Asus CUBX User manual

®
CUBX
Socket 370 ATX Motherboard
USER’S MANUAL

2ASUS CUBX User’s Manual
USER'S NOTICE
Product Name: ASUS CUBX
Manual Revision: 1.03 E529
Release Date: March 2000
No part of this manual, including the products and software described in it, may be repro-
duced, transmitted, transcribed, stored in a retrieval system, or translated into any language in
any form or by any means, except documentation kept by the purchaser for backup purposes,
without the express written permission of ASUSTeK COMPUTER INC. (“ASUS”).
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND,
EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED
WARRANTIES OR CONDITIONS OF MERCHANTABILITYOR FITNESS FORAPAR-
TICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS,
EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDEN-
TAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF
PROFITS, LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSI-
NESS AND THE LIKE), EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY
OF SUCH DAMAGES ARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL
OR PRODUCT.
Product warranty or service will not be extended if: (1) the product is repaired, modified or
altered, unless such repair, modification of alteration is authorized in writing byASUS; or (2)
the serial number of the product is defaced or missing.
Products and corporate names appearing in this manual may or may not be registered trade-
marks or copyrights of their respective companies, and are used only for identification or
explanation and to the owners’ benefit, without intent to infringe.
• Adobe and Acrobat are registered trademarks of Adobe Systems Incorporated.
• Intel, LANDesk, and Pentium are registered trademarks of Intel Corporation.
• Trend and ChipAwayVirus are trademarks of Trend Micro, Inc.
• Windows and MS-DOS are registered trademarks of Microsoft Corporation.
• ADI and SoundMAX are trademarks of Analog Devices, Inc..
The product name and revision number are both printed on the product itself. Manual revi-
sions are released for each product design represented by the digit before and after the period
of the manual revision number. Manual updates are represented by the third digit in the manual
revision number.
For previous or updated manuals, BIOS, drivers, or product release information, contactASUS
at http://www.asus.com.tw or through any of the means indicated on the following page.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUALARE FUR-
NISHED FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT
ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A COM-
MITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY FOR
ANYERRORS ORINACCURACIESTHATMAYAPPEARINTHISMANUAL, INCLUD-
ING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Copyright © 2000 ASUSTeK COMPUTER INC. All Rights Reserved.

ASUS CUBX User’s Manual 3
ASUS CONTACT INFORMATION
ASUSTeK COMPUTER INC. (Asia-Pacific)
Marketing
Address: 150 Li-Te Road, Peitou, Taipei, Taiwan 112
Telephone: [phone]
Fax: [phone]
Email: [email protected]
Technical Support
MB/Others (Tel): [phone] (English)
Notebook (Tel): [phone] (English)
Desktop/Server (Tel):[phone] (English)
Fax: [phone]
Email: [email protected]
WWW: www.asus.com.tw
FTP: ftp.asus.com.tw/pub/ASUS
ASUS COMPUTER INTERNATIONAL (America)
Marketing
Address: 6737 Mowry Avenue, Mowry Business Center, Building 2
Newark, CA 94560, USA
Fax: [phone]
Email: [email protected]
Technical Support
Fax: [phone]
Email: [email protected]
WWW: www.asus.com
FTP: ftp.asus.com/Pub/ASUS
ASUS COMPUTER GmbH (Europe)
Marketing
Address: Harkortstr. 25, 40880 Ratingen, BRD, Germany
Fax: [phone]
Email: [email protected] (for marketing requests only)
Technical Support
Hotline: MB/Others: [phone] Notebook: [phone]
Fax: [phone]
Support (Email): www.asuscom.de/de/support (for online support)
WWW: www.asuscom.de
FTP: ftp.asuscom.de/pub/ASUSCOM

4ASUS CUBX User’s Manual
CONTENTS
1. INTRODUCTION .............................................................................. 7
1.1 How This Manual Is Organized .................................................. 7
1.2 Item Checklist ............................................................................. 7
2. FEATURES ......................................................................................... 8
2.1 The ASUS CUBX Motherboard ................................................. 8
2.1.1 Specifications .................................................................. 8
2.1.2 Special Features ............................................................. 10
2.1.3 Performance Features .................................................... 10
2.1.4 Intelligence .................................................................... 11
2.2 CUBX Motherboard Components ............................................ 12
2.2.1 Component Locations.................................................... 13
3. HARDWARE SETUP ...................................................................... 14
3.1 CUBX Motherboard Layout ..................................................... 14
3.2 Layout Contents ........................................................................ 15
3.3 Hardware Setup Procedure ....................................................... 17
3.4 Motherboard Settings................................................................ 17
3.5 System Memory (DIMM) ......................................................... 22
3.5.1 General DIMM Notes .................................................... 22
3.5.2 Memory Installation ...................................................... 23
3.6 Central Processing Unit (CPU) ................................................. 25
3.7 Expansion Cards ....................................................................... 26
3.7.1 Expansion Card Installation Procedure ......................... 26
3.7.2 Assigning IRQs for Expansion Cards............................ 27
3.7.3 Accelerated Graphics Port (AGP) ................................. 29
3.8 Connectors ................................................................................ 30
3.9 Starting Up the First Time ........................................................ 41
4. BIOS SETUP.................................................................................... 42
4.1 Managing and Updating Your BIOS......................................... 42
4.1.1 Upon First Use of the Computer System....................... 42
4.1.2 Updating BIOS Procedures (only when necessary) ...... 43
4.2 BIOS Setup Program ................................................................ 45
4.2.1 BIOS Menu Bar ............................................................. 46
4.2.2 Legend Bar .................................................................... 46
4.3 Main Menu................................................................................ 48
4.3.1 Primary & Secondary Master/Slave .............................. 49
4.3.2 Keyboard Features ......................................................... 52

ASUS CUBX User’s Manual 5
CONTENTS
4.4 Advanced Menu ........................................................................ 54
4.4.1 Chip Configuration ........................................................ 58
4.4.2 I/O Device Configuration .............................................. 60
4.4.3 PCI Configuration ......................................................... 62
4.4.4 Shadow Configuration ................................................... 65
4.5 Power Menu .............................................................................. 66
4.5.1 Power Up Control.......................................................... 68
4.5.2 Hardware Monitor ......................................................... 70
4.6 Boot Menu ................................................................................ 71
4.7 Exit Menu ................................................................................. 73
5. SOFTWARE SETUP....................................................................... 75
5.1 Install Operating System........................................................... 75
5.2 Start Windows........................................................................... 75
5.3 BX Series Motherboard Support CD ........................................ 76
5.4 Intel LDCM Administrator Setup ............................................. 79
5.5 Intel LDCM Client Setup.......................................................... 81
5.6 ASUS BIOS Flash Utility for LDCM ....................................... 82
5.7 Install ASUS PC Probe Vx.xx .................................................. 83
5.8 Install ASUS Update Vx.xx ...................................................... 84
5.9 Install PC-Cillin 98 Vx.xx ........................................................ 85
5.10 Install Adobe Acrobat Reader Vx.x .......................................... 86
5.11 Uninstalling Programs .............................................................. 87
6. SOFTWARE REFERENCE ........................................................... 89
6.1 ASUS PC Probe ........................................................................ 89
6.2 ASUS Update............................................................................ 94
7. APPENDIX........................................................................................ 95
7.1 PCI-L101 Fast Ethernet Card ................................................... 95
7.2 ASUS CIDB Intrusion Detection Module ................................ 97
7.3 Glossary .................................................................................... 99
INDEX ................................................................................................. 103

6ASUS CUBX User’s Manual
FCC & DOC COMPLIANCE
FederalCommunications Commission Statement
This device complies with FCC Rules Part 15. Operation is subject to the following
two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received, including interference that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installa-
tion. This equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with manufacturer's instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interfer-
ence by one or more of the following measures:
• Re-orient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
WARNING! Any changes or modifications to this product not expressly ap-
proved by the manufacturer could void any assurances of safety or performance
and could result in violation of Part 15 of the FCC Rules.
Reprinted from the Code of Federal Regulations #47, part 15.193, 1993. Washington DC: Office of the
Federal Register, National Archives and Records Administration, U.S. Government Printing Office.
CanadianDepartment of CommunicationsStatement
This digital apparatus does not exceed the Class B limits for radio noise emissions
from digital apparatus set out in the Radio Interference Regulations of the Canadian
Department of Communications.
This Class B digital apparatus complies with Canadian ICES-003.
CetappareilnumériquedelaclasseBestconformeàlanormeNMB-003duCanada.

ASUS CUBX User’s Manual 7
1. INTRODUCTION
1. INTRODUCTION
Manual / Checklist
1.1 How This Manual Is Organized
This manual is divided into the following sections:
1. INTRODUCTION Manual information and checklist
2. FEATURES Production information and specifications
3. HARDWARE SETUP Intructions on setting up the motherboard.
4. BIOS SETUP Intructions on setting up the BIOS
5. SOFTWARE SETUP Intructions on setting up the included software
6. SOFTWARE REFERENCE Reference material for the included software
7. APPENDIX Optional items and general reference
1.2 Item Checklist
Please check that your package is complete. If you discover damaged or missing
items, please contact your retailer.
Package Contents
(1) ASUS Motherboard
(1) 40-pin 80-conductor ribbon
cable for internal UltraDMA/66
or UltraDMA/33 IDE drives
(1) Ribbon cable for internal
UltraDMA/33 IDE drives
(1) Ribbon cable for one 5.25”and
two 3.5”floppy disk drives
(1) ASUS 3-port USB connector set
with bracket
(1) Bag of spare jumper caps
(1) ASUS Support CD with
drivers and utilities
(1) This Motherboard User’s
Manual
Optional Items
ASUS CIDB chassis intrusion de-
tection module
ASUS IrDA-compliant infrared
module
ASUS PCI-L101 Wake-On-LAN
10/100 Ethernet Card

8ASUS CUBX User’s Manual
2.1 The ASUS CUBX Motherboard
The ASUS CUBX is carefully designed for the demanding PC user who wants ad-
vanced features processed by the fastest CPU.
2.1.1 Specifications
•Latest Intel Processor Support
Intel Pentium
®
III 100MHz FSB Coppermine core FC-PGA
Intel Celeron™66MHz FSB Mendocino PPGA
•Intel AGPset: Features Intel’s 440BX AGPset with I/O subsystems and front-side
bus(FSB)platform,whichbooststhetraditional66MHzexternalbusspeedto100MHz.
•JumperFree™Mode:Allows processor settings and easy overclocking of fre-
quency and Vcore voltage all through BIOS setup when JumperFree™mode is
enabled. Easy-to-use DIP switches instead of jumpers are included to allow
manual adjustment of the processor’s external frequency.
•Anti-Boot Virus BIOS: Features a programmable BIOS, offering enhanced
Advanced ConfigurationPower Interface (ACPI) support forWindows 98 com-
patibility, built-infirmware-basedvirusprotection throughTrend ChipAwayVirus
codes, and autodetection of most devices for virtually automatic setup.
•PC100 Memory Support: Equipped with four DIMM sockets to support Intel
PC100-compliant SDRAMs (8, 16, 32, 64, 128, or 256MB) up to 1 GB. These
new SDRAMs are necessary to meet the critical enhanced 100MHz bus speed
requirement.
•Peripheral Wake Up: Supports modem, PS/2 keyboard, PS/2 mouse, and LAN
card wake up functions from sleep or soft-off mode.
•PC Health Monitoring: Provides an easier way to examine and manage system
status information, such as CPU and system voltages, temperatures, and fan
status through the onboard hardware ASIC and the bundled LDCM by Intel or
PC Probe from ASUS.
•AGP Slot: Supports an Accelerated Graphics Port card for high performance,
component level interconnect targeted at 3D graphical display applications us-
ing a 1X or 2X mode bus.
•PCI/ISAExpansionSlots:Providesoptionsofsix32-bitPCI (rev 2.2) expansion
slots with one ISA or six PCI with no ISA, depending on territory. PCI supports
up to 133MB/s maximum throughput.
•Multi-I/O:Providestwohigh-speedUARTcompatibleserialportsandoneparal-
lel port with EPP and ECP capabilities.
2. FEATURES
Specifications
2. FEATURES

ASUS CUBX User’s Manual 9
2. FEATURES
2. FEATURES
Specifications
•UltraDMA/66 & UltraDMA/33 Bus Master IDE: Comes with an onboard
CMD UltraDMA/66 IDE controller with two connectors that support four
UltraDMA/66IDEdevicesintwochannels.SupportsUltraDMA/66,UltraDMA/
33, PIO Modes 3 and 4, and Bus Master IDE DMA Mode 2, as well as Enhanced
IDE devices, such as Tape Backup, CD-ROM, CD-R/RW, and LS-120 drives.
Two additional IDE connectors are onboard that support four UltraDMA/33 IDE
devices. A total of 8 IDE devices can be connected.
•Wake-On-LAN Connector: Supports Wake-On-LAN activity through an op-
tionalASUS PCI-L101 10/100 Fast Ethernet PCI card (see 7.1 PCI-L101 LAN
Card) or a similar ethernet card.
•Suspend and Go: Suspend-to-RAM (STR) provides maximum power savings
as an alternative to leaving the computer ON and QuickStart™so that you do
not have to wait for a long time for system bootup (see Suspend-to-RAM Ca-
pability in 4.5 Power Menu for more information).

10 ASUS CUBX User’s Manual
2.1.2 Special Features
•ACPI Ready: Advanced Configuration Power Interface (ACPI) provides more
Energy Saving Features for operating systems that support OS Direct Power
Management (OSPM) functionality. With these features implemented in the OS,
PCs can be ready around the clock, yet satisfy all the energy saving standards.
To fully utilize the benefits of ACPI, an ACPI-supported OS such as Windows
98 must be used.
•Easy Installation: Incorporates BIOS that supports autodetection of hard disk
drives, PS/2 mouse, and Plug and Play devices to make the setup of hard disk
drives, expansion cards, and other devices virtually automatic.
•NewCompliancy:Both the BIOS and hardware levels of this motherboard meet
the stringent requirements for PC’99 certification. The new PC’99 requirements
for systems and components are based on the following high-level goals: Sup-
port for Plug and Play compatibility and power management for configuring
and managing all system components, and 32-bit device drivers and installation
proceduresforWindows 95/98/NT. Color-codedconnectorsanddescriptive icons
make identification easy as required by PC’99.
•Symbios SCSI BIOS: Supports optional ASUS SCSI controller cards through
the onboard SYMBIOS firmware.
2.1.3 Performance Features
•Concurrent PCI: Concurrent PCI allows multiple PCI transfers from PCI mas-
ter busses to the memory and processor.
•High-Speed Data Transfer Interface: IDE transfers using UltraDMA/33 Bus
Master IDE can handle rates up to 33MB/s. This motherboard with a CMD
UltraDMA/66 IDE controller and support for UltraDMA/66 doubles the
UltraDMA/33 burst transfer rate to 66.6MB/s. UltraDMA/66 is backward com-
patible with both DMA/33 and DMA and with existing DMA devices and sys-
tems so there is no need to upgrade current EIDE/IDE drives and host systems.
(UltraDMA/66 requires a 40-pin 80-conductor cable to be enabled and/or for
UltraDMA Mode 4.)
•SDRAMOptimizedPerformance:Supportsthenewgenerationmemory-Syn-
chronous Dynamic RandomAccess Memory (SDRAM) which increases the data
transfer rate to 800MB/s max using PC100-compliant SDRAM.
2. FEATURES
Specifications
2. FEATURES

ASUS CUBX User’s Manual 11
2.1.4 Intelligence
•Dual Function Power Button: Pushing the power button for less than 4 sec-
onds when the system is in the working state places the system into one of two
states: sleep mode or soft-off mode, depending on the BIOS or OS setting (see
PWR Button < 4 Secs in 4.5 Power Menu). When the power button is pressed
for more than 4 seconds, the system enters the soft-off mode regardless of the
BIOS setting.
•Fan Status Monitoring and Alarm: To prevent system overheat and system
damage, the CPU, power supply, and system fans can be monitored for RPM
and failure. All fans are set for its normal RPM range and alarm thresholds.
•Message LED (requiresACPI OS support):Turbo LEDs now act as informa-
tion providers. Through the way a particular LED illuminates, the user can de-
termine if a message has been received from a fax/modem. A simple glimpse
provides useful information to the user.
•Remote Ring On (requires modem): This allows a computer with this mother-
board to be turned on remotely through an internal or external modem. With this
feature, users can access their computers from anywhere in the world!
•System Resources Alert: Today’s operating systems such as Windows 95/98/
NT and OS/2, require much more memory and hard drive space to present enor-
mous user interfaces and run large applications. The system resource monitor
will warn the user before the system resources are used up to prevent possible
application crashes. Suggestions will give the user information on managing
their limited resources more efficiently.
•Voltage Monitoring andAlert: System voltage levels are monitored to ensure
stable voltage to critical motherboard components. Voltage specifications are
more critical for future processors, so monitoring is necessary to ensure proper
system configuration and management.
2. FEATURES
2. FEATURES
Specifications

12 ASUS CUBX User’s Manual
2.2 CUBX Motherboard Components
See opposite page for locations.
2. FEATURES
MB Components
2. FEATURES
Location
Processor Support Socket 370 for Pentium III/Celeron Processors ....................... 1
Feature Setting DIP Switches ................................................... 8
100/66MHz system bus (Frequency Multiples 2.0-8.0)
Chipsets Intel 440BX AGPset ................................................................. 3
Multi-I/O Chipset ................................................................... 16
Main Memory Maximum 1GB Supported
4 DIMM Sockets ...................................................................... 4
PC100/66 SDRAM Supported
Expansion Slots 6 PCI Slots.............................................................................. 17
1 ISA Slot ............................................................................... 12
1 Accelerated Graphics Port ................................................... 18
System I/O 4 IDE Connectors ..................................................................... 5
CMD ATA/66 IDE Controller ................................................ 19
2 USB Headers ......................................................................... 6
1 Floppy Disk Drive Connector ............................................... 9
Intel PIIX4E PCIset ................................................................ 10
1 Parallel Port Connector ....................................................... 21
2 Serial Port Connectors ................................................... 20, 22
2 USB Connectors .................................................................. 23
1 PS/2 Mouse Connector .............................................. (Top) 24
1 PS/2 Keyboard Connector ................................... (Bottom) 24
BIOS AWARD BIOS, Programmable Flash 4Mbit EEPROM ........ 14
Supports Plug & Play, DMI, and Write Protection
Network Features Wake-On-LAN Connector...................................................... 15
Wake-On-Ring Connector ...................................................... 13
Hardware Monitoring System Voltage Monitoring (integrated in ASUS ASIC) ......... 7
3 Fan Power and Speed Monitoring Connectors
Power ATX Power Supply Connector ................................................. 2
Special Features Onboard Power LED .............................................................. 11
Form Factor ATX

ASUS CUBX User’s Manual 13
2. FEATURES
2. FEATURES
Component Locations
2.2.1 Component Locations
1234 5
610 7912
14
13
15
16
17
18
8
19
20
21
22
23
24
11

14 ASUS CUBX User’s Manual
3. HARDWARE SETUP
3.1 CUBX Motherboard Layout
Motherboard Layout
3. H/W SETUP
(Grayed components are optional at the time of purchase.)
COM1
PARALLEL PORT
COM2
PS/2KBMS
T: Mouse
B: Keyboard
Intel
440BX
AGPset
SMB
PCI1
PCI2
PCI4
PCI3
PANEL
IDELED
FLOPPY
SECONDARYIDE
PRIMARYIDE
ATXPWR
Intel
PIIX4E
PCIset
PCI5
USB
T: Port1
B: Port 2
CUBX
CHA_FAN
Row
ISA1
PWR_FAN
CMD
ATA/66
IDE
Controller
DIP
Switches
®
LED1
IR
VIO
Accelerated Graphics Port
ASUS
ASIC
with
Hardware
Monitor
CR2032 3V
Lithium Cell
CMOS Power
DIMM1 (64/72 bit, 168-pin module)
1
0
DIMM2 (64/72 bit, 168-pin module)
3
2
DIMM3 (64/72 bit, 168-pin module)
5
4
DIMM4 (64/72 bit, 168-pin module)
7
6
21.8 cm (8.6 in)
30.5 cm (12.0 in)
CLRTC
JTPWR
DSW
JEN
USB2
Socket 370
CHASIS
CPU_FAN
WOR
WOL_CON
Multi-I/O
2Mb Flash EEPROM (Programable BIOS)
PCI6
FOURTH IDE
THIRD IDE
USB3A

ASUS CUBX User’s Manual 15
3. HARDWARE SETUP
3.2 Layout Contents
Motherboard Settings
1) JEN p. 18 JumperFree Mode Setting (Disable/Enable)
2) VIO p. 18 I/O Voltage Setting (3.4V/3.6V)
3) DSW 6 p. 20 AGP Bus Frequency Setting
4) DSW 5–10 p. 20 CPU External Frequency Selection
5) DSW 1-4 p. 21 CPU Core:BUS Frequency Multiple Selection
Expansion Slots/Sockets
1) System Memory p.22 System Memory Support
2) DIMM1/2/3/4 p.22 DIMM Memory Module Support
3) Socket 370 p.25 CPU Support
4) PCI1/2/3/4/5/6 p.27 32-bit PCI Bus Expansion Slots
5) ISA1 p.27 16-bit ISA Bus Expansion Slots (optional)
6) AGP p.29 Accelerated Graphics Port
Connectors
1) PS2KBMS p.30 PS/2 Mouse Port Connector (6 pin-female)
2) PS2KBMS p.30 PS/2 Keyboard Port Connector (6-pin female)
3) USB p.31 Universal Serial Bus Connectors 1 & 2 (Two 4-pin female)
4) PRINTER p.31 Parallel Port Connector (25-pin female)
5) COM1/COM2 p.31 Serial Port Connector (Two 9-pin male)
8) CHASSIS p.32 Chassis Intrusion Lead (4-1 pins)
9) PRIMARY IDE p.33 IDE Connectors (Four 40-1 pins)
SECONDARY IDE
THIRD IDE
FOURTH IDE
10) FLOPPY p. 33 Floppy Disk Drive Port Connector (34 pins)
11) WOL_CON p. 34 Wake-On-LAN Connector (3 pins)
12) WOR p. 34 Wake-On-Ring Connector (2 pins)
13) IDELED p. 35 IDE Activity LED (2 pins)
14) PWR_, CPU_,CHA_FAN p. 35 Chassis, Power Supply, CPU Fan Connectors (3 pins)
15) IR p. 36 Infrared Module Connector (5 pins)
16) USB2, USB3A p. 36 USB Headers (10-1 pins and 5-1 pins)
17) SMB p. 37 SMBus Connector (5-1 pins)
18)
PWR.LED ( PANEL ) p. 38 System Power LED Lead (3 pins)
19)
KEYLOCK ( PANEL ) p. 38 Keyboard Lock Switch Lead (2 pins)
20) SPEAKER (PANEL) p. 38 System Warning Speaker Connector (4 pins)
21) MSG.LED (PANEL) p. 38 System Message LED (2 pins)
Layout Contents
3. H/W SETUP

16 ASUS CUBX User’s Manual
3. HARDWARE SETUP
Layout Contents
3. H/W SETUP
22) SMI (PANEL) p. 38 System Management Interrupt Lead (2 pins)
23) PWR.SW (PANEL) p. 38 ATX / Soft-Off Switch Lead (2 pins)
24) RESET (PANEL) p. 38 Reset Switch Lead (2 pins)
25) ATXPWR p. 39 ATX Power Supply Connector (20 pins)
26) JTPWR p. 39 Power Supply Thermal Sensor Connector (2 pins)

ASUS CUBX User’s Manual 17
3. HARDWARE SETUP
3.3 Hardware Setup Procedure
Before using your computer, you must complete the following steps:
1. Check Motherboard Settings
2. Install Memory Modules
3. Install the Central Processing Unit (CPU)
4. Install Expansion Cards
5. Connect Ribbon Cables, Panel Wires, and Power Supply
6. Setup the BIOS Software
3.4 Motherboard Settings
This section explains in detail how to change your motherboard’s function settings
through the use of switches and/or jumpers.
WARNING! Computer motherboards and expansion cards contain very delicate
Integrated Circuit (IC) chips.To protect them against damage from static electric-
ity, you should follow some precautions whenever you work on your computer.
1. Unplug your computer when working on the inside.
2. Use a grounded wrist strap before handling computer components. If you
do not have one, touch both of your hands to a safely grounded object or to
a metal object, such as the power supply case.
3. Hold components by the edges and try not to touch the IC chips, leads or
connectors, or other components.
4. Place components on a grounded antistatic pad or on the bag that came with
the component whenever the components are separated from the system.
CUBX
®
ON OFF
Standby
Power Powered
Off
CUBX Onboard LED
WARNING! Make sure that you unplug your power supply when adding or
removing system components. Failure to do so may cause severe damage to
your motherboard, peripherals, and/or components. The onboard LED when lit
acts as a reminder that the system is in suspend or soft-off mode and not powered
OFF.

18 ASUS CUBX User’s Manual
3. HARDWARE SETUP
Motherboard Features Settings (DIP Switches - DSW)
The motherboard’s onboard functions are adjusted through the DIP switches. The
white block represents the switch’s position. The example below shows all the
switches in the OFF position.
3. H/W SETUP
Motherboard Settings
1. Frequency Multiple
2. Frequency Multiple
3. Frequency Multiple
4. Frequency Multiple
5. (Reserved)
6. AGP Frequency Selection
7. Frequency Selection
8. Frequency Selection
9. Frequency Selection
10. Frequency Selection
CUBX DIP Switches OFF
ON
12345678910
ON
DSW
CUBX
®
1) JumperFree™Mode (JEN)
This jumper allows you to enable or disable the JumperFree™mode. The
JumperFree™mode allows processor settings to be made through the BIOS
setup (see 4.4 Advanced Menu).
Setting JEN
Enable (JumperFree) [2-3] (default)
Disable (Jumper) [1-2]
CUBX
®
CUBX Jumper Mode Setting
Jumper JumperFree
12 23
JEN
OFF
ON
12345678910
DSW
NOTE: In JumperFree™mode, all dip switches (DSW) must be set to OFF.

ASUS CUBX User’s Manual 19
3. HARDWARE SETUP
3. H/W SETUP
Motherboard Settings
2) Voltage I/O Setting (VIO)
This jumper allows you to select the voltage supplied to the DRAM, chipset,
AGP, and PCI. The default setting of 3.45Volt should be used unless processor
overclocking requires a higher voltage (3.60Volt).
Setting VIO
3.45Volt [1-2] (default)
3.60Volt [2-3]
CUBX
®
CUBX Input/Output Voltage Setting
VIO
3.45 Volt
(Default)
12
3.60 Volt
23
WARNING! Using a higher voltage may help when overclocking but may result
in the shortening of your computer component’s life. It is highly recommended
that you leave this setting on its default.
3) AGP Bus Frequency Setting (DSW Switch 6)
Thisoptionsetsthefrequency ratiobetweentheAGPbus frequency and the DRAM
(CPU bus) frequency. The default sets the AGP bus frequency to be 2/3 of the
DRAM frequency. When the CPU/DRAM frequency is set to 66MHz, set this
switch to [ON]. See the processor table on the next page.
Setting DSW Switch 6
DRAM Freq. x 2/3 [OFF] (default)
DRAM Freq. x 1 [ON]
CUBX AGP Bus Frequency Setting
DRAM Freq. x2/3DRAM Freq. x1
ON
12345678910
ON
12345678910
CUBX
®

20 ASUS CUBX User’s Manual
4) CPU External Frequency Selection (DSW Switches 7-10)
This option tells the clock generator what frequency to send to the CPU, DRAM, and
the PCI bus.Thisallowstheselectionofthe CPU’sExternal frequency(orBUSClock).
The BUS Clock multiplied by the Frequency Multiple equals the CPU’s Internal fre-
quency (the advertised CPU speed).
CUBX CPU External
Frequency Selection
CPU/DRAM
PCI BUS →
→
CPU/DRAM
PCI BUS →
→
CPU/DRAM
PCI BUS →
→
CPU/DRAM
PCI BUS →
→
CPU/DRAM
PCI BUS →
→
100.0MHz
33.4MHz
ON
12345678910
133.0MHz
44.3MHz
ON
12345678910
112.0MHz
37.3MHz
ON
12345678910
103.0MHz
34.3MHz
ON
12345678910
133.0MHz
33.3MHz
ON
12345678910
124.0MHz
41.3MHz
ON
12345678910
124.0MHz
31.0MHz
ON
12345678910
150.0MHz
37.5MHz
ON
12345678910
140.0MHz
35.0MHz
ON
12345678910
105.0MHz
35.0MHz
ON
12345678910
110.0MHz
36.7MHz
ON
12345678910 115.0MHz
38.3MHz
ON
12345678910
120.0MHz
40.0MHz
ON
12345678910
CUBX
®
CPU/DRAM
PCI BUS →
→66.0MHz
33.4MHz
ON
12345678910 83.0MHz
41.6MHz
ON
12345678910
75.0MHz
37.5MHz
ON
12345678910
NOTE: Overclocking your processor is not recommended. It may result in a slower
speed.
3. HARDWARE SETUP
