Asus P5KPL-AM IN GB User manual

Motherboard
P5KPL-AM IN/GB

ii
Copyright © 2009 ASUSTeK Computer Inc. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any
means, except documentation kept by the purchaser for backup purposes, without the express written
permission of ASUSTeK Computer Inc. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless
such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the
product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS
MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identication or explanation and to the
owners’ benet, without intent to infringe.
E4450
First Edition V1
March 2009

iii
Contents
Notices.......................................................................................................... v
Safety information ...................................................................................... vi
About this guide ......................................................................................... vi
P5KPL-AM IN/GB specications summary ............................................ viii
Chapter 1: Product introduction
1.1 Before you proceed ..................................................................... 1-1
1.2 Motherboard overview................................................................. 1-2
1.2.1 Motherboard layout ......................................................... 1-2
1.2.2 Layout contents............................................................... 1-2
1.3 Central Processing Unit (CPU) ................................................... 1-3
1.4 System memory ........................................................................... 1-3
1.4.1 Overview ......................................................................... 1-3
1.4.2 Memory congurations.................................................... 1-3
1.5 Expansion slots............................................................................ 1-7
1.5.1 PCI slots.......................................................................... 1-7
1.5.2 PCI Express x16 slot....................................................... 1-7
1.6 Jumpers ........................................................................................ 1-7
1.7 Connectors ................................................................................... 1-9
1.7.1 Rear panel ports ............................................................. 1-9
1.7.2 Internal connectors ....................................................... 1-10
1.8 Software support........................................................................ 1-15
1.8.1 Installing an operating system ...................................... 1-15
1.8.2 Support CD information ................................................ 1-15
Chapter 2: BIOS information
2.1 Managing and updating your BIOS ............................................ 2-1
2.1.1 ASUS Update utility ........................................................ 2-1
2.1.2 ASUS EZ Flash 2 utility................................................... 2-2
2.1.3 ASUS CrashFree BIOS 3 utility ...................................... 2-3
2.2 BIOS setup program .................................................................... 2-4
2.3 Main menu .................................................................................... 2-4
2.3.1 System Time ................................................................... 2-4
2.3.2 System Date ................................................................... 2-4
2.3.3 Primary IDE Master/Slave, SATA 1/2 .............................. 2-5
2.3.4 Storage Conguration ..................................................... 2-5
2.3.5 System Information ......................................................... 2-6

iv
Contents
2.4 Advanced menu ........................................................................... 2-6
2.4.1 JumperFree Conguration .............................................. 2-6
2.4.2 USB Conguration .......................................................... 2-8
2.4.3 CPU Conguration .......................................................... 2-8
2.4.4 Chipset............................................................................ 2-9
2.4.5 Onboard Devices Conguration.................................... 2-10
2.4.6 PCI PnP ........................................................................ 2-10
2.5 Power menu................................................................................ 2-11
2.5.1 Suspend Mode...............................................................2-11
2.5.2 ACPI 2.0 Support ...........................................................2-11
2.5.3 ACPI APIC Support........................................................2-11
2.5.4 APM Conguration........................................................ 2-12
2.5.5 Hardware Monitor ......................................................... 2-12
2.6 Boot menu .................................................................................. 2-13
2.6.1 Boot Device Priority ...................................................... 2-13
2.6.2 Boot Settings Conguration .......................................... 2-13
2.6.3 Security ......................................................................... 2-14
2.7 Tools menu ................................................................................. 2-15
2.7.1 ASUS EZ Flash 2.......................................................... 2-15
2.7.2 AI NET 2........................................................................ 2-15
2.8 Exit menu.................................................................................... 2-16

v
Notices
ASUS REACH
Complying with the REACH (Registration, Evaluation, Authorisation, and
Restriction of Chemicals) regulatory framework, we published the chemical
substances in our products at ASUS REACH website at http://green.asus.com/
english/REACH.htm.
The use of shielded cables for connection of the monitor to the graphics card is required
to assure compliance with FCC regulations. Changes or modications to this unit not
expressly approved by the party responsible for compliance could void the user’s authority
to operate this equipment.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for radio noise emissions from
digital apparatus set out in the Radio Interference Regulations of the Canadian Department
of Communications.
This class B digital apparatus complies with Canadian ICES-003.
DO NOT throw the motherboard in municipal waste. This product has been designed to
enable proper reuse of parts and recycling. This symbol of the crossed out wheeled bin
indicates that the product (electrical and electronic equipment) should not be placed in
municipal waste. Check local regulations for disposal of electronic products.
DO NOT throw the mercury-containing button cell battery in municipal waste. This symbol
of the crossed out wheeled bin indicates that the battery should not be placed in municipal
waste.
Federal Communications Commission Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with manufacturer’s instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.

vi
Safety information
Electrical safety
• To prevent electric shock hazard, disconnect the power cable from the electric outlet
before relocating the system.
• When adding or removing devices to or from the system, ensure that the power cables
for the devices are unplugged before the signal cables are connected. If possible,
disconnect all power cables from the existing system before you add a device.
• Before connecting or removing signal cables from the motherboard, ensure that all
power cables are unplugged.
• Seek professional assistance before using an adapter or extension cord. These devices
could interrupt the grounding circuit.
• Ensure that your power supply is set to the correct voltage in your area. If you are not
sure about the voltage of the electrical outlet you are using, contact your local power
company.
• If the power supply is broken, do not try to x it by yourself. Contact a qualied service
technician or your retailer.
Operation safety
• Before installing the motherboard and adding devices on it, carefully read all the manuals
that came with the package.
• Before using the product, ensure that all cables are correctly connected and the power
cables are not damaged. If you detect any damage, contact your dealer immediately.
• To avoid short circuits, keep paper clips, screws, and staples away from connectors,
slots, sockets, and circuitry.
• Avoid dust, humidity, and temperature extremes. Do not place the product in any area
where it may become wet.
• Place the product on a at and stable surface.
• If you encounter technical problems with the product, contact a qualied service
technician or your retailer.
About this guide
This user guide contains the information you need when installing and conguring the
motherboard.
How this guide is organized
This guide contains the following parts:
• Chapter 1: Product introduction
This chapter describes the features of the motherboard and the new technology it
supports.
• Chapter 2: BIOS information
This chapter tells how to change system settings through the BIOS setup menus.
Detailed descriptions of the BIOS parameters are also provided.

vii
Conventions used in this guide
To ensure that you perform certain tasks properly, take note of the following symbols used
throughout this manual.
DANGER/WARNING:Information to prevent injury to yourself when trying toInformation to prevent injury to yourself when trying to
complete a task.
CAUTION: Information to prevent damage to the components when trying toInformation to prevent damage to the components when trying to
complete a task.
NOTE: Tips and additional information to help you complete a task.Tips and additional information to help you complete a task.
IMPORTANT: Instructions that you MUST follow to complete a task.
Where to nd more information
Refer to the following sources for additional information and for product and software
updates.
1. ASUS websites
The ASUS website provides updated information on ASUS hardware and software
products.
2. Optional documentation
Your product package may include optional documentation, such as warranty yers,
that may have been added by your dealer. These documents are not part of the
standard package.
Typography
Bold text Indicates a menu or an item to select.
Italics Used to emphasize a word or a phrase.
<Key> Keys enclosed in the less-than and greater-than sign means
that you must press the enclosed key.
Example: <Enter> means that you must press the Enter or
Return key.
<Key1>+<Key2>+<Key3> If you must press two or more keys simultaneously, the key
names are linked with a plus sign (+).
Example: <Ctrl>+<Alt>+<D>

viii
P5KPL-AM IN/GB specications summary
(continued on the next page)
CPU LGA775 socket for Intel® Core™2 Extreme / Core™2 Quad
/ Core™2 Duo / Pentium® D / Pentium®4
/ Celeron®E1000 Series and Celeron®400 Series
processors
Supports Intel®45nm CPU
Supports Intel®Hyper-Threading Technology and
Enhanced Intel SpeedStep®Technology (EIST)
* Refer to www.asus.com for the Intel CPU support list
Chipset Northbridge: Intel®G31
Southbridge: Intel®ICH7
Front Side Bus 1600 (O.C.) / 1333 / 1066 / 800MHz
Memory Dual channel memory architecture
2 x 240-pin DIMM sockets support unbuffered non-ECC
800 / 667MHz DDR2 memory modules
Supports up to 4GB system memory
* Refer to www.asus.com for the latest Memory QVL
(Qualied Vendors List).
** When you install a total memory of 4GB or more,
Windows® 32-bit operating system may only recognize
less than 3GB. Hence, a total installed memory of less
than 3GB is recommended if you are using a Windows
32-bit operating system.
Expansion Slots 1 x PCIe x16 slot
2 x PCI slots
VGA Integrated Graphics Media Accelerator (Intel®GMA3100)
supports:
- Maximum resolution: 2048 x 1536 @ 75Hz
Storage Intel®ICH7 southbridge supports:
- 1 x UltraDMA 133/100/66 connector
- 2 x SATA 3Gb/s connectors
LAN Gb LAN
Audio VT1705 6-channel High Denition Audio CODEC
USB 8 x USB 2.0 ports (4 ports at mid-board, 4 ports at the back
panel)
ASUS Features ASUS CrashFree BIOS 3
ASUS Q-Fan
ASUS EZ Flash 2
ASUS AI NET2

ix
P5KPL-AM IN/GB specications summary
*Specications are subject to change without notice.
Internal connectors 2 x USB 2.0 connectors support additional 4 USB 2.0 ports
1 x Speaker connector
2 x SATA connectors
1 x CPU fan connector
1 x 24-pin EATX power connector
1 x 4-pin ATX 12V power connector
1 x Front panel audio connector
1 x System Panel connector
1 x IDE connector
Rear panel ports 1 x PS/2 keyboard port
1 x PS/2 mouse port
1 x COM port
1 x VGA port
1 x LAN (RJ-45) port
4 x USB 2.0 ports
6-channel audio I/O ports
BIOS 8Mb Flash ROM, AMI BIOS, PnP, DMI2.0, WfM2.0,
SM BIOS 2.5
Manageability WOL, PXE, RPL, WOR, PME Wake Up
Support CD Drivers
ASUS PC Probe II
ASUS Update
Accessories 1 x SATA cable
1 x UltraDMA 133/100/66 cable
1 x I/O shield
1 x User Manual
Form factor MicroATX form factor: 9.6 in x 7.0 in (24.4 cm x 17.8 cm)

Thank you for buying an ASUS® P5KPL-AM IN/GB motherboard!
Before you start installing the motherboard, and hardware devices on it, check the items in
your motherboard package. Refer to page ix for the list of accessories.
If any of the items is damaged or missing, contact your retailer.
1.1 Before you proceed
Take note of the following precautions before you install motherboard components or change
any motherboard settings.
• Unplug the power cord from the wall socket before touching any component.
• Before handling components, use a grounded wrist strap or touch a safely grounded
object or a metal object, such as the power supply case, to avoid damaging them due to
static electricity
• Hold components by the edges to avoid touching the ICs on them.
• Whenever you uninstall any component, place it on a grounded antistatic pad or in the
bag that came with the component.
• Before you install or remove any component, ensure that the ATX power supply is
switched off or the power cord is detached from the power supply. Failure to do so may
cause severe damage to the motherboard, peripherals, or components.
Chapter 1
Product introduction
Onboard LED
This motherboard comes with a standby power LED that lights up to indicate that the system
is ON, in sleep mode, or in soft-off mode. This is a reminder that you must shut down
the system and unplug the power cable before removing or plugging in any motherboard
component. The illustration below shows the location of the onboard LED.
1-1 ASUS P5KPL-AM IN/GB

Place this side towards
the rear of the chassis.
Place six screws into the holes indicated by circles to secure the motherboard to the
chassis. DO NOT overtighten the screws! Doing so can damage the motherboard.
1.2.2 Layout contents
Connectors/Jumpers/Slots/LED Page Connectors/Jumpers/Slots/LED Page
1. ATX power connectors (24-pin EATXPWR, 4-pin ATX12V) 1-13 9. IDE connector (40-1 pin PRI_IDE) 1-11
2. CPU fan connector (4-pin CPU_FAN) 1-12 10. USB connectors (10-1 pin USB56, USB78) 1-13
3. Keyboard/mouse power (3-pin PS2_USBPW1-4) 1-9 11. USB device wake-up (3-pin USBPW 5-8) 1-7
4. LGA775 CPU socket 1-3 12. System panel connector (10-1 pin F_PANEL) 1-14
5. DDR2 DIMM slots 1-3 13. Standby power LED (SB_PWR) 1-1
6. Serial ATA connectors (7-pin SATA1, SATA2) 1-10 14. Front panel audio connector (10-1 pin AAFP) 1-12
7. Clear RTC RAM (3-pin CLRTC) 1-8 15. PCIe x16 / PCI slots 1-7
8. Internal speaker connector (4-pin SPEAKER) 1-11
1.2 Motherboard overview
1.2.1 Motherboard layout
Ensure that you install the motherboard into the chassis in the correct orientation. The edge
with external ports goes to the rear part of the chassis.
Chapter 1: Product introduction 1-2

1.3 Central Processing Unit (CPU)
This motherboard comes with a surface mount LGA775 socket designed for the Intel®
Core™2 Extreme / Core™2 Quad / Core™2 Duo / Pentium® D / Pentium® 4 / Celeron® E1000
Series and Celeron®400 Series processors.
Channel Sockets
Channel A DIMM_A1
Channel B DIMM_B1
1.4 System memory
1.4.1 Overview
The motherboard comes with two Double Data Rate 2 (DDR2) Dual Inline Memory Modules
(DIMM) sockets. The gure illustrates the location of the DDR2 DIMM sockets:
Ensure that all power cables are unplugged before installing the CPU.
• Upon purchase of the motherboard, ensure that the PnP cap is on the socket and the
socket contacts are not bent. Contact your retailer immediately if the PnP cap is missing,
or if you see any damage to the PnP cap/socket contacts/motherboard components.
ASUS will shoulder the cost of repair only if the damage is shipment/transit-related.
• Keep the cap after installing the motherboard. ASUS will process Return Merchandise
Authorization (RMA) requests only if the motherboard comes with the cap on the
LGA775 socket.
• The product warranty does not cover damage to the socket contacts resulting from
incorrect CPU installation/removal, or misplacement/loss/incorrect removal of the PnP
cap.
1.4.2 Memory congurations
You may install 512MB, 1GB, 2GB, and 4GB unbuffered non-ECC DDR2 DIMMs into the
DIMM sockets.
This motherboard supports Intel®Hyper-Threading Technology and Enhanced Intel
SpeedStep®Technology (EIST).
1-3 ASUS P5KPL-AM IN/GB

• You may install varying memory sizes in Channel A and Channel B. The system maps
the total size of the lower-sized channel for the dual-channel conguration. Any excess
memory from the higher-sized channel is then mapped for single-channel operation.
• Always install DIMMs with the same CAS latency. For optimum compatibility, we
recommend that you obtain memory modules from the same vendor.
• Due to the memory address limitation on 32-bit Windows®OS, when you install 4GB
or more memory on the motherboard, the actual usable memory for the OS can be
about 3GB or less. For effective use of memory, we recommend that you do any of the
following:
- Install a maximum of 3GB system memory if you are using a 32-bit WindowsInstall a maximum of 3GB system memory if you are using a 32-bit Windows®
OS.
- Use a 64-bit WindowsWindows®OS if you want to install 4GB or more memory on the
motherboard.
• This motherboard does not support DIMMs made up of 256 megabits (Mb) chips or less.
The motherboard supports up to 4GB memory modules on Windows® XP Professional x64
and Vista x64 editions.
P5KPL-AM IN/GB Motherboard Qualied Vendors Lists (QVL)
Vendor Part No. Size SS/
DS
Chip
Brand Chip NO. CL
DIMM
support
A* B*
A-Data M2OAD5G3H3160Q1C52 512MB SS ADATA AD29608A8A-3EG20813 • •
A-Data M2OAD5G314170Q1C58 1024MB DS ADATA AD29608A8A-3EG80814 • •
A-Data M2OAD5H3J4170I1C53 2048MB DS ADATA AD20908A8A-3EG 30724 • •
Apacer 78.91G92.9K5 512MB SS Apacer AM4B5708JQJS7E0751C 5 • •
Apacer AU 512E667C5KBGC 512MB SS Apacer AM4B5708GQJS7E06332F 5 • •
Apacer AU 512E667C5KBGC 512MB SS Apacer AM4B5708MIJS7E0627B 5 • •
Apacer 78.01G9O.9K5 1024MB SS Apacer AM4B5808CQJS7E0751C 5 • •
Apacer AU01GE667C5KBGC 1024MB DS Apacer AM4B5708GQJS7E0636B • •
Apacer AU01GE667C5KBGC 1024MB DS Apacer AM4B5708MIJS7E0627B 5 • •
Apacer AM4B5808CQJS7E0749B 2048MB DS Apacer 78.A1G9O.9K4 5 • •
Corsair VS 512MB667D2 512MB DS Corsair MIII0052532M8CEC • •
Corsair VS1GB667D2 1024MB DS Corsair MID095D62864M8CEC • •
Corsair XMS2-5400 1024MB DS Corsair Heat-Sink Package 4 • •
G.SKILL F2-5400PHU2-2GBNT 2048MB(2 x 1GB) DS G.SKILL D2 64M8CCF 0815 C7173S 5-5-5-15 • •
G.SKILL F2-5300CL5D-4GBMQ 4096MB(2 x 2GB) DS G.SKILL Heat-Sink Package SN:8151030036559 5-5-5-15 • •
GEIL GX21GB5300SX 1024MB DS GEIL Heat-Sink Package 3 • •
GEIL GX22GB5300LX 2048MB DS GEIL Heat-Sink Package 5 • •
GEIL GX24GB5300LDC 2048MB DS GEIL Heat-Sink Package 5 • •
Kingmax KLCC28F-A8KB5 512MB SS Kingmax KKEA88B4LAUG-29DX • •
Kingmax KLCD48F-A8KB5 1024MB DS Kingmax KKEA88B4LAUG-29DX • •
Kingston KVR667D2N5/ 512 512MB SS Kingston SO1237650821 SBP D6408TR4CGL25
USL074905PECNB 5 • •
Kingston KVR667D2N5/1G 1024MB DS Kingston SO1280420822 SOP D6408TR4CGL25
USL156304PECXA 5 • •
Kingston KVR667D2N5/2G 2048MB DS Micron 7RE22 D9HNL 5-5-5-15 • •
Kingston KVR667D2N5/2G 2048MB DS ELPIDA E1108ACBG-8E-E 0813A90CC 5 • •
Micron MT8HTF12864AY-667E1 1024MB SS Micron D9HNL 7ZE17 5 • •
PSC AL6E8E63J-6E1 512MB SS PSC A3R12E3JFF717B9A00 5 • •
PSC AL7E8F73C-6E1 1024MB SS PSC A3R1GE3CFF734MAA0J 5 • •
PSC AL6E8E63J-6E1 1024MB DS PSC A3R12E3JFF717B9A01 5 • •
PSC AL8E8F73C-6E1 2048MB DS PSC A3R1GE3CFF733MAA00 5 • •
Samsung M378T5263AZ3-CE6 4096MB DS Samsung K4T2G084QA-HCE6 • •
Super Talent T667UB1GV 1024MB DS Super
Talent PG 64M8-800 0750 5 • •
Transcend JM667QLU-1G 1024MB SS Transced TQ243PCF8T0838 5 • •
Transcend JM667QLJ-1G 1024MB DS Elpida E5108AJBG-6E-E 5 • •
Transcend JM667QLU-2G 2048MB DS Transced TQ243PCF8T0834 5 • •
Twinmos 8D-A3JK5MPETP 512MB SS PSC A3R12E3GEF633ACAOY 5 • •
DDR2-667MHz capability
Chapter 1: Product introduction 1-4

DDR2-800MHz capability
(continued on the next page)
Vendor Part No. Size SS/
DS Chip Brand Chip NO. CL
DIMM
support
A* B*
A-Data M2GVD6G3H3160Q1E52 512MB SS VDATA VD29608A8A-25EG20813 • •
A-Data M2OAD6G3H3160Q1E58 512MB SS ADATA AD29608A8A-25EG80812 • •
A-Data AD2800E001GOU 2048MB(2 x 1GB) SS N/A Heat-Sink Package 4-4-4-12 • •
A-Data M2GVD6G314170Q1E58 1024MB DS VDATA VD29608A8A-25EG80813 • •
A-Data M2OAD6G314170Q1E58 1024MB DS ADATA AD29608A8A-25EG80810 • •
A-Data AD2800E002GOU 4096MB(2 x 2GB) DS N/A Heat-Sink Package 4-4-4-12 • •
Apacer 78.91G91.9K5 512MB SS Apacer AM4B5708JQJS8E0751C 5 • •
Apacer 78.01GA0.9K5 1024MB SS Apacer AM4B5808CQJS8E0749D 5 • •
Apacer 78.A1GA0.9K4 2048MB DS Apacer AM4B5808CQJS8E0740E 5 • •
Apacer 78.A1GA0.9K4 2048MB DS Apacer AM4B5808CQJS8E0747D 5 • •
Corsair CM2X1024-6400 1024MB DS Corsair Heat-Sink Package • •
Corsair XMS2-6400 1024MB DS Corsair Heat-Sink Package 4 • •
Corsair XMS2-6400 1024MB DS Corsair Heat-Sink Package 5 • •
Corsair CM2X2048-6400C5DHX 4096MB(2 x 2GB) DS N/A Heat-Sink Package 5 • •
Corsair CM2X2048-6400C5 4096MB(2 x 2GB) DS N/A Heat-Sink Package 5 • •
Crucial BL12864AA804.8FE5(EPP) 2048MB(2 x 1GB) SS N/A Heat-Sink Package • •
Crucial BL12864AL804.8FE5(EPP) 2048MB(2 x 1GB) SS N/A Heat-Sink Package 4 • •
G.SKILL F2-6400CL5D-1GBNQ 512MB SS G.SKILL Heat-Sink Package SN:8151030036642 5-5-5-15 • •
G.SKILL F2-6400CL4D-2GBPK 1024MB DS G.SKILL Heat-Sink Package 4 • •
G.SKILL F2-6400CL5D-2GBNQ 1024MB DS G.SKILL Heat-Sink Package 5 • •
G.SKILL F2-6400CL4D-4GBPK 2048MB DS G.SKILL Heat-Sink Package 4 • •
G.SKILL F2-6400CL5D-4GBPQ 2048MB DS G.SKILL Heat-Sink Package 5 • •
G.SKILL F2-6400CL6Q-16GMQ 4096MB DS N/A Heat-Sink Package 5 • •
GEIL GB22GB6400C4DC 1024MB DS GEIL GL2L64M088BA30EB 5 • •
GEIL GB22GB6400C5DC 1024MB DS GEIL GL2L64M088BA30EB 5 • •
GEIL GB24GB6400C4QC 1024MB DS GEIL GL2L64M088BA30EB 4 • •
GEIL GB24GB6400C5QC 1024MB DS GEIL GL2L64M088BA30EB 5 • •
GEIL GE22GB800C4DC 1024MB DS GEIL Heat-Sink Package 4 • •
GEIL GE22GB800C5DC 1024MB DS GEIL Heat-Sink Package 5 • •
GEIL GE24GB800C4QC 1024MB DS GEIL Heat-Sink Package 4 • •
GEIL GE24GB800C5QC 1024MB DS GEIL Heat-Sink Package 5 • •
GEIL GX22GB6400DC 1024MB DS GEIL Heat-Sink Package 5 • •
GEIL GX22GB6400UDC 1024MB DS GEIL Heat-Sink Package 4 • •
GEIL GB24GB6400C4DC 2048MB DS GEIL GL2L128M88BA25AB 4 • •
GEIL GB24GB6400C5DC 2048MB DS GEIL GL2L128M88BA25AB 5 • •
GEIL GB28GB6400C4QC 2048MB DS GEIL GL2L128M88BA25AB 4 • •
GEIL GB28GB6400C5QC 2048MB DS GEIL GL2L128M88BA25AB 5 • •
GEIL GE24GB800C4DC 2048MB DS GEIL Heat-Sink Package 4 • •
GEIL GE24GB800C5DC 2048MB DS GEIL Heat-Sink Package 5 • •
GEIL GE28GB800C4QC 2048MB DS GEIL Heat-Sink Package 4 • •
GEIL GE28GB800C5QC 2048MB DS GEIL Heat-Sink Package 5 • •
GEIL GX22GB6400CUSC 2048MB DS GEIL Heat-Sink Package 4 • •
GEIL GX22GB6400LX 2048MB DS GEIL Heat-Sink Package 5 • •
GEIL GX24GB6400DC 2048MB DS GEIL Heat-Sink Package 5 • •
Kingmax KLDC28F-A8KI5 512MB SS Kingmax KKA8FF1XF-JFS-25A • •
Kingmax KKB8FFBXF-CFA-25U 1024MB SS Kingmax KLDD48F-B8KB5 • •
kingmax KLDE88F-B8KB5 2048MB DS kingmax KKB8FFBXF-CFA-25U • •
Kingston KVR800D2N6/ 512 512MB SS Elpida E5108AJBG-8E-E 6• •
Kingston KHX6400D2LLK2/1GN 1024M(2 x 512MB) SS Kingston Heat-Sink Package 4-4-4-12 • •
Kingston KHX6400D2LL/1G 1024MB DS Kingston Heat-Sink Package 4-4-4-12 • •
Kingston KVR800D2N5/1G 1024MB DS Kingston D6408TR4CGL25USL362406PECXA 5 • •
Kingston KVR800D2N6/1G 1024MB DS Elpida E5108AJBG-8E-E • •
Kingston KHX6400D2K2/2G 2048MB(2 x 1GB) DS N/A Heat-Sink Package 5-5-5-15 • •
Kingston 461625.010819 PTGC 2048MB DS Kingston KVR800D2N6/2G 6 • •
Kingston KHX6400D2/2G 2048MB DS Kingston Heat-Sink Package 5 • •
Kingston KVR800D2N5/2G 2048MB DS Elpida E1108ACBG-8E-E 5 • •
Kingston KVR800D2N6/4G 4096MB DS Elpida E2108ABSE-8G-E 6 • •
OCZ OCZ2G800R22GK 1024MB DS OCZ Heat-Sink Package 5 • •
OCZ OCZ2P800R22GK 1024MB DS OCZ Heat-Sink Package 4 • •
OCZ OCZ2RPR8002GK 1024MB DS OCZ Heat-Sink Package 4 • •
OCZ OCZ2VU8004GK 1024MB DS OCZ Heat-Sink Package 6• •
OCZ OCZ2F8004GK 2048MB DS N/A Heat-Sink Package 5 • •
OCZ OCZ2P8004GK 4096MB(2 x 2GB) DS N/A Heat-Sink Package 5 • •
PSC AL7E8F73C-8E1 1024MB SS PSC A3R1GE3CFF734MAA0E 5 • •
PSC AL8E8F73C-8E1 2048MB DS PSC A3R1GE3CFF734MAA0E 5 • •
PSC SHG772-AA3G 2048MB DS PSC PL8E8F73C-8E1 • •
PSC XCP271A3G-A 2048MB DS PSC PL8E8G73E-8E1 • •
Qimonda HYS64T256020EU-2.5-C2 2048MB DS Qimonda HY818T1G800C2F-2.5 5 • •
Samsung K4T51083QG-HCF7 512MB SS Qimonda M378T6553GZS-CF7 6 • •
Samsung K4T1G084QQ-HCF7 1024MB SS Qimonda M378T2863QZS-CF7 6 • •
Samsung K4T51083QG-HCF7 1024MB DS Samsung M378T2953GZ3-CF7 6 • •
Samsung K4T1G084QQ-HCF7 2048MB DS Samsung M37875663QZ3-CF7 6 • •
1-5 ASUS P5KPL-AM IN/GB

Vendor Part No. Size SS/
DS Chip Brand Chip NO. CL
DIMM
support
A* B*
A-Data AD21066E002GU 4096MB(2 x 2GB) DS N/A Heat-Sink Package 5-5-5-15 • •
Apacer 78.0AG9S.9K4 2048MB(2 x 1GB) DS N/A Heat-Sink Package 5-5-5-15 •
Apacer 78.AAGAL.9KZ 4096MB(2 x 2GB) DS N/A Heat-Sink Package 5-5-5-15 • •
Corsair CM2X1024-8500C5 1024MB DS Corsair Heat-Sink Package • •
Crucial BL12864AA1065.8FE5(epp) 2048MB(2 x 1GB) SS N/A Heat-Sink Package • •
G.SKILL F2-8500CL5S-1GBPK 1024MB DS N/A Heat-Sink PackageSN:815130037562 5-5-5-15 •
G.SKILL F2-8500CL5D-2GBPK 2048MB(2 x 1GB) DS N/A Heat-Sink Package 5-5-5-15 • •
G.SKILL F2-8500CL5D-4GBPK 4096MB(2 x 2GB) DS N/A Heat-Sink Package 5-5-5-15 • •
GEIL GB22GB8500C5DC 1024MB SS GEIL GL2L128M88BA25AB 5 • •
GEIL GB24GB8500C5QC 1024MB SS GEIL GL2L128M88BA25AB 5 • •
GEIL GE22GB1066C5DC 1024MB SS GEIL Heat-Sink Package 5 • •
GEIL GE24GB1066C5QC 1024MB SS GEIL Heat-Sink Package 5 • •
GEIL GB24GB8500C5DC 2048MB DS GEIL GL2L128M88BA25AB 5 • •
GEIL GE24GB1066C5DC 2048MB DS GEIL Heat-Sink Package 5 • •
GEIL GX24GB8500C5UDC 4096MB(2 x 2GB) DS N/A Heat-Sink Package 5 • •
Kingston KHX8500D2/ 512 512MB SS Kingston Heat-Sink Package 5-5-5-18 • •
Kingston KHX8500D2K2/1GN(EPP) 1024MB(2 x 512MB) SS Kingston Heat-Sink Package 5-5-5-18 • •
Kingston KHX8500D2K2/2GN(EPP) 1024MB DS Kingston Heat-Sink Package 5-5-5-18 • •
OCZ OCZ2N10662GK 2048MB(2 x 1GB) DS OCZ Heat-Sink Package 004820806001601-2 • •
OCZ OCZ2N1066SR2DK(Epp) 2048MB(2 x 1GB) DS OCZ Heat-Sink Package 004820806001601-2 5-5-5-15 • •
OCZ OCZ2N1066SR2DK(EPP) 2048MB(2 x 1GB) DS OCZ Heat-Sink Package 004820806001601-2 • •
OCZ OCZ2RPR10664GK 4096MB(2 x 2GB) DS N/A Heat-Sink Package 5-5-5-15 • •
Qimonda HYS64T128000EU-1.9-C2 1024MB DS Qimonda HYB18T1G800C2F-1.9FSS25253 • •
Transcend TX1066QLU-2GK 2048MB(2 x 1GB) SS N/A Heat-Sink Package 5 •
Transcend TX1066QLJ-2GK 2048MB(2 x 1GB) DS Transcend Heat-Sink Package 5 • •
Transcend TX1066QLU-4GK 4096MB(2 x 2GB) DS Transcend Heat-Sink Package 5 • •
DDR2-1066MHz capability
Visit the ASUS website at www.asus.com for the latest QVL.
DDR2-800MHz capability
SS: Single-sided / DS: Double-sided
DIMM support:
• A*: Supports one module inserted into either slot as Single-channel memory
conguration.
• B*: Supports one pair of modules inserted into both the yellow slots as one pair of
Dual-channel memory conguration.
Samsung M378T5263AZ3-CF7 4096MB DS Samsung K4T2G084QA-HCF7 • •
Super Talent T800UB1GC4 1024MB DS Super Talent Heat-Sink Package 4 • •
Transcend TS64MLQ64V8J 512MB SS Micron 7HD22 D9GMH 5 • •
Transcend JM800QLU-1G 1024MB SS Transced TQ1243PCF8 5 • •
Transcend TS128MLQ64V8U 1024MB SS ELPIDA E1108ACBG-8E-E 5 • •
Transcend JM800QLJ-1G 1024MB DS Transced TQ123PJF8F0801 5 • •
Transcend JM800QLJ-1G 1024MB DS Transcend TQ123YBF8 T0747 5 • •
Transcend TS128MLQ64V8J 1024MB DS Mircon 7HD22D9GMH 5 • •
Transcend JM800QLU-2G 2048MB DS Transced TQ243PCF8 5 • •
Transcend TS256MLQ64V8U 2048MB DS Elpida E1108ACBG-8E-E 5 • •
Vendor Part No. Size SS/
DS Chip Brand Chip NO. CL
DIMM
support
A* B*
Chapter 1: Product introduction 1-6

1.5 Expansion slots
In the future, you may need to install expansion cards. Refer to the technical documentation
that comes with your expansion card for installation details.
Ensure to unplug the power cord before adding or removing expansion cards. Failure to do
so may cause you physical injury and damage motherboard components.
1.6 Jumpers
1. USB device wake-up (3-pin USBPW5-8)
Set this jumper to +5V to wake up the computer from S1 sleep mode (CPU stopped,
DRAM refreshed, system running in low power mode) using the connected USB
devices. Set this jumper to +5VSB to wake up from S3 and S4 sleep modes (no power
to CPU, DRAM in slow refresh, power supply in reduced power mode). The
USBPW5-8 jumper is for the internal USB connectors that you can connect to addition
USB ports.
• The USB device wake-up feature requires a power supply that can provide 500mA on
the +5VSB lead for the USB port. Otherwise, the system will not power up.
• The total current consumed must NOT exceed the power supply capability (+5VSB)
whether under normal condition or in sleep mode.
1.5.1 PCI slots
The PCI slot supports cards such as LAN cards, SCSI cards, USB cards, and other cards
that comply with the PCI specications.
1.5.2 PCI Express x16 slot
This motherboard supports a PCI Express x16 graphics card that complies with the PCI
Express specications.
1-7 ASUS P5KPL-AM IN/GB

2. Clear RTC RAM (3-pin CLRTC)
This jumper allows you to clear the Real Time Clock (RTC) RAM in CMOS. You can
clear the CMOS memory of date, time, and system setup parameters by erasing
the CMOS RTC RAM data. The onboard button cell battery powers the RAM data in
CMOS, which include system setup information such as the system passwords.
Except when clearing the RTC RAM, never remove the cap on CLRTC jumper default
position. Removing the cap will cause system boot failure!
To erase the RTC RAM:
1. Turn OFF the computer and unplug the power cord.
2. Move the jumper cap from pins 1-2 (default) to pins 2-3. Keep the cap on pins 2-3
for about 5-10 seconds, then move the cap back to pins 1-2.
3. Plug the power cord and turn ON the computer.
4. Hold down the <Del> key during the boot process and enter BIOS setup to reenter
data.
• If the steps above do not help, remove the onboard battery and move the jumper again
to clear the CMOS RTC RAM data. After clearing the CMOS, reinstall the battery.
• You do not need to clear the RTC when the system hangs due to overclocking. For
system failure due to overclocking, use the CPU Parameter Recall (C.P.R) feature. Shut
down and reboot the system so the BIOS can automatically reset parameter settings to
default values.
Chapter 1: Product introduction 1-8

1.7 Connectors
1.7.1 Rear panel ports
3. Keyboard/mouse power (3-pin PS2_USBPW1-4)
This jumper allows you to enable or disable the keyboard/mouse and USB port 1-4
wake-up feature. When you set this jumper to pins 2-3 (+5VSB), you can wake up the
computer by pressing a key on the keyboard (the default is the Space Bar), clicking
the mouse, or using a USB device. This feature requires an ATX power supply that can
supply at least 1A on the +5VSB lead, and a corresponding setting in the BIOS. The
PS2_USBPW1-4 jumper is for the rear USB ports.
3 42
57 6
1
98
10
1. PS/2 mouse port (green). This port is for a PS/2 mouse.
2. LAN (RJ-45) port. This port allows Gigabit connection to a Local Area Network (LAN)
through a network hub. Refer to the table below for the LAN port LED indications.
LAN port LED indications
Activity/Link LED Speed LED
Status Description Status Description
OFF No link OFF 10Mbps connection
ORANGE Linked ORANGE 100Mbps connection
BLINKING Data activity GREEN 1Gbps connection LAN port
SPEED
LED
ACT/LINK
LED
1-9 ASUS P5KPL-AM IN/GB

3. Line In port (light blue). This port connects to the tape, CD, DVD player, or other
audio sources.
4. Line Out port (lime). This port connects to a headphone or a speaker. In 4-channel
and 6-channel conguration, the function of this port becomes Front Speaker Out.
5. Microphone port (pink). This port connects to a microphone.
Refer to the audio conguration table below for the function of the audio ports in 2, 4, or
6-channel conguration.
Audio 2, 4, 6-channel conguration
Port Headset 2-channel 4-channel 6-channel
Light Blue Line In Rear Speaker Out Rear Speaker Out
Lime Line Out Front Speaker Out Front Speaker Out
Pink Mic In Mic In Bass/Center
6. USB 2.0 ports 1 and 2. These two 4-pin Universal Serial Bus (USB) ports connect to
USB 2.0 devices.
7. USB 2.0 ports 3 and 4. These two 4-pin Universal Serial Bus (USB) ports connect to
USB 2.0 devices.
8. Video Graphics Adapter (VGA) port. This 15-pin port is for a VGA monitor or other
VGA-compatible devices.
9. COM port. This 9-pin COM port is for pointing devices or other serial devices.
10. PS/2 keyboard port (purple). This port is for a PS/2 keyboard.
1.7.2 Internal connectors
1. Serial ATA connectors (7-pin SATA1, SATA2)
These connectors are for the Serial ATA signal cables for Serial ATA 3Gb/s hard disk
drives and optical disk drives. The Serial ATA 3Gb/s is backward compatible with the
Serial ATA 1.5Gb/s specication. The data transfer rate of the Serial ATA 3Gb/s is faster
than that of the standard parallel ATA (133Mb/s).
Install the Windows®Service Pack 1 before using Serial ATA.
Chapter 1: Product introduction 1-10

2. IDE connector (40-1 pin PRI_IDE)
The onboard IDE connector is for the Ultra DMA 133/100/66 signal cable. There are
three connectors on each Ultra DMA 133/100/66 signal cable: blue, black, and gray.
Connect the blue connector to the motherboard’s IDE connector, then select one of the
following modes to congure your device.
Driver Jumper setting Mode of device(s) Cable connector
Single device Cable-Select or Master - Black
Two devices
Cable-Select Master Black
Slave Gray
Master Master Black or gray
Slave Slave
Pin 20 on the IDE connector is removed to match the covered hole on the Ultra DMA cable
connector. This prevents incorrect insertion when you connect the IDE cable.
• Use the 80-conductor IDE cable for Ultra DMA 133/100/66 IDE devices.
• If any device jumper is set to Cable-Select, ensure that all other device jumpers have
the same setting.
3. Speaker connector (4-pin SPEAKER)
This 4-pin connector is for the chassis-mounted system warning speaker. The speaker
allows you to hear system beeps and warnings.
1-11 ASUS P5KPL-AM IN/GB
