Asus P5LD2-DH User manual

Motherboard
P5LD2-FM/DH/VP

ii
Copyright © 2006 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form
or by any means, except documentation kept by the purchaser for backup purposes, without the
express written permission of ASUSTeK COMPUTER INC. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modied or
altered, unless such repair, modication of alteration is authorized in writing by ASUS; or (2)
the serial number of the product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS”WITHOUT WARRANTY OF ANY KIND, EITHER
EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES
OR CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE
LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES
(INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE
OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN IF ASUS HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR
ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED
FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME
WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY
ASUS. ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR
INACCURACIES THAT MAY APPEAR IN THIS MANUAL, INCLUDING THE PRODUCTS
AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered
trademarks or copyrights of their respective companies, and are used only for identication or
explanation and to the owners’ benet, without intent to infringe.
E2934
First Edition
Nov. 2006

iii
Contents
Notices vi
Safety information .........................................................................................................................vii
About this guide............................................................................................................................viii
Typography ....................................................................................................................................... ix
P5LD2-FM/DH/VP specications summary............................................................................. x
Product introduction 1
1.1 Welcome!............................................................................................................................ 2
1.2 Special features................................................................................................................ 2
1.2.1 Product highlights ...................................................................................... 2
1.3 Before you proceed ........................................................................................................ 5
1.4 Motherboard overview ................................................................................................. 6
1.4.1 Placement direction................................................................................... 6
1.4.2 Screw holes ................................................................................................... 6
1.4.3 Motherboard layout................................................................................... 7
1.5 Central Processing Unit (CPU)..................................................................................... 8
1.5.1 Installling the CPU ...................................................................................... 8
1.5.2 Installling the CPU heatsink and fan ..................................................11
1.5.3 Uninstalling the CPU heatsink and fan..............................................13
1.6 System memory.............................................................................................................15
1.6.1 Overview......................................................................................................15
1.6.2 Memory congurations..........................................................................15
1.6.3 Installing a DIMM ......................................................................................17
1.6.4 Removing a DIMM ....................................................................................17
1.7 Expansion slots...............................................................................................................18
1.7.1 Installing an expansion card .................................................................18
1.7.2 Conguring an expansion card............................................................18
1.7.3 Interrupt assignments.............................................................................19
1.7.4 PCI slots.........................................................................................................20
1.7.5 PCI Express x16 .........................................................................................20
1.7.6 PCI Express x1 ............................................................................................20
1.8 Jumpers ............................................................................................................................21
1.9 Connectors ......................................................................................................................24
1.9.1 Rear panel connectors ............................................................................24
1.9.2 Internal connectors ..................................................................................25

iv
Contents
BIOS setup 1
2.1 Managing and updating your BIOS.......................................................................... 2
2.1.1 Creating a bootable oppy disk ............................................................ 2
2.1.2 ASUS EZ Flash utility .................................................................................. 3
2.1.3 AFUDOS utility ............................................................................................. 4
2.1.4 ASUS CrashFree BIOS 2 utility................................................................. 6
2.2 BIOS setup program....................................................................................................... 7
2.2.1 BIOS menu screen....................................................................................... 8
2.2.2 Menu bar........................................................................................................ 8
2.2.3 Navigation keys ........................................................................................... 8
2.2.4 Menu items.................................................................................................... 9
2.2.5 Sub-menu items .......................................................................................... 9
2.2.6 Conguration elds.................................................................................... 9
2.2.7 Pop-up window ........................................................................................... 9
2.2.8 Scroll bar......................................................................................................... 9
2.2.9 General help.................................................................................................. 9
2.3 Main menu.......................................................................................................................10
2.3.1 System Time [xx:xx:xxxx] ........................................................................10
2.3.2 System Date [Day xx/xx/xxxx] ..............................................................10
2.3.3 Legacy Diskette A [Disabled] ................................................................10
2.3.4 Primary and SATA IDE Master/Slave ...................................................11
2.3.5 IDE Conguration......................................................................................12
2.3.6 System Information..................................................................................14
2.4 Advanced menu.............................................................................................................15
2.4.1 USB Conguration ....................................................................................15
2.4.3 CPU Conguration....................................................................................17
2.4.4 Chipset..........................................................................................................19
2.4.5 Onboard Devices Conguration..........................................................20
2.4.6 PCI PnP..........................................................................................................21
2.5 Power menu ....................................................................................................................23
2.5.1 Suspend Mode [S3 only].........................................................................23
2.5.2 ACPI 2.0 Support [Yes].............................................................................23
2.5.3 ACPI APIC Support [Enabled]................................................................23
2.5.4 APM Conguration...................................................................................24

v
Contents
2.5.5 Hardware Monitor.....................................................................................26
2.6 Boot menu .......................................................................................................................28
2.6.1 Boot Settings Conguration .................................................................28
2.6.3 Security.........................................................................................................30
2.7 Exit menu .........................................................................................................................32

vi
Notices
Federal Communications Commission Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received including
interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
manufacturer’s instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment o and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for radio noise
emissions from digital apparatus set out in the Radio Interference
Regulations of the Canadian Department of Communications.
This class B digital apparatus complies with Canadian
ICES-003.
The use of shielded cables for connection of the monitor to the graphics
card is required to assure compliance with FCC regulations. Changes
or modications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate
this equipment.

vii
Safety information
Electrical safety
• To prevent electrical shock hazard, disconnect the power cable from
the electrical outlet before relocating the system.
• When adding or removing devices to or from the system, ensure that
the power cables for the devices are unplugged before the signal
cables are connected. If possible, disconnect all power cables from the
existing system before you add a device.
• Before connecting or removing signal cables from the motherboard,
ensure that all power cables are unplugged.
• Seek professional assistance before using an adapter or extension
cord. These devices could interrupt the grounding circuit.
• Make sure that your power supply is set to the correct voltage in your
area. If you are not sure about the voltage of the electrical outlet you
are using, contact your local power company.
• If the power supply is broken, do not try to fix it by yourself. Contact
a qualified service technician or your retailer.
Operation safety
• Before installing the motherboard and adding devices on it, carefully
read all the manuals that came with the package.
• Before using the product, make sure all cables are correctly connected
and the power cables are not damaged. If you detect any damage,
contact your dealer immediately.
• To avoid short circuits, keep paper clips, screws, and staples away from
connectors, slots, sockets and circuitry.
• Avoid dust, humidity, and temperature extremes. Do not place the
product in any area where it may become wet.
• Place the product on a stable surface.
• If you encounter technical problems with the product, contact a
qualified service technician or your retailer.
The symbol of the crossed out wheeled bin indicates that the product
(electrical and electronic equipment) should not be placed in municipal
waste. Check local regulations for disposal of electronic products.

viii
About this guide
This user guide contains the information you need when installing and
conguring the motherboard.
How this guide is organized
This manual contains the following parts:
• Chapter 1: Product introduction
This chapter describes the features of the motherboard and the
new technology it supports. This chapter also lists the hardware
setup procedures that you have to perform when installing system
components. It includes description of the jumpers and connectors on
the motherboard.
• Chapter 2: BIOS setup
This chapter tells how to change system settings through the BIOS
Setup menus. Detailed descriptions of the BIOS parameters are also
provided.

ix
Conventions used in this guide
To make sure that you perform certain tasks properly, take note of the
following symbols used throughout this manual.
Typography
DANG ER/WARNING: Information to prevent injury to yourself
when trying to complete a task.
CAUTI ON: Information to prevent damage to the components
when trying to complete a task.
NOTE: Tips and additional information to help you complete a
task.
IMPO RTANT: Instructions that you MUST follow to complete a
task.
Bo ld tex t Indicates a menu or an item to select
Italics Used to emphasize a word or a phrase
<Key> Keys enclosed in the less-than and greater-than sign means
that you must press the enclosed key
Example: <Enter> means that you must press the Enter or
Return key
<Key1+Key2+Key3> If you must press two or more keys simultaneously, the
key names are linked with a plus sign (+)
Example: <Ctrl+Alt+D>
Command Means that you must type the command exactly as shown,
then supply the required item or value enclosed in
brackets
Example: At the DOS prompt, type the command line:
afudos /i[lename]
afudos /iP5LD2FMDH.ROM

x
P5LD2-FM/DH/VP specications summary
(continued on the next page)
CPU
Chipset
Front S i d e B u s
M em or y
Expansion slots
Sto rage
Au d i o
LAN
USB
Rear panel
BIOS features
LGA775 socket for Intel® Core™2 Extreme/Core™2 Duo
/Pentium®D/Pentium®4 /Celeron® D Processors
Compatible with Intel®06/05B/05A processors
Supports Intel® next generation 65nm processors
Supports Intel®Enhanced Memory 64 Technology
(EM64T), Enhanced Intel SpeedStep®Technology (EIST),
and Intel®Hyper-Threading Technology
Northbridge: Intel®945P
Southbridge: Intel®ICH7DH
1066/800/533 MHz
Dual-channel memory architecture
4 x 240-pin DIMM sockets support up to 4GB of
unbuerred non-ECC 667/533 MHz DDR2 DIMMs
1 x PCI Express x16 slot for discrete graphics cards
1 x PCI Express x1
2 x PCI slots
Intel®ICH7DH SouthBridge supports:
- 1 x Ultra DMA 100/66/33
- 4 x Serial ATA 300Gb/s ports
ITE IDE controller supports:
- 1 x UltraDMA 100/66/33
Realtek®ALC888 8-channel Azalia CODEC
S/PDIF out interface support
Universal Audio Jack (UAJ®) Sensing Technology support
Intel®Gigabit LAN controller
Supports up to 8 USB 2.0 ports
1 x IEEE1394 connector
1 x LAN (RJ-45) port
1 x SPDIF Out port
4 x USB 2.0 ports
1 x Serial port connector (COM port)
8-channel high-denition audio I/O ports
4 Mb Flash ROM, AMI BIOS, PnP, WfM2.0, DMI2.0,
SM BIOS 2.3, ASUS EZ Flash, CrashFree BIOS2, Qfan1,
Special H/W write protection

xi
*Specications are subject to change without notice .
P5LD2-FM/DH/VP specications summary
Special features
Industry standard
Manageability
Internal
connectors
Powe r
Requirement
Form Fa c tor
ASUS Qfan1
ASUS EZ Flash
PCI 2.2, USB 2.0
WfM 2.0, DMI 2.0, WOL by PME, WOR by PME
2 x USB 2.0 connectors for 4 additional USB 2.0 ports
1 x CPU fan connector
1 x Chassis fan connector
1 x 24-pin EATX power connector
1 x 4-pin ATX 12 V power connector
1 x AUX connector
1 x Front panel high-denition audio connector
1 x S/PDIF out connector
ATX power supply (with 24-pin and 4-pin 12 V plugs)
Micro-ATX form factor: 9.6 in x 9.6 in

xii

ASUS P5LD2-FM/DH/VP 1-1
1
Product
introduction
This chapter describes the motherboard
features and the new technologies
it supports.

1-2 Chapter 1: Product introduction
1.1 Welcome!
Thank you for b uying a n ASUS®P5LD2-FM/DH/VP motherboard!
The motherboard delivers a host of new features and latest technologies,
making it another standout in the long line of ASUS quality motherboards!
Before you start installing the motherboard, and hardware devices on it,
check the items in your package with the list below.
1.2 Special features
1.2.1 Product highlights
Latest processor technology
The motherboard comes with a 775-pin surface mount Land Grid Array
(LGA) socket designed for the Intel®Pentium®D, Intel®Pentium®4 or Intel®
Celeron®processor in the 775-land package. The motherboard supports
the Intel® Pentium® 4 or Intel®Pentium®D processor with 1066/800/533
MHz Front Side Bus (FSB). The motherboard also supports the Intel®
Hyper-Threading Technology and is fully compatible with Intel®PCG
06/05B/05A processors. See page 1-8 for details.
Intel®Dual-Core Technology CPU support
The motherboard supports dual-core processors containing two physical
CPU cores with dedicated L2 caches to meet demands for more powerful
processing. See page 1-8 for details.

ASUS P5LD2-FM/DH/VP 1-3
DDR2 memory support
The motherboard supports DDR2 memory which features data transfer rates
of 667 MHz (FSB 800) or 533 MHz (FSB 1066/800) to meet the higher
bandwidth requirements of the latest 3D graphics, multimedia, and Internet
applications. The dual-channel DDR2 architecture doubles the bandwidth
of your system memory to boost system performance, eliminating
bottlenecks with peak bandwidths of up to 10.7 GB/s.
PCI Express™ interfa ce
The motherboard fully supports PCI Express, the latest I/O interconnect
technology that speeds up the PCI bus. PCI Express features point-to-point
serial interconnections between devices and allows higher clockspeeds by
carrying data in packets. This high speed interface is software compatible
with existing PCI specications. See page 1-20 for details.
64-bit CPU support
The motherboard supports 64-bit processors that provides
high-performance computing and faster memory access required for
memory and data intensive applications.
Serial ATA technology
The motherboard supports the Serial ATA technology through the Serial ATA
interfaces and the Intel®ICH7DH chipset. The SATA specication allows
for thinner, more exible cables with lower pin count, reduced voltage
requirement, and up to 300 MB/s data transfer rate.
Temperature, fan, and voltage monitoring
The CPU temperature is monitored by the ASIC (integrated in the Winbond
Super I/O) to prevent overheating and damage. The system fan rotations
per minute (RPM) is monitored for timely failure detection. The ASIC
monitors the voltage levels to ensure stable supply of current for critical
components. See pages 2-32 and 2-33 for details.

1-4 Chapter 1: Product introduction
8-channel high definition audio
The onboard Realtek®ALC888 8-channel high-denition audio CODEC provides 192 KHz/
24-bit audio output, jack-sensing and restasking functions. With the 8-channel audio
ports and S/PDIF interfaces, you can connect your computer to home theater decoders
to produce crystal-clear digital audio.
S/PDIF digital sound ready
The motherboard supports the S/PDIF Out function through the S/PDIF interfaces at
midboard. The S/PDIF technology turns your computer into a high-end entertainment
system with digital connectivity to powerful audio and speaker systems. See page 1-27 for
details.
Temperature, fan, and voltage monitoring
The CPU temperature is monitored by the ASIC (integrated in the Winbond Super I/O)
to prevent overheating and damage. The system fan rotations per minute (RPM) is
monitored for timely failure detection. The ASIC monitors the voltage levels to ensure
stable supply of current for critical components. See pages 2-32 and 2-33 for details.

ASUS P5LD2-FM/DH/VP 1-5
1.3 Before you proceed
Take note of the following precautions before you install motherboard
components or change any motherboard settings.
• Unplug the power cord from the wall socket before touching any
component.
• Use a grounded wrist strap or touch a safely grounded object or
to a metal object, such as the power supply case, before handling
components to avoid damaging them due to static electricity
• Hold components by the edges to avoid touching the ICs on them.
• Whenever you uninstall any component, place it on a grounded
antistatic pad or in the bag that came with the component.
• Befo re you install or re m ove any component, ensure
that the AT X power supply is switched off or the power
cord is detached from the power supply. Failure to do so
may cause severe damage to the motherboard, peripherals, and/or
components.

1-6 Chapter 1: Product introduction
1.4 Motherboard overview
Before you install the motherboard, study the conguration of your chassis
to ensure that the motherboard ts into it.
Make sure to unplug the power cord before installing or removing the
motherboard. Failure to do so can cause you physical injury and damage
motherboard components.
Do not overtighten the screws! Doing so can damage the motherboard.
1.4.1 Placement direction
When installing the motherboard, make sure that you place it into the
chassis in the correct orientation. The edge with external ports goes to the
rear part of the chassis as indicated in the image below.
1.4.2 Screw holes
Place eight (8) screws into the holes indicated by circles to secure the
motherboard to the chassis.
Place this side towards
the rear of the chassis
®
P5LD2-FM/DH/VP

ASUS P5LD2-FM/DH/VP 1-7
1.4.3 Motherboard layout
Below:
Center/Subwoofer
Center:
Side Speaker Out
Top:Rear Speaker Out
CR2032 3V
Lithium Cell
CMOS Power
Super
I/O
A
TX12V
FLOPPY
DDR2 DIMM_A1 (64 bit,240-pin module)
F_PANEL1
USB56IE1394_2 USB78
PCI1
AAFP
Intel
®
945P
Intel
®
ICH7DH
DDR2 DIMM_A2 (64 bit,240-pin module)
DDR2 DIMM_B1 (64 bit,240-pin module)
DDR2 DIMM_B2 (64 bit,240-pin module)
CHA_FAN
CPU_FAN
PRI_IDE
EATXPWR
PCI2
LGA775
Below:Mic In
Center:Line Out
Top:Line In
PCIEX16
PCIEX1_1
®
P5LD2-FM/DH/VP
SATA4
SATA3
SATA2
SATA1
ALC888
SPDIF_O1
VIA
6308S
Intel 82573L
Phy
PLED1
CLRTC1
BIOS_R
BIOS_C
USBPW56
USBPW78
USBPW12
USBPW34
COM1
SPDIF_O2
LAN_USB34
F_USB12
24.5cm (9.6in)
24.5cm (9.6in)
BUZZ
BIOS
Flash
ROM
AUX

1-8 Chapter 1: Product introduction
1.5.1 Installling the CPU
To install a CPU:
1. Locate the CPU socket on the motherboard.
1.5 Central Processing Unit (CPU)
The motherboard comes with a surface mount LGA775 socket designed for
the Intel®Pentium®4 processor in the 775-land package.
• Your boxed Intel®Pentium®4 LGA775 processor package should
come with installation instructions for the CPU, fan and heatsink
assembly. If the instructions in this section do not match the CPU
documentation, follow the latter.
• Upon purchase of the motherboard, make sure that the PnP cap
is on the socket and the socket pins are not bent. Contact your
retailer immediately if the PnP cap is missing, or if you see any
damage to the PnP cap/socket pins/motherboard components.
ASUS will shoulder the cost of repair only if the damage is shipment/
transit-related.
• Keep the cap after installing the motherboard. ASUS will process
Return Merchandise Authorization (RMA) requests only if the
motherboard comes with the cap on the LGA775 socket.
• The product warranty does not cover damage to the socket pins
resulting from incorrect CPU installation/removal, or misplacement/
loss/incorrect removal of the PnP cap.
Before installing the CPU, make sure that the socket box is facing
towards you and the load lever is on your left.
P5LD2-FM/DH/VP CPU Socket 775
®
P5LD2-FM/DH/VP
