Asus VS238 Series User manual

VS228/VS238
/VS247 Series
LCD Monitor
User Guide
Downloaded from www.vandenborre.be

ii
Copyright © 2013 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any
means, except documentation kept by the purchaser for backup purposes, without the express written
permission of ASUSTeK COMPUTER INC. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless
such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the
product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS
MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identication or explanation and to the
owners’ benet, without intent to infringe.
Table of contents
Notices......................................................................................................... iii
Safety information ...................................................................................... iv
Care & Cleaning ........................................................................................... v
1.1 Welcome! ...................................................................................... 1-1
1.2 Package contents......................................................................... 1-1
1.3 Assembling the monitor base..................................................... 1-2
1.4 Connecting cables ....................................................................... 1-2
1.5 Monitor introduction .................................................................... 1-3
1.5.1 Front of the LCD monitor ................................................ 1-3
1.5.2 Rear of the LCD monitor ................................................. 1-5
2.1 Detaching the arm/stand
(for VESA wall mount).................................................................. 2-1
2.2 Adjusting the monitor.................................................................. 2-2
3.1 OSD (On-Screen Display) menu.................................................. 3-1
3.1.1 Howtorecongure.......................................................... 3-1
3.1.2 OSDFunctionIntroduction.............................................. 3-1
3.2 Specifications............................................................................... 3-6
3.3 Troubleshooting (FAQ)................................................................. 3-9
3.4 Supported Timing List ............................................................... 3-10
Downloaded from www.vandenborre.be

iii
Notices
Federal Communications Commission Statement
ThisdevicecomplieswithPart15oftheFCCRules.Operationissubject
tothefollowingtwoconditions:
• Thisdevicemaynotcauseharmfulinterference,and
• Thisdevicemustacceptanyinterferencereceivedincluding
interferencethatmaycauseundesiredoperation.
Thisequipmenthasbeentestedandfoundtocomplywiththelimitsfora
ClassBdigitaldevice,pursuanttoPart15oftheFCCRules.Theselimits
aredesignedtoprovidereasonableprotectionagainstharmfulinterference
inaresidentialinstallation.Thisequipmentgenerates,usesandcan
radiateradiofrequencyenergyand,ifnotinstalledandusedinaccordance
withmanufacturer’sinstructions,maycauseharmfulinterferencetoradio
communications.However,thereisnoguaranteethatinterferencewill
notoccurinaparticularinstallation.Ifthisequipmentdoescauseharmful
interferencetoradioortelevisionreception,whichcanbedeterminedby
turningtheequipmentoffandon,theuserisencouragedtotrytocorrect
theinterferencebyoneormoreofthefollowingmeasures:
• Reorientorrelocatethereceivingantenna.
• Increasetheseparationbetweentheequipmentandreceiver.
• Connecttheequipmenttoanoutletonacircuitdifferentfromthatto
whichthereceiverisconnected.
• Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
AsanEnergyStar® Partner,ourcompanyhasdetermined
thatthisproductmeetstheEnergyStar® guidelinesfor
energyefciency.
Canadian Department of Communications Statement
ThisdigitalapparatusdoesnotexceedtheClassBlimitsforradio
noiseemissionsfromdigitalapparatussetoutintheRadioInterference
RegulationsoftheCanadianDepartmentofCommunications.
ThisclassBdigitalapparatuscomplieswithCanadianICES-003.
Downloaded from www.vandenborre.be

iv
Safety information
• Beforesettingupthemonitor,carefullyreadallthedocumentationthat
camewiththepackage.
• Topreventfireorshockhazard,neverexposethemonitortorainor
moisture.
• Nevertrytoopenthemonitorcabinet.Thedangeroushighvoltages
insidethemonitormayresultinseriousphysicalinjury.
• Ifthepowersupplyisbroken,donottrytofixitbyyourself.Contacta
qualifiedservicetechnicianoryourretailer.
• Beforeusingtheproduct,makesureallcablesarecorrectlyconnected
andthepowercablesarenotdamaged.Ifyoudetectanydamage,
contactyourdealerimmediately.
• Slotsandopeningsonthebackortopofthecabinetareprovidedfor
ventilation.Donotblocktheseslots.Neverplacethisproductnearor
overaradiatororheatsourceunlessproperventilationisprovided.
• Themonitorshouldbeoperatedonlyfromthetypeofpowersource
indicatedonthelabel.Ifyouarenotsureofthetypeofpowersupplyto
yourhome,consultyourdealerorlocalpowercompany.
• Usetheappropriatepowerplugwhichcomplieswithyourlocalpower
standard.
• Donotoverloadpowerstripsandextentioncords.Overloadingcan
resultinfireorelectricshock.
• Avoiddust,humidity,andtemperatureextremes.Donotplacethe
monitorinanyareawhereitmaybecomewet.Placethemonitorona
stablesurface.
• Unplugtheunitduringalightningstormorifitwillnotbeusedfora
longperiodoftime.Thiswillprotectthemonitorfromdamagedueto
powersurges.
• Neverpushobjectsorspillliquidofanykindintotheslotsonthe
monitorcabinet.
• Toensuresatisfactoryoperation,usethemonitoronlywithULlisted
computerswhichhaveappropriateconfiguredreceptaclesmarked
between100-240VAC.
• Ifyouencountertechnicalproblemswiththemonitor,contacta
qualifiedservicetechnicianoryourretailer.
Downloaded from www.vandenborre.be

v
Care & Cleaning
• Beforeyouliftorrepositionyourmonitor,itisbettertodisconnectthe
cablesandpowercord.Followthecorrectliftingtechniqueswhen
positioningthemonitor.Whenliftingorcarryingthemonitor,graspthe
edgesofthemonitor.Donotliftthedisplaybythestandorthecord.
• Cleaning.Turnyourmonitoroffandunplugthepowercord.Cleanthe
monitorsurfacewithalint-free,non-abrasivecloth.Stubbornstains
mayberemovedwithaclothdampenedwithmildcleaner.
• Avoidusingacleanercontainingalcoholoracetone.Useacleaner
intendedforusewiththeLCD.Neverspraycleanerdirectlyonthe
screen,asitmaydripinsidethemonitorandcauseanelectricshock.
The following symptoms are normal with the monitor:
• Thescreenmayflickerduringtheinitialuseduetothenatureofthe
fluorescentlight.TurnoffthePowerSwitchandturnitonagainto
makesurethattheflickerdisappears.
• Youmayfindslightlyunevenbrightnessonthescreendependingon
thedesktoppatternyouuse.
• Whenthesameimageisdisplayedforhours,anafterimageofthe
previousscreenmayremainafterswitchingtheimage.Thescreenwill
recoverslowlyoryoucanturnoffthePowerSwitchforhours.
• Whenthescreenbecomesblackorflashes,orcannotworkanymore,
contactyourdealerorservicecentertofixit.Donotrepairthescreen
byyourself!
Conventions used in this guide
WARNING:Informationtopreventinjurytoyourselfwhentrying
tocompleteatask.
CAUTION:Informationtopreventdamagetothecomponents
whentryingtocompleteatask.
IMPORTANT:InformationthatyouMUSTfollowtocompletea
task.
NOTE:Tipsandadditionalinformationtoaidincompletingatask.
Downloaded from www.vandenborre.be

vi
Where to find more information
Refertothefollowingsourcesforadditionalinformationandforproduct
andsoftwareupdates.
1. ASUS websites
TheASUSwebsitesworldwideprovideupdatedinformationonASUS
hardwareandsoftwareproducts.Refertohttp://www.asus.com
2. Optional documentation
Yourproductpackagemayincludeoptionaldocumentationthatmay
havebeenaddedbyyourdealer.Thesedocumentsarenotpartof
thestandardpackage.
Downloaded from www.vandenborre.be

1-1
ASUS LCD monitor VS228, VS238, VS247
1.1 Welcome!
ThankyouforpurchasingtheASUS®VS228/VS238/VS247SeriesLCD
monitor!
ThelatestwidescreenLCDmonitorfromASUSprovidesacrisper,
broader,andbrighterdisplay,plusahostoffeaturesthatenhanceyour
viewingexperience.
Withthesefeatures,youcanenjoytheconvenienceanddelightfulvisual
experiencethattheVS228/VS238/VS247Seriesbringsyou!
1.2 Package contents
CheckyourVS228/VS238/VS247SeriesLCDmonitorpackageforthe
followingitems:
LCD monitor
 Monitorbase
 Quickstartguide
 1xPowercord
 1xVGAcable
 1xDVIcable(Onlyforsomemodels)
 1xWarrantycard
Ifanyoftheaboveitemsisdamagedormissing,contactyourretailer
immediately.
Downloaded from www.vandenborre.be

1-2 Chapter 1: Product Introduction
1.3 Assembling the monitor base
To assemble the monitor base:
1. Connectthebasewiththearmofmonitorandturnclockwise.Aclick
indicatesthatthebasehasbeenconnectedsuccessfully.
2. Adjustthemonitortotheanglethatismostcomfortableforyou.
Werecommendthatyoucoverthetablesurfacewithsoftclothto
preventdamagetothemonitor.
1
2
1.4 Connecting cables
To connect cables:
Connectthecablesyouneedbasedonchapter1.5.2,page1-5.
Downloaded from www.vandenborre.be

1-3
ASUS LCD monitor VS228, VS238, VS247
1.5 Monitor introduction
1.5.1 Front of the LCD monitor
12 3 4 6
H
D/N
12 3 4 56
1
1. , , Button:
• Automaticallyadjusttheimagetoitsoptimizedposition,clock,
andphasebylongpressingthisbuttonfor2-4seconds(forVGA
modeonly).( , )
• Usethishotkeytoswitchamongsixvideopresetmodes
(Scenery,Standard,Theater,Game,NightView,andsRGB
Mode)withSPLENDID™VideoEnhancementTechnology.Exit
theOSDmenuorgobacktothepreviousmenuastheOSD
menuisactive.( , )
2. Button:
• Pressthisbuttontodecreasethevalueofthefunctionselected
ormovetothenextfuction.
• Thisisalsoahotkeyforcontrastadjustment.
Downloaded from www.vandenborre.be

1-4 Chapter 1: Product Introduction
3. MENUButton:
• PressthisbuttontoentertheOSDmenu.
• Pressthisbuttontoenter/selecttheicon(function)highlighted
whiletheOSDisactivated.
4. Button:
• Pressthisbuttontoincreasethevalueofthefunctionselected
ormoveright/uptothenextfunction.
• Thisisalsoahotkeyforbrightnessadjustment.
5. InputSelectButton:
• ThisbuttonisavailableformodelVS228HR/VS238HR/
VS247HR/VS247HVonly.
• UsethishotkeytoswitchamongVGA,DVI,orHDMIinputs.
6. PowerButton/PowerIndicator:
• Pressthisbuttontoturnthemonitoron/off.
• Thecolordefinitionofthepowerindicatorisasthetablebelow.
Status Description
Blue ON
Amber Standbymode
OFF OFF
Downloaded from www.vandenborre.be

1-5
ASUS LCD monitor VS228, VS238, VS247
1.5.2 Rear of the LCD monitor
21 3 4 5
1. AC-In
2. HDMI-In
(AvailableformodelVS228HR,VS238HR,VS247HR,VS247HV
only)
3. DVI-In
(AvailableformodelVS228NE/HR,VS238NR/HR,VS247NR/HR/HV
only)
4. VGA-In
5. Earphone-Out
(AvailableformodelVS228HR,VS238HR,VS247HR,VS247HV
only)
Downloaded from www.vandenborre.be

2-1 Chapter 2: Setup
2.1 Detaching the arm/stand
(for VESA wall mount)
ThedetachablestandoftheVS228/VS238/VS247SeriesLCDmonitoris
speciallydesignedforVESAwallmount.
To detach the arm/stand:
1. Pullthestopleverandturnanticlockwisetounlock.
2. Detachthebasefromthemonitor.
3. Useyourngersgentlypullawaytheplatethatcoversthestand
neck.Useascrewdrivertoremovethefourscrewsthatsecurethe
standtothemonitor.
4. Detachthestandfromthemonitor.
• Werecommendthatyoucoverthetablesurfacewithsoftclothto
preventdamagetothemonitor.
• Holdthestandofthemonitorwhileremovingthescrews.
1
2
3
5
4
• TheVESAwallmountkit(100x100mm)ispurchasedseparately.
• UseonlytheULListedWallMountBracketwithminimumweight/
loadaccordingtothemodellistedinthespecificationtable(Screw
size:M4x10mm).
Downloaded from www.vandenborre.be

2-2
ASUS LCD monitor VS228, VS238, VS247
2.2 Adjusting the monitor
• Foroptimalviewing,werecommendthatyoulookatthefullfaceofthe
monitor,thenadjustthemonitortotheanglethatismostcomfortable
foryou.
• Holdthestandtopreventthemonitorfromfallingwhilechangingits
angle.
• Youcanadjustthemonitor’sanglefrom-5˚to20˚.
-5 ~ 20
Downloaded from www.vandenborre.be

3-1 Chapter 3: General Instruction
3.1 OSD (On-Screen Display) menu
3.1.1 How to reconfigure
VS247
Splendid
Color
Input Select
Move Menu Exit
System Setup
Scenery Mode
Standard Mode
Theater Mode
Game Mode
Night View Mode
sRGB
1. Pressthe[MENU]buttontoactivatetheOSDmenu.
2. Pressandtonavigatethroughthefunctions.Highlightand
activatethedesiredfunctionbypressingthe[MENU]button.Ifthe
functionselectedhasasub-menu,pressandagaintonavigate
throughthesub-menufunctions.Highlightandactivatethedesired
sub-menufunctionbypressingthe[MENU]button.
3. Pressandtochangethesettingsoftheselectedfunction.
4. ToexittheOSDmenu,pressthe button.Repeatstep2andstep3
toadjustanyotherfunction.
3.1.2 OSD Function Introduction
1. Splendid
Thisfunctioncontainssixsub-functionsthatyoucanselectforyour
preference.EachmodehastheResetselection,allowingyouto
maintainyoursettingorreturntothepresetmode.
VS247
Splendid
Color
Input Select
Move Menu Exit
System Setup
Scenery Mode
Standard Mode
Theater Mode
Game Mode
Night View Mode
sRGB
• Scenery Mode:Thisisthebestchoiceforsceneryphoto
displayingwithSPLENDID™VideoEnhancement.
Downloaded from www.vandenborre.be

3-2
ASUS LCD monitor VS228, VS238, VS247
• Standard Mode:Thisisthebestchoicefordocumentediting
withSPLENDID™VideoEnhancement.
• Theater Mode:Thisisthebestchoiceformoviewatchingwith
SPLENDID™VideoEnhancement.
• Game Mode:Thisisthebestchoiceforgameplayingwith
SPLENDID™VideoEnhancement.
• Night View Mode:Thisisthebestchoiceforplayingdark-
scenegameorwatchingmoviewithSPLENDID™Video
Enhancement.
• sRGB:Thisisthebestchoiceforviewingphotosandgraphics
fromPCs.
IntheStandard Mode,theSaturation,Skin Tone,Sharpness,and
ASCRfunctionsarenotuser-configurable.
InthesRGB,theBrightness,Contrast,Saturation,Color
Temp.,Skin Tone,Sharpness,andASCRfunctionsarenotuser-
configurable.
2. Color
Selecttheimagecoloryoulikefromthisfunction.
VS247
Splendid
Color
Input Select
Move Menu Exit
System Setup
Brightness
Contrast
Saturation
Color Temp
90
80
User Mode
50
NaturalSkin Tone
Smart View OFF
• Brightness:Theadjustingrangeisfrom0to100.The button
isalsoahotkeytoactivatethisfunction.
• Contrast:Theadjustingrangeisfrom0to100.The buttonis
alsoahotkeytoactivatethisfunction.
• Saturation:Theadjustingrangeisfrom0to100.
• Color Temp.:Containthreepresetcolormodes(Cool,Normal,
Warm)andoneUserMode.
• Skin Tone:ContainthreecolormodesincludingReddish,
Natural,andYellowish.
• Smart View:Enableaclearervisibilityaftertiltedthescreen.
IntheUser Mode,colorsofR (Red),G (Green),andB (Blue) are
userconfigurable;theadjustingrangeisfrom0~100.
Downloaded from www.vandenborre.be

3-3 Chapter 3: General Instruction
3. Image
YoucanadjusttheimageSharpness,AspectControl,Position(VGA
only),andFocus(VGAonly)fromthismainfunction.
VS247
Splendid
Color
Input Select
Move Menu Exit
System Setup
Sharpness
Aspect Control
ASCR
Position
40
Full
OFF
Focus
Trace Free 60
• Sharpness:Asjustthepicturesharpness.Theadjustingrange
isfrom0to100.(Onlyavailableforselecting“StandardMode”in
Splendidmenu.)
• Trace Free:SpeedsuptheresponsetimebyOverDrive
technology.Theadjustingrangeisfromlower0tofaster100.
(AvailableformodelVS247HRonly)
• Aspect Control:Adjusttheaspectratioto“Full”,“4:3”,or“Over
Scan”.(The“OverScan”ratioisonlyavailableforHDMIinput.)
• ASCR:SelectONorOFFtoenableordisabledynamiccontrast
ratiofunction.(ASCR:ASUSSmartContrastRatio.Disabledat
“StandardMode”.)
• Position:Adjustthehorizontalpostition(H-Position)andthe
verticalposition(V-Position)oftheimage.Theadjustingrangeis
from0to100.(OnlyavailableforVGAinput.)
• Focus:ReduceHorizonal-linenoiseandVertical-linenoiseof
theimagebyadjusting(Phase)and(Clock)separately.The
adjustingrangeisfrom0to100.(OnlyavailableforVGAinput.)
Downloaded from www.vandenborre.be

3-4
ASUS LCD monitor VS228, VS238, VS247
4. Input Select
SelecttheinputsourcefromVGA,DVI,orHDMI.
VS247
Splendid
Color
Input Select
Move Menu Exit
System Setup
VGA
DVI
HDMI
• DVI:AvailableformodelVS228NE/HR,VS238NR/HR,
VS247NR/HR/HVonly.
• HDMI:AvailableformodelVS228HR,VS238HR,VS247HR,
VS247HVonly.
5. System Setup
Adjustthesystemconguration.
page1/2:
VS247
Splendid
Color
Input Select
Move Menu Exit
System Setup Language
Information
Splendid Demo Mode OFF
50
OFF
English
1/2
Volume
ECO Mode
OSD Setup
page2/2:
VS247
Splendid
Color
Input Select
Move Menu Exit
System Setup
All Reset
2/2
• Splendid Demo Mode:Activatethedemomodeforthe
Splendidfunction.
Downloaded from www.vandenborre.be

3-5 Chapter 3: General Instruction
• Volume:Adjusttheearphoneoutputvolumelevel.The
adjustingrangeisfrom0to100.(AvailableformodelVS228HR,
VS238HR,VS247HR,VS247HVonly)
• ECO Mode:Activatetheecologymodeforpowersaving.(Some
graylevelsmaynotbedistinguishedifECOisON.Itsbrightness
islowerthanthatwhensettingtheContrastRatioto100.)
• OSD Setup:Adjustthehorizontalpostition(H-Position),vertical
position(V-Position),OSDTimeout,DDC/CI,andTransparency
of the OSD screen.
• Language:SelectOSDlanguage.TheselectionsareEnglish,
French,German,Spanish,Italian,Dutch,Russian,Traditional
Chinese,SimplifiedChinese,andJapanese.
• Information:DisplaythemonitorinformationofInputPort,
Resolution,H-freq.,V-freq,andModelName.
• All Reset:Setto“Yes”torevertallsettingstothefactorydefault
status.
Downloaded from www.vandenborre.be

3-6
ASUS LCD monitor VS228, VS238, VS247
3.2 Specications
Model VS228DE/NE VS228DR/HR
PanelSize 21.5”W(54.6cm)
Max.Resolution 1920x1080(FHD)
BacklightTech. LEDBacklightTechnology
Brightness(Typ.) 200cd/m2250cd/m2
IntrisincContrastRatio(Typ.) 600:1 1000:1
ViewingAngle(CR=10) ≧90°(H)/≧65°(V) ≧170°(H)/≧160°(V)
DisplayColors 16.7M
ResponseTime 5 ms
EarphoneOutput No VS228DR:No
VS228HR:Yes
SoundfromHDMI No VS228DR:No
VS228HR:Yes
HDMIinput(HDMI1.3) No VS228DR:No
VS228HR:Yes
DVIinput VS228DE:No
VS228NE:Yes
VS228DR:No
VS228HR:Yes
D-Subinput Yes
PowerConsumption PowerON<21.1W*
Note *BasedonEnergyStar6.0standard
PowerSavingMode <0.5W
PowerOFFMode <0.5W
Tilt -5°~+20°
VESAWallMounting Yes(100mmx100mm)
Phys.Dimension(WxHxD) 514x386x200mm
BoxDimension(WxHxD) 566x443x130mm
NetWeight(Esti.) 3.8kg
GrossWeight(Esti.) 5.9kg
VoltageRating AC100~240V(Built-in)
Downloaded from www.vandenborre.be

3-7 Chapter 3: General Instruction
Model VS238HR VS238NR
PanelSize 23”W(58.4cm)
Max.Resolution 1920x1080(FHD)
BacklightTech. LEDBacklightTechnology
Brightness(Typ.) 250cd/m2
IntrisincContrastRatio(Typ.) 1000:1
ViewingAngle(CR=10) ≧170°(H)/≧160°(V)
DisplayColors 16.7M
ResponseTime 5 ms
EarphoneOutput Yes No
SoundfromHDMI Yes No
HDMIinput(HDMI1.3) Yes No
DVIinput Yes
D-Subinput Yes
PowerConsumption PowerON<22W*
Note *BasedonEnergyStar6.0standard
PowerSavingMode <0.5W
PowerOFFMode <0.5W
Tilt -5°~+20°
VESAWallMounting Yes(100mmx100mm)
Phys.Dimension(WxHxD) 552x400x200mm
BoxDimension(WxHxD) 608x460x130mm
NetWeight(Esti.) 3.4kg
GrossWeight(Esti.) 5.8kg
VoltageRating AC100~240V(Built-in)
Downloaded from www.vandenborre.be
