Asus P9D-I User manual

Motherboard
P9D-I

ii
E8351
First Edition
July 2013
Copyright © 2013 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced, transmitted,
transcribed, stored in a retrieval system, or translated into any language in any form or by any means,
except documentation kept by the purchaser for backup purposes, without the express written permission
of ASUSTeK COMPUTER INC. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless
such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the
product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE, AND
SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY
OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL,
INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identification or explanation and to the
owners’ benefit, without intent to infringe.

iii
Contents
Notices ...................................................................................................................... vii
Federal Communications Commission Statement.........................................vii
Canadian Department of Communications Statement...................................vii
REACH ......................................................................................................vii
Safety information.................................................................................................... viii
Electrical safety ............................................................................................. viii
Operation safety............................................................................................ viii
Australia statement notice...............................................................................ix
About this guide.......................................................................................................... x
How this guide is organized ............................................................................ x
Where to find more information....................................................................... x
P9D-I Specications Summary ................................................................................ xii
Chapter 1: Product Introduction
1.1 Welcome! .................................................................................................... 1-3
1.2 Package contents....................................................................................... 1-3
1.3 Serial number label.................................................................................... 1-4
1.4 Special features.......................................................................................... 1-4
1.4.1 Product highlights........................................................................ 1-4
1.4.2 Innovative ASUS features ........................................................... 1-6
Chapter 2: Hardware Information
2.1 Before you proceed ................................................................................... 2-3
2.2 Motherboard overview............................................................................... 2-4
2.2.1 Placement direction..................................................................... 2-4
2.2.2 Screw holes................................................................................. 2-4
2.2.3 Motherboard layout ..................................................................... 2-5
2.2.4 Layout contents........................................................................... 2-6
2.3 Central Processing Unit (CPU) ................................................................. 2-8
2.3.1 Installing the CPU ....................................................................... 2-8
2.3.2 Installing the CPU heatsink....................................................... 2-11
2.3.3 Uninstalling the CPU heatsink and fan...................................... 2-12
2.4 System memory ....................................................................................... 2-13
2.4.1 Overview ................................................................................... 2-13
2.4.2 Memory Configurations ............................................................. 2-13
2.4.3 Installing a DIMM on a single clip DIMM socket........................ 2-14

iv
Contents
2.5 Expansion slots........................................................................................ 2-15
2.5.1 Installing an expansion card...................................................... 2-15
2.5.2 Configuring an expansion card ................................................. 2-15
2.5.3 Interrupt assignments................................................................ 2-16
2.5.4 PCI Express x16 slot (x16 link) ................................................. 2-17
2.6 Onboard LEDs .......................................................................................... 2-18
2.7 Jumpers .................................................................................................... 2-20
2.8 Connectors ............................................................................................... 2-23
2.8.1 Rear panel connectors.............................................................. 2-23
2.8.2 Internal connectors.................................................................... 2-24
Chapter 3: Powering Up
3.1 Starting up for the rst time...................................................................... 3-3
3.2 Powering off the computer........................................................................ 3-4
3.2.1 Using the OS shut down function................................................ 3-4
3.2.2 Using the dual function power switch.......................................... 3-4
Chapter 4: BIOS setup
4.1 Managing and updating your BIOS .......................................................... 4-3
4.1.1 ASUS CrashFree BIOS 3 utility................................................... 4-3
4.1.2 ASUS EzFlash Utility................................................................... 4-4
4.1.3 BUPDATER utility........................................................................ 4-5
4.2 BIOS setup program .................................................................................. 4-7
4.2.1 BIOS menu screen...................................................................... 4-8
4.2.2 Menu bar ..................................................................................... 4-8
4.2.3 Menu items.................................................................................. 4-9
4.2.4 Submenu items ........................................................................... 4-9
4.2.5 Navigation keys........................................................................... 4-9
4.2.6 General help................................................................................ 4-9
4.2.7 Configuration fields ..................................................................... 4-9
4.2.8 Pop-up window............................................................................ 4-9
4.2.9 Scroll bar ..................................................................................... 4-9
4.3 Main menu ................................................................................................ 4-10
4.3.1 System Date ............................................................................. 4-10
4.3.2 System Time ............................................................................. 4-10

v
Contents
4.4 Advanced menu ....................................................................................... 4-11
4.4.1 CPU Configuration .................................................................... 4-12
4.4.2 PCH-IO Configuration ............................................................... 4-15
4.4.3 SATA Configuration ................................................................... 4-16
4.4.4 System Agent (SA) Configuration ............................................. 4-17
4.4.5 PCI Subsystem Settings ........................................................... 4-19
4.4.6 USB Configuration .................................................................... 4-21
4.4.7 ACPI Settings............................................................................ 4-22
4.4.8 WHEA Support .......................................................................... 4-22
4.4.9 NCT6779D Super IO Configuration .......................................... 4-23
4.4.10 Intel Server Platform Services................................................... 4-24
4.4.11 Onboard LAN Configuration...................................................... 4-24
4.4.12 Serial Port Console Redirection................................................ 4-25
4.4.13 Runtime Error Logging Support ................................................ 4-27
4.4.14 APM .......................................................................................... 4-27
4.4.15 Network Stack ........................................................................... 4-28
4.4.16 Intel RC Drivers Version Detail.................................................. 4-28
4.5 Event Logs menu ..................................................................................... 4-29
4.6 Boot menu ................................................................................................ 4-30
4.7 Monitor menu ........................................................................................... 4-33
4.8 Security ..................................................................................................... 4-34
4.9 Tool menu ................................................................................................. 4-37
4.10 Exit menu .................................................................................................. 4-37
Chapter 5: RAID Conguration
5.1 Setting up RAID.......................................................................................... 5-3
5.1.1 RAID definitions .......................................................................... 5-3
5.1.2 Installing hard disk drives............................................................ 5-4
5.1.3 Setting Jumpers .......................................................................... 5-4
5.1.4 Setting the RAID mode in BIOS.................................................. 5-4
5.1.5 RAID configuration utilities.......................................................... 5-4
5.2 LSI Software RAID Conguration Utility.................................................. 5-5
5.2.1 Creating a RAID set .................................................................... 5-6
5.2.2 Adding or viewing a RAID configuration.................................... 5-16
5.2.3 Initializing the virtual drives ....................................................... 5-21
5.2.4 Rebuilding failed drives............................................................. 5-25
5.2.5 Checking the drives for data consistency.................................. 5-27
5.2.6 Deleting a RAID configuration................................................... 5-30
5.2.7 Selecting the boot drive from a RAID set.................................. 5-31
5.2.8 Enabling the Disk Write Cache (DWC) ..................................... 5-32

vi
Contents
5.3 Intel®Rapid Storage Technology enterprise
SATA Option ROM Utility......................................................................... 5-34
5.3.1 Creating a RAID set .................................................................. 5-35
5.3.2 Deleting a RAID set................................................................... 5-37
5.3.3 Resetting disks to Non-RAID .................................................... 5-38
5.3.4 Exiting the Intel®Rapid Storage Technology enterprise
SATA Option ROM utility ........................................................... 5-39
5.3.5 Rebuilding the RAID.................................................................. 5-39
5.3.6 Setting the Boot array in the BIOS Setup Utility........................ 5-41
5.4 Intel®Rapid Storage Technology enterprise (Windows) ...................... 5-42
5.4.1 Creating a RAID set .................................................................. 5-43
5.4.2 Changing a Volume Type .......................................................... 5-45
5.4.3 Deleting a volume ..................................................................... 5-46
5.4.4 Preferences............................................................................... 5-47
Chapter 6: Driver installation
6.1 RAID driver installation ............................................................................. 6-3
6.1.1 Creating a RAID driver disk......................................................... 6-3
6.1.2 Installing the RAID controller driver............................................. 6-5
6.2 Management applications and utilities installation .............................. 6-14
6.3 Running the Support DVD ...................................................................... 6-14
6.4 Installing the LAN driver.......................................................................... 6-22
6.5 Installing the VGA driver ......................................................................... 6-27
6.6 Installing the Intel®C22x MEI NULL HECI driver................................... 6-30
6.7 Installing the Intel®I210 Gigabit Adapter driver .................................... 6-32
Appendix A: Reference Information
A.1 P9D-I block diagram.................................................................................. A-3
ASUS contact information.......................................................................................... 1

vii
Notices
Federal Communications Commission Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
This device may not cause harmful interference, and
This device must accept any interference received including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used
in accordance with manufacturer’s instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
•
•
•
•
•
•
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for radio noise emissions from
digital apparatus set out in the Radio Interference Regulations of the Canadian Department of
Communications.
This class B digital apparatus complies with Canadian ICES-003.
The use of shielded cables for connection of the monitor to the graphics card is required
to assure compliance with FCC regulations. Changes or modifications to this unit not
expressly approved by the party responsible for compliance could void the user’s authority
to operate this equipment.
REACH
Complying with the REACH (Registration, Evaluation, Authorization, and Restriction of
Chemicals) regulatory framework, we publish the chemical substances in our products at
ASUS REACH website at http://csr.asus.com/english/REACH.htm.

viii
Safety information
Electrical safety
To prevent electrical shock hazard, disconnect the power cable from the electrical outlet
before relocating the system.
When adding or removing devices to or from the system, ensure that the power cables
for the devices are unplugged before the signal cables are connected. If possible,
disconnect all power cables from the existing system before you add a device.
Before connecting or removing signal cables from the motherboard, ensure that all power
cables are unplugged.
Seek professional assistance before using an adapter or extension cord. These devices
could interrupt the grounding circuit.
Make sure that your power supply is set to the correct voltage in your area. If you are
not sure about the voltage of the electrical outlet you are using, contact your local power
company.
If the power supply is broken, do not try to fix it by yourself. Contact a qualified service
technician or your retailer.
•
•
•
•
•
•
Operation safety
Before installing the motherboard and adding devices on it, carefully read all the manuals
that came with the package.
Before using the product, make sure all cables are correctly connected and the power
cables are not damaged. If you detect any damage, contact your dealer immediately.
To avoid short circuits, keep paper clips, screws, and staples away from connectors,
slots, sockets and circuitry.
Avoid dust, humidity, and temperature extremes. Do not place the product in any area
where it may become wet.
Place the product on a stable surface.
If you encounter technical problems with the product, contact a qualified service
technician or your retailer.
•
•
•
•
•
•
DO NOT throw the motherboard in municipal waste. This product has been designed to
enable proper reuse of parts and recycling. This symbol of the crossed out wheeled bin
indicates that the product (electrical and electronic equipment) should not be placed in
municipal waste. Check local regulations for disposal of electronic products.
DO NOT throw the mercury-containing button cell battery in municipal waste. This symbol
of the crossed out wheeled bin indicates that the battery should not be placed in municipal
waste.

ix
Australia statement notice
From 1 January 2012 updated warranties apply to all ASUS products, consistent with
the Australian Consumer Law. For the latest product warranty details please visit http://
support.asus.com. Our goods come with guarantees that cannot be excluded under the
Australian Consumer Law. You are entitled to a replacement or refund for a major failure and
compensation for any other reasonably foreseeable loss or damage. You are also entitled
to have the goods repaired or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
If you require assistance please call ASUS Customer Service 1300 2787 88 or visit us at
http://support.asus.com

x
About this guide
This user guide contains the information you need when installing and configuring the
motherboard.
How this guide is organized
This user guide contains the following parts:
• Chapter 1: Product introduction
This chapter describes the features of the motherboard and the new technologies it
supports.
• Chapter 2: Hardware information
This chapter lists the hardware setup procedures that you have to perform when
installing system components. It includes description of the switches, jumpers, and
connectors on the motherboard.
• Chapter 3: Powering up
This chapter describes the power up sequence and ways of shutting down the system.
• Chapter 4: BIOS setup
This chapter tells how to change system settings through the BIOS Setup menus.
Detailed descriptions of the BIOS parameters are also provided.
• Chapter 5: RAID conguration
This chapter provides instructions for setting up, creating, and configuring RAID sets
using the available utilities.
• Chapter 6: Driver installation
This chapter provides instructions for installing the necessary drivers for different
system components.
• Appendix: Reference information
This appendix includes additional information that you may refer to when configuring
the motherboard.
Where to nd more information
Refer to the following sources for additional information and for product and software updates.
1. ASUS websites
The ASUS website provides updated information on ASUS hardware and software
products. Refer to the ASUS contact information.
2. Optional documentation
Your product package may include optional documentation, such as warranty flyers,
that may have been added by your dealer. These documents are not part of the
standard package.

xi
Conventions used in this guide
To ensure that you perform certain tasks properly, take note of the following symbols used
throughout this manual.
DANGER/WARNING: Information to prevent injury to yourself when trying to
complete a task.
CAUTION: Information to prevent damage to the components when trying to
complete a task
IMPORTANT: Instructions that you MUST follow to complete a task..
NOTE: Tips and additional information to help you complete a task.
Typography
Bold text Indicates a menu or an item to select.
Italics Used to emphasize a word or a phrase.
<Key> Keys enclosed in the less-than and greater-than sign means
that you must press the enclosed key.
Example: <Enter> means that you must press the Enter or
Return key.
<Key1> + <Key2> + <Key3> If you must press two or more keys simultaneously, the key
names are linked with a plus sign (+).
Example: <Ctrl> + <Alt> + <Del>
Command
Means that you must type the command exactly as shown,
then supply the required item or value enclosed in brackets.
Example: At DOS prompt, type the command line:
format A:/S

xii
Processor Support / System Bus 1 x Socket LGA1150
Intel®Xeon®processor E3-1200 v3 product family
Core Logic Intel®C222 Chipset
Form Factor Mini-ATX, 6.7 in. x 6.7 in.
ASUS Features
Fan Speed Control
Rack Ready
(Rack and Pedestal
dual use)
ASWM Enterprise
Memory
Total Slots 2 (1 Channel)
Capacity Maximum up to 16GB
Memory Type DDR3 1333/1600 ECC UDIMM
Expansion
Slots
(follow SSI
Location
number)
Total PCI/PCI-E Slots 1
Slot Location 7 1 x PCI-E x16 (x16 Gen3 link)
Storage SATA Controller
Intel®C222:
- 2 x SATA 3Gb/s ports
- 2 x SATA 6Gb/s ports
- Intel®Rapid Storage Technology Enterprise
(RSTe) supports software RAID 0, 1, 10, & 5
(Windows)
- LSI MegaRAID driver supports software
RAID 0, 1, & 10 (Windows & Linux)
Networking LAN 2 x Intel®I210AT
Graphic VGA Aspeed AST2300 32MB
Onboard I/O
Connectors
PSU Connector 24-pin ATX power connector +
4-pin ATX 12V power connector
USB Connector/
Header 1 x USB 2.0 pin header (up to 2 devices)
Fan Header 2 x 4 pin headers
Chassis Intruder 1
Front LAN LED 2
Rear I/O
Connectors
External Serial Port 1
External USB Port 2 x USB 3.0
2 x USB 2.0
VGA Port DVI
RJ-45 2 x GbE LAN
PS/2 KB/Mouse 1
Management
Solution
Software ASWM Enterprise
Out of Band Remote
Management ASMB7-iKVM for KVM-over-Internet
P9D-I Specications Summary
(continued on the next page)
* Refer to www.asus.com for the complete list of supported CPUs.

xiii
Monitoring CPU Temperature
FAN RPM
Environment
Operation temperature:
10oC – 35oC (50oF – 95oF)
Non operation temperature:
-40oC – 70oC (-40oF – 158oF)
Non operation humidity:
20% – 90% (Non condensing)
Specifications are subject to change without notice.

xiv

Chapter 1:
Product Introduction

ASUS P9D-I
Chapter summary
1
1.1 Welcome! .................................................................................................... 1-3
1.2 Package contents....................................................................................... 1-3
1.3 Serial number label.................................................................................... 1-4
1.4 Special features.......................................................................................... 1-4
This chapter describes the motherboard features and the new technologies it supports. This
chapter contains the following sections:

ASUS P9D-I 1-3
1.1 Welcome!
Thank you for buying an ASUS®P9D-I motherboard!
The motherboard delivers a host of new features and latest technologies, making it another
standout in the long line of ASUS quality motherboards!
Before you start installing the motherboard and hardware devices on it, check the items in
your package with the list below.
1.2 Package contents
Check your motherboard package for the following items.
If any of the above items is damaged or missing, contact your retailer.
Items Standard Gift Box Pack Standard Bulk Pack
I/O Shield 11
SATA 3G cable 2 --
SATA 6G cable 2 --
Application CD Support CD 2 2
ASWM Enterprise SDVD 1 1
Documentation User Guide 2 2
Packaging Qty. 1 pc per carton 10 pcs per carton

1-4 Chapter 1: Product introduction
1.4 Special features
1.4.1 Product highlights
Latest processor technology
This motherboard supports the latest Intel® Xeon®Processor E3-1200 v3/ CoreTM i3 series
in LGA1150 package, which has memory and PCI Express controller integrated to support
1-channel (2 DIMMs) DDR3 memory and 16 PCI Express 3.0 lanes. The Intel®Xeon®
E3-1200 v3 have improve CPU performance and integrated voltage regulators making it one
of the most powerful and energy efficient CPU in the world.
Intel®Turbo Boost
Intel®Turbo Boost automatically allows the processor to run faster than the marked frequency
if the processor is operating below its power, current, and temperature specification
limits. This technology increases performance of both multi-threaded and single-threaded
workloads.
Intel®Hyper Threading
The thread-level parallelism on each processor makes more efficient use of the processor
resources, higher processing throughout and improved performance on today's multi-
threaded software.
Intel®EM64T
The motherboard supports Intel®processors with the Intel®EM64T (Extended Memory 64
Technology). The Intel®EM64T feature allows your computer to run on 64-bit operating
systems and access larger amounts of system memory for faster and more efficient
computing.
DDR3 memory support
The motherboard supports ECC UDIMM DDR3 memory that features data transfer rates
of 1600/1333 MHz to meet the higher bandwidth requirements of server and workstation
applications. The dual-channel DDR3 architecture boosts system performance, eliminates
bottlenecks with peak bandwidth up to 25Gb/s, and dramatically reduces the memory voltage
to just 1.5V compared to DDR2's memory voltage of 1.8V.
1.3 Serial number label
Before requesting support from the ASUS Technical Support team, you must take note of the
motherboard's serial number containing 12 characters xxS2xxxxxxxx shown as the figure
below. With the correct serial number of the product, ASUS Technical Support team members
can then offer a quicker and satisfying solution to your problems.
xxS2xxxxxxxx
P9D-I Made
in
China
合格

ASUS P9D-I 1-5
PCI Express 3.0
PCI Express 3.0 (PCIe 3.0) is the PCI Express bus standard that provides twice the
performance and speed of PCIe 2.0. It provides an optimal graphics performance,
unprecedented data speed, and seamless transition with its complete backward
compatibility to PCIe 1.0/2.0 devices.
Intel®I210AT LAN Solution
The motherboard comes with two LAN controllers and ports which provide a total solution
for your networking needs. The onboard Intel®I210AT Gigabit LAN controllers use the PCI
Express interface and could achieve network throughput close to Gigabit bandwidth.
Enhanced Intel SpeedStep Technology (EIST)
The Enhanced Intel SpeedStep Technology (EIST) intelligently manages the CPU
resources by automatically adjusting the CPU voltage and core frequency depending on
the CPU loading and system speed or power requirement.
Serial ATA II technology
The motherboard supports the Serial ATA II 3 Gb/s technology through the Serial ATA
interface and Intel®C222 chipset. The Serial ATA II specification provides twice the
bandwidth of the current Serial ATA products with a host of new features, including Native
Command Queuing (NCQ), Power Management (PM) Implementation Algorithm, and Hot
Swap. Serial ATA allows thinner, more flexible cables with lower pin count and reduced
voltage requirements.
Serial ATA III technology
The motherboard supports the Serial ATA III 6 Gb/s technology through the Serial ATA
interface and Intel®C222 chipset. Get enhanced scalability, faster data retrieval, double
the bandwidth of current bus systems with up to 6Gbps data transfer rates.
USB 2.0 technology
The motherboard implements the Universal Serial Bus (USB) 2.0 specification that
dramatically increases the connection speed from the 12 Mbps bandwidth on USB 1.1 to
a fast 480 Mbps on USB 2.0. USB 2.0 is backward compatible with USB 1.1.
USB 3.0 technology
The motherboard implements the USB 3.0 technology with data transfer speeds of up to
5Gbps, faster charging time for USB-chargeable devices, optimized power efficiency, and
backward compatibility with USB 2.0.
Temperature, fan, and voltage monitoring
The CPU temperature is monitored to prevent overheating and damage. The system fan
rotations per minute (RPM) is monitored for timely failure detection. The chip monitors the
voltage levels to ensure stable supply of current for critical components.

1-6 Chapter 1: Product introduction
1.4.2 Innovative ASUS features
ASUS Fan Speed technology
The ASUS Fan Speed technology smartly adjusts the fan speeds according to the system
loading to ensure quiet, cool, and efficient operation.
