Asus VP349CGL Series User manual

VP349CGL Series
LCD Monitor
User Guide

ii
Copyright © 2021 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any
means, except documentation kept by the purchaser for backup purposes, without the express written
permission of ASUSTeK COMPUTER INC. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless
such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the
product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS
MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identication or explanation and to the
owners’ benet, without intent to infringe.
Table of contents
Notices......................................................................................................... iii
Safety information ...................................................................................... iv
Care & Cleaning......................................................................................... vii
1.1 Welcome ....................................................................................... 1-2
1.2 Package contents......................................................................... 1-2
1.3 Assembling the monitor.............................................................. 1-3
1.4 Connect cables............................................................................. 1-4
1.4.1 Rear of the LCD monitor ................................................. 1-4
1.5 Monitor introduction .................................................................... 1-5
1.5.1 Using the Controls button .............................................. 1-5
2.1 Detaching the arm/stand (for VESA wall mount) ...................... 2-1
2.2 Adjusting the monitor.................................................................. 2-2
2.3 Outline dimension........................................................................ 2-3
3.1 OSD (On-Screen Display) menu ................................................. 3-1
3.1.1 Howtorecongure.......................................................... 3-1
3.1.2 OSD Function Introduction.............................................. 3-2
3.2 Specications............................................................................. 3-14
3.3 Troubleshooting (FAQ).............................................................. 3-15
3.4 Supported Timing List............................................................... 3-16

iii
Notices
Federal Communications Commission Statement
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
• This device may not cause harmful interference.
• This device must accept any interference received including
interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for radio
noise emissions from digital apparatus set out in the Radio Interference
Regulations of the Canadian Department of Communications.
This class B digital apparatus complies with Canadian ICES-003.
Made in China

iv
Safety information
• Before setting up the monitor, carefully read all the documentation that
came with the package.
• To prevent fire or shock hazard, never expose the monitor to rain or
moisture.
• Never try to open the monitor cabinet. The dangerous high voltages
inside the monitor may result in serious physical injury.
• If the power supply is broken, do not try to fix it by yourself. Contact a
qualified service technician or your retailer.
• Before using the product, make sure all cables are correctly connected
and the power cables are not damaged. If you detect any damage,
contact your dealer immediately.
• Slots and openings on the back or top of the cabinet are provided for
ventilation. Do not block these slots. Never place this product near or
over a radiator or heat source unless proper ventilation is provided.
• The monitor should be operated only from the type of power source
indicated on the label. If you are not sure of the type of power supply to
your home, consult your dealer or local power company.
• Use the appropriate power plug which complies with your local power
standard.
• Do not overload power strips and extension cords. Overloading can
result in fire or electric shock.
• Avoid dust, humidity, and temperature extremes. Do not place the
monitor in any area where it may become wet. Place the monitor on a
stable surface.
• Unplug the unit during a lightning storm or if it will not be used for a
long period of time. This will protect the monitor from damage due to
power surges.
• Never push objects or spill liquid of any kind into the slots on the
monitor cabinet.
• To ensure satisfactory operation, use the monitor only with UL listed
computers which have appropriate configured receptacles marked
between 100 ~ 240V AC.
• The socket-outlet shall be installed near the equipment and shall be
easily accessible
• If you encounter technical problems with the monitor, contact a
qualified servic er.
• Provide an earthing connection before the mains plug is connected to
the mains. And, when disconnecting the earthing connection, be sure
to disconnect after pulling out the mains plug from the mains.

v
WARNING
Usageofotherthanspeciedhead-orearphonescanresultinhearing
loss due to excessive sound pressures.
Declaration of Conformity This device complies with the requirements
set out in the Council Directive on the Approximation of the Laws of the
Member States relating to Electromagnetic Compatibility (2014/30/EU),
Low-voltage Directive (2014/35/EU), ErP Directive (2009/125/EC) and
RoHS directive (2011/65/EU). This product has been tested and found
to comply with the harmonized standards for Information Technology
Equipment, these harmonized standards published under Directives of
OfcialJournaloftheEuropeanUnion.
Excessive sound pressure from earphones and headphones can cause
hearing loss. Adjustment of the equalizer to maximum increases the
earphones and headphones output voltage and therefore the sound
pressure level.
Do not dispose of electrical appliances as unsorted municipal waste, use
separate collection facilities.
Contact your local government for information regarding the collection
systems available.
Ifelectricalappliancesaredisposedofinlandllsordumps,hazardous
substances can leak into the groundwater and get into the food chain,
damaging your health and well-being.
When replacing old appliances with new once, the retailer is legally
obligated to take back your old appliance for disposal at least for free of
charge.
Pleaseconrmthedistributionsysteminbuildinginstallationshallprovide
the circuit breaker rated 120/240V, 20A (maximum).
If provided with a 3-pin attachment plug on the power cord, plug the cord
into a grounded (earthed) 3-pin outlet. Do not disable the power cord
grounding pin, for example, by attaching a 2-pin adapter. The grounding
pin is an important safety feature.

vi
The product may fall, causing serious personal injury or death. To
preventinjury,thisproductmustbesecurelyattachedtotheoor/wallin
accordance with the installation instructions.
A product may fall, causing serious personal injury or death. Many injuries,
particularly to children, can be avoided by taking simple precautions such
as:
ALWAYS use cabinets or stands or installation methods recommended by
the manufacturer of the product set.
ALWAYS use furniture that can safely support the product.
ALWAYS ensure the product is not overhanging the edge of the supporting
furniture.
ALWAYS educate children about the dangers of climbing on furniture to
reach the product or its controls.
ALWAYS route cords and cables connected to your product so they cannot
be tripped over, pulled or grabbed.
NEVER place a product in an unstable location.
NEVER place the product on tall furniture (for example, cupboards or
bookcases) without anchoring both the furniture and the product to a
suitable support.
NEVER place the product on cloth or other materials that may be located
between the product and supporting furniture.
NEVER place items that might tempt children to climb, such as toys and
remote controls, on the top of the product or furniture on which the product
is placed.
If the existing product is going to be retained and relocated, the same
considerations as above should be applied.

vii
Care & Cleaning
• Before you lift or reposition your monitor, it is better to disconnect the
cables and power cord. Follow the correct lifting techniques when
positioning the monitor. When lifting or carrying the monitor, grasp the
edges of the monitor. Do not lift the display by the stand or the cord.
• Cleaning. Turn your monitor off and unplug the power cord. Clean the
monitor surface with a lint-free, non-abrasive cloth. Stubborn stains
may be removed with a cloth dampened with mild cleaner.
• Avoid using a cleaner containing alcohol or acetone. Use a cleaner
intended for use with the LCD. Never spray cleaner directly on the
screen, as it may drip inside the monitor and cause an electric shock.
The following symptoms are normal with the monitor:
• The screen may flicker during the initial use due to the nature of the
fluorescent light. Turn off the Power Switch and turn it on again to
make sure that the flicker disappears.
• You may find slightly uneven brightness on the screen depending on
the desktop pattern you use.
• When the same image is displayed for hours, an afterimage of the
previous screen may remain after switching the image. The screen will
recover slowly or you can turn off the Power Switch for hours.
• When the screen becomes black or flashes, or cannot work anymore,
contact your dealer or service center to fix it. Do not repair the screen
by yourself!
Conventions used in this guide
WARNING: Information to prevent injury to yourself when trying to
complete a task.
CAUTION: Information to prevent damage to the components
when trying to complete a task.
IMPORTANT: Information that you MUST follow to complete a
task.
NOTE: Tips and additional information to aid in completing a task.

viii
Wheretondmoreinformation
Refer to the following sources for additional information and for product
and software updates.
1. ASUS websites
The ASUS websites worldwide provide updated information on ASUS
hardware and software products. Refer to http://www.asus.com
2. Optional documentation
Your product package may include optional documentation that may
have been added by your dealer. These documents are not part of
the standard package.
Disposal of waste equipment by user in private
household in the European Union
This symbol on the product or on its packaging indicates
that this product must not be disposed of with your other
household waste. Instead, it is your responsibility to dispose
of your waste equipment by handing it over to a designated
collection point for the recycling of waste electrical and
electronic equipment. The separate collection and recycling
of your waste equipment at the time of disposal will help to
conserve natural resources and ensure that it is recycled in a
manner that protects human health and the environment. For
more information ab ut where you can drop off your waste
equipmentforrecycling,pleasecontactyourlocalcityofce,
your household waste disposal service or the shop where
you purchased the product.
Product information for EU energy label

1-1
ASUS LCD Monitor VP349Series
Prevent Tipping
When using the display, fasten the LCD to a wall using a cord or chain that can
support the weight of the monitor in order to prevent the monitor from falling.
Cord or chain
M4 or M6 Screw
Cord
1
2
• Display design may differ from those illustrated.
• Installing must be done by a qualified technician , and please
contact your supplier for more information.
• For the Models with net weight >=7kg. Please select the suitable
way to Prevent Tipping.
• For the models with VESA Mount, please use method , install
the screws with ring to the VESA Mount hole, then tie the cord
or chain to the wall. Otherwise, please use method to tie the
cord or chain to the stand and then fix it to the wall.

1-2 Chapter 1: Product Introduction
1.1 Welcome
Thank you for purchasing the ASUS®LCD monitor!
The latest widescreen LCD monitor from ASUS provides a crisper,
broader, and brighter display, plus a host of features that enhance your
viewing experience.
With these features, you can enjoy the convenience and delightful visual
experience that the monitor brings you!
1.2 Package contents
Check your package for the following items:
LCD Monitor
Monitor Base
Quick Start Guide
Warranty Card
1x Power Cord
1x HDMI Cable (optional)
1x DP Cable (optional)
1x Type-C Cable (optional)
• If any of the above items is damaged or missing, contact your retailer
immediately.

1-3
ASUS LCD Monitor VP349Series
1.3 Assembling the monitor
To assemble the monitor
1. Placethedisplayatonaclothonthetable,Thenattachthebase
tothearmandxwiththescrewtojointhemtightly.Youcaneasily
tightenthescrewbyngers.
2. Adjust the monitor to the angle that is most comfortable for you.
2
1
3
-5 ~ 35
+/-180°
130mm
*Base screw size: M6 x 14mm

1-4 Chapter 1: Product Introduction
1.4 Connect cables
1.4.1 Rear of the LCD monitor
6
HDMI 15W
3 4
25
1
1. AC-IN Port
2. HDMI Port
3. DisplayPort
4. Type-C Port
5. Audio - out Port
6. Kensington Lock

1-5
ASUS LCD Monitor VP349Series
1.5 Monitor introduction
1.5.1 Using the Controls button
Use the control button on the back of the monitor to adjust the image
settings.
Power
Close
Menu
Input Select
1. Power Indicator:
• The color definition of the power indicator is as the below table.
Status Description
White ON
Amber Standby mode
OFF OFF
2. Power Button:
• Press this button to turn the monitor on/off.
3. (5-way) Button:
• Press this button to turn on the OSD menu.
• Turns on the start menu. Execute the selected OSD menu item.
• Increases/Decreases values or moves your selection up/down/left/right
4. Input Select Button
• This is a hotkey. The default setting is Input Select. Use Input Select
hotkey to switch from “HDMI”, “DisplayPort” or “USB Type-C”

2-1
ASUS LCD Monitor VP349Series
2.1 Detaching the arm/stand (for VESA wall
mount)
The detachable stand of this monitor is specially designed for VESA wall
mount.
To detach the arm/stand
1. Disconnect power and signal cables. Carefully put the front of the
monitor face down on a clean table.
2. Press the quick release button from rear cover, and then detach the
arm/stand from the monitor.
• We recommend that you cover the table surface with soft cloth to prevent
damage to the monitor.
• Hold the stand of the monitor while removing the screws.
1
2
1
2

2-2 Chapter 2: Setup
2.2 Adjusting the monitor
• For optimal viewing, we recommend that you look at the full face of the
monitor, then adjust the monitor to the angle that is most comfortable
for you.
• Hold the stand to prevent the monitor from falling when you change its
angle.
• Youcanadjustthemonitor’sanglefrom+35˚to-5˚.
-5 ~ 35
130mm
+/-180°
It is normal that the monitor slightly shakes while you adjust the viewing
angle.

2-3
ASUS LCD Monitor VP349Series
2.3 Outline dimension
Unit: mm [inch]

3-1
ASUS LCD Monitor VP349Series
3.1 OSD (On-Screen Display) menu
3.1.1 Howtorecongure
Reading Mode
Darkroom Mode
Splendid
Scenery Mode
sRGB Mode
Game Mode
Night View Mode
Theater Mode
Standard Mode USB Type-C 3440x1440@60Hz
VP349CGL HDR OFF
Standard Mode
1. Press the MENU button to activate the OSD menu.
2. Press the and buttons to toggle between options in the
Menu. As you move from one icon to another, the option name is
highlighted.
3. To select the highlighted item on the menu press the Center key.
4. Press the and buttons to select the desired parameter.
5. Press the Center key to enter the slide bar and then use the or
buttons, according to the indicators on the menu, to make your
changes.
6. Press the ◄/► to move left / right menu.

3-2 Chapter 3: General Instruction
3.1.2 OSD Function Introduction
1. Splendid
This function contains eight sub-functions that you can select for
your preference. Each mode has the Reset selection, allowing you to
maintain your setting or return to the preset mode.
Reading Mode
Darkroom Mode
Splendid
Scenery Mode
sRGB Mode
Game Mode
Night View Mode
Theater Mode
Standard Mode USB Type-C 3440x1440@60Hz
VP349CGL HDR OFF
Standard Mode
• Standard Mode: This is the best choice for document editing with
SPLENDID™ Video Intelligence Technology.
• sRGB Mode: This is the best choice for viewing photos and graphics
from PCs.
• Scenery Mode: This is the best choice for scenery photo displaying with
SPLENDID™ Video Intelligence Technology.
• Theater Mode: This is the best choice for movie watching with
SPLENDID™ Video Intelligence Technology.
• Game Mode: This is the best choice for game playing with SPLENDID™
Video Intelligence Technology.
• Night View Mode: This is the best choice for playing dark-scene game
or watching dark-scene movie with SPLENDID™ Video Intelligence
Technology.
• Reading Mode : This is the best choice for book reading.
• Darkroom Mode : This is the best choice for a weak ambient light
environmen.
• In the Standard Mode, the Saturation, SkinTone, Sharpness, and ASCR
functions are not user-configurable.
• In the sRGB, the Saturation, Color Temp., SkinTone, Sharpness, Brightness,
Contrast and ASCR functions are not user-configurable.
• In the Reading Mode, the Saturation, SkinTone, ASCR, contrast, and Color
Temp functions are not user-configurable.

3-3
ASUS LCD Monitor VP349Series
2. EyeCare
EyeCare
Color Augmentation
Rest Reminder
EyeCheck
Blue Light Filter
Standard Mode DisplayPort 3440x1440@60Hz
VP349CGL HDR OFF
• Blue Light Filter: In this function, you can adjust the blue light filter from
0 to max. 0: no changes；Max: The higher the level, the less blue light
is scattered. When blue light filter is activated, the default settings of
Standard Mode will be automatically imported. Besides maximum level,
the brightness is user-configurable. Maximum is the optimized setting.
It is compliance with TUV low blue light certification*. The brightness
function is not user configurable.
• When the user adjusts blue light filter bar to maximum level.
• *When color augmentation is in default value (50).
• Rest Reminder: This function provides you a rest reminder according
to how long you set for your working time. For example, a user sets 60
minutes working time and there will be a pop up reminder appeared on
the upper left corner of the monitor for 5 seconds. Press any key to make
this reminder OSD disappeared.
• When this function is enable, the following functions are not available:
Splendid Demo Mode, GamePlus and QuickFit.
• Color Augmentation: The adjusting range of color enhancement is from
0 to 100.
• This function is not available in sRGB mode under Splendid.
• This function is not available when Reddish or Yellowish is selected in the
Skin Tone menu.

3-4 Chapter 3: General Instruction
• EyeCheck: The EyeCheck function contains three patterns: (1) Snellen
Chart (2) Amsler Grid (3)Astigmatism.
1. Snellen Chart
P1 P3
L11
L10
L9
L8
L7
P2
L6
L5
L4
L3
L2
L1
2. Amsler Grid
While focusing at the center point, check that all the lines are
straight.
3. Astigmatism
Check that each line is of the same width.
