Asus P4S533-VM User manual

Motherboard
®
P4S533-VM
User Manual

ii
Checklist
Copyright © 2002 ASUSTeK COMPUTER INC. All Rights Reserved.
Nopartofthismanual,includingtheproductsandsoftwaredescribedinit,maybereproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any
form or by any means, except documentation kept by the purchaser for backup purposes,
without the express written permission of ASUSTeK COMPUTER INC. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modified or
altered, unless such repair, modification of alteration is authorized in writing byASUS; or (2)
the serial number of the product is defaced or missing.
Products and corporate names appearing in this manual may or may not be registered
trademarks or copyrights of their respective companies, and are used only for identification
or explanation and to the owners’benefit, without intent to infringe.
Theproductname and revision number are both printed on the product itself. Manual revisions
are released for each product design represented by the digit before and after the period of
the manual revision number. Manual updates are represented by the third digit in the manual
revision number.
For previous or updated manuals, BIOS, drivers, or product release information, contact
ASUS at: http://www.asus.com or through any of the means indicated on the following page.
ASUS PROVIDES THIS MANUAL “AS IS”WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALLASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM
ANY DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN
THIS MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
P4S533-VM
E1058
June 2002

iii
Features
About this guide
This user manual contains complete information for installing the ASUS
P4S533-VM motherboard.
How this guide is organized
• Chapter 1: Product introduction. A summary of product features and
special attributes of new technologies.
• Chapter 2: Hardware information. A list of hardware setup procedures
and descriptions of all jumpers and connectors on the motherboard.
•Chapter 3: Powering up. Describes the power up sequence with
information on BIOS beep codes.
• Chapter 4: BIOS setup. How to change system settings using onboard
BIOSfirmware.DetaileddescriptionsoftheBIOSparametersaresupplied.
• Chapter 5: Software support. A summary of contents on the
motherboard support CD ROM.
• Appendix and Glossary. Optional componentsandtechnicaldefinitions.
• Index
Conventions used in this guide
Tomakesurethatyouperform set-up tasksproperly,takenoteofthefollowing
symbols used throughout this manual.
WARNING! Information to prevent injury to yourself.
CAUTION! Information to prevent damage to the components.
IMPORTANT! Information that youMUSTfollowtocomplete a task.
NOTE! Tips and helpful information.

iv
Safeguards
Contents
About this guide .............................................................................. iii
How this guide is organized.................................................... iii
Conventions used in this guide............................................... iii
Safety information ...........................................................................vi
FCC/CDC statements .................................................................... vii
ASUS contact information ............................................................. viii
Chapter 1: Product introduction ............................................. 1
Welcome! ........................................................................................ 1
1.1 Package contents .................................................................. 1
1.2 Core Specifications ................................................................ 2
1.3 Value-added Solutions ........................................................... 3
1.4 Motherboard Components...................................................... 4
1.4.1 Component Locations................................................ 5
Chapter 2: Hardware information ............................................ 1
2.1 Motherboard installation ......................................................... 7
2.1 Motherboard installation ......................................................... 7
2.1.1 Placement direction ................................................... 7
2.1.2 Screw holes............................................................... 7
2.2 Motherboard layout ................................................................ 8
2.2.1 Layout contents ......................................................... 9
2.3 Before you proceed...............................................................10
2.4 Central Processing Unit (CPU) ..............................................11
2.4.1 Overview ..................................................................11
2.4.2 Installing the CPU .................................................... 12
2.4.3 Installing the heatsink and fan.................................. 14
2.4.4 Connecting the CPU fan cable................................. 16
2.5 System memory ....................................................................17
2.5.1 Overview ..................................................................17
2.5.2 Memory configurations ............................................ 18
2.5.3 Installing a DIMM ..................................................... 19
2.5.4 Removing a DIMM................................................... 20
2.6 Expansion slots.....................................................................21
2.6.1 Installing an expansion card..................................... 21
2.6.2 Configuring an expansion card ................................ 22
2.6.3 PCI slots ...................................................................23
2.6.4 AGP slot ...................................................................23
2.7 Jumpers ................................................................................24

v
Contents
2.8 Connectors ...........................................................................29
Chapter 3: Powering up ......................................................... 41
3.1 Starting up for the first time................................................... 41
3.3 Powering off the computer.................................................... 42
Chapter 4: BIOS setup ........................................................... 43
4.1 Managing and updating your BIOS....................................... 43
4.1.1 Using the computer system for the first time ............ 43
4.1.2 Updating BIOS procedures ...................................... 45
4.2 BIOS Setup program.............................................................47
4.2.1 BIOS menu bar.........................................................48
4.2.2 Legend bar ...............................................................48
4.3 Main menu ............................................................................50
4.3.1 Primary & Secondary Master/Slave ......................... 51
4.3.2 Keyboard Features .................................................. 55
4.4 Advanced Menu ....................................................................57
4.4.1 Chip Configuration ................................................... 59
4.4.2 I/O Device Configuration.......................................... 62
4.4.3 PCI Configuration .................................................... 64
4.5 Power Menu..........................................................................67
4.5.1 Power Up Control .................................................... 69
4.5.2 Hardware Monitor .................................................... 71
4.6 Boot Menu ............................................................................72
4.7 Exit Menu..............................................................................74
Chapter 5: Software support ................................................. 77
5.1 Install an operating system................................................... 77
5.2 Support CD information.........................................................77
5.3 P4S533-VM Motherboard Support CD ................................. 78
5.4 ASUS PC Probe....................................................................80
5.5 ASUS Live Update ................................................................85
5.6 3Deep Color Tuner................................................................86
5.7 ITE GSM Editor.....................................................................88
Glossary .................................................................................. 93
Index ........................................................................................ 97

vi
Safety information
Electrical safety
•To prevent electrical shock hazard, disconnect the power cable from the
electrical outlet before relocating the system.
•When adding or removing devices to or from the system, ensure that the
power cables for the devices are unplugged before the signal cables are
connected. Disconnect all power cables from the existing system before
you add a device.
•Beforeconnectingor removingsignalcablesfromthemotherboard,ensure
that all power cables are unplugged.
•Seek professional assistance before using an adpater or extension cord.
These devices could interrupt the grounding circuit.
•Make sure that your power supply is set to the voltage available in your
area.
•If the power supply is broken, contact a qualified service technician or your
retailer.
Operational safety
•Before installing the motherboard and adding new devices, carefully read
all the manuals that came with the package.
•Before use ensure all cables are correctly connected and the power cables
arenotdamaged.Ifyoudetectanydamage,contactthedealerimmediately.
•To avoid short circuits, keep paper clips, screws, and staples away from
connectors, slots, sockets and circuitry.
•Avoid dust, humidity, and temperature extremes. Do not place the product
in any area where it may become wet.
•Mount the motherboard inside a standard PC enclosure.
•If you encounter technical problems with the product, contact a qualified
service technician or the dealer.

vii
FCC/CDC statements
Federal Communications Commission Statement
This device complies with FCC Rules Part 15. Operation is subject to the
following two conditions:
•This device may not cause harmful interference, and
•This device must accept any interference received including interference
that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
manufacturer’s instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment to an outlet on a circuit different from that to
which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
The use of shielded cables for connection of the monitor to the
graphics card is required to assure compliance with FCC regulations.
Changes or modifications to this unit not expressly approved by the
party responsible for compliance could void the user’s authority to
operate this equipment.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for radio noise
emissions from digital apparatus set out in the Radio Interference
Regulations of the Canadian Department of Communications.
This class B digital apparatus complies with Canadian ICES-003.

viii
ASUS contact information
ASUSTeK COMPUTER INC. (Asia-Pacific)
Address: 150 Li-Te Road, Peitou, Taipei, Taiwan 112
General Tel: [phone]
General Fax: [phone]
General Email: [email protected]
Technical Support:
MB/Others (Tel): [phone] (English)
Notebook (Tel): [phone] (English)
Desktop/Server (Tel): [phone] (English)
Support Fax: [phone]
Support Email: [email protected]
Web Site: www.asus.com.tw
Newsgroup: cscnews.asus.com.tw
ASUS COMPUTER INTERNATIONAL (America)
Address: 6737 Mowry Avenue, Mowry Business Center,
Building 2, Newark, CA 94560, USA
General Fax: [phone]
General Email: [email protected]
Technical Support:
Support Fax: [phone]
General Support: [phone]
Notebook Support: +1-877-918-ASUS (2787)
Web Site: www.asus.com
Support Email: [email protected]
ASUS COMPUTER GmbH (Europe)
Address: Harkortstr. 25, 40880 Ratingen, BRD, Germany
General Fax: [phone]
General Email: [email protected] (for marketing requests only)
Technical Support:
Support Hotline: MB/Others: [phone]
Notebook (Tel): [phone]
Support Fax: [phone]
Support (Email): www.asuscom.de/de/support (for online support)
Web Site: www.asuscom.de

Chapter 1
Product introduction

ASUS P4S533-E motherboard

ASUS P4S533-VM motherboard user guide 1
Welcome!
Thank you for buying the ASUS
®
P4S533-VM motherboard!
The ASUS
P4S533-VM motherboard delivers a host of new features to
ensure long-lasting, superlative performance. The ASUS
®
P4S533-VM
motherboard is the prime choice for home PCs and workstations.
The P4S533-VM incorporates the Intel
®
Pentium
®
4 Processor coupled
with the SiS 651 chipset to set a new benchmark for an effective desktop
platform solution.
~ CPU Thermal Protection
~ Up to 2GB of system memory of PC 2700 / 2100 / 1600 DDR
~ High-resolution graphics via an AGP 4X slot
~ Digital Audio Interface for 3D sound
~ Realtek
™
LAN Controller onboard
~ Two USB ports plus two headers for four more
Before installing the motherboard, check the items in your package:
1.1 Package contents
Check your P4S533-VM package for the following items.
ASUS P4S533-VM motherboard (micro-ATX 24.4 cm x 20.9 cm)
ASUS P4S533-VM support CD
ASUS 4-port USB 2.0 module
40 pin conductor ribbon cable for UltraDMA/33/66/100/133 IDE drives
9 pin COM2 cable
Ribbon cable for a 3.5-inch floppy drive
Bag of extra jumper caps
User Guide
If any of the above items is damaged or missing, contact your retailer.

2 Chapter 1: Product introduction
1.2 Core Specifications
The P4S533-VM motherboard is designed and assembled according to the
highest standards. ThisASUS motherboard represents the latest advances
to supply users the finest componentry available today...
Latest 533MHz P4 Processor Technology: Intel Pentium 4 Socket 478
Northwood Processor. The Pentium 4 processor utilizes the advanced
0.18micron processor core in FC-PGA2packagefora2.0GHzfrequency,
whilethe Northwood processor usesthe 0.13micronprocessor core with
512KBL2 cache forup to aspeedy 2.53+ GHzfrequency and a533 MHz
FSB. TheP4offers optimized performance for audio,video,andInternet
applications.
North Bridge Chipset: the SiS
®
651 supports AGP 4X/2X mode,
133/100MHz Front Side Bus, and the fastest 333 MHz memory bus.
South Bridge Chipset: the SiS
®
962L integrated peripheral controller
supports UltraDMA133/100/66/33 for burst mode data transfer rates up
to 133MB/sec, and USB controller with three root hubs for six USB ports.
PC 2700 / 2100 / 1600 DDR Support: Equipped with two Double Data Rate
Dual InlineMemory Module (DDR DIMM) sockets to support up to 2GB of
DDR DRAM, the newest memory standard with the highest bandwidth
and lowest latency currently available. This new memory technology
increasesperformance by executing two actions per clock cycle, resulting
in data transfer rates of up to 2.7 GB/s for 166MHz DDR SDRAM and
2.1GB/s for 133MHz DDR SDRAM.
UltraDMA133 Support: Comes with an onboard PCI Bus Master IDE
controller with two connectors that support four IDE devices on two
channels. Supports UltraDMA133/100/66/33, PIO Modes 3 & 4, Bus
Master IDE DMA Mode 2, and Enhanced IDE devices, such as DVD-
ROM, CD-ROM, CD-R/RW, LS-120, and Tape Backup drives.
Multi-I/O Chipset: The ITE 8707F chip offers complete support for a variety
of I/O functions. Provides two high-speed UART compatible serial ports
and one parallel port with EPP and ECPcapabilities. UART2 can switch
from COM2 to the Infrared Module for wireless connections. The Super
I/O controller supports a floppy disk drive.
Smart BIOS: 2Mb firmware enables boot block write protection, and HD/
SCSI/MO/ZIP/CD/Floppy boot selection.
Expansion: OneAGP4X, four USB ports, one COM port, one COM header,
three PCI slots, SPDIF digital audio, front audio panel, headers, smart
card header, CIR infrared, serial IRQ header.
Connections: Parallel, PS/2 mouse, PS/2 keyboard, 2 USB, VGA, RJ45
(optional), Microphone, Line-In / Line-Out jacks, StandardATX,AUX and
12V power.

ASUS P4S533-VM motherboard user guide 3
1.3 Value-added Solutions
SoftwareAudio: On audio models, a digital audio CODEC, CMI-9738
supports 4-Ch output, and the SiS962L supports the Sony/Philips Digital
Interface (S/PDIF) Output module for coaxial and fiber interfaces.
Experience surround sound and enhanced 3D audio.
SmartCard Reader Support: AspecialconnectorfortheSmartCardReader
comes onboard to support the cutting-edge technology for increased
securityinauthenticatingonlinetransactions,editingIC-basedinformation.
USB2.0: The latest connection standard for next generation components
and peripherals. Compatible with 1.1 USB, the new 2.0 USB protocol
delivers transfer speeds up to 40 times faster at 480Mb/s.
NOTICE: USB2.0 functions arenot supported under Win98and WinME.
Temperature, Fan and Voltage Monitoring:CPU temperature is monitored
by the ASUS ASIC through the CPU’s internal thermal diode to prevent
overheating and damage. All system fans are monitored for RPM and
failure. System voltage levels are monitored to ensure stable voltage to
critical motherboard components.
Auto Fan Off: Thesystemfanspowersoffautomaticallyeveninsleepmode.
ACPI Ready: AdvancedConfigurationPowerInterface(ACPI) providesmore
Energy Saving Features for operating systems that support OS Direct
Power Management (OSPM).
Onboard LAN (Optional): The motherboard incorporates the RTL8201L
PHY chip to support 10BASE-T/100BASE-TX Fast Ethernet networking.
Concurrent PCI: Concurrent PCI allows multiple PCI transfers from PCI
master busses to the memory and processor.
DualFunction Power Button: Pushthepower buttonforlessthan4seconds
when the system is operating places the system into sleep or soft-off
modes, depending on the BIOS or OS setting. If the power button is
pressed for more than 4 seconds, the system enters soft-off mode.

4 Chapter 1: Product introduction
Location
Processor Support Socket 478 for Intel
®
P4
™
Processors .............................2
Chipsets SiS
®
651 North Bridge .....................................................3
SiS
®
962L South Bridge................................................. 12
2Mbit Programmable Flash EEPROM ..........................18
Multi-I/O Controller ........................................................19
Audio Controller ............................................................22
Main Memory 2 DDR SDRAM DIMM Sockets (2GB) ............................5
Expansion Slots 3 PCI Slots ....................................................................20
Accelerated Graphics Port (AGP) 4X Slot..................... 23
System I/O Floppy Disk Drive Connector ........................................15
2 IDE Connectors (UltraDMA133 Support) .....................6
Serial IRQ Connector ......................................................7
System Panel Connector ................................................9
Infrared Connector ........................................................ 11
USB Headers (USB_34, USB_56) ................................14
Serial (COM2) Header ..................................................16
Smart Card Connector ..................................................17
Modem Connector.........................................................25
Parallel Port................................................................... 29
Game Port .....................................................................30
Serial Port (COM1)........................................................35
USB Connectors (Port 1/2) .......................................... 36
PS/2 Mouse Connector ....................................(green) 27
PS/2 Keyboard Connector ............................. (purple) 37
Hardware Monitoring System Voltage Monitor (integrated in ASUS ASIC) .....10
Special Feature Onboard LED ................................................................13
Network Feature Realtek 100/10 Mbps LAN PHY .................................... 26
RJ45 Connector (Optional) ...........................................28
Audio Features (on audio models only)
Audio Controller Chipset ...............................................22
SPDIF-out Connector ......................................................8
Front Panel Audio Header .............................................21
Audio Connectors..........................................................24
Line Out Connector ............................................ (lime) 33
Line In Connector ...................................... (light blue) 32
Microphone Connector ....................................... (pink) 31
Power ATX 12V Power Supply Connector .................................1
ATX Power Supply Connector.........................................4
Form Factor micro-ATX
1.4 Motherboard Components
BeforeinstallingtheP4S533-VMmotherboard,taketimetofamiliarizeyourself
withits configuration: understanding the motherboard makesupgradingeasy.
Sufficient knowledge of specifications prevents accidental damage.

ASUS P4S533-VM motherboard user guide 5
1.4.1 Component Locations
23 4 5
1216
20
19
1
18
13
21
26
15 14 9111017
24 6
8
7
25
22
23
27 28 29 30
3132333537 36 34

Chapter 2
Hardware information

ASUS P4S533-VM motherboard

ASUS P4S533-VM motherboard user guide 7
2.1 Motherboard installation
Before you install the motherboard, study the configuration of your chassis
to ensure that the motherboard fits into it. The P4S533-VM uses the micro-
ATX form factor that measures 24.4 cm (9.6 in.) x 20.9 cm (8.2 in.), a
standard fit for most chassis.
Do not overtighten the screws! Doing so may damage the
motherboard.
2.1.1 Placement direction
When installing the motherboard, make sure that you place it into the
chassis in the correct orientation. The edge with external ports goes to the
rear part of the chassis. Refer to the image below.
2.1.2 Screw holes
Place six (6) screws into the holes indicated by circles to secure the
motherboard to the chassis.
Make sure to unplug the power cord before installing or removing the
motherboard. Failure to do so may cause you physical injury and
damage motherboard components.
Place this side towards
the rear of the chassis

8 Chapter 2: Hardware information
2.2 Motherboard layout
The audio and LAN features are optional. These components are
grayed out in the above motherboard layout.
FLOPPY1
PANEL1
IR_CON1
BATTERY1
CD1
CPU_FAN1
SiS651
HOST/
Memory
Controller
PS/2
T: Mouse
B: Keyboard
GAME_AUDIO
Mic
In
Line
Out
Line
In
AUX1
IDE_LED1
USBPWR_34
P4S533-VM
®
SMARTCON1
FP_AUDIO1
MODEM
ITE 8707F
Super I/O
2Mbit
Flash
BIOS
PCI Slot 1
ATX Power Connector
SEC_IDE1
Bottom:
USB1
USB2
Top:
RJ-45
DDR DIMM2 (64/72 bit, 184-pin module)
2 3
DDR DIMM1 (64/72 bit, 184-pin module)
0 1
Accelerated Graphics Port
(AGP)
USBPWR_12
SiS962L
MuTLOL
Media
I/0
SPDIF_OUT1
ATX12V1
Audio
Codec
RTL
8201
ASUS
Mozart
SIRQ1
CHA_FAN1
CLRTC1
20.9cm (8.2in)
24.4cm (9.6in)
Socket 478
COM1
PARALLEL PORT
VGA
PCI Slot 2
PCI Slot 3
PRI_IDE1
BUZZER1
SB_PWR1
FSJ1
FP_LO_SWR
COM2
USBPWR_56
USB_56USB_34
FP_LO_SWL
