Asus STRIX X99 User manual

Motherboard
STRIX X99
GAMING

ii
E11712
Revised Edition V2
May 2016
Copyright© 2016 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any
means, except documentation kept by the purchaser for backup purposes, without the express written
permission of ASUSTeK COMPUTER INC. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless
such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the
product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS
MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identication or explanation and to the
owners’ benet, without intent to infringe.
Offer to Provide Source Code of Certain Software
This product contains copyrighted software that is licensed under the General Public License (“GPL”),
under the Lesser General Public License Version (“LGPL”) and/or other Free Open Source Software
Licenses. Such software in this product is distributed without any warranty to the extent permitted by the
applicable law. Copies of these licenses are included in this product.
Where the applicable license entitles you to the source code of such software and/or other additional data,
you may obtain it for a period of three years after our last shipment of the product, either
(1) for free by downloading it from https://www.asus.com/support/
or
(2) for the cost of reproduction and shipment, which is dependent on the preferred carrier and the location
where you want to have it shipped to, by sending a request to:
ASUSTeK Computer Inc.
Legal Compliance Dept.
15 Li Te Rd.,
Beitou, Taipei 112
Taiwan
In your request please provide the name, model number and version, as stated in the About Box of the
product for which you wish to obtain the corresponding source code and your contact details so that we
can coordinate the terms and cost of shipment with you.
The source code will be distributed WITHOUT ANY WARRANTY and licensed under the same license as
the corresponding binary/object code.
This offer is valid to anyone in receipt of this information.
ASUSTeK is eager to duly provide complete source code as required under various Free Open Source
Software licenses. If however you encounter any problems in obtaining the full corresponding source
code we would be much obliged if you give us a notication to the email address [email protected], stating
the product and describing the problem (please DO NOT send large attachments such as source code
archives, etc. to this email address).

iii
Contents
Safety information...................................................................................................... vi
About this guide........................................................................................................ vii
STRIX X99 GAMING specifications summary.......................................................... ix
Package contents..................................................................................................... xiii
Installation tools and components......................................................................... xiv
Chapter 1: Product Introduction
1.1 Motherboard overview............................................................................... 1-1
1.1.1 Before you proceed..................................................................... 1-1
1.1.2 Motherboard layout ..................................................................... 1-2
1.1.3 Central Processing Unit (CPU) ................................................... 1-4
1.1.4 System memory .......................................................................... 1-5
1.1.5 Expansion slots........................................................................... 1-8
1.1.6 Onboard buttons and switches..................................................1-10
1.1.7 Jumpers .................................................................................... 1-13
1.1.8 Onboard LEDs .......................................................................... 1-15
1.1.9 Internal connectors.................................................................... 1-22
Chapter 2: Basic Installation
2.1 Building your PC system...........................................................................2-1
2.1.1 Motherboard installation.............................................................. 2-1
2.1.2 CPU installation........................................................................... 2-3
2.1.3 CPU heatsink and fan assembly installation............................... 2-4
2.1.4 DIMM installation......................................................................... 2-6
2.1.5 ATX Power connection................................................................2-7
2.1.6 SATA device connection............................................................. 2-8
2.1.7 Front I/O Connector .................................................................... 2-9
2.1.8 Expansion Card installation....................................................... 2-10
2.1.9 Wi-Fi antenna installation.......................................................... 2-12
2.2 BIOS update utility...................................................................................2-13
2.3 Motherboard rear and audio connections .............................................2-14
2.3.1 Rear I/O connection .................................................................. 2-14
2.3.2 Audio I/O connections............................................................... 2-16
2.4 Starting up for the first time.................................................................... 2-18
2.5 Turning off the computer ........................................................................ 2-19

iv
Chapter 3: BIOS Setup
3.1 Knowing BIOS ............................................................................................3-1
3.2 BIOS setup program ..................................................................................3-2
3.2.1 EZ Mode...................................................................................... 3-3
3.2.2 Advanced Mode .......................................................................... 3-4
3.2.3 QFan Control............................................................................... 3-7
3.2.4 EZ Tuning Wizard ....................................................................... 3-9
3.3 My Favorites .............................................................................................3-12
3.4 Main menu ................................................................................................3-14
3.5 Ai Tweaker menu......................................................................................3-15
3.6 Advanced menu .......................................................................................3-19
3.6.1 CPU Conguration .................................................................... 3-20
3.6.2 PCH Conguration .................................................................... 3-21
3.6.3 PCH Storage Conguration....................................................... 3-22
3.6.4 System Agent Conguration ..................................................... 3-24
3.6.5 USB Conguration .................................................................... 3-24
3.6.6 Platform Misc Conguration...................................................... 3-25
3.6.7 Onboard Devices Conguration................................................ 3-25
3.6.8 APM Conguration.................................................................... 3-28
3.6.9 Network Stack Conguration..................................................... 3-28
3.6.10 HDD/SSD SMART Conguration.............................................. 3-29
3.6.11 NVMe Conguration.................................................................. 3-29
3.7 Monitor menu ...........................................................................................3-30
3.8 Boot menu ................................................................................................3-32
3.9 Tool menu.................................................................................................3-35
3.9.1 ASUS EZ Flash 3 Utility ............................................................ 3-35
3.9.2 Secure Erase ............................................................................ 3-36
3.9.3 ASUS Overclocking Prole ....................................................... 3-37
3.9.4 ASUS SPD Information............................................................. 3-38
3.10 Exit menu..................................................................................................3-39
3.11 Updating BIOS..........................................................................................3-40
3.11.1 EZ Update................................................................................. 3-40
3.11.2 ASUS EZ Flash 3...................................................................... 3-40
3.11.3 ASUS CrashFree BIOS 3.......................................................... 3-43

v
Chapter 4: RAID Support
4.1 RAID configurations ..................................................................................4-1
4.1.1 RAID denitions .......................................................................... 4-1
4.1.2 Installing Serial ATA hard disks .................................................. 4-2
4.1.3 Intel®Rapid Storage Technology in UEFI BIOS.......................... 4-2
4.1.4 Intel®Rapid Storage Technology Option ROM utility.................. 4-6
4.2 Creating a RAID driver disk ....................................................................4-10
4.2.1 Creating a RAID driver disk in Windows®................................. 4-10
Appendix
Notices .................................................................................................................... A-1
ASUS contact information...................................................................................... A-6

vi
Safety information
Electrical safety
• To prevent electrical shock hazard, disconnect the power cable from the electrical outlet
before relocating the system.
• When adding or removing devices to or from the system, ensure that the power cables
for the devices are unplugged before the signal cables are connected. If possible,
disconnect all power cables from the existing system before you add a device.
• Before connecting or removing signal cables from the motherboard, ensure that all
power cables are unplugged.
• Seek professional assistance before using an adapter or extension cord. These devices
could interrupt the grounding circuit.
• Ensure that your power supply is set to the correct voltage in your area. If you are not
sure about the voltage of the electrical outlet you are using, contact your local power
company.
• If the power supply is broken, do not try to x it by yourself. Contact a qualied service
technician or your retailer.
Operation safety
• Before installing the motherboard and adding devices on it, carefully read all the manuals
that came with the package.
• Before using the product, ensure all cables are correctly connected and the power
cables are not damaged. If you detect any damage, contact your dealer immediately.
• To avoid short circuits, keep paper clips, screws, and staples away from connectors,
slots, sockets and circuitry.
• Avoid dust, humidity, and temperature extremes. Do not place the product in any area
where it may become wet.
• Place the product on a stable surface.
• If you encounter technical problems with the product, contact a qualied service
technician or your retailer.

vii
About this guide
This user guide contains the information you need when installing and conguring the
motherboard.
How this guide is organized
This guide contains the following parts:
1. Chapter 1: Product Introduction
This chapter describes the features of the motherboard and the new technology it
supports. It includes description of the switches, jumpers, and connectors on the
motherboard.
2. Chapter 2: Basic Installation
This chapter lists the hardware setup procedures that you have to perform when
installing system components.
3. Chapter 3: BIOS Setup
This chapter tells how to change system settings through the BIOS Setup menus.
Detailed descriptions of the BIOS parameters are also provided.
4. Chapter 4: RAID Support
This chapter describes the RAID congurations.
Where to find more information
Refer to the following sources for additional information and for product and software
updates.
1. ASUS website
The ASUS website (www.asus.com) provides updated information on ASUS hardware
and software products.
2. Optional documentation
Your product package may include optional documentation, such as warranty yers
that may have been added by your dealer. These documents are not part of the
standard package.

viii
Conventions used in this guide
To ensure that you perform certain tasks properly, take note of the following symbols used
throughout this manual.
DANGER/WARNING: Information to prevent injury to yourself when trying to
complete a task.
CAUTION: Information to prevent damage to the components when trying to
complete a task.
IMPORTANT: Instructions that you MUST follow to complete a task.
NOTE: Tips and additional information to help you complete a task.
Typography
Bold text Indicates a menu or an item to select.
Italics Used to emphasize a word or a phrase.
<Key> Keys enclosed in the less-than and greater-than sign
means that you must press the enclosed key.
Example: <Enter> means that you must press the Enter or
Return key.
<Key1> + <Key2> + <Key3> If you must press two or more keys simultaneously, the key
names are linked with a plus sign (+).

ix
(continued on the next page)
STRIX X99 GAMING specifications summary
CPU
New Intel®Core™ i7 X-Series Processors on LGA 2011-v3 Socket
Supports 14nm CPU
Supports Intel®Turbo Boost Max Technology 3.0*
* The support of these features depends on the CPU types.
Chipset Intel®X99 Chipset
Memory
8 x DIMM DDR4 max at 128 GB
3333 (O.C.)* / 3300 (O.C.)* / 3000 (O.C.)* / 2800 (O.C.)* /
2666 (O.C.)* / 2400 (O.C.)* / 2133 MHz, non-ECC unbuffered
memory
Quad channel memory architecture
Supports Intel® Extreme Memory Prole (XMP)
* Hyper DIMM support is subject to the physical characteristics of
individual CPUs. Please refer to Memory QVL (Qualified Vendors Lists)
on www.asus.com for details.
Expansion Slots
3 x PCI Express 3.0/2.0 x16 slots
( support x16, x16/x16, x8/x16/x8 mode with 40-LANE CPU;
x16, x16/x8, x8/x8/x8 mode with 28-LANE CPU)*
1 x PCI Express 2.0 x16 slot (max. at x4 mode)**
2 x PCI Express 2.0 x1 slot***
* The PCIEX16_2 slot supports x8 devices only with 28-LANE CPU.
** The PCIEX4_1, PCIEX1_2, and USB3.1_EC1EA2 connectors share
the same bandwidth. By default, the PCIEX4_1 slot and PCIEX1_2
slot automatically run at x1 mode with USB3.1_EC1 and USB3.1_EA2
enabled for best resource optimization.
*** PCIEX1_1 slot shares bandwidth with WI-FI port at back panel.
Multi-GPU Support Supports NVIDIA®3-Way/2-Way SLI®Technology
Supports AMD®3-Way/2-Way CrossFireX™ Technology
Storage
New Intel®Core™ i7 X-Series Processors
- 1 x M.2 Socket 3 with M Key, type 2242/2260/2280/22110 storage
devices support (supports PCIE SSDs only)*
- 1 x U.2 port (supports PCIe 3.0 x4 NVM Express storage)*
* The M.2 slot shares bandwidth with U.2 slot.
Intel® X99 Chipset
- 1 x SATA Express port, compatible with 2 x SATA 6Gb/s ports
- 8 x SATA 6Gb/s ports
- Supports Intel®Smart Response Technology, Intel®Rapid
Recovery Technology*
* These functions will work depending on the CPU installed.
LAN
Intel®I218-V Gigabit LAN-Dual interconnect between the integrated
Media Access Controller (MAC) and physical layer (PHY)
Anti-surge LANGuard
ROG GameFirst technology

x
(continued on the next page)
STRIX X99 GAMING specifications summary
Wireless & Bluetooth
Wi-Fi 802.11 a/b/g/n/ac supports dual frequency band 2.4/5 GHz
with MU-MIMO support
Bluetooth v4.1, 4.0LE, 3.0+HS
Audio
SupremeFX 8-Channel High Definition Audio CODEC
- SupremeFX Shielding Technology
- Dual Headphone Ampliers
- Jack-detection, Multi-streaming, and Front Panel Jack-retasking
Audio Features
- Sonic Radar II
USB
Intel®X99 Chipset - supports ASUS USB 3.0 Boost
- 5 x USB 3.0 ports (1 port at back panel [blue], 4 ports at
mid-board)
- 8 x USB 2.0 ports (4 ports at back panel, 4 ports at mid-board)*
ASMedia®USB 3.0 controller - supports ASUS USB 3.0 Boost
- 3 x USB 3.0 ports at back panel [blue]
ASMedia®USB 3.1 controller - supports ASUS USB 3.1 Boost
- 2 x USB 3.1 ports
(1 x Type-A [red] and 1 x Type-C ports at back panel)**
* 2 x USB 2.0 ports at mid-board share with ROG extension (ROG_EXT)
port.
** USB3.1_EC1 and USB3.1_EA2 ports at back panel will be disabled
when the PCIEX4_1 slot is occupied by a X4 bandwidth device.
ROG Exclusive Features ROG RAMCache
ROG CPU-Z
Special Features
Media Streamer
ASUS Exclusive Features
- Ai Suite 3
- USB 3.1 Boost
- Ai Charger+
- Push Notice
- Disk Unlocker
ASUS EZ DIY
- USB BIOS Flashback
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
- MemOK!
ASUS Q-Design
- Q-Code
- Q-Shield
- Q-Connector
- Q-LED (CPU, DRAM, VGA, Boot Device LED)
- Q-Slot
- Q-DIMM

xi
Back I/O Ports
1 x USB BIOS Flashback button
1 x PS/2 keyboard/mouse combo port
4 x USB 2.0 ports
4 x USB 3.0 ports [blue]
2 x USB 3.1 ports (1 x Type-A [red] and 1 x Type-C ports)
1 x Anti-surge LAN (RJ45) port
1 x ASUS Wi-Fi GO! module (Wi-Fi 802.11 a/b/g/n/ac and
Bluetooth v4.1)
5 x Audio jacks
Internal I/O Ports
2 x USB 3.0 connectors support additional 4 USB 3.0 ports
2 x USB 2.0 connectors support additional 4 USB 2.0 ports (one
connector via ROG_EXT header)
1 x SATA Express connector (compatible with 2 x SATA 6Gb/s
ports)
8 x SATA 6.0 Gb/s connectors
1 x ROG extension (ROG_EXT) header
1 x 4-pin Water pump connector
1 x 4-pin H_AMP fan connector
1 x 4-pin CPU fan connector
1 x 4-pin CPU_OPT fan connector
2 x 4-pin Chassis fan connectors
1 x 5-pin Extension fan connector
1 x 24-pin EATX power connector
1 x 8-pin EATX 12V power connector
1 x 4-pin EATX 12V power connector
1 x Power-on button
1 x Reset button
1 x MemOK! button
1 x M.2 Socket 3 for M Key, type 2242/2260/2280/22110 storage
devices support (supports PCIE SSD only)
1 x U.2 port (supports PCIe 3.0 x4 NVM Express storage)
1 x 5-pin Thunderbolt header for ASUS ThunderboltEX III series
support
1 x Front panel audio connector (AAFP)
1 x COM connector
1 x RGB header
1 x TPM connector
1 x System panel connector
1 x Thermal sensor connector
1 x CPU OverVoltage (OV) header
1 x DirectKey (DRCT) connector
1 x 2-pin Clear CMOS jumper
1 x XMP switch
STRIX X99 GAMING specifications summary
(continued on the next page)

xii
BIOS Features
128 Mb Flash ROM, UEFI AMI BIOS, PnP, WfM 2.0, SM BIOS 3.0,
ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 2, CrashFree BIOS
3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Quick
Note, Last Modied Log, F12 PrintScreen function, F3 Shortcut
function, and ASUS DRAM SPD (Serial Presence Detect) memory
information
Manageability WfM 2.0, WOL by PME, PXE
Software
Drivers
Anti-virus software (OEM version)
ASUS Utilities
Operating System
Windows®10*
Windows®8.1
Windows®7
* 64-bit supported only.
Form Factors ATX Form Factor, 12 in. x 9.6 in. (30.5 cm x 24.4 cm)
STRIX X99 GAMING specifications summary
The specications are subject to change without notice.

xiii
If any of the above items is damaged or missing, contact your retailer.
Package contents
Check your motherboard package for the following items:
Motherboard STRIX X99 GAMING
Cables
2 x 2-in-1 SATA 6 Gb/s cables
1 x SLI®cable
1 x 80 cm RGB LED extension cable
Accessories
1 x I/O Shield
1 x 1-in-1 Q-Connector kit
1 x CPU installation tool for Broadwell-E CPU
1 x ASUS 2T2R dual band Wi-Fi moving antennas
(Wi-Fi 802.11 a/b/g/n/ac compliant)
1 x ROG cable label
1 x ROG fan label
1 x M.2 screw package
1 x Pack of cable ties
1 x Pack of customizable color decals
Application DVD ROG motherboard support DVD
Documentation User guide

xiv
Installation tools and components
The tools and components in the table above are not included in the motherboard package.
PC chassis
Power supply unit
Intel®LGA2011-v3 compatible CPU Fan
Intel®LGA2011-v3 CPU
DIMM
SATA hard disk drive
Graphics card
Philips (cross) screwdriver
SATA optical disc drive (optional)
1 bag of screws

ASUS STRIX X99 GAMING
1-1
Chapter 1
Product Introduction
1
Chapter 1: Product Introduction
1.1 Motherboard overview
1.1.1 Before you proceed
Take note of the following precautions before you install motherboard components or change
any motherboard settings.
• Unplugthepowercordfromthewallsocketbeforetouchinganycomponent.
• Beforehandlingcomponents,useagroundedwriststraportouchasafelygrounded
objectorametalobject,suchasthepowersupplycase,toavoiddamagingthemdue
to static electricity.
• HoldcomponentsbytheedgestoavoidtouchingtheICsonthem.
• Wheneveryouuninstallanycomponent,placeitonagroundedantistaticpadorinthe
bag that came with the component.
• Beforeyouinstallorremoveanycomponent,ensurethattheATXpowersupplyis
switched off or the power cord is detached from the power supply. Failure to do so
maycauseseveredamagetothemotherboard,peripherals,orcomponents.

1-2
Chapter 1: Product Introduction
Chapter 1
Refer to 1.1.9 Internal connectors and 2.3.1 Rear I/O connection for more information
about rear panel connectors and internal connectors.
1.1.2 Motherboard layout

ASUS STRIX X99 GAMING
1-3
Chapter 1
Layout contents
Connectors/Jumpers/Buttons and switches/Slots Page
1. DDR4DIMMslots 1-5
2. CPU,CPUoptional,waterpump,highamp,extension,andchassisfan
connectors(4-pinCPU_FAN;4-pinCPU_OPT;4-pinW_PUMP;4-pin
H_AMP_FAN;5-pinEXT_FAN;4-pinCHA_FAN1-2)
1-26
3. LGA2011-v3CPUsocket 1-4
4. ATXpowerconnectors(24-pinEATXPWR;8-pinEATX12V_1;4-pin
EATX12V_2)
1-27
5. MemOK!button 1-11
6. Intel®SerialATA6Gb/sconnectors(7-pinSATA6G_12,SATA6G_34,
SATA6G_56/SATAEXPRESS,SATA6G_78,SATA6G_910)
1-22
7. USB3.0connectors(20-1pinUSB3_12,USB3_34) 1-24
8. M.2Socket3 1-23
9. CPUOverVoltagejumper(3-pinCPU_OV) 1-14
10. U.2connector 1-23
11. EZXMPswitch 1-12
12. Thunderboltheader(5-pinTB_HEADER) 1-30
13. ClearRTCRAMjumper(2-pinCLRTC) 1-13
14. Systempanelconnector(20-3pinPANEL) 1-28
15. DirectKeyconnector(2-pinDRCT) 1-29
16. USB2.0connectors(10-1pinUSB1112,USB1314) 1-25
17. ROGExtensionconnector(18-1pinROG_EXT) 1-32
18. T_Sensorconnector(2-pinT_SENSOR1) 1-30
19. TPMconnector(14-1pinTPM) 1-29
20. Q-CodeLEDs 1-17
21. Reset button 1-10
22. Power-onbutton 1-10
23. RGBheader(4-pinRGB_HEADER) 1-31
24. Serialportconnector(10-1pinCOM) 1-32
25. Frontpanelaudioconnector(10-1pinAAFP) 1-33

1-4
Chapter 1: Product Introduction
Chapter 1
1.1.3 Central Processing Unit (CPU)
ThemotherboardcomeswithasurfacemountLGA2011-v3socketdesignedforIntel®Core™
i7 processors.
• EnsurethatallpowercablesareunpluggedbeforeinstallingtheCPU.
• Uponpurchaseofthemotherboard,ensurethatthePnPcapisonthesocketand
thesocketcontactsarenotbent.ContactyourretailerimmediatelyifthePnPcap
ismissing,orifyouseeanydamagetothePnPcap/socketcontacts/motherboard
components.ASUSwillshoulderthecostofrepaironlyifthedamageisshipment/
transit-related.
• Keepthecapafterinstallingthemotherboard.ASUSwillprocessReturnMerchandise
Authorization(RMA)requestsonlyifthemotherboardcomeswiththecaponthe
LGA2011-v3socket.
• Theproductwarrantydoesnotcoverdamagetothesocketcontactsresultingfrom
incorrectCPUinstallation/removal,ormisplacement/loss/incorrectremovalofthePnP
cap.

ASUS STRIX X99 GAMING
1-5
Chapter 1
Recommended memory configurations
1.1.4 System memory
Themotherboardcomeswitheight(8)DDR4(DoubleDataRate4)QuadInlineMemory
Modules(DIMM)slots.
ADDR4moduleisnotcheddifferentlyfromaDDR,DDR2,orDDR3module.DONOT
installaDDR,DDR2,orDDR3memorymoduletotheDDR4slot.
EnsuretoinstallatleastoneofthememorymodulesintotheA1*/B1*/C1*/D1*slot.

1-6
Chapter 1: Product Introduction
Chapter 1
• Side(s):SS-Single-sided DS-Double-sidedDIMMsupport:
 Supportsone(1)moduleinsertedintoanyslotassingle-channelmemory
conguration.WesuggestthatyouinstallthemoduleintoD1*slot.
 Supportstwo(2)modulesinsertedintoonepairoftheslotsasquad-channel
memoryconguration.WesuggestthatyouinstallthemodulesintoslotsB1*and
D1*for better compatibility.
 Supportsfour(4)modulesinsertedintotwopairsoftheslotsasquad-channel
memoryconguration.WesuggestthatyouinstallthemodulesintoslotsA1*,
B1*,C1*,andD1*for better compatibility.
 Supportssix(6)modulesinsertedintotheslotsasthreepairsofquad-channel
memoryconguration.WesuggestthatyouinstallthemodulesintoslotsA1*,
B1*,B2*,C1*,D1*,andD2*for better compatibility.
 Supportseight(8)modulesinsertedintoallslotsasfully-loadedquad-channel
memorycongurations.
• ASUSexclusivelyprovideshyperDIMMsupportfunction.
• HyperDIMMsupportissubjecttothephysicalcharacteristicsofindividualCPUs.Load
theX.M.P.orD.O.C.P.settingsintheBIOSforthehyperDIMMsupport.
• VisittheASUSwebsiteforthelatestQVL.
