Function)

1-4 Chapter1:ProductIntroduction
1.3.2 Rear of the LCD monitor
4321 5 6 8 9 107
11
Rear connectors
1. AC-INport:Thisportconnectsthepowercord.
2. Powerswitch:Pressthisswitchtoturnon/offpower.
3. DisplayPort. This port is for connection with a DisplayPort compatible
device.
4. HDMIport:ThisportisforconnectionwithanHDMIcompatible
device.
5. DVIport:This24-pinportisforPC(PersonalComputer)DVI-Ddigital
signalconnection.
6. VGAport:This15-pinportisforPCVGAconnection.
7. AudioLine-inPort:
8. USBupstreamport:ThisportisforconnectionwithaUSBupstream
cable.
9. USBdownstreamports:TheseportsareforconnectionwithUSB
devices,suchasUSBkeyboard/mouse,USBashdrive,etc.

1-5ASUS LCD Monitor PB238Q Series
10. Kensingtonlockslot.
11. USBdownstreamports:TheseportsareforconnectionwithUSB
devices,suchasUSBkeyboard/mouse,USBashdrive,etc.
1.3.3 QuickFit Function
TheQuickFitfunctioncontainsthreepatterns:(1)Grid(2)Papersize(3)Photo
size.
1. Gridpatterns
Thegridpatternsfacilitatedesignersanduserstoorganizecontentandlayoutona
pageandachieveaconsistentlookandfeel.
AlignmentGrid
QuiFit - Alignment Grid
Alignment Grid

2. Paper size
QuickFit provides numerous commonly used standard paper sizes for users to
view their documents in real size on the screen.
Letter
QuiFit - Letter
Letter
 

1-6 Chapter1:ProductIntroduction
3. Photo size
The various real photo sizes displayed in the QuickFit function provides
photographersandotheruserstoaccuratelyviewandedittheirphotosinrealsize
on the screen.
Photo 4x6, 3x5, 2x2 Photo8x10,5x7
QuiFit - 4x6, 3x5, 2x2
4x6 3x5 2x2
  QuiFit - 8x10, 5x7
8x10 5x7
 

2-1ASUS LCD Monitor PB238Q Series
2.1 Detaching the arm/stand
(for VESA wall mount)
ThedetachablestandofthismonitorisspeciallydesignedforVESAwallmount.
Todetachthearm/stand:
1. Disconnectpowerandsignalcables.Carefullyput the front of the
monitor face down on a clean table.
2. Useascrewdrivertoremovethefourscrewsonthearm(Figure1),
andthendetachthearm/standfromthemonitor(Figure2).
• Werecommendthatyoucoverthetablesurfacewithsoftclothtoprevent
damagetothemonitor.
• Holdthestandofthemonitorwhileremovingthescrews.
Figure1 Figure2
• TheVESAwallmountkit(100x100mm)ispurchasedseparately.
• UseonlytheULListedWallMountBracketwithminimumweight/load22.7
kg(Screwsize:4x10mm).

2-2 Chapter3:GeneralInstruction
2.2 Adjusting the monitor
• Foroptimalviewing,werecommendthatyoulookatthefullfaceofthe
monitor,thenadjustthemonitortotheanglethatismostcomfortable
for you.
• Holdthestandtopreventthemonitorfromfallingwhenyouchangeits
angle.
• Youcanadjustthemonitor’sanglefrom+20˚to-5˚anditallows60˚
swiveladjustmentfromeitherleftorright.Youcanalsoadjustthe
monitor’sheightwithin+/-10cm.


10cm
-5° ~ +20°
60°
0°
60°
Pivoting the monitor
1. Liftthemonitortothehighestposition.
2. Tiltthemonitortoitsmaximumangle.
3. Pivotthemonitorclockwisetotheangleyouneed.
-5° ~ +20°
123




Itisnormalthatthemonitorslightlyshakeswhileyouadjusttheviewingangle.

2-3ASUS LCD Monitor PB238Q Series
2.3 Connecting the cables
Connectthecablesasthefollowinginstructions:
• To connect the power cord:Connectoneendofthepowercord
securely to the monitor’s AC input port, the other end to a power outlet.
• To connect the VGA/HDMI/DVI/DisplayPort cable:
a.PlugoneendoftheVGA/HDMI/DVI/DisplayPortcabletothemonitor’sVGA/
HDMI/DVI/DisplayPort jack.
b.ConnecttheotherendoftheVGA/HDMI/DVI/DisplayPortcabletoyour
computer’sVGA/HDMI/DVI/DisplayPortjack.
c.TightenthetwoscrewstosecuretheVGA/DVIconnector.
• To connect the audio cable: Plugoneendoftheaudiocabletothe
monitor’s Audio Line-in Port . Connect the other end of the audio cable to your
computer’s audio Port.
• To use the USB ports:Plugthesmallerend(typeB)oftheUSB
upstreamcabletothemonitor’sUSBupstreamport,andthelargerend
(type A) to your computer’s USB port.
Whenthesecablesareconnected,youcanchoosethedesiredsignalfromthe
Input Select item in the OSD menu.

3-1 Chapter3:GeneralInstruction
3.1 OSD (On-Screen Display) menu
3.1.1 Howtorecongure
PB238
Splendid
Color
Sound
Input Select
Move Menu Exit
System Setup
Scenery Mode
Standard Mode
Theater Mode
Game Mode
sRGB
Night View Mode
1. Press the MENU button to activate the OSD menu.
2. Press and tonavigatethroughthefunctions.Highlightandactivate
thedesiredfunctionbypressingtheMENUbutton.Ifthefunctionselected
has a sub-menu, press and againtonavigatethroughthesub-menu
functions.Highlightandactivatethedesiredsub-menufunctionbypressing
the MENU button.
3. Press and tochangethesettingsoftheselectedfunction.
4. To exit the OSD menu, press the button. Repeat step 2 and step 3 to
adjust any other function.

3-2ASUS LCD Monitor PB238Q Series
3.1.2 OSD Function Introduction
1. Splendid
This function contains six sub-functions that you can select for your
preference.EachmodehastheResetselection,allowingyoutomaintain
yoursettingorreturntothepresetmode.
PB238
Splendid
Color
Sound
Input Select
Move Menu Exit
System Setup
Scenery Mode
Standard Mode
Theater Mode
Game Mode
sRGB
Night View Mode
• Scenery Mode:Thisisthebestchoiceforsceneryphoto
displayingwithSPLENDID™VideoIntelligence.
• Standard Mode:Thisisthebestchoicefordocumenteditingwith
SPLENDID™VideoIntelligence.
• Theater Mode:Thisisthebestchoiceformoviewatchingwith
SPLENDID™VideoIntelligence.
• Game Mode:Thisisthebestchoiceforgameplayingwith
SPLENDID™VideoIntelligence.
• Night View Mode:Thisisthebestchoiceforplayingdark-scene
gameorwatchingmoviewithSPLENDID™VideoIntelligence.
• sRGB:Thisisthebestchoiceforviewingphotosandgraphics
from PCs.
• In the Standard Mode, the Saturation, Skin Tone, Sharpness, and
ASCRfunctionsarenotuser-configurable.
• In the sRGB, the Saturation, Color Temp., Skin Tone, Sharpness, and
ASCRfunctionsarenotuser-congurable.

3-3 Chapter3:GeneralInstruction
2. Color
Selecttheimagecoloryoulikefromthisfunction.
PB238
Splendid
Color
Sound
Input Select
Move Menu Exit
System Setup
Brightness
Contrast
Saturation
Color Temp.
100
80
User Mode
Skin Tone
50
Natural
• Brightness:Theadjustingrangeisfrom0to100.The
button is also a hot key to activate this function.
• Contrast:Theadjustingrangeisfrom0to100.
• Saturation:Theadjustingrangeisfrom0to100.
• Color Temp.:Containthreepresetcolormodes(Cool,Normal,
Warm)andoneUserMode.
• Skin Tone:ContainthreecolormodesincludingReddish,Natural,
and Yellowish.
IntheUserMode,colorsofR(Red),G(Green),andB(Blue)are
userconfigurable;theadjustingrangeisfrom0~100.

3-4ASUS LCD Monitor PB238Q Series
3. Image
YoucanadjusttheimageSharpness,TraceFree,AspectControl,Position
(VGAonly),andFocus(VGAonly)fromthismainfunction.
PB238
Splendid
Color
Sound
Input Select
Move Menu Exit
System Setup Focus
Sharpness
Trace Free
Aspect Control
ASCR
50
60
Full
Position
OFF
• Sharpness:Adjustthepicturesharpness.Theadjustingrangeis
from0to100.
• Trace Free:Speed up the response time by Over Drive
technology.Theadjustingrangeisfromlower0tofaster100.
• Aspect Control:Adjusttheaspectratioto“Full”,“4:3”,or“Over
Scan”(onlyavailableforHDMIinput).
• ASCR:SelectONorOFFtoenableordisabledynamiccontrast
ratio function.
• Position:Adjustthehorizontalposition(H-Position)andthe
verticalposition(V-Position)oftheimage.Theadjustingrangeis
from0to100(onlyavailableforVGAinput).
• Focus:ReduceHorizontal-linenoiseandVertical-linenoiseofthe
imagebyadjusting(Phase)and(Clock)separately.Theadjusting
rangeisfrom0to100(onlyavailableforVGAinput).

3-5 Chapter3:GeneralInstruction
4. Sound
Adjustthesoundsettingstoyourpreference.
PB238
Splendid
Color
Sound
Input Select
Move Menu Exit
System Setup
Volume
Mute
Source
50
OFF
Line In
• Volume:Adjusttheoutputvolumelevel.
• Mute:Mutetheoutputvolume.
• Source:Adjustaudiosourceto“LineIn”or“HDMI”(onlyavailable
forHDMIinput);
Adjustaudiosourceto“LineIn”or“DisplayPort”(onlyavailablefor
DisplayPort input).
5. Input Select
Select the input source from VGA, DVI, HDMI, or DisplayPort.
PB238
Splendid
Color
Sound
Input Select
Move Menu Exit
System Setup
VGA
DVI
HDMI
DisplayPort
