Asus P2V-B User manual

R
P2V-B
Pentium®III / II / CeleronTM Motherboard
USER’S MANUAL

ASUS P2V-B User’s Manual
2
USER'S NOTICE
Product Name: ASUS P2V-B
Manual Revision: 1.02 E353
Release Date: March 1999
No part of this manual, including the products and software described in it, may be repro-
duced, transmitted, transcribed, stored in a retrieval system, or translated into any language
in any form or by any means, except documentation kept by the purchaser for backup pur-
poses, without the express written permission of ASUSTeK COMPUTER INC. (“ASUS”).
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND,
EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOTLIMITED TOTHE IMPLIED
WARRANTIES OR CONDITIONS OF MERCHANTABILITY OR FITNESS FORAPAR-
TICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS,
EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDEN-
TAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF
PROFITS, LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSI-
NESS AND THE LIKE), EVEN IF ASUS HAS BEENADVISED OF THE POSSIBILITY
OF SUCH DAMAGESARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL
OR PRODUCT.
Product warranty or service will not be extended if: (1) the product is repaired, modified or
altered, unless such repair, modification of alteration is authorized in writing by ASUS; or
(2) the serial number of the product is defaced or missing.
Products and corporate names appearing in this manual may or may not be registered trade-
marks or copyrights of their respective companies, and are used only for identification or
explanation and to the owners’ benefit, without intent to infringe.
• VIAandApollo Pro Plus are trademarks of VIA Technologies, Inc.
• Intel, LANDesk, and Pentium are registered trademarks of Intel Corporation.
• IBM and OS/2 are registered trademarks of International Business Machines.
• Symbios is a registered trademark of Symbios Logic Corporation.
• Windows and MS-DOS are registered trademarks of Microsoft Corporation.
• Sound Blaster AWE32 and SB16 are trademarks of Creative Technology Ltd.
• Adobe and Acrobat are registered trademarks of Adobe Systems Incorporated.
The product name and revision number are both printed on the product itself. Manual revi-
sions are released for each product design represented by the digit before and after the period
of the manual revision number. Manual updates are represented by the third digit in the
manual revision number.
For previous or updated manuals, BIOS, drivers, or product release information, contactASUS
at http://www.asus.com.tw or through any of the means indicated on the following page.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUALARE FUR-
NISHED FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT
ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A COM-
MITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY FOR
ANYERRORSORINACCURACIESTHATMAYAPPEARINTHISMANUAL,INCLUD-
ING THE PRODUCTSAND SOFTWARE DESCRIBED IN IT.
Copyright © 1999 ASUSTeK COMPUTER INC. All Rights Reserved.

ASUS P2V-B User’s Manual 3
ASUS CONTACT INFORMATION
ASUSTeK COMPUTER INC. (Asia-Pacific)
Marketing
Address: 150 Li-Te Road, Peitou, Taipei, Taiwan 112
Telephone: [phone]
Fax: [phone]
Email: [email protected]
Technical Support
Tel (English): [phone] ext. 706
Tel (Chinese): [phone] ext. 701
Fax: [phone]
Email: [email protected]
Newsgroup: news2.asus.com.tw
WWW: www.asus.com.tw
FTP: ftp.asus.com.tw/pub/ASUS
ASUS COMPUTER INTERNATIONAL (America)
Marketing
Address: 6737 Mowry Avenue, Mowry Business Center, Building 2
Newark, CA 94560, USA
Fax: [phone]
Email: [email protected]
Technical Support
Fax: [phone]
BBS: [phone]
Email: [email protected]
WWW: www.asus.com
FTP: ftp.asus.com.tw/pub/ASUS
ASUS COMPUTER GmbH (Europe)
Marketing
Address: Harkort Str. 25, 40880 Ratingen, BRD, Germany
Telephone: [phone]
Fax: [phone]
Email: [email protected]
Technical Support
Hotline: [phone]
BBS: 49-2102-448690
Email: [email protected]
WWW: www.asuscom.de
FTP: ftp.asuscom.de/pub/ASUSCOM

ASUS P2V-B User’s Manual
4
CONTENTS
I. INTRODUCTION 7
How this Manual is Organized ........................................................... 7
Item Checklist ..................................................................................... 7
II. FEATURES 8
Features of the ASUS P2V-B Motherboard ........................................ 8
The ASUS P2V-B Motherboard .................................................. 11
III. HARDWARE SETUP 12
Layout of the ASUS P2V-B Motherboard ........................................ 12
Installation Steps............................................................................... 14
1. Motherboard Settings.................................................................... 14
SPD Support .......................................................................... 18
2. System Memory (DIMM) ............................................................. 18
DIMM Memory Installation Procedures: .............................. 19
3. Central Processing Unit (CPU).................................................... 21
Universal Retention Mechanism ........................................... 21
Heatsinks ............................................................................... 21
Installing the Processor ............................................................... 22
ASUS Smart Thermal Solutions............................................ 24
Recommended Heatsinks for Slot 1 Processors .................... 25
4. Expansion Cards ........................................................................... 26
Expansion Card Installation Procedure ................................. 26
Assigning IRQs for Expansion Cards.................................... 26
Assigning DMA Channels for ISA Cards.............................. 27
ISA Cards and Hardware Monitor ......................................... 27
Accelerated Graphics Port (AGP) ......................................... 27
5. External Connectors..................................................................... 28
Power Connection Procedures .......................................................... 37
Flash Memory Writer Utility ............................................................ 38
IV. BIOS SETUP 38
Main Menu .................................................................................. 38
Managing and Updating Your Motherboard’s BIOS................... 40
6. BIOS Setup .................................................................................. 41
Load Defaults ........................................................................ 42
Standard CMOS Setup ................................................................ 42
Details of Standard CMOS Setup:......................................... 42
BIOS Features Setup ................................................................... 45
Details of BIOS Features Setup............................................. 45

ASUS P2V-B User’s Manual 5
CONTENTS
Chipset Features Setup ................................................................ 48
Details of Chipset Features Setup.......................................... 48
Power Management Setup........................................................... 51
Details of Power Management Setup .................................... 51
PNP and PCI Setup ..................................................................... 54
Details of PNP and PCI Setup ............................................... 54
Load BIOS Defaults .................................................................... 56
Load Setup Defaults .................................................................... 56
Supervisor Password and User Password ................................... 57
IDE HDD Auto Detection ........................................................... 58
Save & Exit Setup ....................................................................... 60
Exit Without Saving .................................................................... 60
V. SOFTWARE SETUP 63
Operating Systems ............................................................................ 63
Windows 98 First Time Installation ............................................ 63
P2V-B Support CD ........................................................................... 64
Installation Menu ........................................................................ 64
LDCM Local Setup........................................................................... 65
LDCM Administrator Setup.............................................................. 67
ASUS PC Probe Setup ...................................................................... 68
Adobe Acrobat Reader...................................................................... 69
Bus Master ........................................................................................ 70
Install Chipset patch and VGARTD Driver ...................................... 71
Instal PC-Cillin ................................................................................. 72
Uninstalling Programs ...................................................................... 73
VI. SOFTWARE REFERENCE 75
Intel LANDesk Client Manager........................................................ 75
ASUS PC Probe ................................................................................ 81
Desktop Management Interface (DMI)............................................. 84
VII. APPENDIX 87
ASUS CIDB Chassis Intrusion Sensor Module................................ 87
ASUS S370 CPU Card ..................................................................... 89
ASUS PCI-L101 Fast Ethernet Card ................................................ 91
Glossary ............................................................................................ 93

ASUS P2V-B User’s Manual
6
FCC & DOC COMPLIANCE
FederalCommunicationsCommission Statement
This device complies with FCC Rules Part 15. Operation is subject to the following
two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received, including interference that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installa-
tion. This equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with manufacturer's instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the inter-
ference by one or more of the following measures:
• Re-orient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
WARNING! The use of shielded cables for connection of the monitor to the
graphics card is required to assure compliance with FCC regulations. Changes
or modifications to this unit not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for radio noise emissions
from digital apparatus set out in the Radio Interference Regulations of the Cana-
dian Department of Communications.

ASUS P2V-B User’s Manual 7
I. INTRODUCTION
I. INTRODUCTION
Manual / Checklist
How this Manual is Organized
This manual is divided into the following sections:
I. Introduction Manual information and checklist
II. Features Information and specifications concerning this product
III. Installation Instructions on setting up the motherboard and jumpers
IV. BIOS Setup Instructions on setting up the BIOS software
V. Software Setup Information on the included support software
VI. Software Reference Reference materials for the included support software
VII. Appendix Optional items and general reference
Item Checklist
Check that your package is complete. If you discover damaged or missing items,
contact your retailer.
(1) ASUS Motherboard
(1) Universal Retention Mechanism for SECC/SECC2/SEPP
(1) Ribbon cable for master and slave IDE drives
(1) Ribbon cable for (1) 5.25” and (2) 3.5” floppy disk drives
(2) Serial cable connector set
(1) Parallel+PS/2 mouse connector set
(1) Bag of spare jumper caps
(1) Support CD with drivers and utilities
(1) This Motherboard User’s manual
ASUS IrDA-compliant module (optional)
ASUS USB/MIR module (optional)
ASUS CIDB chassis sensor module (optional)
ASUS S370 CPU card (optional)
ASUS PCI-L101 Wake-On-LAN 10/100 ethernet card (optional)

8ASUS P2V-B User’s Manual
Features of the ASUS P2V-B Motherboard
The ASUS P2V-B is carefully designed for the demanding PC user who wants ad-
vanced features processed by the fastest CPU.
Specifications
•Multi-Speed: Supports Intel Pentium
®
III (450MHz and faster), Pentium
®
II
(233MHz to 450MHz) and Celeron
TM
(266MHz and faster) processors.
•VIA AGPset: Features the VIA Apollo Pro Plus (VT82C693) AGPset with I/O
subsystems and front-side bus (FSB) platform, which boosts the traditional 66-MHz
external bus speed to 100MHz.
•Multi-Cache: Supports processors with Pipelined Burst Level 2 cache.
•PC100 Memory Support: Equipped with three DIMM sockets to support Intel
PC100-compliant SDRAMs (8, 16, 32, 64, 128, or 256MB) up to 768MB. These
new SDRAMs are necessary to meet the critical enhanced PC100-compliant
100MHz bus speed requirement.
•Peripheral Wake Up: Supports modem wake up, keyboard wake up, and LAN
card wake up functions from sleep or soft-off mode.
•Chassis Intrusion Detection: Supports chassis-intrusion monitoring through the op-
tionalASUS CIDB (see APPENDIX) and Intel LANDesk Client Manager (LDCM).
•PC Health Monitoring: Provides an easier way to examine and manage sys-
tem status information such as system voltage, temperature, and fan status
through the optional onboard hardware monitoring ASIC and Intel LDCM or
ASUS PC Probe.
•AGPSlot: Supports 1X or 2X modeAGP graphics cards for high performance,
component level interconnect targeted at 3D graphical display applications.
•SMBus:Features the System Management Bus interface, which is used to physi-
cally transport commands and information between SMBus devices.
•PCI & ISA Expansion Slots: Provides three 32-bit PCI and two 16-bit ISA
slots. One ISA slot is shared with a PCI slot.
•Super Multi-I/O: Provides two high-speed UART compatible serial ports and
one parallel port with EPP and ECP capabilities. UART2 can also be directed
from COM2 to the Infrared Module for wireless connections.
•Ultra DMA/33 Bus Master IDE: Comes with an onboard PCI Bus Master IDE
controller with two connectors that support four IDE devices in two channels,
supports UltraDMA/33, PIO Modes 3 and 4 and Bus Master IDE DMA Mode 2,
and supports Enhanced IDE devices, such as Tape Backup, CD-ROM, CD-R,
CD-RW, and LS-120 drives.
•Universal Retention Mechanism: Supports a Pentium
®
III / II processor pack-
aged in a Single Edge Contact Cartridge (SECC2/SECC) or a Celeron
TM
proces-
sor packaged in a Single Edge Processor Package (SEPP).
•Wake-On-LAN Connector: Supports Wake-On-LAN activity through an op-
tional ASUS PCI-L101 10/100 Fast Ethernet PCI card (see APPENDIX) or a
similar ethernet card.
II. FEATURES
Specifications
II. FEATURES

ASUS P2V-B User’s Manual 9
Special Features
•EnhancedACPI andAnti-BootVirus BIOS: Features a programmable BIOS,
offering enhancedACPI for Windows 98 compatibility, built-in firmware-based
virus protection throughTrend ChipAway Virus codes, and autodetection of most
devices for virtually automatic setup.
• Desktop Management Interface (DMI): Supports DMI through BIOS, which
allows hardware to communicate within a standard protocol creating a higher
level of compatibility. (Requires DMI-enabled components.) (see SOFTWARE
REFERENCE.)
• Easy Installation: Incorporates BIOS that supports autodetection of hard disk
drives, PS/2 mouse, and Plug and Play devices to make the setup of hard disk
drives, expansion cards, and other devices virtually automatic.
• PC’98 Compliant: Both the BIOS and hardware levels ofASUS smart series of
motherboards meet PC’98 compliancy. The new PC’98 requirements for sys-
tems and components are based on the following high-level goals: Support for
Plug and Play compatibility and power management for configuring and man-
aging all system components, and 32-bit device drivers and installation proce-
dures for Windows 95/98/NT.
•Symbios SCSI BIOS: Supports optional ASUS SCSI controller cards or other
Symbios SCSI cards through the onboard SYMBIOS firmware.
Performance Features
•ConcurrentPCI:ConcurrentPC Iallowsmultiple PCItransfersfrom PCImaster
busses to the memory and processor.
• Double the IDE Transfer Speed: ASUS smart series motherboards with Intel
chipsets improve IDE transfer rates using Bus Master UltraDMA/33 IDE which
can handle data transfer up to 33MB/s. The best of all is that this new technol-
ogy is compatible with existingATA-2 IDE specs so there is no need to upgrade
current hard drives or cables.
• SDRAMOptimized Performance: Supports the new generation memory, Syn-
chronous Dynamic Random Access Memory (SDRAM), which increases the
data transfer rate to 800MB/s max using PC100-compliant SDRAM.
II. FEATURES
II. FEATURES
Specifications

10 ASUS P2V-B User’s Manual
II. FEATURES
Specifications
II. FEATURES
Intelligent Features (some features require the optional hardware/thermal monitor)
• Auto Fan Off: The system fans will power off automatically even in sleep
mode.This function reduces both energy consumption and system noise, and is
an important feature in implementing silent PC systems.
• DualFunctionPowerButton(requiresATXpowersupply):Pushingthepower
button for less than 4 seconds when the system is in the working state places the
system into one of two states: sleep mode or soft-off mode, depending on the
BIOS setting (see Power Management Setup under BIOS SETUP). When the
power button is pressed for more than 4 seconds, the system enters the soft-off
mode regardless of the BIOS setting.
• Fan Status Monitoring and Alarm: To prevent system overheat and system
damage, the CPU fan and system fans can be monitored for RPM and failure.
All the fans are set for its normal RPM range and alarm thresholds.
• Keyboard Power Up: Keyboard Power Up can be enabled or disabled to allow
the computer to be powered ON using your keyboard.
• Message LED (requiresACPI OS support):Turbo LEDs now act as informa-
tion providers. Through the way a particular LED illuminates, the user can de-
termine the stage the computer is in.Asimple glimpse provides useful informa-
tion to the user.
• Remote Ring On (requires external modem): This allows a computer to be
turned on remotely through an external modem. With this benefit on-hand, any
usercan access vitalinformationfrom theircomputerfrom anywhere intheworld!
• System Resources Alert: Today’s operating systems such as Windows 95/98/
NT and OS/2, require much more memory and hard drive space to present enor-
mous user interfaces and run large applications. The system resource monitor
will warn the user before the system resources are used up to prevent possible
application crashes. Suggestions will give the user information on managing
their limited resources more efficiently.
•Temperature Monitoring and Alert: To prevent system overheat and system
damage, there are thermal sensors to monitor the CPU (the Pentium II processor
requires a special heatsink with a thermal sensor) and system temperatures to
warn of damaging temperatures.
•Voltage Monitoring and Alert: System voltage levels are monitored to ensure
stable voltage to critical motherboard components. Voltage specifications are
more critical for future processors, so monitoring is necessary to ensure proper
system configuration and management.

ASUS P2V-B User’s Manual 11
The ASUS P2V-B Motherboard
II. FEATURES
II. FEATURES
Motherboard Parts
AT Keyboard
3 PCI Slots
2 ISA Slots Programmable
Flash EEPROM
VIA
PCIset
Multi-I/O &
Keyboard
Controller
3 DIMM Sockets
VIA
AGPset IDE
Connectors
CPU Slot 1
Serial Ports
COM1 &
COM2
AGP Slot
Wake-On-LAN
Connector Wake-On-Ring Connector
Hardware
Monitor
(optional)
ATX PowerAT Power
USB/MIR
Parallel Port
Floppy
Connector
Universal Retention
Module

12 ASUS P2V-B User’s Manual
III. HARDWARE SETUP
Layout of the ASUS P2V-B Motherboard
Motherboard Layout
III. H/W SETUP
DIMM Socket 1 (64/72-bit, 168-pin module)
DIMM Socket 2 (64/72-bit, 168-pin module)
DIMM Socket 3 (64/72-bit, 168-pin module)
Row
102345
Serial Ports
FLOPPY
PARALLEL
KBPWR
AT Power Connector
Hardware
Monitor
PS/2
USB/MIR
CHASIS
AT
Keyboard
ISA Slot 1
ISA Slot 2
PANEL
IR
COM 2
COM 1
IDELED
PWR_FAN
CHA_FAN
CPU_FAN
WOL_CON
FREQ
MULT
BUS
FREQ
BF1 BF2 BF0 BF3
P8
P9
RT3
FS1
FS2
FS0
FS3
VIO
SMB
RT2
CLRTC
SECONDARY IDE
PRIMARY IDE
CR2032 3V
Lithium Cell
CMOSPower
2Mbit Flash EEPROM
(Programable BIOS)
VIA
VT82C596A
PCIset
Accelerated Graphics Port (AGP)
CPU Slot 1
PCI Slot 1 (PCI1)
PCI Slot 2 (PCI2)
PCI Slot 3 (PCI3)
ASUS
ASIC
ATXPWR
ATX Power Connector
Multi I/O
&
Keyboard
Controller
WOR
VIA
VT82C693
AGPset
VCORE
R
P2V-B
Greyed item is optional.

ASUS P2V-B User’s Manual 13
III. HARDWARE SETUP
Contents
III. H/W SETUP
Motherboard Settings
1) KBPWR p. 14 Keyboard Power Up
2) VIO p. 15 Voltage Input/Output Selection
3) VCORE p. 15 Voltage Regulator Output Selection
4) FS0, FS1, FS2, FS3 p. 16 CPU BUS Frequency Selection
5) BF0, BF1, BF2, BF3 p. 16 CPU to BUS Frequency Multiple
Expansion Slots/Sockets
1) System Memory p. 18 System Memory (DIMM)
2) DIMM Sockets p. 19 DIMM Memory Installation Procedures
3) Slot 1 p. 21 Central Processing Unit (CPU)
4) SLOT1, SLOT2 p. 26 16-bit ISA Bus Expansion Slots
*
5) PCI1, PCI2, PCI3 p. 26 32-bit PCI Bus Expansion Slots
6) AGP p.27 Accelerated Graphics Port
Hardware Monitor
1) RT2, RT3 p.25 Thermal Sensor Connectors
Connectors
1) KB-PS2KB p. 28 Keyboard Connector (5-pin female)
2) FLOPPY p. 28 Floppy Disk Drive Connector (34-1 pins)
3) PARALLEL p. 29 Parallel Port Connector (25-pin female)
4) COM1, COM2 p. 29 Serial Ports (9-pin male)
5) PRIMARY/SECONDARYIDE p. 30 Primary / Secondary IDE Connectors (Two 40-1pins)
6) IDELED p. 30 IDE Activity LED Connector (2 pins)
7) CHA_, CPU_, PWR_FAN p.31 Chassis,CPU,PowerSupplyFanConnectors(Three3 pins)
8) WOL_CON p. 31 Wake-On-LAN Connector (3 pins)
9) MSG.LED (PANEL) p. 32 Message LED Lead (2 pins)
10) SMI (PANEL) p. 32 System Management Interrupt Lead (2 pins)
11) PWR.SW (PANEL) p. 32 ATX Power/Soft Power Switch Lead (2 pins)
12) RESET (PANEL) p. 32 Reset Switch Lead (2 pins)
13) PWR.LED ( PANEL ) p. 32 System Power LED Lead (3-1 pins)
14) KEYLOCK ( PANEL ) p. 32 Keyboard Lock Switch Lead (2 pins)
15) SPEAKER (PANEL) p. 32 System Warning Speaker Connector (4 pins)
16) USB/MIR P. 33 USB,PS/2Mouse,IrDAModule Connector(18-1 pins)
17) IR p. 33 IrDA-Compliant Infrared Module Connector (5 pins)
18) WOR p. 36 Wake-On-Ring Connector (2 pins)
19) CHASIS p. 36 Chassis Intrusion Sensor Lead (4-1 pins)
20) SMB p. 35 SMBus Connector (5-1 pins)
21) ATXPWR p. 34 ATX Power Supply Connector (20 pins)
22) PS/2 p. 34 AT Power Supply Connector (20 pins)
*
The onboard hardware monitor uses the address 290H-297H so legacy ISA cards must not
use this address otherwise conflicts will occur.

14 ASUS P2V-B User’s Manual
III. HARDWARE SETUP
Installation Steps
1. Check Motherboard Settings
2. Install System Memory Modules
3. Install the Central Processing Unit (CPU)
4. Install Expansion Cards
5. Connect Ribbon Cables, Cabinet Wires, and Power Supply
6. Setup the BIOS Software
1. Motherboard Settings
This section explains how to change your motherboard’s functions settings through
the use of switches and/or jumpers.
WARNING! Computer motherboards and expansion cards contain very delicate
Integrated Circuit (IC) chips.To protect them against damage from static electric-
ity, you should follow some precautions whenever you work on your computer.
1. Unplug your computer when working on the inside.
2. Use a grounded wrist strap before handling computer components. If you do
not have one, touch both of your hands to a safely grounded object or to a
metal object, such as the power supply case.
3. Hold components by the edges and try not to touch the IC chips, leads or
connectors, or other components.
4. Place components on a grounded antistatic pad or on the bag that came with
the component whenever the components are separated from the system.
Jumpers
III. H/W SETUP
1. Keyboard Power Up (KBPWR)
This allows you to enable or disable the keyboard power up function. Set to
Enable if you want to use your keyboard (by pressing the SPACEBAR) to power
up your system. This feature requires an ATX power supply that can supply at
least 300mA on the +5VSB lead and new BIOS support. The default is set to
Disablebecause not all computers have the appropriateATX power supply.Your
computer will not function if you set this to Enable but do not have the appropri-
ate ATX power supply.

ASUS P2V-B User’s Manual 15
III. HARDWARE SETUP
2. Voltage Input/Output Selection (VIO)
This jumper allows you to select the voltage supplied to the DRAM, chipset,
AGP, and the CPU’s I/O buffer.
P2V-B Voltage Input/Output Selection
VIO
3.66Volts
1 2 3
3.50Volts
(Default)
1 2 3
R
P2V-B
3. Voltage Regulator Output Selection (VCORE)
This jumper sets the VCORE voltage supplied to the microprocessor.
P2V-B CPU VCORE Voltage Selection
Test
1 2 3
Normal
(Default)
1 2 3
VCORE
R
P2V-B
III. H/W SETUP
Jumpers
WARNING! Using a higher voltage Test for VCORE or 3.66Volts for VIO may
help when overclocking but may result in the shortening of your computer
component’s life. It is strongly recommended that you leave these jumpers on
their default settings.

16 ASUS P2V-B User’s Manual
III. HARDWARE SETUP
4. CPU BUS Frequency Selection (FS0, FS1, FS2, FS3)
This optiontells theclock generatorwhat frequencyto sendto theCPU, DRAM, and
the chipset.Thisallows theselectionoftheCPU’sExternalfrequency(orBUSClock).
The BUS Clock multiplied by the BUS Ratio equals the CPU's Internal frequency
(the advertised CPU speed).
P2V-B CPU Bus Frequency
Selection
103.00MHz
34.33MHz
123
100.30MHz
33.43MHz
123
83.30MHz
41.65MHz
123
75.0MHz
37.5MHz
123
66.8MHz
33.4MHz
123
133.00MHz
44.33MHz
123
120.0MHz
40.0MHz
123
115.00MHz
38.33MHz
123
CPU
PCI
FS0
FS1
FS2
FS3
110.00MHz
36.67MHz
123
112.00MHz
37.33MHz
123
105.0MHz
35.0MHz
123
CPU
PCI
FS0
FS1
FS2
FS3
CPU
PCI
FS0
FS1
FS2
FS3
R
P2V-B
WARNING! Frequencies above 100MHz exceed the specifications for the on-
board chipset and are not guaranteed to be stable.
WARNING! PCI frequencies above 33MHz exceed the specifications for PCI
cards and are not guaranteed to be stable.
Jumpers
III. H/W SETUP
5. CPU to BUS Frequency Multiple (BF0, BF1, BF2, BF3)
This option sets the frequency multiple between the Internal frequency of the
CPU and the CPU’s External frequency. This must be set in conjunction with the
CPU BUS Frequency.
P2V-B CPU Core-to-Bus
Frequency Multiple Settings
BF1 BF2 BF0 BF3
4.0x(4/1)
BF1 BF2 BF0 BF3
2.0x(2/1)
1
2
3
BF1 BF2 BF0 BF3
2.5x(5/2)
BF1 BF2 BF0 BF3
3.0x(3/1)
BF1 BF2 BF0 BF3
3.5x(7/2)
BF1 BF2 BF0 BF3
4.5x(9/2)
BF1 BF2 BF0 BF3
5.0x(5/1)
BF1 BF2 BF0 BF3
5.5x(11/2)
R
P2V-B
1
2
3
1
2
3
BF1 BF2 BF0 BF3
7.0x(7/1) 7.5x(15/2)
BF1 BF2 BF0 BF3
8.0x(8/1)
BF1 BF2 BF0 BF3
1
2
3
6.5x(13/2)6.0x(6/1)
BF1 BF2 BF0 BF3 BF1 BF2 BF0 BF3

ASUS P2V-B User’s Manual 17
III. HARDWARE SETUP
NOTES: Overclocking your processor is not recommended. It may result in a slower
speed. Voltage Regulator Output Selection (VID) is not needed for the Pentium III / II /
Celeron processors because they send a VID signal directly to the onboard power con-
troller.
Set the jumpers by the Internal speed of your processor as follows:
(CPU BUS Freq.) (Freq. Multiple)
Intel CPU Model Freq. Ratio BUS F. FS0 FS1 FS2 FS3 BF0 BF1 BF2 BF3
Pentium III 500MHz 5.0x 100MHz [1-2] [1-2] [1-2] [2-3] [2-3] [1-2] [1-2] [2-3]
Pentium III / II 450MHz 4.5x 100MHz [1-2] [1-2] [1-2] [2-3] [1-2] [2-3] [1-2] [2-3]
Pentium II/Celeron 400MHz 4.0x 100MHz [1-2] [1-2] [1-2] [2-3] [2-3] [2-3] [1-2] [2-3]
Pentium II 350MHz 3.5x 100MHz [1-2] [1-2] [1-2] [2-3] [1-2] [1-2] [2-3] [2-3]
Celeron 466MHz 7.0x 66MHz [1-2] [1-2] [2-3] [2-3] [2-3] [1-2] [2-3] [1-2]
Celeron 433MHz 6.5x 66MHz [1-2] [1-2] [2-3] [2-3] [1-2] [2-3] [2-3] [1-2]
Pentium II/Celeron 400MHz 6.0x 66MHz [1-2] [1-2] [2-3] [2-3] [2-3] [2-3] [2-3] [1-2]
Celeron 366MHz 5.5x 66MHz [1-2] [1-2] [2-3] [2-3] [1-2] [1-2] [1-2] [2-3]
Pentium II/Celeron 333MHz 5.0x 66MHz [1-2] [1-2] [2-3] [2-3] [2-3] [1-2] [1-2] [2-3]
Pentium II/Celeron 300MHz 4.5x 66MHz [1-2] [1-2] [2-3] [2-3] [1-2] [2-3] [1-2] [2-3]
Pentium II/Celeron 266MHz 4.0x 66MHz [1-2] [1-2] [2-3] [2-3] [2-3] [2-3] [1-2] [2-3]
Pentium II 233MHz 3.5x 66MHz [1-2] [1-2] [2-3] [2-3] [1-2] [1-2] [2-3] [2-3]
III. H/W SETUP
Jumpers

18 ASUS P2V-B User’s Manual
2. System Memory (DIMM)
NOTE: No hardware or BIOS setup is required aftrer adding or removing memory.
This motherboard uses only Dual Inline Memory Modules (DIMMs). Sockets are
available for 3.3Volt (power level) unbuffered Synchronous Dynamic Random Ac-
cess Memory (SDRAM) of either 8, 16, 32, 64, or 128MB. One side (with memory
chips) of the DIMM takes up one row on the motherboard.
To utilize the chipset’s Error Checking and Correction (ECC) feature, you must use a
DIMM module with 9 chips per side (standard 8 chips/side + 1 ECC chip) and make
the proper settings through “Chipset Features Setup” in BIOS setup.
Memoryspeed setupis recommended throughSDRAM Configurationunder“Chipset
Features Setup” in BIOS setup.
General DIMM Notes
•Forthesystem CPU bus tooperateabove 100MHz, use onlyPC100-compli-
ant DIMMs . This motherboard operates at 100MHz, thus most systems will
not even boot if non-compliant modules are used because of the strict timing
issues involved under this speed. If your DIMMs are not PC100-compliant, set
the CPU bus frequency to 66MHz for system stability.
• Two possible memory chips are supported: SDRAM with and without ECC.
• SDRAM chips are generally thinner with higher pin density than EDO (Ex-
tended Data Output) chips.
• BIOS shows SDRAM memory on bootup screen.
• 4 or 8 chips/side modules do not support ECC, only 5 or 9 chips/side modules
support ECC.
• Single-sided DIMMs come in 4, 8, 16, 32, 64,128MB; double-sided come in 8,
16, 32, 64, 128, 256MB.
Install memory in any combination as follows:
DIMM Location 168-pin DIMM Memory Modules Total Memory
Socket 1 (Rows 0&1) SDRAM 4, 8, 16, 32, 64, 128, 256MB x1
Socket 2 (Rows 2&3) SDRAM 4, 8, 16, 32, 64, 128, 256MB x1
Socket 3 (Rows 4&5) SDRAM 4, 8, 16, 32, 64, 128, 256MB x1
Total System Memory (Max 768MB) =
III. HARDWARE SETUP
System Memory
III. H/W SETUP
SPD Support
This motherboard supports SPD DIMMs. It is recommended that SPD DIMMS be
used.

ASUS P2V-B User’s Manual 19
III. HARDWARE SETUP
DIMM Memory Installation Procedures:
Insert the module(s) as shown. Because the number of pins are different on either
side of the breaks, the module will only fit in the orientation as shown. DRAM
SIMM modules have the same pin contacts on both sides. SDRAM DIMMs have
different pin contacts on each side and therefore have a higher pin density.
P2V-B 168-Pin DIMM Memory Sockets
20 Pins 60 Pins 88 Pins
Lock
R
P2V-B
The DIMMs must be 3.3Volt unbuffered SDRAMs. To determine the DIMM type,
check the notches on the DIMMs (see figure below).
168-Pin DIMM Notch Key Definitions (3.3V)
DRAM Key Position Voltage Key Position
Unbuffered
RFU
Buffered Reserved
3.3V
5.0V
The notches on the DIMM will shift between left, center, or right to identify the type
and also to prevent the wrong type from being inserted into the DIMM slot on the
motherboard. You must tell your retailer the correct DIMM type before purchasing.
This motherboard supports four clock signals per DIMM.
III. H/W SETUP
System Memory

20 ASUS P2V-B User’s Manual
(This page was intentionally left blank.)
