Asus P8h61-i r2.0 User manual

Motherboard

P8H61-I R2.0

E7443

First Edition

June 2012

No part of this manual, including the products and software described in it, may be reproduced,

transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any

means, except documentation kept by the purchaser for backup purposes, without the express written

permission of ASUSTeK COMPUTER INC. (“ASUS”).

Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless

such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the

product is defaced or missing.

ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS

OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS

DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,

INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,

LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),

EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY

DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR

INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,

AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO

RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS

MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.

Products and corporate names appearing in this manual may or may not be registered trademarks or

copyrights of their respective companies, and are used only for identication or explanation and to the

owners’ benet, without intent to infringe.

Offer to Provide Source Code of Certain Software

This product contains copyrighted software that is licensed under the General Public License (“GPL”),

under the Lesser General Public License Version (“LGPL”) and/or other Free Open Source Software

Licenses. Such software in this product is distributed without any warranty to the extent permitted by the

applicable law. Copies of these licenses are included in this product.

Where the applicable license entitles you to the source code of such software and/or other additional data,

you may obtain it for a period of three years after our last shipment of the product, either

(1) for free by downloading it from http://support.asus.com/download

(2) for the cost of reproduction and shipment, which is dependent on the preferred carrier and the location

where you want to have it shipped to, by sending a request to:

ASUSTeK Computer Inc.

Legal Compliance Dept.

15 Li Te Rd.,

Beitou, Taipei 112

Taiwan

In your request please provide the name, model number and version, as stated in the About Box of the

product for which you wish to obtain the corresponding source code and your contact details so that we

can coordinate the terms and cost of shipment with you.

The source code will be distributed WITHOUT ANY WARRANTY and licensed under the same license as

the corresponding binary/object code.

This offer is valid to anyone in receipt of this information.

ASUSTeK is eager to duly provide complete source code as required under various Free Open Source

Software licenses. If however you encounter any problems in obtaining the full corresponding source

code we would be much obliged if you give us a notication to the email address [email protected], stating

the product and describing the problem (please DO NOT send large attachments such as source code

archives, etc. to this email address).

iii

Contents

Safety information ...................................................................................... vi

About this guide ......................................................................................... vi

P8H61-I R2.0 specications summary.................................................... viii

Chapter 1 Product introduction

1.1 Before you proceed ..................................................................... 1-1

1.2 Motherboard overview................................................................. 1-2

1.2.1 Placement direction ........................................................ 1-2

1.2.2 Screw holes .................................................................... 1-2

1.2.3 Motherboard layout ......................................................... 1-3

1.2.4 Layout contents............................................................... 1-3

1.3 Central Processing Unit (CPU) ................................................... 1-4

1.4 System memory ........................................................................... 1-4

1.4.1 Overview ......................................................................... 1-4

1.4.2 Memory congurations.................................................... 1-5

1.5 Expansion slots.......................................................................... 1-13

1.5.1 Installing an expansion card ......................................... 1-13

1.5.2 Conguring an expansion card ..................................... 1-13

1.5.3 PCI Express x16 slot..................................................... 1-13

1.6 Jumpers ...................................................................................... 1-14

1.7 Connectors ................................................................................. 1-15

1.7.1 Rear panel connectors.................................................. 1-15

1.7.2 Internal connectors ....................................................... 1-17

1.8 Software support........................................................................ 1-22

1.8.1 Installing an operating system ...................................... 1-22

1.8.2 Support DVD information .............................................. 1-22

Chapter 2 BIOS information

2.1 Managing and updating your BIOS ............................................ 2-1

2.1.1 ASUS Update utility ........................................................ 2-1

2.1.2 ASUS EZ Flash 2............................................................ 2-2

2.1.3 ASUS CrashFree BIOS 3 utility ...................................... 2-3

2.1.4 ASUS BIOS Updater....................................................... 2-4

Contents

2.2 BIOS setup program .................................................................... 2-6

2.3 Main menu .................................................................................. 2-10

2.3.1 System Language [English] .......................................... 2-10

2.3.2 System Date [Day xx/xx/xxxx]....................................... 2-10

2.3.3 System Time [xx:xx:xx] ................................................. 2-10

2.3.4 Security ......................................................................... 2-10

2.4 Ai Tweaker menu........................................................................ 2-12

2.4.1 Memory Frequency [Auto]............................................. 2-12

2.4.2 GPU Boost .................................................................... 2-13

2.4.3 DRAM Timing Control ................................................... 2-13

2.4.4 CPU Power Management ............................................. 2-13

2.4.5 CPU Offset Mode Sign [+]............................................. 2-14

2.4.6 DRAM Voltage [Auto] .................................................... 2-14

2.4.7 VCCSA Voltage [Auto] .................................................. 2-14

2.4.8 VCCIO Voltage [Auto] ................................................... 2-14

2.4.9 PCH Voltage [Auto] ....................................................... 2-14

2.5 Advanced menu ......................................................................... 2-15

2.5.1 CPU Conguration ........................................................ 2-15

2.5.2 PCH Conguration ........................................................ 2-17

2.5.3 SATA Conguration ....................................................... 2-19

2.5.4 System Agent Conguration ......................................... 2-19

2.5.5 USB Conguration ........................................................ 2-20

2.5.6 Onboard Devices Conguration.................................... 2-21

2.5.7 APM .............................................................................. 2-22

2.5.8 Network Stack............................................................... 2-22

2.6 Monitor menu ............................................................................. 2-23

2.6.1 CPU Temperature / MB Temperature [xxxºC/xxxºF]...... 2-23

2.6.2 CPU / Chassis Fan Speed ............................................ 2-23

2.6.3 CPU Q-Fan Control [Enabled] ...................................... 2-24

2.6.4 Chassis Q-Fan Control [Enabled] ................................. 2-24

2.6.5 CPU Voltage, 3.3V Voltage, 5V Voltage, 12V Voltage .. 2-24

2.6.6 Anti Surge Support [Enabled] ....................................... 2-24

2.7 Boot menu .................................................................................. 2-25

2.7.1 Bootup NumLock State [On] ......................................... 2-25

2.7.2 Full Screen Logo [Enabled]........................................... 2-25

2.7.3 Wait For ‘F1’ If Error [Enabled]...................................... 2-26

2.7.4 Option ROM Messages [Force BIOS]........................... 2-26

2.7.5 Setup Mode [EZ Mode] ................................................. 2-26

2.7.6 UEFI/Legacy Boot [Enable both UEFI and Legacy]...... 2-26

2.7.7 PCI ROM Priority [Legacy ROM] .................................. 2-26

2.7.8 Boot Option Priorities .................................................... 2-26

2.7.9 Boot Override................................................................ 2-26

2.8 Tools menu ................................................................................. 2-27

2.8.1 ASUS EZ Flash Utility ................................................... 2-27

2.8.2 ASUS SPD Information................................................. 2-27

2.8.3 ASUS O.C. Prole......................................................... 2-27

2.9 Exit menu.................................................................................... 2-28

Appendices

Notices.......................................................................................................A-1

ASUS contact information .......................................................................A-3

Contents

Safety information

Electrical safety

• To prevent electric shock hazard, disconnect the power cable from the electric outlet

before relocating the system.

• When adding or removing devices to or from the system, ensure that the power cables

for the devices are unplugged before the signal cables are connected. If possible,

disconnect all power cables from the existing system before you add a device.

• Before connecting or removing signal cables from the motherboard, ensure that all

power cables are unplugged.

• Seek professional assistance before using an adapter or extension cord. These devices

could interrupt the grounding circuit.

• Ensure that your power supply is set to the correct voltage in your area. If you are not

sure about the voltage of the electrical outlet you are using, contact your local power

company.

• If the power supply is broken, do not try to x it by yourself. Contact a qualied service

technician or your retailer.

Operation safety

•

Before installing the motherboard and adding devices on it, carefully read all the manuals

that came with the package.

•

Before using the product, ensure that all cables are correctly connected and the power

cables are not damaged. If you detect any damage, contact your dealer immediately.

•

To avoid short circuits, keep paper clips, screws, and staples away from connectors,

slots, sockets and circuitry.

•

Avoid dust, humidity, and temperature extremes. Do not place the product in any area

where it may become wet.

•

Place the product on a stable surface.

•

If you encounter technical problems with the product, contact a qualied service

technician or your retailer.

About this guide

This user guide contains the information you need when installing and conguring the

motherboard.

How this guide is organized

This guide contains the following parts:

• Chapter 1: Product introduction

This chapter describes the features of the motherboard and the new technology it

supports.

• Chapter 2: BIOS information

This chapter tells how to change system settings through the BIOS Setup menus.

Detailed descriptions of the BIOS parameters are also provided.

vii

Bold text Indicates a menu or an item to select.

Italic

sUsed to emphasize a word or a phrase.

<Key> Keys enclosed in the less-than and greater-than sign

means that you must press the enclosed key.

Example: <Enter> means that you must press the Enter

or Return key.

<Key1> + <Key2> + <Key3> If you must press two or more keys simultaneously, the

key names are linked with a plus sign (+). Example:

Typography

Where to nd more information

Refer to the following sources for additional information and for product and software

updates.

1. ASUS websites

The ASUS website provides updated information on ASUS hardware and software

products. Refer to the ASUS contact information.

2. Optional documentation

Your product package may include optional documentation, such as warranty yers,

that may have been added by your dealer. These documents are not part of the

standard package.

Conventions used in this guide

To ensure that you perform certain tasks properly, take note of the following symbols used

throughout this manual.

DANGER/WARNING: Information to prevent injury to yourself when completing

a task.

CAUTION: Information to prevent damage to the components when completing a

task.

NOTE: Tips and additional information to help you complete a task.

IMPORTANT: Instructions you MUST follow to complete a task.

viii

P8H61-I R2.0 specications summary

(continued on the next page)

CPU LGA1155 socket for Intel®3nd / 2nd Generation Core™ i7 / Core™ i5 /

Core™ i3 / Pentium®/ Celeron®processors

Supports 22/32nm CPU

Supports Intel®Turbo Boost technology 2.0

* The Intel®Turbo Boost technology 2.0 support depends on the

CPU types.

** Refer to www.asus.com for Intel®CPU support list.

Chipset Intel®H61 Express Chipset

Memory 2 x DIMMs, maximum 16GB, DDR3 2200 (O.C.) / 2100 (O.C.) /

2000 (O.C.) / 1800 (O.C.) / 1600 (O.C.) / 1333 / 1066 MHz, non-

ECC, un-buffered memory*

Dual-channel memory architecture

*When you install a total memory of 4GB capacity or more,

Windows® 32-bit operating system may only recognize less than

3GB. We recommend a maximum of 3GB system memory if you

are using a Windows®32-bit operating system.

**DDR3 1600 MHz and higher memory frequency is supported by

Intel®3rd generation processors.

***Refer to www.asus.com for the latest Memory QVL (Qualied

Vendors List).

Expansion slots 1 x PCI Express 3.0*/2.0 x16 slot

*PCIe 3.0 speed is supported by Intel® 3rd generation processors.

Graphics Supports HDMI with max. resolution up to 1920 x 1200 @60Hz

Supports DVI with max. resolution up to 1920 x 1200 @60Hz

Supports D-Sub with max. resolution up to 2048 x 1530 @75Hz

Max. UMA memory: 1748MB

Storage Intel®H61 Express Chipset:

- 4 x Serial ATA 3.0 Gb/s connectors (blue)

- Supports AHCI Mode (in Windows®7/Vista)

LAN Realtek®RTL8111F Gigabit LAN controller

Audio VIA VT1708S 8-channel High Denition Audio CODEC

- Supports Jack-Detection, Multi-streaming, and Front Panel Jack-

Retasking

USB 2 x USB 3.0/2.0 ports (the back panel)

8 x USB 2.0/1.1 ports (4 ports at the mid-board, 4 ports at the back

panel)

P8H61-I R2.0 specications summary

Rear panel ports 1 x PS/2 Keyboard/Mouse Combo port

1 x HDMI output port

1 x DVI-D output port

1 x D-Sub output port

1 x LAN (RJ-45) port

4 x USB 2.0/1.1 ports

2 x USB 3.0/2.0 ports (blue)

3 x Audio jacks

Internal connectors 2 x USB 2.0/1.1 connector support additional 4 USB 2.0/1.1 ports

4 x SATA 3.0Gb/s connectors

1 x 4-pin CPU fan connector

1 x 4-pin Chassis fan connector

1 x Front panel audio connector

1 x System panel connector

1 x Clear CMOS jumper

1 x 24-pin EATX power connector

1 x 4-pin ATX 12V power connector

1 x speaker header

1 x S/PDIF out connector

1 x DRCT Header

BIOS features 64 Mb Flash ROM, AMI BIOS, PnP, DMI 2.0, WfM 2.0, ACPI 2.0a,

SM BIOS 2.5

Manageability WOL by PME, PXE

Accessories 2 x Serial ATA cables

1 x I/O shield

1 x User Manual

1 x Support DVD

Support DVD Drivers

ASUS utilities

ASUS Update

Anti-virus software (OEM version)

Form factor Mini-ITX form factor: 6.75 in x 6.75 in (17.1 cm x 17.1 cm)

* Specications are subject to change without notice.

1-1 Chapter 1: Product introduction

Chapter 1

Product introduction

Thank you for buying an ASUS®P8H61-I R2.0 motherboard!

Before you start installing the motherboard and adding hardware components, check the

items in your motherboard package. Refer to page ix for the list of accessories.

1.1 Before you proceed

Take note of the following precautions before you install motherboard components or change

any motherboard settings.

• Unplug the power cord from the wall socket before touching any component.

• Before handling components, use a grounded wrist strap or touch a safely grounded

object or a metal object, such as the power supply case, to avoid damaging them due to

static electricity.

• Hold components by the edges to avoid touching the ICs on them.

• Whenever you uninstall any component, place it on a grounded antistatic pad or in the

bag that came with the component.

• Before you install or remove any component, ensure that the ATX power supply is

switched off or the power cord is detached from the power supply. Failure to do so may

cause severe damage to the motherboard, peripherals, or components.

If any of the items is damaged or missing, contact your retailer.

Onboard LED

This motherboard comes with a standby power LED that lights up to indicate that the system

is ON, in sleep mode, or in soft-off mode. This is a reminder that you must shut down

the system and unplug the power cable before removing or plugging in any motherboard

component. The illustration below shows the location of the onboard LED.

P8H61-I R2.0

SB_PWR

Standby Power Powered Off

OFF

P8H61-I R2.0 Onboard LED

ASUS P8H61-I R2.0 1-2

1.2 Motherboard overview

Before you install the motherboard, study the conguration of your chassis to ensure that the

motherboard ts.

Unplug the power cord before installing or removing the motherboard. Failure to do so can

cause you physical injury and damage motherboard components.

1.2.1 Placement direction

When installing the motherboard, place it into the chassis in the correct orientation. The edge

with external ports goes to the rear part of the chassis as indicated in the image below.

1.2.2 Screw holes

Place four screws into the holes indicated by circles to secure the motherboard to the

chassis.

Do not overtighten the screws! Doing so can damage the motherboard.

P8H61-I R2.0

Place this side

towards the rear

of the chassis

1-3 Chapter 1: Product introduction

P8H61-I R2.0

PCIEX16

Super

I/O

F_PANEL

AAFP

ATX12V

EATXPWR

CPU_FAN CHA_FAN

USB78

USB56

Lithium Cell

CMOS Power

LAN1_USB3_12

USB12

RTL

8111F

ASM

1042

ASM

1442

VIA

VT1708S

EPU

32Mb

BIOS

SB_PWR

17.1cm(6.75in)

17.1cm(6.75 in)

Intel®

H61

SATA3G_1

SATA3G_2

SATA3G_3

SATA3G_4

AUDIO

KBMS

SPDIF_OUT

SPEAKER

DDR3 DIMMA1 (64bit, 240-pin module)

DDR3 DIMMB1 (64bit, 240-pin module)

CLRTC

DRCT

DVI_VGA

LGA1155

HDMI

41 2

911

12 10

1.2.4 Layout contents

1.2.3 Motherboard layout

Connectors/Jumpers/Slots/LED Page Connectors/Jumpers/Slots/LED Page

1. USB 2.0 connector (10-1 pin USB78, USB56) 1-17 7. System panel connector (10-1 pin F_PANEL) 1-13

2. ATX power connectors (24-pin EATXPWR,

4-pin ATX12V)

1-13 8. Standby power LED (SB_PWR) 1-1

3. Intel®H61 Serial ATA 3.0Gb/s connectors (7-pin

SATA3G_1/2/3/4)

1-15 9. Clear RTC RAM (3-pin CLRTC) 1-10

4. CPU and chassis fan connectors (4-pin

CPU_FAN, 4-pin CHA_FAN)

1-14 10. Intel®LGA1155 CPU socket 1-13

5. DDR3 U-DIMM slots 1-4 11. Digital audio connector (4-1 pin SPDIF_OUT) 1-16

6. Speaker Connector (4-pin SPEAKER) 1-16 12. Front panel audio connector (10-1 pin AAFP) 1-17

ASUS P8H61-I R2.0 1-4

P8H61-I R2.0

P8H61-I R2.0 240-pin DDR3 DIMM sockets

DIMMA1

DIMMB1

1.3 Central Processing Unit (CPU)

The motherboard comes with a surface mount LGA1155 socket designed for the Intel®3rd/ 2rd

Generation Core™ i7 / Core™ i5 / Core™ i3 / Pentium®/ Celeron®processors processors.

Unplug all power cables before installing the CPU.

• Upon purchase of the motherboard, ensure that the PnP cap is on the socket and the

socket contacts are not bent. Contact your retailer immediately if the PnP cap is missing,

or if you see any damage to the PnP cap/socket contacts/motherboard components.

ASUS will shoulder the cost of repair only if the damage is shipment/transit-related.

• Keep the cap after installing the motherboard. ASUS will process Return Merchandise

Authorization (RMA) requests only if the motherboard comes with the cap on the

LGA1155 socket.

• The product warranty does not cover damage to the socket contacts resulting from

incorrect CPU installation/removal, or misplacement/loss/incorrect removal of the PnP

cap.

1.4 System memory

1.4.1 Overview

The motherboard comes with two Double Data Rate 3 (DDR3) unbuffered Dual Inline

Memory Module (U-DIMM) sockets.

A DDR3 module has the same physical dimensions as a DDR2 DIMM but is notched

differently to prevent installation on a DDR2 DIMM socket. DDR3 modules are developed for

better performance with less power consumption.

The gure below illustrates the location of the DDR3 DIMM sockets:

Channel Sockets

Channel A DIMM_A1

Channel B DIMM_B1

1-5 Chapter 1: Product introduction

1.4.2 Memory congurations

You may install 1GB, 2GB, 4GB and 8GB unbuffered non-ECC DDR3 U-DIMMs into the

DIMM sockets.

• The default memory operation frequency is dependent on its Serial Presence Detect

(SPD), which is the standard way of accessing information from a memory module.

Under the default state, some memory modules for overclocking may operate at a lower

frequency than the vendor-marked value. To operate at the vendor-marked rate or at a

higher frequency, refer to section 2.4 Ai Tweaker menu for manual memory frequency

adjustment.

• For system stability, use a more efcient memory cooling system to support a full

memory load (2 U-DIMMs) or overclocking condition.

• You may install varying memory sizes in Channel A and Channel B. The system maps

the total size of the lower-sized channel for the dual-channel conguration. Any excess

memory from the higher-sized channel is then mapped for single-channel operation.

• Always install DIMMs with the same CAS latency. For optimal compatibility, we

recommend that you install memory modules of the same version or date code (D/C)

from the same vendor. Check with the retailer to get the correct memory modules.

• Due to the memory address limitation on 32-bit Windows®OS, when you install 4GB

or more memory on the motherboard, the actual usable memory for the OS can be

about 3GB or less. For effective use of memory, we recommend that you do any of the

following:

- Use a maximum of 3GB system memory if you are using a 32-bit Windows®OS.

- Install a 64-bit Windows®OS when you want to install 4GB or more on the

motherboard.

• This motherboard does not support DIMMs that use 512Mb (64MB) chips or less.

• Memory modules with memory frequency higher than 2133 MHz and its corresponding

timing or the loaded X.M.P. Prole is not the JEDEC memory standard. The stability

and compatibility of these memory modules depend on the CPU’s capabilities and other

installed devices.

ASUS P8H61-I R2.0 1-6

P8H61-I R2.0 Motherboard Qualied Vendors Lists (QVL)

DDR3-2666 MHz capability

Vendors Part No. Size SS/

Chip

Brand Chip NO. Timing Voltage

DIMM socket support

(Optional)

1 DIMM 2 DIMMs

KINGSTON KHX2250C9D3T1K2/4GX(XMP) 4GB(2 x 2GB) DS - - - 1.65V • •

Vendors Part No. Size SS/

Chip

Brand Chip NO. Timing Voltage

DIMM socket support

(Optional)

1 DIMM 2 DIMMs

KINGSTON KHX2250C9D3T1K2/4GX(XMP) 4GB(2 x 2GB) DS - - - 1.65V • •

DDR3-2600 MHz capability

DDR3-2400 MHz capability

Vendors Part No. Size SS/DS Chip

Brand

Chip

NO. Timing Voltage

DIMM socket

support (optional)

1 DIMM 2 DIMM

CORSAIR CMGTX8(XMP) 8GB (2GBx 4) SS - - 10-12-10-27 1.65V · ·

G.SKILL F3-19200CL11Q-16GBZHD(XMP1.3) 16GB ( 4GB x4 ) DS - - 11-11-11-31 1.65V · ·

G.SKILL F3-19200CL9D-4GBPIS(XMP) 4GB(2x 2GB) DS - - 9-11-9-28 1.65V · ·

GEIL GET34GB2400C9DC(XMP) 2GB DS - - 9-11-9-27 1.65V · ·

KINGMAX FLLE88F-C8KKAA HAIS(XMP) 2GB SS - - 10-11-10-30 1.8V · ·

Transcend TX2400KLU-4GK(427652)(XMP) 4GB(2 x 2GB) SS - - - 1.65V · ·

Transcend TX2400KLU-4GK (381850)(XMP) 4GB(2x 2GB) SS - - 1.65V · ·

Transcend TX2400KLU-4GK(374243)(XMP) 4GB(2x 2GB) DS - - 1.65V · ·

PATRIOT PVV34G2400C9K(XMP) 4GB(2x 2GB) DS - - 9-11-9-27 1.65V · ·

DDR3-2250 MHz capability

Vendors Part No. Size SS/

Chip

Brand Chip NO. Timing Voltage

DIMM socket support

(Optional)

1 DIMM 2 DIMMs

KINGSTON KHX2250C9D3T1K2/4GX(XMP) 4GB(2 x 2GB) DS - - - 1.65V • •

DDR3-2200 MHz capability

Vendors Part No. Size SS/DS Chip

Brand

Chip

NO. Timing Voltage

DIMM socket support

(Optional)

1 DIMM 2 DIMM

G.SKILL F3-17600CL8D-4GBPS(XMP) 4GB(2 x 2GB) DS - - 8-8-8-24 1.65V

GEIL GET34GB2200C9DC(XMP) 2GB DS - - 9-10-9-28 1.65V · ·

GEIL GET38GB2200C9ADC(XMP) 4GB DS - - 9-11-9-28 1.65V · ·

KINGMAX FLKE85F-B8KJAA-FEIS(XMP) 2GB DS - - - - · ·

KINGMAX FLKE85F-B8KHA EEIH(XMP) 4GB(2 x 2GB) DS - - - 1.5V-1.7V · ·

KINGMAX FLKE85F-B8KJA FEIH(XMP) 4GB(2 x 2GB) DS - - - 1.5V-1.7V · ·

1-7 Chapter 1: Product introduction

DDR3-2133 MHz capability

Vendors Part No. Size SS/DS Chip

Brand

Chip

NO. Timing Voltage

DIMM socket

support (Optional)

1DIMM 2DIMM

A-DATA AX3U2133GC2G9B-DG2(XMP) 2GB SS - - 9-11-9-27 1.55~1.75V · ·

CORSAIR CMT16GX3M4X2133C9(XMP 1.3) 16GB ( 4GB x4 ) DS - - 9-11-10-27 1.50V · ·

CORSAIR CMT4GX3M2A2133C9(XMP) 4GB(2x 2GB) DS - - 9-10-9-24 1.65V · ·

CORSAIR CMT4GX3M2B2133C9(XMP) 4GB(2x 2GB) DS - - 9-10-9-27 1.50V · ·

CORSAIR CMT8GX3M2B2133C9(XMP) 8GB ( 4GB x 2) DS - - 9-11-9-27 1.50V · ·

G.SKILL F3-17000CL9Q-16GBZH(XMP1.3) 16GB ( 4GB x4 ) DS - - 9-11-10-28 1.65V · ·

GEIL GE34GB2133C9DC(XMP) 2GB DS - - 9-9-9-28 1.65V · ·

GEIL GU34GB2133C9DC(XMP) 4GB(2 x 2GB) DS - - 9-9-9-28 1.65V · ·

KINGSTON KHX2133C11D3T1K2/16GX(XMP) 16GB(8GB x 2) DS - - - 1.6V · ·

KINGSTON KHX2133C9AD3T1K2/4GX(XMP) 4GB ( 2x 2GB ) DS - - - 1.65V · ·

KINGSTON KHX2133C9AD3X2K2/4GX(XMP) 4GB(2 x 2GB) DS - - 9-11-9-27 1.65V · ·

KINGSTON KHX2133C9AD3T1K4/8GX(XMP) 8GB(4 x 2GB) DS - - 9-11-9-27 1.65V · ·

KINGSTON KHX2133C9AD3T1FK4/8GX(XMP) 8GB(4x 2GB) DS - - - 1.65V · ·

PATRIOT PGD38G2133C11K(XMP) 16GB ( 4GB x4 ) DS - - 11-11-11-30 1.65V · ·

DDR3-2000 MHz capability

Vendors Part No. Size SS/

Chip

Brand Chip NO. Timing Voltage

DIMM socket

support

(Optional)

1DIMM 2DIMM

Apacer 78.AAGD5.9KD(XMP) 6GB(3 x 2GB) DS - - 9-9-9-27 1.65V · ·

CORSAIR CMZ4GX3M2A2000C10(XMP) 4GB(2 x 2GB) SS - - 10-10-10-27 1.50V · ·

CORSAIR CMT6GX3M3A2000C8(XMP) 6GB(3 x 2GB) DS - - 8-9-8-24 1.65V · ·

G.SKILL F3-16000CL9D-4GBFLS(XMP) 4GB(2 x 2GB) DS - - 9-9-9-24 1.65V · ·

G.SKILL F3-16000CL9D-4GBTD(XMP) 4GB(2 x 2GB) DS - - 9-9-9-27 1.65V · ·

G.SKILL F3-16000CL6T-6GBPIS(XMP) 6GB (3x 2GB ) DS - - 6-9-6-24 1.65V · ·

GEIL GUP34GB2000C9DC(XMP) 4GB(2 x 2GB) DS - - 9-9-9-28 1.65V · ·

KINGSTON KHX2000C9AD3T1K2/4GX(XMP) 4GB ( 2x 2GB ) DS - - - 1.65V · ·

KINGSTON KHX2000C9AD3W1K2/4GX(XMP) 4GB ( 2x 2GB ) DS - - - 1.65V · ·

KINGSTON KHX2000C9AD3T1K2/4GX(XMP) 4GB(2 x 2GB) DS - - 9 1.65V · ·

KINGSTON KHX2000C9AD3W1K3/6GX(XMP) 6GB ( 3x 2GB ) DS - - - 1.65V · ·

KINGSTON KHX2000C9AD3T1K3/6GX(XMP) 6GB (3x 2GB ) DS - - - 1.65V · ·

Transcend TX2000KLN-8GK(XMP) 8GB(2 x 4GB) DS - - - 1.6V · ·

Asint SLA302G08-ML2HB(XMP) 4GB DS HYNIX H5TQ2G83BFR H9C - - · ·

PATRIOT PVT36G2000LLK 6GB(3 x 2GB) DS - - 8-8-8-24 1.65V ·

DDR3-1866 MHz capability

Vendors Part No. Size SS/

Chip

Brand

Chip

NO. Timing Voltage

DIMM socket support

(Optional)

1DIMM 2DIMM

A-DATA AX3U1866PB2G8-DP2(XMP) 2GB DS - - 8-8-8-24 1.55V-1.75V

CORSAIR CMT4GX3M2A1866C9(XMP) 4GB(2 x 2GB) DS - - 9-9-9-24 1.65V · ·

CORSAIR CMT6GX3MA1866C9(XMP) 6GB(3 x 2GB) DS - - 9-9-9-24 1.65V · ·

CORSAIR CMZ8GX3M2A1866C9(XMP) 8GB(2 x 4GB) DS - - 9-10-9-27 1.50V · ·

G.SKILL F3-14900CL9Q-16GBZL(XMP1.3) 16GB ( 4GB x4 ) DS - - 9-10-9-28 1.5V · ·

G.SKILL F3-14900CL10Q2-

64GBZLD(XMP1.3) 64GB ( 8GBx 8 ) DS - - 10-11-10-30 1.5V · ·

G.SKILL F3-14900CL9D-8GBXL(XMP) 8GB(2 x 4GB) DS - - 9-10-9-28 1.5V · ·

G.SKILL F3-14900CL9Q-8GBXL(XMP) 8GB(2GBx4) DS - - 9-9-9-24 1.6V · ·

KINGSTON KHX1866C9D3T1K3/3GX(XMP) 3GB(3 x 1GB) SS - - - 1.65V · ·

KINGSTON KHX1866C9D3K4/16GX(XMP) 16GB ( 4GB x4 ) DS - - - 1.65V · ·

KINGSTON KHX1866C9D3T1K3/6GX(XMP) 6GB(3 x 2GB) DS - - - 1.65V · ·

KINGSTON KHX1866C11D3P1K2/8G 8GB ( 4GB x 2) DS - - - 1.5V

KINGSTON KHX1866C9D3K2/8GX(XMP) 8GB(4GBX2) DS - - - 1.65V · ·

ASUS P8H61-I R2.0 1-8

DDR3-1600 MHz capability

Vendors Part No. Size SS/DS Chip

Brand Chip NO. Timing Voltage

DIMM socket

support

(Optional)

1DIMM 2DIMM

A-DATA AM2U16BC2P1 2GB SS A-DATA 3CCD-1509A

EL1126T - - · ·

A-DATA AD31600E001GM(O)U3K 3GB (3 x

1GB) SS - - 8-8-8-24 1.65V-1.85V ·

A-DATA AX3U1600XB2G79-2X(XMP) 4GB (2 x

2GB) DS - - 7-9-7-21 1.55V-1.75V

A-DATA AM2U16BC4P2 4GB DS A-DATA 3CCD-1509A

EL1126T - - · ·

A-DATA AX3U1600GC4G9-2G(XMP) 8GB (2 x

4GB) DS - - 9-9-9-24 1.55V-1.75V · ·

A-DATA AX3U1600XC4G79-2X(XMP) 8GB (2 x

4GB) DS - - 7-9-7-21 1.55V-1.75V · ·

CORSAIR TR3X3G1600C8D(XMP) 3GB (3 x

1GB) SS - - 8-8-8-24 1.65V · ·

CORSAIR CMD12GX3M6A1600C8(XMP) 12GB

(6x2GB) DS - - 8-8-8-24 1.65V · ·

CORSAIR CMZ32GX3M4X1600C10(XMP) 32GB

(8GBx4) DS - - 10-10-10-27 1.50V · ·

CORSAIR CMP4GX3M2A1600C8(XMP) 4GB (2 x

2GB) DS - - 8-8-8-24 1.65V · ·

CORSAIR CMP4GX3M2A1600C9(XMP) 4GB (2 x
